ASKO HG1666AD, HG1666SD, HG1776AD, HG1986AD Installation Guide
Installation instructions
Gas hobs
05
E
E/F
C
D
G
B
A
F
H
A
B
C
D
A (mm) B (mm) C (mm) D (mm)
HG16 min. 650 min. 600 min. 450 min. 120
HG17 min. 650 min. 750 min. 450 min. 120
HG19 min. 650 min. 900 min. 450 min. 120
A (>mm) B (mm) C (mm) D (>mm) E (>mm) F (>mm) G H
HG16 600 560 490 60 50 50 55 100
HG17 600 560 490 60 50 50 55 100
HG19 600 860 490 60 50 50 55 100
The gas connection must comply with national and local regulations.
The hotplate can be connected with rigid pipe as specified in
AS/NZS 5601.1current edition.
When the appliance is connected with a hose assembly,
the supply point shall be accessible with the appliance installed.
240 V - 50 Hz - max. 20 W
This appliance must be earthed
The electrical connection must comply with national and local regulations.
1/2” ISO 228 / 1/2" ISO 7-1
Free space around appliance
The fitting of the appliance should only be carried out by a authorised person/licensed gasfitter. Please read the safety regulations.
See the data plate for information regarding the total gas consumption, gas type and gas pressure.
Rangehoods and exhaust fans shall be
installed in accordance with
manufacturers instructions.
For an overhead exhaust fan A>750 mm!
Gas connection
Important information
Pictograms used
Electrical connection
A
B
C
D
A (mm) B (mm) C (mm) D (mm)
HG16 600 526 48 520
HG17 750 526 48 594
HG19 900 526 48 514
y
y
x
x
>60º C
<60º C
oven
oven
Accessibility!
Y:
metal
Gas supply valve
shall be accessible
X:
safety hose
Gas supply valve
shall be accessible
Preparations for installation
en (04-16)
Injector burner
(mm)
Adj. Screw
(mm)
Burner rate
(MJ/h)
Gas pressure
(kPa)
Natural gas (NG)
Small
0.90
0.45
4.00
Medium
1.17
0.60
6.70
Large
1.31
0.65
8.60
Wok
1.60 + 0.65
0.60
15.70
ULPG
Small
0.46
0.26
2.80
Medium
0.60
0.30
4.90
Large
0.72
0.36
7.10
Wok
0.93 + 0.40
0.40
14.50
563618 / VER 1 / 18-02-2016
Check that the connections are gastight.
Test the working of the appliance!
Check the ignition of all burners individually and combined.
1.0
2.75
05
Worktop
C
C
1/2“ ISO 7-1
1/2“ ISO 228
05
Gas connection
PTFE tape
Fitting of appliance regulator
for Natural gas or test point
adaptor for LPG. Check and set
the gas pressure with appliance
operating!
05
Gas Burner
05
Placing sealing tape
For stainless steel drip tray
Building in
Connecting and testing
Simmer Normal Large Wok
HG16 1 2 - 1
HG17 1 2 1 1
HG19 2 2 2 -
