Q-POWER
Series
CAMCO Q-Power Series is a new range of 4 channel,
high output power amplifiers. The Q-Power 6 and the
Q-Power 10 have been designed to provide that, Powerful Pure Sonic Performance which is now so synonymous with the CAMCO brand name.
New Technology
The CAMCO Q-Power 10 introduces new class D amplifier
technology offering smooth and responsive handling with massive
power output while maintaining CAMCO’s famous sonic integrity,
the CAMCO Q-Power 6 uses class H technology, both models
benefiting from the latest advances in CAMCO’s SMPS technology,
the resulting high power, lightweight units are at home in all
professional applications.
Designed for flexibility of Use
With the introduction of the Q-Power series CAMCO aim to deliver
simple, pure and reliable power for applications where cost and
ease of use are paramount without lose of integrity.
Straight Forward Approach
CAMCO have paid attention to market requirements for a straight
forward approach. In introducing the Q-Power Series CAMCO
identified, key elements, such as power output, loading, AC power
supply flexibility and connectivity. The result is two, outstanding
power output options, across four channels, in a 19” 2 RU rugged
case design, suitable for professional Installations, Theatre and
Live Sound applications.
Features
§ Dual Voltage SMPS with automatic voltage selection for 120 V
/ 230 V operation
§ Two temperature controlled cooling fans
§ Two switchable peak-limiter for channel A+B and C+D
§ 100 V/70 V (Q-Power 10), 70 V (Q-Power 6) line operation
§ CAMCO Switch Mode Power Supply technology
§ 2500 W (Q-Power 10) / 1500 W (Q-Power 6) max RMS output at
4 Ω per channel
6 Years Warranty
CAMCO amplifiers renowned reliability is backed up by 6 years
warranty from date of first purchase.
Along with ABCD channel identification, clear LED status indicators above each potentiometer
indicate; Amp on, Signal present
(this is red if in protect mode),
Output current and clip status, all
information is clear and precise. A
gain control security cover is also
provided.
Flexible connectivity as standard;
the input section is supplied with
both XLR and Phoenix connectors,
while the output section is supplied with both Speakon and Barrier Strip connectors with cover.
OFF
SLOW
FAST
CLIP LIMITER
26 dB
1,4 V
32 dB
26 dB
1,4 V
32 dB
DC BA
:LEDOM
:PMI/HCREPRWPTUPTUO
YNAMREGNIEDAM
:.ON.RES
D ABC
Do not remove this cover or
connect any loudspeaker
cables while the amplifier is
running!
See the manual for detailed
cabling instructions
Warning! Risk of
electrical shock
.
D C B A
D C B A
:LEDOM
:PMI/HCREPRWPTUPTUO
YNAMREGNIEDAM
:.ON.RES
Gain Setting
(26 dB, 32 dB, 1,4 V)
Specifications:
Power per channel
All channels driven
@ 1kHz, THD < 1%
Power per channel
Single channel driven
@ 1kHz, THD < 1%
Channel A & B output
Channel C & D output
Channel D, C, B & A output (barrier strip)
Q-Power 6
Input Channel C
Input Channel D
Input Channel D & C
Clip Limiter Channel D & C
(Off, On)
Clip Limiter Channel B & A
Q-Power 10
16 Ω 470 W 620 W
8 Ω 800 W 1100 W
4 Ω 1000 W 1800 W
4 Ω Max RMS 1500 W 2500 W
70 V line operation 950 W 1600 W
100 V line operation N/A 625 W
16 Ω 480 W 620 W
8 Ω 960 W 1350 W
4 Ω 1500 W 2400 W
4 Ω Max RMS 1600 W 2600 W
Input Channel B
Input Channel A
Input Channel B & A
(Off, On)
No. of channels
Max. Output Voltage
Output Circuitry
Signal To Noise-Ratio
20 Hz - 20 kHz, 8 Ω load
THD+N (typical)
20 Hz - 20 kHz, 8 Ω load,
6 dB below rated power
SMPTE 4:1 (typical)
60 Hz + 7kHz, 8 Ω load
8 dB below rated power
Damping Factor
8 Ω load, 1 kHz and below
Net Weight
Shipping Weight
Frequency Response
8 Ω load, 1 dB below rated power
Input Impedance
Input Gain
20 Hz - 20 kHz ± 0,15 dB
15 kΩ balanced
selectable: 26 dB, 32 dB or 1,4 V input sensitivity
inrush-current limitation, protection circuits against power on/off transients, temperature monitoring of
Protection Circuits
transformers and heat-sinks, output DC protection, power transistor control, temperature dependent SOA
protection, intelligent mains fuse protection
Limiter
Fan
Indicators
Input Connectors
Output Connectors
Operation Voltage
Dimensions (WxHxD)
Shipping Dim. (WxHxD)
Accessories included
Specifications subject to technical alterations without prior notice.
two switchable peak-limiter for channel A+B and C+D respectively
2 temperature dependent speed-controlled axial fans
LED’s for ON, SIGNAL/PROTECT, CLIP, Output Current
3-pin XLR, male and female per channel, pin 2 = in phase / Phoenix Connectors, pin 1 = in phase, pin 2 = GND
Two 4-pole SPEAKON connectors / Barrier Strip with protection cover
Dual Voltage SMPS with automatic voltage selection for 120 V / 230 V operation
483 x 88,9 x 419 mm / 19 x 3,5 x 16,5 inches (19”, 2U)
600 x 105 x 527 mm / 23,3 x 4,1 x 20,7 inches
Gain pot security cover
4 4
125Vp / 250V
pp
145Vp / 290V
Class H Class D
> 115 dB (A-weighted)
> 112 dB (unweighted)
> 115 dB (A-weighted)
> 112 dB (unweighted)
< 0,01 % < 0,01 %
< 0,01 % < 0,02 %
> 350 > 600
10,6 kg / 23,4 lbs 11,5 kg / 25,4 lbs
12,6 kg / 27,8 lbs 13,5 kg / 29,8 lbs
pp
