Ashly PE Amplifier

PNE-C2 Cobranet Module

Field Installation

Remove Four Mounting Screws

aiHPf ^ ^ ^

. - •• • " J

TiT i it rv»- /

1) Remove the four screws

from the standard input as shown.

2) Carefully pull out the installed
standard input assembly, only as
far as shown. Note the ribbon
cable shown furthest left that is

labelled "ST992". Gently remove

this and the other two ribbon cables.

3) The PNE-C2 plugs are in the

same general location as the three

i * I P i

standard input plugs. Plug in the
cable "ST992" first. Be sure to fully
seat each connector, applying
even pressure across the top.

Do not stress the wires.

4) Gently guide the PNE-C2 module
back into the amplifier, and fasten

the four mounting screws.
