DATA SHEET
ARUBA 570 SERIES
WIRELESS ACCESS POINTS
High performance Wi-Fi 6 (802.11ax) for
outdoor environments
Weatherproof and temperature hardened, Aruba 570 Series
access points deliver the highest Wi-Fi 6 performance in
outdoor and environmentally challenging locations. The
high-performance and high power 570 Series APs deliver
maximum capacity and range. It delivers 4x4:4SS MU-MIMO
capability, Aruba’s advanced ClientMatch and integrated
Bluetooth to enable Aruba location services.
Purpose-built to survive in the harshest outdoor
environments, 570 Series APs withstand exposure to
extreme high and low temperatures, persistent moisture
and precipitation, and are fully sealed to keep out airborne
contaminants. All electrical interfaces include industrial
strength surge protection.
Aruba Wi-Fi 6 access points provide high-performance
connectivity in dense mobile and IoT environments. With
maximum aggregate on air data rates of 3 Gbps (HE80/HE40),
the 570 Series APs deliver the speed and reliability needed
for demanding environments.
Advantages of OFDMA
This capability allows Aruba Wi-Fi 6 APs to handle multiple
Wi-Fi 6 enabled clients simultaneously on a single radio.
Channel utilization is optimized per transaction by matching
allocated bandwidth in a channel to the oered user load.
These sub divisions of the channel are referred to as
Resource Units (RU).
Multi-User MIMO (MU-MIMO)
The 570 Series APs support downlink MU-MIMO similar to
Wi-Fi 5 (802.11ac Wave 2) APs. With the introduction OFDMA
in Wi-Fi 6, the overhead for this capability is reduced and
MU-MIMO eectiveness is substantially improved for large
client counts.
INCREDIBLE EFFICIENCY
The 570 Series APs are designed to optimize user experience
by maximizing Wi-Fi eciency and dramatically reducing
airtime contention between clients.
Features include Uplink and Downlink Orthogonal Frequency
Division Multiple Access (OFDMA), Downlink Multi-User MIMO
(MU-MIMO) and cellular co-location. With up to 4spatial
stream and 160 MHz channel capability, the 570Series
provides groundbreaking wireless capabilities for any
application.
Read the Multi-User 802.11ax white paper for further
information.
Wi-Fi 6 and MU-MIMO aware client optimization
Aruba’s patented AI powered ClientMatch technology ensures
that all clients are attached to their best serving Access Point.
Session metrics, network metrics, applications and client type
are used to identify and maintain the best connection.
Advanced Cellular Coexistence (ACC)
The ACC feature uses built in ltering to automatically
minimize the impact of interference of high power cellular
base stations, in building distributed antenna systems as well
as small cell and femtocell equipment.
Intelligent Power Monitoring (IPM)
Aruba APs continuously monitor and report hardware energy
consumption. APs can be congured to enable or disable
capabilities based on the available PoE power – ideal when
wired switches have exhausted their power budget.
DATA SHEET
ARUBA 570 SERIES WIRELESS ACCESS POINTS
IOT PLATFORM CAPABILITIES
Aruba Wi-Fi 6 APs include an integrated Bluetooth 5 and
802.15.4 radio (for Zigbee support) to simplify deploying and
managing IoT-based location services, asset tracking services,
security solutions and IoT sensors. This allow organizations to
leverage the 570 Series as an IoT platform, which eliminates
the need for an overlay infrastructure and additional IT
resources.
Target Wake Time (T WT)
Ideal for IoT solutions that communicate infrequently,
this Wi-Fi 6 capability allows IoT devices to use 802.11ax
protocol. TWT coordinates with client devices to allow them
to sleep for extended periods and use shorter wake times
to communicate before returning to sleep. This substantially
extends the useful operating life of Wi-Fi 6 based battery
powered sensors.
ARUBA SECURE INFRASTRUCTURE
The Aruba 570 Series is an integral part of Aruba’s zero trust
security approach to help protect user authentication and
wireless trac. Select capabilities include:
Trusted Platform Module (TPM)
For enhanced device assurance, all Aruba APs have an
installed TPM for secure storage of credentials, keys and boot
code.
SIMPLE AND SECURE ACCESS
To simplify policy enforcement, the Aruba 570 Series uses
Aruba’s Policy Enforcement Firewall (PEF) to encapsulate all
trac from the AP to the Mobility Controller (gateway) for
end-to-end encryption and inspection. Policies are applied
based on context including user role, device type, application,
and location. This reduces the manual conguration of SSIDs,
VLANs, and ACLs. PEF also serves as the underlying technology
for Aruba Dynamic Segmentation.
HIGH DENSITY CONNECTIVITY
Each 570 Series AP provide connectivity for a maximum of 512
associated clients per radio (1024 total).
Flexible Operation and Management
A unique feature of Aruba APs is the ability to operate in either
controller-less or controller-based mode.
WPA3 and Enhanced Open
With the introduction of WPA3 and Enhanced Open, a Wi-Fi 6
certied client will never send unencrypted trac over the air.
Even with an open authenticated network, Enhanced Open
still provides strong encryption over the air.
In all Wi-Fi 6 user sessions, each user is uniquely encrypted
and if they disconnect and reconnect, the encryption changes
from session to session.
WPA 2-MPSK
MPSK enables simpler passkey management for WPA2
devices – should the Wi-Fi password on one device change, no
additional changes are needed for other devices. This feature
is enabled when networks are deployed with ClearPass Policy
Manager.
VPN Tunnels
In Remote AP (RAP) and IAP-VPN deployments, the Aruba 570
Series can be used to establish a secure SSL/IPSec VPN tunnel
to a Gateway or Mobility Controller that is congured as a VPN
concentrator.
Controller-less (Instant) Mode
In controller-less mode, one AP serves as a virtual controller
for the entire network. Learn more about Instant mode in this
technology brief.
Mobility Controller Mode
For optimized network performance, roaming and security,
APs tunnel all trac to a mobility controller for central
management of trac forwarding, segmentation, encryption,
and policy enforcement. Learn more in the ArubaOS
datasheet.
Management Options
Available management choices include Aruba Central (cloud-
based) or Aruba AirWave (multi-vendor, on prem) solutions.
For large installations across multiple sites, Aruba APs can be
shipped and activated with Zero Touch Provisioning through
Aruba Central or AirWave. This reduces deployment time,
centralizes conguration, and provides inventory visibility.
2
DATA SHEET
ARUBA 570 SERIES WIRELESS ACCESS POINTS
ADDITIONAL WI-FI FEATURES
Transmit Beamforming (TxBF)
Increased signal reliability and range
Passpoint Release 2
Seamless cellular-to-Wi-Fi carryover for guests
Dynamic Frequency Selection (DFS)
Optimized use of available RF spectrum
Maximal Ratio Combining (MRC)
Improved receiver performance for multi antenna access
points.
Cyclic Delay/Shift Diversity (CDD/CSD)
Enable use of multiple transmit antennas
Space-Time Block Coding (STBC)
Increased connection robustness
Low-Density Parity Check (LDPC)
High performance error detection and correction coding for
enhanced receiver performance.
AP-570 SERIES SPECIFICATIONS
Hardware Variants
• AP-574
- 5 GHz: Four Nf connectors for external antenna
operation
- 2.4 GHz Two Nf connectors for external antenna
operation
- BLE/Zigbee: Integrated omnidirectional antenna and
peak gain of 4.2dBi
• AP-575
- Built in Omni Directional Antennas
- 5 GHz Antennas 5dBi
- 2.4GHz Antennas 3.4dBi
- BLE/Zigbee: Integrated omnidirectional antenna and the
peak gain of 6dBi
• AP-577
- Built in 90°H x 90°V Directional Antennas
- 5 GHz Antennas 5.6dBi
- 2.4 GHz Antennas 6.8dBi
- BLE/Zigbee: Integrated omnidirectional antennas with
peak gain of 8.4dBi
Wi-Fi Radio Specications
• AP type: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz 4x4
MIMO and 2.4 GHz 2x2 MIMO
• Software-congurable dual radio supports 5 GHz (Radio 0)
and 2.4 GHz (Radio 1)
5 GHz:
• Four spatial stream Single User (SU) MIMO for up to 4.8
Gbps wireless data rate to individual 4SS HE160 Wi-Fi 6
client device (max)
• Two spatial stream Single User (SU) MIMO for up to 1.2
Gbps wireless data rate to individual 2SS HE80 Wi-Fi 6
client device (typical)
• Four spatial stream Multi User (MU) MIMO for up to
4.8 Gbps wireless data rate to up to four 1SS or two
2SS HE160 Wi-Fi 6 DL-MU-MIMO capable client devices
simultaneously (max)
• Four spatial stream Multi User (MU) MIMO for up to
2.4 Gbps wireless data rate to up to four 1SS or two
2SS HE80 Wi-Fi 6 DL-MU-MIMO capable client devices
simultaneously (typical)
2.4 GHz
• Two spatial stream Single User (SU) MIMO for up to
575Mbps wireless data rate to individual 2SS HE40 Wi-Fi
6 client device (max)
• Two spatial stream Single User (SU) MIMO for up to
287Mbps wireless data rate to individual 2SS HE20 Wi-Fi
6 client device (typical)
• Two spatial stream Multi User (MU) MIMO for up to 575
Mbps wireless data rate to up to two 1SS HE40 Wi-Fi 6 DL-
MU-MIMO capable client devices simultaneously (max)
• Two spatial stream Multi User (MU) MIMO for up to 287
Mbps wireless data rate to up to two 1SS HE20 Wi-Fi 6 DL-
MU-MIMO capable client devices simultaneously (typical)
• Support for up to 512 associated client devices per radio,
and up to 16 BSSIDs per radio
• Supported frequency bands (country-specic restrictions
apply):
- 2.400 to 2.4835 GHz
- 5.150 to 5.250 GHz
- 5.250 to 5.350 GHz
- 5.470 to 5.725 GHz
- 5.725 to 5.850 GHz
- 5.825 to 5.875 GHz
• Available channels: Dependent on congured regulatory
domain.
• Dynamic frequency selection (DFS) optimizes the use of
available RF spectrum.
• Supported radio technologies:
3
DATA SHEET
ARUBA 570 SERIES WIRELESS ACCESS POINTS
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division
multiplexing (OFDM)
- 802.11ax: Orthogonal frequency-division multiple access
(OFDMA) with up to 16 resource units (RU)
• Supported modulation types:
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
(proprietary extension)
- 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM,
1024 QAM (proprietary extension)
- 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM,
1024 QAM
• 802.11n high-throughput (HT) support: HT 20/40
• 802.11ac very high throughput (VHT) support: VHT
20/40/80/160
• 802.11ax high eciency (HE) support: HE20/40/80/160
• Supported data rates (Mbps):
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n (2.4GHz): 6.5 to 300 (MCS0 to MCS15, HT20 to
HT40)
- 802.11n (5GHz): 6.5 to 600 (MCS0 to MCS31, HT20 to
HT40)
- 802.11ac: (5 GHz): 6.5 to 3,467 (MCS0 to MCS9, NSS = 1
to 4 for VHT20 to VHT160)
- 802.11ax (2.4GHz): 8.6 to 574 (MCS0 to MCS11, NSS = 1
to 2, HE20 to HE40)
- 802.11ax (5GHz): 8.6 to 4803 (MCS0 to MCS11, NSS = 1
to 4, HE20 to HE160)
• 802.11n/ac packet aggregation: A-MPDU, A-MSDU
• Transmit power: Congurable in increments of 0.5 dBm
• Maximum (conducted) transmit power (limited by local
regulatory requirements):
- 2.4 GHz band: +22 dBm per chain, +25dBm aggregate
(2x2)
- 5 GHz band: +22 dBm per chain, +28dBm aggregate
(4x4)
- Note: conducted transmit power levels exclude
antennagain.
• Maximum EIRP (limited by local regulatory requirements):
- 2.4 GHz band:
• 574: 25 + Antenna Gain + TxBF Gain
• 575: 29.0 dBm EIRP
• 577: 34.4 dBm EIRP
- 5 GHz band:
• 574: 28 + Antenna Gain + TxBF Gain
- 575: 32.6 dBm EIRP
- 577: 36 dBm EIRP
• Advanced Cellular Coexistence (ACC) minimizes
interference from cellular networks.
• Maximum ratio combining (MRC) for improved receiver
performance.
• Cyclic delay/shift diversity (CDD/CSD) to enable the use of
multiple transmit antennas
• Short guard interval for 20-MHz, 40-MHz, 80-MHz and
160-MHz channels.
• Space-time block coding (STBC) for increased range and
improved reception.
• Low-density parity check (LDPC) for high-eciency error
correction and increased throughput.
• Transmit beam-forming (TxBF) for increased signal
reliability and range.
POWER
• Maximum (worst-case) power consumption:
- POE powered (dual ports): 32.0W
- POE powered (single port, full function): 26.1W
• Maximum (worst-case) power consumption in idle mode:
14.0W (single POE) or 16.0W (dual POE)
• Maximum (worst-case) power consumption in deep-sleep
mode: 2.9W (single POE) or 3.9W (dual POE)
• The AP supports Power over Ethernet (POE; on port E0
and/or E1)
• When POE power is supplied to both Ethernet ports,
the AP can be congured to combine or prioritize power
sources
• Power sources are sold separately; see the ordering
Information section below for details
• When powered by 1x 802.3at (class 4) POE and with
the IPM feature disabled, the AP will disable the other
Ethernet port. In the same conguration but with IPM
enabled, the AP will start up in unrestricted mode, but
may dynamically apply restrictions depending on the POE
budget and actual power. The feature restrictions and
order can be programmed.
• Operating the AP with single or dual 802.3af (class 3 or
lower) POE source is not supported.
ADDITIONAL INTERFACES
• E0: HPE SmartRate port (RJ-45)
- Auto-sensing link speed (100/1000/2500BASE-T) and
MDI/MDX
4
DATA SHEET
ARUBA 570 SERIES WIRELESS ACCESS POINTS
- 2.5Gbps speed complies with NBase-T and 802.3bz
specications
- PoE-PD: 48Vdc (nominal) 802.3at/bt (Class 4 or higher)
- 802.3az Energy Ecient Ethernet (EEE)
• E1: 100/1000BASE-T (RJ-45)
- Auto-sensing link speed and MDI/MDX
- 802.3az Energy Ecient Ethernet (EEE)
- PoE-PD: 48Vdc (nominal) 802.3at/bt (Class 4 or higher)
• Link Aggregation (LACP) support between both network
ports for redundancy and increased capacity
• Bluetooth 5 and 802.15.4 radio
- 2.4 GHz
- Bluetooth 5: up to 8dBm transmit power and -95dBm
receive sensitivity
- Zigbee: up to 8 dBm transmit power and -97dBm receive
sensitivity
- Up to 4dBm transmit power (class 2) and -91 dBm
receive sensitivity
• Visual indicator (multi-color LED): For system and radio
status
• Reset button: Factory reset (during device power up)
• USB-C console interface
MOUNTING
• AP-270-MNT-V1
• AP-270-MNT-V2
• AP-270-MNT-H1
• AP-270-MNT-H2
MECHANICAL
AP-574
• Dimensions/weight (excluding mount):
- 24 cm (W) x 24 cm (D) x 19 cm (H)/
9.4” (W) x 9.4” (D) x 7.5” (H)
- 2.7kg/6.0lbs
AP-575
• Dimensions/weight (excluding mount):
- 24 cm (W) x 24 cm (D) x 27 cm (H)/
9.4” (W) x 9.4” (D) x 10.6” (H)
- 2.5kg/5.6lbs
AP-577
• Dimensions/weight (excluding mount):
- 23 cm (W) x 22 cm (D) x 14 cm (H)
- 9.0” (W) x 8.7” (D) x 5.6” (H)
- 2.1 kg/4.6 lbs
ENVIRONMENTAL
• Operating:
- Temperature: -40° C to +65° C (-40° F to +149° F) with
full solar loading
- Humidity: 5% to 93% non-condensing internal
- Rated for operation in all weather conditions
• Storage and transportation:
- Temperature: -40° C to +70° C (-40° F to +158° F)
• Operating Altitude: 3,000 m
• Water and Dust
- IP66/67
• Salt Tolerance
- Tested to ASTM B117-07A Salt Spray 200hrs
• Wind Survival: Up to 165 Mph
• Shock and Vibration ETSI 300-19-2-4
REGULATORY
• FCC/ISED
• CE Marked
• RED Directive 2014/53/EU
• EMC Directive 2014/30/EU
• Low Voltage Directive 2014/35/EU
• UL/IEC/EN 60950
• EN 60601-1-1, EN60601-1-2
For more country-specic regulatory information and
approvals, please see your Aruba representative.
REGULATORY MODEL NUMBER
• AP-574: APEX0574
• AP-575: APEX0575
• AP-577: APEX0577
CERTIFICATIONS
• CB Scheme Safety, cTUVus
• UL2043 plenum rating
• Wi-Fi Alliance certied 802.11a/b/g/n/
• Wi-Fi CERTIFIED™ 6 (802.11ax)
• Wi-Fi CERTIFIED™ ac (with Wave 2 features)
• Passpoint® (Release 2) with ArubaOS and Instant
WARRANTY
• Limited Lifetime Warranty
MINIMUM OPERATING SYSTEM SOFTWARE
• ArubaOS & Aruba InstantOS 8.7.0.0
5
RF PERFORMANCE TABLE
DATA SHEET
ARUBA 570 SERIES WIRELESS ACCESS POINTS
Maximum transmit power (dBm)
per transmit chain
2.4GHz, 802.11b
1 Mbps 22 -97
11 Mbps 22 -89
2.4GHz, 802.11g
6 Mbps 22 -94
54 Mbps 20 -76
2.4GHz, 802.11n/ac HT20
MCS0 22 -93
MCS8 19 -72
2.4GHz, 802.11ax HE20
MCS0 22 -93
MCS11 17 -62
5GHz, 802.11a
6 Mbps 22 -95
54 Mbps 20 -76
5GHz, 802.11n/ac HT20/VHT20
MCS0 22 -94
MCS8 19 -72
5GHz, 802.11n/ac HT40/VHT40
MCS0 22 -92
MCS9 19 -68
5GHz, 802.11ac VHT80
MCS0 22 -90
MCS9 19 -65
5GHz, 802.11ac VHT160
MCS0 22 -84
MCS9 19 -59
5GHz, 802.11ax HE20
MCS0 22 -94
MCS11 17 -62
5GHz, 802.11ax HE40
MCS0 22 -91
MCS11 17 -60
5GHz, 802.11ax HE80
MCS0 22 -87
MCS11 17 -57
5GHz, 802.11ax HE160
MCS0 22 -85
MCS11 17 -53
Maximum capability of the hardware provided (excluding antenna gain). Maximum transmit power is limited by local regulatory settings.
Receiver sensitivity (dBm)
per receive chain
6
DATA SHEET
ARUBA 570 SERIES WIRELESS ACCESS POINTS
ORDERING INFORMATION
Part Number Description
AP-570 Series Unied Outdoor Access Points
R4H09A Aruba AP-574 (EG) 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H10A Aruba AP-574 (IL) 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H11A Aruba AP-574 (JP) 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H12A Aruba AP-574 (RW) 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H13A Aruba AP-574 (US) 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H14A Aruba AP-575 (EG) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H15A Aruba AP-575 (IL) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H16A Aruba AP-575 (JP) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H17A Aruba AP-575 (RW) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H18A Aruba AP-575 (US) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H19A Aruba AP-577 (EG) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Directional Antenna Outdoor AP
R4H20A Aruba AP-577 (IL) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Directional Antenna Outdoor AP
R4H21A Aruba AP-577 (JP) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Directional Antenna Outdoor AP
R4H22A Aruba AP-577 (RW) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Directional Antenna Outdoor AP
R4H23A Aruba AP-577 (US) 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Directional Antenna Outdoor AP
AP-570 Series Unied Outdoor Access Points FIPS/TAA
R4H24A Aruba AP-574 (EG) TAA 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H25A Aruba AP-574 (IL) TAA 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H26A Aruba AP-574 (JP) TAA 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H27A Aruba AP-574 (RW) TAA 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H28A Aruba AP-574 (US) TAA 802.11ax 2x2:2/4x4:4 Dual Radio 6xNf Connectorized Outdoor AP
R4H29A Aruba AP-575 (EG) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H30A Aruba AP-575 (IL) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H31A Aruba AP-575 (JP) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H32A Aruba AP-575 (RW) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H33A Aruba AP-575 (US) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integrated Omni Antenna Outdoor AP
R4H34A Aruba AP-577 (EG) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integ Directional Antenna Outdoor AP
R4H35A Aruba AP-577 (IL) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integ Directional Antenna Outdoor AP
R4H36A Aruba AP-577 (JP) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integ Directional Antenna Outdoor AP
R4H37A Aruba AP-577 (RW) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integ Directional Antenna Outdoor AP
R4H38A Aruba AP-577 (US) TAA 802.11ax 2x2:2/4x4:4 Dual Radio Integ Directional Antenna Outdoor AP
Refer to the ordering guide for more information.
© Copyright 2020 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without
notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
DS_Aruba570Series_SK_042720 a00096370enw
Contact Us Share
7
Loading...
