DATA SHEET
ARUBA 310 SERIES
ACCESS POINTS
High-performance 802.11ac Wave 2
The Aruba 310 Series access points deliver high performance and superb user experience for mobile devices, Internet of Things (IoT) devices, and applications in dense office environments.
Featuring the 4x4:4SS MU-MIMO capability, advanced Aruba ClientMatch radio management, and Aruba Beacon technologies, the 310 Series enables an all-wireless digital work environment in a cost-effective manner.
With a maximum concurrent data rate of 1,733 Mbps in the 5 GHz band and 400 Mbps in the 2.4 GHz band (for an
aggregate peak data rate of 2.1 Gbps), the 310 Series Access
Points can quickly add required capacities to your existing or new wireless networks. The mid-range 310 Series, with its single gigabit Ethernet uplink, is ideal for high device density environments, such as schools, retail branches, hotels and enterprise offices, where the organization is cost sensitive.
The high performance and high density 802.11ac 310 Series supports 160 MHz channel bandwidth (VHT160), multi-user
MIMO (MU-MIMO) and 4 spatial streams (4SS). It provides simultaneous data transmission to multiple devices, maximizing data throughput and improving network efficiency.
The 310 Series includes the enhanced ClientMatch technology that extends the client steering technology with MU-MIMO client awareness. It automatically identifies MU-MIMO capable mobile devices and steers those devices to the closest
MU-MIMO capable Aruba access point. By grouping
MU-MIMO capable mobile devices together, the network starts taking advantage of the simultaneous transmission to these devices, increasing its overall capacity. These dynamic roaming policies that are based on device types, help users achieve the best WLAN performance in a mixed device environment during the technology transition period.
The 310 Series also has an integrated Bluetooth Aruba
Beacon that simplifies the remote management of a network of large-scale battery-powered Aruba beacons while also providing advanced location and indoor way finding, and proximity-based push notification capabilities. It enables businesses to leverage mobility context to develop applications that will deliver an enhanced user experience and increase the value of the wireless network
for organizations.
UNIQUE BENEFITS
• Dual Radio 802.11ac access point with Multi-User MIMO
--Supports up to 1,733Mbps in the 5GHz band (with 4SS/VHT80 or 2SS/VHT160 clients) and up to 400 Mbps in the 2.4 GHz band (with 2SS/VHT40 clients).
• Built-in Bluetooth Low-Energy (BLE) radio --Enables location based services with BLE-enabled
mobile devices receiving signals from multiple Aruba
Beacons at the same time. • Advanced Cellular Coexistence (ACC)
--Minimizes interference from 3G/4G cellular networks, distributed antenna systems, and commercial small cell/femtocell equipment.
• Quality of service for unified communication apps
--Supports priority handling and policy enforcement for unified communication apps, including Microsoft Skype for Business with encrypted videoconferencing, voice, chat, and desktop sharing.
DATA SHEET
ARUBA 310 SERIES ACCESS POINTS
• RF Management
--Adaptive Radio Management (ARM) technology automatically assigns channel and power settings, provides airtime fairness, and ensures that APs stay clear of all sources of RF interference to deliver reliable, high-performance WLANs. --The Aruba 310 Series Access Points can be configured to provide part-time or dedicated air monitoring for spectrum
analysis and wireless intrusion protection, VPN tunnels to extend remote locations to corporate resources,
and wireless mesh connections where Ethernet drops are not available.
• Intelligent app visibility and control
--AppRF technology leverages deep packet inspection to classify and block, prioritize or limit bandwidth for over
1,500 enterprise apps or groups of apps. • Security
--Integrated wireless intrusion protection offers threat protection and mitigation, and eliminates the need for separate RF sensors and security appliances.
--IP reputation and security services identify, classify, and block malicious files, URLs and IPs, providing
comprehensive protection against advanced online threats.
--Integrated Trusted Platform Module (TPM) for secure storage of credentials and keys.
• Intelligent Power Monitoring (IPM):
--Enables the AP to continuously monitor and report its actual power consumption and optionally make autonomous decisions to disable certain capabilities
--For the 310 Series Access Points, the IPM power-save feature applies when the unit is powered by an 802.3af PoE source. By default, the USB interface will be the first feature to turn off if AP power consumption will exceed the available power budget. In rare cases it may be necessary to take additional power saving measures, but in most cases, the 310 Series Access Points will operate in unrestricted mode.
CHOOSE YOUR OPERATING MODE
Aruba 310 Series Access Points offer a choice of operating modes to meet your unique management and deployment requirements.
• Controller-managed mode – When managed by Aruba Mobility Controllers, Aruba 310 Series Access Points offer centralized configuration, data encryption, policy enforcement and network services, as well as distributed and centralized traffic forwarding.
• Aruba Instant mode – In Aruba Instant mode, a single
AP automatically distributes the network configuration to other Instant APs in the WLAN. Simply power-up one Instant AP, configure it over the air, and plug in the other APs – the entire process takes about five minutes. If WLAN requirements change, a built-in migration path allows 310 Series instant APs to become part of a WLAN that is managed by a Mobility Controller.
• Remote AP (RAP) for branch deployments
• Air monitor (AM) for wireless IDS, rogue detection and containment
• Spectrum analyzer, dedicated or hybrid, for identifying sources of RF interference
• Secure enterprise mesh
For large installations across multiple sites, the Aruba Activate service significantly reduces deployment time by automating device provisioning, firmware upgrades, and inventory management. With Aruba Activate, Instant APs are factoryshipped to any site and configure themselves when powered up.
AP-310 SERIES SPECIFICATIONS
• AP-314 (controller-managed) and IAP-314 (Instant):
--802.11ac – 5 GHz 4x4 MIMO (1,733 Mbps max rate) and 2.4 GHz 2x2 MIMO (400 Mbps max rate) radios, with
a total of four dual-band RP-SMA connectors for external antennas
• AP-315 (controller-managed) and IAP-315 (Instant):
--802.11ac – 5 GHz 4x4 MIMO (1,733 Mbps max rate) and 2.4 GHz 2x2 MIMO (400 Mbps max rate) radios, with a total of four integrated omni-directional downtilt dual-band antennas
WI-FI RADIO SPECIFICATIONS
• AP type: Indoor, dual radio, 5 GHz 802.11ac 4x4 MIMO and 2.4 GHz 802.11n 2x2 MIMO
• Software-configurable dual radio supports 5 GHz (Radio 0) and 2.4 GHz (Radio 1)
• 5 GHz: Four spatial stream Single User (SU) MIMO for up to 1,733 Mbps wireless data rate to individual 4x4 VHT80 or 2x2 VHT160 client devices
• 2.4 GHz: Two spatial stream Single User (SU) MIMO for up to 400 Mbps wireless data rate to individual 2x2 VHT40 client devices (300 Mbps for HT40 802.11n client devices) • 5 GHz: Four spatial stream Multi User (MU) MIMO for up
to 1,733 Mbps wireless data rate to up to three MU-MIMO capable client devices simultaneously
DATA SHEET
ARUBA 310 SERIES ACCESS POINTS
• Support for up to 255 associated client devices per radio, and up to 16 BSSIDs per radio
• Supported frequency bands (country-specific restrictions apply):
--2.400 to 2.4835 GHz --5.150 to 5.250 GHz --5.250 to 5.350 GHz --5.470 to 5.725 GHz --5.725 to 5.850 GHz
• Available channels: Dependent on configured regulatory domain.
• Dynamic frequency selection (DFS) optimizes the use of available RF spectrum.
• Supported radio technologies:
--802.11b: Direct-sequence spread-spectrum (DSSS) --802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
• Supported modulation types:
--802.11b: BPSK, QPSK, CCK
--802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM • Transmit power: Configurable in increments of 0.5 dBm • Maximum (conducted) transmit power (limited by local
regulatory requirements):
--2.4 GHz band: +18 dBm per chain --5 GHz band: +18 dBm per chain
--Note: conducted transmit power levels exclude antenna gain. For total (EIRP) transmit power, add antenna gain
• Advanced Cellular Coexistence (ACC) minimizes interference from cellular networks. • Maximum ratio combining (MRC) for improved
receiver performance.
• Cyclic delay/shift diversity (CDD/CSD) for improved downlink RF performance.
• Short guard interval for 20-MHz, 40-MHz, 80-MHz and
160-MHz channels.
• Space-time block coding (STBC) for increased range and improved reception.
• Low-density parity check (LDPC) for high-efficiency error correction and increased throughput.
• Transmit beam-forming (TxBF) for increased signal reliability and range.
• Supported data rates (Mbps):
--802.11b: 1, 2, 5.5, 11
--802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 --802.11n: 6.5 to 600 (MCS0 to MCS31)
--802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4 for VHT20/40/80, NSS = 1 to 2 for VHT160)
• 802.11n high-throughput (HT) support: HT 20/40 • 802.11ac very high throughput (VHT) support:
VHT 20/40/80/160
• 802.11n/ac packet aggregation: A-MPDU, A-MSDU
WI-FI ANTENNAS
• AP-314/IAP-314: Four RP-SMA connectors for external dual band antennas. Worst-case internal loss between radio interface and external antenna connectors (due to diplexing circuitry): 0.6dB in 2.4 GHz and 1.2dB in 5 GHz. • AP-315/IAP-315: Four integrated dual-band downtilt
omni-directional antennas for 4x4 MIMO with maximum antenna gain of 3.1dBi in 2.4 GHz and 5.0dBi in 5 GHz.
Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
--The maximum gain of the combined (summed) antenna patterns for all elements operating in the same band is
3.9dBi in 2.4 GHz and 5.7dBi in 5 GHz.
OTHER INTERFACES
• One 10/100/1000BASE-T Ethernet network interfaces (RJ-45) --Auto-sensing link speed and MDI/MDX
--802.3az Energy Efficient Ethernet (EEE) • USB 2.0 host interface (Type A connector) • Bluetooth Low Energy (BLE) radio
--Up to 3dBm transmit power (class 2) and -91dBm receive sensitivity
--Integrated antenna with roughly 30 degrees downtilt and peak gain of 3.4dBi (AP-314/IAP-314) or 1.5dBi
(AP-315/IAP-315)
• Visual indicators (multi-color LEDs): For system and radio status
• Reset button: Factory reset (during device power up) • Serial console interface (proprietary; optional adapter
cable available)
• Kensington security slot
POWER SOURCES AND CONSUMPTION
• The AP supports direct DC power and Power over Ethernet (POE)
• When both power sources are available, DC power takes priority over POE
• Power sources are sold separately
• Direct DC source: 12Vdc nominal, +/- 5%
--Interface accepts 2.1/5.5-mm center-positive circular plug with 9.5-mm length
