Artusi ACH12BBQB, ACH12BBQ User Manual

ACH12BBQ

ACH12BBQB

Range Hoods User Manual

!

IMPORTANT SAFETY INFORMATION

**Read the complete manual carefully before installation**

Warnings:

TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR PERSONAL INJURY, PLEASE
OBSERVE THE FOLLOWING:

1. Installation and electrical work must be done by a qualified person in accordance with all
applicable codes and standards

2. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a
similarly qualified person to avoid a hazard. Any modifications that may be required to the

electrical system for the installation of the range hood must only be made by qualified
electricians.

3. Before servicing or cleaning unit, turn off the hood and pull out the power plug/cord.

4. Use this unit only in the manner intended by the manufacturer.

5. Sufficient air is needed for combustion and exhausting of gases through the chimney of fuel
burning equipment to prevent back drafting. Follow the heating equipment manufacturer's

guidelines and safety standards, and the local authorities’ codes.

6. When cutting or drilling into a wall or ceiling, be careful not to damage existing electrical wiring
and other hidden utilities.

7. Ducted fans must always be vented to the outdoors.

8. To reduce the risk of fire, use only metal ductwork.

9. This unit must be grounded.

10. The appliance is not to be used by persons (including children) with reduced physical, sensory

or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction.

11. Children being supervised not to play with the appliance

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

1. Never leave surface units unattended at high settings. Boil-overs cause smoke and greasy
spillovers that may ignite. Heat oils slowly on low or medium settings.

2. Always turn hood ON when cooking at high heat.

3. Clean ventilating fans frequently. Grease should not be allowed to accumulate on the fan or
filter. Suggest at least one time per month to clean.

4. Always use cookware appropriate for the size of the surface element.

5. There shall be adequate ventilation of the room when the range hood is used at the same time
as appliances burning gas or other fuels.

6. The rangehood can be used on six cookers at most; The rangehood can be used on BBQ.

CAUTION

1. To reduce the risk of fire and to properly exhaust air, be sure to duct air outside. Do not vent
exhaust air into spaces within walls or ceiling or into attics, crawl spaces or garages.

2. Take care when using cleaning agents or detergents.

3. Avoid using food products that produce flames under the range hood.

4. Do not flame under the range hood

5. The range hood must only be used for the exhaust of cooking fumes in home kitchens. The

manufacturer disclaims all liability for any other use of the appliance.

6. Two installers are recommended because of the large size and weight of this hood.

7. Use approved cord-connection kit only.

8. Accessible parts may become hot when used with cooking appliances.

9. Please read specification label on product for further information and requirements.

INSTALLATION INSTRUCTIONS

Before You Start...

1.Read this manual carefully and completely.

2.The range hoods confirms to related appliance standards. Please check your local building codes
for any additional requirements.

3.The appliance has been manufactured as class I, therefore ground connection is necessary. The

range hood must be installed so that that the plug is easily accessible.

Unpacking

Remove the packaging with the product in place. Cut off the packing ribbons and carefully cut
open the packaging (do not cut too deeply), remove the packaging. Check that the product is
free from transport damage. Any damage shall be reported immediately to the carrier or seller.

Damage, faults and missing parts must be reported immediately to the seller

Installation preparation

1.Before mounting the hood, plug in and test all functions for proper operation.

2.Remove the filters from the bottom of the hood to prevent damage during the installation.

3.Connect duct tube (if included with the range hood) to the top of the range hood using duct tape
on all seals.

3.Your range hood will need to be ducted to ensure it operates and complies with local and national
regulations.

DUCT MOUNTING OPTIONS

You will need some additional parts to complete these installations.

All motors need to be ducted individually and the included expanding duct is 150mm diameter.

The air must not be discharged into a flue that is used for exhausting fumes from appliances
burning gas or other fuels.

REAR TOP (ROOF) TOP (SOFFIT/EAVE)

(RECOMMENDED)
