Artograph LED 500 Quick Setup Guide [en, es, fr]

Image Composition, Scaling

and Viewing… Made Easy

Quick Setup Guide

Before operating the LED 500™ Digital Art Projector™, carefully

read the following step-by-step setup and operating instructions and the

enclosed Owner’s Manual and/or CD. Becoming fully familiar with the rich

features this product has to offer will simplify the process of art composition

and scaling, allowing you to spend more time on the creation of art.

Thank you

Thank you for purchasing the LED 500TM Digital Art Projector. This Guide

will assist you with setup and operation of this fine art tool.

You will notice that each instruction/feature has a bracketed number behind it which

identifies the page number in the Owner’s Manual where you can find additional information

about this step. The enclosed CD* provides these same instructions in 27 languages.

We encourage you to test all of the LED 500

your experience with the system. It is truly a product designed for the creative mind.

For setup and operation questions, or if you have comments or suggestions you wish to

offer, please feel free to contact our toll-free Customer Service line at 888-975-9555.

Sincerely, Artograph, Inc.

*Please note that the CD refers to the LED 500TM as PB60A. The “Optional Extras” outlined in the CD are not

necessarily available from Artograph but may be available from other sources of consumer electronics.

TM

Digital Art Projector’s features to enhance

Artograph® products are warranted to be free from defects in material and workmanship for a period of one year from the date of

Warranty

sale to the original purchaser. Any defective product will be repaired or replaced by Artograph at its option, provided the product
is returned, shipping prepaid, to our factory within the warranty period. Customer shall promptly notify either the original seller or
Artograph of any warranty claim in sufficient detail to describe both the problem and its symptoms along with a copy of the original
purchase receipt of other acceptable proof of purchase. All allowed returns will be provided a return authorization number. Any
product received without an authorization number will be returned. Equipment repaired or replaced under this warranty will be
returned freight or postage prepaid. The warranty period for repaired or replacement products shall be for the same duration as the
original warranty. This warranty does not cover repair for damage to the product, or product components or malfunctions caused
by (i) misuse, neglect, power failures or surges, lightning, fire, flood or accident; (ii) use of products or facilities supplied by others:
or (iii) failure to follow installation, operation or maintenance instructions.

THE EXPRESS WARRANTIES HEREIN CONTAINED ARE IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTIBILITY, FITNESS FOR A PAR­TICULAR PURPOSE AND NON-INFRINGEMENT, EACH OF WHICH SELLER DISCLAIMS AND ARE EXCLUDED. WHILE
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF, CUSTOMER’S
LOCAL LAW MAY PROVIDE OTHERWISE. SELLER SHALL NOT BE LIABLE FOR DAMAGES, INCLUDING SPECIAL AND
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INTERRUPTION OF BUSINESS ARISING OUT OF OR IN CONNECTION
WITH PERFORMANCE OF THE PRODUCTS OR USE BY CUSTOMER.

#306-376 ©2014

www.artograph.com

Important Safety Information

Please refer to pages 2 – 6 in the enclosed Owner’s Manual for detailed safety information.

Step One – Review Package Contents (page 13)

1. LED 500™ Digital Art Projector

2. Remote control w/one CR2032/3V battery

™

1

3. Power supply (AC/DC adapter + power cord)

4. RGB computer cable

5. Composite cable

6. RGB

VGA adapter for MAC

g

7. Multi-card USB card reader

8. Soft storage bag for LED 500

™

9. Owner’s Manual (English)

10. CD Owner’s Manual

Optional Extras discussed on page 14 of the Owner’s
Manual are either available from Artograph or through
your local consumer electronics store.

3

2

9

7

10

8

6

5

Step Two – Getting Started (Page 19)

1. Remove protective film from projector

2. Install CR2032/3V battery into remote control

3. Review remote control features:

POWER: on/off
INPUT: input source
MUTE: mutes sounds
VOLUME+ / VOLUME–: adjusts volume
PAGE / PAGE : next screen

AUTO: RGB-PC input image
BLANK: Screen on/off

OK

: moves cursor

OK: saves
EXIT: clears on-screen displays
O: return to previous screen
SETTINGS: select or close menu
Q.MENU: quick access menu

STILL: freezes (not USB mode)
GRID: select one of 19 grid patterns + grid color
USB: access USB mode
MARK: set optional functions
KEY.S p / KEY.S q: Adjusts keystone
tt uu: controls playback of My Media
: shows 3D images
II : switch left to right in 3D mode
Color buttons: access special functions

Note: when using remote control, the optimal range is less than 3 meters and within
a 30 degree arc of the IR receiver. The IR receiver is on the back of the receiver.

Step Three – Start Projector (Page 21)

1. Mount LED 500™ onto a tri-pod or sturdy,
hard platform near a power outlet
(DO NOT block vents on projector)

2. Connect power supply cord into nearby
outlet and into the back of LED 500

™

marked DC IN

4

3. Aim LED 500™ toward desired surface

4. Press red Power button on remote

LED 500™
Tripod

Mobile

Floor Stand

or lighted button on top
of LED 500

™

5. FOCUS – Rotate focus wheel on side
of LED 500

™

Focus Wheel

Step Four – Select Input Source (Page 23)

The LED 500™ accepts input from a variety of devices including computers, SD cards,
HDMI devices and USB flashdrives:

1. USB (Pages 25-26) insert USB flashdrive into USB port
a. “New external input is connected;

do you want to use this?” Answer YES
b. If USB device is not recognized:
i. press “USB” button on remote (or)
ii. press “input” button on remote and

manually select USB

2. SD Card Reader (Same as USB Pages 25 – 26)
Insert SD memory card into multi-card reader; insert multi-card
reader into USB port ; the following menus will appear:
a. All Media (Page 25): allows viewing all media files at once
b. Movie List (Pages 28-33): allows viewing all movie files
c. Photo List (Pages 34-36): allows viewing of all photo files
d. Music List (Pages 29, 36-37, 49): allows viewing of all music files
e. Files List (Pages 38-39): allows viewing of MicroSoft

3. RGB/HDMI Devices (Page 54)

™

Direct connect LED 500

to PC or MAC computer
a. PC: use RGB cable or HDMI cable
b. MAC: use MAC Adapter cable or HDMI cable

Ports for RGB/HDMI Devices

USB Port

®

Office document files

Step Five – Picture Settings and
Adjustments

1. Grid Templates/Patterns (not covered in CD or printed manual)

a. The LED 500
simplify the process of art composition, alignment and scaling
b. Select “Grid” on the remote; press left or right arrows to
Select desired grid and grid color based on the projected surface

2. Auto Keystone (Pages 23, 51) – LED 500
focused on an angled surface.
a. Select the Key.S

3. Grayscale (Page 46) Color images can be adjusted to grayscale to aid in tracing and/or
to evaluate tonal values
a. In “USB” mode, select “Q.Menu”
on the remote, scroll down to “Color”; adjust the color down to zero
b. All other devices – select “Settings”
the remote, scroll down to “Grayscale” and turn “on” or “off”
(OR)
c. Alternate method – select “Settings”
down to zero

4. Rotating/Flipping Images (Page 35) The LED 500
images to suit your artistic requirements
a. USB Mode only – when previewing an image, use
of image; use
to orient the image correctly.
b. Flipping images (Page 51) – (Must exit from USB)

5. Enlarging Photos (Page 35) USB mode only; images can be enlarged up to 400%
a. i Arrow down to bottom bar on the image;
magnifying glass symbol;
repeat
then move around the magnified image

6. Picture Wizzard II (Page 47)
and standards (Exit USB mode completely to access this feature)
a. Select “Settings” on the remote; scroll down to “Picture Wizzard II” and follow
the on-screen instructions

7. Edge Enhancement (Page 48) increases line clarity to enhance tracing
a. Works in USB Mode only;
“OK”
desired

Note: The LED 500

“PJT Mode”

g

All information will remain confidential and solely for Artograph use.

(Pages 46-48)

™

has 19 composition grid templates/patterns built into the device to

™

auto adjusts to the right angle when

p

/ Key.S q on the remote for further keystone adjustment

“Set Video” g using the arrow keys

g

“Options” g using the arrow keys on

g

“Picture” g “Color”; adjust color

g

™

allows you to rotate and flip

arrow key to move to bottom

i

arrow key to move right to ; g OK as many times as necessary

g

OK g blue button with four dots ;

g

symbol again to scroll up to 400% enlargement; use the arrow keys to

g

adjusts the settings of each input to desired picture quality

“Settings” on the remote; g v g “Set Video”

g

v to get to “Edge Enhancer”; g > arrow to obtain level

g

“OK”

g

™

has been designed to function with most input devices, but not all.

If you wish to receive product updates, register your

Artograph product at www.artograph.com.



“Settings” g “Option”

g

to the right until coming the the

g

Composición, escalamiento y

visualización de imágenes...

de manera sencilla

Guía de configuración rápida

Antes de usar el LED 500™ Digital Art Projector™, lea atentamente las siguientes
instrucciones detalladas de configuración y uso, y el Manual del propietario adjunto
y/o el CD. Familiarizarse por completo con la infinidad de características que ofrece

este producto simplificará el proceso de composición y escalamiento de obras de

arte, lo que le permitirá pasar más tiempo en la creación de arte.

Gracias

Gracias por adquirir el LED 500TM Digital Art Projector. Esta guía le ayudará con

la configuración y uso de esta herramienta para artes gráficos.

Observará que cada instrucción/característica tiene un número entre corchetes detrás, que

identifica el número de página en el Manual del propietario, donde puede encontrar información

adicional sobre este paso. El CD* adjunto brinda estas mismas instrucciones en 27 idiomas.

Le recomendamos probar todas las características del LED 500

su experiencia con el sistema. Es verdaderamente un producto diseñado para las mentes creativas.

Por preguntas sobre configuración y uso, o si tiene comentarios o sugerencias que desee brindar,

puede comunicarse con nuestra línea gratuita de Atención al cliente al 888-975-9555.

Atentamente, Artograph, Inc.

*Tenga en cuenta que el CD se refiere al LED 500TM como PB60A. Los “Extras opcionales”

descritos en el CD no necesariamente están disponibles de parte de Artograph, sino que pueden

estar disponibles de otras fuentes de productos electrónicos para consumidores.

TM

Digital Art Projector para mejorar

Garantía

Los productos de Artograph® están garantizados contra defectos en materiales y mano de obra durante un período de un año a
partir de la fecha de venta al comprador original. Cualquier producto defectuoso será reparado o reemplazado por Artograph a
su elección, siempre y cuando el producto sea devuelto, con porte prepagado, a nuestra fábrica dentro del período de garantía.
El cliente deberá notificar puntualmente ya sea al vendedor original o a Artograph sobre cualquier reclamación de garantía
proporcionando información suficientemente específica que describa el problema y sus síntomas, junto con una copia del recibo
original de compra u otra prueba aceptable de compra. Todas las devoluciones aprobadas recibirán un número de autorización de
devolución. Todos los productos recibidos sin un número de autorización serán devueltos. Los equipos reparados o reemplazados
bajo esta garantía serán devueltos al cliente, previo pago del porte o franqueo. El período de garantía para los productos reparados
o reemplazados tendrá la misma duración que la garantía original. Esta garantía no cubre la reparación de daños en el producto
o en los componentes del producto ni su mal funcionamiento causado por (i) uso inadecuado, negligencia, cortes eléctricos o
sobretensiones, rayos, incendios, inundaciones o accidentes, (ii) el uso de productos o servicios suministrados por terceros, o (iii)
incumplimiento de las instrucciones de instalación, operación o mantenimiento.

LAS GARANTÍAS EXPRESAS CONTENIDAS EN EL PRESENTE DOCUMENTO SE BRINDAN EN LUGAR DE CUALQUIER
Y TODA OTRA GARANTÍA EXPRESA O IMPLÍCITA, INCLUIDAS ENTRE OTRAS, LAS GARANTÍAS IMPLÍCITAS DE
COMERCIABILIDAD, APTITUD PARA UN PROPÓSITO PARTICULAR Y DE NO CONTRAVENCIÓN, CADA UNA DE LAS
CUALES ES RECHAZADA POR EL VENDEDOR Y SE ENCUENTRAN EXCLUIDAS. AUNQUE NO HAY GARANTÍAS QUE SE
EXTIENDAN MÁS ALLÁ DE LA DESCRIPCIÓN DE LA PRESENTE GARANTÍA, LAS LEYES LOCALES DEL CLIENTE PUEDEN
ESTIPULAR LO CONTRARIO. EL VENDEDOR NO SERÁ RESPONSABLE POR DAÑOS, INCLUIDOS DAÑOS ESPECIALES,
INCIDENTALES O CONSECUENTES, INTERRUPCIÓN DE ACTIVIDADES COMERCIALES QUE SE PRODUZCAN POR O EN
RELACIÓN CON EL DESEMPEÑO DE LOS PRODUCTOS O SU USO POR PARTE DEL CLIENTE.

Artograph provides free lifetime telephone
technical service support on the LED 500

TM

#306-376 ©2014

www.artograph.com
