ARM® Developer Suite

Version 1.2

Assembler Guide

ARM DUI 0068B

ARM Developer Suite

Assembler Guide

Release Information

The following changes have been made to this book.

Change History

Date Issue Change

November 2000 A Release 1.1

November 2001 B Release 1.2

Proprietary Notice

Words and logos marked with brands and names mentioned herein may be the trademarks of their respective owners.

Neither the whole nor any part of the information contained in, or the product described in, this document may be adapted or reproduced in any material form except with the prior written permission of the copyright holder.

or ™ are registered trademarks or trademarks owned by ARM Limited. Other

The product described in this document is subject to continuous developments and improvements. All particulars of the product and its use contained in this document are given by ARM in good faith. However, all warranties implied or expressed, including but not limited to implied warranties of merchantability, or fitness for purpose, are excluded.

This document is intended only to assist the reader in the use of the product. ARM Limited shall not be liable for any loss or damage arising from the use of any information in this document, or any error or omission in such information, or any incorrect use of the product.

ARM Developer Suite Assembler Guide

Preface

About this book .............................................................................................. vi

Feedback ....................................................................................................... ix

Chapter 1 Introduction

1.1 About the ARM Developer Suite assemblers .............................................. 1-2

Chapter 2 Writing ARM and Thumb Assembly Language

2.1 Introduction ................................................................................................. 2-2

2.2 Overview of the ARM architecture .............................................................. 2-3

2.3 Structure of assembly language modules ................................................. 2-12

2.4 Using the C preprocessor ......................................................................... 2-19

2.5 Conditional execution ................................................................................ 2-20

2.6 Loading constants into registers ............................................................... 2-25

2.7 Loading addresses into registers .............................................................. 2-30

2.8 Load and store multiple register instructions ............................................. 2-39

2.9 Using macros ............................................................................................ 2-48

2.10 Describing data structures with MAP and FIELD directives ...................... 2-51

2.11 Using frame directives ............................................................................... 2-66

Chapter 3 Assembler Reference

3.1 Command syntax ........................................................................................ 3-2

Contents

3.2 Format of source lines ................................................................................ 3-8

3.3 Predefined register and coprocessor names .............................................. 3-9

3.4 Built-in variables ....................................................................................... 3-10

3.5 Symbols .................................................................................................... 3-12

3.6 Expressions, literals, and operators ......................................................... 3-18

Chapter 4 ARM Instruction Reference

4.1 Conditional execution ................................................................................. 4-4

4.2 ARM memory access instructions .............................................................. 4-6

4.3 ARM general data processing instructions ............................................... 4-23

4.4 ARM multiply instructions ......................................................................... 4-39

4.5 ARM saturating arithmetic instructions ..................................................... 4-55

4.6 ARM branch instructions .......................................................................... 4-57

4.7 ARM coprocessor instructions .................................................................. 4-62

4.8 Miscellaneous ARM instructions ............................................................... 4-71

4.9 ARM pseudo-instructions ......................................................................... 4-78

Chapter 5 Thumb Instruction Reference

5.1 Thumb memory access instructions ........................................................... 5-4

5.2 Thumb arithmetic instructions ................................................................... 5-15

5.3 Thumb general data processing instructions ............................................ 5-22

5.4 Thumb branch instructions ....................................................................... 5-31

5.5 Thumb software interrupt and breakpoint instructions .............................. 5-37

5.6 Thumb pseudo-instructions ...................................................................... 5-39

Chapter 6 Vector Floating-point Programming

6.1 The vector floating-point coprocessor ........................................................ 6-4

6.2 Floating-point registers ............................................................................... 6-5

6.3 Vector and scalar operations ...................................................................... 6-7

6.4 VFP and condition codes ............................................................................ 6-8

6.5 VFP system registers ............................................................................... 6-10

6.6 Flush-to-zero mode .................................................................................. 6-13

6.7 VFP instructions ....................................................................................... 6-15

6.8 VFP pseudo-instruction ............................................................................ 6-38

6.9 VFP directives and vector notation ........................................................... 6-40

Chapter 7 Directives Reference

7.1 Alphabetical list of directives ...................................................................... 7-2

7.2 Symbol definition directives ........................................................................ 7-3

7.3 Data definition directives .......................................................................... 7-13

7.4 Assembly control directives ...................................................................... 7-26

7.5 Frame description directives ..................................................................... 7-33

7.6 Reporting directives .................................................................................. 7-44

7.7 Miscellaneous directives ........................................................................... 7-49

Glossary

Preface

This preface introduces the documentation for the ARM Developer Suite (ADS) assemblers and assembly language. It contains the following sections:

• About this book on page vi

• Feedback on page ix.

Preface

About this book

Intended audience

Using this book

This book provides tutorial and reference information for the ADS assemblers (

armasm

the free-standing assembler, and inline assemblers in the C and C++ compilers). It describes the command-line options to the assembler, the pseudo-instructions and directives available to assembly language programmers, and the ARM, Thumb

, and

Vector Floating-point (VFP) instruction sets.

This book is written for all developers who are producing applications using ADS. It assumes that you are an experienced software developer and that you are familiar with the ARM development tools as described in ADS Getting Started.

This book is organized into the following chapters:

Chapter 1 Introduction

Read this chapter for an introduction to the ADS version 1.2 assemblers and assembly language.

Chapter 2 Writing ARM and Thumb Assembly Language

Read this chapter for tutorial information to help you use the ARM assemblers and assembly language.

Chapter 3 Assembler Reference

Read this chapter for reference material about the syntax and structure of the language provided by the ARM assemblers.

Chapter 4 ARM Instruction Reference

Read this chapter for reference material on the ARM instruction set.

Chapter 5 Thumb Instruction Reference

Read this chapter for reference material on the Thumb instruction set.

Chapter 6 Vector Floating-point Programming

Read this chapter for reference material on the VFP instruction set, and other VFP-specific assembly language information.

Chapter 7 Directives Reference

Read this chapter for reference material on the assembler directives available in the ARM assembler,

armasm

Typographical conventions

The following typographical conventions are used in this book:

Preface

Feedback

ARM Limited welcomes feedback on both ADS and the documentation.

Feedback on the ARM Developer Suite

If you have any problems with ADS, please contact your supplier. To help them provide a rapid and useful response, please give:

• your name and company

• the serial number of the product

• details of the release you are using

• details of the platform you are running on, such as the hardware platform,

operating system type and version

• a small standalone sample of code that reproduces the problem

• a clear explanation of what you expected to happen, and what actually happened

• the commands you used, including any command-line options

• sample output illustrating the problem

• the version string of the tools, including the version number and build numbers.

Feedback on this book

Preface

If you have any problems with this book, please send email to

errata@arm.com

giving:

• the document title

• the document number

• the page number(s) to which your comments apply

• a concise explanation of the problem.

General suggestions for additions and improvements are also welcome.

Preface

Chapter 1

Introduction

This chapter introduces the assemblers provided with ARM Developer Suite (ADS) version 1.2. It contains the following sections:

• About the ARM Developer Suite assemblers on page 1-2.

Introduction

1.1 About the ARM Developer Suite assemblers

ARM Developer Suite (ADS) has:

• a freestanding assembler,

armasm

• an optimizing inline assembler built into the C and C++ compilers.

The language that these assemblers take as input is basically the same. However, there are limitations on what features of the language you can use in the inline assemblers. Refer to the Mixing C, C++, and Assembly Language chapter in ADS Developer Guide for further information on the inline assemblers.

armasm

The remainder of this book relates mainly to

Chapter 2

Writing ARM and Thumb Assembly Language

This chapter provides an introduction to the general principles of writing ARM and Thumb assembly language. It contains the following sections:

• Introduction on page 2-2

• Overview of the ARM architecture on page 2-3

• Structure of assembly language modules on page 2-12

• Using the C preprocessor on page 2-19

• Conditional execution on page 2-20

• Loading constants into registers on page 2-25

• Loading addresses into registers on page 2-30

• Load and store multiple register instructions on page 2-39

• Using macros on page 2-48

• Describing data structures with MAP and FIELD directives on page 2-51

• Using frame directives on page 2-66.

Writing ARM and Thumb Assembly Language

2.1 Introduction

This chapter gives a basic, practical understanding of how to write ARM and Thumb assembly language modules. It also gives information on the facilities provided by the ARM assembler (armasm).

This chapter does not provide a detailed description of the ARM, Thumb, or VFP instruction sets. This information can be found in Chapter 4 ARM Instruction

Reference, Chapter 5 Thumb Instruction Reference, and Chapter 6 Vect or Floating-point Programming. Further information can be found in ARM Architecture Reference Manual.

2.1.1 Code examples

There are a number of code examples in this chapter. Many of them are supplied in the

examples\asm

Follow these steps to build, link, and execute an assembly language file:

directory of the ADS.

1. Type

armasm -g filename.s

at the command prompt to assemble the file and

generate debug tables.

2. Type

armlink filename.o -o filename

to link the object file and generate an ELF

executable image.

3. Type

4. Type

5. Type

armsd filename

at the

armsd:

quit

at the

armsd:

to load the image file into the debugger.

prompt to execute it.

prompt to return to the command line.

To see how the assembler converts the source code, enter:

fromelf -text/c filename.o

or run the module in AXD with interleaving on.

See:

• AXD and armsd Debuggers Guide for details on armsd, and AXD.

armlink

and

• ADS Linker and Utilities Guide for details on

fromelf

2.2 Overview of the ARM architecture

This section gives a brief overview of the ARM architecture.

ARM processors are typical of RISC processors in that they implement a load/store architecture. Only load and store instructions can access memory. Data processing instructions operate on register contents only.

2.2.1 Architecture versions

The information and examples in this book assume that you are using a processor that implements ARM architecture v3 or above. See ARM Architecture Reference Manual for details of the various architecture versions.

All these processors have a 32-bit addressing range.

2.2.2 ARM and Thumb state

ARM architecture versions v4T and above define a 16-bit instruction set called the Thumb instruction set. The functionality of the Thumb instruction set is a subset of the functionality of the 32-bit ARM instruction set. Refer to Thumb instruction set overview on page 2-9 for more information.

Writing ARM and Thumb Assembly Language

A processor that is executing Thumb instructions is operating in Thumb state. A processor that is executing ARM instructions is operating in ARM state.

A processor in ARM state cannot execute Thumb instructions, and a processor in Thumb state cannot execute ARM instructions. You must ensure that the processor never receives instructions of the wrong instruction set for the current state.

Each instruction set includes instructions to change processor state.

You must also switch the assembler mode to produce the correct opcodes using and

CODE32

directives. Refer to CODE16 and CODE32 on page 7-54 for details.

CODE16

ARM processors always start executing code in ARM state.

Writing ARM and Thumb Assembly Language

2.2.3 Processor mode

ARM processors support up to seven processor modes, depending on the architecture version. These are:

• User

• FIQ - Fast Interrupt Request

• IRQ - Interrupt Request

• Supervisor

• Abort

• Undefined

• System (ARM architecture v4 and above).

All modes except User mode are referred to as privileged modes.

Applications that require task protection usually execute in User mode. Some embedded applications might run entirely in Supervisor or System modes.

Modes other than User mode are entered to service exceptions, or to access privileged resources. Refer to the Handling Processor Exceptions chapter in ADS Developer Guide, and ARM Architecture Reference Manual for more information.

2.2.4 Registers

ARM processors have 37 registers. The registers are arranged in partially overlapping banks. There is a different register bank for each processor mode. The banked registers give rapid context switching for dealing with processor exceptions and privileged operations. Refer to ARM Architecture Reference Manual for a detailed description of how registers are banked.

The following registers are available in ARM architecture v3 and above:

• 30 general-purpose, 32-bit registers

• The program counter (pc) on page 2-5

• The Current Program Status Register (CPSR) on page 2-5

• Five Saved Program Status Registers (SPSRs) on page 2-5.

30 general-purpose, 32-bit registers

Fifteen general-purpose registers are visible at any one time, depending on the current processor mode, as r0, r1, ... ,r13, r14.

By convention, r13 is used as a stack pointer (sp) in ARM assembly language. The C and C++ compilers always use r13 as the stack pointer.

Writing ARM and Thumb Assembly Language

In User mode, r14 is used as a link register (lr) to store the return address when a subroutine call is made. It can also be used as a general-purpose register if the return address is stored on the stack.

In the exception handling modes, r14 holds the return address for the exception, or a subroutine return address if subroutine calls are executed within an exception. r14 can be used as a general-purpose register if the return address is stored on the stack.

The program counter (pc)

The program counter is accessed as r15 (or pc). It is incremented by one word (four bytes) for each instruction in ARM state, or by two bytes in Thumb state. Branch instructions load the destination address into the program counter. You can also load the program counter directly using data operation instructions. For example, to return from a subroutine, you can copy the link register into the program counter using:

MOV pc,lr

During execution, r15 does not contain the address of the currently executing instruction. The address of the currently executing instruction is typically pc–8 for ARM, or pc–4 for Thumb.

The Current Program Status Register (CPSR)

The CPSR holds:

• copies of the Arithmetic Logic Unit (ALU) status flags

• the current processor mode

• interrupt disable flags.

The ALU status flags in the CPSR are used to determine whether conditional instructions are executed or not. Refer to Conditional execution on page 2-20 for more information.

On Thumb-capable processors, the CPSR also holds the current processor state (ARM or Thumb).

On ARM architecture v5TE, the CPSR also holds the Q flag (see The ALU status flags on page 2-20).

Five Saved Program Status Registers (SPSRs)

The SPSRs are used to store the CPSR when an exception is taken. One SPSR is accessible in each of the exception-handling modes. User mode and System mode do not have an SPSR because they are not exception handling modes. Refer to the Handling Processor Exceptions chapter in ADS Developer Guide for more information.

Writing ARM and Thumb Assembly Language

2.2.5 ARM instruction set overview

All ARM instructions are 32 bits long. Instructions are stored word-aligned, so the least significant two bits of instruction addresses are always zero in ARM state. Some instructions use the least significant bit to determine whether the code being branched to is Thumb code or ARM code.

See Chapter 4 ARM Instruction Reference for detailed information on the syntax of the ARM instruction set.

ARM instructions can be classified into a number of functional groups:

• Branch instructions

• Data processing instructions

• Single register load and store instructions on page 2-7

• Multiple register load and store instructions on page 2-7

• Status register access instructions on page 2-7

• Semaphore instructions on page 2-7

• Coprocessor instructions on page 2-7.

Branch instructions

These instructions are used to:

• branch backwards to form loops

• branch forward in conditional structures

• branch to subroutines

• change the processor from ARM state to Thumb state.

Data processing instructions

These instructions operate on the general-purpose registers. They can perform operations such as addition, subtraction, or bitwise logic on the contents of two registers and place the result in a third register. They can also operate on the value in a single register, or on a value in a register and a constant supplied within the instruction (an immediate value).

Long multiply instructions (unavailable in some architectures) give a 64-bit result in two registers.

Writing ARM and Thumb Assembly Language

Single register load and store instructions

These instructions load or store the value of a single register from or to memory. They can load or store a 32-bit word or an 8-bit unsigned byte. In ARM architecture v4 and above they can also load or store a 16-bit unsigned halfword, or load and sign extend a 16-bit halfword or an 8-bit byte.

Multiple register load and store instructions

These instructions load or store any subset of the general-purpose registers from or to memory. Refer to Load and store multiple register instructions on page 2-39 for a detailed description of these instructions.

Status register access instructions

These instructions move the contents of the CPSR or an SPSR to or from a general-purpose register.

Semaphore instructions

These instructions load and alter a memory semaphore.

Coprocessor instructions

These instructions support a general way to extend the ARM architecture.

Writing ARM and Thumb Assembly Language

2.2.6 ARM instruction capabilities

The following general points apply to ARM instructions:

• Conditional execution

• Register access

• Access to the inline barrel shifter.

Conditional execution

Almost all ARM instructions can be executed conditionally on the value of the ALU status flags in the CPSR. You do not need to use branches to skip conditional instructions, although it can be better to do so when a series of instructions depend on the same condition.

You can specify whether a data processing instruction sets the state of these flags or not. You can use the flags set by one instruction to control execution of other instructions even if there are many instructions in between.

Refer to Conditional execution on page 2-20 for a detailed description.

In ARM state, all instructions can access r0 to r14, and most also allow access to r15 (pc). The

MRS

and

MSR

instructions can move the contents of the CPSR and SPSRs to a general-purpose register, where they can be manipulated by normal data processing operations. Refer to MRS on page 4-73 and MSR on page 4-74 for more information.

Access to the inline barrel shifter

The ARM arithmetic logic unit has a 32-bit barrel shifter that is capable of shift and rotate operations. The second operand to all ARM data-processing and single register data-transfer instructions can be shifted, before the data-processing or data-transfer is executed, as part of the instruction. This supports, but is not limited to:

• scaled addressing

• multiplication by a constant

• constructing constants.

Refer to Loading constants into registers on page 2-25 for more information on using the barrel-shifter to generate constants.

2.2.7 Thumb instruction set overview

The functionality of the Thumb instruction set is almost exactly a subset of the functionality of the ARM instruction set. The instruction set is optimized for production by a C or C++ compiler.

All Thumb instructions are 16 bits long and are stored halfword-aligned in memory. Because of this, the least significant bit of the address of an instruction is always zero in Thumb state. Some instructions use the least significant bit to determine whether the code being branched to is Thumb code or ARM code.

All Thumb data processing instructions:

• operate on full 32-bit values in registers

• use full 32-bit addresses for data access and for instruction fetches.

Refer to Chapter 5 Thumb Instruction Reference for detailed information on the syntax of the Thumb instruction set, and how Thumb instructions differ from their ARM counterparts.

2.2.8 Thumb instruction capabilities

The following general points apply to Thumb instructions:

• Conditional execution

• Register access

• Access to the barrel shifter on page 2-10.

Writing ARM and Thumb Assembly Language

Conditional execution

The conditional branch instruction is the only Thumb instruction that can be executed conditionally on the value of the ALU status flags in the CPSR. All data processing instructions update these flags, except when one or more high registers are specified as operands to the

MOV

ADD

instructions. In these cases the flags cannot be updated.

You cannot have any data processing instructions between an instruction that sets a condition and a conditional branch that depends on it. Use a conditional branch over any instruction that you wish to be conditional.

In Thumb state, most instructions can access only r0 to r7. These are referred to as the low registers.

Registers r8 to r15 are limited access registers. In Thumb state these are referred to as high registers. They can be used, for example, as fast temporary storage.

Writing ARM and Thumb Assembly Language

Refer to Chapter 5 Thumb Instruction Reference for a complete list of the Thumb data processing instructions that can access the high registers.

Access to the barrel shifter

In Thumb state you can use the barrel shifter only in a separate operation, using an

LSR, ASR,

ROR

instruction.

2.2.9 Differences between Thumb and ARM instruction sets

The general differences between the Thumb instruction set and the ARM instruction set are dealt with under the following headings:

• Branch instructions

• Data processing instructions

• Single register load and store instructions on page 2-11

• Multiple register load and store instructions on page 2-11.

There are no Thumb coprocessor instructions, no Thumb semaphore instructions, and no Thumb instructions to access the CPSR or SPSR.

Branch instructions

LSL

These instructions are used to:

• branch backwards to form loops

• branch forward in conditional structures

• branch to subroutines

• change the processor from Thumb state to ARM state.

Program-relative branches, particularly conditional branches, are more limited in range than in ARM code, and branches to subroutines can only be unconditional.

Data processing instructions

These operate on the general-purpose registers. In many cases, the result of the operation must be put in one of the operand registers, not in a third register. There are fewer data processing operations available than in ARM state. They have limited access to registers r8 to r15.

The ALU status flags in the CPSR are always updated by these instructions except when

MOV

ADD

instructions access registers r8 to r15. Thumb data processing instructions

that access registers r8 to r15 cannot update the flags.

Writing ARM and Thumb Assembly Language

Single register load and store instructions

These instructions load or store the value of a single low register from or to memory. In Thumb state they can only access registers r0 to r7.

Multiple register load and store instructions

LDM

and

STM

load from memory and store to memory any subset of the registers in the

range r0 to r7.

PUSH

and

POP

instructions implement a full descending stack using the stack pointer (r13)

as the base. In addition to transferring r0 to r7,

PUSH

can store the link register and

POP

can load the program counter.

Writing ARM and Thumb Assembly Language

2.3 Structure of assembly language modules

Assembly language is the language that the ARM assembler ( assembles to produce object code. This can be:

• ARM assembly language

• Thumb assembly language

• a mixture of both.

2.3.1 Layout of assembly language source files

The general form of source lines in assembly language is:

{label} {instruction|directive|pseudo-instruction} {;comment}

Note

Instructions, pseudo-instructions, and directives must be preceded by white space, such as a space or a tab, even if there is no label.

All three sections of the source line are optional. You can use blank lines to make your code more readable.

Case rules

Instruction mnemonics, directives, and symbolic register names can be written in uppercase or lowercase, but not mixed.

armasm

) parses and

Line length

To make source files easier to read, a long line of source can be split onto several lines by placing a backslash character ( \ ) at the end of the line. The backslash must not be followed by any other characters (including spaces and tabs). The backslash/end-of-line sequence is treated by the assembler as white space.

Note

Do not use the backslash/end-of-line sequence within quoted strings.

The exact limit on the length of lines, including any extensions using backslashes, depends on the contents of the line, but is generally between 128 and 255 characters.

Writing ARM and Thumb Assembly Language

Labels

Labels are symbols that represent addresses. The address given by a label is calculated during assembly.

The assembler calculates the address of a label relative to the origin of the section where the label is defined. A reference to a label within the same section can use the program counter plus or minus an offset. This is called program-relative addressing.

Labels can be defined in a map. See Describing data structures with MAP and FIELD directives on page 2-51. You can place the origin of the map in a specified register at runtime, and references to the label use the specified register plus an offset. This is called register-relative addressing.

Addresses of labels in other sections are calculated at link time, when the linker has allocated specific locations in memory for each section.

Local labels

Local labels are a subclass of label. A local label begins with a number in the range 0-99. Unlike other labels, a local label can be defined many times. Local labels are useful when you are generating labels with a macro. When the assembler finds a reference to a local label, it links it to a nearby instance of the local label.

The scope of local labels is limited by the

AREA

directive. You can use the

ROUT

directive

to limit the scope more tightly.

Refer to the Local labels on page 3-16 for details of:

• the syntax of local label declarations

• how the assembler associates references to local labels with their labels.

Comments

The first semicolon on a line marks the beginning of a comment, except where the semicolon appears inside a string constant. The end of the line is the end of the comment. A comment alone is a valid line. All comments are ignored by the assembler.

Writing ARM and Thumb Assembly Language

Constants

Constants can be numeric, boolean, character or string:

Numbers Numeric constants are accepted in three forms:

Boolean The Boolean constants

Characters Character constants consist of opening and closing single quotes,

Strings Strings consist of opening and closing double quotes, enclosing

• Decimal, for example,

• Hexadecimal, for example,

•

n_xxx

where:

xxx

{FALSE}

is a base between 2 and 9

is a number in that base.

TRUE

123

and

0x7B

FALSE

must be written as

{TRUE}

and

enclosing either a single character or an escaped character, using the standard C escape characters.

characters and spaces. If double quotes or dollar signs are used within a string as literal text characters, they must be represented by a pair of the appropriate character. For example, you must use single

in the string. The standard C escape sequences can be used within

if you require a

string constants.

Writing ARM and Thumb Assembly Language

2.3.2 An example ARM assembly language module

Example 2-1 illustrates some of the core constituents of an assembly language module. The example is written in ARM assembly language. It is supplied as

examples\asm

subdirectory of ADS. Refer to Code examples on page 2-2 for instructions

on how to assemble, link, and execute the example.

The constituent parts of this example are described in more detail in the following sections.

AREA ARMex, CODE, READONLY ; Name this block of code ARMex ENTRY ; Mark first instruction to execute start MOV r0, #10 ; Set up parameters MOV r1, #3 ADD r0, r0, r1 ; r0 = r0 + r1 stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI

armex.s

Example 2-1

in the

END ; Mark end of file

ELF sections and the AREA directive

ELF sections are independent, named, indivisible sequences of code or data. A single code section is the minimum required to produce an application.

The output of an assembly or compilation can include:

• One or more code sections. These are usually read-only sections.

• One or more data sections. These are usually read-write sections. They may be

zero initialized (ZI).

The linker places each section in a program image according to section placement rules. Sections that are adjacent in source files are not necessarily adjacent in the application image. Refer to the Linker chapter in ADS Linker and Utilities Guide for more information on how the linker places sections.

Writing ARM and Thumb Assembly Language

In an ARM assembly language source file, the start of a section is marked by the

AREA

directive. This directive names the section and sets its attributes. The attributes are placed after the name, separated by commas. Refer to AREA on page 7-52 for a detailed description of the syntax of the

AREA

directive.

You can choose any name for your sections. However, names starting with any nonalphabetic character must be enclosed in bars, or an generated. For example:

|1_DataArea|

Example 2-1 on page 2-15 defines a single section called is marked as being

READONLY

AREA name missing

ARMex

that contains code and

error is

The ENTRY directive

ENTRY

The

directive marks the first instruction to be executed. In applications containing C code, an entry point is also contained within the C library initialization code. Initialization code and exception handlers also contain entry points.

Application execution

The application code in Example 2-1 on page 2-15 begins executing at the label

start

where it loads the decimal values 10 and 3 into registers r0 and r1. These registers are added together and the result placed in r0.

Application termination

After executing the main code, the application terminates by returning control to the debugger. This is done using the ARM semihosting SWI (

0x123456 by default

), with

the following parameters:

• r0 equal to

• r1 equal to

angel_SWIreason_ReportException (0x18

ADP_Stopped_ApplicationExit (0x20026

)

Refer to the Semihosting SWIs chapter in ADS Debug Target Guide for additional information.

The END directive

This directive instructs the assembler to stop processing this source file. Every assembly

END

language source module must finish with an

directive on a line by itself.

2.3.3 Calling subroutines

To call subroutines, use a branch and link instruction. The syntax is:

BL destination

where

destination

is usually the label on the first instruction of the subroutine.

Writing ARM and Thumb Assembly Language

destination

can also be a program-relative or register-relative expression. Refer to B

and BL on page 4-58 for further information.

The

instruction:

• places the return address in the link register (lr)

• sets pc to the address of the subroutine.

After the subroutine code is executed you can use a

MOV pc,lr

convention, registers r0 to r3 are used to pass parameters to subroutines, and to pass results back to the callers.

Note

Calls between separately assembled or compiled modules must comply with the restrictions and conventions defined by the procedure call standard. Refer to the Using the Procedure Call Standard in ADS Developer Guide for more information.

Example 2-2 shows a subroutine that adds the values of its two parameters and returns a result in r0. It is supplied as

subrout.s

in the

examples\asm

to Code examples on page 2-2 for instructions on how to assemble, link, and execute the example.

AREA subrout, CODE, READONLY ; Name this block of code ENTRY ; Mark first instruction to execute start MOV r0, #10 ; Set up parameters MOV r1, #3 BL doadd ; Call subroutine stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI

instruction to return. By

subdirectory of ADS. Refer

Example 2-2

doadd ADD r0, r0, r1 ; Subroutine code MOV pc, lr ; Return from subroutine END ; Mark end of file

Writing ARM and Thumb Assembly Language

2.3.4 An example Thumb assembly language module

Example 2-3 illustrates some of the core constituents of a Thumb assembly language module. It is based on

subrout.s

. It is supplied as

thumbsub.s

in the subdirectory of the ADS. Refer to Code examples on page 2-2 for instructions on how to assemble, link, and execute the example.

AREA ThumbSub, CODE, READONLY ; Name this block of code ENTRY ; Mark first instruction to execute CODE32 ; Subsequent instructions are ARM header ADR r0, start + 1 ; Processor starts in ARM state, BX r0 ; so small ARM code header used ; to call Thumb main program CODE16 ; Subsequent instructions are Thumb start MOV r0, #10 ; Set up parameters MOV r1, #3 BL doadd ; Call subroutine stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0xAB ; Thumb semihosting SWI doadd ADD r0, r0, r1 ; Subroutine code MOV pc, lr ; Return from subroutine END ; Mark end of file

examples\asm

Example 2-3

CODE32 and CODE16 directives

These directives instruct the assembler to assemble subsequent instructions as ARM

CODE32

(

) or Thumb (

CODE16

) instructions. They do not assemble to an instruction to

change the processor state at runtime. They only change the assembler state.

The ARM assembler,

armasm

, starts in ARM mode by default. You can use the

-16

option

in the command line if you want it to start in Thumb mode.

BX instruction

This instruction is a branch that can change processor state at runtime. The least significant bit of the target address specifies whether it is an ARM instruction (clear) or

ADR

a Thumb instruction (set). In this example, this bit is set in the

pseudo-instruction.

2.4 Using the C preprocessor

Writing ARM and Thumb Assembly Language

You can include the C preprocessor command

#include

in your assembly language source file. If you do this, you must preprocess the file using the C preprocessor, before using

armasm

to assemble it. See ADS Compilers and Libraries Guide.

armasm

correctly interprets

messages and

debug_line

#line

commands in the resulting file. It can generate error

tables using the information in the

#line

commands.

Example 2-4 shows the commands you write to preprocess and assemble a file,

sourcefile.s armasm

armcpp -E < sourcefile.s > preprocessedfile.s armasm preprocessedfile.s

. In this example, the preprocessor outputs a file called

assembles

preprocessed.s

Example 2-4 Preprocessing an assembly language source file

preprocessed.s

, and

Writing ARM and Thumb Assembly Language

2.5 Conditional execution

In ARM state, each data processing instruction has an option to update ALU status flags in the Current Program Status Register (CPSR) according to the result of the operation.

Add an flags in the CPSR.

suffix to an ARM data processing instruction to make it update the ALU status

Do not use the update the flags. This is their only effect.

In Thumb state, there is no option. All data processing instructions update the ALU status flags in the CPSR, except when one or more high registers are used in instructions.

Almost every ARM instruction can be executed conditionally on the state of the ALU status flags in the CPSR. Refer to Table 2-1 on page 2-21 for a list of the suffixes to add to instructions to make them conditional.

In ARM state, you can:

• update the ALU status flags in the CPSR on the result of a data operation

• execute several other data operations without updating the flags

• execute following instructions or not, according to the state of the flags updated

in the first operation.

In Thumb state, most data operations always update the flags, and conditional execution can only be achieved using the conditional branch instruction ( instruction are the same as in ARM state. No other instruction can be conditional.

2.5.1 The ALU status flags

The CPSR contains the following ALU status flags:

N Set when the result of the operation was Negative.

Z Set when the result of the operation was Zero.

C Set when the operation resulted in a Carry.

V Set when the operation caused oVerflow.

Q ARM architecture v5E only. Sticky flag (see The Q flag on page 4-5).

suffix with

MOV

and

CMP, CMN, TST

ADD

cannot update the status flags in these cases.

, or

TEQ

. These comparison instructions always

MOV

and

). The suffixes for this

ADD

A carry occurs if the result of an addition is greater than or equal to 2

, if the result of a subtraction is positive, or as the result of an inline barrel shifter operation in a move or logical instruction.

Overflow occurs if the result of an add, subtract, or compare is greater than or equal to

, or less than –231.

2.5.2 Execution conditions

Writing ARM and Thumb Assembly Language

The relation of condition code suffixes to the

N, Z, C

Suffix Flags Meaning

EQ Z

NE Z

CS/HS C

CC/LO C

MI N

PL N

VS V

VC V

HI C

LS C

GE N

LT N

set Equal

clear Not equal

set Higher or same (unsigned >= )

clear Lower (unsigned < )

set Negative

clear Positive or zero

set Overflow

clear No overflow

set and Z clear Higher (unsigned > )

clear or Z set Lower or same (unsigned <= )

and V the same Signed >=

and V differ Signed <

and V flags is shown in Table 2-1.

Table 2-1 Condition code suffixes

GT Z

LE Z

clear, N and V the same Signed >

set, N and V differ Signed <=

Any Always. This suffix is normally omitted.

Examples

ADD r0, r1, r2 ; r0 = r1 + r2, don't update flags

ADDS r0, r1, r2 ; r0 = r1 + r2, and update flags

ADDCSS r0, r1, r2 ; If C flag set then r0 = r1 + r2, and update flags

CMP r0, r1 ; update flags based on r0-r1.

Writing ARM and Thumb Assembly Language

2.5.3 Using conditional execution in ARM state

You can use conditional execution of ARM instructions to reduce the number of branch instructions in your code. This improves code density.

Branch instructions are also expensive in processor cycles. On ARM processors without branch prediction hardware, it typically takes three processor cycles to refill the processor pipeline each time a branch is taken.

Some ARM processors, for example ARM10 prediction hardware. In systems using these processors, the pipeline only needs to be flushed and refilled when there is a misprediction.

2.5.4 Example of the use of conditional execution

This example uses two implementations of Euclid’s Greatest Common Divisor (gcd) algorithm. It demonstrates how you can use conditional execution to improve code density and execution speed. The detailed analysis of execution speed only applies to an ARM7™ processor. The code density calculations apply to all ARM processors.

In C the algorithm can be expressed as:

int gcd(int a, int b) { while (a != b) do { if (a > b) a = a - b; else b = b - a; } return a; }

™

and StrongARM®, have branch

You can implement the gcd function with conditional execution of branches only, in the following way:

gcd CMP r0, r1 BEQ end BLT less SUB r0, r0, r1 B gcd less SUB r1, r1, r0 B gcd end

Writing ARM and Thumb Assembly Language

Because of the number of branches, the code is seven instructions long. Every time a branch is taken, the processor must refill the pipeline and continue from the new location. The other instructions and non-executed branches use a single cycle each.

By using the conditional execution feature of the ARM instruction set, you can implement the gcd function in only four instructions:

gcd CMP r0, r1 SUBGT r0, r0, r1 SUBLT r1, r1, r0 BNE gcd

In addition to improving code size, this code executes faster in most cases. Table 2-2 and Table 2-3 on page 2-24 show the number of cycles used by each implementation for the case where r0 equals 1 and r1 equals 2. In this case, replacing branches with conditional execution of all instructions saves three cycles.

The conditional version of the code executes in the same number of cycles for any case where r0 equals r1. In all other cases, the conditional version of the code executes in fewer cycles.

Table 2-2 Conditional branches only

r0: a r1: b Instruction Cycles (ARM7)

CMP r0, r1

BEQ end

BLT less

SUB r1, r1, r0

B gcd

CMP r0, r1

BEQ end

1 (not executed)

Total = 13

Writing ARM and Thumb Assembly Language

r0: a r1: b Instruction Cycles (ARM7)

Table 2-3 All instructions conditional

CMP r0, r1

SUBGT r0,r0,r1

SUBLT r1,r1,r0

BNE gcd

CMP r0,r1

SUBGT r0,r0,r1

SUBLT r1,r1,r0

BNE gcd

1 (not executed)

Total = 10

Converting to Thumb

Because

is the only Thumb instruction that can be executed conditionally, the gcd

algorithm must be written with conditional branches in Thumb code.

Like the ARM conditional branch implementation, the Thumb code requires seven instructions. However, because Thumb instructions are only 16 bits long, the overall code size is 14 bytes, compared to 16 bytes for the smaller ARM implementation.

In addition, on a system using 16-bit memory the Thumb version runs faster than the second ARM implementation because only one memory access is required for each Thumb instruction, whereas each ARM instruction requires two fetches.

Branch prediction and caches

To optimize code for execution speed you need detailed knowledge of the instruction timings, branch prediction logic, and cache behavior of your target system. Refer to ARM Architecture Reference Manual and the technical reference manuals for individual processors for full information.

2.6 Loading constants into registers

You cannot load an arbitrary 32-bit immediate constant into a register in a single instruction without performing a data load from memory. This is because ARM instructions are only 32 bits long.

Thumb instructions have a similar limitation.

You can load any 32-bit value into a register with a data load, but there are more direct and efficient ways to load many commonly-used constants. You can also include many commonly-used constants directly as operands within data-processing instructions, without a separate load operation at all.

The following sections describe:

• how to use the Direct loading with MOV and MVN on page 2-26

• how to use the with LDR Rd, =const on page 2-27

• how to load floating-point constants, see Loading floating-point constants on page 2-29.

MOV

and

MVN

LDR

pseudo-instruction to load any 32-bit constant, see Loading

Writing ARM and Thumb Assembly Language

instructions to load a range of immediate values, see

Writing ARM and Thumb Assembly Language

2.6.1 Direct loading with MOV and MVN

In ARM state, you can use the

MOV

and

MVN

instructions to load a range of 8-bit constant

values directly into a register:

•

MOV

can load any 8-bit constant value, giving a range of

0x0

0xFF

(0-255).

It can also rotate these values by any even number. Table 2-4 shows the range of values that this provides.

•

MVN

can load the bitwise complement of these values. The numerical values are

-(n+1)

, where n are the values given in Table 2-4.

You do not need to calculate the necessary rotation. The assembler performs the calculation for you.

MOV

MVN

You do not need to decide whether to use

. The assembler uses whichever is

appropriate. This is useful if the value is an assembly-time variable.

If you write an instruction with a constant that cannot be constructed, the assembler reports the error:

Immediate n out of range for this operation

The range of values shown in Table 2-4 can also be used as one of the operands in data-processing operations. You cannot use their bitwise complements as operands, and you cannot use them as operands in multiplication operations.

Table 2-4 ARM-state immediate constants

Rotate Binary Decimal Step Hexadecimal

No rotate

Right, 30 bits

Right, 28 bits

Right, 26 bits

000000000000000000000000xxxxxxxx

0000000000000000000000xxxxxxxx00

00000000000000000000xxxxxxxx0000

000000000000000000xxxxxxxx000000

0-255 1

0-1020 4

0-4080 16

0-16320 64

0-0xFF

0-0x3FC

0-0xFF0

0-0x3FC0

... ... ... ...

Right, 8 bits

Right, 6 bits

Right, 4 bits

Right, 2 bits

xxxxxxxx000000000000000000000000

xxxxxx000000000000000000000000xx

xxxx000000000000000000000000xxxx

xx000000000000000000000000xxxxxx

0-255 x 2

---

0-0xFF000000

Direct loading with MOV in Thumb state

Writing ARM and Thumb Assembly Language

In Thumb state you can use the cannot generate constants outside this range because:

• The Thumb Constants cannot be right-rotated as they can in ARM state.

• The Thumb Bitwise complements cannot be directly loaded as they can in ARM state.

If you attempt to use a assembler reports the error:

Immediate n out of range for this operation

2.6.2 Loading with LDR Rd, =const

LDR Rd,=const

The single instruction. Use this pseudo-instruction to generate constants that are out of range of the

MOV

and

MVN

LDR

The

pseudo-instruction generates the most efficient code for a specific constant:

• If the constant can be constructed with a generates the appropriate instruction.

• If the constant cannot be constructed with a

— places the value in a literal pool (a portion of memory embedded in the code

to hold constant values)

— generates an

constant from the literal pool.

For example:

LDR rn, [pc, #offset to literal pool] ; load register n with one word ; from the address [pc + offset]

You must ensure that there is a literal pool within range of the generated by the assembler. Refer to Placing literal pools on page 2-28 for more information.

MOV

instruction to load constants in the range 0-255. You

MOV

instruction does not provide inline access to the barrel shifter.

MVN

instruction can act only on registers and not on constant values.

MOV

instruction with a value outside the range 0-255, the

pseudo-instruction can construct any 32-bit numeric constant in a

instructions.

MOV

MVN

instruction, the assembler

MOV

MVN

instruction, the assembler:

LDR

instruction with a program-relative address that reads the

LDR

instruction

Refer to LDR ARM pseudo-instruction on page 4-82 for a description of the syntax of the

LDR

pseudo-instruction.

Writing ARM and Thumb Assembly Language

Placing literal pools

The assembler places a literal pool at the end of each section. These are defined by the

AREA

directive at the start of the following section, or by the the assembly. The a section.

END

directive at the end of

END

directive at the end of an included file does not signal the end of

In large sections the default literal pool can be out of range of one or more

LDR

instructions. The offset from the pc to the constant must be:

• less than 4KB in ARM state, but can be in either direction

• forward and less than 1KB in Thumb state.

When an

LDR Rd,=const

pseudo-instruction requires the constant to be placed in a literal

pool, the assembler:

• Checks if the constant is available and addressable in any previous literal pools.

If so, it addresses the existing constant.

• Attempts to place the constant in the next literal pool if it is not already available.

If the next literal pool is out of range, the assembler generates an error message. In this case you must use the the

LTORG

directive after the failed

LTORG

directive to place an additional literal pool in the code. Place

LDR

pseudo-instruction, and within 4KB (ARM) or

1KB (Thumb). Refer to LTORG on page 7-14 for a detailed description.

You must place literal pools where the processor does not attempt to execute them as instructions. Place them after unconditional branch instructions, or after the return instruction at the end of a subroutine.

Example 2-5 shows how this works in practice. It is supplied as

examples\asm

subdirectory of the ADS. The instructions listed as comments are the

loadcon.s

in the

ARM instructions that are generated by the assembler. Refer to Code examples on page 2-2 for instructions on how to assemble, link, and execute the example.

Example 2-5

AREA Loadcon, CODE, READONLY ENTRY ; Mark first instruction to execute start BL func1 ; Branch to first subroutine BL func2 ; Branch to second subroutine stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI func1 LDR r0, =42 ; => MOV R0, #42 LDR r1, =0x55555555 ; => LDR R1, [PC, #offset to ; Literal Pool 1]

LDR r2, =0xFFFFFFFF ; => MVN R2, #0 MOV pc, lr LTORG ; Literal Pool 1 contains ; literal Ox55555555 func2 LDR r3, =0x55555555 ; => LDR R3, [PC, #offset to ; Literal Pool 1] ; LDR r4, =0x66666666 ; If this is uncommented it ; fails, because Literal Pool 2 ; is out of reach MOV pc, lr LargeTable SPACE 4200 ; Starting at the current location, ; clears a 4200 byte area of memory ; to zero END ; Literal Pool 2 is empty

2.6.3 Loading floating-point constants

You can load any single-precision or double-precision floating-point constant in a single instruction, using the

FLD

Refer to FLD pseudo-instruction on page 6-38 for details.

Writing ARM and Thumb Assembly Language

pseudo-instructions.

Writing ARM and Thumb Assembly Language

2.7 Loading addresses into registers

It is often necessary to load an address into a register. You might need to load the address of a variable, a string constant, or the start location of a jump table.

Addresses are normally expressed as offsets from the current pc or other register.

This section describes two methods for loading an address into a register:

• load the register directly, see Direct loading with ADR and ADRL.

• load the address from a literal pool, see Loading addresses with LDR Rd, = label

on page 2-35.

2.7.1 Direct loading with ADR and ADRL

The

ADR

and

ADRL

pseudo-instructions enable you to generate an address, within a certain

range, without performing a data load.

• A program-relative expression, which is a label with an optional offset, where the

address of the label is relative to the current pc.

• A register-relative expression, which is a label with an optional offset, where the

address of the label is relative to an address held in a specified general-purpose register. Refer to Describing data structures with MAP and FIELD directives on page 2-51 for information on specifying register-relative expressions.

ADR

and

ADRL

accept either of the following:

The assembler converts an

• a single

ADD

ADR rn,label

SUB

instruction that loads the address, if it is in range

pseudo-instruction by generating:

• an error message if the address cannot be reached in a single instruction.

The offset range is ±255 bytes for an offset to a non word-aligned address, and ±1020 bytes (255 words) for an offset to a word-aligned address. (For Thumb, the address must be word aligned, and the offset must be positive.)

The assembler converts an

ADRL rn,label

pseudo-instruction by generating:

• two data-processing instructions that load the address, if it is in range

• an error message if the address cannot be constructed in two instructions.

The range of an ±256KB for a word-aligned address. (There is no

ADRL

assembles to two instructions, if successful. The assembler generates two

ADRL

pseudo-instruction is ±64KB for a non word-aligned address and

ADRL

pseudo-instruction for Thumb.)

instructions even if the address could be loaded in a single instruction.

Refer to Loading addresses with LDR Rd, = label on page 2-35 for information on loading addresses that are outside the range of the

ADRL

pseudo-instruction.

Writing ARM and Thumb Assembly Language

Note

The label used with

ADR

ADRL

must be within the same code section. The assembler faults references to labels that are out of range in the same section. The linker faults references to labels that are out of range in other code sections.

In Thumb state,

ADRL

is not available in Thumb code. Use it only in ARM code.

Example 2-6 shows the type of code generated by the assembler when assembling and

ADRL

pseudo-instructions. It is supplied as

ADR

can generate word-aligned addresses only.

adrlabel.s

in the

examples\asm

ADR

subdirectory of the ADS. Refer to Code examples on page 2-2 for instructions on how to assemble, link, and execute the example.

The instructions listed in the comments are the ARM instructions generated by the assembler.

Example 2-6

AREA adrlabel, CODE,READONLY ENTRY ; Mark first instruction to execute Start BL func ; Branch to subroutine stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI LTORG ; Create a literal pool func ADR r0, Start ; => SUB r0, PC, #offset to Start ADR r1, DataArea ; => ADD r1, PC, #offset to DataArea ; ADR r2, DataArea+4300 ; This would fail because the offset ; cannot be expressed by operand2 ; of an ADD ADRL r2, DataArea+4300 ; => ADD r2, PC, #offset1 ; ADD r2, r2, #offset2 MOV pc, lr ; Return DataArea SPACE 8000 ; Starting at the current location, ; clears a 8000 byte area of memory ; to zero END

Writing ARM and Thumb Assembly Language

Implementing a jump table with ADR

Example 2-7 on page 2-33 shows ARM code that implements a jump table. It is supplied as

jump.s

page 2-2 for instructions on how to assemble, link, and execute the example.

The

ADR

pseudo-instruction loads the address of the jump table.

in the

examples\asm

subdirectory of ADS. Refer to Code examples on

In the example, the function

arithfunc

takes three arguments and returns a result in r0. The first argument determines which operation is carried out on the second and third arguments:

argument1=0 Result = argument2 + argument3.

argument1=1 Result = argument2 – argument3.

The jump table is implemented with the following instructions and assembler directives:

EQU

Is an assembler directive. It is used to give a value to a symbol. In this

example it assigns the value 2 to code, the value 2 is substituted. Using

#define

DCD

Declares one or more words of store. In this example each

to define a constant in C.

num

. When

num

is used elsewhere in the

EQU

in this way is similar to using

DCD

stores the

address of a routine that handles a particular clause of the jump table.

LDR

The

LDR pc,[r3,r0,LSL#2]

instruction loads the address of the required

clause of the jump table into the pc. It:

• multiplies the clause number in r0 by 4 to give a word offset

• adds the result to the address of the jump table

• loads the contents of the combined address into the program

counter.

Writing ARM and Thumb Assembly Language

Example 2-7 ARM code jump table

AREA Jump, CODE, READONLY ; Name this block of code CODE32 ; Following code is ARM code num EQU 2 ; Number of entries in jump table ENTRY ; Mark first instruction to execute start ; First instruction to call MOV r0, #0 ; Set up the three parameters MOV r1, #3 MOV r2, #2 BL arithfunc ; Call the function stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI arithfunc ; Label the function CMP r0, #num ; Treat function code as unsigned integer MOVHS pc, lr ; If code is >= num then simply return ADR r3, JumpTable ; Load address of jump table LDR pc, [r3,r0,LSL#2] ; Jump to the appropriate routine JumpTable DCD DoAdd DCD DoSub

DoAdd ADD r0, r1, r2 ; Operation 0 MOV pc, lr ; Return DoSub SUB r0, r1, r2 ; Operation 1 MOV pc, lr ; Return END ; Mark the end of this file

Writing ARM and Thumb Assembly Language

Converting to Thumb

Example 2-8 shows the implementation of the jump table converted to Thumb code.

Most of the Thumb version is the same as the ARM code. The differences are commented in the Thumb version.

In Thumb state, you cannot:

• increment the base register of

• load a value into the pc using an

LDR

and

LDR

STR

instructions

instruction

• do an inline shift of a value held in a register.

Example 2-8 Thumb code jump table

AREA Jump, CODE, READONLY CODE16 ; Following code is Thumb code num EQU 2 ENTRY start MOV r0, #0 MOV r1, #3 MOV r2, #2 BL arithfunc stop MOV r0, #0x18 LDR r1, =0x20026 SWI 0xAB ; Thumb semihosting SWI arithfunc CMP r0, #num BHS exit ; MOV pc, lr cannot be conditional ADR r3, JumpTable LSL r0, r0, #2 ; 3 instructions needed to replace LDR r0, [r3,r0] ; LDR pc, [r3,r0,LSL#2] MOV pc, r0 ALIGN ; Ensure that the table is aligned on a ; 4-byte boundary JumpTable DCD DoAdd DCD DoSub

DoAdd ADD r0, r1, r2 exit MOV pc, lr DoSub SUB r0, r1, r2 MOV pc, lr END

2.7.2 Loading addresses with LDR Rd, = label

The

LDR Rd,=

pseudo-instruction can load any 32-bit constant into a register. See Loading with LDR Rd, =const on page 2-27. It also accepts program-relative expressions such as labels, and labels with offsets.

Writing ARM and Thumb Assembly Language

The assembler converts an

• Placing the address of

LDR r0,=label

label

pseudo-instruction by:

in a literal pool (a portion of memory embedded in

the code to hold constant values).

• Generating a program-relative

LDR

instruction that reads the address from the

literal pool, for example:

LDR rn [pc, #offset to literal pool] ; load register n with one word ; from the address [pc + offset]

You must ensure that there is a literal pool within range. Refer to Placing literal pools on page 2-28 for more information.

Unlike the

ADR

and

ADRL

pseudo-instructions, you can use

LDR

with labels that are outside the current section. If the label is outside the current section, the assembler places a relocation directive in the object code when the source file is assembled. The relocation directive instructs the linker to resolve the address at link time. The address remains valid wherever the linker places the section containing the

Example 2-9 shows how this works. It is supplied as

LDR

and the literal pool.

ldrlabel.s

in the

examples\asm

subdirectory of the ADS. Refer to Code examples on page 2-2 for instructions on how to assemble, link, and execute the example.

The instructions listed in the comments are the ARM instructions that are generated by the assembler.

Example 2-9

AREA LDRlabel, CODE,READONLY ENTRY ; Mark first instruction to execute start BL func1 ; Branch to first subroutine BL func2 ; Branch to second subroutine stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI func1 LDR r0, =start ; => LDR R0,[PC, #offset into

Writing ARM and Thumb Assembly Language

; Literal Pool 1] LDR r1, =Darea + 12 ; => LDR R1,[PC, #offset into ; Literal Pool 1] LDR r2, =Darea + 6000 ; => LDR R2, [PC, #offset into ; Literal Pool 1] MOV pc,lr ; Return LTORG ; Literal Pool 1 func2 LDR r3, =Darea + 6000 ; => LDR r3, [PC, #offset into ; Literal Pool 1] ; (sharing with previous literal) ; LDR r4, =Darea + 6004 ; If uncommented produces an error ; as Literal Pool 2 is out of range MOV pc, lr ; Return Darea SPACE 8000 ; Starting at the current location, ; clears a 8000 byte area of memory ; to zero END ; Literal Pool 2 is out of range of ; the LDR instructions above

Writing ARM and Thumb Assembly Language

An LDR Rd, =label example: string copying

Example 2-10 shows an ARM code routine that overwrites one string with another string. It uses the

LDR

pseudo-instruction to load the addresses of the two strings from a

data section. The following are particularly significant:

DCB

The

DCB

values,

directive defines one or more bytes of store. In addition to integer

DCB

accepts quoted strings. Each character of the string is placed

in a consecutive byte. Refer to DCB on page 7-18 for more information.

LDR/STR

The

LDR

and

STR

instructions use post-indexed addressing to update their

address registers. For example, the instruction:

LDRB r2,[r1],#1

loads r2 with the contents of the address pointed to by r1 and then increments r1 by 1.

Example 2-10 String copy

AREA StrCopy, CODE, READONLY ENTRY ; Mark first instruction to execute start LDR r1, =srcstr ; Pointer to first string LDR r0, =dststr ; Pointer to second string BL strcopy ; Call subroutine to do copy stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI strcopy LDRB r2, [r1],#1 ; Load byte and update address STRB r2, [r0],#1 ; Store byte and update address CMP r2, #0 ; Check for zero terminator BNE strcopy ; Keep going if not MOV pc,lr ; Return

AREA Strings, DATA, READWRITE srcstr DCB "First string - source",0 dststr DCB "Second string - destination",0 END

Writing ARM and Thumb Assembly Language

Converting to Thumb

There is no post-indexed addressing mode for Thumb of this, you must use an and

STR

instructions. For example:

LDRB r2, [r1] ; load register 2 ADD r1, #1 ; increment the address in ; register 1.

ADD

instruction to increment the address register after the

LDR

and

STR

instructions. Because

LDR

Writing ARM and Thumb Assembly Language

2.8 Load and store multiple register instructions

The ARM and Thumb instruction sets include instructions that load and store multiple registers to and from memory.

Multiple register transfer instructions provide an efficient way of moving the contents of several registers to and from memory. They are most often used for block copy and for stack operations at subroutine entry and exit. The advantages of using a multiple register transfer instruction instead of a series of single data transfer instructions include:

• Smaller code size.

• A single instruction fetch overhead, rather than many instruction fetches.

• On uncached ARM processors, the first word of data transferred by a load or store

multiple is always a nonsequential memory cycle, but all subsequent words transferred can be sequential memory cycles. Sequential memory cycles are faster in most systems.

Note

The lowest numbered register is transferred to or from the lowest memory address accessed, and the highest numbered register to or from the highest address accessed. The order of the registers in the register list in the instructions makes no difference.

Use the

-checkreglist

assembler command line option to check that registers in register lists are specified in increasing order. Refer to Command syntax on page 3-2 for further information.

Writing ARM and Thumb Assembly Language

2.8.1 ARM LDM and STM instructions

The load (or store) multiple instruction loads (stores) any subset of the 16 general-purpose registers from (to) memory, using a single instruction.

Syntax

The syntax of the

LDM{cond}address-mode Rn{!},reg-list{^}

LDM

where:

instructions is:

cond

is an optional condition code. Refer to Conditional execution on page 2-20 for more information.

address-mode

specifies the addressing mode of the instruction. Refer to LDM and STM addressing modes on page 2-41 for details.

is the base register for the load operation. The address stored in this register is the starting address for the load operation. Do not specify r15 (pc) as the base register.

specifies base register write back. If this is specified, the address in the base register is updated after the transfer. It is decremented or incremented by one word for each register in the register list.

is a comma-delimited list of symbolic register names and register ranges enclosed in braces. There must be at least one register in the list. Register ranges are specified with a dash. For example:

{r0,r1,r4-r6,pc}

Do not specify writeback if the base register Rn is in

You must not use this option in User or System mode. For details of its use in privileged modes, see the Handling Processor Exceptions chapter in ADS Developer Guide and LDM and STM on page 4-18.

The syntax of the effect of the

option.

STM

instruction corresponds exactly, except for some details in the

Usage

See Implementing stacks with LDM and STM on page 2-42 and Block copy with LDM and STM on page 2-44.

2.8.2 LDM and STM addressing modes

There are four different addressing modes. The base register can be incremented or decremented by one word for each register in the operation, and the increment or decrement can occur before or after the operation. The suffixes for these options are:

Writing ARM and Thumb Assembly Language

Increment after.

Increment before.

Decrement after.

Decrement before.

There are alternative addressing mode suffixes that are easier to use for stack operations. See Implementing stacks with LDM and STM on page 2-42.

Writing ARM and Thumb Assembly Language

2.8.3 Implementing stacks with LDM and STM

The load and store multiple instructions can update the base register. For stack operations, the base register is usually the stack pointer, r13. This means that you can use load and store multiple instructions to implement push and pop operations for any number of registers in a single instruction.

The load and store multiple instructions can be used with several types of stack:

Descending or ascending

The stack grows downwards, starting with a high address and progressing to a lower one (a descending stack), or upwards, starting from a low address and progressing to a higher address (an ascending stack).

Full or empty

The stack pointer can either point to the last item in the stack (a full stack), or the next free space on the stack (an empty stack).

To make it easier for the programmer, stack-oriented suffixes can be used instead of the increment or decrement and before or after suffixes. Refer to Table 2-5 for a list of stack-oriented suffixes.

Table 2-5 Suffixes for load and store multiple instructions

Stack type Push Pop

Full descending

Full ascending

Empty descending

Empty ascending

STMFD (STMDB) LDMFD (LDMIA)

STMFA (STMIB) LDMFA (LDMDA)

STMED (STMDA) LDMED (LDMIB)

STMEA (STMIA) LDMEA (LDMDB)

For example:

STMFD r13!, {r0-r5} ; Push onto a Full Descending Stack LDMFD r13!, {r0-r5} ; Pop from a Full Descending Stack.

Note

The ARM-Thumb Procedure Call Standard (ATPCS), and ARM and Thumb C and C++ compilers always use a full descending stack.

Writing ARM and Thumb Assembly Language

Stacking registers for nested subroutines

Stack operations are very useful at subroutine entry and exit. At the start of a subroutine, any working registers required can be stored on the stack, and at exit they can be popped off again.

In addition, if the link register is pushed onto the stack at entry, additional subroutine calls can safely be made without causing the return address to be lost. If you do this, you can also return from a subroutine by popping the pc off the stack at exit, instead of popping lr and then moving that value into the pc. For example:

subroutine STMFD sp!, {r5-r7,lr} ; Push work registers and lr ; code BL somewhere_else ; code LDMFD sp!, {r5-r7,pc} ; Pop work registers and pc

Note

Use this with care in mixed ARM and Thumb systems. In ARM architecture v4T systems, you cannot change state by popping directly into the program counter.

In ARM architecture v5T and above, you can change state in this way.

See the Interworking ARM and Thumb chapter in ADS Developer Guide for further information on mixing ARM and Thumb.

Writing ARM and Thumb Assembly Language

2.8.4 Block copy with LDM and STM

Example 2-11 is an ARM code routine that copies a set of words from a source location to a destination by copying a single word at a time. It is supplied as

examples\asm

subdirectory of the ADS. Refer to Code examples on page 2-2 for

word.s

instructions on how to assemble, link, and execute the example.

Example 2-11 Block copy

AREA Word, CODE, READONLY ; name this block of code num EQU 20 ; set number of words to be copied ENTRY ; mark the first instruction to call start LDR r0, =src ; r0 = pointer to source block LDR r1, =dst ; r1 = pointer to destination block MOV r2, #num ; r2 = number of words to copy wordcopy LDR r3, [r0], #4 ; load a word from the source and STR r3, [r1], #4 ; store it to the destination SUBS r2, r2, #1 ; decrement the counter BNE wordcopy ; ... copy more stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI

in the

AREA BlockData, DATA, READWRITE src DCD 1,2,3,4,5,6,7,8,1,2,3,4,5,6,7,8,1,2,3,4 dst DCD 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 END

This module can be made more efficient by using

LDM

and

STM

for as much of the copying as possible. Eight is a sensible number of words to transfer at a time, given the number of registers that the ARM has. The number of eight-word multiples in the block to be copied can be found (if r2 = number of words to be copied) using:

MOVS r3, r2, LSR #3 ; number of eight word multiples

This value can be used to control the number of iterations through a loop that copies eight words per iteration. When there are less than eight words left, the number of words left can be found (assuming that r2 has not been corrupted) using:

ANDS r2, r2, #7

Example 2-12 on page 2-45 lists the block copy module rewritten to use

LDM

and

STM

for

copying.

Writing ARM and Thumb Assembly Language

Example 2-12

AREA Block, CODE, READONLY ; name this block of code num EQU 20 ; set number of words to be copied ENTRY ; mark the first instruction to call start LDR r0, =src ; r0 = pointer to source block LDR r1, =dst ; r1 = pointer to destination block MOV r2, #num ; r2 = number of words to copy MOV sp, #0x400 ; Set up stack pointer (r13) blockcopy MOVS r3,r2, LSR #3 ; Number of eight word multiples BEQ copywords ; Less than eight words to move? STMFD sp!, {r4-r11} ; Save some working registers octcopy LDMIA r0!, {r4-r11} ; Load 8 words from the source STMIA r1!, {r4-r11} ; and put them at the destination SUBS r3, r3, #1 ; Decrement the counter BNE octcopy ; ... copy more LDMFD sp!, {r4-r11} ; Don't need these now - restore ; originals copywords ANDS r2, r2, #7 ; Number of odd words to copy BEQ stop ; No words left to copy? wordcopy LDR r3, [r0], #4 ; Load a word from the source and STR r3, [r1], #4 ; store it to the destination SUBS r2, r2, #1 ; Decrement the counter BNE wordcopy ; ... copy more stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0x123456 ; ARM semihosting SWI

AREA BlockData, DATA, READWRITE src DCD 1,2,3,4,5,6,7,8,1,2,3,4,5,6,7,8,1,2,3,4 dst DCD 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 END

Writing ARM and Thumb Assembly Language

2.8.5 Thumb LDM and STM instructions

The Thumb instruction set contains two pairs of multiple-register transfer instructions:

•

LDM

and

STM

for block memory transfers

•

PUSH

and

POP

for stack operations.

LDM and STM

These instructions can be used to load or store any subset of the low registers from or to memory. The base register is always updated at the end of the multiple register transfer instruction. You must specify the instructions is

Examples of these instructions are:

LDMIA r1!, {r0,r2-r7} STMIA r4!, {r0-r3}

PUSH and POP

These instructions can be used to push any subset of the low registers and (optionally) the link register onto the stack, and to pop any subset of the low registers and (optionally) the pc off the stack. The base address of the stack is held in r13. Examples of these instructions are:

character. The only valid suffix for these

PUSH {r0-r3} POP {r0-r3} PUSH {r4-r7,lr} POP {r4-r7,pc}

The optional addition of the lr or pc to the register list provides support for subroutine entry and exit.

The stack is always full descending.

Thumb-state block copy example

The block copy example, Example 2-11 on page 2-44, can be converted into Thumb instructions (see Example 2-13 on page 2-47).

LDM

and

STM

Because the Thumb number of words copied per iteration is reduced from eight to four. In addition, the and

STM

instructions can be used to carry out the single word at a time copy, because they

update the base pointer after each access. If

instructions can access only the low registers, the

LDR

and

STR

were used for this, separate

LDM

ADD

instructions would be required to update each base pointer.

Writing ARM and Thumb Assembly Language

Example 2-13

AREA Tblock, CODE, READONLY ; Name this block of code num EQU 20 ; Set number of words to be copied ENTRY ; Mark first instruction to execute header ; The first instruction to call MOV sp, #0x400 ; Set up stack pointer (r13) ADR r0, start + 1 ; Processor starts in ARM state, BX r0 ; so small ARM code header used ; to call Thumb main program CODE16 ; Subsequent instructions are Thumb start LDR r0, =src ; r0 =pointer to source block LDR r1, =dst ; r1 =pointer to destination block MOV r2, #num ; r2 =number of words to copy blockcopy LSR r3,r2, #2 ; Number of four word multiples BEQ copywords ; Less than four words to move? PUSH {r4-r7} ; Save some working registers quadcopy LDMIA r0!, {r4-r7} ; Load 4 words from the source STMIA r1!, {r4-r7} ; and put them at the destination SUB r3, #1 ; Decrement the counter BNE quadcopy ; ... copy more POP {r4-r7} ; Don't need these now-restore originals copywords MOV r3, #3 ; Bottom two bits represent number AND r2, r3 ; ...of odd words left to copy BEQ stop ; No words left to copy? wordcopy LDMIA r0!, {r3} ; load a word from the source and STMIA r1!, {r3} ; store it to the destination SUB r2, #1 ; Decrement the counter BNE wordcopy ; ... copy more stop MOV r0, #0x18 ; angel_SWIreason_ReportException LDR r1, =0x20026 ; ADP_Stopped_ApplicationExit SWI 0xAB ; Thumb semihosting SWI

AREA BlockData, DATA, READWRITE src DCD 1,2,3,4,5,6,7,8,1,2,3,4,5,6,7,8,1,2,3,4 dst DCD 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 END

Writing ARM and Thumb Assembly Language

2.9 Using macros

A macro definition is a block of code enclosed between defines a name that can be used instead of repeating the whole block of code. This has two main uses:

• to make it easier to follow the logic of the source code, by replacing a block of

code with a single, meaningful name

• to avoid repeating a block of code several times.

Refer to MACRO and MEND on page 7-27 for more details.

2.9.1 Test-and-branch macro example

A test-and-branch operation requires two ARM instructions to implement.

You can define a macro definition such as this:

MACRO $label TestAndBranch $dest, $reg, $cc

$label CMP $reg, #0 B$cc $dest MEND

The line after the

MACRO

statement defines the name ( parameters (

$label, $dest, $reg

you invoke the macro. The assembler substitutes the values you give into the code.

MACRO

and

MEND

directives. It

directive is the macro prototype statement. The macro prototype

TestAndBranch

, and

) you use to invoke the macro. It also defines

$cc

). You must give values to the parameters when

This macro can be invoked as follows:

test TestAndBranch NonZero, r0, NE ... ... NonZero

After substitution this becomes:

test CMP r0, #0 BNE NonZero ... ... NonZero

2.9.2 Unsigned integer division macro example

Example 2-14 shows a macro that performs an unsigned integer division. It takes four parameters:

$Bot

The register that holds the divisor.

$Top

The register that holds the dividend before the instructions are executed.

After the instructions are executed, it holds the remainder.

$Div

The register where the quotient of the division is placed. It can be

(

) if only the remainder is required.

$Temp

A temporary register used during the calculation.

MACRO $Lab DivMod $Div,$Top,$Bot,$Temp ASSERT $Top <> $Bot ; Produce an error message if the ASSERT $Top <> $Temp ; registers supplied are ASSERT $Bot <> $Temp ; not all different IF "$Div" <> "" ASSERT $Div <> $Top ; These three only matter if $Div ASSERT $Div <> $Bot ; is not null ("") ASSERT $Div <> $Temp ; ENDIF $Lab MOV $Temp, $Bot ; Put divisor in $Temp CMP $Temp, $Top, LSR #1 ; double it until 90 MOVLS $Temp, $Temp, LSL #1 ; 2 * $Temp > $Top CMP $Temp, $Top, LSR #1 BLS %b90 ; The b means search backwards IF "$Div" <> "" ; Omit next instruction if $Div is null MOV $Div, #0 ; Initialize quotient ENDIF 91 CMP $Top, $Temp ; Can we subtract $Temp? SUBCS $Top, $Top,$Temp ; If we can, do so IF "$Div" <> "" ; Omit next instruction if $Div is null ADC $Div, $Div, $Div ; Double $Div ENDIF MOV $Temp, $Temp, LSR #1 ; Halve $Temp, CMP $Temp, $Bot ; and loop until BHS %b91 ; less than divisor MEND

Writing ARM and Thumb Assembly Language

NULL

Example 2-14

Writing ARM and Thumb Assembly Language

The macro checks that no two parameters use the same register. It also optimizes the code produced if only the remainder is required.

To avoid multiple definitions of labels if

DivMod

is used more than once in the assembler source, the macro uses local labels (90, 91). Refer to Local labels on page 2-13 for more information.

Example 2-15 shows the code that this macro produces if it is invoked as follows:

ratio DivMod r0,r5,r4,r2

Example 2-15

ASSERT r5 <> r4 ; Produce an error if the ASSERT r5 <> r2 ; registers supplied are ASSERT r4 <> r2 ; not all different ASSERT r0 <> r5 ; These three only matter if $Div ASSERT r0 <> r4 ; is not null ("") ASSERT r0 <> r2 ; ratio MOV r2, r4 ; Put divisor in $Temp CMP r2, r5, LSR #1 ; double it until 90 MOVLS r2, r2, LSL #1 ; 2 * r2 > r5 CMP r2, r5, LSR #1 BLS %b90 ; The b means search backwards MOV r0, #0 ; Initialize quotient 91 CMP r5, r2 ; Can we subtract r2? SUBCS r5, r5, r2 ; If we can, do so ADC r0, r0, r0 ; Double r0

MOV r2, r2, LSR #1 ; Halve r2, CMP r2, r4 ; and loop until BHS %b91 ; less than divisor

Writing ARM and Thumb Assembly Language

2.10 Describing data structures with MAP and FIELD directives

You can use the

MAP

and

FIELD

directives to describe data structures. These directives are

always used together.

MAP

and

FIELD

Data structures defined using

• are easily maintainable

• can be used to describe multiple instances of the same structure

• make it easy to access data efficiently.

The

MAP

directive specifies the base address of the data structure. Refer to MAP on

page 7-15 for further information.

The

FIELD

directive specifies the amount of memory required for a data item, and can give the data item a label. It is repeated for each data item in the structure. Refer to FIELD on page 7-16 for further information.

Note

No space in memory is allocated when a map is defined. Use define constant directives (for example,

DCD

) to allocate space in memory.

Writing ARM and Thumb Assembly Language

2.10.1 Relative maps

To access data more than 4KB away from the current instruction, you can use a register-relative instruction, such as:

LDR r4,[r9,#offset]

is limited to 4096, so r9 must already contain a value within 4KB of the address

offset

of the data.

MAP 0 consta FIELD 4 ; consta uses four bytes, located at offset 0 constb FIELD 4 ; constb uses four bytes, located at offset 4 x FIELD 8 ; x uses eight bytes, located at offset 8 y FIELD 8 ; y uses eight bytes, located at offset 16 string FIELD 256 ; string is up to 256 bytes long, starting at offset 24

Using the map in Example 2-16, you can access the data structure using the following instructions:

MOV r9,#4096 LDR r4,[r9,#constb]

Example 2-16

The labels are relative to the start of the data structure. The register used to hold the start address of the map (r9 in this case) is called the base register.

There are likely to be many

LDR

STR

instructions accessing data in this data structure.

This map does not contain the location of the data structure. The location of the structure is determined by the value loaded into the base register at runtime.

The same map can be used to describe many instances of the data structure. These can be located anywhere in memory.

MOV

There are restrictions on what addresses can be loaded into a register using the instruction. Refer to Loading addresses into registers on page 2-30 for details of how to load arbitrary addresses.

Note

r9 is the static base register (sb) in the ARM-Thumb Procedure Call Standard. Refer to the Using the Procedure Call Standard chapter in ADS Developer Guide for further information.

2.10.2 Register-based maps

In many cases, you can use the same register as the base register every time you access a data structure. You can include the name of the register in the base address of the map. Example 2-17 shows such a register-based map. The labels defined in the map include the register.

MAP 0,r9 consta FIELD 4 ; consta uses four bytes, located at offset 0 (from r9) constb FIELD 4 ; constb uses four bytes, located at offset 4 x FIELD 8 ; x uses eight bytes, located at offset 8 y FIELD 8 ; y uses eight bytes, located at offset 16 string FIELD 256 ; string is up to 256 bytes long, starting at offset 24

Using the map in Example 2-17, you can access the data structure wherever it is:

ADR r9,datastart LDR r4,constb ; => LDR r4,[r9,#4]

contains the offset of the data item from the start of the data structure, and also

constb

includes the base register. In this case the base register is r9, defined in the

Writing ARM and Thumb Assembly Language

Example 2-17

MAP

directive.

Writing ARM and Thumb Assembly Language

2.10.3 Program-relative maps

You can use the program counter (r15) as the base register for a map. In this case, each

STM

LDM

instruction must be within 4KB of the data item it addresses, because the offset is limited to 4KB. The data structure must be in the same section as the instructions, because otherwise there is no guarantee that the data items will be within range after linking.

Example 2-18 shows a program fragment with such a map. It includes a directive which allocates space in memory for the data structure, and an instruction which accesses it.

datastruc SPACE 280 ; reserves 280 bytes of memory for datastruc MAP datastruc consta FIELD 4 constb FIELD 4 x FIELD 8 y FIELD 8 string FIELD 256

code LDR r2,constb ; => LDR r2,[pc,offset]

Example 2-18

In this case, there is no need to load the base register before loading the data as the program counter already holds the correct address. (This is not actually the same as the address of the

LDR

instruction, because of pipelining in the processor. However, the

assembler takes care of this for you.)

2.10.4 Finding the end of the allocated data

Writing ARM and Thumb Assembly Language

You can use the

FIELD

directive with an operand of 0 to label a location within a

structure. The location is labeled, but the location counter is not incremented.

The size of the data structure defined in Example 2-19 depends on the values of

MaxStrLen

and

ArrayLen

. If these values are too large, the structure overruns the end of

available memory.

Example 2-19 uses:

• an

• a

EQU

directive to define the end of available memory

FIELD

directive with an operand of 0 to label the end of the data structure.

ASSERT

directive checks that the end of the data structure does not overrun the

available memory.

Example 2-19

StartOfData EQU 0x1000 EndOfData EQU 0x2000 MAP StartOfData Integer FIELD 4 Integer2 FIELD 4 String FIELD MaxStrLen Array FIELD ArrayLen*8 BitMask FIELD 4 EndOfUsedData FIELD 0 ASSERT EndOfUsedData <= EndOfData

Writing ARM and Thumb Assembly Language

2.10.5 Forcing correct alignment

You are likely to have problems if you include some character variables in the data structure, as in Example 2-20. This is because a lot of words are misaligned.

StartOfData EQU 0x1000 EndOfData EQU 0x2000 MAP StartOfData Char FIELD 1 Char2 FIELD 1 Char3 FIELD 1 Integer FIELD 4 ; alignment = 3 Integer2 FIELD 4 String FIELD MaxStrLen Array FIELD ArrayLen*8 BitMask FIELD 4 EndOfUsedData FIELD 0 ASSERT EndOfUsedData <= EndOfData

Example 2-20

You cannot use the location within memory.

ALIGN

directive, because the

MAP

and

FIELD

ALIGN

directive aligns the current

directives do not allocate any memory for the

structures they define.

You could insert a dummy

FIELD 1

after

Char3 FIELD 1

. However, this makes maintenance difficult if you change the number of character variables. You must recalculate the right amount of padding each time.

Example 2-21 on page 2-57 shows a better way of adjusting the padding. The example uses a

FIELD

directive with a 0 operand to label the end of the character data. A second

FIELD

directive inserts the correct amount of padding based on the value of the label. An

:AND:

operator is used to calculate the correct value.

(-EndOfChars):AND:3

The

0 if EndOfChars is 0 mod 4; 3 if EndOfChars is 1 mod 4; 2 if EndOfChars is 2 mod 4; 1 if EndOfChars is 3 mod 4.

expression calculates the correct amount of padding:

This automatically adjusts the amount of padding used whenever character variables are added or removed.

Writing ARM and Thumb Assembly Language

StartOfData EQU 0x1000 EndOfData EQU 0x2000 MAP StartOfData Char FIELD 1 Char2 FIELD 1 Char3 FIELD 1 EndOfChars FIELD 0 Padding FIELD (-EndOfChars):AND:3 Integer FIELD 4 Integer2 FIELD 4 String FIELD MaxStrLen Array FIELD ArrayLen*8 BitMask FIELD 4 EndOfUsedData FIELD 0 ASSERT EndOfUsedData <= EndOfData

Example 2-21

Writing ARM and Thumb Assembly Language

2.10.6 Using register-based MAP and FIELD directives

MAP

and

FIELD

directives define register-based symbols. There are two

main uses for register-based symbols:

• defining structures similar to C structures

• gaining faster access to memory sections described by non register-based

FIELD

directives.

MAP

and

Defining register-based symbols

Register-based symbols can be very useful, but you must be careful when using them. As a general rule, use them only in the following ways:

into

Location

LDR

• As the location for a load or store instruction to load from or store to. If

is a register-based symbol based on the register assembler automatically translates, for example,

ADRL

instruction,

ADR Rn,Location

Rn,[Rb,#offset]

In an

ADR

ADD Rn,Rb,#offset

and with numeric offset, the

LDR Rn,Location

is converted by the assembler into

• Adding an ordinary numeric expression to a register-based symbol to get another

• Subtracting an ordinary numeric expression from a register-based symbol to get

another register-based symbol.

• Subtracting a register-based symbol from another register-based symbol to get an

ordinary numeric expression. Do not do this unless the two register-based symbols are based on the same register. Otherwise, you have a combination of two registers and a numeric value. This results in an assembler error.

• As the operand of a

:BASE:

:INDEX:

operator. These operators are mainly of

use in macros.

Other uses usually result in assembler error messages. For example, if you write

Rn,=Location

, where

from a memory location that always has the current value of the register

Location

is register-based, you are asking the assembler to load Rn

LDR

plus offset

in it. It cannot do this, because there is no such memory location.

Similarly, if you write asking for a single its offset to

ADD

. Again, the assembler cannot do this. You must use two

ADD Rd,Rn,#expression

instruction that adds both the base register of the expression and

, and

expression

is register-based, you are

ADD

instructions

to perform these two additions.

Writing ARM and Thumb Assembly Language

Setting up a C-type structure

There are two stages to using structures in C:

1. Declaring the fields that the structure contains.

2. Generating the structure in memory and using it.

For example, the following three

float

fields named x, y and z, but it does not allocate any memory. The second

statement allocates three structures of type

newloc

typedef struct Point { float x,y,z; } Point;

Point origin,oldloc,newloc;

The following assembly language code is equivalent to the

PointBase RN r11 MAP 0,PointBase Point_x FIELD 4 Point_y FIELD 4 Point_z FIELD 4

typedef

statement defines a point structure that contains

Point

in memory, named

typedef

origin, oldloc

, and

statement above:

The following assembly language code allocates space in memory. This is equivalent to the last line of C code:

origin SPACE 12 oldloc SPACE 12 newloc SPACE 12

You must load the base address of the data structure into the base register before you can use the labels defined in the map. For example:

LDR PointBase,=origin MOV r0,#0 STR r0,Point_x MOV r0,#2 STR r0,Point_y MOV r0,#3 STR r0,Point_z

is equivalent to the C code:

origin.x = 0; origin.y = 2; origin.z = 3;

Writing ARM and Thumb Assembly Language

Making faster access possible

To gain faster access to a section of memory:

1. Describe the memory section as a structure.

2. Use a register to address the structure.

For example, consider the definitions in Example 2-22.

StartOfData EQU 0x1000 EndOfData EQU 0x2000 MAP StartOfData Integer FIELD 4 String FIELD MaxStrLen Array FIELD ArrayLen*8 BitMask FIELD 4 EndOfUsedData FIELD 0 ASSERT EndOfUsedData <= EndOfData

If you want the equivalent of the C code:

Example 2-22

Integer = 1; String = ""; BitMask = 0xA000000A;

With the definitions from Example 2-22, the assembly language code can be as shown in Example 2-23.

Example 2-23

MOV r0,#1 LDR r1,=Integer STR r0,[r1] MOV r0,#0 LDR r1,=String STRB r0,[r1] MOV r0,#0xA000000A LDR r1,=BitMask STRB r0,[r1]

Example 2-23 uses

LDR

pseudo-instructions. Refer to Loading with LDR Rd, =const on

page 2-27 for an explanation of these.

Writing ARM and Thumb Assembly Language

Example 2-23 on page 2-60 contains separate address of each of the data items. Each

LDR

pseudo-instructions to load the

LDR

pseudo-instruction is converted to a separate instruction by the assembler. However, it is possible to access the entire data section with a single

LDR

pseudo-instruction. Example 2-24 shows how to do this. Both speed

and code size are improved.

Example 2-24

AREA data, DATA StartOfData EQU 0x1000 EndOfData EQU 0x2000 DataAreaBase RN r11 MAP 0,DataAreaBase StartOfUsedData FIELD 0 Integer FIELD 4 String FIELD MaxStrLen Array FIELD ArrayLen*8 BitMask FIELD 4 EndOfUsedData FIELD 0 UsedDataLen EQU EndOfUsedData - StartOfUsedData ASSERT UsedDataLen <= (EndOfData - StartOfData)

AREA code, CODE LDR DataAreaBase,=StartOfData MOV r0,#1 STR r0,Integer MOV r0,#0 STRB r0,String MOV r0,#0xA000000A STRB r0,BitMask

Note

In this example, the

MAP 0, DataAreaBase

MAP

directive is:

not:

MAP StartOfData,DataAreaBase

MAP

and

FIELD

The

directives give the position of the data relative to the

LDR DataAreaBase,=StartOfData

DataAreaBase

statement

provides the absolute position of the entire data section.

Writing ARM and Thumb Assembly Language

If you use the same technique for a section of memory containing memory-mapped I/O (or whose absolute addresses must not change for other reasons), you must take care to keep the code maintainable.

One method is to add comments to the code warning maintainers to take care when modifying the definitions. A better method is to use definitions of the absolute addresses to control the register-based definitions.

Using

MAP offset,reg

symbol with register part

StartOfIOArea EQU 0x1000000 SendFlag_Abs EQU 0x1000000 SendData_Abs EQU 0x1000004 RcvFlag_Abs EQU 0x1000008 RcvData_Abs EQU 0x100000C IOAreaBase RN r11 MAP (SendFlag_Abs-StartOfIOArea),IOAreaBase SendFlag FIELD 0 MAP (SendData_Abs-StartOfIOArea),IOAreaBase SendData FIELD 0 MAP (RcvFlag_Abs-StartOfIOArea),IOAreaBase RcvFlag FIELD 0 MAP (RcvData_Abs-StartOfIOArea),IOAreaBase RcvData FIELD 0

followed by

reg

and numeric part

label FIELD 0

offset

makes

label

into a register-based

. Example 2-25 shows this.

Example 2-25

Load the base address with locations to be accessed with statements like

LDR IOAreaBase,=StartOfIOArea

LDR R0,RcvFlag

. This allows the individual

and

STR R4,SendData

2.10.7 Using two register-based structures

Sometimes you need to operate on two structures of the same type at the same time. For example, if you want the equivalent of the pseudo-code:

newloc.x = oldloc.x + (value in r0); newloc.y = oldloc.y + (value in r1); newloc.z = oldloc.z + (value in r2);

Writing ARM and Thumb Assembly Language

The base register needs to point alternately to the

oldloc

structure and to the Repeatedly changing the base register would be inefficient. Instead, use a non register-based map, and set up two pointers in two different registers as in Example 2-26.

Example 2-26

MAP 0 ; Non-register based relative map used twice, for Pointx FIELD 4 ; old and new data at oldloc and newloc Pointy FIELD 4 ; oldloc and newloc are labels for Pointz FIELD 4 ; memory allocated in other sections

; code

ADR r8,oldloc ADR r9,newloc LDR r3,[r8,Pointx] ; load from oldloc (r8) ADD r3,r3,r0 STR r3,[r9,Pointx] ; store to newloc (r9) LDR r3,[r8,Pointy] ADD r3,r3,r1 STR r3,[r9,Pointy] LDR r3,[r8,Pointz] ADD r3,r3,r2 STR r3,[r9,Pointz]

newloc

one.

Writing ARM and Thumb Assembly Language

2.10.8 Avoiding problems with MAP and FIELD directives

Using

MAP

and

FIELD

directives can help you to produce maintainable data structures. However, this is only true if the order the elements are placed in memory is not important to either the programmer or the program.

You can have problems if you load or store multiple elements of a structure in a single instruction. These problems arise in operations such as:

• loading several single-byte elements into one register

• using a store multiple or load multiple instruction (

multiple words from or to multiple registers.

These operations require the data elements in the structure to be contiguous in memory, and to be in a specific order. If the order of the elements is changed, or a new element is added, the program is broken in a way that cannot be detected by the assembler.

There are several methods for avoiding problems such as this.

Example 2-27 shows a sample structure.

STM

and

LDM

) to store or load

Example 2-27

MiscBase RN r10 MAP 0,MiscBase MiscStart FIELD 0 Misc_a FIELD 1 Misc_b FIELD 1 Misc_c FIELD 1 Misc_d FIELD 1 MiscEndOfChars FIELD 0 MiscPadding FIELD (-:INDEX:MiscEndOfChars) :AND: 3 Misc_I FIELD 4 Misc_J FIELD 4 Misc_K FIELD 4 Misc_data FIELD 4*20 MiscEnd FIELD 0 MiscLen EQU MiscEnd-MiscStart

There is no problem in using

LDM

and

STM

instructions for accessing single data elements that are larger than a word (for example, arrays). An example of this is the 20-word element

ArrayBase RN R9 ADR ArrayBase, MiscBase LDMIA ArrayBase, {R0-R5}

Misc_data

. It could be accessed as follows:

Writing ARM and Thumb Assembly Language

Example 2-27 on page 2-64 loads the first six items in the array

Misc_data

. The array is a single element and therefore covers contiguous memory locations. No one is likely to want to split it into separate arrays in the future.

However, for loading

Misc_I, Misc_J

, and

Misc_K

into registers r0, r1, and r2 the

following code works, but might cause problems in the future:

ArrayBase RN r9

ADR ArrayBase, Misc_I LDMIA ArrayBase, {r0-r2}

Problems arise if the order of

Misc_New

is added in the middle. Either of these small changes breaks the code.

Misc_I, Misc_J

, and

Misc_K

is changed, or if a new element

If these elements are accessed separately elsewhere, you must not amalgamate them into a single array element. In this case, you must amend the code. The first remedy is to comment the structure to prevent changes affecting this section:

Misc_I FIELD 4 ; ==} Do not split/reorder Misc_J FIELD 4 ; } these 3 elements, STM Misc_K FIELD 4 ; ==} and LDM instructions used.

If the code is strongly commented, no deliberate changes are likely to be made that affect the workings of the program. Unfortunately, mistakes can occur. A second method of catching these problems is to add

ASSERT

directives just before the

STM

and

LDM

instructions to check that the labels are consecutive and in the correct order:

ArrayBase RN R9

; Check that the structure elements ; are correctly ordered for LDM ASSERT (((Misc_J-Misc_I) = 4) :LAND: ((Misc_K-Misc_J) = 4)) ADR ArrayBase, Misc_I LDMIA ArrayBase, {r0-r2}

This

ASSERT

directive stops assembly at this point if the structure is not in the correct

order to be loaded with an

LDM

. Remember that the element with the lowest address is

always loaded from, or stored to, the lowest numbered register.

Writing ARM and Thumb Assembly Language

2.11 Using frame directives

You must use frame directives to describe the way that your code uses the stack if you want to be able to do either of the following:

• debug your application using stack unwinding

• use either flat or call-graph profiling.

Refer to Frame description directives on page 7-33 for details of these directives.

The assembler uses these directives to insert DWARF2 debug frame information into the object file in ELF format that it produces. This information is required by the debuggers for stack unwinding and for profiling. Refer to the Using the Procedure Call Standard chapter in ADS Developer Guide for further information about stack unwinding.

Frame directives do not affect the code produced by

armasm

Chapter 3

Assembler Reference

This chapter provides general reference material on the ARM assemblers. It contains the following sections:

• Command syntax on page 3-2

• Format of source lines on page 3-8

• Predefined register and coprocessor names on page 3-9

• Built-in variables on page 3-10

• Symbols on page 3-12

• Expressions, literals, and operators on page 3-18.

This chapter does not explain how to write ARM assembly language. See Chapter 2 Writing ARM and Thumb Assembly Language for tutorial information.

It also does not describe the instructions, directives, or pseudo-instructions. See the separate chapters for reference information on these.

Assembler Reference

3.1 Command syntax

This section relates only to

armasm

. The inline assemblers are part of the C and C++

compilers, and have no command syntax of their own.

armasm

The

command line is case-insensitive, except in filenames, and where specified.

Invoke the ARM assembler using this command:

armasm [-16| -32] [-apcs [none |[/qualifier[/qualifier[...]]]]] [-bi

gend| -littleend] [-checkreglist] [-cpu cpu] [-depend dependfile |-m|-md]

[-e

rrors errorfile] [-fpu name] [-g] [-help] [-i dir [,dir]…] [-keep] [-list [listingfile] [options]] [-m [-noe

sc] [-noregs] [-nowarn] [-o filename] [-predefine "directive"] [-split_ldm]

[-unsafe] [-via file] inputfile

axcache n] [-memaccess attributes] [-nocache]

where:

-16

-32

instructs the assembler to interpret instructions as Thumb instructions. This is equivalent to a

CODE16

directive at the head of the source file.

instructs the assembler to interpret instructions as ARM instructions. This is the default.

-apcs [none| [/qualifier[/qualifier[...]]]]

specifies whether you are using the ARM/Thumb Procedure Call Standard (ATPCS). It can also specify some attributes of code sections. See ADS Developer Guide for more information about the ATPCS.

/none

specifies that

inputfile

does not use ATPCS. ATPCS registers

are not set up. Qualifiers are not allowed.

Note

ATPCS qualifiers do not affect the code produced by the assembler. They

are an assertion by the programmer that the code in

inputfile

complies with a particular variant of ATPCS. They cause attributes to be set in the object file produced by the assembler. The linker uses these attributes to check compatibility of files, and to select appropriate library variants.

Values for

/interwork

qualifier

are:

specifies that the code in

inputfile

is suitable for ARM/Thumb interworking. See ADS Developer Guide for information on interworking.

/nointerwork

specifies that the code in

inputfile

is not suitable for ARM/Thumb interworking. This is the default.

Assembler Reference

-bigend

-littleend

/ropi

/pic

/nopic

/rwpi

/pid

/nopid

/swstackcheck

specifies that the content of

inputfile

position-independent. The default is

is a synonym for

specifies that the content of

/ropi

/noropi

inputfile

position-independent. The default is

is a synonym for

specifies that the code in

/rwpi

/norwpi

inputfile

is read-only

/noropi

is read-write

/norwpi

carries out

software stack-limit checking.

/noswstackcheck

specifies that the code in

inputfile

does not carry out software stack-limit checking. This is the default.

/swstna

specifies that the code in

inputfile

is compatible both with code which carries out stack-limit checking, and with code that does not carry out stack-limit checking.

instructs the assembler to assemble code suitable for a big-endian ARM. The default is

-littleend

instructs the assembler to assemble code suitable for a little-endian ARM.

-checkreglist

instructs the assembler to check

RLIST, LDM

, and

STM

register lists to ensure that all registers are provided in increasing register number order. A warning is given if registers are not listed in order.

-cpu cpu

sets the target CPU. Some instructions produce either errors or warnings if assembled for the wrong target CPU (see also the option). Valid values for or part numbers such as ARM7TDMI

cpu

are architecture names such as 3, 4T, or

. See ARM Architecture Reference

-unsafe

assembler

5TE

Manual for information about the architectures. The default is ARM7TDMI.

-depend dependfile

instructs the assembler to save source file dependency lists to

dependfile

These are suitable for use with make utilities.

-m

instructs the assembler to write source file dependency lists to

stdout

Assembler Reference

-md

-errors errorfile

instructs the assembler to write source file dependency lists to

inputfile.d

instructs the assembler to output error messages to

-fpu name

this option selects the target floating-point unit (FPU) architecture. If you specify this option it overrides any implicit FPU set by the Floating-point instructions produce either errors or warnings if assembled for the wrong target FPU.

The assembler sets a build attribute corresponding to file. The linker determines compatibility between object files, and selection of libraries, accordingly.

Valid options are:

none

vfp

This is a synonym for

vfpv1

vfpv2

fpa

Selects hardware Floating Point Accelerator.

softvfp+vfp

softvfp

softfpa

errorfile

-cpu

name

in the object

name

in the object

option.

Selects no floating-point option. This makes your assembled

object file compatible with any other object file.

-fpu vfpv1

Selects hardware vector floating-point unit conforming to

architecture VFPv1.

Selects hardware vector floating-point unit conforming to

architecture VFPv2.

Selects hardware Vector Floating Point unit.

armasm

, this is identical to

-fpu vfpv1

. See the C and C++

Compilers chapter in ADS Compilers and Libraries Guide for

details of the effect on software library selection at link time.

Selects software floating-point library (FPLib) with

pure-endian doubles. This is the default if no

-fpu

option is

specified.

Selects software floating-point library with mixed-endian

doubles.

-g

instructs the assembler to generate DWARF2 debug tables. For backwards compatibility, the following command line option is permitted, but not required:

-dwarf2

Assembler Reference

-help

instructs the assembler to display a summary of the assembler command-line options.

-i dir [,dir]…

adds directories to the source file search path so that arguments to

INCLUDE

, or

INCBIN

INCLUDE on page 7-61).

-keep

instructs the assembler to keep local labels in the symbol table of the object file, for use by the debugger (see KEEP on page 7-64).

-list [listingfile] [options]

instructs the assembler to output a detailed listing of the assembly language produced by the assembler to

listingfile

sent to

, listing is sent to

inputfile.lst

Use the following command-line options to control the behavior of

-noterse

turns the due to conditional assembly do not appear in the listing. If the

terse

default is on.

-width

-length

sets the listing page width. The default is 79 characters.

sets the listing page length. Length zero means an unpaged listing. The default is 66 lines.

-xref

instructs the assembler to list cross-referencing information on symbols, including where they were defined and where they were used, both inside and outside macros. The default is off.

GET

directives do not need to be fully qualified (see GET or

stdout

listingfile

. If no

listingfile

. If - is given as

is given, listing is

-list

terse

flag off. When this option is on, lines skipped

option is off, these lines do appear in the listing. The

-maxcache n

sets the maximum source cache size to n. The default is 8MB.

-memaccess attributes

Specifies memory access attributes of the target memory system. The default is to allow aligned loads and saves of bytes, halfwords and words.

attributes

+L41

-L22

-S22

-L22-S22

modify the default. They can be any one of the following:

Allow unaligned

LDR

Disallow halfword loads.

Disallow halfword stores.

Disallow halfword loads and stores.

Assembler Reference

-nocache

turns off source caching. By default the assembler caches source files on the first pass and reads them from memory on the second pass.

-noesc

-noregs

instructs the assembler to ignore C-style escaped special characters, such as

and \t.

instructs the assembler not to predefine register names. See Predefined register and coprocessor names on page 3-9 for a list of predefined register names.

-nowarn

-o filename

turns off warning messages.

names the output object file. If this option is not specified, the assembler uses the second command-line argument that is not a valid command-line option as the name of the output file. If there is no such argument, the assembler creates an object filename of the form

-predefine "directive"

instructs the assembler to pre-execute one of the enclose

The assembler executes a corresponding

directive

in quotes. See SETA, SETL, and SETS on page 7-7.

GBLL, GBLS

inputfilename.o

SET

directives. You must

, or

GBLA

directive to

define the variable before setting its value.

The variable name is case-sensitive.

Note

The command line interface of your system might require you to enter

special character combinations, such as

directive

. Alternatively, you can use

\”

, to include strings in

-via file

to include a

-predefine

argument. The command line interface does not alter arguments from

-via

files.

-split_ldm

This option instructs the assembler to fault

LDM

and

STM

instructions if the

maximum number of registers transferred exceeds:

• five, for all

• four, for

STM

s, and for

LDM

s that load the PC.

LDM

s that do not load the PC

Avoiding large multiple register transfers can reduce interrupt latency on ARM systems that:

• do not have a cache or a write buffer (for example, a cacheless ARM7TDMI)

• use zero wait-state, 32-bit memory.

Assembler Reference

Note

Avoiding large multiple register transfers increases code size and

decreases performance slightly.

Avoiding large multiple register transfers has no significant benefit for cached systems or processors with a write buffer.

Avoiding large multiple register transfers also has no benefit for systems without zero wait-state memory, or for systems with slow peripheral devices. Interrupt latency in such systems is determined by the number of cycles required for the slowest memory or peripheral access. This is typically much greater than the latency introduced by multiple register transfers.

-unsafe

-via file

inputfile

allows assembly of a file containing instructions that are not available on the specified architecture and processor. It changes corresponding error messages to warning messages. It also suppresses warnings about operator precedence (see Binary operators on page 3-28).

instructs the assembler to open

file

and read in command-line arguments to the assembler. For further information see the Via File Syntax appendix in ADS Compilers and Libraries Guide.

specifies the input file for the assembler. Input files must be ARM or Thumb assembly language source files.

Assembler Reference

3.2 Format of source lines

The general form of source lines in an ARM assembly language module is:

{symbol} {instruction|directive|pseudo-instruction} {;comment}

All three sections of the source line are optional.

Instructions cannot start in the first column. They must be preceded by white space even if there is no preceding symbol.

You can write directives in all upper case, as in this manual. Alternatively, you can write directives in all lower case. You must not write a directive in mixed upper and lower case.

You can use blank lines to make your code more readable.

symbol

is usually a label (see Labels on page 3-15). In instructions and pseudo-instructions it is always a label. In some directives it is a symbol for a variable or a constant. The description of the directive makes this clear in each case.

symbol

must begin in the first column and cannot contain any whitespace character such as a space or a tab (see Symbol naming rules on page 3-12).

3.3 Predefined register and coprocessor names

All register and coprocessor names are case-sensitive.

3.3.1 Predeclared register names

The following register names are predeclared:

r0-r15

and

•

a1-a4

•

v1-v8

•

and SB (static base, r9)

•

and SL (stack limit, r10)

•

and FP (frame pointer, r11)

•

and IP (intra-procedure-call scratch register, r12)

•

and SP (stack pointer, r13)

•

and LR (link register, r14)

•

and PC (program counter, r15).

3.3.2 Predeclared program status register names

R0-R15

(argument, result, or scratch registers, synonyms for r0 to r3)

(variable registers, r4 to r11)

Assembler Reference

The following program status register names are predeclared:

cpsr

and

CPSR

•

spsr

and

(current program status register)

SPSR

(saved program status register).

3.3.3 Predeclared floating-point register names

The following floating-point register names are predeclared:

f0-f7

and

F0-F7

•

s0-s31

and

•

d0-d15

and

(FPA registers)

S0-S31

(VFP single-precision registers)

D0-D15

(VFP double-precision registers).

3.3.4 Predeclared coprocessor names

The following coprocessor names and coprocessor register names are predeclared:

p0-p15

•

(coprocessors 0-15)

c0-c15

(coprocessor registers 0-15).

Assembler Reference

3.4 Built-in variables

Table 3-1 lists the built-in variables defined by the ARM assembler.

{PC}

{VAR}

Address of current instruction.

Current value of the storage area location counter.

Table 3-1 Built-in variables

{TRUE}

{FALSE}

{OPT}

{CONFIG}

{ENDIAN}

{CODESIZE}

{CPU}

{FPU}

{ARCHITECTURE}

{PCSTOREOFFSET}

{ARMASM_VERSION}

|ads$version|

{INTER}

Logical constant true.

Logical constant false.

Value of the currently-set listing option. The

OPT

directive can be used to save the current listing

option, force a change in it, or restore its original value.

Has the value 32 if the assembler is assembling ARM code, or 16 if it is assembling Thumb code.

Has the value

Is a synonym for

Holds the name of the selected cpu. The default is the command line

Holds the name of the selected fpu. The default is

big

if the assembler is in big-endian mode, or

{CONFIG}

-cpu

option,

{CPU}

holds the value "

ARM7TDMI

SoftVFP

little

if it is in little-endian mode.

. If an architecture was specified in

Generic ARM

Holds the name of the selected ARM architecture.

Is the offset between the address of the

STR pc,[...]

STM Rb,{..., pc}

instruction and the

value of pc stored out. This varies depending on the CPU or architecture specified.

Holds an integer that increases with each version. See also Determining the armasm version at assembly time on page 3-11

Has the same value as

Has the value True if

{ARMASM_VERSION}

/inter

is set. The default is False.

{ROPI}

{RWPI}

{SWST}

{NOSWST}

Has the value True if

/ropi

is set. The default is False.

/rwpi

is set. The default is False.

/swst

is set. The default is False.

/noswst

is set. The default is False.

Built-in variables cannot be set using the

SETA, SETL

, or

SETS

directives. They can be used

in expressions or conditions, for example:

IF {ARCHITECTURE} = "4T"

Assembler Reference

|ads$version|

must be all lower case. The other built-in variables can be upper-case,

lower-case, or mixed.

3.4.1 Determining the armasm version at assembly time

The built-in variable

armasm

from ADS1.0 onwards. However, previous versions of

{ARMASM$VERSION}

can be used to distinguish between versions of

built-in variable.

If you need to build both ADS and SDT versions of your code, you can test for the built-in variable

IF :DEF: |ads$version| ; code for ADS ELSE ; code for SDT ENDIF

|ads$version|

. Use code similar to the following:

armasm

did not have this

Assembler Reference

3.5 Symbols

You can use symbols to represent variables, addresses, and numeric constants. Symbols representing addresses are also called labels. See:

• Variables on page 3-13

• Numeric constants on page 3-13

• Labels on page 3-15

• Local labels on page 3-16.

3.5.1 Symbol naming rules

The following general rules apply to symbol names:

• You can use uppercase letters, lowercase letters, numeric characters, or the

underscore character in symbol names.

• Do not use numeric characters for the first character of symbol names, except in

local labels (see Local labels on page 3-16).

• Symbol names are case-sensitive.

• All characters in the symbol name are significant.

• Symbol names must be unique within their scope.

• Symbols must not use built-in variable names or predefined symbol names (see

Predefined register and coprocessor names on page 3-9 and Built-in variables on page 3-10).

• Symbols must not use the same name as instruction mnemonics or directives. If

you use the same name as an instruction mnemonic or directive, use double bars to delimit the symbol name. For example:

||ASSERT||

The bars are not part of the symbol.

If you need to use a wider range of characters in symbols, for example, when working with compilers, use single bars to delimit the symbol name. For example:

|.text|

The bars are not part of the symbol. You cannot use bars, semicolons, or newlines within the bars.

3.5.2 Variables

Assembler Reference

The value of a variable can be changed as assembly proceeds. Variables are of three types:

• numeric

• logical

• string.

The type of a variable cannot be changed.

The range of possible values of a numeric variable is the same as the range of possible values of a numeric constant or numeric expression (see Numeric constants and Numeric expressions on page 3-20).

The possible values of a logical variable are on page 3-23).

The range of possible values of a string variable is the same as the range of values of a string expression (see String expressions on page 3-19).

Use the variables, and assign values to them using the

• GBLA, GBLL, and GBLS on page 7-4

• LCLA, LCLL, and LCLS on page 7-6

• SETA, SETL, and SETS on page 7-7.

3.5.3 Numeric constants

Numeric constants are 32-bit integers. You can set them using unsigned numbers in the range 0 to 2 assembler makes no distinction between –n and 2 use the unsigned interpretation. This means that 0 > –1 is

Use the the value of a numeric constant after you define it.

See also Numeric expressions on page 3-20 and Numeric literals on page 3-21.

{TRUE}

{FALSE}

(see Logical expressions

GBLA, GBLL, GBLS, LCLA, LCLL

– 1, or signed numbers in the range –231 to 2

EQU

directive to define constants (see EQU on page 7-57). You cannot change

, and

LCLS

directives to declare symbols representing

SETA, SETL

, and

SETS

directives. See:

– 1. However, the

– n. Relational operators such as >=

{FALSE}

Assembler Reference

3.5.4 Assembly time substitution of variables

You can use a string variable for a whole line of assembly language, or any part of a line. Use the variable with a

prefix in the places where the value is to be substituted for the variable. The dollar character instructs the assembler to substitute the string into the source code line before checking the syntax of the line.

Numeric and logical variables can also be substituted. The current value of the variable is converted to a hexadecimal string (or

Use a dot to mark the end of the variable name if the following character would be permissible in a symbol name (see Symbol naming rules on page 3-12). You must set the contents of the variable before you can use it.

If you need a

that you do not want to be substituted, use $$. This is converted to a single

You can include a variable with a way as anywhere else.

Substitution does not occur within vertical bars, except that vertical bars within double quotes do not affect substitution.

or F for logical variables) before substitution.

prefix in a string. Substitution occurs in the same

Examples

; straightforward substitution GBLS add4ff ; add4ff SETS "ADD r4,r4,#0xFF" ; set up add4ff $add4ff.00 ; invoke add4ff ; this produces ADD r4,r4,#0xFF00

3.5.5 Labels

Assembler Reference

Labels are symbols representing the addresses in memory of instructions or data. They can be program-relative, register-relative, or absolute.

Program-relative labels

These represent the program counter, plus or minus a numeric constant. Use them as targets for branch instructions, or to access small items of data embedded in code sections. You can define program-relative labels using a label on an instruction or on one of the data definition directives. See:

• DCB on page 7-18

• DCD and DCDU on page 7-19

• DCFD and DCFDU on page 7-21

• DCFS and DCFSU on page 7-22

• DCI on page 7-23

• DCQ and DCQU on page 7-24

• DCW and DCWU on page 7-25.

These represent a named register plus a numeric constant. They are most often used to access data in data sections. You can define them with a storage map. You can use the

EQU

directive to define additional register-relative labels, based on labels defined in

storage maps. See:

• MAP on page 7-15

• SPACE on page 7-17

• DCDO on page 7-20

• EQU on page 7-57.

Absolute addresses

These are numeric constants. They are integers in the range 0 to 2

–1. They address the

memory directly.

Assembler Reference

3.5.6 Local labels

A local label is a number in the range 0-99, optionally followed by a name. The same number can be used for more than one local label in an ELF section.

Local labels are typically used for loops and conditional code within a routine, or for small subroutines that are only used locally. They are particularly useful in macros (see MACRO and MEND on page 7-27).

ROUT

Use the

directive to limit the scope of local labels (see ROUT on page 7-68). A reference to a local label refers to a matching label within the same scope. If there is no matching label within the scope in either direction, the assembler generates an error message and the assembly fails.

You can use the same number for more than one local label even within the same scope. By default, the assembler links a local label reference to:

• the most recent local label of the same number, if there is one within the scope

• the next following local label of the same number, if there is not a preceding one

within the scope.

Use the optional parameters to modify this search pattern if required.

Syntax

The syntax of a local label is:

n{routname}

The syntax of a reference to a local label is:

%{F|B}{A|T}n{routname}

where:

routname

If neither

is the number of the local label.

is the name of the current scope.

introduces the reference.

instructs the assembler to search forwards only.

instructs the assembler to search backwards only.

instructs the assembler to search all macro levels.

instructs the assembler to look at this macro level only.

or B is specified, the assembler searches backwards first, then forwards.

or T is specified, the assembler searches all macros from the current level to

the top level, but does not search lower level macros.

routname

against the name of the nearest preceding

is specified in either a label or a reference to a label, the assembler checks it

ROUT

directive. If it does not match, the

assembler generates an error message and the assembly fails.

Assembler Reference

3.6 Expressions, literals, and operators

This section contains the following subsections:

• String expressions on page 3-19

• String literals on page 3-19

• Numeric expressions on page 3-20

• Numeric literals on page 3-21

• Floating-point literals on page 3-22

• Register-relative and program-relative expressions on page 3-23

• Logical expressions on page 3-23

• Logical literals on page 3-23

• Operator precedence on page 3-24

• Unary operators on page 3-26

• Binary operators on page 3-28.

3.6.1 String expressions

String expressions consist of combinations of string literals, string variables, string manipulation operators, and parentheses. See:

• String literals

• Variables on page 3-13

• Unary operators on page 3-26

• String manipulation operators on page 3-28

• SETA, SETL, and SETS on page 7-7.

Characters that cannot be placed in string literals can be placed in string expressions using the

The value of a string expression cannot exceed 512 characters in length. It can be of zero length.

Example

improb SETS "literal":CC:(strvar2:LEFT:4) ; sets the variable improb to the value "literal" ; with the left-most four characters of the ; contents of string variable strvar2 appended

:CHR:

unary operator. Any ASCII character from 0 to 255 is allowed.

Assembler Reference

3.6.2 String literals

String literals consist of a series of characters contained between double quote characters. The length of a string literal is restricted by the length of the input line (see Format of source lines on page 3-8).

To include a double quote character or a dollar character in a string, use two of the character.

-noesc

C string escape sequences are also allowed, unless

is specified (see Command

syntax on page 3-2).

Examples

abc SETS "this string contains only one "" double quote" def SETS "this string contains only one $$ dollar symbol"

Assembler Reference

3.6.3 Numeric expressions

Numeric expressions consist of combinations of numeric constants, numeric variables, ordinary numeric literals, binary operators, and parentheses. See:

• Numeric constants on page 3-13

• Variables on page 3-13

• Numeric literals on page 3-21

• Binary operators on page 3-28

• SETA, SETL, and SETS on page 7-7.

Numeric expressions can contain register-relative or program-relative expressions if the overall expression evaluates to a value that does not include a register or the program counter.

Numeric expressions evaluate to 32-bit integers. You can interpret them as unsigned numbers in the range 0 to 2 However, the assembler makes no distinction between –n and 2 operators such as >= use the unsigned interpretation. This means that 0 > –1 is

Example

a SETA 256*256 ; 256*256 is a numeric expression MOV r1,#(a*22) ; (a*22) is a numeric expression

– 1, or signed numbers in the range –231 to 231 – 1.

– n. Relational

{FALSE}

3.6.4 Numeric literals

Numeric literals can take any of the following forms:

•

0xhexadecimal-digits

&hexadecimal-digits

•

'character'

where

Assembler Reference

decimal-digits

n_base-n-digits

decimal-digits

hexadecimal-digits

is a sequence of characters using only the digits 0 to 9.

is a sequence of characters using only the digits 0 to 9 and the letters A to F or a to f.

is a single digit between 2 and 9 inclusive, followed by an underscore character.

base-n-digits

character

is a sequence of characters using only the digits 0 to (n – 1)

is any single character except a single quote. Use \' if you require a single quote. In this case the value of the numeric literal is the numeric code of the character.

You must not use any other characters. The sequence of characters must evaluate to an integer in the range 0 to 2

– 1).

to 2

– 1 (except in

DCQ

and

DCQU

directives, where the range is 0

Examples

a SETA 34906 addr DCD 0xA10E LDR r4,=&1000000F DCD 2_11001010 c3 SETA 8_74007 DCQ 0x0123456789abcdef LDR r1,='A' ; pseudo-instruction loading 65 into r1 ADD r3,r2,#'\'' ; add 39 to contents of r2, result to r3

Assembler Reference

3.6.5 Floating-point literals

Floating-point literals can take any of the following forms:

{-}digits E{-}digits

{-}{digits}.digits{E{-}digits}

0xhexdigits

&hexdigits

digits

are sequences of characters using only the digits 0 to 9. You can write E in uppercase or lowercase. These forms correspond to normal floating-point notation.

hexdigits

are sequences of characters using only the digits 0 to 9 and the letters A to F or a to f. These forms correspond to the internal representation of the numbers in the computer. Use these forms to enter infinities and NaNs, or if you want to be sure of the exact bit patterns you are using.

The range for single-precision floating point values is:

• maximum 3.40282347e+38

• minimum 1.17549435e–38.

The range for double-precision floating point values is:

• maximum 1.79769313486231571e+308

• minimum 2.22507385850720138e–308.

Examples

DCFD 1E308,-4E-100 DCFS 1.0 DCFD 3.725e15 LDFS 0x7FC00000 ; Quiet NaN LDFD &FFF0000000000000 ; Minus infinity

ARM Developer Suite User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Preface

About this book

Intended audience

Using this book

Further reading

Feedback

Feedback on the ARM Developer Suite

Feedback on this book

Introduction

1.1 About the ARM Developer Suite assemblers

Writing ARM and Thumb Assembly Language

2.1 Introduction

2.1.1 Code examples

2.2 Overview of the ARM architecture

2.2.1 Architecture versions

2.2.2 ARM and Thumb state

2.2.3 Processor mode

2.2.4 Registers

2.2.5 ARM instruction set overview

2.2.6 ARM instruction capabilities

2.2.7 Thumb instruction set overview

2.2.8 Thumb instruction capabilities

2.2.9 Differences between Thumb and ARM instruction sets

2.3 Structure of assembly language modules

2.3.1 Layout of assembly language source files

2.3.2 An example ARM assembly language module

2.3.3 Calling subroutines

2.3.4 An example Thumb assembly language module

2.4 Using the C preprocessor

2.5 Conditional execution

2.5.1 The ALU status flags

2.5.2 Execution conditions

2.5.3 Using conditional execution in ARM state

2.5.4 Example of the use of conditional execution

2.6 Loading constants into registers

2.6.1 Direct loading with MOV and MVN

2.6.2 Loading with LDR Rd, =const

2.6.3 Loading floating-point constants

2.7 Loading addresses into registers

2.7.1 Direct loading with ADR and ADRL

2.7.2 Loading addresses with LDR Rd, = label

2.8 Load and store multiple register instructions

2.8.1 ARM LDM and STM instructions

2.8.2 LDM and STM addressing modes

2.8.3 Implementing stacks with LDM and STM

2.8.4 Block copy with LDM and STM

2.8.5 Thumb LDM and STM instructions

2.9 Using macros

2.9.1 Test-and-branch macro example

2.9.2 Unsigned integer division macro example

2.10 Describing data structures with MAP and FIELD directives

2.10.1 Relative maps

2.10.2 Register-based maps

2.10.3 Program-relative maps

2.10.4 Finding the end of the allocated data

2.10.5 Forcing correct alignment

2.10.6 Using register-based MAP and FIELD directives

2.10.7 Using two register-based structures

2.10.8 Avoiding problems with MAP and FIELD directives

2.11 Using frame directives

Assembler Reference

3.1 Command syntax

3.2 Format of source lines

3.3 Predefined register and coprocessor names

3.3.1 Predeclared register names

3.3.2 Predeclared program status register names

3.3.3 Predeclared floating-point register names

3.3.4 Predeclared coprocessor names

3.4 Built-in variables

3.4.1 Determining the armasm version at assembly time

3.5 Symbols

3.5.1 Symbol naming rules

3.5.2 Variables

3.5.3 Numeric constants

3.5.4 Assembly time substitution of variables
