Ariston SL16.1P, SL19.1P User Manual

IT
Cappa aspirante
Istruzioni per linstallazione e luso
Cooker hood
GB
Instructions for installation and use
FR
Hotte aspirante
Instruction pour linstallation et lemploi
Campana extractora
ES
Instrucciones para la instalacion y uso
PT
Instruções para a instalação e o uso
Afzuigkap
NL
Gebruiksaanwijzingen voor de plaatsing en gebruik
Dunstabzugshaube
DE
Informationen für installation und gebrauch
C
F
A
B
B
D
P
1cm
J
K
J
K
H
M
H
L
G
Filtro grassi
O
O
W
V
O
Grease Filter Filtre a graisse Filtro grasas Filtro gorduras Vetfilter Fettfilter
Filtro al carbone Carbon Filter Filtre au charbon Filtro al carbón Filtro de carvão ativado Koolstoffilter Aktivkohlefilter
b
R1
Filtro metallico autoportante Self-supporting metal filter Filtre métallique autoportant Filtro metálico autoportante Filtro metálico autoportante Zelfdragend metalen vetfilter Selbsttragender Metallfilter
P4
P4
a
Lampada alogena Halogen lamp Lampe halogène Lámpara halógena Lâmpada de halogéneos Halogeenlamp Halogenlampe
Lampade 40W Lightbulbs 40W Ampoule 40W Làmparas 40W Lâmpadas 40W Lampje 40W Lämpchen 40W
Consult the designs in the front pages referenced in the text by alphabet letters. Closely follow the instructions set out in this manual. All responsibility, for any eventual inconveniences, damages or fires caused by not complying with the instructions in this manual, is declined.
The cooker hood has an upper air duct B1 and an optional rear air duct B2, for external fumes exit. Select the suitable air duct and apply the flange C supplied, ensure to close the unused hole duct with tap D supplied if provided.
Check that the filter/suction selector (inside the cooker hood) G is in the suction (A) position. In the case where it is not possible to discharge the cooking fumes externally, the cooker hood may be used in the filter version by fixing a carbon filter, the fumes and vapours are recycled via the anterior grill placed above the control panel. Check that the suction/filter selector is in the filter (F) position.
Installation - Do not tile, grout or silicone this appliance to the wall.
Surface mounting only. Do not fix chimney flue to furniture or fly over shelves unless the chimney flue can be easily removed, in case maintenance is ever required.The cooker hood must be placed at a minimum distance of 60 cm from the cooking plane for electric cookers and 75cm for gas or mixed cookers. The cooker hood may be installed on the wall or on the base of a cabinet; if supplied, use the hole gauge H to drill the correct distance, otherwise lean the cooker hood on the wall or on the base of the cabinet and mark the holes with a pencil.
Wall mounting - Insert the wall screw anchors J in the drilled holes
and the two K screws in the upper drill holes, remove the grill and hook the cooker hood to the 2 screws, finally from the inside, insert the third screw L and lock them all in.
Cabinet fixing - Affix the cooker hood with the 4 M screws from
inside the cabinet.
Electrical connection - The electrical tension must correspond
to the tension noted on the label placed inside the cooker hood. Connect the electrical plug, where provided, to the an easily accessible outlet in conformity with local standards in force. Where an electrical plug is not provided (for direct connection to electrical network) place a standards approved bipolar switch with an aperture distance of not less than 3mm (accessible) from the contacts.
Operation - The control panel is situated on the front of the cooker
hood and is equipped with various suction speeds. Use the highest speed for situations of high level vapour concentration in cooking. Always open the vapour collector N. It is advisable to switch on the suction at least 5 minutes prior to cooking and leave it in operation for 15 minutes approximately after cooking is terminated.
Maintenance - Prior to any maintenance operation ensure that
the cooker hood is disconnected from the electrical outlet.
Cleaning - The cooker hood should be cleaned regularly
internally and externally. For cleaning use a cloth moistened with denatured alcohol or neutral liquid detergents. Avoid abrasive detergents. Failure to carry out the basic standards of the cleaning of the cooker hood and replacement of the filters may cause fire risks.
Grease Filter  may be one of the following types:
Metallic filter must be cleaned once a month with suitable detergents either by hand or in dishwasher (65°C). When washed in a dish washer, the grease filter may discolour slightly, but this does not affect its filtering capacity. In order to remove the grease filter open the grill via the P hooks and free the R1 or R2 stoppers. The self-supporting metal filter does not include a support grill, in order to remove the filter  pull the release springs P4 backwards and slide the filter downwards. Attention! the metal filter may discolour if washed in dishwasher but the filtering performance is unaltered.
Carbon Filter - to be replaced every 6 months
Mounting: Remove the cover W by rotating the O knobs to 90° fit the carbon filter V and fix by rotating the O knobs to 90°, then close the cover. Proceed in the inverse for dismounting.
Replacing lightbulbs 40W - Unscrew the damaged light bulb and
replace with an incandescent oval light bulb with a maximum of 40W E14. Remove the grill in order to reach the light bulb area.
Replacing the hologen bulbs - Access the light compartment 
extract the lamp cover by levering it off with a small screwdriver or similar tool. Warning! Prior to touching the light bulbs ensure they are cooled down. Replace the damaged light bulb. Only use halogen bulbs of 20W max (G4), making sure you do not touch them with your hands. Close the lamp cover (it will snap shut).
Caution - This appliance is designed to be operated by adults.
Children should not be allowed to tamper with the controls or play with the appliance. Do not use the cooker hood where the grill is not correctly fixed! The suctioned air must not be conveyed in the same channel used for fumes discharged by appliances powered by other than electricity. The environment must always be adequately aerated when the cooker hood and other appliances powered by other than electricity are used at the same time. Flambé cooking with a cooker hood is prohibited. The use of a free flame is damaging to the filters and may cause fire accidents, therefore free flame cooking must be avoided. Frying of foods must be kept under close control in order to avoid overheated oil catching fire. Carry out fumes discharging in accordance with the regulations in force by local laws for safety and technical restrictions.
LI2AIB
