THANK YOU FOR PURCHASING AN
ARISTON PRODUCT
To receive more comprehensive help and
support, please register your product at
www. aristonchannel. com
Before using the appliance carefully read the Health and Safety guide.
PRODUCT DESCRIPTION
1
2
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website www. aristonchannel. com and
following the instructions on the back of
this booklet.
1. Control panel
2. Identification plate
(do not remove)
3. Door
4
5
4. Upper heating element/grill
5. Light
6. Turntable
3
CONTROL PANEL
1
1. LEFT-HAND DISPLAY
2. ON/OFF
For switching the oven on and off
and for stopping an active function
at any time.
3. BACK
For returning to the previous
menu.
6
2 5 93 4 7 86
4. POWER
For setting the power of the
microwave.
5. KNOB
For navigating between the
functions, as well as changing the
time and cooking time parameters.
6. START
For starting functions and
confirming settings.
7. TIME
For setting the time as well as
setting or adjusting the cooking
time.
8. CONFIRM
For confirming an item you have
selected or the settings for a
function.
9. RIGHT-HAND DISPLAY
1
ACCESSORIES
TURNTABLE
Placed on its support, the glass
turntable can be used with all
cooking methods.
The turntable must always be used
as a base for other containers or
accessories, with the exception of
the rectangular baking tray.
TURNTABLE SUPPORT
Only use the support for the
glass turntable. Do not rest other
accessories on the support.
CRISP PLATE
Only for use with the designated
function.
The Crisp plate must always be
placed in the centre of the glass
turntable and can be pre-heated
when empty, using the special
function for this purpose only. Place the food directly
on the Crisp plate.
HANDLE FOR THE CRISP PLATE
Useful for removing the hot Crisp
plate from the oven.
WIRE RACK
This allows you to place food
closer to the grill, for perfectly
browning your dish. Place the
wire shelf on the turntable,
making sure that it does not
come into contact with other
surfaces.
COVER (IF SUPPLIED)
Useful for covering food while
it is cooking or heating in the
microwave.
The cover reduces splashes, keeps
foods moist and can also be used
to create two cooking levels. It is
not suitable with any of the grill functions.
Other accessories that are not supplied can be purchased separately from the After-sales Service.
There are a number of accessories available on
the market. Before you buy, ensure they are
suitable for microwave use and resistant to oven
temperatures.
Metallic containers for food or drink should never
be used during microwave cooking.
Always ensure that foods and accessories do not
come into contact with the inside walls of the oven.
Always ensure that the turntable is able to turn
freely before starting the oven. Take care not to
unseat the turntable whilst inserting or removing
other accessories.
2
*
*
*
FUNCTIONS
MICROWAVES
For quickly cooking and reheating food or
drinks.
POWER RECOMMENDED FOR
1000W
800W
650 W
500 W
350 W
160 W
90 W
Quickly reheating drinks or other foods
with a high water content
Cooking vegetables
Cooking meat and sh
Cooking meaty sauces, or sauces
containing cheese or egg. Finishing o
meat pies or pasta bakes
Slow, gently cooking. Perfect for melting
butter or chocolate
Defrosting frozen foods or softening
butter and cheese
Softening ice cream
EN
AUTOMATIC FUNCTIONS
With the automatic functions, simply select the
type and weight or the quantity of the food
items to obtain the best results. The oven will
automatically calculate the optimum settings and
continue to change them as cooking progresses.
The total time does not include preheating phases.
REHEAT DYNAMIC
For reheating ready-made food that is either
frozen or at room temperature.
The oven automatically calculates the settings
required to achieve the best results in the shortest
amount of time. Place food on a microwave-safe
and heatproof dinner plate or dish.
CATEGORY FOOD
DINNER PLATE 250 - 500 g
WEIGHT
GRILL
For browning, grilling and gratins. We
recommend turning the food during cooking.
For best results, preheat the grill for 3-5 minutes.
Recommended accessories: wire shelf
GRILL + MW
For quickly cooking and gratinating dishes,
combining the microwave and grill functions.
Recommended accessories: wire shelf
CRISP DYNAMIC
For perfectly browning a dish, both on the
top and bottom of the food. This function must
only be used with the special crisp plate.
Required accessories: Crisp plate, handle for the Crisp
plate
FROZEN PORTION 250 - 500 g
FROZEN LASAGNA 250 - 500 g
SOUPS 200 - 800 g
BEVERAGES 100 - 500 g
COOK DYNAMIC
For cooking foods quickly and achieving
optimal results. Use a heatproof container suitable
for microwave use.
CATEGORY FOOD
BAKED POTATOES
(Turn when prompted)
FRESH VEGETABLES
(Cut into pieces of equal
size and add 2 to 4
tablespoons of water.
Cover)
FROZEN VEGETABLES
(Turn when prompted.
Cover)
WEIGHT
200g - 1kg
200 - 800 g
200 - 800 g
CANNED VEGETABLES 200 - 600 g
POPCORN 100 g
3
CRISP DYNAMIC
For quickly reheating and cooking frozen
foods and giving them a golden, crunchy top. Only
use this function with the crisp plate provided. Turn
the food when prompted.
CATEGORY FOOD
FRENCH FRIES
(spread out in a single
layer and sprinkle with
salt before cooking)
PIZZA, THIN CRUST 200 - 500 g
PIZZA, THICK CRUST 300 - 800 g
WEIGHT
200 - 500 g
DEFROST DYNAMIC
For quickly defrosting various different types of
food simply by specifying their weight.
Food should be placed directly on the glass
turntable.
Turn the food when prompted.
CATEGORY FOOD
MEAT
(mince, cutlets, steaks,
roasting joints)
POULTRY
(whole chicken, pieces,
llets)
WEIGHT
100 g - 2 kg
100 g - 2.5
kg
CHICKEN WINGS,
CHICKEN PIECES
(Lightly oil the plate)
FISH FINGERS
(Crisp plate must be
preheated)
200 - 500 g
200 - 500 g
Recommended accessories: Crisp plate, handle for the
Crisp plate
FISH
(whole, steaks, llets)
VEGETABLES
(mixed vegetables, peas,
broccoli, etc.)
BREAD
(loaves, buns, rolls)
USING THE APPLIANCE FOR THE FIRST TIME
. SETTING THE TIME
You will need to set the time when you switch on the
oven for the first time.
Please note: To change the time at a later point, press and
hold for at least one second while the oven is o and
repeat the steps above.
You may need to set the time again following lengthy
power outages.
100 g - 1.5
kg
100 g - 1.5
kg
100 g - 1 kg
The two digits for the hour will start flashing: Turn the
adjustment knob to set the hour and then press
to
confirm.
The two digits for the minutes will start flashing. Turn
the adjustment knob to set the minutes and press
to confirm.
4
DAILY USE
EN
1. SELECT A FUNCTION
When the oven is off, only the time is shown on the
display. Press and hold
Turn the knob to view the main functions available on
the left-hand display. Select one and press
To select a sub-function (where available), select the
main function and then press
to the function menu.
Turn the knob to select from amongst the subfunctions available on the right-hand display and then
press
to confirm.
to switch the oven on.
.
to confirm and go
2. SET A FUNCTION
Note: During cooking, you can adjust the cooking time by
turning the knob; each time you press , the cooking
time increases by 30 seconds.
. AUTOMATIC FUNCTIONS/DYNAMIC DEFROST
CATEGORIES
Once you have chosen one of the automatic
functions, you will need to select a category for the
food you are cooking.
When the icon flashes, turn the knob to select the
category you require and then press
WEIGHT
To achieve the best results, the automatic functions
(and Dynamic Defrost) require you to enter the weight
of the food, selecting from amongst the default
settings: the oven will calculate the ideal length of
time for the function to run for each category of food.
to confirm.
. MANUAL FUNCTIONS
After having selected the function you require, you
can change its settings.
The display will show the settings that can be
changed in sequence.
MICROWAVE LEVEL
When the icon flashes on the display,
turn the knob to adjust the setting and then press
to confirm and continue to alter the settings that
follow (if possible).
Please note: Once the function has been activated, the
power can be changed by pressing to access the
settings menu, then turning the knob to change the
setting.
COOKING TIME
When the icon flashes on the display,
use the knob to set the cooking time you require and
then press
You do not have to set the cooking time if you want to
manage cooking manually: Press
start the function.
to confirm.
to confirm and
When the default setting appears on the display and
the
and then press
icon flashes, turn the knob to set the weight
to confirm.
3. ACTIVATE THE FUNCTION
Once you have applied the settings you require, press
to activate the function.
Every time the
cooking time will be increased by a further 30
seconds.
Please note: You can press at any time to pause the
function that is currently active.
JET START
When the oven is switched off, it is possible to press
to activate cooking with the microwave function
set at full power (1000 W) for 30 seconds.
. SAFETY LOCK
This function is automatically activated to prevent the
oven from being switched on accidentally.
Open and close the door, then press to start the
function.
button is pressed again, the
5
4. PAUSE
To pause an active function, for example to stir or turn
the food, simply open the door.
To start it up again, close the door and press
AUTOMATIC PAUSE
(STIR OR TURN THE FOOD)
Certain functions will pause to allow you to turn or
stir the food.
Once the oven has paused cooking, open the door
and carry out the action you are prompted to perform
before
closing the door again and pressing
with cooking.
Please note: When using the “Dynamic Defrost” functions,
the function will start again automatically after two
minutes, even if you have not turned or stirred the food.
to continue
5. COOKING END TIME
An audible signal will sound and the display will
indicate that cooking is complete.
To extend the cooking time without changing the
settings, turn the knob to set a new cooking time and
press
. KEY LOCK
To lock the keypad, press and hold for at least 5
seconds.
Do this again to unlock the keypad.
Please note: The key lock can also be activated while
cooking is in progress.
For safety reasons, the oven can be switched o at any
time by pressing and holding .
.
6
COOKING TABLE
EN
FOOD FUNCTION
PRE
HE ATING
GRILL LEVEL
POWER
(W)
TIME
(MIN)
Sponge cake - - - 7 - 15
Fruit pie - - - 12 - 20
Cookies - - - 5 - 10
Savoury bakes or quiche lorraine
(1 - 1.2 kg)
Ready meals
(250 - 500 g)
Lasagne/pasta bake
Frozen lasagne
(500 - 700 g)
(300 g) - - - 14 - 16
Pizza
- - - 18 - 25
- - 800 4 - 7 -
- 2 350 15 - 40
- - 500 - 800 14 - 20 -
Meat (chops, steak) - 3 350 10 - 15
Poultry (whole, 800 g - 1.5 kg)
- 3 350 30 - 45 *
ACCESSORIES
Chicken llets or pieces - 3 350 10 -17
Roasts - 2 350 25 - 40 *
Sausages/kebabs - 2 / 3 - 20 - 40 *
Sausages/hamburgers Yes ** - - 6 - 16 *
Fish (steaks or llets) Yes 3 160 - 350 15 - 30 *
Whole sh - 3 160 20 - 40 *
Roast potatoes
- 2 350 - 500 30 - 50 *
Potato wedges - - - 25 - 30
Baked apples - 2 160 -350 15 -25
* Turn the food halfway through cooking ** Preheat the Crisp plate for 3-5 minutes
WWW
Download the Use and Care Guide from www. aristonchannel. com to consult the table of tested recipes, which
has been compiled for the certication authorities in accordance with the IEC 60350 standard
FUNCTIONS
ACCESSORIES
Crisp Grill Grill + Microwaves
Heatproof plate/container suitable for use in
microwaves
Rack Crisp plate
7
CLEANING
Make sure that the oven has cooled down before
carrying out any maintenance or cleaning.
Do not use wire wool, abrasive scourers or abrasive/
corrosive cleaning agents, as these could damage
the surfaces of the appliance.
Do not use steam cleaners.
INTERIOR AND EXTERIOR SURFACES
• Clean the surfaces with a damp cloth. If they are very
dirty, add a few drops of pH-neutral detergent. Finish
off with a dry cloth.
• Clean the door glass with a suitable liquid detergent.
• At regular intervals or in case of spills, remove the
turntable and its support to clean the bottom of the
ACCESSORIES
All accessories are dishwasher safe with the exception
of the crisp plate.
The crisp plate should be cleaned using water and
a mild detergent. For stubborn dirt, rub gently with
a cloth. Always leave the crisp plate to cool down
before cleaning.
oven, removing all food residue.
• The grill does not need to be cleaned as the intense
heat burns away any dirt: Use this function on a
regular basis.
TROUBLESHOOTING
Problem Possible cause Solution
The oven is not working. Power cut.
Disconnection from the
mains.
The oven makes noises, even
when it is switched off.
The display shows the letter “F”
Cooling fan
active.
Software fault. Contact you nearest After-sales Service
followed by a letter or number.
PRODUCT FICHE
WWW
The product fiche with energy data of this
appliance can be downloaded from the website
www. aristonchannel. com
HOW TO OBTAIN THE USE AND CARE GUIDE
WWW
>
Download the Use and
Care Guide from our website
www. aristonchannel. com (you can use
this QR Code), specifying the product’s
commercial code.
> Alternatively, contact our Client After-sales Service
Check for the presence of mains electrical
power and whether the oven is connected to
the electricity supply.
Turn off the oven and restart it to see if the
fault persists.
Open the door or wait until the cooling
process has finished.
Centre and state the letter or number that
follows the letter “F”.
CONTACTING OUR AFTER-SALES SERVICE
You can find our
contact details in the
warranty manual. When
contacting our Client
After-sales Service,
please state the codes
provided on your
product’s identification
plate.
XXXXXXXXXXXX
XXXXXXXXXXXX
XXX/XXX
400011171470
Printed in I taly
8
Loading...
