Argos LCD32947HDS ASSEMBLY INSTRUCTIONS

32” LCD TV

Installation & Operating Instructions - Please keep for future reference

529/9232

LCD32947HDS

APPROVED

IMPORTANT - Please read these instructions fully before installing or operating

These instructions contain important information which will help you get the best from your
television and ensure safe and correct installation and operation.

For any help concerning set up and use of your TV please call the

Customer Helpline: 0345 604 0105

Lines open: 9am - 8pm Monday to Saturday and 10am - 4pm Sunday

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Issue 1 - 9/2/11

Contents

Contents
Contents

Getting Started 7-14
TV - Features 8
Viewing remote control - TV 9
Getting Started 10
Attaching the Stand 10
Getting Started 11
TV - Control buttons (left side) 11
Aerial connection 12
Power connection 12
Remote control - Inserting batteries
Wall Mounting 12
Switching the TV On and Off 12

Operation using TV control buttons 13
Operation using Remote control buttons
Initial set up 14
General operation 14

Preparation
Intended Use
Power source
Positioning the TV
Power cord and plug
Moisture and Water
Ventilation
Heat sources and Flames
Headphone Volume
Wall Mounting (optional)
LCD Screen
Cleaning
Batteries
Replacement Parts
Servicing
Taking out of service and storing
Connection to a Television Distribution System
(Cable TV etc.) from Tuner
Symbols in this Instruction Book

Switching the TV On
Switching the TV Off 12

Information Banner

2

3-6

4
4
4
4
4
5
5
5
5
5
5
5
5
6
6
6

6
6

12

12

13

14

Connections 15-19
Back connections explained
Left side connections explained
HDMI Connections
SCART Connections
VGA Connections
Side AV Connections
Using a Conditional Access Module
USB Connections
Basic Features 20-28
How to navigate menus - Selecting source 20
Electronic programme guide (EPG)
General Operation

Displaying Subtitles 21
Zoom Modes 21
Using Main Menu Screen 21
Configuring Date/Time Settings
Source Settings 21
Audio Language 21

Basic Features 22
Navigating Channel List

Moving a Channel 22
Deleting a Channel 22
Renaming a Channel
Locking a Channel 22
Sorting Channel List 22

Language Settings

Language Settings 24

Other Functions and Features

Favourite Mode 25
Conditional Access 25
Setting Sleep Timer 25
Setting Programme Timers

Editing a Timer 25
Deleting a Timer
Picture Controls

Configuring Picture Settings 26
Operating Picture Settings Menu Items
Picture Settings Menu Items 26
PC Picture Settings Operation 26

Sound and Source Settings

Configuring Sound Settings 27
Sound Settings Menu Items 27
Configuring Source Settings

Other Controls

Operation 28
Other Settings Menu Items

15
16
17
17
17
18
18
19

20
21

21

22

22

24

25

25

25
26

26

27

27
28

28

2

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Contents

Advanced Features

29-32

Media Browser

29

Starting Media Browser

29

Media Browser Configuration

29

Operation

29

View Style

29

Slide Show Interval

29

Show Subtitle

29

Subtitle Language

29

Subtitle Position

29

Subtitle Font Size

29

Loop / Shuffle during Playback

29

Media Browser - continued

30

Viewing Videos via USB

30

Video Playback Screen

30

Subtitle Time Correction

30

Viewing Photos via USB

30

Displaying Photos in Slideshow Mode

30

Playing Music via USB

30

Setting the channels

31

Accessing Installation Menu

31

Automatic Channel Scan (Retune)

31

Manual Channel Scan

31

Analogue Fine Tune

31

First Time Installation

31

Clear Service List

31

Parental Control

32

Other Information

33-36

Teletext

33

Analogue Teletext

33

Digital Teletext (for the UK only)

33

Specifications

34

Other Information

35

Plug replacement - UK and Ireland only

35

Other Information

36

Product Support

37-42

Trouble shooting

37

Disposal information

38

Supported DVI Resolutions

38

Supported File Formats for USB Mode

39

AV and HDMI Signal Compatibility (Input
Types)

Signal

39

PC Input Typical Display Modes

40

Definition of important terms - TV

41

Software Upgrade

42

Guarantee

43

Model number

ALBA DVB-T LCD32947HDS

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

3

Safety Information

IMPORTANT - Please read these instructions fully before installing or operating

CAUTION:

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NO T REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock of persons.

The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.

Preparation

Place the device on a solid even surface. For ventilation,
leave a free space of at least 10 cm all around the
set. To prevent any fault and unsafe situations, do not
place any objects on top of the set. Use this device in
moderate climates.

Operation temperature and operation humidity:
5ºC up to 45ºC, 85% rel. humidity max. (not blocking
ventilation openings).

Intended Use

This device is used to receive and display TV
programmmes.The different connection options make
an additional expansion of the reception and display
sources possible (various external devices). This device
is only suitable for dry interior use. This appliance is
intended solely for private domestic use and may not
be used for industrial and commercial purposes. We
exclude liability in principle, if the device is not used
as intended, or unauthorized modifications have been
made. To operate your LCD TV in extreme ambient
conditions may cause the damage of the device.

WARNING: Never let people (including children)
with physical, sensory or mental abilities or lack of
experience and / or knowledge unsupervised use
electrical device!

Children may not recognize dangers right! The
swallowing of batteries can be fatal. Keep batteries
always out of reach of small children. If a battery is
swallowed, seek immediate medical attention. Keep
the packaging films out of reach of children, there is a
risk of suffocation.

Power source

• The TV should be operated only from a 220-240V
AC, 50 Hz outlet.

• Warning: Do not leave your TV in standby or
operating mode when you leave your house.

Positioning the TV

• For ventilation, please leave a clear space of at
least 10cm all around the TV.

• Do not block the ventilation openings.

• Do not place the TV on sloping or unstable

surfaces, the TV may tip over.

• To prevent damage to the TV, do not place any
objects on top of the TV.

• Only use the TV in moderate climates.

Power cord and plug

• The power cord plug should be easily accessible.
In case of storms and lightning, when going on
holiday, or when the TV is not used for a long
period of time disconnect the power cord from the
mains power socket.

• The mains plug is used to disconnect TV set from
the mains and therefore it must remain readily
accessible.

• Do not place the TV, furniture, etc. on the power
cord or pinch the cord.

• Handle the power cord by the plug, do not unplug
the TV by pulling the power cord.

• Never touch the power cord/plug with wet hands as
this could cause a short circuit or electric shock.

• Never make a knot in the power cord or tie it with
other cords.

• Power cords should be placed in such a way
that they are not likely to be stepped on or driven
over.

• A damaged power cord/plug can cause fire or give
you an electric shock. When damaged it must be
replaced, this should only be done by qualified
personnel.

4

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Safety Information

IMPORTANT - Please read these instructions fully before installing or operating

Moisture and Water

• Do not use this TV in a humid or damp place (avoid
bathrooms, the sink in the kitchen, etc.

• Do not expose this TV to rain or water, as this may
be dangerous.

• Do not place objects filled with liquids, such as
flower vases, on top of the TV. Avoid from dripping
or splashing.

• If any solid object or liquid falls into the cabinet,
unplug the TV and have it checked by qualified
personnel before operating it any further.

Ventilation

• The slots and openings on the TV set are intended
for ventilation and to ensure reliable operation.

• To prevent overheating, these openings must not
be blocked or covered in anyway.

Heat sources and Flames

• Do not expose the TV to direct sunlight or other
heat sources.

• The TV should not be placed near to
open flames and sources of intense
heat such as an electric heater.

• Ensure that no open flame sources,
such as lighted candles, are placed on top of the
TV.

Batteries

• Warning: Incorrect installation of
batteries may cause battery leakage
and corrosion, resulting in damage to

the remote control.

• Do not mix old and new batteries, or
batteries of different types.

• Do not dispose of batteries in a fire.

• Do not dispose of batteries with normal household

waste, take to a local recycling centre.

CAUTION: Insert the batteries / rechargeable
batteries in the correct polarity. Don´t try to recharge
non rechargeable batteries and under no circumstances
throw them into fire. Danger of explosion. Do not use
unequal batteries (old and new, Alkaline and carbon,
etc.) simultaneously. If you will not use the device for
a long time, remove the batteries and store the device
in a dry and dust free place. Improper use of batteries
may cause an explosion or leakage. If the batteries have
leaked, use gloves and clean the appliance thoroughly
with a dry cloth! Batteries should not be exposed to
heat, such as sunshine, fire or the like.

Headphone Volume

• Excessive sound pressure from earphones
and headphones can cause hearing loss,
please take care.

Wall Mounting (optional)

• To prevent injury, this TV must be securely attached
to the wall in accordance with the installation
instructions (if the option is available).

LCD Screen

• Occasionally, a few non-active pixels may appear
on the screen as a fixed blue, green or red
point. Please note that this does not affect the
performance of your product.

• Take care not to scratch the screen with fingernails
or other hard objects.

Cleaning

• Before cleaning, unplug the TV from the wall
socket.

• Do not use liquid or aerosol cleaners. Only use a
soft, dry cloth.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

5

Safety Information

IMPORTANT - Please read these instructions fully before installing or operating

Replacement Parts

When replacement parts are required, make sure that
the service technician has used replacement parts,
which are specified by the manufacturer or have the
same specifications as the original one. Unauthorised
substitutions may result in fire, electrical shock or other
hazards.

Servicing

• Warning: Risk of electric shock, do not attempt
to repair, service or modify this TV yourself. Contact
the manufacturer, their approved service agent or
the Customer Helpline: 0345 604 0105.

Taking out of service and storing

Unplug the TV from the mains and pack the TV in an
appropriate cardboard box. Remove the batteries from
the remote control and pack the remote control to the
TV set.

NOTE: The TV set should be stored in a dry and

dust-free room.

Connection to a Television Distribution
System (Cable TV etc.) from Tuner

Device connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection to protective
earthing-and to a television distribution system using
coaxial cable, may in some circumstances create a
fire hazard.

Connection to a cable distribution system has therefore
to be provided through a device providing electrical
isolation below a certain frequency range (galvanic
isolator, see EN 60728-11).

Symbols in this Instruction Book

The following symbols are used in the Instruction
Book as a marker for restrictions and precautions and
safety instructions. Note such information for security
reasons.

WARNING

If you do not pay attention to such a marked warning, it
can cause serious injury or death. Note these warnings
strictly, in order to ensure a safe operation.

CAUTION

Such a precaution is marked, you should take up
or note, to avoid injury or property damage. Note
these instructions strictly, in order to ensure a safe
operation.

IMPORTANT

Warnings on the appliance and restrictions are displayed
like this. Read this information strictly in order to operate
the system correctly and avoid damage.

NOTE: Information about the operation and
additional explanations are marked like this. To be
aware of such information is recommended to ensure
that the functions can be used optimally.

WARNING

This is a class A product. In a domestic
environment it could cause radio
interference, in which case it may
require the user to take appropriate
action.

6

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Getting Started

The Argos Technical Helpline is here to help

Technical experts are available 7 days a week

• Simple help and advice on setting up your digital
equipment (image).

• Guidance on connecting other devices to your
television such as a DVD player, Sky, home cinema
system or a games console.

• Order spare parts, including that lost remote
control.

• Any other technical issues you may need
assistance with.

Call us today: 0345 604 0105

Local call rates applies*

Lines open 9am-8pm Monday to Saturday and 10am-4pm Sunday.

*Calls to Argos enquiry lines may attract a charge and set up fee from residential
lines depending on your call plan/tariff. Mobile and other providers costs may vary,
see www.bt.com/pricing for details.

For Security and training purposes, telephone calls to and from customer service
centres maybe recorded and monitored. Calls from Republic of Ireland will attract
international call charges.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

7

Getting Started

TV - Features

• Remote controlled colour LCD TV.

• Fully integrated Terrestrial digital TV (DVB-T - MPEG2,

MPEG4)

• HDMI connectors for digital video and audio.
This connection is also designed to accept high
definition signals.

• USB input.

• 1000 programmes (analogue+digital).

• OSD menu system.

• Integrated tuner MPEG 2, MPEG 4 compatible.

• Scart socket for external devices (such as video,

video games, audio set, etc.).

• Stereo sound system. (German+Nicam)

• Teletext, fastext, TOP text.

• Headphone connection.

• Automatic programming system.

• Forward or backward manual tuning.

• Sleep timer / Child lock.

• Automatic sound mute when no transmission.

• NTSC playback.

• AVL (Automatic Volume Limiting).

• Auto power down.

• PLL (Frequency Search).

• PC input.

• Plug&Play for Windows 98, ME, 2000, XP, Vista,

Windos 7.

• Game Mode

Accessories included

Remote Control
Batteries: 2 x AAA
Instruction Book
Quick Start Guide

8

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Optional Accessories

Wall mount bracket

NOTE:You should check the accessories after
purchasing. Make sure that each accessory is
included.

1

28

?

Getting Started - TV

V

V

Viewing remote control - TV

1.

Standby

2.

Mono/Stereo - Dual I-II / Currrent Language (in

DVB channels)

3.

Image size

4.

Green button

5.

Red button

6.

Numeric buttons

7.

Teletext / Mix(in TXT mode)

8.

Cursor Left

9.

Menu on-off

10.

AV / Source selection

11.

Favourite Mode Selection(in DVB channels)
Volume Up

12.

Info / Reveal (in TXT mode)

13.

Mute

14.

Volume Down

15.

Programme Down / Page up(in DVB channels)

16.

Electronic programme guide(in DVB channels)

17.

18.

Programme Up / Page down(in DVB channels)

19.

Sleep Timer

20.

Picture mode selecion

21.

Okay (Confirm) / Hold (in TXT mode)/ Edit

Channel List

22.

Cursor Down

23.

Exit / Return / Index page (in TXT mode)

24.

Cursor Right / Subpage (in TXT mode)

25.

Cursor Up

26.

Previous programme

2

3
4

5
6

7

8

9

10

11
12

30

SCREEN LANG SUBTITLE

PIP

29

2

1

5

6
9

4

3

7 8
0

MENU

SOURCE FAV PRESETS SLEEP

OK

RETURN

INFO EPG

27

26

25
24

23

22

21

20

+ PP

+

19

18

27.

Yellow button

28.

Blue button

29.

No function

30.

Subtitle on-off (in DVB channels)

NOTE: Remote Control buttons that are not indicated

with a number can not be used in TV mode.
The Remote Control range is approximately

7m / 23ft.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

13
14

V- PP

15

17

-

16

9

Getting Started

Attaching the Stand

1.

Stand is placed on a flat surface (fig.1).

2.

To install the TV on the wall, first of all, foot
assembly should be removed. Unscrew the 4 screws
that attach the foot assembly to the panel and
remove the foot assembly from the panel (fig.2).

fig.1

10

fig.2

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Getting Started

TV - Control buttons (left side)

1.

Standby ( ) button

Turns the TV on when in standby mode or turns
the TV off into standby mode.

2.

TV/AV button

Changes the operation of “Up” and “Down”
buttons.

3.

Programme Up/Down buttons

Moves up/down a channel.

4.

Volume Up/Down buttons

Increases/decreases the volume.

NOTE: If you switch on your TV via PROGRAMME

UP/DOWN buttons on the remote control or on the
TV set, the programme that you were watching last
will be reselected.

NOTE:Press “ ” / “ ” buttons at the same
time to view main menu.

Standby-LED

1

4 3

2

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

11

Getting Started

22

D

M

ID

M

I H

H

D

M

I

1

Aerial connection

Connect the “aerial” or “cable TV” plug to AERIAL
INPUT (ANT.) socket located on the back of the
TV (fig.1).

Power connection

IMPORTANT :The TV set is designed to operate on

220-240V AC, 50 Hz.
Please note: After unpacking, allow the TV to reach

ambient room temperature before connecting the TV
to the mains power socket.

Connect the power cord plug to the mains power
socket.

The LED on the front of the TV then lights up, this
indicates that the TV is in ‘Standby’ mode.

Remote control - Inserting batteries

Remove the battery cover on the back of the remote
control, gently push down and pull backwards at the
same time as shown.

Insert two AAA/R3 or equivalent type batteries. Ensure
the batteries are inserted the correct way and replace
the battery cover (fig.2).

SPDIF

Coax.OUT

fig.1

NOTE: When the remote control is not going to
be used for long periods of time, the batteries should
be removed. Otherwise the remote control may be
damaged, caused by battery leakage and corrosion.

Wall Mounting

When wall mounting please ensure you use a compatible
wall mount (not supplied). This TV conforms to the VESA
mounting specifications and is 200 x 200mm.

Switching the TV On and Off

Switching the TV On

With power cord plug connected to the mains power
socket, the TV is in ‘Standby’ mode.

To switch the TV on from standby mode:
Connect the power cord to the 220-240V AC 50 Hz.

Then the standby LED lights up. (The led will blink
during the standby On/Off)

To switch on the TV from standby mode either:

a.

Press the “ ” button, P+ / P- or a numeric button on

the remote control.

b.

Press the “ ”, - or + button of the TV.

By either method the TV will switch on.

AAA/R3 x 2

fig.2

Batteries

Switching the TV Off

Press the “ ” button on the remote control or press
the “ ” switch on the TV, the TV will switch to standby
mode.

To turn off the TV completely, remove the power
cord plug from the mains power socket.

NOTE: When the TV is in standby mode, the standby
LED can blink to indicate that features such as Standby
Search, Over Air Download or Timer is active.

NOTE: If you switch on your TV via P +/- buttons on
the remote control or +/- on the TV set, the programme
that you were watching last will be reselected.

12

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Getting Started

Operation using TV control buttons

V

V

Operation using Remote control buttons

The main menu OSD (On Screen Display) cannot
be displayed using the TV control buttons.

The “ ”/“ ” buttons will function as volume
up/down as default. Even if you set other functions
for these buttons, the “ ”/“ ” buttons will
return to volume control after a short while.

Volume Setting
Press “ ” button to decrease volume or “ ”

button to increase volume, so a volume level scale
(slider) will be displayed on the screen.

Programme Selection
Press “P/CH +” button to select the next

programme or “P/CH -” button to select the
previous programme.

AV Mode
Hold the TV/AV button for a few seconds, the

“Source” OSD will be displayed.

The remote control is designed to control all the
functions of the model you selected.

Volume Setting
Press “V +” button to increase the volume. Press

“V -” button to decrease the volume. A volume level
scale (slider) will be displayed on the screen.

Programme Selection (Previous or Next
Programme)

Press P- button to select the previous programme.
Press P+ button to select the next programme.

Programme Selection (Direct Access)
Press number buttons on the remote control to

select programmes between 0 and 9. The TV will
switch to the selected programme.

To select programmes between 10-500 (IDTV)
or 10-199 (analogue), press the number buttons
consecutively.

SUBTIITLE

SCREEN LA NG

1
5

MENU

SOURCE FAV PRESETS SLEEP

?

INFO

PIP

2

3 4
6 7 8
9 0

OK

+ PP+

V- PP-

RETURN

EPG

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

13

Getting Started

Initial set up

When turned on for the first time, language selection
message is displayed (fig.1). Press the “ ” or “
” button to highlight the required language, press OK
button to select. “First Time Installation” appears. Use“

” or “ ” button to set the required country, and press
“ ” button to select “Teletext Language”. Use “ ” or
“ ” button to set the “Teletext Language” and select
“Scan Encrypted” using “ ” or “ ” button. Set “Scan
Encrypted” using “ ” or “ ” button (fig.2).

Press OK button on the remote control to continue and the
confirmation screen will be displayed on the screen (fig.3).To
start automatic select Yes (to cancel select No), highlight
the item required using the “ ” or “ ” button and press
OK button to select. The search will start (fig.4).

IMPORTANT: Do not turn off the TV while

“First Time Installation” is in operation.

After all the available stations are stored, Channel List
will be displayed on the screen. If LCN (*) is available in
your country, a message appears on the screen which
asks you if you want to sort the channels according to
LCN. In some countries, the order of the channels is
arranged automatically by the broadcaster. This is called
logical channel number (LCN). If the selected country
has LCN support, the channels will be enumerated one
by one, beginning from number 1. You cannot move
any programme to a position after the last saved one.
If you try to do this, both programmes will change their
places. If LCN support is not available, you can move
the channels as you wish.

Press OK button to quit channel list and watch TV.

(*) LCN is the Logical Channel Number system that
organizes available broadcasts in accordance with a
recognizable channel sequence.

(fig.1)

(fig.2)

(fig.3)

Source Selection

Press the SOURCE button on the remote control for
switching between the sources.

Information Banner
Whenever you change channel using the P-/P+ buttons

or the numeric buttons, the TV displays the broadcast
picture along with an information banner at the bottom
of the screen. The information banner can be displayed
at any time while watching TV by pressing the INFO
button on the remote control (fig.5).

Hint: Not all channels broadcast the programme data. If
the name and time of the programme are not available,
then information banner will be displayed with blanks.

If the selected channel is locked, you must enter the
correct four-digit numeric code to view the channel
(default code is 0000). “Enter PIN” will be displayed on
the screen in such a case.

14

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

(fig.4)

(fig.5)
