Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
• For outdoor use only. Not for commercial use.
• Use only Propane regulator 37mbar.
• Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
• Warning: accessible parts may be very hot. Keep young children away.
• Do not move the appliance during use.
• Turn off the gas supply at the gas bottle after use.
• Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
• Retain these instructions for future reference.
• Leak test your barbecue annually. Check the hose connections are tight and leak
test them each time you reconnect the gas bottle.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and
contact your local dealer.
Model KS0993
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359
FOR YOUR SAFETY
PDF created with pdfFactory trial version www.pdffactory.com
A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on
hardware, please see the corresponding Hardware Reference Diagram for your barbecue model.
CODEPARTQTY
A1 Lid 1
A2 Lid handle 1
A3 Cooking grill 1
A4 Heat tent 1
A5 Hinge 2
A6 Burner 1
A7 Firebowl 1
A8 Grease cup hanger 1
A9 Grease cup 1
B1 Right front leg 1
B2 Right rear leg 1
B3 Left front leg 1
B4 Left rear leg 1
B5 Wheel 2
B6 Left upper support 1
B7 Right upper support 1
B8 Control panel assembly 1
B9 Front canvas 1
B10 Bottom shelf 1
C1 Side table 1
C2 Side table front support 1
C3 Side table rear support 1
D1 Side burner assembly 1
D2 Side burner knob 1
D3 Side burner electrode 1
D4 Side burner 1
D5 Side burner grate 1
D6 Side burner front support 1
D7 Side burner rear support 1
E1 M6*20 bolt 8
E2 M6*12 bolt 20
E3 ST4*10 bolt 10
E4 M4 nut 2
E5 Washer 2
E6 M6 nut 8
E7 M5*8 bolt 8
E8 M6*15 Shoulder bolt 4
E9 M4*8 bolt 3
E10 Axle 2
E11 Heat tent support 1
E12 R-pin 2
E13 M5 nut 6
2
PDF created with pdfFactory trial version www.pdffactory.com
B1. Parts Diagram
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on
hardware, please see the corresponding Hardware Reference Diagram for your barbecue mode
A1
A2
A3
A4
A5
A6
A5
D5
D2
A7
B6
D4
D1
D3
B8
D7
D6
B3
B1
B4
A8
A9
B5
B7
C1
F4
B2
B1
C3
C2
B5
B10
3
PDF created with pdfFactory trial version www.pdffactory.com
B9
B2. Hardware Reference Diagram
Specifications subject to change without prior notice.
E1 M6x20 Bolt 8PCS E2 M6x12 Bolt 20PCS
E1M6x20BOLT8PCS
E4 M4 Nut 2PCS
E4M4NUT2PCS
E3 ST4*10 Bolt 6PCS
E3 ST4*10 6PCS
E9 M4x8 BOLT 3PCS
E9 M4x8 Bolt 3PCS
E8 M6x15 Shoulder Bolt 4PCS
E11 Heat tent support 1PCS
E2 M6x12BOLT20PCS
E5 Washer 2PCS
E5Washer 2PCS
E10 Axle 2PCS
E10 Wheel-Axle 2PCS
KS0993
E6 M6 Nut 8PCS
E6 M6 Nut8pcs
E12 R Pin 2PCS
E7 M5x8 Bolt 8PCS
E7M5x8BOLT8PCS
E13 M5 Nut 6PCS
E13 M5NUT6PCS
4
PDF created with pdfFactory trial version www.pdffactory.com
C. Assembly
TOOLS NEEDED FOR ASSEMBLY:
Medium size flat blade or Philips/cross-point screwdriver, adjustable spanner or metric spanner set
This barbecue requires two people for assembly. Please remove all packaging materials from all individual parts before
assembling. Please lay out all nuts and bolts and check lengths before assembling. Whilst every care is taken during the
manufacture of this product, care must be taken during the assembly in case sharp edges are present.
1
F2
B3
F3
Fig 1
B4
B10
F11
Fix the left front leg (B3) and left rear leg (B4) on the bottom shelf (B10) using M6*12 bolts (E2) as Fig 1 .
2
B1
F5
B10
Fig 2
B2
F6
Fix the right front leg (B1) and left rear leg (B2) on the bottom shelf (B10) using M6*12 bolts (E2) as Fig 2 .
5
PDF created with pdfFactory trial version www.pdffactory.com
3
B4
B3
E12
F10
B5
F9
F8
E10
Fig 3
Install the wheels (B5) to the left front leg (B3) and left rear leg (B4) using the axle (E10). Then fix the axle
(E10) by R pin (E12) as Fig 3 .
4
B3
B6
F1
B4
B1
B7
F4
B2
Fig 4
Connect the left upper support (B6) with the left front leg (B3) and left rear leg (B4) using M6*20 bolts (E1)
and M6 nuts (E6) as Fig 4.
Repeat the same connection of the right upper support (B7) with the right front leg (B1) and right rear leg (B2)
using M6*20 bolts (E1) and M6 nuts (E6) as Fig 4. Fix the bolts tightly by the screwdriver.
6
PDF created with pdfFactory trial version www.pdffactory.com
5
Fix the control panel assembly (B8) on the left upper support (B6) and right upper support (B7) using M6*12
bolts (E2) as Fig 5.
B6
B8
F7
Fig 5
B7
6
E11
A7
Fig 6
Fix the heat tent support (E11) on the firebowl (A7) using M4*8 bolts (E9) and M4 nuts (E4) as Fig 6.
7
PDF created with pdfFactory trial version www.pdffactory.com
7
A7
B6
B7
Fig 7
Set the firebowl (A7) on the left upper support (B6) and right upper support (B7) using M6*20 bolts (E1) as
Fig 7.
8
A6
A7
Fig 8a
Put the burner (A6) through the hole of the firebowl (A7) as Fig 8a.
Align all valves on the control panel assembly (B8) against each venturi of the burner (A6). Make sure all
the valve tips go into the venturi tube completely with good alignment. Fix the burner (A6) on the firebowl
(A7) using ST4*10 bolts (E3) as Fig 8b.
Put the burner electrode in the valve on the control panel assembly (B8).
Fig 8b
8
PDF created with pdfFactory trial version www.pdffactory.com
9
A5
Fig 9
Fix the hinge (A5) on the firebowl (A7) using M5*8 bolts (E7) and M5 nuts (E13) as Fig 9
10
A1
A1
E5
A2
A2
Fig 10
Put the washer (E5) between the lid handle (A2) and lid (A1). Align the holes and fix the lid handle (A1) on the
lid (A1) using M5*8 bolts (E7) as Fig 10.
9
PDF created with pdfFactory trial version www.pdffactory.com
11
Fig 11
Fix the lid (A1) and firebowl (A7) by the hinge (A5) using M5*8 bolts (E7) and M5 nuts (E13) as Fig 11.
12
C1
E1
C3
E2
C2
E3
Fig 12
Assemble the side table front support (C2) and side table rear support (C3) to the side table (C1). Secure the
supports with ST4*10 screws (E3) as Fig 12.
10
PDF created with pdfFactory trial version www.pdffactory.com
13
B7
Fig 13a
Install the side table assembly made on step 12 to the right upper support (B7) by M6*15 shoulder bolts (E8)
as Fig 13a and Fig 13b.
Fig 13b
B7
14
D1
D1
D7
D7
D6
D6
Fig 14
Fix the side burner front support (D6) and side burner rear support (D7) to the side burner assembly (D1)
using M6*12 bolt (E2) and lock the support narrow side by M6 nuts (E6) as Fig 14.
11
PDF created with pdfFactory trial version www.pdffactory.com
15
Fig 15
Fix the side table assembly (D1) to the left upper support (B6) using M6*12 bolts (E2) as Fig 15.
16
Fig 16a
Loosen the pre-assembled screws on the side burner valve of the control panel assembly (B8) as Fig 16a.
Fix the side burner valve on the side burner panel bracket of the side burner assembly (D1) using the
screws as Fig 16b.
12
PDF created with pdfFactory trial version www.pdffactory.com
Fig 16b
D4
D4
D3
D3
D5
D5
Fig 16c
Fig 16d
Fig 16e
Electrode of Main Burner
Electrode of Side Burner
Fig 16f
Fig 16g
Fix the side burner electrode (D3) on the side burner assembly (D1) using M4*8 bolt (E9). Put the side burner
(D4) through the hole of side burner assembly (D1) as Fig 16c.
Adjust the burner venturi against the valve. Make sure the valve tip goes into the venturi tube completely with
good alignment. Then tighten the side burner (D4) on the side burner assembly (D1) using M4*8 bolt (E9) as
Fig 16d.
Put the side burner grate (D5) on the side burner assembly (D1) and align with 3 holes as Fig 16e.
Connect the side burner electrode (D3) to the valve of the control panel assembly (B8) as Fig 16f and 16g.
13
PDF created with pdfFactory trial version www.pdffactory.com
17
A8
Fig 17
Put the grease cup hanger (A8) through the hole on firebowl (A7) as Fig 17.
18
B7
A9
F12
B9
Fig 18
Hang the grease cup (A9) on the grease cup hanger (A8). Attach the Front Canvas (B9) to the left front leg
(B3) and right front leg (B1) as Fig 18. Secure the position with the velcro on canvas edge.
14
PDF created with pdfFactory trial version www.pdffactory.com
19
A3
A4
D2
Fig 19
Put the side burner knob (D2) on the side burner assembly (D1). Put the heat tent (A4) and cooking grill
(A3) on the firebowl (A7) as Fig 19.
20
Fig 20
Complete the assembly as Fig 20.
15
PDF created with pdfFactory trial version www.pdffactory.com
D. Important Information
Please read these instructions carefully before
assembly and use.
• Retain these instructions for future reference.
• For outdoors use only – do not use indoors. Do
not use below ground level.
• For use with LPG bottled gas only. A regulator of
37mbar must be used for propane.
• Do not use within 1m of any flammable structure
or surface.
• LP gas cylinders should not be placed directly
underneath the barbecue.
• LP gas cylinders must not be stored or used in the
horizontal position. A leak would be very serious
and liquid could enter the gas line.
• When igniting barbecue open its hood before
lighting.
• Do not move the barbecue while alight.
• This barbecue must not be left unattended when
lit.
• The hood handle can become very hot. Grip only
the centre of the handle. Use of a cooking glove is
advised.
• Use caution when opening the hood, as hot
steam inside is released upon opening.
• Parts of this barbecue become very hot – care
must be taken when children, elderly people, and
animals are present.
• Always turn off the gas bottle when the barbecue
is not in use.
• Never cover a barbecue until it has completely
cooled.
• Never use the barbecue with the side shelf in the
down position.
• Leak test annually, and whenever the gas bottle is
removed or replaced.
• Do not store flammable materials near this
barbecue.
• Do not use aerosols near this barbecue.
• Failure to follow the manual’s instructions could
result in serious injury or damage.
• If you have any queries regarding these
instructions, contact your local dealer.
E. Gas and Regulator
This barbecue can use only propane LPG bottled
gas. Propane bottles will supply gas all year round,
even on cold winter days. A spanner may be required
to change gas bottles. The bottle should never be
stood on the trolley base and placed directly under
the barbecue. Gas bottles should never be stored or
used laid on their side. Never store gas bottles
indoors.
YOU MUST HAVE THE PROPER REGULATOR
AND BOTTLE IN ORDER FOR THE BARBECUE TO
OPERATE SAFELY AND EFFICIENTLY. USE OF
AN INCORRECT OR FAULTY REGULATOR IS
DANGEROUS AND WILL INVALIDATE ANY
WARRANTY. Please consult your local gas dealer
for the most suitable gas bottles.
F. Installation
F1. Selecting a Location
This barbecue is for outdoor use only and should be
placed in a well-ventilated area. Take care to ensure
that it is not placed UNDER any combustible surface.
The sides of the barbecue should NEVER be closer
than 1 metre from any combustible surface. Keep
this barbecue away from any flammable materials!
F2. Precautions
Do not obstruct any ventilation openings in the
barbecue body. Secure the gas bottle on the cylinder
holder and always tighten it with the black strap
provided. Should you need to change the gas bottle,
confirm that the barbecue is switched off, and that
there are no sources of ignition (cigarettes, open
flame, sparks, etc.) near before proceeding. Inspect
the gas hose to ensure it is free of any twisting or
tension. The hose should hang freely with no bends,
folds, or kinks that could obstruct free flow of gas.
Apart from the connection point, no part of the hose
should touch any hot barbecue parts. Always inspect
the hose for cuts, cracks, or excessive wear before
use. If the hose is damaged, it must be replaced with
hose suitable for use with LPG and meet the national
standards for the country of use. The length of the
hose shall not exceed 1.5m. N.B.-The date on U.K.
hose is the date of manufacture, not the expiry date.
F3. Fixing the Regulator to the Gas Bottle
Confirm all barbecue control knobs are in the off
position. Connect the regulator to the gas bottle
according to your regulator and bottle dealer’s
instructions.
F4. Leak Testing (To be performed in a wellventilated area.)
Confirm all control knobs are in the off position. Open
the gas control valve on the bottle or regulator.
Check for leaks by brushing a solution of ½ water
and ½ soap over all gas system joints, including all
valve connections, hose connections and regulator
connections. NEVER USE AN OPEN FLAME to test
for leaks at anytime. If bubbles form over any of the
joints, there is a leak. Turn off the gas supply and
retighten all joints. Repeat test. If bubbles form again,
do not use the barbecue. Please contact your local
dealer for assistance. Leak test your barbecue
annually. Check the hose connections are tight and
leak test them each time you reconnect the gas
bottles.
16
PDF created with pdfFactory trial version www.pdffactory.com
G. Operation
G1. Warning
• Before proceeding, make certain that you
understand the IMPORTANT INFORMATION
section of this manual.
G2. Preparation Before Cooking
To prevent foods from sticking to the cooking grill,
please use a long handled brush to apply a light coat
of cooking or vegetable oil before each barbecuing
session. (Note: When cooking for the first time,
paint colours may change slightly as a result.
This is normal and should be expected.)
G3. Lighting the Main Burner
• Open the barbecue hood.
• Ensure all knobs are in the off position. Open the
gas control valve on the gas bottle or regulator.
• Push in and turn the burner control knob to the
Max position. Press the ignition button rapidly
several times until left portion of the burner is lit.
If burner fails to ignite, turn control knob to the off
position and turn gas off at the bottle or regulator.
Wait five minutes, then repeat the above steps.
After successful lighting of the left side, ignite the
remaining portion of the burner. If the burner fails
to ignite after following above procedure, turn all
the knobs to the off position. Close the gas valve
on the gas bottle. Wait 5 minutes, then repeat the
above steps. If the barbecue still fails to light,
please refer to the manual ignition instruction in
the section below.
• After ignition, the burner should be burned at the
high position for 3-5 minutes in order to preheat
the barbecue. This process should be done
before every cooking session. The hood (where
applicable) should be open during preheating.
• After completion of preheating, the burner should
normally be turned down to a lower position for
best cooking results.
G4. Manual Ignition Instruction for Main Burner
• Insert lit match through the match-lighting hole at
the bottom of the barbecue body.
• Push in and turn the rightmost control knob anticlockwise to the max position.
• After the right portion of the burner is lit, light the
remaining portion of the burner.
• If burner fails to ignite, contact your local dealer
for assistance.
• After ignition, the burner should be burned at the
max position for 3-5 minutes in order to preheat
the barbecue. This process should be done
before every cooking session. The hood (where
applicable) should be open during preheating.
• After completion of preheating, the burner should
normally be turned down to a lower position for
best cooking results.
G5. Lighting the Side Burner
• Keep side burner free.
• Set the control knob to off and turn on the gas
supply.
• Push in and turn the control knob anti-clockwise
to max position.
• Push the ignition button several times and the
burner should ignite.
• If the burner fails to ignite after above procedure,
turn the knob to the off position and close the gas
valve. Wait 5 minutes and then repeat the above
steps. If the barbecue still fails to light, please
refer to the manual ignition instruction in the
section below.
G6. Manual Ignition Instruction for Side Burner
• Set the control knob to the off position.
• Apply a lit match on the gap to burner ports.
• Push and turn the control knob anti-clockwise to
max position and the burner should ignite. If the
burner fails to ignite, contact your local dealer for
assistance.
G7. Roasting Hood Cooking
Barbecues equipped with a roasting hood give the
option of cooking with hood closed to form an ‘oven’
for roasting food, such as joints of meat, whole
chickens, etc.
When roasting, turn the burner under the food to the
OFF position. Close the hood and turn the other
burner down to a lower setting i.e. low to medium to
achieve the temperature required. DO NOT ALLOW
YOUR BARBECUE TO OVERHEAT. Avoid lifting the
hood unnecessarily as heat is lost each time the
hood is opened.
G8. End of Cooking Session
After each cooking session, turn the barbecue burner
to the “max” position and burn for 5 minutes. This
procedure will burn off cooking residue, thus making
cleaning easier. Make sure the hood is open during
this process.
G9. Turning Off Your Barbecue
When you have finished using your barbecue, turn all
the control valves fully clockwise to the “Off” position,
then switch off the gas at the bottle. Wait until the
barbecue is sufficiently cool before closing its hood.
H. CARE AND MAINTENANCE
Regularly clean your barbecue between uses and
especially after extended periods of storage. Ensure
the barbecue and its components are sufficiently cool
before cleaning. Do not leave the barbecue exposed
to outside weather conditions or stored in damp,
moist areas.
• Never douse the barbecue with water when its
surfaces are hot.
• Never handle hot parts with unprotected hands.
17
PDF created with pdfFactory trial version www.pdffactory.com
H1. Cooking Grill
Clean with hot soapy water. To remove any food
residue, use a mild cream cleaner on a non-abrasive
pad. Rinse well and dry thoroughly.
H2. Burner Maintenance
Your burner has been preset for optimal flame
performance. You will normally see a blue flame,
possibly with a small yellow tip when the burner is
alight. If the flame pattern is significantly yellow, this
could be a problem caused by grease from cooking
blocking the burner or spiders or other insects in the
burner venturi. This can result in the flow of the gas
and air mixture being restricted or blocked which may
result in a fire behind the control panel causing
serious damage to your barbecue. If this happens,
the gas should be immediately turned off at the
bottle. Burners should be inspected and cleaned on
a regular basis in addition to the following conditions:
1) Bringing the barbecue out of storage.
2) One or more of the burners do not ignite.
3) The burner flame pattern is significantly yellow.
4) The gas ignites behind the control panel.
To clean a burner, remove it from the barbecue. The
outside of the burner can be cleaned with a wire
brush. Clean the portholes with a pipe cleaner or
piece of wire. Take care not to enlarge the portholes.
Clean the insect screen on the end of the venturi
tube with a bristle brush (i.e. an old toothbrush).
Clean the venturi tube with a pipe cleaner or piece of
wire. You may need a torch to see into the venturi
tube to make sure it is clear. ”Turn the burner up on
end and lightly tap against a piece of wood to
dislodge any debris from inside.”
H3. Barbecue Body
Regularly remove excess grease or fat from the
barbecue body with a soft plastic or wooden scraper.
It is not necessary to remove all the grease from the
body. If you need to clean fully, use hot soapy water
and a cloth, or nylon-bristled brush only. Remove
cooking surfaces and burners before full cleaning. Do
not immerse the gas controls or manifold in water.
Check burner operation after carefully refitting into
body.
H4. Fixings
All screws and bolts, etc. should be checked and
tightened on a regular basis.
H5. Storage
Store your barbecue in a cool dry place. It must be
inspected on a regular basis as damp or
condensation can form which may result in damage
to the barbecue. It may be necessary to dry the
barbecue and the inside of the cover if used. Mould
can grow under these conditions and should be
cleaned and treated if required. Any rust that is found
that does not come into contact with the food should
be treated with a rust inhibitor and painted with
barbecue paint or a heat resistant paint. Chrome
plated warming racks and grills should be coated
with cooking oil. Wrap the burners in aluminium foil to
help prevent insects or other debris from obstructing
the burners.
The gas bottle must be always be disconnected from
the barbecue and stored in a well ventilated area at
least 1 metre away from any fixed ignition source. Do
not store inside residential accommodation. Never
store cylinders below ground level (e.g. cellars). Do
not let children tamper with bottles.
I. Technical Specifications
Model Number KS0993
Gas Category I3P (37)
Type of Gas Propane
Gas Pressure 37 mbar
Pin Number 359/BU/1016
Injector Size (Main Burner) 0.75mm
Injector Size (Side Burner) 0.74mm
Total Heat Input 7.0 kW
2 Burner Heat Input 4.7 kW
Side Burner Heat Input 2.3 kW
Gas Consumption 500 g/h
Country of Destination GB and IE
This barbecue grill is manufactured by:
Donguang Kingsun Enterprises Co. Ltd.
Address: Xicheng Area 2, Shiyong Village, Hengli
Town, Dongguan City, Guangdong Province,
China
18
PDF created with pdfFactory trial version www.pdffactory.com
L. Troubleshooting
Problem Possible Cause Solution
Burner will not light using the
ignition system
Faulty regulator Have regulator checked or replace Obstructions in burner Clean burner
Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected on
Electrode or wire is damaged Change electrode and wire Faulty pushbutton ignitor Change ignitor
Burner will not light with a match LP gas cylinder is empty Replace with full cylinder
Faulty regulator Have regulator checked or replace Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose
Low flame or flashback (fire in
burner tube— a hissing or
roaring noise may be heard)
Obstructions in burner Clean burner
LP gas cylinder is empty Replace with full cylinder
Reconnect wire
electrode or ignition unit.
LP gas cylinder too small Use larger cylinder.
Obstructions in gas jets or gas hose Clean jets and gas hose Windy conditions. Use BBQ in a more sheltered position
Gas valve knob difficult to turn Gas valve jammed Replace gas valve
19
PDF created with pdfFactory trial version www.pdffactory.com
Argos Limited, MK9 2W
2 Burner Gas BBQ with side burner
Assembly Instructions -
Please keep for future reference
345/0901
307223
Dimensions
Width - 112cm
Depth - 52cm
Height - 96.5cm
Important -
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 (Argos)/ 03450 778888 (Homebase). Please visit the website www.argos.co.uk or www.homebase.co.uk for more information.
Please read this instructions fully before using the appliance
Issue 1 - 25/08/2014
Safety and Care Advice
Important - Please read this instructions fully before using the appliance
•
Assembly time: approx. 45 mins.
•
Retain these instructions for future reference.
•
Use outdoors only.
•
Do not use the barbecue or store gas bottles below ground level. LP gas is heavier than air so if a
leak occurs the gas will collect at a low level and could ignite in the presence of a flame or spark.
•
For use with LPG bottled gas only. A suitable regulator must be used for butane, propane or mixes.
•
Remove plastic wrap from any part before lighting.
•
Do not use within 1m of any flammable structure or surface. Do not use under any combustible surface.
•
LP gas cylinders should never be placed directly underneath the barbecue.
•
LP gas cylinders should never be stored or used lai on their side, in the horizontal position. A leak
would be very serious and liquid could enter the gas line with serious result.
•
Never store gas bottles indoors.
•
Do not move the appliance during use.
•
Open the barbecue hood before lighting.
•
Do not move the barbecue until it has completely cooled after use.
•
This barbecue must not be left unattended when lit.
•
The hood handle can become very hot. Grip only the centre of the handle. Always use oven gloves
when cooking or carrying out any adjustments to the barbecue.
•
Use purpose designed barbecue tools with long and heat resistant handles.
•
Use caution when opening the hood, as hot steam inside is released upon opening.
•
Warning: accessible parts may be very hot. Keep young children away.
•
Turn off the gas supply at the gas cylinder after use.
•
Never cover a barbecue until it has completely cooled.
•
Use this barbecue only on a stable and flat surface.
•
Before use this barbecue , perform a leak test. Thus us the only safe and sure way to detect any gas
leaking from joints and connections of the barbecue after assembly.
•
Leak test annually, and whenever the gas bottle is removed or replaced.
•
Do not store flammable materials near this barbecue.
•
Do not use aerosols near this barbecue.
•
Failure to follow the manual’s instructions could result in serious injury or damage.
•
Do not modify the appliance. Modification of this barbecue may be dangerous, is not permitted and
will nullify any warranty.
•
This appliance must be kept away from flammable materials during use.
•
All the parts sealed by the manufactured or his agent shall not be manipulated by the user.
•
If you have any queries regarding these instructions, contact your local dealer.
Gas and Regulator
This barbecue can use either propane or butane or propane/ butane mixed LPG (liquid petroleum gas)
bottled gas. Propane bottles, will supply gas all year round, even on cold winter days. Butane bottles will
supply sufficient gas in summer, but it may affect the performance of the barbecue and restrict the heat
output available from the burners, particularly once the gas temperature starts to fall below +10°C. A
spanner may be required to change gas bottles.
• The hose should hang freely with no bends, twisting, tension, folds, or kinks that could obstruct free
flow of gas. Always inspect the hose for cuts, cracks, or excessive wear before use.
• Apart from the connection point, no part of the hose should touch any hot barbecue parts. If the hose
shows any sign of damage it must be replaced with a hose suitable for use with LP gas which meets
the national standards for the country of use.
• A suitable hose must comply with BS3212, and the length should not exceed 1.5 metres.
1
Safety and Care Advice
For optimal performance, we suggest to use a 5-15kg gas bottle. The maximum dimension of the gas
bottle is dia 31.5cm and height 58cm.
Key
1= maximum diameter
2= maximum height
Never mount the gas bottle under the barbecue on the base shelf as this could result in serious injury to
the user, other people and/or property. Always place the gas bottle at the side of the appliance. The
gas bottle should be sited as far away from the appliance as possible without straining the hose.
This appliance is only suitable for use with low-pressure butane or propane gas and fitted with the appropriate low-pressure regulator via a flexible hose. The hose should be secured to the regulator and the
appliance with hose clips/nut. This barbecue is set to operate a 28-30 mbar regulator with butane gas or
a 37mbar regulator with propane gas. Use a suitable regulator certified to EN16129. Please consult your
LPG dealer for information regarding a suitable regulator for the gas cylinder.
2
1
Installation
Selecting a Location
This barbecue is for outdoor use only and should be placed in a well-ventilated area, and on a safe and
even surface. Never place your barbecue below ground level. Take care to ensure that the barbecue
must be used on incombustible floor. The sides of the barbecue should NEVER be closer than 1 me-
tre from any combustible surface, including trees and fences and make sure that there are no heat
sources near the barbecue (cigarettes, open flames, spark etc.). Keep this barbecue away from any
flammable materials!
Precautions
Do not obstruct any ventilation openings in the barbecue body. Position the gas bottle on level ground next
to the barbecue and safely away from any source of heat. Should you need to install or change the gas
bottle, confirm that the barbecue is switched off, and that there are no sources of ignition (cigarettes, open
flame, sparks, etc.) near before proceeding.
Fixing a Regulator to the Gas Bottle
Confirm all barbecue control knobs are in the off position. Connect the regulator to the gas bottle according
to your regulator and bottle dealer’s instructions.
Leak Testing (Always perform a leak test in a well-ventilated area)
Confirm all control knobs are in the off position. Turn the gas on / open the gas control valve on the gas
bottle or regulator. Check for leaks by brushing a solution of ½ water and ½ liquid detergent / soap over all
the gas system joints, including gas bottle valve connections, hose connections, and regulator connections.
NEVER USE AN OPEN FLAME to test for leaks at any time. If bubbles form over any of the joints there is
a leak. Turn off the gas supply at the gas bottle. Retighten all joints. Repeat test. If bubbles form again do
not use the barbecue and contact your local distributor for assistance. Always wipe the mixed solution (½
water and ½ liquid detergent / soap) from all joints and connections after leak testing.
2
Safety and Care Advice
Operation
Warning
• Before proceeding, make certain that you understand the IMPORTANT INFORMATION section of
this manual.
• Your barbecue is not designed to be used with more than 50% of the cooking area as a solid plate —
this includes baking dishes. Full coverage will cause excessive build-up of heat and damage the
barbecue. This is not covered by warranty.
Preparation Before Cooking
To prevent foods from sticking to the cooking surface, please use a long handled brush to apply a light
coat of cooking or vegetable oil before each barbecuing session. (Note: When cooking for the first time,
paint colours may change slightly as a result. This is normal and should be expected.) During use, the
protective coating may come off the cooking surface. This is normal an is not harmful. Line the drip pan
with aluminium foil. This will make cleanup easy.
Lighting the Main Burner
• Open the barbecue hood.
• Ensure all knobs are in the off position. Open the gas control valve on the gas bottle or regulator.
• Push in and turn the control knob to the Max position. Press the ignition button rapidly several times
until left or right portion of the burner is lit. If burner fails to ignite, turn control knob to the off position
and turn gas off at the bottle or regulator. Wait five minutes, then repeat the above steps. After successful lighting of one side, ignite the remaining portion of the burner. If the burner fails to ignite after
following above procedure, turn all the knobs to the off position. Close the gas valve on the gas bottle. Wait 5 minutes, then repeat the above steps. If the barbecue still fails to light, please refer to the
manual ignition instruction in the section below.
• After ignition, the burner should be burned at the high position for 3-5 minutes in order to preheat the
barbecue. This process should be done before every cooking session. The hood (where applicable)
should be open during preheating.
• After completion of preheating, the burner should normally be turned down to a lower position for
best cooking results.
Manual Ignition Instruction for Main Burner
• Insert lit match through the match-lighting hole at the side or bottom of the barbecue body.
• Push in and turn the control knob anti-clockwise to the max position.
• After the left or right portion of the burner is lit, light the remaining portion of the burner.
• If burner fails to ignite, contact your local dealer for assistance.
• After ignition, the burner should be burned at the max position for 3-5 minutes in order to preheat the
barbecue. This process should be done before every cooking session. The hood (where applicable)
should be open during preheating.
• After completion of preheating, the burner should normally be turned down to a lower position for
best cooking results.
Lighting the Side Burner
• Keep side burner free.
• Set the control knob to off and turn on the gas supply.
• Push in and turn the control knob anti-clockwise to max position.
• Push the ignition button several times and the burner should ignite.
• If the burner fails to ignite after above procedure, turn the knob to the off position and close the gas
valve. Wait 5 minutes and then repeat the above steps. If the barbecue still fails to light, please refer
to the manual ignition instruction in the section below.
3
Safety and Care Advice
Manual Ignition Instruction for Side Burner
• Set the control knob to the off position.
• Apply a lit match on the gap to burner ports.
• Push and turn the control knob anti-clockwise to max position and the burner should ignite. If the
burner fails to ignite, contact your local dealer for assistance.
Grill Cooking
The burners heat up the flame tamer underneath the grill, which in turn heats the food on the grill. The
natural food juices produced during cooking fall onto the hot flame tamer below and vaporise. The subsequent rising smoke bastes the food, as it travels upwards, imparting that unique barbecued flavor.
Roasting Hood Cooking
Barbecues equipped with a roasting hood give the option to form an ‘oven’ for roasting or baking food,
such as joints of meat or whole chickens, etc. More even cooking of food will actually be achieved by using
the barbecue with the hood down. However, this should only be done with the burners on low.
For best results, place the food you wish to bake or roast on a metal baking tray and set it on one side of
the cooking grill.
Turn the burner directly under the food to the OFF position and turn all other burners to a LOW to MEDIUM
position.
Close the hood to cook the food ‘indirectly’. Avoid lifting the hood unnecessarily as heat is lost every time
the hood is opened. If the hood is opened during cooking please allow extra time for the barbecue to regain
its temperature and complete the cooking. Use the temperature gauge (if applicable) to monitor the heat of
the barbecue.
If the internal heat becomes too high, turn the burners down to the low position. It is not necessary or
advisable to have all of the burners on high when the hood is closed.
DO NOT ALLOW YOUR BARBECUE TO OVERHEAT. Take care when opening the hood as hot steam
can be released on opening.
Flare-Up Control *Very Important Notice*
Flare-ups occur when meat is barbecued, and its fat and juices fall upon the hot flame tamer. Smoke of
course helps give food its barbecued flavour, but it is best to avoid excessive flare-up to prevent food
being burned. To control flare-ups, it is ABSOLUTELY ESSENTIAL to trim away excess fat from meat
and poultry before grilling, use cooking sauces and marinades sparingly and try to avoid very cheap cuts
of meat or meat products as these tend to have a high fat and water content. Also, the burners should
always be placed on the low setting during cooking.
When flare-ups do occur, they can usually be extinguished by applying baking soda or salt directly onto
the flame tamer. Always protect your hands when handling anything near the cooking surface of the barbecue and take care to protect yourself from the flames.
If a fat fire occurs, please see the instructions given below.
Fat Fires
Empty and clean the drip tray, of food debris after each cooking session. If the barbecue is to be used for
large gatherings, it will be necessary to turn off and cool the barbecue every two hours to remove food
debris from the drip tray, and clean it out. The time between cleaning may need to be reduced if very
fatty foods or cheap meat products are being cooked. Failure to do this may result in a fat fire, which
may cause injury and could seriously damage the barbecue.
4
Safety and Care Advice
In the event of a fat fire:
‧
If safe to do so, turn all control knobs to the ‘off’ position.
‧
Turn off the gas supply at the gas bottle.
‧
Keep everyone at a safe distance from the barbecue and wait until the fire has burnt out.
‧
Do not close the hood or lid of the barbecue.
‧
NEVER DOUSE A BARBECUE WITH WATER. IF AN EXTINGUISHER IS USED, IT SHOULD BE A
POWDER TYPE.
‧
DO NOT REMOVE THE DRIP TRAY.
‧
If the fire does not seem to be abating or appears to be worsening, contact your local Fire Brigade for
assistance.
End of Cooking Session
After each cooking session, turn the barbecue burners to the “high” position and burn for 5 minutes. This
procedure will burn off cooking residue, thus making cleaning easier. Make sure the hood is open during
this process.
Turning Off Your Barbecue
When you have finished using your barbecue, turn all the control valves fully clockwise to the “Off” position,
then switch off the gas supply at the bottle.
Wait until the barbecue is sufficiently cool before closing the hood or lid.
Care and Maintenance
Regularly clean your barbecue between uses and especially after extended periods of storage. Ensure
the barbecue and its components are sufficiently cool before cleaning. Do not leave the barbecue exposed to outside weather conditions or stored in damp, moist areas.
•
Never douse the barbecue with water when its surfaces are hot.
•
Never handle hot parts with unprotected hands.
In order to extend the life and maintain the condition of your barbecue, we strongly recommend that the
unit be covered when left outside for any length of time, especially during the winter months
.
Even when your barbecue is covered for its protection, it must be inspected on a regular basis as damp or
condensation can form which may result in damage to the barbecue. It may be necessary to dry the barbecue and the inside of the cover. It is possible for mould to grow on any fat remaining on parts of the
barbecue. This should be cleaned off smooth surfaces with hot soapy water.
Any rust that is found that does not come into contact with the food should be treated with a rust inhibitor
and painted with barbecue paint or a heat resistant paint. A chrome cleaner may be used on chrome parts
if required. To prevent rusting, wipe chrome plated parts with cooking oil after rinsing and drying.
Cooking Surfaces
When the barbecue has cooled, clean with hot soapy water. To remove any food residue, use a mild cream
cleaner on a non-abrasive pad. Do not use scouring pads or powders as they can permanently damage
the finish. Rinse well and dry thoroughly. Due to the weight of the cooking surfaces, we do not recommend
cleaning in a dishwasher.
It is quite normal for surface rust to be present on the cooking surface. If rust appears between uses or in
storage, clean with a soft brass wire brush. Be careful not to damage the cooking surface, re-oil and cure.
Burner
Provided that they are operating correctly, in normal usage, burning off the residue after cooking will keep
5
Safety and Care Advice
the burners clean.
The burners should be removed and cleaned annually, or whenever heavy build-up is found, to ensure that
there are no signs of blockage (debris, insects) in either the burner portholes or the primary air inlet of the
burners. Use a pipe cleaner to clear obstructions.
When refitting the burners, be careful to check that the neck of the burner fits over the valve outlet.
It is quite normal for surface rust to be present on the burners. If rust appears between uses or in storage,
clean with a soft brass wire brush.
Flame Tamer
Remove any food residue from the flame tamer surface with a plastic or wooden scraper or brass wire
brush.
Do not use a steel scraper or wire brush. Clean with hot soapy water and rinse well.
Drip Tray
After every use, empty and clean the drip tray of any fat or food particles, using a plastic or wooden scraper
if necessary.
Failure to keep it clean, and excessive build up can result in a fat fire. This can be hazardous and severely
damage the barbecue. This is not a fault in the barbecue and is therefore not covered by the terms of the
warranty. If required, the tray can be washed in hot soapy water.
Barbecue Body
Regularly remove excess grease or fat from the barbecue body using a cloth wrung out in hot soapy water
and dry thoroughly. Excess fat and food debris can be removed from inside the body using a soft plastic or
wooden scraper. It is not necessary to remove all the grease from the body. If you need to clean fully, use
hot soapy water and a cloth, or nylon-bristled brush only. Do not use abrasives. Remove cooking surfaces
and burners before full cleaning. Do not immerse the gas controls or manifold in water. Check burner
operation after carefully refitting into body.
A stainless steel cleaner may be used on stainless steel parts if required.
Whenever a barbecue is being assembled for the first time or its burners are being cleaned, make sure
each gas valve tip goes into the burner venturi tube completely during the assemble or re-assemble
process.
Barbecue Hood or Lid
Use a non-abrasive cloth or pad and clean with hot, soapy water. Do not use scouring pads or powders as
they can permanently damage the finish.
Trolley
Wipe with a cloth wrung out in hot soapy water and dry.
Burner venturi tube
Gas valve
6
if required the next
Safety and Care Advice
Fixings
All screws and bolts, etc. should be checked and tightened on a regular basis.
Storage
Ensure the barbecue is properly cooled before covering or storing. Store your barbecue in a cool dry place.
It must be inspected on a regular basis as damp or condensation can form which may result in damage to
the barbecue. It may be necessary to dry the barbecue and the inside of the cover if used.
Mould can grow under these conditions and should be cleaned and treated if required. Any rust that is
found that does not come into contact with the food should be treated with a rust inhibitor and painted with
barbecue paint or a heat resistant paint.
Cooking grills should be coated with cooking oil.
Cover the burners with aluminum foil in order to prevent insects or other debris from obstructing the burner
holes.
If the barbecue is to be stored indoors, the gas bottle must be disconnected and left outside. The gas bottle
should always be stored outside, in a dry, well-ventilated area, away from any sources of heat or ignition.
Do not let children tamper with the bottle.
When using the barbecue after extended periods of storage follow the cleaning procedures.
Carbon Monoxide Hazard
7
Note:
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
Components - Parts
Please check you have all the panels listed below
1
Lid x1
2
Lid handle x1
If you have damaged or missing components,
call the Customer Helpline: 03456 400800
(Argos)/ 03450 778888 (Homebase).
Cooking grill x1
3
Heat tent x1
4
Firebowl x1
7
10
12
Right front leg x 1
Left front leg x 1
5
Hinge x 2
Grease cup hanger x 1
8
11
Right rear leg x1
13
Left rear leg x1
Burner x 1
6
9
Grease cup x1
8
Components - Parts
Please check you have all the panels listed below
14
Wheel x 2
18
Front canvas x1
15
Left upper support
x 1
19
Bottom shelf x1
16
Right upper support
x 1
20
17
Control panel assembly x 1
Side table x1
9
21
Side table front support x1
25
Side burner electrode x 1
22
Side table rear
support x1
26
Side burner x 1
24
Side burner
23
Side burner assembly x1
Side burner grate x 1
27
28
knob x 1
Venturi clip
x 1
Components - Fittings
Please check you have all the panels listed below
Note
:
:
The quantities below are the correct amount to complete the assembly.
::
A
B
C
D
20mm Bolt x 8
E
Washer x 2
I
8mm Bolt x 3
M
M5 nut x 6
12mm Bolt x 16
F
M6 nut x 4
J L
Axle x 2
10mm screw x 6
G
8mm Bolt x 8
K
Heat tent support x 1
H
M4 nut x 2
15mm Shoulder bolt x 4
R-pin x 2
Tool required
Philips screwdriver
Wrench
(Do not provided in this
product)
Small hammer
Ruler/ tape measure
10
Assembly Instructions
Step 1
12
Fix the left front leg and
13
left rear leg on the bottom shelf using 12mm
B
bolts
19
.
F3
13
12
F2
B
B
B
FRONT
19
B
F11
Step 2
10
Fix the right front leg
19
11
and left rear leg on the
bottom shelf using 12mm
B
bolts
.
FRONT
11
19
F6
F5
10
B
B
B
B
11
Assembly Instructions
Step 3
14
Install the wheels to the
left front leg and left rear
13
leg using the axles
12
Then fix the axles by R
L
pins
.
J
13
J
.
12
J
14
L
L
F10
14
F9
F8
J
FRONT
Step 4
Connect the left upper sup-
15
port with the left front
12
leg and left rear leg
using 20mm bolts and M6
nuts
Repeat the same connection
of the right upper support
with the right front leg
and right rear leg using
20mm bolts and M6 nuts
F
.
Fix the bolts tightly by the
screwdriver.
11
13
A
10
F
.
A
15
F1
12
F4
16
A
10
A
F
11
F
A
F
13
A
F
16
FRONT
12
Assembly Instructions
Step 5
Fix the control panel assem-
17
bly on the left upper support and right
upper support using
12mm bolts
15
16
B
.
15
16
17
F7
B
B
FRONT
Step 6
Fix the heat tent support
7
on the firebowl using
8mm bolts and M4 nuts
D
.
I
K
B4
K
D
I
7
13
Assembly Instructions
Step 7
7
Set the firebowl on the
left upper support and
right upper support using
20mm bolts
15
16
A
.
7
A7
A
A
A
B6
15
A
B7
16
Step 8
a:
Put the burner
through the hole of the fire-
7
bowl
.
b:
Align all valves on the
control panel assembly
against each venturi of the
6
burner
.
Important:
Make sure the valve
tip goes into the
venturi tube
completely with
good alignment.
Fix the burner on the fire-
7
bowl using 10mm
screws
C
.
6
6
17
a:
b:
valve
17
7
venturi
C
6
6
7
7
6
C
14
Assembly Instructions
Step 9
5
Fix the hinge on the firebowl using 8mm bolts
G
7
and M5 nuts
M
.
A5
5
G
M
7
5
M
G
Step 10
E
Put the washer between
the lid handle and the lid
1
.
Align the holes and fix the lid
2
handle on the lid using 8mm bolts
2
1
G
.
A1
1
G
E
E
A2
2
G
15
Assembly Instructions
Step 11
1
Fix the lid and firebowl
by the hinge using 8mm
bolts and M5 nuts
5
G
M
7
.
1
M
5
G
7
M
5
G
Step 12
Assemble the side table
21
20
22
.
C
.
front support and the
side table rear support to
the side table
Secure the supports with
10mm screws
C
E1
C
C
21
E3
20
C
22
E2
16
Assembly Instructions
Step 13
Install the side table assembly made on step 12 to the
right upper support by
15mm shoulder bolts
16
H
.
20
16
H
H
H
H
Step 14
Install the side burner
23
assembly to the left upper support using
12mm bolts
15
B
.
23
B
B
B
B
15
17
Assembly Instructions
Step 15
a:
Loosen the preassembled screws on the
side burner valve of the control panel assembly
b:
Fix the side burner valve
on the side burner panel
bracket of the side burner
23
assembly using the
screws.
17
a:
.
b:
23
26
c:
Put the side burner
and the side burner elec-
25
trode through the
hole of side burner assembly
23
.
c:
23
D4
26
D3
25
18
Assembly Instructions
D5
Step 15
d:
Align the venturi of the
26
side burner against the
valve.
venturi tube
completely with
good alignment.
Then tighten the side burner
on the side burner assembly
using 8mm bolt
Connect the electrode of the
main burner and the side
burner electrode to the
electrode end of ignitor on
the control panel assembly
17
.
Important:
Make sure the valve
tip goes into the
I
.
6
25
d:
I
26
6
Electrode of Main Burner
25
Valve
Burner venturi
e:
Put the side burner grate
27
on the side burner as-
23
sembly and align with 3
holes.
e:
Electrode of Side Burner
27
23
19
Assembly Instructions
Step 15
f:
Insert the hook end of the
28
venturi clip into the air
hole of the side burner venturi. Then clip another end
on the side burner valve.
The venturi clip is used to
stabilize the side burner so
as to make sure the side
burner valve tip goes into the
burner venturi securely with
the right position.
f:
valve
28
Venturi clip
Venturi
28
valve
28
Venturi
20
Assembly Instructions
Step 16
Put the grease cup hanger
8
through the hole of the
7
firebowl
.
B6
8
7
8
8
Step 17
Hang the grease cup on
the grease cup hanger
Attach the front canvas
to the left front leg and
right front leg
10
Secure the position with the
velcro on canvas edge.
9
12
.
Top view
8
.
18
B7
9
10
8
Side view
F12
18
12
21
Assembly Instructions
Step 18
24
Put the side burner knob
on the side burner assembly
23
.
4
Put the heat tent and
cooking grill on the fire-
7
bowl
.
3
23
B1
3
B2
4
7
Step 19
Assembly is complete.
ALL JOINTS AND
CONNECTIONS MUST
NOW BE LEAK TESTED
BEFORE USING THE
BARBECUE.
Leak test annually, and
whenever the gas bottle
is removed or replaced.
Always place the gas bottle at the side of the appliance. The gas bottle
should be sited as far
away from the appliance
as possible without straining the hose. The hose
length should not exceed
1.5 metres.
24
If you need help or have damaged or missing parts, call the
03450 778888 (Homebase).
Customer Helpline: 03456 400800(Argos)/
22
Technical Specification
Model Number
Gas Category
Type of Gas
Gas Pressure
Pin Number
Injector Size (Main Burner)
Injector Size (Side Burner)
Total Heat Input
2 Burner Heat Input
Side Burner Heat Input
Gas Consumption
Country of Destination
Do not use this barbecue outside England and Ireland.
