Argos kent panel 6ft bed ASSEMBLY INSTRUCTIONS
kent panel 6ft bed
Assembly Instructions - Please keep for future reference
538/9300
Dimensions
Width - 219cm
Depth - 197cm
Height - 103,3cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
issue 1 - 9/3/16
!
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Check you have all the
components and tools listed on
the following pages.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
Only clean using a damp cloth
and mild detergent, do not use
bleach or abrasive cleaners.
During assembly do not stand
or put weight on the product,
this could cause damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
From time to time check that
there are no loose screws on
this unit.
To redure
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Handy Hints
Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts.
Regularly check and ensure
that all bolts and fittings are
tightened properly.
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
If you have damaged or missing components, call the
Components - Panels
Customer Helpline: Argos = 0345 6400800
Please check you have all the panels listed below
3
Side rail (205x4.5x18 cm)
1
Headboard (197x8x103,3 cm)
2
Footboard (197x8x73,3 cm)
7
center cap x 14 (7.5x6.7x2.4 cm)
6
Slat x 14 (91x7x460 cm)
8
end cap x 28 (7.5x3.2x2.4 cm)
4
Center rail (209x4x6 cm)
Slat x 14 (91x7x460 cm)
8
3
Side rail (205x4.5x18 cm)
5
Support center rail (31x4x6 cm)
2
