Argos 1476303, 1523892 ASSEMBLY INSTRUCTIONS

656/0159

Assembly Instructions – Please keep for future reference

Important – Please read these instructions fully before starting assembly

Dimensions

Length - 200cm

Width - 97.5cm

Height - 185cm

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Issue 2 - 26/06/13

Metal High Sleeper

Safety and Care Advice

Important – Please read these instructions fully before starting assembly

• Check you have all the components and tools listed on pages 2 and 3.

• Remove all fittings from the plastic bags and separate them into their groups.

• Keep children and animals away from the work area, small parts could choke if swallowed.

• Parts of the assembly will be easier with 2 people.

• Place the product on flat and steady surface during use.

• Keep these instructions for further use.

• To ensure an easier assembly, we strongly advise that all fittings are only finger tightened during initial assembly. Only upon completion of the assembly should all fixing points be fully tightened.

Mattress height safety notice

• Make sure you have enough space to layout the parts before starting.

• Assemble the item as close to its final position (in the same

room) as possible.

• Assemble on a soft level

surface to avoid damaging the unit or your floor.

• Dispose of all packaging

carefully and responsibly.

• Safety: To avoid any risk of suffocation to animals or children dispose of the plastic bags immediately.

• Cleaning: As with all surfaces

clean with a damp cloth and mild detergent, do not use bleach or abrasive products.

Care and maintenance

• Only clean using a damp cloth and mild detergent, do no use bleach or abrasive cleaners.

• From time to time check that there are no loose screws on this unit.

• This product should not be discarded with household waste. Take to your local authority waste disposal centre.

Important

1) Please note the maximum mattress height is indicated on the corner post inside the opening at the top of the ladder.

2) This is legal requirement and it is vital that the mattress does not exceed this mark.

3) Maximum thickness of the mattress is 20cm:The top of the mattress shall not come above the line marked on the bed.

4) All assembly fixings should always be tightened properly.Take care to ensure that no fixings are loose.

5) Recommended size of the mattress for the top bunk is 90×190cm.

6) The bunk bed should not be used if any structural part is broken or missing.

7) Warning: High beds and the upper bed of bunk beds are not suitable for children under six years due to the risk of injury from falls.

8) Children can strangle in items such as ropes, strings, cords, harnesses and belts attached to or hung on a bunk bed.

Warning

1) Children can become trapped between the bed and wall. To avoid risk of serious injury the distance between the top safety barrier and the wall shall not exceed 75mm or shall be more than 230mm.

2) The bed complies with EN747-1:2012

Please check you have all the parts listed below

Components - Parts

Corner post x 2 (Ø4.5 x 184.7cm)

Ladder (151 x 35.7cm)

End panel x 2 (97 x 39.8cm)

Front guard (191 x 42cm)

Rear guard (191 x 42cm)

Slats x 2 (□2 x 1 x 95cm)

Support x 2 (Ø1.3 x 90cm)

Lower stretcher (long) (190.4 x 3cm)

Lower stretcher (short) x 2 (Ø1.9 x 88.5cm)

Slats x 22 ((□2 x 1 x 95cm)

Corner post x 2 (Ø4.5 x 184.7cm)

Smaller diameter
