EN
PORTABLE AIR CONDITIONER (LOCAL)
SWAN EVO
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance work. Observe all the safety instructions; failure to do so may lead to accidents and/or damage. Store these instructions in a safe place for future reference.
V 11/18 |
17 |
Appliance filled with flammable gas R290.
Before installing and using the appliance, read the owner’s manual.
Before repairing the appliance, read the service manual.
The Refrigerant R290
•To realize the function of the air conditioner unit, a special refrigerant circulates in the system. The refrigerant is the fluoride R290 = 3 GWP (Global warming potential). This refrigerant is flammable and inodorous. It can lead to explosions under certain conditions, however the flammability of this refrigerant is very low and it can be ignited only by fire.
•Compared to other common refrigerants, R290 is a non-polluting refrigerant with no harm to the ozonosphere and a no effect upon the greenhouse effect. R290 has very good thermodynamic features which lead to a really high energy efficiency. The units therefore need less filling.
Warning:
Do not try to accelerate the defrosting process or to clean the appliance in different ways other than those recommended by the manufacturer. Should repair be necessary, contact your nearest authorized Argoclima Service Centre. Any repairs carried out by unqualified personnel may be dangerous. The appliance has to be stored in a room that doesn’t have any continuously operating ignition sources. (for example: open flames, an operating gas appliance or an operating electric heater.) Do not pierce or burn.
Appliance has to be installed, operated and stored in a room with a floor area larger than 7 m2.
For repairs, strictly follow manufacturer’s instructions only for appliances filled with R290 flammable gas. Be aware that refrigerants do not have any odour.
V 11/18 |
18 |
GENERAL OPERATING AND SAFETY INSTRUCTIONS
•This appliance is a local air conditioner designed for domestic use.
•Only use this air-conditioner as described in this manual.
•Ensure that the required voltage and frequency (220-240V/50 Hz) match the available power source.
•Fuse style 5ET or SMT 250V, the electricity passing through the fuse cannot be above 3.15A.
•This appliance can be used by children aged from 8 years and above and people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children without supervision.
•Ensure that the electricity system is able to deliver the operating current required by the air conditioner, in addition to that normally absorbed by other appliances (household appliances, lighting system, etc.). Please refer to the maximum power input data indicated on the air conditioner's data plate.
•Connection to the electricity grid must take place in accordance with current installation standards.
•Ensure that the automatic switches and system protection valves are able to withstand a start-up current of 6A (normally for less than 1 second).
•The system socket must always be fitted with an efficient earth connection.
•Make sure that the plug is fully inserted. Do not use multiple adapters. Do not touch the plug with wet hands. Make sure that the plug is clean.
V 11/18 |
19 |
•Do not use the plug as a means by which to start/stop the air conditioner: use the ON/OFF button on the remote control or on the control panel.
•Do not install the air conditioner in rooms where it may receive water splashes (e.g. laundry rooms).
•This air conditioner can be used by children of 8 years of age or older, and by persons with reduced physical, sensory and mental abilities or who lack the necessary know-how and experience to operate it, if under the supervision or instruction of a person responsible for their safety, so that they are fully aware of the attendant risks.
•Before moving or cleaning the device, ensure that it is unplugged from the socket.
•Do not move the air conditioner while it is operating; first turn the appliance off, check for any condensate build-up and empty it if necessary.
•To turn the appliance off, set the remote control to OFF and remove the plug from the socket. Pull on the plug only. Do not pull the cord.
•Do not use the appliance if the cord or plug are damaged. If the power supply cord is damaged, it must be replaced by the manufacturer, dealer or a similarly qualified person so as to avoid any safety risks.
•Keep the unit away from fire, possible fire sources, inflammable or explosive objects.
•Do not leave the unit unattended while it’s operating, turn the unit off and unplug it.
•If drainage hose is used, the ambient temperature musnt’t be lower than 0°C. It can cause water leakage to the air conditioner.
•Do not splash or pour water on the air conditioner
V 11/18 |
20 |
PRECAUTION!
•Do not insert any objects into the air conditioner: this is very dangerous as the fan turns at high speed.
•Ensure that air circulates freely around the unit. Do not cover the air intake and delivery grilles with drapes or any other means.
WARNING!
•The air conditioner must be positioned at least 50 cm from the wall or any other obstacles, on a flat and stable surface so as to avoid water leaks.
•The air conditioner is fitted with a system for protecting the compressor from overload. This means that the compressor only starts 3 minutes after its previous stoppage.
•Please wait at least 3 minutes before starting the unit. This helps prevent the compressor from being damaged.
WARNING!
In the event of an anomaly, switch the appliance off and unplug it from the socket. Do not dismantle or attempt to repair or modify the product. In the event of a malfunction, contact the service centre directly.
WARNING!
•Do not expose the air conditioner to direct sunlight, as the colour of the materials may change; moreover, the appliance may overheat causing the protection mechanism to intervene and switch the appliance off.
•Do not use insecticides, oils, detergents or spray paints near the appliance; do not use aggressive chemical detergents to clean the casing: this may damage the finish and colour.
V 11/18 |
21 |
