Apollo 1650ETL, 1550ETL User Manual
APOLLO Gate Operators, Inc.
Model 1550ETL Single Swing Gate Operator
INSTALLATION MANUAL
04/07
Model 1650ETL Dual Swing Gate Operator
2
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ..................... 3
Applications .............................................................. 4
Pre-Installation Checklist ........................................ 5
Parts Identification ................................................... 6
Operator Installation ................................................ 7-9
Pivot Arm Installation
Actuator Installation
Control Box Installation
Connecting the Actuator
Gate Bracket Installation
Limit Switch Adjustment
Control Board Connections
Control Board Adjustments - Learn Mode
1550ETL/1650ETL Actuator Option ………………….. 10
Push to Open Installation .......................................... 11
Programming Instructions ……………………………. 12
Control Board Description ……………………………. 13-17
Siren Connection ……………………………………… 18
Radio Receiver Options ............................................. 19
Troubleshooting guide .............................................. 20-22
Warranty .................................................................... 23
3
WARNING - To reduce the risk of injury or death:
READ AND FOLLOW ALL INSTRUCTIONS.
Installation should be performed by a professional installer.
Required welding should be performed by a qualified welder.
Should electricity be required, use a certified electrician only.
Any device that requires 120 Volts AC should be U.L. approved.
Review with the owner all safety concerns including:
Do not operate the gate unless area around gate is in full view.
Never let children operate or play with gate controls. Keep the remote control
away from children.
Always keep people and objects away from the gate. NO ONE SHOULD CROSS
THE PATH OF THE MOVING GATE.
Periodically test the obstruction sensitivity to assure safe and proper
operation. Do not test sensitivity by standing between the gate and the hinge or
stop post.
The “CAUTION AUTOMATIC GATE” signs should be clearly visible from both
sides of the gate.
Always insure that the gate has closed securely before leaving area.
Arrange with local fire and law enforcement for emergency access.
Use the emergency release only when the gate is not moving.
A secondary entrapment device such as loop detectors, edge switches, and beam
detectors are highly recommended and required to meet the UL325 standard.
Install control devices such as keypads far enough away (5 feet or further) from any
moving parts of the operator and gate to prevent possible injury.
Do not install control box where the gate can come in contact with person using the
push button on side of control box.
Always disconnect the battery or power source when making adjustments or repairs to
any part of the gate or operator.
All rollers should be covered to prevent injury.
KEEP GATES PROPERLY MAINTAINED. Read the owner’s manual. Have a qualified
service person make repairs to gate hardware.
The entrance is for vehicles only. Pedestrians must use separate entrance.
Test the gate operator monthly. The gate MUST reverse on contact with a rigid object or
stop when an object activates the non contact sensors. After adjusting the force or limit of
travel, retest the gate operator. Failure to adjust and retest the gate operator properly can
increase the risk of injury or death.
SAVE THESE INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
4
APPLICATIONS
The Apollo Model 1550ETL/1650ETL Swing Gate Operator is approved for Vehicular Class I & II usage under UL 325 Guidelines, and is designed to handle swing
gates up to 16 feet in length and 600 pounds each. A professional fence or gate
dealer is recommended to assure proper installation.Apollo Gate Operators are
available only through qualified dealers with an outstanding reputation in the fence
and gate industry. These dealers will be able to recommend the proper equipment
for particular applications. Apollo Gate Operators are 12 Volt DC (Direct Current)
powered. A 12 Volt sealed battery (33 ampere hour minimum) with connecting
posts located on the top is recommended. There are several advantages with 12
Volt DC systems:
Low voltage virtually eliminates risk of electrical shock.
Battery powered operators provide up to 200 operations in the event of
power outages.
The battery may be recharged with a trickle charger or by solar energy
(Electrical battery chargers should have a class 2 transformer rating).
If a trickle charger is used and a standard electrical outlet is not readily available, a
licensed electrician will be required for proper electrical hook up.
The following table should be used as a guide for capacity of operation of operators
only, additional options may reduce the the daily usage. Please note that the charge
capability of solar panels will vary with different geographical locations.
Daily Cycles 1-10 1-20 1-40 1-60 1-80 80+
5 watt solar panel
*
10 watt solar panel
*
20 watt solar panel(requires 5310 regulator)
*
30 watt solar panel(requires 5310 regulator)
*
40 watt solar panel(requires 5310 regulator)
*
1.5 amp battery charger
*
10 amp battery charger
*
Note: Double the amount of solar panels for Dual Gate Operators.
5
PRE-INSTALLATION CHECKLIST
The following check list should be used before beginning installation:
Verify that the proper operator has been selected for this application.
Verify proper installation and operation of the gate.
1. Are the hinges servicable?
2. Does the gate swing free and level?
3. Will the gate require a locking device?
4. Is the hinge and stop posts sturdy enough to handle the gate & operator?
5. Does the gate meet U.L. construction?
Determine the general location of the operator, attachment points, and solar
panel (if used).
1. Is there a suitable location for the operator?
2.Can the solar panel (if used) be mounted in an unobstructed area facing
south (in the northern hemisphere)?
3. Will additional solar panel cable be required?
4. Is electricity available (if required)?
Consider safety and access options. Recommend if needed.
1. Will there be children or animals in the area?
2. Are safety loops, edge switches, or photo beam detectors required?
3. How can the gate be opened in emergencies?
4. How will visitors enter and exit?
5. Will vehicles (and trailers) have sufficient room off roadway to operate any
control devices such as keypads?
IMPORTANT
Never weld parts to the gate or posts when the operator circuit
board is powered. Doing so may damage the board beyond repair.
6
PARTS IDENTIFICATION
#10025215
Gate Bracket
(2 with 1650)
#1125
Hardware Kit
(2 with 1650)
#404C
Automatic Battery Charger (optional)
#201
5 Watt Solar Panel & Bracket
(optional)
(2 required with 1650)
816E
Actuator with 8’ cable
(816EX slave actuator with
38’ cable supplied with 1650)
#11111B
Control Box
#10000415
Pivot Arm
(2 with 1650)
#446
Bolt On Pivot Arm (optional)
(2 required with 1650)
#273G
CAUTION Signs (2 each)
(4 each with 1650)
OPTIONS
7
OPERATOR INSTALLATION
Location of Pivot Point.
1/2”
Center Line of attachment
point for gate bracket
Hinge post
Vertical position
of pivot arm
Measurements are taken from
the center of the hinge.
STEP 1
PIVOT ARM INSTALLATION (standard pull to open)
Front View
Pivot ArmMust be level
Notes:
PULL TO OPEN pulls gate open (actuator is extended when gate is in the closed position).
PUSH TO OPEN pushes the gate open (actuator is retracted when gate is in the closed
position).
For PUSH TO OPEN installations see page 12.
If a 400 Upgrade Kit is to be used, refer to the 400 instructions for pivot point location.
The following instructions provide up to 105o of swing.
Gate (closed)
13”
6”
Direction of
opening
13”
6”
Left Hand Swing
Right Hand Swing
Top View
