Apollo 150, 120 User Manual

Download

APOLLO 120 /150 III

12.1”/15.1” TFT Intel® Celeron/Pentium® III

Plastic-housing Panel PC with

Versatile

Stand design

User’s Manual (Version 2207)

This document is copyrighted 2002 by the Manufacturer. The information provided in this document has been carefully checked and is accurate at the time of publication. However, the Manufacturer assumes no responsibility for any infringements of patents or other rights of third parties that may result from its use.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form of or via any means without the prior written permission of the Manufacturer. Further, this publication and features described herein are subject to change without notice.

Trademarks

All brand and product names used for identification in this document are trademarks or registered trademarks of their respective companies.

Unpacking

After unpacking the APOLLO 120/150 III carton, check and see if the following items are included and in good condition.

u APOLLO III main system x 1 u Accessories

- Power cord (90o) x 1

- External FDD cable (optional) x 1

- External 5V/12V DC power cable (optional) x 1

- Utilities & drivers & user manual CD diskette x 1

(for touchscreen drivers, please download the updated drivers from the following website

http://www.3m.com or http://www.elotouch.com

- Base knob with rubber cushion x 1

- Panel mounting kit (optional) x 1 set

Make sure that all of the items listed above are present. If any of the above items is missing, contact your dealer immediately.

Warranty

All products manufactured by the Manufacturer. are warranted against defective materials and workmanship for one year starting from the date of delivery to the original purchaser. However, warranty or service will not be extended if 1). the product is repaired, modified or altered unless such repair, modification or alteration is authorized by the Manufacturer; or 2). the product serial number or warranty label is defaced or missing; or 3). the product is not properly used.

Important Safety Precautions

Before getting started, read these instructions and save them for later reference.

1. Turn off the computer before cleaning. Clean with a damp or dry cloth only. Do not spray any liquid cleaner on screen directly.

2. The power outlet socket used to plug in the computer power cord must be located near the system and easily accessible. Do not use outlets on the same circuit of the systems that regularly switched on and off.

3. Make sure the voltage of the power source is correct before connecting the computer to the power outlet.

4. If the computer is sharing an extension cord with other devices, make sure the total ampere rating of the devices plugged into the extension cord does not exceed the cord’ s ampere rating.

5. Do not expose the power cord, extension cord and power outlet to moisture.

6. Install the computer on a reliable surface to prevent damage caused by dropping.

7. This computer is not equipped with an operating system. An operating system must be loaded first before installing any software into the computer.

8. Disconnect the power cord from the computer before any installation. Make sure both the computer and the external devices are turned off. The sudden surge of power may ruin any sensitive components. Also make sure the computer is properly grounded.

9. During installation of any internal components, be sure to ground yourself to keep from any static charge. Most electronic components are sensitive to the static electric charge. Use a grounding wrist strap and place all electronic components in any static-shielded devices.

10. The openings on the computer enclosure are for the cabin ventilation to prevent the computer from overheating. DO NOT COVER THE OPENINGS.

11. The brightness of the flat panel display will decrease with use. However, hours of use will vary depending on the application environment.

12. If the computer is equipped with a touch panel, avoid using sharp objects to operate the touch panel. Scratches on the touch panel may cause mal-calibration or non-function to the panel.

13. The LCD panel display is not subject to shock or vibration. When assembling the computer, make sure it is securely installed.
