APG Kari Operating Manual

AUTOMATION
Operator’s Manual
PRODUCTS
GROUP, INC.
KA Series
9004020
Rev. B, 08/14
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • E-mail: sales@apgsensors.com
KA Series Rev. B, 08/14
Table of Contents
Warranty ...........................................................................................3
Introduction ......................................................................................4
Specications ...................................................................................5
Dimensions .......................................................................................5
Options .............................................................................................6
Chemical Compatibility—Corrosion Resistance .............................6
Cable Weights...................................................................................7
Cable Specications .........................................................................7
Switch Wiring and Type Detail Table ...............................................8
Selecting the Right Switch ................................................................9
Understanding the Switch Action/Terminology .............................10
Single vs. Dual Point Control ........................................................10
Single Point with Timed Relay Control ..........................................11
Emptying/Filling Pump Control Circuits .......................................11
Duplex Pump Control Circuit ........................................................12
Operating Level Adjustment...........................................................13
Termination and Height Fixing ......................................................14
Position in Tank/Swing Distance Allowance..................................15
Control Contact Ratings ................................................................16
Verifying Operation ........................................................................16
Tips .................................................................................................17
Certicate of Compliance...............................................................18
Automation Products Group, Inc.
2
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • sales@apgsensors.com
Rev. B, 08/14 KA Series
Warranty and Warranty Restrictions
APG warrants its products to be free from defects of material and workmanship and will, without charge, replace or repair any equipment found defective upon inspection at its factory, provided the equipment has been returned, transportation prepaid, within 24 months from date of shipment from factory.
THE FOREGOING WARRANTY IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES NOT EXPRESSLY SET FORTH HEREIN, WHETHER EXPRESSED OR IMPLIED BY OPERATION OF LAW OR OTHERWISE INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
No representation or warranty, express or implied, made by any sales representative, distributor, or other agent or representative of APG which is
not specically set forth herein shall be binding upon APG. APG shall not be
liable for any incidental or consequential damages, losses or expenses directly or indirectly arising from the sale, handling, improper application or use of the goods or from any other cause relating thereto and APG’s liability hereunder, in any case, is expressly limited to the repair or replacement (at APG’s option) of goods.
Warranty is specically at the factory. Any on site service will be provided at the sole expense of the Purchaser at standard eld service rates.
All associated equipment must be protected by properly rated electronic/ electrical protection devices. APG shall not be liable for any damage due to improper engineering or installation by the purchaser or third parties. Proper installation, operation and maintenance of the product becomes the responsibility of the user upon receipt of the product.
Returns and allowances must be authorized by APG in advance. APG will assign a Return Material Authorization (RMA) number which must appear on all related papers and the outside of the shipping carton. All returns are subject to
the nal review by APG. Returns are subject to restocking charges as determined
by APG’s “Credit Return Policy”.
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • sales@apgsensors.com
3
KA Series Rev. B, 08/14
• Introduction
KA series controls consist of a free-oating switch enclosure to which a protected multiconductor cable is attached. Inside the oat there are a number of microswitches set at different angles. A control weight is xed at a point along the cable to keep the cable immersed in the liquid. The suspended oat switch
follows the movement of the liquid level. As the liquid level rises and falls, the
weight on the cable causes the inclination of the oat to change. This tilting
action results in microswitches opening and closing, sequentially, at different elevations. The switch-operating levels are easily adjusted by moving the weight along the cable and/or altering the
height of the cable xing point.
The switch enclosure is conical in shape and the required number of microswitches are cast at predetermined angles inside it. The hermetically sealed
oat housing is lled with plastic foam
and is weighted on one side. This
rugged oat and the weight are made
of chemically resistant polypropylene while the standard cable is PVC coated.
There are three versions of the KA series switch. The standard S Series units are the largest, with a diameter of 6.7 inches, the C Series units have a diameter of 3.9 inches, and the smallest, M series units, are 3.0 inches in diameter.
Alarms Control Plus Alarms Level IL IH IC 2HL 2L 3L 2H 3H 4L 4H 4L5E 4H5E
(1LE) (1HE) (3LE) (3HE)
Stop Both
HH — — — High — — — High Alarm Alarm Pumps Alarm
Pump Pump Pump Pump Start Start H — — — — Stop Start Stop Start Pump Pump No.1 No.2
Pump Pump Pump Pump Start Start L — — — — Start Stop Start Stop Pump Pump No.2 No.1
LL Low High High/Low Low — Low — — Low Alarm Alarm Alarm Alarm Alarm Alarm Pumps
O Height of Face of Float in Free-Hanging Position
High
Stop Both
Automation Products Group, Inc.
4
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • sales@apgsensors.com
Rev. B, 08/14 KA Series
• Specications
S Series C Series M Series Contact Rating: Max.V oltage 250 V AC/DC 250 V AC/DC 250 V AC/DC Max. AC Current (Resistive) 6 A 6 A 6A (Inductive) 3 A 3 A 3A Max. DC Power 75 VA 75 VA 75 VA (75 VA = 0.3 A @ 250 V) Max. liquid Temp 60°C (140°F) 60°C (140°F) 60°C (140°F) Max. pressure (at 20°C) 28 PSI 28 PSI 28 PSI
Min. Fluid Specic Gravity 0.7 0.7 0.95
Standard Cable Length 16 ft. 16 ft. 16 ft. Switching Differential: Min. 10 in. 10 in. 10 in. Max. 50 in. 50 in. 40 in. Max. No. of Switching Levels 4 3 2 Max. No. of wires in Cable 5 4 3 Standard Weight Type
G (black-3/4 lb.) G (black-3/4 lb.) B (red-3/4 lb.)
• Dimensions - in./mm
S Series
2.13”
54.1 mm
4.25”
107.95 mm
6.1”
155 mm
6.70”
170 mm
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • sales@apgsensors.com
5.6”
142.24 mm
C Series
5.0”
127 mm
3.90”
99 mm
M Series
3.0”
76 mm
5
KA Series Rev. B, 08/14
• Options
Higher working temperature to 80°C (175°F): Model K
Longer cables to specied lengths
Smaller switching differentials down to 1.25 in.
Greater switching differentials to 75 in. (S series) or 60 in. (M series)
Alternative logic at switching points (normally open vs. normally closed)
Alternative cables in rubber and urethane
Alternative cables in teon (max. 5 conductors = 4 or less switch points)
Lead weight in place of polypropylene-covered weight
Strain Relief Connector, Part #SRCG
• Chemical Compatibility — Corrosion Resistance of Materials
With a standard KA oat switch, the only materials in contact with the liquid are the polypropylene covered oat and weight, the heavy duty PVC coated cable,
and the polypropylene wedge. Consequently, these switches are unaffected by a wide range of liquids. However, there are some liquids that are not compatible with these materials. For such applications, alternative construction materials are available as indicated in the Options section above. In assessing corrosion, key factors are the liquid’s temperature and concentration, and the amount of
time the oat is immersed. Even if periodic replacement of KA oat switches
is necessary, they still may be the most economical choice. Rubber cables are preferred for applications where freezing conditions can occur, because PVC­coated cables tend to stiffen in such situations.
Automation Products Group, Inc.
6
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • sales@apgsensors.com
