APEX PF2025, PF2425, PF2725, PF3225 User guide

APEX Digital,Inc.

2919 E. Philadelphia Avenue

Ontario, California 91761

FOR SERVICE CALL: 800-4-APEX-INC

Please read this manual carefully before operation.

PF SERIES COLOR TELEVISIONS

INSTRUCTION MANUAL

Standard - PF2025, PF2425, PF2725, PF3225

M

O

C

.

C

N

I

L

A

T

I

G

I

D

X

E

P

A

1

PF Series Instruction Manual

Dear Customer:
Congratulations! You have purchased one of the
finest CoIor TVs on the market!
This manuaI wiIl help you use the many exciting
and usefuI features to make your TV viewing more
enjoyabIe than ever before.
Before operating your TV set, pIease read alI these
safety and operating instructions completely and
then retain for future reference.

Customer's Record
You wiIl find the model number and chassis num­ber on the back of your TV set.
Record these numbers in the spaces provided
beIow.
Refer to them whenever you caII upon your Apex
deaIer regarding this product.
Model Number: PF2425/PF2725/PF3225
Chassis Number: CH-10C2

Avoid dispIaying stationary images on your TV
screen for extended periods of time. Stationary
patterns generated by computer dispIays, video
games, stock market reports, etc. can become
permanentIy engrained on the picture tube. This
damage is not protected by your warranty as it is
the result of misuse. ShouId you wish to use your
Apex TeIevision to dispIay stiIl images, it is aIways
advisabIe to reduce brightness and contrast set­tings. Never Ieave a video game or computer dis­play unattended.

NOTE TO CABLE INSTALLER lN THE USA:
This reminder is provided to caIl your attention to
ArticIe 820 - 40 of the NEC that provides guide­Iines for proper grounding and, in particular,
specifies that the cable ground shaII be connect­ed to the grounding system of the building, as
cIose to the point of cable entry as practicaI.

BEFORE OPERATION

Safety Precautions

WARNING:
TO REDUCE THE RISK OF FlRE OR ELECTRlC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAlN OR MOISTURE.

CAUTION : TO REDUCE THE RISK OF ELEC­TRIC SHOCK, DO NOT REMOVE COVER(OR
BACK). NO USER SERVICEABLE PARTS lN­SlDE. REFER SERVlClNG TO QUALlFIED
SERVlCE PERSONNEL.

The Iightning symboI in the triangIe tells
you that the voltage inside this product
may be strong enough to cause an
eIectric shock.

The excIamation point in the triangIe tells
you that important operating and mainte­nance instructions foIlow this symboI.DO

CAUTIONS:

TO PREVENT ELECTRIC SHOCK, DO NOT USE
THlS POLARlZED PLUG WlTH AN EXTENSION
CORD RECEPTACLE OR OTHER OUTLET UN­LESS THE PRONGS CAN BE FULLY INSERTED
INTO THE OUTLET TO PREVENTANY EXPOSURE
OF THE PRONGS ON THE POLARIZED PLUG.

NOT TRY TO SERVlCE THlS
PRODUCT YOURSELF.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

2

Standard - PF2025, PF2425, PF2725, PF3225

BEFORE OPERATiON (continued)

CAUTION

PLEASE READ THESE INSTRUCTIONS, KEEP THESE INSTRUCTIONS AND HEED ALL WARNINGS. FOLLOW ALL INSTRUCTIONS.

Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to assure your personal safety. However
improper use can result in potential electrical shock or fire hazards. In order not to defeat the safe guards incorporated in this TV set, observe the follow­ing basic rules for antenna/ TV installation, use and servicing. All operating and use instructions should be followed.
Do not remove the cabinet cover. This may expose you to dangerous voltages. Refer all servicing to qualified service personnel.

Important Safety Instructions

Power Sources - The TV set should be operated only from the type of power source indicated on the TV set or as indicated in the Operation Manual.
If you are not sure of the type of power supply in your home, consult your local power company. For TV sets designed to operate from battery power, or
other sources, refer to the operating instructions.

Alternate Warnings - This plug will only fit into a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet, contact your electrician to have a suitable outlet installed. Do not defeat the safety purpose of the ground­ing plug.

Water and Moisture Warnings - Do not use the TV set near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet base­ment; or near a swimming pool; and the like. The TV set should not be exposed to dripping or splashing and no objects filled with liquids, such as vases,
should be placed on the TV set.

Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV set and to protect it from overheat­ing, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV set on a bed, sofa, rug,or other simi­lar surface. This TV set should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufactur­er's instructions have been adhered to.

Grounding or Polarization - Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. Agrounding - type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Heat - Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

Aproduct and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the TV set and cart combi­nation to overturn.

Accessories - Do not place the TV set on an unstable cart, stand, tripod, bracket, or table. The TV set may fall, causing serious injury to a child or adult,
and serious damage to the TV set. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or accessory recommended
by the manufacturer, or sold with the TV set, and should use a mounting accessory recommended by the manufacturer.

Power-Cord Protection - Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where
they exit from the TV.

Overloading - Do not overload wall outlets, extension cords or integral convenience receptacles as this can result in fire or electric shock.

Cleaning - Unplug the TV set from the wall outlet before cleaning or polishing it. Do not use liquid cleaners or aerosol cleaners. Use a dry cloth for

cleaning the exterior of the TV set.

Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards or electric shock.

If a snapping or popping sound from a TV set is heard continuously or frequently while the TV set is operated, unplug the TV set and consult your dealer
or service technician. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being turned on or off.

Lightning - For added protection for this TV set during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

Object and Liquid Entry - Never push objects of any kind into the TV set through openings as they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV set.

Precautions

Damage Requiring Service - Unplug the TV set from the wall outlet and refer servicing to qualified se rvice personnel

under the following conditions:

a. lf the power cord or plug is damaged or frayed.
b. lf liquid has been spilled or objects have fallen into the TV set.
c. lf the TV set has been exposed to rain or water.
d. If the TV set has been subject to excessive shock by being dropped, or the cabinet has been damaged.
e. If the TV set does not operate normally by following the operating instructions. Adjust only those

controls that are covered by the operating instructions as an improper adjustment of other controls may result in dam­age and will often require extensive work by a qualified technician to restore the TV set to its normal operation.

f. When the TV set exhibits a distinct change in performan ce-this indicates a need for service.

Servicing - Do not attempt to service the TV set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.

BEFORE OPERATiON (continued)

Precautions (continued)

ANTENNA

Outdoor Antenna Grounding- If an outdoor antenna is
installed, follow the precautions below.
An outdoor antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can come in contact with such
power lines or circuits.
WHEN INSTALLNG AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL
Be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static
charges. Section 810 of the National Electrical Code in
USA and Section 54 of the Canadian Electrical
Code(ANSl/NFPA 70) in Canada provides information with
respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna dis­charge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding elec­trodes, and requirements for the grounding electrode.

Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original parts. Unauthorized substitutions may
result in fire, electric shock, or other hazards.

Safety Check - Upon completion of any service or repairs to the TV set, ask the service technician to perform routine safety
checks to determine that the TV set is in proper operating condition.

Disposal - When the TV set reaches the end of its useful life, improper disposal could result in a picture tube implosion.
Ask a qualified service technician to dispose of the TV set.

Example of antenna grounding according

to National Electrical Code (NEC )

3

PF Series Instruction Manual

4

PF Series Instruction Manual

BEFORE OPERATlON (continued)

FCC Warning

Class B Computing Device

Information to User

This equipment has been tested and found to compIy with the Iimits for a class B digitaI device pursuant to
part 15 of FCC Rules. These limits are designed to provide reasonabIe protection against harmful interfer­ence in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not instalIed and used in accordance with the instructions, may cause harmfuI interference to radio
communications. However, there is no guarantee that interference wiIl not occur in a particuIar instaIlation. lf
this equipment off and on, the user is encouraged to try to correct the interference by one or more of the
foIIowing measures:

1 ) Reorient or reIocate the receiving antenna.

2) lncrease the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is con­nected.

4) ConsuIt the deaIer or an experienced radio/TV technician for help and for additionaI suggestions.

The user may find the foIlowing booklet prepared by the FederaI Communications Commission helpfuI: How
to ldentify and ResoIve Radio -TV Interference Problems”. This bookIet is available from the US Government
Printing Office. Washington, D. C 20402, Stock No. 004-000-00345-4.

FCC Warning

The user is cautioned that changes or modifications not expressly approved by the manufacturer could void
the user's authority to operate the equipment.

NOTE: ln order for an installation of the product to maintain compIiance with the Iimits for a CIass B device.

shielded cables must be used.

5

PF Series Instruction Manual

CONTENTS

lNTRODUCTlON

Features....................................................................................................................................................9

ControI Buttons........................................................................................................................................10

Menus......................................................................................................................................................12

INSTALLATION

To Connect the Antenna...........................................................................................................................13

Remote Batteries......................................................................................................................................13

To Connect ExternaI Equipment..............................................................................................................14

BASlC FUNCTlONS

Power On/Off............................................................................................................................................15

On - Screen DispIay.......................................................................... .......................................................15

Tuning in...................................................................................................................................................16

Function SeIection....................................................................................................................................17

GeneraI Operation................................................................................................................................... 20

Picture Improvement................................................................................................................................ 22

Sound Improvement................................................................................................................................. 23

ADDlTlONAL FEATURES

Time Setting............................................................................................................................................. 24

ChildIock...................................................................................................................................................24

Programming the Remote Control............................................................................................................25

SPEClFICATIONS......................................................................................................................................... 30

TROUBLESHOOTlNG GUIDE...................................................................................................................... 31

LIMITED UNITED STATES WARRANTY...................................................................................................... 32

Note:

The OSD and illustration in this manuaI may be somewhat different from the actual situation. PIease take
the TV as the standard.

6

PF Series Instruction Manual

FeaturesINTRODUCTION

Features

True FIat Picture Tube
English/French/Spanish Menus

The unique English/French/Spanish menu control function makes the operation more easily.

181 Channel Tuner

2-69 channels in the Air mode and 1-125 channels in the Cable mode can be preset (of which 2-13

channels in the Air and Cable modes are the same.)

On/Off Timer

The TV automatically turns off and on and tunes to the desired channel at the time when programmed.

Auto Off

Under no signal condition, the TV will turn off in15 min.

Childlock Function

Prevents children from watching TV for a long period of time. Especially when parents are out .

ChanneI Scan

DispIays alI channeIs set in the Add mode.

Parental Control

Prevents children from watching programs not suitable for them.

Blue/BIack LeveI Extension

The bIue level extension circuit guarantees more reaI and natural white area; the black Ievel extension

circuit enhances the picture gradation.

CCD /Text Function

If they are included in a program, you can view closed captions or text information.

AV/S - VIDEO/DVD TerminaIs for ExternaI Equipment Connection
Quick SeIectabIe Picture/Sound Modes

AIIows one - touch seIection of your favorite picture and sound quality among three picture modes and four

sound modes.

DigitaI Geometric Correction

The TV adopts digitaI geometric correction with no mechanic adjustment, which offers the TV reIiablity.

Auto Dark BaIance Adjustment

It is unnecessary to do any adjustment for the TV's dark baIance. ReaI time adjustment done by corre­sponding dark - balance & auto - track circuit can avoid poor dark - balance resulted from components
aging.

DigitaI Auto White Balance Adjustment

Computer controI - more efficient and more reIiable.

MTS Stereo/Video Stereo

UniversaI Remote ControI

Program your remote controI to operate your connected cabIe box, VCR, digital sateIIite receiver, power
ampIifier, or DVD pIayer.

AVC - Auto Volume Correction
VM - Velocity ModuIation

7

PF Series Instruction Manual

Control Buttons

INTRODUCTION (continued)

Front panel

See the right figure.

ANTENNA IN

POWER INDICATOR

MAIN POWER SWITCH
INFRARED SENSOR

Side-set AV IN(4)

VIDEO

See the right figure.

MENU - VOL + - CH +

Note:

The buttons on the TV set share the same functions with those buttons of the same name on the remote
controI. The foIlowing section of this manuaI wiIl focus on operation of the remote controI.

Rear panel

8

PF Series Instruction Manual

INTRODUCTION (continued)

Control Buttons

Remote control

The buttons marked with shades don't function for the TV set.

STANDBY

Channel Number

VOLUME DOWN

RECALL

CCD/TEXT

CHANNEL SCAN

PICTURE MODE SELECT

SOUND MODE SELECT

INDICATOR
ASSIST OPERATION

THREE-DIGIT SELECT

TV/VIDEO SELECT
CHANNEL UP

VOLUME UP

ON-SCREEN DISPLAY
CHANNEL DOWN

TIME SETTING
STEREO

MUTE

MENU SELECT

Notes:

1 When in operation, please point your remote control directly to the infrared sensor.
2 Do not expose the remote control to impacts,water or disassemble it.
3 Do not repeatedly press the buttons on the remote control. Allow interval of no less than one second

between selections.

(continued)

9

PF Series Instruction Manual

After selecting a sub- menu, press the / buttons to highlight the desired item and press the /
buttons to adjust.
MENU display except “ Tuner” disappears 6 seconds after last selection.

Notes:

1 After calling up the sub menu, pressing the MENU button can return to the primary menu dispIay.
2 The adjustabIe Tint range in the Picture menu and BaIance range in the Audio menu are - 31 ~ +31

and L31 ~ R31 respectiveIy whiIe the other adjustments are 0 ~63.

3 When the Tuner menu is recalled, the display will not disappear automatically. Press the DISPLAY

button to cancel menu display.

CaII up a sub - menu in the same way mentioned above, then press the / buttons to highlight an adjust­ment and the / buttons to adjust the seIection. ln the foIIowing function introductions, the operations are
simiIar to the above ways unIess otherwise noted.

INTRODUCTION (continued)

Press the MENU button , and the TV will display the primary menu as follows:

Menu
Audio
Tuner
Timer
System

To adjust a function, press the / buttons to highlight the selection, and press the / buttons to select
a sub-menu. (Take English menus for example).

Tint
Brightness
Contrast
Color
Sharp

00
32
32
32
32


Menus

Language
Blue Back
CCD/Text
Parental Guide

MPAA - R

TV - Y7

System

Time
On Time
Cn Channel
Off Time

Timer

Bass
Treble
Balance
Surround Low
AVC Off
MTS Mono

31
31
00

Audio

Channel
Add/Erase
Antenna
Auto Program

Stop Start

2
Add
Ai r

Tuner

Eng. Fra. Esp.

On
Off
On

10

PF Series Instruction Manual

INSTALLATION

Please read the safety instructions in this manual completely before installation.
Install your TV in a room where direct sunlight will not fall upon the screen.
Allow enough space (at least 10cm) between the TV and the wall for proper ventilation.
It is recommended to watch TV in soft and indirect light. The optimum watching distance is 5-7 times of the
screen's vertical length.

Auto-degaussing

Color TV is easily affected by magnetism which leads to color distortion. If your TV is moved or affected by near
magnetic components or appliances with power on, turn it off for 1 hour. The built-in auto-degaussing circuit
will eliminate the magnetism interference.

An outdoor antenna or CATV is recommended for the best reception.

75-ohm coaxial cable

300-ohm twin-lead cable

OR

OR Antenna adapter

(not supplied)

U/V mixer
(not supplied)

Notes:

1 It is recommended that a 75 coaxial cable be used in order to eliminate possible interference and

noise which may occur due to nearby radio transmissions.
2 The antenna cable should not be tied together with other wiring.
3 Set up a lightning arrester and check it regularly when an outdoor antenna is used.

1.Remove the battery compartment lid.

2.Place in two AAAbatteries. Make sure the positive + and
negative - polarities are correct.

3.Reattach the battery lid.

Notes:

1 Alkaline batteries are recommended for longer life. Always

replace both batteries with fresh ones of the same type.
2 Do not expose batteries to fire or disassemble them.
3 To avoid battery leakage, remove batteries from the remote

control when it is not to be used for a long period of time

or the batteries are exhausted.

Remote Batteries

VHF
UFH
or Cable

VHF

UHF

To Connect the Antenna

11

PF Series Instruction Manual

INSTALLATION (continued)

To Connect External Equipment

The following are optional connections. Please refer to operation manuals of external audio/video equipment that will be con­nected to your set.

Connect VCR' s or DVD player' s RF OUT terminal to the AN­TENNA IN jack located on the rear panel.

Coaxial Cable

VCR with Modulator

AUDIO/VIDEO OUT

DVD Player

AUDIO

VIDEO

With S-VIDEO Terminal

AUDIO

YCbC

r

Yellow

White

Red

Yellow

White

Red

AUDIO

VIDEO

Yellow

White

Red

Yellow

White

Red

Camcorder

VCR

VCR

AUDIO/VIDEO IN

AV IN

MONITOR OUT

Front-set AV IN(4)

ANTENNA IN

Notes:

1 Before connection, do power off your TV and external equipment.
2 To receive signaIs from externaI equipment, you must seIect a proper AV input.
3 Do not use S - VIDEO and AV IN(1) terminals at the same time.

12

PF Series Instruction Manual

BASIC FUNCTIONS

Power On/Off

1. Power on

1) When in the Power On mode, press the button on the remote controI to enter the Standby mode. At
this time, the power indicator lights. (Part of circuit on the TV set remains active when the TV in the
Standby mode. )

2) In the Standby mode, pressing any of the , CH - / + buttons on the remote controI can enter the
Power On mode.

3) When in the Power On or Standby mode, press the MAIN POWER SWlTCH button to power off the TV.

Note:

Avoid switching the TV on and off frequently. Doing so may shorten life span of internal components.

Auto off when no signal received

When a channeI has no signaI (e. g. the TV station fails to send signals) and if no button is pressed within
15 minutes, the TV wiIl automatically enter the Standby mode. ln the Video mode, this function doesn' t
work.

Press the DISPLAY button repeatedty in the TV or Video mode to dispIay the current mode on the screen
and turn off the display respectively.

Press the DISPLAY button first and the TV screen is dispIayed as folIows.

Note:

With other OSD, pressing the DISPLAY button first can turn it off.

On - Screen Display

Video1

In the Video mode

Input: Stereo

2

Air

In the TV mode

MTS: Stereo/SAP

13

PF Series Instruction Manual

This section gives descriptions about adjustment of items in the Tuner menu.

1.Auto program

1)Press the / buttons to highlight

“ Auto Program”.

BASIC FUNCTIONS (continued)

Tuning in

Stop Start

Channel
Add/Erase
Antenna
Auto Program

2
Add
Ai r

Tuner

2)Press the button, and the TV will search automatically in sequence. After auto search, the TV will store
receivable channels and return to the lowest channel number.
During auto program, press the button to stop searching.

Notes:

1 After auto program, there may be some repeated channels or inferior signal received. In thes case,

press any of the / , Channel Number buttons to select one of the channels. Then set Add/
Erase to Erase so that pressing the CH - / + buttons can not caII up the channeIs. To resume the
channeIs, set Add/Erase to Add in the way mentioned above.

2 When Antenna is set to the Air mode, the TV wiII auto search from channel number 2 to 69; when set to

the Cable mode, it wilI auto search from 1 to 125 (of which 2 -13 channeIs in the Air and CabIe modes
are the same.)

2.Channel selection

Press the / buttons to highlight “ Channel” in the Tuner menu, and press any of the / ,
Channel Number buttons to select channel numbers.

3.Add/Erase selection

Press the / buttons to highlight “ Add / Erase”, and press the / buttons to select “ Add ” or

“ Erase” cyclically.

14

PF Series Instruction Manual

BASIC FUNCTIONS (continued)

Function SelectionMenus

1.Language selection

1)Press the / ¸ buttons to highlight “ Language ”.

2)Press the / buttons to select a desired language display (English/French/Spanish).

2.Blue screen display

When there is no signal received with Blue Back On, the TV will display a soft blue backgrund on the
screen.

1)Press the / buttons to highlight”Blue Back”.

2)Press the / buttons and set Blue Back to On.

Notes:

1 The Blue Back function is inactive during search.
2 If Blue Back is set to Off, noise dots will be displayed on the screen when no signal is present in the TV

mode. Blue Back is not available when no signal is present in the Video mode.

3.Closed caption function

When available in a program, you can view closed captions or text information.

1)Press the / buttons to highlight ”Closed Caption”.

When you select the Closed - Caption (CC1-CC4) mode, the TV can decode CCD signal, and display it
on the screen , which is especially helpful for hearing impaired individuals.
Closed caption provides an on-screen display of the dialogue, narration, and / or sound effects of a TV
program.

2)Press the / buttons ( - VOL + buttons on the TV) to select one of the 9 modes
Closed Captions (CC1 - CC4) Text Mode ( T1 - T4 )

CCD/Text Off

System

Language
Blue Back
Closed Caption
Parental Guide

MPAA- X

TV - MA

Eng. Fra. Esp.

On
CC1
On

System

Language
Blue Back
Closed Caption
Parental Guide

MPAA- X

TV - MA

Eng. Fra. Esp.

On
CC1
On

System

Language
Blue Back
Closed Caption
Parental Guide

MPAA- X

TV - MA

Eng. Fra. Esp.

On
CC1
On

15

PF Series Instruction Manual

BASIC FUNCTIONS (continued)

(continued)

Function Selection

Captions will appear at either the top or bottom of the screen while a captioned broadcast is received.
When you select the Text (T1-T4) mode, the TV can receive teletext signal.
When you select “CCD/Text Off ”, the CCD / Text function is off.

3)Press the CC button to turn on/off the CCD/Text mode.

Notes:

A CCD signal may not be decoded in the following conditions:

When a video tape has been dubbed.
When the signal reception is weak.
When the signal has been changed or altered.

With signal received without Closed Captions or Text, closed captions or text characters do not appear

on the screen.

4. Parental Control

You may prevent children from watching programs not suitable for them, such as sexual or violence prog­rams.
Press the / ¸ buttons to highlight

“Parental Guide

”(provided it has been preset).

Language
Blue Back
CCD/Text
Parental Guide

TV-Y U
TV-Y7 U U
TV-G U
TV-PG U U U U U
TV-14 B B B B B
TV-MA B B B

Age Based Rating

Rating

FV D L S V

TV-Rating

System

MPAA-X TV-MA

Enter Pass Code - - - -

Eng. Fra. Esp.

On
Off
On

Use the Channel Number buttons to enter the initial pass code 6688, then press the button again to
proceed to the next menu display.

The TV ratings are divided into two groups: age - based and content - based.

Age Defined as
TV - Y All Children
TV - Y7 Directed to Older Children
TV - G General Audience
TV - PG Parental Guidance Suggested
TV - 14 Parents Strongly Cautioned
TV - MA Mature Audience Only

Contents Defined as
FV Fantasy Violence
D Sexually Suggestive Dialogue
L Adult Language
S Sexual Situations
V Violence

TV-Y U
TV-Y7 U U
TV-G U
TV-PG U U U U U
TV-14 B B B B B
TV-MA B B B

Fantasy Violence

Rating

FV D L S V

TV-Rating

16

PF Series Instruction Manual

Press the / buttons to highlight one of the items TV-Y, TV-Y7, TV-G, TV-PG, TV-14, TV-MA,
Rating, FV, D, L, S, V. Press the MENU button to display “U” or “ B ” on the screen. A“U”indicates a
rating which is unblocked and a “ B ” indicates a rating which is blocked.

Press the button to move the cursor from “ Pass Code Menu ”,“ MPAA Rating ”, “TV-Rating” to
“System”, and select “ Parental Guide Off ” to stop circulation.
The following is the MPAA-Rating menu.

After caIIing up the Pass Code Menu first, press the / buttons to highIight “Pass Code 6688”, and then

“Enter Pass Code - - - - ”appears on the screen. Press the ChanneI Number buttons to enter new

pass code which you need enter when caIIing up the ParentaI Guide Menu.

Notes:

1 Only when the set pass code appears on the screen before the menu display is turned off, does the TV

remind you of entering the pass code when you caII up the Parental Guide Menu again.

2 If you forget the new pass code when turning on the ParentaI Guide Menu display, you may enter the

initial pass code 6688.

3 lf you wouldn' t like to set any pass code, press the / buttons to highIight Pass “Code ControI”

and MENU button to turn off the pass code setting display.

Press the button repeatedly to recall the Pass Code menu as follows.

TV - Rating MPAA Rating
System Pass Code Menu

BASIC FUNCTIONS (continued)

(continued)

Function Selection

Moving Rating

MPAA - Rating

G U
PG U
PG - 13 U
R U
NC - 17 B
X B

Pass Code Menu

Pass Code Setting

Pass Code Control
Pass Code 6688

Age Based Rating

Enter Pass Code - - - -

Pass Code Menu

Pass Code Control

Press Menu Key

17

PF Series Instruction Manual

BASIC FUNCTIONS (continued)

General Operation

2.To select a channel

1.To control volume

Press the - VOL + buttons to decrease or increase the vol­ume.

Volume 20

Mute

the CH button - Press the CH + button

While adjusting volume, press the F and - VOL + buttons at the
same time and the volume decreases or increases by 4 levels.

During normal play, press the MUTE button to eliminate the
sound until you press the VOL + or MUTE button again.

Press the CH + button to choose higher-num­bered channels and the -CH button to choose
lower-numbered channels. For example, if the
current channel number is 7 (Provided that
Channel 6,8 are set to Add).

Using the Channel Number buttons

To select a one -digit channel number
Press the 0 button, then press another Channel Number but­ton (except 100+) to select a desired number.

To select a two -digit channel number
Enter a first-digit, then second-digit.

To select channel number between 100 and 125 in the
Cable mode
Press the 100+ button so that “1_ _ ” appear on the screen,
then enter the next digit one and two.

Press the RECALL button and the TV will directly skip back to
the previous channel. For example, you are watching Channel
3 and previously you watched Channel 15.If you press the
RECALL button, the channel number will skip directly from
Channel 3 to Channel 15. Press the RECALL button repeat­edly to change between these two channels.

Note:

In the Video mode, pressing the RECALL button can return
to the TV mode.

6

0

1 18

12

1

15

124

9

78

3

18

PF Series Instruction Manual

BASIC FUNCTIONS (continued)

General Operation (continued)

1 Press the SCAN button so that “ Scan Off ” appear on the screen.

4)
SCAN

Note:

2 Press the SCAN button again so that “Scan On ”appear on the

screen and the TV begins to scan from the current channel.

During scanning, pressing any button can interrupt scanning.

3. CCD/Text switch

4. TV/Video selection

Press the CC button to display the current Closed Captions/Text mode on the screen.Press
the button again to display “CCD/Text Off” on the screen

Notes:

1 Vldeo4is side - set AV lN (4 ) terminals.
2 ln the DVD mode, no “ Tint ” appears in the Picture menu.

5. Stereo seIection

In the TV mode, the TV can automaticatly identify MTS stereo modes among Mono, Stereo,
Stereo/SAP and Mono/SAP.
Press the STEREO button firstIy to dispIay the auto - identified MTS mode on the screen. Press

the button again before the OSD disappears to shift to other MTS mode as follows.
With Stereo signaI received, you may select one of the Stereo and Mono modes cyclically.
With Mono/SAP signal received, you may seIect one of the Mono and SAP modes cyclically.
With Stereo/SAP signal received, you may seIect one of the Stereo, SAP and Mono modes cyclically.
With Mono signal received, only Mono mode can be avaiIable.

When receiving signaIs from externaI equipment in the Video mode, the TV identifies automatically external
signals to Stereo. Press the STEREO button to set lnput to Stereo, L or R.L or R. Stereo input modes change as
follows.(Set Surround to Off.)

Note:

Press the STEREO
button repeatedIy
to switch the TV
among the MTS
modes quickly.

CC

VIDEO

STEREO

Scan On

Press the VIDEO button, and the screen display changes in circular way:

Channel Number Video1(S-VHS1) Video2 Video3(S-VHS3)

To receive signaIs from external equipment, pIease be sure to select a corresponding Video mode.

Input Mode Left Channel Out Right Channel Out

Terminals to Be Connected

Left Right

Stereo

L
R

Stereo

L
R

Stereo

L
R

Audio L
Audio L
Audio R
Audio L
Audio L

Audio L
No sound
No sound

Audio R

Audio R
Audio L
Audio R
Audio L
Audio L
Audio L
Audio R

No sound

Audio R

19

PF Series Instruction Manual

BASIC FUNCTIONS (continued)

Picture Improvement

1.To seIect picture modes


2. To set desired picture quality

Press the PICTURE button repeatedly to seIect one of the Normal, Memory and Theater
modes.

NormaI Memory Theater

Refer to the foIIowing introduction about each mode.

Mode Picture Quality
Normal Standard mode, suitable for watching ordinary program.
Memory Picture quality users set.
Theater Movie-like picture setting, suitable for viewing some movie programs.

1) Call up the Picture menu and the TV screen is displayed as follows.

2) Press the / buttons to choose an adjustment.

3) Press the / buttons to adjust the digitaI leveI of the selected adjustment as desired.
The adjusted Ievel is stored in the MEMORY position and remains unchanged until next adjustment.

Tint
Brightness
Contrast
Color
Sharp


00
32
32
32
32

Item

Picture Quality

Press

button
Purplish
Darker
Lower
Paler
Softer

Tint
Brightness
Contrast
Color
Sharp

button
Greenish
Brighter
Higher
Deeper
Sharper

20

PF Series Instruction Manual

BASIC FUNCTIONS (continued)

Sound Improvement

1. To seIect sound modes

2. To set desired sound quaIity

SOUND

Press the SOUND button repeatedIy to seIect one of the Speeh, Music, Theater and
Memory modes.

Speech Music Theater Memory

Refer to the foIIowing introduction about each mode.

Mode Sound Quality

Speech Language clarity improvement, suitable for program focusing on dialogue

Music Suitable for enjoying music programs

Theater

Memory

1) Call up the Audio menu.

2) Press the / buttons to select an adjustment.

3) Press the / buttons to adjust the digital Ievel of the seIected item as desired.

The adjusted Ievel is stored in the Memory position and remains unchanged untiI next adjustment.

programs of entertaninment
Sound quality users set

Movie-like sound setting, suitable for enjoying dynamic sound, such as

Bass
Treble
Balance
Surround Low
AVC Off
MTS Mono

31
31
30

Audio

Sound Quality

Press

button

Weaker Stronger

Stronger

Weaker

Decrease the right volume Decrease the left volume

Off, Low, High

Off, On

Refer to “Stereo selection”.

button

Bass
Treble
Balance
Surround
AVC
MTS

ltem

21

PF Series Instruction Manual

ADDITIONAL FEATURES

Time Setting

Childlock

In the Standby or Power On mode, the TV can automatically complete some functions such as power -on,
channel preset and power-off as desired.
1 . Press the TIMER button to turn on the Timer menu display as shown right.
2 . Press the / buttons to select an adjustment.
3 . Press the / buttons to adjust the selection.

For example, now it is 6:00PM, you have set On Time, On Channel and Off

Time to 7:00PM, 22 and 8:00PM respectively. The TV will automatically per-

form the above settings in the Standby or Power On mode.

Notes:

1 Only after setting

“Time”, can you set other items.

The CHlLDLOCK function prevents chiIdren from watching TV.
HoId down the F button and then press the MUTE button until the symboI “ ”
appears on the screen, and the TV enters the CHlLDLOCK mode.
Except for the symboI“ ”, the screen becomes blue back and mutes when
you press the buton to turn the TV off, then turn the TV on after setting the
CHILDLOCK function. To unlock the TV, hoId down the F button and then press
the MUTE button again.

Note:

The CHlLDLOCK can be set or cancelIed only by the remote controI. After setting CHlLDLOCK, secure

the remote control in a safe place.

Timer
Time

On Time
On Channel
Off Time

Timer
Time

On Time
On Channel
Off Time

6:00PM
7:00PM

22

8:00PM

22

PF Series Instruction Manual

ADDITIONAL FEATURES

Remote - controIIer switchover

Press the TV, VCR/DVD, SAT/CAB or AUX button to seIect the device you want to controI.

To program the remote controller

Press and hoId the TV, VCR/DVD, SAT/CAB or AUX button for over 2 seconds until the lNDlCATOR on the
remote controIler turns off (the remote controIIer enters the PROGRAMMlNG mode).
Use the 0 - 9 buttons to enter three - digit code number for your equipment. lf the correct code number is
entered, the INDICATOR bIinks three times. If you enter a code not listed beIow, or you press any other
buttons than SEARCH and 100 +, the lNDICATOR turns off.

To search codes

Press and hoId the TV, VCR/DVD, SAT/CAB or AUX button for over 2 seconds until the INDICATOR turns
off. ReIease the button (the INDICATOR wiII light again) and the remote controIIer enters the PROGRAM­MING mode.

Press the SEARCH button.
Press the - CH + buttons to search codes downwards or upwards. Each time you press the - CH + but­tons, the code number decreases or increases by 1 whiIe the remote controIler sends the code number for
POWER button on your device.

lf the desired code number is found, press the 100 + button to program the code for your device until the
lNDICATOR bIinks three times. Then the remote controIler exits from the PROGRAMMING mode and returns
to normal operation. Or press any other button to exit from the PROGRAMMING mode after the INDICATOR
bIinks rapidly eight times, and the operation is not active.

To check the current code number

Press and hold the TV, VCR/DVD, SAT/CAB or AUX button for over 2 seconds until the lNDlCATOR turns
off. ReIease the button (the INDlCATOR wiII Iight again) and the remote controller enters the PROGRAM­MlNG mode.

Press the 100 + button.

You may read the code number according to the INDICATOR display status as foIlows.

Notes: If there is no operation within 20 seconds during the steps mentioned above, the remote controIler

will automaticalIy exit from the appropriate operation.
If only your TV does not respond to the remote control, try 000 for your TV. If the batteries are weak
or exhausted, the remote control can' t function,either.

Programming the Remote Controller

Code Number

First-digit

0
1

1
0

0
0

5
4

0
6

0
3

Second-digit

Third-digit

INDICATOR Display Status

(2 sec.time interval between every two digits.)

Blinks rapidly once
Blinks once
Blinks once
Blinks rapidly once

First-digit Second-digit

Blinks rapidly once
Blinks rapidly once
Blinks five times
Blinks four times

Third-digit

Blinks rapidly once
Blinks six times
Blinks rapidly once
Blinks three times

23

PF Series Instruction Manual

ADDITIONAL FEATURES

Programming the Remote Controller (continued)

DVD codes

LD codes

Brand

APEX

ChangHong

Aiwa

Hitachi

JVC

Magnvox

Mitsubishi

Panasonic

Philips

Pioneer

Proscan

RCA

Sanyo

Sony

Toshiba

300,382

300,301,302,303

312

313

309,314

308

307

315

308,316,317,318

306,311

310

310

319

305,320,321

304

Code Number

Code Number

Brand

322

326,327

328

323,324,325

Magnavox

Panasonic

Pioneer

Sony

24

PF Series Instruction Manual

Dynatech
Electrohome
Electrophonic
Emerson
Fisher
Funai
GE
Go Video
Goldstar
Goodmans
Gradiente
Grundig
Harley Davidson
Harman Kardon
Hinari
Hitachi
Instant Replay
JC Penney
Jensen
JVC
Kenwood
Kodak
Lloyd
Logik
LXI
Magnavox
Marantz
Marta
MEI
Memorex
MGA
Minolta
Mitsubishi
Motorola

Brand

Admiral
Aiwa
Akai
Amstrad
ASA
Audio Dynamics
Audiovox
Broksonic
Bush
Calix
Candle
Canon
capeheart
Carver
CCE
Citizen
Craig
Curtis Mathes
Daewoo
Daytron
DBX

Code Number

373
340
350,379
340
357
334,374
376
375,377
339
376
336,376
361,362
349
343
379
336,337,376,379
331,337,376
332,336,361,372
349,363,377,379,380
349
334,374

Brand
MTC
Mutitech
NEC
Nikko
Olympus
Optimus
Optonica
Panasonic
Pentax
Perdio
Philco
Philips
Pilot
Pioneer
Portland
Proscan
Quasar
Radio Shack
Radix
Randex
RCA
Realistic
Ricoh
Salora
Samsung
Sanky
Sansui
Sanyo
SBR
Schneider
Scott
Sears
Sharp
Shintom
Sony
STS
Sylvania
Symphonic
Tandy
Tashiko
Tatung
Teac
Technics
Tekknika
Toshiba
Totevision
Vector Research
Victor
Videosonic
Video Concepts
Wards
XR-1000
Yamaha
Zenith

Code Number
340,378
337,339,340,378
333,334,336,350,352,358,364,374
376
383
373,376
346
335,348,361,365,366
336,342,347
340
343,346,357,361
343,346,357,361
376
334,342,352,358,374
349
332,372
354,355,361
329,330,331,341,346,373,376,378,381
376
376
332,337,342,347,365,372
340,341,346,361,373,376,378,381
369
356
337,363
373
334,350,352,353
331
357
339
338,345,375,377
329,331,341,342,347,351,376

330.346,381
339
367,368,369,370,371
347
340,343,344,345,356,361,378
340,378
340
340,376
333,350,353
333,340,350,378
348,361
340,361,376,378
338,341,342,345,356,363
337,376
334,364
334,358
337
334

378
333,334,336,350,364
370,371

330,331,337,338,339,340,342,
346,347,361,373,376,378,381

340
330,376,381
376
330,338,340,345,375,376,377,381
329,331,340,341,351
377
332,337,361,372
359,360
336,376,379
339
378
357
378
364
339
340,342,347,350
385
333,334,337,347,350,361,364,374,376
342,350
333,334,336,350,352,358,374
333,334,336,350,352,358,374
376
340,378
339
376
343,344,357,361
333,334,336,343,357,361,374
376
361
331,340,361,373,376,378
330,345,356,381
342,347
330,342,345,352,356,358,381
373

VCR codes

25

PF Series Instruction Manual

ADDITIONAL FEATURES (continued)

Programming the Remote Controller (continued)

CABLE codes

SAT codes

AMP codes

Brand

ChangHong
ABC
General Instrument
hamiln
Hytex
Jerrold
Movie Time
NSC
Oak

Code Number

500
508,509,510,511
525
541,542
508
506,510,511,512,513,520,525
515
515
501,508,516
502,507
514
503,504,517
524
504,505,518,519
511
509,512
515
508
514,515
504,521,522,523

Panasonic
Philips
Pioneer
RCA
Scientific Atlantic
StarCom
Tocom
TV86
United Artists
Viewstar
Zenith

Brand

GE
Genernal Electric
Hitachi
Hughes
JVC
Magnavox
Philips
Proscan
RCA
Sony
Toshiba

Code Number

528,531,532
526
534,535
537,538
533
536
536
528,531,532
528,531,532,540
529,539
527,530

Code Number

700,701
702
709
709
706,712
708
704
710
703,704
708
710
707,713
702,705
710
711
706

Brand

ChangHong
Aiwa
Carver
Fisher
JVC
Magnavox
Memorex
Panasonic
Pioneer
Proton
Quasar
RCA
Sony
Techniques
Toshiba
Victor

26

PF Series Instruction Manual

ADDITlONAL FEATURES (continued)

Programming the Remote Conboller (continued)

Operating a VCR Operating a DVD pIayer

Operating a laser disc pIayer

Note:

When operating your non - TV AV equipment with the
remote controller, refer to operation instructions of your
originaI remote.

Power on the laser disc pIayer

Search chapters forward or backwad

Play disc

Stop

Pause

Power on the VCR

SeIect channeIs directly

Change channeIs

PIay video tape

Stop

Search forward or backward

Pause

Record

To

Press

Power on the DVD pIayer

SeIect chapters directly

Search chapters forward or backward

PIay DVD

Stop

Pause

Move the cursor in the menu

Display the DVD menu

Press To Press To

27

PF Series Instruction Manual

SPECIFCATIONS

Model Number

Television system NTSC-M

Channel coverage VHF 2~13/UHF 14~69/CABLE TV: MID BAND(A-8~A-1, A~I)

SUPER BAND(J~W)

HYPER BAND(AA~ZZ, AAA, BBB)

ULTRA BAND(65~94, 100~125)

Channels preset 181

Antenna input 75 (unbalanced)

Pictue tube
Effective screen dimensions 478mm x 363mm 540mm x 405mm 640mm x 478mm
(Approx.) 18.82 x 12.29 in. 21.26 x 15.94 in. 25.20 x 18.82 in.

Max.audio output 5W+5W
Power source ~120Vac 60Hz
Weight(Approx.) 30kg(69 lbs.) 48kg(106 lbs.) 71kg(156 lbs.)

Dimensions(W/H/D) 656 x 511x 492mm 718x 563x 515mm 824 x 653x 600mm
(Approx.) 23.10 x 22.62 x 18.98 in. 26.54 x 25.16x 20.31 in. 32.44x 25.71x 23.62in.

Packing Dimensions 735 x 585x 560mm 841 x 670x 620mm 1005x 843x 700mm
(W/H/D) (Approx.) 28.94 x23.03x 22.05 in. 33.11x 26.38 x 24.41 in. 39.57 x 33.19x27.56in.

Rated power consumption 125W 135W 150W

Designs and specifications are subject to change without notice.

GT2415 GT27125 GT3215

Anyone notice anything wrong
here?! NOT GT. Please Check
and supply with correct info!

28

PF Series Instruction Manual

TROUBLESHOOTING GUIDE

Check the following guide for a possible correction to a problem before contacting customer service.Check
FAQ at our website: www.apexdigitalinc.com.

Symptoms and Correction

Symptoms Correction

No power

No picture

No sound

No TV signal

Stripe or purple interfe­rence appears in the
screen.

Picture with multi-image

Picture becomes
snowy.

No stereo or foreign
language received

TV channel not received

Black box appears on
screen.

Remote control
doesn't operate.

Connect the power plug into the wall outlet securely.

Verify the connection from the DVD/VCR video output to the TV video input is

secure.Then switch TV to the appropriate Video mode.

Verify coaxial cable from antenna is connected to RF IN.

Connect the audio cables into the terminals securely.
Verify the connection from the DVD/VCR audio output to the TV autio input.
Then switch to the appropriate mode on the receiver. Refer to your audio amp­lifier owner's manual.
Mute feature may be enabled.
Make sure MTS feature is properly set.

Check whether your receiver is set to the TV mode.
Check whether the antenna is well connected to the TV receiver.
Unplug the TV from the wall for 30 seconds, then plug in and try again.
Unplug the antenna connection from the back of the TV, unplug the TV from the
wall, wait 30 seconds, then try again.
Interference may come from high frequency sources such as a broadcasting
station, poor ground connection in cable used, or non shielded audio speakers
too close to the picture tube.

Check the antenna lead wire to see if it has open circuit or not.
Check the connection of antenna lead wire to the TV set input.
Check whether there is any damage to antenna.

Change the direction of antenna to minimize the multi image.
The video frequency radiated from TV station can be reflected by tall buildings,
high tower, etc.

Make sure the Air/Cable setting is correct.
Channel may be locked with the block channel feature, such as Parental Control.
Check Add/Erase feature, as channel may have been erased during set up.

Make sure MTS feature is properly set.

Closed Caption to Text feature may be active.

Batteries may be weak. Replace batteries.
Make sure remote sensor is not blocked including deflection from curved glass
cabinet.

29

PF Series Instruction Manual

LIMITED UNITED STATES WARRANTY

PF2425/PF2725/PF3225

Apex DigitaI, Inc. makes the foIlowing Iimited warranties. These Iimited warranties extend to the originaI consumer purchaser or any person
receiving this product as a gift from the originaI consumer purchaser and to no other purchaser or transferee.

Limited Ninety (90) Days Warranty

Apex Digital, Inc. warrants this product and its parts against defects in materiaI or workmanship for a period of ninety (90) days after the
date of original retaiI purchase. During this period Apex DigitaI, Inc. wilI repair or repIace a defective part or product at their option, with a
new or refurbished part or product, without charge to you.° Authorized°±Apex Digital, Inc. Service Center personnel will come to your home
when warranty service is required. Depending on the type of repair required, the service will either be performed in your home or the set will
be taken to the Authorized Apex Digital, Inc. Service Center' s repair facility for repair and then returned to your home at no cost to you.

Limited One (1) Year Warranty

Apex Digital, lnc. further warrants the parts in this product against defects in materiaIs or workmanship for a period of one (1) year
after the date of original retail purchase with exception of the remote control which is guaranteed for ninety (90) days. During this period
Apex Digital,Inc. will replace a defective part with a new or refurbished part without charge to you, except that if a defective part is replaced
after ninety (90) days from the date of original retail purchase, you are responsible to pay all labor charges involved in the part(s) replace­ment including all packing, transportation and insurance charges for the set to and from the Service Center.

Limited Two (2) Years Warranty

Apex Digital, lnc. further warrants the picture tube in this product against defects in materiaIs or workmanship for a period of two (2) years
after the date of original retail purchase. During this period Apex Digital,Inc. will replace the defective picture tube at their option with a new
or rebuilt picture tube or at their option replace the entire product with a new or refurbished product at no charge to you; if however the
defective picture tube or product is replaced after one (1) year from the date of the original retail purchase, you pay all labor, packing and
transportation charges involved in the replacement.

RentaI Product

The warranty for a rental product begins with the original date of receipt by the rentaI firm.

Your ResponsibiIity
The above warranties are subject to the foIIowing conditions:
You must retain your bill of sale to provide proof of purchase.
AII warranty service of this product must be made by an Authorized Apex DigitaI, Inc. Service Center.
These warranties are effective onIy if the product is purchased and operated in the U S. A. , Hawaii and Puerto Rico.
Labor service charges for set instaIlation, setup, adjustment of customer controIs and installation or repair of any type of antenna
or cabIe systems are not covered by this warranty. Reception probIems caused by inadequate antenna or cable system are your
responsibility.
Warranties extend onIy to defects in materials or workmanship as limited above and do not extend to any product or parts which have
been Iost or discarded by you or damage to product or parts caused by misuse, accident, damage caused by Acts of God, such
as Iightning or fluctuations in eIectricaI power, improper instaIlation, improper maintenance or use in vioIation of instructions fur­nished by us; or to product which has been modified or had the seriaI number removed, aItered, defaced or rendered iIlegibIe.
Warranties do not cover cosmetic damages or lost accessories.

How to Obtain Warranty Service

lf after foIlowing aII the operating instructions in this manuaI and reading the section TROUBLESHOOTING you find that service is necessary:

1. Should it be necessary contact our Customer Service Center directly caIl 866 4 APEXlNC (866 427 - 3946 ), Mon - Fri 8am - 5pm
(Pacific Time).

2. After obtaining the requested information, you must present your biIl of saIe to the Authorized Service Center to obtain warranty servlce.

3. Authorized Apex Digital, lnc. Service personnel will come to your home when warranty service is required. Depending on the type of
repair required, the service will either be performed in your home or the set will be taken to the Authorized Service Center's facility for
repair and then returned to your home.

Limitations

AlI warranties implied by state law, including the impIied warranties of merchantability and fitness for a particular purpose, are expressly
limited to the duration of the Iimited warranties as set forth above. With the exception of any warranties impIied by state law as hereby
limited, the foregoing warranty is excIusive and in Iieu of alI other warranties, guarantees, agreements and similar obligations of manufac­turers or seIIer with respect to the repair or repIacement of any parts. ln no event shall Apex Digital, Inc. be IiabIe for consequentiaI or in­cidentaI damages.

No person, agent, distributor, deaIer or company is authorized to change, modify or extend the terms of these warranties in any manner
whatsoever. The time within which action must be commenced to enforce any obligation of Apex Digital, lnc. arising under this warranty or
under any stature, or Iaw of the United States or any state thereof, is hereby Iimited to ninety (90 ) days from the date you discover or shouId
have discovered the defect. This Iimitation does not appIy to impIied warranties arising under state Iaw.

This warranty gives you specific rights and you may aIso have these rights which may vary from state to state. Some states do not aIlow
Iimitation on how long an implied warranty lasts, when an action may be brought, or the excIusion or Iimitation of incidental or consequentiaI
damages, so the above provisions may not appIy to you.

30

PF Series Instruction Manual

Packing List

Parts

Color TV Receiver

K12C-C1 Infrared Remote Control

Operation Manual

AAA Alkaline Batteries

NO. Quantity Remarks

1
2
3
4

1

1

1

2
