Safety precautions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with an arrowhead symbol within an equilateral
triangle is intended to alert the user of the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user of the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
!
the appliance.
CLASS 1
LASER PRODUCT
WARNING: DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE, DUE TO THE HIGH RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT OPEN THE CABINET DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE. ONL YQUALIFIED SERVICE
PERSONNEL SHOULD ATTEMPT THIS.
CAUTION: DURING PLA YBACK, THE DISC SPINS AT HIGH SPEED, SO DO
NOT LIFT OR MOVE THE PLA YER, DOING SO MAYDAMAGE THE DISC.
CAUTION:This Digital Video Disc Player employs a Laser System. Make sure
the device is shut down prior to opening player lid.Visible laser radiation
when open and interlocks defeated.Use of controls or adjustments or
performance of procedures other than those specified herein may result in
hazardous radiation exposure.
!
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1)THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED. INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
1APEX DIGITALMPD-50/100
Safety precautions
DO NOT STAREINTO BEAM.
To ensure proper use of this product, please read this owner’ s manual carefully
and retain for future reference. Should the unit require maintenance, contact an
authorized service location, or contact APEX Digital Inc.Only qualified service
personnel should remove the cover.
FCC NOTICE: This equipment has been tested and found to comply with
the limits for a Class B digital device. Pursuant with the FCC Rules, Part 15.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates,uses and can radiate radio frequency energy
and,if not installed and used in accordance with the instructions,may
cause harmful interference to radio communication,However,this is no
guarantee that interference will not occur in a particular installation.If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,the user is
encouraged to try to correct the interference by one of the following
measures:
FCC Caution:To assure continued compliance,(example-use only
shielded interface cables when connecting to computer or peripheral
devices).Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV techni-
cian for help.
WARNING: Changes or modifications made to this equipment, not
expressly approved by APEX or parties authorized by APEX will void all
manufacture warranties.
2 APEX DIGITAL MPD-50/100
Safety Information
CAUTION: Use of controls or adjustments or performance
of procedures other than those specified herein may
result in hazardous radiation exposure.
Please carefully study this manual and always keep it
available. There are, however, some installation and operation
precautions which you should be aware of.
1.Read Instructions - All the safety and operating instructions
should be read before the product is operated.
2.Retain Instructions - The safety and operating instructions
should be retained for future reference.
3.Heed Warnings - All warnings on the product and in the
operating instructions should be adhered to.
4.Follow Instructions - All operating and use instructions should
be followed.
5.Cleaning - Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6.Attachments - Do not use attachments not recommended by
the product manufacturer as they may cause hazards.
7.Water and Moisture - Do not use this product near water - for
example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.
8.Accessories - Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory
recommended by the manufacturer.
9.A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the product and cart combination to overturn.
3APEX DIGITALMPD-50/100
Safety Information
10.Ventilation - Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not be
blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11.Power Sources - This product should be operated only from
the type of power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your
product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the
operating instructions.
12.Grounding or Polarization - This product may be equipped with
a polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug.
Alternate Warnings - This product is equipped with a three-wire
grounding-type plug, a plug having a third (grounding) pin. This
plug will only fit into a grounding-type power outlet. This is a
safety feature, If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
13.Power-Cord Protection - Power-supply cords should be routed
so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords
at plugs, convenience receptacles, and the point where they exit
from the product.
14.Protective Attachment Plug - The product is equipped with an
4 APEX DIGITAL MPD-50/100
Safety Information
attachment plug having overload protection. This is a safety
feature. See Instruction Manual for replacement or resetting of
protective device. If replacement of the plug is required, be sure
the service technician has used a replacement plug specified by
the manufacturer that has the same overload protection as the
original plug.
15.Outdoor Antenna Grounding - If an outside antenna or cable
system is connected to the product, be sure the antenna or cable
system is grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA 70, provides information with
regard to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size or
grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the
grounding electrode. See Figure 131.1.
16.Lightning - For added protection for this product during a
lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the product
due to lightning and power-line surges.
17.Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits
as contact with them might be fatal.
18.Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of fire
or electric shock.
19.Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock.Never spill liquid of any kind on the product.
5APEX DIGITALMPD-50/100
Safety Information
20.Servicing - Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service personnel.
21.Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualified service personnel under the
following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the
operating instructions. Adjust only those controls that are covered
by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive
work by a qualified technician to restore the product to its normal
operation.
e. If the product has been dropped or damaged in any way, and
f. When the product exhibits a distinct change in performance - this
indicates a need for service.
22.Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
23.Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
24.Wall or Ceiling Mounting - The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.
25. Heat - The product should be situated away from heat sources
such as radiators, heat registers, stoves or other products
(including amplifiers) that produce heat.
26. Rechargeable battery - Charge voltage cannot below 12.4V.
6 APEX DIGITAL MPD-50/100
Introduction
Your new APEX Digital PD-50/100
Portable DVD player is designed for
you to enjoy all forms of disc media. Its
slim shape allows you to easily carry it
with you and enjoy movies and music
anywhere. Your player incorporates the
latest digital audio/video (AV)
technologies to give you the ultimate in
listening and viewing pleasure.
Your new player also supports CD and
MP3. Your player also has several
unique features, including an S-video
output (for greater picture clarity), large
active LCD screen, multi-angle and
multi-language, Parental Control (to
prevent children from viewing
inappropriate content), This is a truly
multimedia machine designed for the
multimedia world to enjoy. The digital
age has never been easier to enjoy
than with APEX Digital.
7APEX DIGITALMPD-50/100
Notes on Discs
HOW TO HANDLE, CLEAN, AND STORE DISCS.
HANDLING DISCS
• Do not touch the playback side of the disc.
• Do not attach paper or tape to discs.
NOTE: Apex Digital Inc.shall not be
responsible for damage that may occur to a
disc from being operated in the player.
PLAYABLE DISCS
This DVD video player can play back the following
discs.
Disk Mark Contains Disc size Maximum playback time
DVD
video
disc
Audio
CD
MP3
CD
MP3
Audio
+
Video
(moving
pictures)
Audio
Audio
12 cm
12 cm
8 cm
(CD single)
12 cm
Approx. 4 hours
(single sided disc)
Approx. 8 hours
(double sided disc)
Approx. 74 minutes
Approx. 20 minutes
Approx. 600+ minutes
8 APEX DIGITAL MPD-50/100
Table of Contents
Safety Precautions............................................................1-2
Safety Information ............................................................3-6
Introduction ..........................................................................7
Note on discs ......................................................................8
Table of Contents ................................................................9
DVD Display ......................................................................10
Remote Control ............................................................11-12
Identification of Controls ....................................................13
Quick Starting Guide ....................................................14-15
Connecting to a TV ......................................................16-17
Connecting to Optional Equipment ..............................18-22
Playing Back a Disc......................................................23-26
Locating a Specific Title, Chapter or Track........................27
Playing Repeatedly ......................................................28-29
Playing in Favorite Order..............................................30-31
Zooming a Picture..............................................................32
Selecting Subtitles ..............................................................33
Using the On-Screen Display ............................................34
Selecting the Camera Angle ..............................................35
Setting the Parental Lock ..............................................36-37
Setting the Book Mark ........................................................38
Rechargeable Battery Installation ................................39-40
Customizing the Function Settings ....................................41
Warranty ............................................................................42
9APEX DIGITALMPD-50/100
DVD Display
1
5
6
3
2
7
4
1. DVD indicator
2. MP3 indicator
3. CD indicator
4. repeat mode indicator
5. play indicator
6. pause indicator
7. chapter number
8. play time indicator
(A-B, ALL)
The indicators (1- 3) vary depending on the
type of discs you play.
The indicator 4 shows the current disc with
playback control function.
The indicator 5 shows the current repeat mode,
point A to point B set up, or the entire disc.
The indicators (6- 7) shows disc playback
status.
10 APEX DIGITAL MPD-50/100
Remote Control
THE INSTRUCTIONS IN THIS MANUAL DESCRIBE THE
FUNCTIONS ON THE REMOTE CONTROL.
1. SETUP
2. POWER
3. DISPLAY
4. TITLE
5. NUMBERS
6. SLOW
7. PAUSE/STEP
8. REWIND
9. FORWARD
10. REPEAT
11. A-B REPEAT
12. MENU
13. MUTE
14. AUDIO
15. SUBTITLE
16. DIRECTION
(UP/DOWN/LEFT/RIGHT)
17. SHIFT
18. STOP
19. PLAY
20. PREVIOUS
21. NEXT
22. BOOK MARK
23. PROGRAM
1
2
3
4
5
6
7
8
9
10
11
• When you need to use the keys
ANGLE, ZOOM, ENTER and
DIRECTION, set shift on by pressing
SHIFT, and set shift off to use
NUMBERS.
12
13
14
15
16
17
18
19
20
21
22
23
• Please turn the master power
switch on the DVD video player.
Power button on this remote control
unit is for standby power only.
11APEX DIGITALMPD-50/100
Remote Control
PREPARING THE REMOTE CONTROL
1. Open the cassette cover.
.
Slide the cover in the direction of
the arrow 1 while folding down as
1
the arrow 2.
2. place the battery into the
guide.
3. Insert the tray into the
remote control.
OPERATING WITH THE REMOTE CONTROL
Operating DVD video player with the
remote control.
The remote control must point at the
remote sensor, in order for the DVD
player to function correctly.
Distance: Maximum of 7 m from the front of
the remote sensor.
Angle: Approximately 30º from each
direction.
2
12 APEX DIGITAL MPD-50/100
Identification of Controls
MAIN PANEL
1. LCD
(LIQUID CRYST ALDISPLA Y)
2. DISPLAY MODE
3. COLOR
1
2
4. BRIGHTNESS
5. DISC TRAY
6. OPEN
7. PLAY
8. STOP
9. FORWARD
10. REWIND
SIDE FACE
1
1. VOLUME
2. PHONES JACK
3. AUDIO SIGNAL JACK
(LEFT/RIGHT)
MPD-50/100
10
5
62 3 4
4. VIDEO SIGNAL JACK
5. S-VIDEO OUT
6. AV SELECT (ON/OFF)
3
4
5
6
7
8
9
13APEX DIGITAL
Quick Starting Guide
If you want to use rechargeable batteries for this DVD
player, please first read the rechargeable battery
instructions.
1. Connecting to an External Power Source
Connect the power cord (supplied
with the player) to the side input
plug and to a wall outlet. Do not
use any other device otherwise
specified by your dealer.
2. Open the protective cover
The cover opens to a maximum 135
only , so please do not try to open it any
further.
3. Press the open button on the
right to open the internal CD player
cover
Never press the OPEN button on the
right during playback.
4. Inserting a DVD disc
Align the center of the DVD disc with
the center of the disc guide. Press
gently down on the DVD to snap the
disc into place, then close the disc lid.
5. Slide the side power switch
to ‘on’.
APEX DIGITAL MPD-50/10014
o
5
Quick Starting Guide
6. Press the PLAY button on the
player face
In general, the DVD already
inserted into the player will start
reading automatically when power
is turned on.
The DVD player will immediately start rendering
the DVD program.
When you want to stop, press the STOP button and
slide the ON/OFF switch to the left to shut off power
and then close the cover.
15APEX DIGITALMPD-50/100
Connecting to a TV
SETTING UP YOUR PLAYER
Step 1:connect the RCA Video/Audio cable to your TV.
Step 2:connect the yellow cable to the VIDEO on the
back of your player.
Step 3:connect the White and Red cables to AUDIO
OUT of the DVD player.
(For TVs that support S-Video Output please follow the
diagram “BETTER” bellow.)
GOOD
Red
White
TV Audio Input
Yellow
TV Video Input
16 APEX DIGITAL MPD-50/100
Connecting to a TV
BETTER
White
TV Audio Input
Red
TV S-Video input
Connect the DVD video player with an
optional S-Video cable, if the TV has an S
video input. Do not connect the yellow video
cable if using the S Video cable.
• Turn off the power and unplug both units before setting up
any connections.
• If your TV only has a cable antenna connection and no
video inputs to connect your TV to the DVD player, you will
need to purchase an RF adapter from your dealer.
17APEX DIGITALMPD-50/100
Connecting to Optional Equipment
CONNECTING HEADPHONES
1. Connect the headphones.
Headphones with a 3.5 mm stereo plug can be
connected.
2. Adjust the volume.
• Avoid listening to sound at levels which may be harmful to
your ears.
18 APEX DIGITAL MPD-50/100
Connecting to Optional Equipment
Enjoy Dolby Digital or DTS (BEST)
Dolby Digital/DTS
Dolby Digital and DTS programming can deliver surround
sound with five discrete full range channels plus a sixth
channel for a subwoofer. You can enjoy your APEX DVD
with a Dolby Digital or DTS Digital Surround Sound
System. All you need is to connect your DVD player to a
Dolby Digital/DTS receiver or a Dolby Digital Ready
receiver with an external decoder.
DVD SIDE
DVD BACK
To VIDEO OUT
To PCM/BITSTREAM
(Optional)
• How to setup the sound output:
From the SETUP MENU display, select General Setup
by pressing ENTER.
Use “down arrow” key, set the "AUDIO OUTPUT" to
"SPDIF/RAW".
19APEX DIGITALMPD-50/100
Connecting to Optional Equipment
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be authorized by Macrovision
Corporation, and is intended for home and other
limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
It is forbidden by law to copy, broadcast, show, play in
public, and rent copyrighted material without permission.
DVD video discs are copy protected, and any recordings
made from these discs will be distorted.
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol are
trademarks of Dolby Laboratories. Confidential
Unpublished works.
1992-1997 Dolby Laboratories, Inc. All rights
reserved.
“DTS” and “DTS Digital Out” are trademarks of Digital
Theater Systems, Inc.
• Adjust the volume of your receiver to a comfortable
listening level to avoid any speaker damage.
• When connecting and disconnecting the DVD video player,
turn off the amplifier to avoid any speaker damage.
20 APEX DIGITAL MPD-50/100
Connecting to Optional Equipment
Enjoying 2 Channel Digital Stereo Sound (BETTER)
2 Channel Digital Stereo
Enjoy the dynamic sound of 2 Channel Digital Stereo by
connecting an amplifier equipped with a digital audio
input and speaker system (right and left front speakers).
DVD SIDE
DVD BACK
To VIDEO
Video cable
Connection
Example
Front
speaker
(left)
OUT
To digital
audio input
To video
input
TV
To PCM/DOLBY
DIGITALAUDIO OUT
Optical cable
Amplifier equipped
with digital audio input
Front
speaker
(right)
Set "AUDIO OUTPUT" to "SPDIF/PCM " via the
setup menu.
MPD-50/100 APEX DIGITAL 21
Connecting to Optional Equipment
Enjoying Dolby Pro Logic Surround Sound (GOOD)
Dolby Pro Logic Surround
Enjoy the dynamic realistic sound of Dolby Pro Logic
Surround by connecting an amplifier and speaker
system (right and left front speakers, a center speaker,
and one or two rear speakers).
Connection
Example
DVD SIDE
Center
speaker
To VIDEO
OUT
To video
input
Amplifier
equipped with
Dolby Pro
Logic Surround
Front
speaker
(right)
Video cable
Front
speaker
(left)
Connect one or
two speakers. The
output sound from
the rear speakers
will be monaural
even if you
connect two rear
speakers.
To ANALOG
AUDIO OUT
Audio cable
To audio
input
TV
Rear
speaker
Set "AUDIO OUTPUT" to "ANALOG" via the
setup menu.
APEX DIGITAL MPD-50/10022
Playing Back a Disc
BASIC PLAYBACK
1. Open the protective cover
The cover opens to a maximum 135
o
only, so please do not try to open it any
further.
2. Press the open button on the right
to open the internal CD player cover
This will open the disc tray.
3. Insert a DVD disc
Be sure the playback side is faced down.
4. Slide the side power switch to
‘ON’.
5
5. Press PLAY on the panel or the remote control.
As the DVD video player is reading the disc, a menu will
appear on screen.
•
For playback on TV, connect the player to TV as
described on Page16-17.
• To enjoy the sound from the audio system, connect
both units as described on Page 19-21.
MPD-50/100 APEX DIGITAL 23
Playing Back a Disc
HOW TO START PLAYBACK FROM THE MENU SCREEN
1. Press or
Title 1
Title 2
the number buttons to
select the title.
2.Press SHIFT to set shift
Title 3
Title 4
on, then you can use
direction keys and the
enter key.
3. Press the ENTER or
PLAY button.
The DVD video player will
ENTER
start playback from the title
selected.
SHIFT
HOW TO PAUSE PLAYBACK (STILL PLAYBACK)
Press the PAUSE/STEP once during playback, then
press PLAY to resume normal playback. Press
PAUSE/STEP during playback, the picture will
advance one frame each time, then press PLAY
button to resume normal playback.
During the still playback the sound
II/STEP
is muted. MP3 CD does not have the step
feature.
PLAY
APEX DIGITAL MPD-50/10024
Playing Back a Disc
HOW TO STOP PLAYBACK
Press the STOP button.
The player is stopped.
Press the PLAY button to replay.
The player resumes to playback from
the location where it is stopped.
ADVANCED PLAYBACK
You can playback a disc at 2x, 4x, 6x, or
8x the normal speed. You may also resume playback
from the location where you stopped playback.
STOP
REV
PLAY
FWD
FF 2x FF 4x FF 8x
FR 2x
FR 4x
FR 8x
PLAY
PLAY
Press the REV or FWD button during playback.
The playback speed becomes 2x the normal speed.
The playback speed changes, each time you press the
REV or FWD button.
REV: Fast reverse
FWD: Fast forward
TO RESUME NORMAL PLAYBACK.
Press PLAY.
PLAY
25APEX DIGITALMPD-50/100
Playing Back a Disc
PLAYING IN SLOW-MOTION
A disc can also be played back in slow-motion.
TV SCREEN
1/2 1/4
1/4 the normal speed1/2 the normal speed
1/8
1/8 the normal speed
SLOW
Press the SLOW button during
playback
The playback speed becomes 1/2, 1/4, or 1/8 of the
normal speed each time you press the SLOW button.
TO RESUME NORMAL PLAYBACK.
Press PLAY.
PLAY
• During REV, FWD and slow-motion playback, the
sound is muted.
APEX DIGITAL MPD-50/10026
PLAY
Locating a Specific Title, Chapter or Track
DVD DISCS ARE NORMALLY DIVIDED INTO TITLES
WHICH ARE SUB-DIVIDED INTO CHAPTERS.
MOREOVER, CD and MP3 CD ARE DIVIDED INTO
TRACKS.
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
TITLE 1
DVD Video Disc
TITLE 2
LOCATING A TITLE USING THE TITLE MENU
You can locate a specific title using the title menu function, if a
DVD video disc contains a title menu.
1. Press the TITLE button
On the LCD or TV screen, the title menu
will appear.
2. Press the button to select
the title you want. (set shift on)
You can also directly locate a specific title
by pressing its assigned number with the
PREVIOUS
number buttons.
3. Press the PLAY button
This will cause the DVD video player to start playback from
chapter 1 of the title selected.
You also can use skip buttons to to select a title or track
desired:
Press or button repeatedly till the one displays.
MPD-50/100 APEX DIGITAL 27
PLAY
NEXT
Playing Repeatedly
C
_
TITLE
DISC
DISC
THIS DVD VIDEO PLAYER ALLOWS YOU TO
PLAYBACK A SPECIFIC TITLE, CHAPTER, TRACK,
OR SEGMENT REPEATEDLY. (TITLE REPEAT,
CHAPTER/TRACK REPEAT, A-B REPEAT)
HOW TO REPEAT A TITLE, CHAPTER, OR DISC
1. During normal playback,
press the REPEAT button.
The repeat mode changes, each
time you press the REPEAT
button.
REPEAT
OFF
HAP
Resumes normal playback.
Repeats the same chapter.
Repeats the same title.
Repeats the whole disc
2. Input the number of the chapter or title you want to
repeat.
The unit will playback it repeatedly.
If you want to playback the whole disc repeatedly, select
, and select to resume normal playback.
28 APEX DIGITAL MPD-50/100
OFF
Playing Repeatedly
HOW TO REPEAT A SPECIFIC SEGMENT
1. Press the A-B button at the beginning of the
segment in which you want to repeat playback
(point A)
2. Press the A-B button again at the end of the
segment (point B)
The DVD video player will automatically return to point A
and start to repeat playback of the selected segment (AB).
3. Press the A-B RPT button to cancel the A-B
repeat function
The DVD video player will resume to normal playback.
A-
A-B
OFF
MPD-50/100 APEX DIGITAL 29
A-B
Playing in Favorite Order
THIS PORTABLE DVD ALLOWS YOU TO PROGRAM
ITEMS INTO THE MEMORY AND THEN PLAY THEM
BACK IN ANY ORDER WHICH YOU WANT IT PLAYED
BACK. (PROGRAM PLAYBACK)
HOW TO SET TITLES, CHAPTERS, OR TRACKS IN A
FAVORITE ORDER
1. Press the PROGRAM button.
PROGRAM MENU displays on the screen.
PROGRAM MENU
DISC PROGRAM
1 2 3 4 5
6 7 8 9 10
_ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _
CLEAR
START
CLEAR ALL
2. In the DISC volume, use direction buttons to move
the cursor and press ENTER to select one.
The number of the item selected will be input into the
PROGRAM volume.
APEX DIGITAL MPD-50/10030
Playing in Favorite Order
3. Program in each item in your favorite order as
above step.
For example: To program in 5, 8,10.
DISC PROGRAM
1 2 3 4 5
6 7 8 9 10
_5_ _ _ _ _ ____
_ _ __ _ _____
_ _ __ _ _____
_ _ __ _ _____
CLEAR
CLEAR ALL
1 2 3 4 5
6 7 8 910
_5_ _8_ _ _ ____
_ _ __ _ _____
_ _ __ _ _____
_ _ __ _ _____
CLEAR
CLEAR ALL
_5_ _8_ _10 _ _ _
1 2 3 4 5
6 7 8 9 10
_ _ __ _ _____
_ _ __ _ _____
_ _ __ _ _____
CLEAR
CLEAR ALL
4. Select START to start program playback.
5. To clear the programmed, move the cursor to
CLEAR or CLEAR ALL by pressing direction buttons
and press ENTER to confirm it.
The function is not available on DVD.
MPD-50/100 APEX DIGITAL
31
Zooming a Picture
ZOOMING A PICTURE
This DVD video player allows you to zoom into a picture
as well as shift the zoom point.
Press ZOOM during normal
ZOOM
playback or slow - motion. (To use
the ZOOM button, it should be set
‘SHIFT ON’ by pressing SHIFT.)
The DVD video player magnifies in the center of the
picture.
If you press during zoom playback, the zoom
point shifts.
ZOOM
32 APEX DIGITAL MPD-50/100
Selecting Subtitles
HOW TO DISPLAY SUBTITLES
You have the option to select a preferred subtitle
from those included on the DVD video disc.
Press to select the subtitle language as
well as to set subtitle on or off.
01 / 05
EN ON
02 / 05
CH ON
03 / 05
GE ON
01 / 05
EN ON
01 / 05
EN OFF
Press the SUBTITLE button to access to
subtitle menu.
Highlight the item you want to select by
pressing or number keys (0-9).
SUBTITLE
01 / 05
EN ON
01 / 05
EN ON
33APEX DIGITALMPD-50/100
Using the On-Screen Display
5
h
THIS UNIT ALLOWS YOU TO VIEW THE STATUS AND
DISC INFORMATION ON TO THE SCREEN,
MOREOVER, YOU CAN SELECT ITEMS CONTAINED
ON THE DISC FROM DISPLAY MENU.
20
25
00:00:00
//
1 1
EN
.1c
02 05
A
CH O N
/
2 2
OFF
CHECKING THE OPERA TIONALSTATUS
With this function, you can view
the current title, chapter, total
playing time, audio, subtitle,
angle, repeat mode and
bookmark.
SETTING UP YOUR FAVORITE ITEMS
Use to highlight the item you want to set up. And
select your favorite by press or , for some, you also
can select one by inputting its number directly. Detailed
operation is just as each short-cut such as TITLE, AUDIO,
SUB-T, ANGLE, REPEAT, A-B and MARK.
34 APEX DIGITAL MPD-50/100
A-B
1 2 3 4 5
DISPLAY
Selecting the Camera Angle
2 2
/
THIS DVD VIDEO PLAYER ALLOWS YOU TO SELECT
FROM SEVERAL DIFFERENT ANGLES.
ANGLE 1 ANGLE 2
Selecting the camera angle
HOW TO CHANGE THE CAMERA ANGLE
If the DVD video disc was recorded from multiple
angles, you have the option to change the camera angle
of the scene you are watching.
SUBTITLE
Press the ANGLE button while playing back a scene
recorded with multiple angles.
• You may only press the ANGLE button when the angle
icon is flashing on the DVD display.
• Each time you press the ANGLE button, the angle will
change.
2/2
1/2
• The angle function will not work on DVD video discs
that does not contains recorded multiple angles.
35APEX DIGITALMPD-50/100
Setting the Parental Lock
YOU CAN USE THE PARENTAL LOCK FUNCTION
ONLY WITH DVD VIDEO DISCS EQUIPPED WITH THE
PARENTALLOCK FEATURE.
SETTING THE PARENTAL LOCK
DVD video discs equipped with the
parental lock function are rated
according to their content. The
contents allowed by a parental lock
level and the way a DVD video disc
can be controlled may vary from disc
to disc. For example, if the disc
allowed, you could edit out violent
scenes unsuitable for children and
replace them with more suitable
scenes, or lock out playback of the
disc all together.
1. Press STOP during
playback
Press STOP once.
2. Press SETUP
The SETUP MENU appears
on the screen.
3. Press SHIFT to set shift
on, then you can use
direction keys and the enter
key.
Press it again to set shift off
to use the number keys.
36 APEX DIGITAL MPD-50/100
DIRECTION
SHIFT
STOP
Setting the Parental Lock
4. Use down key to select
RATING, press right key or
ENTER to access to the sub-
1. KID SAFE
2. G
3. PG
4. PG-13
5.
6. PG-R
7. NC-17
8. ADULT
BYPASS
Select ratings, press
5.
menu.
ENTER.
6. Enter your password then
press ENTER.
The pre-set password is 3308
7. Press SETUP to exit setup,
press ENTER to start.
LANG
VIDEO
AUDIO
RATING
OTHER
EXIT
MPD-50/100 APEX DIGITAL
37
Setting the Book Mark
A BOOK MARK ALLOWS YOU TO EASILY ACCESS TO
ONE POINT FROM WHICH YOU WANT TO START.
1. Under ‘SHIFT ON’ status,
press the MARK button, it
appears:
2. As the disc is played back
PLAY
where you want to set a
bookmark, Press ENTER.
MARK
Each time you press it, a
bookmark will be set. At
maximum, five bookmarks
(1,2,3,4,5) can be set.
1
1234 12345
1 2
1 2 3
3. When you desire to start playback from which
mark you set, use direction buttons to move cursor
to it, and press PLAY.
APEX DIGITAL MPD-50/10038
Rechargeable Battery Installation & Use
USE AND MAINTENANCE
THIS UNIT IS SUPPLIED WITH HIGHLY-EFFECTIVE
RECHARGEABLE BATTERY (NI-MH). SUCH BATTERY PACK
A HIGH STORAGE CAPACITY AND LOW LEVEL OF
DEGRADATION. THE LATTER MEANS THAT THE BATTERY
CAN ALSO BE RECHARGED WHEN ONLY PARTLY SPENT.
Plug the AV adapter into the battery.
Please fully charge the battery
prior to first use.
During the time the battery is
being charged, the red light is
flashing. When the light turns
green this indicates that the battery is fully charged. You can
then unplug it from the wall outlet. During recharging, the battery
will become warm, this is normal.
You can also directly plug the A/C adapter into the power
jack of the player which is connected with the battery, then
you can charge the battery while enjoying movies.
Make sure you always use only the AC adapter supplied
with the player to recharge the battery.
Charging indicator
AC Adapter/charge input
If the battery will not be used for a long duration of time (say one
week or longer), it is recommended that you first fully charge the
battery and store it away properly, and recharge it at least once
every two months for maintenance.
39APEX DIGITALMPD-50/100
Rechargeable Battery Installation & Use
The provided battery can be recharged for about 300 times.
Each full recharge takes about 3 hours. A fully charged battery
can power the unit for about 2 hours. Power consumption
depends on the operations of the player such as brightness of
the screen, volume level, etc.
Recharge the battery in time when fully spent in order to
maximize its life.
Never recharge the battery which is already fully charged.
Under no circumstance should you short out the battery, store it
in a metal container, or leave it in a humid or damp environment.
Store the battery in an airtight container if possible. Recharge
effectiveness will degrade when environmental temperatures
drop below 10 ºC or exceed 35 ºC.
INSTALLING & REMOVING THE BATTERY PACK
2
1
3
1. Make sure the unit is powered off and unplugged.
2. Plug the battery pack into the outlet of the unit as the
arrowhead 1, and push it forward as arrowhead 2 to align them
with each other when you hear a click sound.
Removing the Battery Pack
1. Make sure the unit is powered off and unplugged.
2. Pull the battery pack backward as arrowhead 3 till it is
released.
40 APEX DIGITAL MPD-50/100
Customizing the Function Settings
THIS UNIT ALLOWS YOU TO CUSTOMIZE THE
PERFORMANCE TO YOUR PERSONAL PREFERENCE.
SETUP MENU
LANG
VIDEO
AUDIO
RATING
DISPLAYING THE SETUP MENU SCREEN
LANG
VIDEO
AUDIO
RATING
OTHER
EXIT
1. Press SETUP.
2. Press
to select category
(highlight), then press
ENTER.
3. Press SETUP to
normal playback.
• Preset password is 3308 .
• Functions and menu may change without notice.
* Factory defaults
** You must press STOPto set up PREFERENCES.
/ / /
O.S.D
AUDIO
SUBTITLE
DISCMENU
SYSTEM
ASPECT
CAPTION
OFF*
ON
DIGITAL
RATING LEVEL8*
CHANGE PASSWORD
CANCEL PASSWORD
SCR SAVER
FACTORYSETTING
PAL*
NTSC
16:9 WS*
4:3 PS
4:3 LB
LPCM*
DOLBY DTS
OTHER
ON*
OFF
ENGLISH*
CHINESE
ENGLISH*
CHINESE
ORIGINAL
JAPAN
SPANISH
FRENCH
OFF*
JAPAN
SPANISH
FRENCH
ENGLISH
CHINESE
ORIGINAL
ENGLISH*
CHINESE
ORIGINAL
JAPAN
SPANISH
FRENCH
41APEX DIGITALMPD-50/100
Limited Warranty
PLAYERS
90 DAYS LABOR
ONE YEAR REPLACEMENT OF PARTS
WHO IS COVERED?
Proof of purchase is required to receive warranty service such
as the original sales receipt showing original date of purchase
from an authorized APEX Digital, Inc. dealer in N. America. Keep
your original box and packaging in case your unit needs to be
shipped to us. You will need to prepay shipping and APEX will
pay the cost of shipping the unit back to you.
WHAT IS COVERED?
Warranty repair from the original date of purchase: One (1) year
replacement of parts; 90 days limited labor warranty coverage.
If you don’t have proof of purchase, your unit will be considered outof-warranty & will be charged at a flat labor rate.
WHAT IS EXCLUDED?
Your warranty does not cover:
- Labor charges for installation or setup of the product,
adjustment of customer controls on the product, and installation
or repair of antenna systems outside of the product.
- Product repair and/or part replacement because of misuse,
accident, unauthorized repair or other cause not within the
control of Apex Digital, Inc.
42 APEX DIGITAL MPD-50/100
Limited Warranty
- A product that requires modification or adaptation to
enable it to operate in any country other than the country
for which it was designed, manufactured, approved
and/or authorized, or repair of products damaged by
these modifications.
- Incidental or consequential damages resulting from the
product. (Some states do not allow the incidental or
consequential damages, so the above exclusion may not
apply to you. This includes, but is not limited to,
prerecorded material, whether copyrighted or not.)
BEFORE REQUESTING SERVICE:
Check your owner’s manual under “Troubleshooting
Guide” and visit our website www.apexdigitalinc.com
for the latest updates under FAQ.
WHERE IS SERVICE AVAILABLE?
Please contact APEX DIGITAL, INC.
customer service: 2919 E. Philadelphia St., Ontario, CA
91761 (909) 930-1239 Monday-Friday
8:30am-5:00pm (California)
www.apexdigitalinc.com
This warranty gives you specific legal rights. You may
have other rights which vary from state/province to
state/province.
43APEX DIGITALMPD-50/100
Loading...
