Apex GT2715DV Owner’s Manual

TV/DVD COMBO

GT2715DV

OPERATION MANUAL

Read this manual carefully before operation.

CONTENTS

BEFORE OPERATION ............................................................................................................................. 1

INTRODUCTION

Features ................................................................................................................................................. 10

To Connect the Antenna ......................................................................................................................... 11

Remote Batteries ................................................................................................................................... 11

To Connect External Equipment ............................................................................................................ 12

Control Buttons ...................................................................................................................................... 14

TV FUNCTIONS

Tuning in ................................................................................................................................................ 17

General Operation ................................................................................................................................ 17

Quick Start to the Menus ....................................................................................................................... 19

Function Selection ................................................................................................................................. 19

Picture Improvement .............................................................................................................................. 21

Sound Improvement ............................................................................................................................... 21

Time Setting ........................................................................................................................................... 22

Childlock ................................................................................................................................................. 22

DVD FUNCTIONS

MP3 Operation ....................................................................................................................................... 23

Playing Back a Disc ............................................................................................................................... 24

Locating a Specific Title, Chapter or Track ............................................................................................ 27

Zooming a Picture .................................................................................................................................. 29

Selecting the Camera Angle/Language/Audio Settings ......................................................................... 30

Playing in a Favorite Order. ................................................................................................................... 31

Selecting Subtitles ................................................................................................................................. 32

Playing Repeatedly ................................................................................................................................ 32

Playing Back Yor KODAK Picture CD .................................................................................................... 33

Playing Your JPEG Files ........................................................................................................................ 34

Using the On-screen Display ................................................................................................................. 35

Setting the Parental Lock ....................................................................................................................... 36

Customizing the Function Settings ........................................................................................................ 37

SPECIFICATIONS ....................................................................................................................................... 38

TROUBLESHOOTING GUIDE .................................................................................................................... 39

TV / DVD Combo Warranty Information .................................................................................................. A0

Note:

The OSD and illustration in this manual may be somewhat different from theactual situation.

Please take the unitas the standard.

BEFORE OPERATION

Dear Customer:

Congratulationst You have purchased one of the finest TV/DVD combos on the markefl This manual will help you use the many exciting and useful features to make your unit viewing more enjoyable than ever before.

Before operating your unit, please read all these safety and operating instructions completely and then retain for future reference.

Customer's Record

You will find the model number and chassis number on the back of your unit.

Record these numbers in the spaces provided below. Refer to them whenever you call upon your Apex dealer regarding this product.

Model Number: GT2715DV

Chassis Number: CH-10C3(D)

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

The lightning symbol in the triangle tells

w_gllll[O],

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELEC- TRIC SHOCK, DO NOT REMOVE COVER(OR

BACK). NO USER SERVICEABLE PARTS IN- SIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

you that the voltage inside this product may be strong enough to cause an

electric shock. NOT TRY TO SERVICE THIS PRODUCT YOURSELF.

The exclamation point in the triangle tells

you that important operating and mainte- nance instructions follow this symbol.

CAUTIONS: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION CORD RECEP-

TACLE OR OTHER OUTLET UNLESS THE PRONGS CAN BE FULLY INSERTED INTO THE OUTLET TO PREVENT ANY EXPOSURE OF THE PRONGS ON THE POLARIZED PLUG.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IH HAZARDOUS RADIATION EXPOSURE. DO NOT STARE INTO BEAM.

The unit employs a Laser System. To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible laser

radiation when open and interlocks defeated.

Avoid displaying stationary images on your TV screen for extended periods of time. Stationary patterns generated by computer displays, video games, stock market reports, etc. can become permanently engrained on the picture tube. This damage is not protected by your warranty as it is the result of misuse. Should you wish to use yourApex TV/DVD combo to display still images, it is always advisable to reduce brightness and contrast settings. Never leave a video game or com-

puter display unattended.

BEFORE OPERATION (continued)

Safety Precautions

WARNING:

THE REGION CODE FOR THE UNIT IS 1.

Since it is very usual for DVD movies to be released at different times in different regions of the world, all players have region codes and disks can have an optional region code. If you load a disk of a different region code to your player, you will see the region code notice on the screen. The disk will not

play, and should be unloaded.

NOTE TO CABLE INSTALLER IN THE USA: This reminder is provided to call your attention to Article 820-40 of te NEC that provides guidelines for proper grounding and,

in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

(continued)

Important Safety Instructions

CAUTION

PLEASE READ THESE INSTRUCTIONS, KEEP THESE INSTRUCTIONS

AND HEED ALL WARNINGS.

FOLLOW ALL INSTRUCTIONS.

Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to assure your personal safety. However improper use can result in potential electrical shock or fire hazards. In order not to defeat the safe

guards incorporated in this TV set, observe the following basic rules for antenna/TV installation, use and servicing. All oper- ating and use instructions should be followed.

Do not remove the cabinet cover. This may expose you to dangerous voltages. Refer all servicing to qualified service per-

sonnel.

BEFORE OPERATION (continued)

Precautions

Power Sources - The unit should be operated only

from the type of power source indicated on the unit or as indicated in the Operation Manual. If you are not sure of the type of power supply in your home, consult your sales person or your local power company. For

unit designed to operate from battery power, or other

sources, refer to the operating instructions.

Grounding or Polarization- Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has two blades with one wider than the other. A grounding - type plug

has two blades and a third grounding prong. The

wide blade or the third prong is provided for your safety. If the provided plug does not fit into your

outlet, consult an electrician for replacement of the obsolete outlet.

Water and Moisture Warnings- Do not use the unit near water-for example, near a bath tub, wash

bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like. The unit shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the unit.

Ventilation-Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the unit and to protect it from

overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug,or other similar surface. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is pro-

vided or the manufacturer's instructions have been adhered to.

Wide blade Lame large

Cuchilla ancha

Alternate Warnings -This plug will only fit into a grounding-type power outlet. This is a safety feature.

If you are unable to insert the plug into the outlet, contact your electrician to have a suitable outlet ins- talled. Do not defeat the safety purpose of the groun- ding plug.

BEFORE OPERATION (continued)

Precautions (continued)

Heat-Do not install near any heat sources such as radiators, heat registers, stoves, or other appa-

ratus (including amplifiers ) that produce heat.

Overloading -Do not overload wall outlets, exten- sion cords or integral convenience receptacles as this can result in fire or electric shock.

Lightning-For added protection for this unit during a lightning storm, or when it is left

unattended and unused for long periods of time,

unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

Accessories -Do not place the unit on an un- stable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury to a child or adult, and serious damage to the unit. Use only with a cart, stand, tripod, bracket, or table recom -

mended by the manufacturer, or accessory re - commended by the manufacturer, or sold with the TV set, and should use a mounting accessory recommended by the manufacturer.

A product and cart combination should be moved with care. Quick stops, excessive force, and un- even surfaces may cause the unit and cart

combination to overturn.

Power-Cord Protection-Protect the power cord from being walked on or pinched particu-

larly at plugs, convenience receptacles, and the point where they exit from the apparatus.

Object and Liquid Entry-Never push objects of any kind into the unit through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric

shock. Never spill liquid of any kind on the unit.

BEFORE OPERATION (continued)

Precautions (continued)

Cleaning-Unplug the unit from the wall outlet

before cleaning or polishing it. Do not use liquid cleaners or aerosol cleaners. Use a dry cloth for cleaning the exterior of the unit.

Attachments -Do not use attachments not recom-

mended by the product manufacturer as they may cause hazards or electric shock.

Damage Requiring Service - Unplug the unit from the wall outlet and refer servicing to qualified

service personnel under the following conditions: a. If the power cord or plug is damaged or frayed.

b. If liquid has been spilled or objects have fallen into the unit.

_.,,.! I

If a snapping or popping sound from a unit is

heard continuously or frequently while the unit

is operated, unplug the unit and consult your dealer or service technician. It is normal for some

unit to make occasional snapping or popping sounds, particularly when being turned on or off.

c.lf the unitt has been exposed to rain or water.

BEFORE OPERATION (continued)

Precautions (continued)

d. If the unit has been subject to excessive shock by being dropped, or the cabinet has been

damaged.

e. If the unit does not operate normally by following the operating instructions. Adjust only those controls

that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to its normal operation. f.When the unit exhibits a distinct change in per-

formance-this indicates a need for service.

Replacement Parts - When replacement parts are required, be sure the service technician has used

replacement parts specified by the manufacturer or have the same characteristics as the original parts. Unauthorized substitutions may result in fire,

electric shock, or other hazards.

Safety Check - Upon completion of any service or repairs to the unit, ask the service technician to perform routine safety checks to determine that the TV set is in proper operating condition.

Servicing - Do not attempt to service the unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

When the unit reaches the end of its useful life, improper disposal could result in a picture tube implosion. Ask a qualified service technician to dispose of the unit.

BEFORE OPERATION (continued)

Precautions (continued)

ANTENNA

Outdoor Antenna Grounding-if an outdoor antenna is installed, follow the precautions below.

An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power

circuits, or where it can come in contact with such power lines or circuits. WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM, EXTREME CARE SHOULD BE TAKEN TO KEEP FROM CONTACTING SUCH POWER LINES OR CIRCUITS AS CONTACT WITH THEM IS ALMOST INVARIABLY FATAL

Be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code in USA and Section 54 of the Canadian Electrical Code(ANSI/NFPA

70) in Canada provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit,size of grounding conductors, location of antenna discharge unit, con- nection to grounding electrodes, and requirements for the grounding electrode.

Example of antenna grounding according to NationalElectrical Code (NEC)

Antenna lead-in wire

.... ....dc, mp

_i_ fi Antenna discharge unit

_ .... ==i=----_==_ _ 7._-_ (NEC Section 810.20)

E_ectri ..... ice equipment% J _ _!

......................

"_Z .-1_'__. O.... ding conductors

Ground clamp _ (NEC Section 810.21)

Power service grounding electrode system (NEC Air 250 Part H)

BEFORE OPERATION (continued)

FCC Warning

Class B Computing Device

Information to User

This equipment has been tested and found to comply with the limits for a class B digital device pursuant to part

15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1 ) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help and for additional suggestions.

The user may find the following booklet prepared by the Federal Communications Commission helpful: How to

Identify and Resolve Radio -TV Interference Problems". This booklet is available from the US Government

Printing Office. Washington, D. C 20402, Stock No. 004-000-00345-4.

FCC Warning

The user is cautioned that changes or modifications not expressly approved by the manufacturer could void the

user's authority to operate the equipment.

NOTE: In order for an installation of the product to maintain compliance with the limits for a Class B device.

shielded cables must be used.

BEFORE OPERATION (continued)

Notes on Discs

HOW TO HANDLE, CLEAN, AND STORE DISCS.

Handling discs

• DO NOT TOUCH THE PLAYBACK SIDE OF THE DISC.

• DO NOT ATTACH PAPER OR TAPE TO DISCS.

Note: APEX DIGITAL INC. SHALL NOT BE RESPONSIBLE FOR DAMAGE

THAT MAY OCCUR TO A DISC FROM BEING OPERATEDD IN THE UNIT.

Cleaning discs

• Fingerpints and dirt on the disc cause picture and sound deterioration. Wipe the disc from the center outward with a soft cloth. Always keep the disc clean.

• If you cannot wipe off the dirt off, wipe the disc lightly with a slightly moistened soft cloth and finish witha dry cloth.

• Do not use any of solvent such as paint thinner, benzine, commercially available cleaners or anti-static spray for vinyl LP's

Storing discs

• Do not store discs in places subject to direct sunlight or near heat sources.

• Do not store discs in places subject to moisture and dust.

• Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.

Playable discs

This unit can play back the following discs.

Disk Mark Contains Disc Size

DVD + video Video disc "_€1OE o (moving

Audio Audio

CD 8cm

Audio

12cm

pictures)

12cm

(CD single)

Maximum playback time

Approx. 4 hours (single sided disc)

Approx. 8 hours (double sided disc)

Approx. 74 minutes

Approx. 20minutes

Notes on regional numbers

DVDs are divided into separate regions. The United States and Canada are designated as

region 1 DVD. Your unit plays region 1 DVDs

only.

INTRODUCTION

Features

True Flat Picture Tube

English/French/Spanish Menus

• The unique English/French/Spanish menu control function makes the operation more easily,

On/Off Timer

• The TV automatically turns off and on and tunes to the desired channel at the time when programmed,

Childlock Function

• Prevents children from watching TV for a long period of time, Especially when parents are out,

Channel Scan

• Displays all channels set in the Add mode, Parental Control

• Prevents children from watching programs not suitable for them,

CGD/Text Function

• if they are included in a program, you can view closed captions or text information,

Auto-degaussing

• Color TV is easily affected by magnetism which leads to color distortion, If you TV is moved or affected by near magnetic components or appliances with power on, turn it off for 1 hour, The builtqn auto-de-gaussing circuit will

eliminate the magnetism interference,

Auto off when no signal received

• When a channel has no signal (e,g, the TV station fails to send signals) and if no button is pressed within 15

minutes, the TV automatically enter the Standby mode, In the Video & DVD mode, this function doesn't work,

AVIS-VIDEO/COAXIAL Terminals for External Equipment Connection Quick Selectable Picture / Sound Modes

MTS Stereo / Video Stereo

AVC-Auto Volume Correction

DVD/CD/MP3/KODAK Picture CD Support

INTRODUCTION (continued)

To Connect the Antenna

VHF

UFH

or Cable

VHF

UHF

Antenna adapter %_

LI/V mixer (not supplied)

Notes:

It is recommended that a 75_-2 coaxial cable be used in order to eliminate possible interference and noise which may occur due to nearby radio transmissions,

The antenna cable should not be tied together with other wiring,

@ Set up a lightning arrester and check it regularly when an outdoor antenna is used,

Remote Batteries

1 Remove the battery compartment lid. 2 Place in two AAA batteries, Make sure the positive (_) and negative (_) polarities are correct, 3 Reattach the battery lid,

Notes:

Alkaline batteries are recommended for longer life, Always replace both batteries with fresh ones of the same

type,

Do not expose batteries to fire or disassemble them,

® To avoid battery leakage, remove batteries from the remote control when it is not to be used for a long pe-

riod of time or the batteries are exhausted,

+ 30 hidden pages
