APC Easy UPS 1 Ph Online
For IT professionals in small to medium
businesses, EasyUPS Online provides basic
power protection for unstable power
conditions, ensuring consistent and
reliable connectivity at the most critical
moments. APC Easy UPS Online is a
versatile, high quality, cost competitive
UPS developed to handle a wide voltage
range, and inconsistent power conditions;
delivering the quality millions of IT
professionals trust around theworld.
www.apc.com
APC Easy UPS 1 Ph Online
Standard Features (1-10kVA)
High Power Factor
More real output power in watts 0.8 Pf(1,2,3 kVA),
PF=1 (6 & 10 kVA)
Input power factorcorrection
(0.95 under normal input & fullyloaded 1, 2, 3 kVA)
(0.99 under normal input & fully loaded 6 & 10 kVA)
Minimizes installation costs by enabling the use of
smaller generators andcabling
GeneratorCompatible
Ensures clean, uninterrupted power to the loads inthe
event of an extended power outage
OVCD (Overvoltage Cutoff Device)protection
Under special application with high voltage condition,
OVCD protection will prevent the damage of UPS
components and extend the life of theUPS
Wide input voltagerange
60% load: 110-300VAC
Allows for unstable powerenvironments
Intelligent BatteryManagement
Maximizes battery performance, life, and reliability
through intelligent precision temperaturecompensated
charging
Built-in Automatic Bypass
Ensures seamless power to the load even in theevent
of catastrophic UPSfailure
USB Port / Serial Port
Provides management of the UPS via USB
communication
Power Conditioning
Protects connected loads from surges, spikes,lightning,
and other powerdisturbances
Flash UpgradeableFirmware
Allows for field updates of firmware via communication
ports (USB orRS232)
LCD/LED Display
Intuitive interface provides detailed and accurate
information with the ability to configurelocally
Environmentallyrobust
Conformal coated
ECO mode / Greenmode
An energy saving mode that allows the input voltage
regulation range to be set and modified through the
LCD display
Safety agencyapproved
Ensures the product has been tested and approvedto
work safely with the connected service provider
equipment and within the specifiedenvironment
Excellent power quality and performance
True double conversion provides tight voltage and
frequency regulation and zero transfer time forreactive
loads such as machinery or lab equipment
APC Easy UPS Online
LCD display
1.On/Off StatusLED
Indicates power ison
2. On/Off Button
Press to power UPS on or off
3. Alert LED
Flashes red when UPS has a
notification or is in a steady state
when there is afault
4. Mute/ESC button
Mutes current alarm temporarily and
also serves as the escape key when
navigating the sub menus of the
display
5. Enter key
Press to enter the display menusand
chose an option within themenu
6. Up/Down arrows
Keys for navigation throughthe
displaymenu
LCD displayicons
UPS is on utility power
UPS is on batterypower
UPS is in bypass mode
Replacebattery
An internal fault isdetected
Overload- connected load is drawing more
than the power rating
Batterycharge
Loadlevel
Mute- audible alarm has beendisabled
ECO mode – illuminated when the unit is
providing utility power directly and power is
within configured ranges
Alert or notification – UPS has detectedand
error please see user’s manual fordetails
Event – illuminated when the user is
reviewing the event log
UPS Model
SRV1KI-TW SRV2KI-TW SRV3KI-TW
Output
Power Capacity
800 W / 1000 VA 1600 W / 2000 VA 2400 W / 3000 VA
Nominal Output Voltage
220/230/240 VAC
Output Frequency Range
(sync mode)
47-53 Hz or 57-63 Hz
Topology and output
waveform
Double conversion online; sine wave
Output Connections
(3) IEC C13 (4) IEC C13 (6) IEC C13, (1) C19
Crest Factor
3:1
Input
Nominal Input Voltage
220/230/240 VAC
Input Frequency
40 - 70 Hz
Input Voltage Range
110-285 Vac at 50% load
Input Connection
IEC C14 IEC C20
Batteries
Battery Type
Maintenance-free sealed Lead-Acid battery
Typical recharge time
4 hours to recover to 90% capacity
Runtime Estimates at full
and half load, min
400W / 800 W 800 W / 1600 W 1200W / 2400 W
Half Load Runtime (min)
10 10 10
Full Load Runtime (min)
4 4 4
Communication and
management
DB
-9 RS-232 Supports Windows 2000/2003/XP/Vista/2008/7/8/10
Intelligent Slot
Mini slot
Control panel and audible
alarms
Multi-function LCD status and control console
Battery user disconnector
Yes
Emergency power off (EPO)
No
Surge Protection and
Filtering
Surge Energy Rating
(Joules)
600 J
Physical
Dimension
DxWxH(mm) 288 x 145 x 223 400 x 145 x 238 425 x 190 x 336
Weight (
kgs) 9.3 16.8 26.8
Conformance
Regulatory
BSMI, CE
Technical Specifications
UPS Model
SRV6KI-TW SRV10KI-TW
Output
Power Capacity
6000 W / 6000 VA 10,000 W / 10,000 VA
Nominal Output Voltage
220/230/240 VAC
Output Frequency Range (sync mode)
60 Hz or 50 Hz +/- 0.1 Hz
Topology and output waveform
Double conversion online; sine wave
Output Connections
Terminal block
Crest Factor
3:1
Input
Nominal Input Voltage
220/230/240 VAC
Input Frequency
50 / 60 Hz
Input Voltage Range
110-300 Vac at 60% load
Input Connection
Terminal block
Batteries
Battery Type
Maintenance-free sealed Lead-Acid battery
Typical recharge time
4 hours to recover to 90% capacity
Runtime Estimates at full and half
load, min
3000 W / 6000 W 5000 W / 10000 W
Half Load Runtime (min)
10 7
Full Load Runtime (min)
3.5 2
Communication and management
DB
-9 RS-232 Supports Windows 2000/2003/XP/Vista/2008/7/8/10
Intelligent Slot
Mini slot
Control panel and audible alarms
Multi-function LCD status and control console
Battery user disconnector
Yes
Emergency power off (EPO)
Yes
Surge Protection and Filtering
Surge Energy Rating (Joules)
600 J
Physical
Dimension
DxWxH(mm) 374 x 190 x 685 447 x 190 x 685
Weight (
kgs) 54 65
Conformance
Regulatory
BSMI, CE
Technical Specifications
APC Easy UPS 1 Ph Online
Schneider Electric
132 Fairgrounds Road
West Kingston, RI02892
Phone:401-789-5735
©2018 Schneider Electric. All Rights Reserved. Schneider Electric I Life Is On, APC, and
PowerChute are trademarks and the property of Schneider Electric SE, its subsidiaries, and
affiliated companies. All other trademarks are the property of the respective owners.
