APC NetBotz Quick Start Guide

Download

NetBotz

Rack Monitor 450/550/570

Installation and Quick Configuration Manual

NBRK0450

NBRK0550

NBRK0570

990-3291L-001

Publication Date: 5/2020

APC by Schneider Electric Legal Disclaimer

The information presented in this manual is not warranted by APC by Schneider Electric to be authoritative, error free, or complete. This publication is not meant to be a substitute for a detailed operational and site specific development plan. Therefore, APC by Schneider Electric assumes no liability for damages, violations of codes, improper installation, system failures, or any other problems that could arise based on the use of this Publication.

The information contained in this Publication is provided as is and has been prepared solely for the purpose of evaluating data center design and construction. This Publication has been compiled in good faith by APC by Schneider Electric. However, no representation is made or warranty given, either express or implied, as to the completeness or accuracy of the information this Publication contains.

IN NO EVENT SHALL APC BY SCHNEIDER ELECTRIC, OR ANY PARENT, AFFILIATE OR SUBSIDIARY COMPANY OF APC BY SCHNEIDER ELECTRIC OR THEIR RESPECTIVE OFFICERS, DIRECTORS, OR EMPLOYEES BE LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL, OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS, CONTRACT, REVENUE, DATA, INFORMATION, OR BUSINESS INTERRUPTION) RESULTING FROM, ARISING OUT, OR IN CONNECTION WITH THE USE OF, OR INABILITY TO USE THIS PUBLICATION OR THE CONTENT, EVEN IF APC BY SCHNEIDER ELECTRIC HAS BEEN EXPRESSLY ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. APC BY SCHNEIDER ELECTRIC RESERVES THE RIGHT TO MAKE CHANGES OR UPDATES WITH RESPECT TO OR IN THE CONTENT OF THE PUBLICATION OR THE FORMAT THEREOF AT ANY TIME WITHOUT NOTICE.

Copyright, intellectual, and all other proprietary rights in the content (including but not limited to software, audio, video, text, and photographs) rests with APC by Schneider Electric or its licensors. All rights in the content not expressly granted herein are reserved. No rights of any kind are licensed or assigned or shall otherwise pass to persons accessing this information.

This Publication shall not be for resale in whole or in part.

Contents

Important Safety Information..................................................................................1

Please Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Safety Information for your NetBotz Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Introduction ............................................................................................................3

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Document Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Additional Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

StruxureWare certified . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Physical Description...............................................................................................5

Inventory ................................................................................................................7

Installation..............................................................................................................8

Install the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Cage Nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Rack-mount installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Power cord and network cable connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Initial Configuration ..............................................................................................11

Obtain network settings using DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Configure network settings using a terminal emulator . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Configure network settings using the Serial Configuration Utility . . . . . . . . . . . . . . . . . . . 12

Access an Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Web UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Advanced View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Types of User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

NetBotz Quick Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Configure appliance settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Configure alert actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connect Sensors and Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connect Sensors to Sensor Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Add pods to your appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Connect Sensors and Sensor Pods to A-Link Ports . . . . . . . . . . . . . . . . . . . . . . 21

Connect a wireless sensor network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Install a third-party wireless network device . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Connect a USB modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connect a USB digital I/O device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connect an APC by Schneider Electric Switched Rack PDU . . . . . . . . . . . . . . . 25

Connect external sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Software Upgrades. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Care and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Specifications.......................................................................................................27

Sensor Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

NetBotz Rack Monitor 450/550/570 Installation and Quick i

Two-Year Factory Warranty ................................................................................29

Terms of warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Non-transferable warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Exclusions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Warranty claims . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

NetBotz Rack Monitor 450/550/570 Installation and Quick ii

Important Safety Information

Read the instructions carefully to become familiar with the equipment before trying to install, operate, service or maintain it. The following messages may appear throughout this manual or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.

The addition of this symbol to a Danger or Warning safety label indicates that an electrical hazard exists which will result in personal injury if the instructions are not followed.

This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

DANGER

DANGER indicates an imminently hazardous situation which, if not avoided, will result in death

or serious injury.

WARNING

WARNIN G indicates a potentially hazardous situation which, if not avoided, can result in death

or serious injury.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided, can result in minor

or moderate injury.

NOTICE

NOTICE addresses practices not related to physical injury including certain environmental hazards, potential damage or loss of data.

Please Note

Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility is assumed by APC by Schneider Electric for any consequences arising out of the use of this material.

A qualified person is one who has skills and knowledge related to the construction, installation, and operation of electrical equipment and has received safety training to recognize and avoid the hazards involved.

1NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Safety Information for your NetBotz Appliance

DANGER

HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH

• No user-serviceable parts inside. Refer servicing to qualified personnel.

• Use indoors only in a dry location.

• Ensure the power input for the appliance has a reliable ground (earth) connection.

• The appliance is intended to be installed and operated by a skilled person in a controlled location with restricted access.

• Disconnect the load power cord from this product before servicing the load equipment or the power cord.

Failure to follow these instructions will result in death or serious injury.

CAUTION

FALLING EQUIPMENT HAZARD

• Do not create a hazardous condition due to uneven mechanical loading. For example, do not use the appliance as a shelf.

• Ensure the appliance is mounted securely and evenly.

Failure to follow these instructions can result in injury or equipment damage.

NOTICE

EQUIPMENT DAMAGE HAZARD

The ambient operating temperature of a closed or multi-unit rack environment may be greater than the ambient temperature of the room. Ensure the ambient operating temperature of your rack environment does not exceed the rated ambient operating temperature for the appliance.

Failure to follow these instructions can result in injury or equipment damage.

The appliance is suitable for installation in Information Technology Rooms in accordance with Article 645 of the National Electric Code and NFPA 75.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual2

Introduction

Product Description

The APC by Schneider Electric NetBotz® Rack Monitor 570, Rack Monitor 550 or Rack Monitor 450 functions as the central hardware appliance for a NetBotz security and environmental monitoring system. The rack-mountable appliance includes multiple ports for connecting APC by Schneider Electric environmental sensors and other third-party sensors. The appliances include additional ports that provide power to or allow control over other devices. With a NetBotz 570, 550, or 450, you can increase the space monitored. With a NetBotz 570 or 550, you can add up to twelve NetBotz sensor pods. With a NetBotz 450, you can add up to two NetBotz sensor pods.

NOTE: To get the latest features, update the firmware before using your appliance. Go to

www.apc.com to download updates for this product.

Document Overview

The NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual describes how to install a NetBotz Rack Monitor 450, 550, or 570, how to connect devices to the appliances, and how to configure network settings. After performing the configuration procedures in this manual, you can access your system through its software interface, perform additional configuration tasks, and begin monitoring the environment.

Additional Options

The following options are available for the appliance. For more information about any of the options, contact your APC by Schneider Electric representative or the distributor from whom you purchased your APC by Schneider Electric product.

• NetBotz Camera Pod 160 (NBPD0160/NBPD0160A*)

• NetBotz Rack Sensor Pod 150 (NBPD0150)

• NetBotz Room Sensor Pod 155 (NBPD0155)

• Temperature Sensor (AP9335T)

• Temperature/Humidity Sensor (AP9335TH)

• Temperature Sensor with Digital Display (AP9520T)

• Temperature/Humidity Sensor with Digital Display (AP9520TH)

• Alarm Beacon (AP9324)

• NetBotz Spot Fluid Sensor (NBES0301)

• NetBotz Door Switch Sensor for Rooms or Third Party Racks (NBES0302)

• NetBotz Door Switch Sensor for APC by Schneider Electric Racks (NBES0303)

• NetBotz Dry Contact Cable (NBES0304)

• NetBotz 0-5 V Sensor Cable (NBES0305)

• NetBotz Vibration Sensor (NBES0306)

• NetBotz Smoke Sensor (NBES0307)

• NetBotz Rope Leak Sensor (NBES0308)

• NetBotz Rope Leak Extension (NBES0309)

• NetBotz Particle Sensor PS100 (NBES0201)

• NetBotz USB-to-Serial Cable (NBAC0226)

• Power Supply 100-240 VAC/24 VDC (AP9505i)

• NetBotz 4-20mA Sensor Pod (NBPD0129)

• NetBotz CCTV Adapter 120 with USB Cable (NBPD0123)

• NetBotz Sensor Pod 120 (NBPD0122)

• NetBotz Camera Pod 120 (NBPD0121)

• NetBotz Rack Access Pod 170 (NBPD0170) (for NBRK0550 and NBRK0570 only)

• NetBotz Rack Access Electronic Handle (NBHN0170)

(for NBRK0550 and NBRK0570 only)

• NetBotz Wireless Sensor Pod 180 (NBPD180)

• NetBotz USB Coordinator & Router (NBWC100U)

• NetBotz Wireless Temperature Sensor (NBWS100T and NBWS100H)

NBHN017BHN0171

*NBPD0160A is only compatible with BotzWare v4.6.1 and newer.

StruxureWare certified

This product is certified for use in StruxureWare® systems.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual4

Physical Description

MAC ADDRESS

LABEL

AC Line Inlet

123

564

Sensors

4-20mA Inputs

MODEL/SN

885-349 7A

aem0230b

Item Description

AC line inlet Provides for the input power connection; see “Specifications” on page 27 for



voltage information.

Reset switch Resets the appliance.



Port activity LED Flashes green when the RS485 port is receiving. Only available on the



NBRK0570 appliance.

RS485 port Provides for a Modbus connection. Only available on the NBRK0570 appliance.



10/100 Base-T



Network Port

Alert LED Indicates the alert status of the system. When more than one alert exists, the



Provides for a 10/100 Base-T network connection. Status and link LEDs indicate network traffic:

• Status LED—blinks orange and green at start-up; indicates the status of the network connection (solid green—IP address established; blinking green— attempting to obtain an IP address).

• Link LED—blinks to indicate network traffic (green—connected at 10 Mbps; orange—connected at 100 Mbps).

most severe will be indicated.

• Flashing once every eight seconds—Informational

• Flashing once every four seconds—Warning

• Flashing once every two seconds—Error

• Flashing once every second—Critical

• Flashing twice per second—Failure

Voltage Output Provides 12 VDC or 24 VDC (75 mA) to one connected device.



Relay Output Ports 1, 2

Power LED Indicates whether the unit is receiving power (green—receiving power; dark—not



Used for connecting relay-controlled external devices. Provides 24 VDC (100mA) each.

receiving power).

4-20 mA Inputs Provides 24 VDC for connecting third-party sensors with an input current range



from 4 to 20 mA.

Sensor ports Used for connecting APC by Schneider Electric sensors, third-party dry-contact



sensors, and standard third-party 0-5 V sensors. (See “Additional Options” on page 4 for details on sensor options.) Third-party dry-contact state sensors require the NetBotz Dry Contact Cable (NBES0304). Standard third-party 0-5 V

Leak Rope port Used for connecting a NetBotz Rope Leak Sensor (NBES0308)



Beacon port Used for connecting an Alarm Beacon (AP9324).



sensors require the NetBotz 0-5 V Sensor Cable (NBES0305). NBRK0450/550 5/24 VDC (50mA). NBRK0570 - 5/24 VDC (200mA).

5NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Item Description

A-Link port Used for cascading NetBotz sensor pods and temperature and humidity sensors



with digital displays. Provides communications and power to the connected devices over standard CAT-5 cabling with straight-through wiring. For details, see “Connect Sensors and Sensor Pods to A-Link Ports” on page 21.

Alert LED Same as item 4 above.



Power LED Indicates whether the unit is receiving power (green—receiving power;



dark—not receiving power).

Console Port Used to connect a console to the appliance. Enable the USB-to-serial converter



support (FTDI) in your operating system.

USB Type A ports



(2 or 4)

Exhaust fan Exhausts hot air from the NBRK0570. Not present on the NBRK550 or NBRK450.



Used to connect USB devices to the appliance. The NBRK0550 and NBRK0450 have two USB ports, while the NBRK0570 has four.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual6

Inventory

aem031 4c

Inspect the package and contents for shipping damage. Make sure all parts were sent. Immediately report any shipping damage to the shipping agent. Report missing contents, product damage, or other problems with the product to APC by Schneider Electric or your Schneider Electric reseller.

The shipping and packaging materials are recyclable. Please save them for later use or dispose of them appropriately.

Item Description

NetBotz Rack Monitor 450, Rack Monitor 550 or Rack Monitor 570



Brackets for a standard 19-in rack



M4 x 8 Phillips flat-head screws



Power cord retainer bracket



8-position terminal block plug



9-position terminal block plug



203-mm (8-in) tie wraps



203-mm (8-in) hook and loop cable strap



1.8-m (6-ft) IEC-320-C13 to IEC-320-C14 power cord



1.8-m (6-ft) NEMA 5-15P to IEC-320-C13 power cord



5-m (16.4-ft) USB cable



3-position terminal block plug



Temperature/Humidity Sensor (AP9335TH)—not shown

7NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Installation

ns1768a

gen0188a

Install the Appliance

Install the appliance in the front or the rear of the rack or enclosure using the rack-mount procedure, which requires 1 U of rack space. When installing the appliance, take into consideration the following:

NOTICE

Only connect approved devices to ports on the appliance as directed in this manual. Plugging in other devices may result in equipment damage.

Install the appliance in an environment compatible with the maximum ambient temperature (Tma) specified in “Specifications” on page 27. Appliances installed in a closed or multi-unit rack assembly can experience a greater operating ambient temperature than the ambient room temperature.

Install the appliance in a way that allows sufficient airflow for safe operation.

NOTICE

When you install the appliance in the rack, be sure that you do not create a hazardous condition due to uneven mechanical loading. For example, do not use the appliance as a shelf.

Cage Nuts

CAUTION

FALLING EQUIPMENT HAZARD

Do NOT install cage nuts vertically with the ears engaging the top and bottom of the square hole.

Failure to follow these instructions can result in injury or equipment damage.

Install a cage nut . APC by Schneider Electric offers a cage nut hardware kit (AR8100) for use with

square holes.

1. Install cage nuts horizontally, with the ears engaging the sides of the square hole. Insert the cage nut into the square hole by hooking one ear of the cage nut assembly through the far side of the hole.

NOTE: Install the cage nuts on the interior of the vertical mounting rail.

2. Place the cage nut tool on the other side of the cage nut and pull to snap it into position.

Remove a cage nut.

1. Remove any attached screw.

2. Grasp the cage nut and squeeze the sides to release it from the square hole.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual8

Rack-mount installation

1 U

ns0014 a



M4 x 8 Phillips flat-head screws



Bracket



Power cord retainer bracket

aem0208a

To avoid equipment damage, use only the hardware provided when installing the brackets.

1. Choose a location for the appliance in the front or rear of the rack. The appliance occupies one U-space. A notched hole or a number on the rack vertical rail denotes the middle of a U-space.

2. Install the brackets ( and ), including the power cord retainer bracket, on the end nearest the AC Line Inlet.

NOTICE

aem0233b

3. Secure the appliance to the rack, using cage nuts and screws (not provided).

9NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Power cord and network cable connections

NOTICE

Before you energize the appliance, review the electrical specifications on page 27 to avoid overloading the circuit. Make sure you properly ground the appliance by plugging the power cord directly into a wall outlet or by verifying the ground path if using a power strip.

The power cords provided are to be used only with APC by Schneider Electric NetBotz products.

1. Connect the appropriate power cord to the AC Line Inlet of the appliance.

2. Secure the power cord to the power cord retainer bracket using the tie wraps.

3. Connect a network cable to the 10/100 Base-T Network Port on the appliance.

4. Plug the power cord into a power source.

5. Use the hook and loop cable strap to secure the cables.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual10

Initial Configuration

NOTE: Disregard the procedures in this section if you have a StruxureWare Data Center Expert server

as part of your system. See the documentation for your StruxureWare device for more information.

You must configure the following TCP/IP settings before the appliance can operate on a network:

• IP address of the appliance

• Subnet mask

• Default gateway

NOTE: If a default gateway is unavailable, use the IP address of a computer that is located on the same subnet as the appliance and that is usually running. The appliance uses the default gateway to test the network when traffic is very light.

You can obtain TCP/IP settings automatically through DHCP, or configure them manually with a terminal emulator or the Serial Configuration Utility.

before you can access the Serial Configuration Utility. Follow steps 1-4 of “Configure network settings using a terminal emulator” on page 11 to change the root password.

Obtain network settings using DHCP

By default, your appliance obtains its network settings using DHCP. When you connect the appliance to your network and apply power to the unit, it automatically attempts to contact a DHCP server. The appliance waits 30 seconds for a response.

If the DHCP server is configured to provide a hostname, the appliance requests either its configured hostname or ‘netbotzxxxxxx’ (where xxxxxx is the last 6 digits of the MAC address of the appliance) as a hostname associated with the IP address granted by the DHCP server. You can then use a Web browser to connect to the appliance using the address http://netbotzxxxxxx without any additional configuration.

You must use a terminal emulator to change the root password

The appliance also requests DNS server addresses, a DNS domain, SMTP server addresses, and NTP server addresses from the DHCP server.

Configure network settings using a terminal emulator

1. Connect a USB A to USB mini B cable to the Console Port on the NetBotz appliance and a USB port on your computer.

2. Plug the power cord provided with your NetBotz appliance into a wall outlet, and then connect it to the AC line inlet. The green Power LED illuminates immediately after you apply power to the appliance. The unit can take up to two minutes to initialize, depending on appliance configuration. The red Alert LED illuminates when the appliance detects an alert condition.

3. Open a serial connection on your terminal emulator using port settings 38400 baud, 8, 1, N.

4. Enter the root account user name and password for the appliance (root/apc, by default). Then change the password when prompted. It is recommended that you use a strong password that conforms to your company’s password requirements.

5. Specify the network settings of your appliance to use network settings assigned by a DHCP server, or provide an IP address, subnet mask, and gateway address for the appliance. You can specify a NAT proxy name or IP address to be used by a NAT Proxy server in your network to allow users to connect to the appliance from outside the firewall. You can also specify speed and duplex settings for use by this interface, or use Auto Negotiate.

6. Close the terminal emulator. Test the IP connection of the NetBotz appliance. Start your Web browser and type https://your_appliance_IP into the address field. Press Enter. If the appliance is online and properly configured, the Web UI displays in the browser window.

11NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Configure network settings using the Serial Configuration Utility

The serial configuration utility is automatically installed with Advanced View (see “Install Advanced View” on page 14). To configure your appliance using the Serial Configuration Utility:

1. Click Start > Programs > NetBotz > Serial Configuration > Serial Configuration Utility to start

the Serial Configuration Utility.

2. Connect one end of a USB cable to your computer and the other end of the cable to the Console port on the NetBotz appliance.

3. Plug the power cord provided with your NetBotz appliance into a wall outlet, and then connect it to the AC line inlet.

NOTE: Use only the provided power cord with NetBotz products.

The green Power LED illuminates immediately after you apply power to the appliance. The unit can take up to two minutes to initialize, depending on appliance configuration. The red Alert LED illuminates when the appliance detects an alert condition. Click Next to continue.

4. The Serial Configuration Utility automatically scans your system COM ports to determine if a NetBotz appliance is connected to the network. If an appliance is discovered, the appliance is listed in the Device column of the window. Select the radio button for the appliance to configure and click

Next to continue.

NOTE: If the COM port associated with the port to which your USB cable is connected is currently in

use by another application, the message beside the COM port in the Owner column indicates that the port is not available. To correct this, close the application that is using the COM port and click Scan Serial Ports.

5. The Root Password window appears. Enter the root password and click OK.

6. Specify whether to use DHCP to specify the network settings of your appliance. Click Yes or No, and click Next to continue.

7. The utility scans the appliance and displays the network settings stored on the appliance. The network settings are divided into Ethernet Card Settings and DNS Settings.

8. Specify the Ethernet Card settings.

–To use network settings assigned by a DHCP server, select Configure automatically via DHCP. –To specify network settings for use by this appliance, select Configure using these settings and

provide an IP address, subnet mask, and gateway address for the appliance. Specify a NAT proxy name or IP address to be used by a NAT Proxy server in your network to allow users to connect to the appliance from outside the firewall. You can also specify speed and duplex settings for use by this interface, or use the default setting, Auto Negotiate.

9. Specify the DNS Settings.

–To use DNS Settings provided by your DHCP server, select

Use DHCP DNS Settings.

–To specify DNS Settings for this appliance manually, clear the Use DHCP DNS Settings check box

and provide the domain and DNS server information.

10. Click Next to save your configuration settings. Click Finish to close the Serial Configuration Utility.

11. Test the IP connection of the NetBotz appliance. Start your Web browser and type the IP address of the appliance into the address field. Press Enter. If the appliance is online and properly configured, the Basic View displays in the browser window.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual12

Access an Appliance

After the appliance is running on your network, you can access the configured appliance through the Web UI or Advanced View.

NOTE: You must change the root password before you can access the Web UI or Advanced View. Follow steps 1-4 of “Configure network settings using a terminal emulator” on page 11 to change the root password.

Web UI

The NetBotz Web UI provides a real-time overview of alerts and device details, including sensor readings and images captured by camera pods, for a NetBotz appliance running version 4.2 and above.

To access the Web UI, enter https://your_appliance_IP_address into the URL address bar of your Web browser. (See the Release Notes on www.apc.com for a list of supported Web browsers. If needed, you can use Advanced View to enable HTTP.)

You may receive a message that the Web page is not secure. This is normal, and you can continue to the Web UI. The warning is generated because your Web browser does not automatically trust the selfsigned certificate installed on your appliance. However, the certificate is still used to encrypt information transmitted over HTTPS. You can direct the Web browser to accept the default certificate permanently or install a CA-signed certificate to stop the warning. See the User Guide on www.apc.com for more information about certificates.

Log on to the appliance (the default user name is apc, and the default password is the password for the Root account).

NOTE: You can use the Advanced View Users task to change the default User ID and Password.

13NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Advanced View

Use Advanced View to view sensor data, camera images, and other appliance data in a custom Java application. You can also use Advanced View to generate relay output actions and configure all appliance features. Advanced View is a stand-alone application that must be installed on a supported network-attached computer. For more information on using Advanced View, see the User Guide on

www.apc.com.

NOTE: Advanced View is not supported on mobile devices.

Install Advanced View. NOTE: The Java Runtime Environment used by Advanced View is always

installed, regardless of whether the installation target already has a suitable JRE installed.

Microsoft

Windows 8, 10, 7 Pro, Windows Vista

install.exe from www.apc.com. Follow the prompts to complete the installation of your software.

Linux Systems: To install the applications and the JRE on a computer running Red Hat

Linux to complete the installation of your software.

Access an Appliance with Advanced View. Before using Advanced View to manage an appliance,

you must first add the appliance IP address or hostname to the Appliance list. To add an appliance to the Appliance list:

Windows® Systems: To install the applications and the JRE on a computer running

5 or 7 or Fedora™ 12 or 24, download install.bin from www.apc.com. Follow the prompts

Enterprise, or Windows Vista Business, download

Enterprise

1. Click Add Appliance. The Add Host Device window opens.

2. In the IP Address or Hostname field, type the IP address or hostname of the appliance.

3. In the Port field, type the TCP port through which you will communicate with this appliance.

4. To use SSL encryption to communicate with this appliance, select Connect Using SSL. NOTE: HTTP is disabled by default. Until you enable HTTP, you must select this option.

5. If you want to be logged out after a period of inactivity, select Auto Logoff and specify the length of idle time before you are logged out in the provided field. Click OK.

You may receive an Untrusted certificate warning. This is normal on first startup, and you can proceed to the appliance. The warning is generated because the default certificate is self-signed, rather than being signed by a trusted Certificate Authority. However, the certificate still allows your information to be encrypted over SSL. You can direct Advanced View to Accept this

certificate permanently or install a CA-signed certificate to stop the warning. See the User Guide on www.apc.com for more information about certificates.

6. Log on to the appliance. (On first startup, the User name is apc and the Password is the Root password).

NOTE: To increase security, use the Advanced View Users task to change the default User ID and Password.

7. The NetBotz Configuration Wizard opens. See “The NetBotz Configuration Wizard.” on page 15 and the User Guide on www.apc.com for more information on the Configuration Wizard, or select Close to go to your appliance.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual14

The NetBotz Configuration Wizard. The Configuration Wizard runs each time you use Advanced

View with your NetBotz appliance until you complete all of the steps in the Wizard, or until you select

Don’t Show Configuration Wizard Next Time. You can run the Wizard again by selecting Configuration Wizard from the Advanced View Tools drop-down list.

You can use the Configuration Wizard to configure the following settings on your appliance:

• Domain Name Server Settings

• Clock and Calendar Settings

• Region Settings

• Administrator User ID and Password

• E-Mail Settings

• E-Mail Alert Notification Recipients

The Configuration Wizard downloads the latest available version of BotzWare to your appliance.

When you finish configuring your appliance with the Wizard, your appliance monitors your environment for lack of adequate air flow and for changes in temperature and humidity and detects motion in the area in which the camera is located. Alert conditions detected by any of these sensors generate an email to send to a specified email address.

Types of User Accounts

Your appliance has a pre-configured Administrator account and Root account. You must change the Root account password before you can access the Administrator account. After you set the Root account password, you can use the Administrator account to access the Web UI or Advanced View using the Root password and the default user ID (apc).

The Root account is used only for communications that are performed with the USB Console Port, e.g., when you use the Serial Configuration Utility to specify network settings. The default user ID is root and the password is apc.

NOTE:

Change Root Password tool to change the root account password.

You cannot change the root account user ID. After initial log on, you can use the Advanced View

15NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

NetBotz Quick Configuration

Once you configure, install, and apply power to your appliance, use Advanced View to perform the following procedures.

• Configure Appliance Settings: Configure the appliance Clock, DNS, Region, Network Interface

(hostname, NAT proxy, and speed and duplex settings), E-mail Servers, and Proxy settings.

• Configure Alert Actions: Configure the Play Audio Alert and Primary E-mail Notification alert

actions.

Configure appliance settings

Open Advanced View and perform the following Appliance Settings tasks. The icons associated with each task are located in the Configuration pane, in the Appliance Settings region.

1. Set the Clock settings. By default, your appliance synchronizes the system clock with the default NTP servers. If network access to these servers is not permitted, double-click on the Clock icon and specify your NTP server address or manually specify clock settings.

2. Set DNS settings. Double-click the DNS icon and specify the DNS Domain and at least one DNS Server address.

3. Set the Region settings. Double-click the Region icon and set Locale and Time Zone. The default settings are US and Central Standard Time.

4. Specify a hostname for your appliance. Double-click on Network Interfaces and specify a hostname for your appliance. Optionally, specify a NAT proxy name or IP address to be used by a NAT Proxy server in your network to allow users connect to the appliance from outside the firewall. You can also specify speed and duplex settings for use by this interface, or use the default setting, Auto Negotiate.

5. Assign a unique User ID and Password to the Administrator account. By default, User ID and Password for the Administrator account are both apc. To increase security, double-click the Users icon, double-click NetBotz Admin Account, and specify a unique User ID and password for the administrator account.

6. Set your email server settings. This is the email server that your appliance uses to deliver email alert notifications. Double-click the E-mail Servers icon, and configure the following settings:

a. (Optional) Provide a From address.

b. In the SMTP server field, type the hostname or IP address of your SMTP server (for

example, mail.yourcompany.com).

c. If necessary, specify a Port value (25, by default).

d. Select an SSL option for authentication and certificate verification. Check with your

network administrator for further assistance.

e. Click Test E-mail Server, type in your email address, and click OK. An email is sent to your

address when an alert is detected. Confirm that you received the test email and continue.

7. If your network uses an HTTP or Socks proxy server, double-click the Proxy icon and specify your Proxy settings. If you are unsure whether you use an HTTP or Socks proxy, check with your network administrator.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual16

Configure alert actions

You can configure your appliance to play audio alert notifications through the headphone/speaker jack on your Camera Pod 160 or Sensor Pod 120 or to send an email alert notification to your email address when sensor thresholds are violated.

Open Advanced View and perform the following Pod/Alerts Settings tasks. The icons associated with each task are located in the Configuration pane, in the Pod/Alerts Settings region.

1. Open the Alert Actions task. Double-click the Alert Actions icon to open the Alert Action

Configuration window.

2. Click Add... to open the Select Alert Action window, select Play Audio Alert and click OK to

open the Add Alert Action window.

3. In the Alert Action Name field, type a name for this alert action (for example, Play Audio Alert).

4. Select your Camera Pod from the Output Device drop box. Optionally, adjust the Volume%

setting.

5. Click OK to close the Add Alert Action window and continue. Your newly created alert action is

included in the list of Alert Actions.

6. Select Primary E-mail Notification from the list of defined alert actions and click Edit.

7. Check Include a sound clip with the alert. This ensures that any alert emailed to you includes

a sound clip with any camera images that are delivered. You can disable this option later, if the file size of alert notifications is too large.

8. Click Add..., type your email address in the Add E-mail Address window, and click OK.

9. Click OK to close the Edit Alert Action window and continue.

Click OK to close the Alert Action Configuration window.

17NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Connect Sensors and Devices

Connect Sensors to Sensor Ports

This procedure applies to the following sensors, which are supported by the appliance and connect to the sensor ports:

• Temperature Sensor (AP9335T)

• Temperature/Humidity Sensor (AP9335TH)

• NetBotz Vibration Sensor (NBES0306)

• NetBotz Smoke Sensor (NBES0307)

• NetBotz Spot Fluid Sensor (NBES0301)

• NetBotz 0-5 V Sensor Cable (NBES0305)

• NetBotz Door Switch Sensor for APC by Schneider Electric Racks (NBES0303)

• NetBotz Door Switch Sensor for Rooms or Third Party Racks (NBES0302)

• NetBotz Dry Contact Cable (NBES0304)

Connect APC by Schneider Electric and third-party sensors to the six sensor ports labeled Sensors on the appliance.

• Third-party dry contact sensors require the NetBotz Dry Contact Cable (NBES0304). To connect a

sensor to the cable, follow the instructions provided with the sensor and the instructions provided with the cable.

• Standard third-party 0-5 V sensors require the NetBotz 0-5 V Sensor Cable (NBES0305). To

connect a sensor to the cable, follow the instructions provided with the sensor and the instructions provided with the cable.

• If a sensor cable is not long enough, use an RJ-45 coupling (provided with some sensors) and

standard CAT-5 cabling to extend the cable up to 15 m (50 ft) for a Temperature/Humidity Sensor (AP9335TH) or a Temperature Sensor (AP9335T) and up to 30.5 m (100 ft) for all other supported sensors.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual18

Add pods to your appliance

The NetBotz Rack Monitor supports the following pods:

Pod Type Rack Monitor 570 Rack Monitor 550 Rack Monitor 450

Camera Pod 160 total of 4 pods total of 4 pods* total of 2 pods Camera Pod 120 CCTV Adapter Pod 120 Sensor Pod 150 total of 12 pods total of 12 pods total of 2 pods Sensor Pod 155 Sensor Pod 120 4-20 mA Input Pod 120 Smoke Sensor 2 2 2 AP9520 Temp/Humidity

Probe (A-Link) Rack Access Pod 170** 13 13 -

* Installing four camera pods requires an external USB hub. ** Installing more than four Rack Access Pods requires a AP9505i power supply for every four

pods after the first.

NOTE: For sensors that connect to A-Link ports (AP9520T/H, Sensor Pod 150/155, and Rack Access Pod 170 units), see “Connect Sensors and Sensor Pods to A-Link Ports” on page 21.

Camera Pods, Sensor Pod 120s, and 4-20 mA Input Pod 120s can be connected directly to any of the appliance USB ports, or you can connect USB hubs to your appliance and then connect pods to the hub. Hubs can also be daisy chained, and pods can be connected to the daisy-chained hubs as long as the pod is no more than the fifth device in the chain.

888

NOTICE

Due to power requirements, Camera Pod 160s, Sensor Pod 120s, CCTV Adapter Pod 120s, and 4-20 mA Input Pod 120s must be connected either directly to one of the USB ports at the appliance or to a USB hub receiving power from an external source. RS232-based sensors or devices can be connected to unpowered USB hubs.

As pods are connected to your appliance, they automatically appear in the Navigation pane in both the Web UI and Advanced View interfaces. Newly added pods are labeled by their pod type and their serial number.

• Once connected, CCTV Adapter Pod 120s require additional configuration before they can be used. For more information, see “Install and configure a CCTV Adapter Pod 120” on page 20.

• If you connect a pod and then disconnect it, its entry in the Navigation pane in Advanced View is grayed out. If you reconnect a disconnected pod, its Navigation pane entry becomes active again.

19NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Install and configure a CCTV Adapter Pod 120. To install a CCTV Adapter Pod 120, connect your

video source to the appropriate DIN, BNC, or RCA video input jack on the pod. Use the USB cable to connect your pod to your NetBotz appliance, or to a USB hub connected to the appliance. To reduce radio frequency noise and emissions from the USB cable, clamp one clamp-on ferrite onto the USB cable within 51-76 mm (2-3 in) of the end that connects to the pod, and the second clamp-on ferrite onto the USB cable within 51-76 mm (2-3 in) of the end that connects to your appliance or to the USB hub.

After you connect your CCTV Adapter Pod 120 and video source to your appliance, use Advanced View to configure the pod.

To configure your pod:

1. Start Advanced View. From the Appliance drop-down list, select the IP address of the appliance to which you have connected the CCTV Adapter Pod 120. Log in to the appliance using a user account that has administrator privileges. After you log in, confirm that the newly connected CCTV Adapter Pod 120 appears in the Navigation Pane. The default label for CCTV Adapter Pod 120s is CCTV Video Pod serial, where serial is the serial number of the pod.

2. Select the Configuration button and double-click the Camera Pods icon (located in the Pod/ Sensor Settings portion of the Configuration pane).

3. In the Camera Pod Configuration pane, select the entry that corresponds to the CCTV Adapter Pod 120 and then click Capture.

4. The Camera Capture Settings window opens. In addition to the fields that are available when you use this window to configure Camera Pod 160s, one additional control is available when you configure a CCTV Adapter Pod 120:

Video Format: Used to specify the format in which video is transmitted by the video source. Available selections include: NTSC-M, NTSC-Japan, PAL-B, PAL-D, PAL-G, PAL-H, PAL-I, PAL-M, PAL-N Combination, and SECAM.

5. Use the controls in the Camera Capture Settings window to configure the camera and image capture settings for use with the pod. To see an example of an image capture using the currently selected Video Format, Brightness, Contrast, and Image Quality settings, click Apply. The sample image in the Capture window will be updated using the new values. When you are finished, click OK to save your changes to the appliance.

Your video source should now appear in the Advanced View Cameras pane. Once configured, you can use the video source in the same ways you use Camera Pod 160s.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual20

Connect Sensors and Sensor Pods to A-Link Ports

(NBRK0450)

(NBPD0150)

Rack Sensor

Pod 150

NetBotz

NetBotz Rack

Monitor 450

(NBPD0150)

Rack Sensor

Pod 150

NetBotz

(AP9520TH)

Humidity

Sensor

Temperature/

aem0 243a

With a NetBotz 550 or NetBotz 570, you can cascade up to a combined total of twelve NetBotz Rack Sensor Pod 150s (NBPD0150) and NetBotz Room Sensor Pod 155s (NBPD0155) plus up to a combined total of eight Temperature Sensors with Digital Display (AP9520T) and Temperature/Humidity Sensors with Digital Display (AP9520TH). In addition, you can cascade up to a total of thirteen Rack Access Pod 170s.

With a NetBotz 450, you can cascade up to a combined total of two NetBotz Rack Sensor Pod 150s (NBPD0150) and NetBotz Room Sensor Pod 155s (NBPD0155), plus up to a combined total of eight Temperature Sensors with Digital Display (AP9520T) and Temperature/Humidity Sensors with Digital Display (AP9520TH).

You cannot cascade appliances. Use one appliance per system. A-Link is an APC by Schneider Electric proprietary CAN (Controller Area Network) bus. Devices compatible with A-Link are not Ethernet devices and cannot coexist on an Ethernet bus with other networking devices, such as hubs and switches.

Before performing this procedure, follow the installation instructions provided with the devices you are cascading. If you cascade more than ten sensor pods, be sure you have a supplemental power supply (Power Supply 100-240 VAC/24 VDC—AP9505i) to connect to your system as directed in this procedure. If you cascade more than four Rack Access Pod 170s, you will need an additional power supply for every four Rack Access Pods. The NetBotz 570 does not require an external power supply.

NOTICE

Do not use crossover cables.

1. Connect sensors and sensor pods to the appliance as shown.

– Use CAT-5 (or equivalent) Ethernet

patch cables (.

– Connect to in and out ports as shown.

– The maximum combined length of all

A-Link cables must not exceed 1000 m (3,280 ft).

2. Plug an A-Link terminator into the unused A-Link port (). NOTE: The first time a sensor pod receives power, it obtains a unique identification address for communication over the A-Link bus. To avoid communication problems, you must complete steps 1 and 2 before you connect a supplemental power supply.

3. With a Rack Monitor 450 or 550, if you have cascaded ten or more devices, connect one supplemental power supply (AP9505i) to the 24 VDC Input jack of the Rack Sensor Pod 150 or the Room Sensor Pod 155 in or closest to the eleventh position.

-Link

21NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Connect a wireless sensor network

NOTICE

Only the devices listed here are compatible with the NetBotz wireless sensor network. Other devices will not function and may damage the appliance and other wireless devices.

You can connect a wireless sensor network to a NetBotz appliance, v4.4 and above, to monitor temperature and humidity.

The wireless sensor network is made of a host appliance, a coordinator, routers, and end devices.

• The host appliance

network and generates alerts based on sensor readings.

• The coordinator is connected directly to the host appliance via USB. It reports data from the

sensors on the network and provides available firmware updates to the wireless network. Each wireless sensor network must have only one coordinator, which is connected to a USB Type A port on the NetBotz appliance.

• Routers extend the range of the wireless sensor network. Routers pass information between

themselves and the coordinator, and between the coordinator and end devices. Routers are optional. In a data center environment where obstructions are common, routers are recommended if sensors are more than 50 feet from the coordinator. Each router is powered by an AC-USB adapter, not directly connected to the NetBotz appliance.

• End devices monitor attached and internal sensors and send data back to the host appliance

through the network. End devices are powered by batteries.

The following devices can be configured on your wireless network:

(the Rack Monitor or Room Monitor) collects data from the wireless sensor

Wireless Device Network Role

USB Coordinator & Router (NBWC100U) coordinator or router Wireless Sensor Pod 180 (NBPD0180) coordinator, router, or end device

Wireless Temperature Sensor (NBWS100T/NBWS100H) end device

NOTE: Wireless devices have a maximum range of 100 ft, line of sight. In a data center environment where obstructions are common, a range of 50 feet is typical.

NOTE: You can connect additional sensors to the Wireless Sensor Pod 180. See the documentation that comes with your sensor pod for more information.

The NetBotz Room Monitor 455 and Rack Monitor 450, 550, and 570 appliances support a total of 48 wireless devices on the wireless sensor network, including the Coordinator and Routers.

NOTE: In NetBotz versions prior to v4.5.3, the NetBotz Rack Monitor 450 appliance supports a total of 26 wireless devices on the wireless sensor network, including the Coordinator and Routers.

NOTE: A total of 26 Wireless Sensor Pod 180 devices are supported on NetBotz v4.3 appliances,

including the Coordinator and Routers. The NetBotz Wireless Sensor Pod 180 is the only wireless device supported on the wireless sensor network in BotzWare v4.3 and Advanced View v4.3.

You configure the wireless sensor network in Advanced View in the following order:

• Add the extended addresses (MAC) of the wireless devices to the commission list in the Wireless Sensor Setup task.

• Apply the commission list to save it to the NetBotz appliance.

• Configure the Coordinator (Wireless Sensor Pod 180 only).

The order in which you configure your wireless sensor network and power your wireless devices is important.

For information about installing and configuring your wireless devices, see the installation manual that came with each device.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual22

Add wireless devices to Advanced View. You can add wireless sensors to the network in the

following ways:

• Enter the MAC addresses for the wireless sensors manually.

• Use any bar code or QR code scanner to save a list of MAC addresses to a text file, one address per line, and copy and paste it into the dialog.

• Use a hand-held USB scanner to manually scan the MAC address bar code on the USB Coordinator & Router label, or the QR code on the Wireless Temperature Sensor or Wireless Sensor Pod 180, directly into the dialog.

• Once the Coordinator is connected to the appliance, allow powered wireless devices to automatically join and form the network using Auto Join.

Some bar code and QR code scanners return the part number, serial number, and MAC address on one line: XN:NBWC100U%SN:XXXXXX123456%MAC:00C0B70000XXXXXX. To add a sensor to your wireless network, enter only the alphanumeric MAC address of each sensor in the “Add Addresses” dialog in Advanced View.

USB scanner. When you use a USB scanner with document capture capabilities, only the extended

address (MAC) of each wireless device will appear in the list in Advanced View in the correct format.

1. Attach a hand-held USB scanner with document capture capabilities to a computer running the

NetBotz Advanced View.

2. With Advanced View open to the “Add Addresses” dialog in the Wireless Sensor Setup task, scan

the QR code on the label of each wireless device.

3. Click Apply Commission List to save the list to the NetBotz appliance.

Update wireless devices. Once you have added all the wireless devices to your wireless network, you

can check their current firmware revision in the Wireless Sensor Setup task. If an update is available, the Firmware Update Available button will be activated in the display.

For more information about updating your wireless devices, see the User Guide on www.apc.com.

Install a third-party wireless network device

You can install a third-party wireless network device by connecting it to the Ethernet port on the appliance using an Ethernet cable. APC by Schneider Electric currently supports the D-Link G820, a wireless Ethernet bridge.

To install and configure a third-party wireless network device, see the instructions provided with that device.

DWL-

23NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Connect a USB modem

You can enhance the network communication capabilities of your appliance by connecting a supported USB modem to your appliance. The following USB modems are supported for use with the appliance:

• MultiTech

MultiModem® GPRS

• MultiTech MultiMobile™ USB

• MultiTech MultiModem Cell

• MultiTech MultiModem Cell 3G MTCBA-H5

• MultiTech MultiModem iCell 3G MTCMR-H5

• MultiTech QuickCarrier® USB-D, MTD-H5-2.0

• Option GlobeSurfer

iCon

Connect the USB modem to your appliance, or to a USB hub that is connected to the appliance. Once the modem is recognized as a serial port by the appliance, use the Advanced View Serial Devices task to specify the modem that is associated with the serial port. Once you specify the modem model, use the Advanced View PPP/Modem task to configure your appliance for PPP communications.

To uninstall your USB modem, use the Serial Devices task in Advanced View to remove the device.

Connect a USB digital I/O device

You can increase the number of dry contact sensors that can be connected to your appliance by connecting a supported USB digital I/O device to your appliance. The following USB digital I/O devices are supported for use with the appliance:

• Sealevel

• Sealevel SeaI/O 462U (adds 96 digital I/O connections)

• Sealevel SeaI/O 463U (adds 96 digital I/O connections)

• Sealevel SeaI/O 450U (adds 16 digital I/O connections)

SeaLINK® PIO-48 (adds 48 digital I/O connections)

To connect a USB digital I/O device to your appliance:

1. Remove power from the appliance.

2. Connect the USB digital I/O device to your appliance, or to a USB hub that is connected to the appliance.

3. Apply power to the appliance.

4. Once the appliance has finished booting up, power for the digital I/O device will be recognized as a serial port by the appliance. Use the Advanced View Serial Devices task to specify the digital I/ O device that is associated with the serial port.

5. Use the Advanced View Dry Contacts task to configure any dry contact sensors you have connected to your digital I/O device.

To uninstall your USB digital I/O device, use the Serial Devices task in Advanced View to remove the device.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual24

Connect an APC by Schneider Electric Switched Rack PDU

To connect an APC by Schneider Electric Switched Rack Power Distribution Unit (PDU) to your appliance, use an FTDI USB-to-serial cable to add serial ports to your appliance. Connect your USB-toserial cable to your appliance, or to a USB hub that is connected to the appliance.

NOTE: The serial port connector on the USB-to-serial port converter cable is a male connector. If the Rack PDU you are connecting to the cable also has a male connector you will need a female-to-female connector null modem cable or converter block to connect the device to the USB-to-serial cable.

Once you connect the USB-to-serial cable to your appliance, you can connect the Rack PDU to the cable for use with your appliance.

Supported APC by Schneider Electric Switched Rack PDUs. APC by Schneider Electric

Switched Rack PDUs with firmware version 2.74 and lower are supported at this time.

Install intelligent power strips. Connect the intelligent power strip to a serial port on your USB-to-

serial cable. Use the Advanced View Serial Devices task to specify which serial port-based sensor you have connected to the appliance.

The sensor readings associated with the device will appear in the Web UI and Advanced Views once you complete installation.

To uninstall your intelligent power strip, use the Serial Devices task in Advanced View to remove the device.

Connect external sensors

To install an external sensor, plug the sensor into an available External Port on any Sensor Pod 150, Sensor Pod 155, or Sensor Pod 120.

NOTE: When connecting a sensor to a Sensor Pod 120, be sure to note both the sensor pod serial number, located on the back of the pod, and the number of the External Port on the pod when you connect the cable. You will need this information when you use the sensor pod task to configure your appliance. The External Port number is printed above the port on the pod.

The female connectors on the NetBotz 120 Sensor Pod units are Version 2, NetBotz DIN standard connectors and can only accept male, Version 2, NetBotz DIN Sensor Cables. The new Version 3 products use standard RJ-45 connectors.

If the external sensor cable is not long enough, use an Extension Cable for External Sensors, available in 15 m (50 ft) and 30 m (100 ft) lengths from your NetBotz reseller, to lengthen the cable.

When you have finished installing external sensors, use the Sensor Pods task to configure the appliance to use the external sensor. Once you configure your appliance, an additional temperature sensor appears in the Sensor Data pane when the pod to which it is connected is selected from the Navigation pane. Use the Advanced View Sensor Pods task to specify thresholds for this external sensor.

25NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Software Upgrades

The BotzWare on your appliance can be upgraded using the Upgrade task in Advanced View. The following software packs can be added to your appliance.

• Advanced Software Pack, which includes the following features:

NOTE: The features of this pack are standard on the NetBotz 570 and 550.

– Block out masking for camera images

– Digitally signed clips

– Enhanced audio features

– Detailed appliance location information

– Increased number of definable users and user capabilities

• 5 Node Scanner/IPMI Pack, which provide IPMI and SNMP scanner integration

When you upgrade your appliance, the connected pods are automatically updated. If your network includes more than one appliance, you must perform the upgrade on all appliances. Valid data is not available during the upgrade.

Care and Disposal

To clean your appliance, gently wipe the surfaces with a clean, dry cloth.

NetBotz Rack Monitor appliances contain non-replaceable, lithium coin-cell batteries. Do not attempt to replace the battery. Please take the battery into consideration when disposing of the appliance.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual26

Specifications

Electrical

Input voltage, nominal 100–240 VAC; 50/60 Hz

Maximum total current draw

Rack Monitor 450/550 Rack Monitor 570

Physical

Dimensions (H x W x D) 43.5 x 432.0 x 93.0 mm (1.7 x 17.0 x 3.7 in)

Weight

Rack Monitor 450/550 Rack Monitor 570

Environmental

Elevation (above MSL)

Operating Storage

Temperature

Operating Storage

Humidity

Operating Storage

1A 2A

1.40 kg (3.09 lb)

1.47 kg (3.24 lb)

0 to 3000 m (0 to 10,000 ft) 0 to 15 000 m (0 to 50,000 ft)

0 to 40ºC (32 to 104°F) –15 to 65°C (5 to 149°F)

0 to 95%, non-condensing 0 to 95%, non-condensing

Output Voltages

Voltages 12 VDC or 24 VDC

Current

A-Link 24V (Rack Monitor 450/550) A-Link 24V (Rack Monitor 570)

75 mA total for 12 V and 24 V load 560 mA 1000 mA

27NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Compliance

Rack Monitor 450/550

Immunity/Emissions

Rack Monitor 570

EMC

Safety

Wireless

CE, C-UL tested to CSA C22.2 No. 60950-1-3, UL 60950-1, FCC Part 15 Class A, ICES-003 Class A, VCCI Class A, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, AS/NZS CISPR 22, VDE tested to EN 60950–1

• EMC directive 2014/30/EU

• EN55024:2010, EN55022:2010+AC:2011, Class A

• FCC 47 CFR Part 15 Radiated and Conducted Emissions

• ICES-003:2012

• ASNZS CISPR:22

• VCCI V-3:2015

• cULus / UL-EU / CE - UL/EN/IEC 62368-1

• LVD 2014/35/EU

• CE - EMC Directive 2004/108/EC/

• RED Directive 2014/53/EU

• FCC 47 CFR Part 15 Radiated and Conducted

Emissions

Sensor Specifications

Temperature Sensor(AP9335T)

Temperature accuracy ±3ºF (±2ºC), from 32 to 104ºF (0 to 40ºC)

Sensor operating temperature 14 to 159ºF (–10 to 70ºC)

Maximum length of cable 50 ft (15.2 m)

Temperature/Humidity (AP9335TH)

Temperature accuracy ±3ºF (±2ºC), from 32 to 104ºF (0 to 40ºC)

Humidity accuracy ±4% RH, 20 to 90% RH, at 77ºF (25ºC)

Sensor operating temperature 14 to 159ºF (–10 to 70ºC)

User input response time 200 mS

• ICES-003:2012

• IC: 3351C-NBWC100U

• FCC ID: SNSNBWC100U

±8% RH, 30 to 80% RH, from 59 to 95ºF (15 to 30ºC)

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual28

Two-Year Factory Warranty

This warranty applies only to the products you purchase for your use in accordance with this manual.

Terms of warranty

APC by Schneider Electric warrants its products to be free from defects in materials and workmanship for a period of two years from the date of purchase. APC by Schneider Electric will repair or replace defective products covered by this warranty. This warranty does not apply to equipment that has been damaged by accident, negligence or misapplication or has been altered or modified in any way. Repair or replacement of a defective product or part thereof does not extend the original warranty period. Any parts furnished under this warranty may be new or factory-remanufactured.

Non-transferable warranty

This warranty extends only to the original purchaser who must have properly registered the product. The product may be registered at the APC by Schneider Electric website, www.apc.com.

Exclusions

APC by Schneider Electric shall not be liable under the warranty if its testing and examination disclose that the alleged defect in the product does not exist or was caused by end user’s or any third person’s misuse, negligence, improper installation or testing. Further, APC by Schneider Electric shall not be liable under the warranty for unauthorized attempts to repair or modify wrong or inadequate electrical voltage or connection, inappropriate on-site operation conditions, corrosive atmosphere, repair, installation, exposure to the elements, Acts of God, fire, theft, or installation contrary to APC by Schneider Electric recommendations or specifications or in any event if the APC by Schneider Electric serial number has been altered, defaced, or removed, or any other cause beyond the range of the intended use.

THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, BY OPERATION OF LAW OR OTHERWISE, OF PRODUCTS SOLD, SERVICED OR FURNISHED UNDER THIS AGREEMENT OR IN CONNECTION HEREWITH. APC BY SCHNEIDER ELECTRIC DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTION AND FITNESS FOR A PARTICULAR PURPOSE. APC BY SCHNEIDER ELECTRIC EXPRESS WARRANTIES WILL NOT BE ENLARGED, DIMINISHED, OR AFFECTED BY AND NO OBLIGATION OR LIABILITY WILL ARISE OUT OF, APC BY SCHNEIDER ELECTRIC RENDERING OF TECHNICAL OR OTHER ADVICE OR SERVICE IN CONNECTION WITH THE PRODUCTS. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES AND REMEDIES. THE WARRANTIES SET FORTH ABOVE CONSTITUTE APC BY SCHNEIDER ELECTRIC’S SOLE LIABILITY AND PURCHASER’S EXCLUSIVE REMEDY FOR ANY BREACH OF SUCH WARRANTIES. APC BY SCHNEIDER ELECTRIC WARRANTIES EXTEND ONLY TO PURCHASER AND ARE NOT EXTENDED TO ANY THIRD PARTIES.

IN NO EVENT SHALL APC BY SCHNEIDER ELECTRIC, ITS OFFICERS, DIRECTORS, AFFILIATES OR EMPLOYEES BE LIABLE FOR ANY FORM OF INDIRECT, SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, ARISING OUT OF THE USE, SERVICE OR INSTALLATION, OF THE PRODUCTS, WHETHER SUCH DAMAGES ARISE IN CONTRACT OR TORT, IRRESPECTIVE OF FAULT, NEGLIGENCE OR STRICT LIABILITY OR WHETHER APC BY SCHNEIDER ELECTRIC HAS BEEN ADVISED IN ADVANCE OF THE POSSIBILITY OF SUCH DAMAGES. SPECIFICALLY, APC BY SCHNEIDER ELECTRIC IS NOT LIABLE FOR ANY COSTS, SUCH AS LOST PROFITS OR REVENUE, LOSS OF EQUIPMENT, LOSS OF USE OF EQUIPMENT, LOSS OF SOFTWARE, LOSS OF DATA, COSTS OF SUBSTITUENTS, CLAIMS BY THIRD PARTIES, OR OTHERWISE.

NO SALESMAN, EMPLOYEE OR AGENT OF APC BY SCHNEIDER ELECTRIC IS AUTHORIZED TO ADD TO OR VARY THE TERMS OF THIS WARRANTY. WARRANTY TERMS MAY BE MODIFIED, IF AT ALL, ONLY IN WRITING SIGNED BY AN APC BY SCHNEIDER ELECTRIC OFFICER AND LEGAL DEPARTMENT.

29NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual

Warranty claims

Customers with warranty claims issues may access the APC by Schneider Electric customer support network through the Support page of the APC by Schneider Electric website, www.apc.com/support. Select your country from the country selection pull-down menu at the top of the Web page. Select the Support tab to obtain contact information for customer support in your region.

NetBotz Rack Monitor 450/550/570 Installation and Quick Configuration Manual30

Radio Frequency Interference

Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

USA—FCC

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with this user manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference. The user will bear sole responsibility for correcting such interference.

After an electrostatic discharge (ESD) event, the appliance may require up to 2 minutes to restart services that are necessary for normal operation. During this time, the Web interface of the appliance will be unavailable. If any necessary services or devices external to the appliance, such as a DHCP server, were affected by the ESD event, these devices also need to restart properly.

Canada—ICES

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

Japan— VCCI

This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may occur, in which case, the user may be required to take corrective actions.

この装置は、情報処理装置等電波障害自主規制協議会（VCCI）の基準に基づくクラス A 情報技術装置です。この装置を家庭環境で使用すると、電波妨害を引き起こすことがあります。この場合には、使用者が適切な対策を講ずるように要求されることがあります。

Taiwan—BSMI

警告使用者 : 這是甲類的資訊產品 , 在居住的環境中使用時 , 可能會造成射頻干擾 , 在這種情況下 , 使用者會被要求採取某些適當的對策。

Australia and New Zealand

Attention: This is a Class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.

European Union

This product is in conformity with the protection requirements of EU Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility. APC by Schneider Electric cannot accept responsibility for any failure to satisfy the protection requirements resulting from an unapproved modification of the product.

This product has been tested and found to comply with the limits for Class A Information Technology Equipment according to CISPR 22/European Standard EN 55022. The limits for Class A equipment were derived for commercial and industrial environments to provide a reasonable protection against interference with licensed communication equipment.

Attention: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

Worldwide Customer Support

Customer support for this or any other product is available at www.apc.com.

© 2020 APC by Schneider Electric. All Rights Reserved. APC, the APC logo, NetShelter, and StruxureWare are trademarks owned by Schneider Electric SE. All other brands may be trademarks of their respective owners.

5/2020990-3291L-001

APC NetBotz Quick Start Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Important Safety Information

Please Note

Safety Information for your NetBotz Appliance

Introduction

Product Description

Document Overview

Related Documents

Additional Options

StruxureWare certified

Physical Description

Inventory

Installation

Install the Appliance

Cage Nuts

Rack-mount installation

Power cord and network cable connections

Initial Configuration

Obtain network settings using DHCP

Configure network settings using a terminal emulator

Configure network settings using the Serial Configuration Utility

Access an Appliance

Web UI

Advanced View

Types of User Accounts

NetBotz Quick Configuration

Configure appliance settings

Configure alert actions

Connect Sensors and Devices

Connect Sensors to Sensor Ports

Add pods to your appliance

Connect Sensors and Sensor Pods to A-Link Ports

Connect a wireless sensor network

Install a third-party wireless network device

Connect a USB modem

Connect a USB digital I/O device

Connect an APC by Schneider Electric Switched Rack PDU

Connect external sensors

Software Upgrades

Care and Disposal

Specifications

Sensor Specifications

Two-Year Factory Warranty

Terms of warranty

Non-transferable warranty

Exclusions

Warranty claims

USA—FCC

Canada—ICES

Japan— VCCI

Taiwan—BSMI

Australia and New Zealand

European Union
