AOpen AX4T533PRO User Manual
XX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
Overview
AX4T-533 Pro
DOC. NO.: AX4T533P-OL-E0209A
1
Installation
Hardware
Drivers &
Utilities
BIOS Setup
AWARD
Glossary
Troubleshooting &
Technical Support
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
WWhhaatt’’ss iinn tthhiiss mmaannuuaall
AX4T-533 Pro .................................................................................................................................... 1
What’s in this manual ...................................................................................................................................................... 2
You Must Notice .............................................................................................................................................................. 9
Before You Start............................................................................................................................................................ 10
Overview ....................................................................................................................................................................... 11
Feature Highlight........................................................................................................................................................... 12
Quick Installation Procedure .........................................................................................................................................15
Motherboard Map .......................................................................................................................................................... 16
Block Diagram............................................................................................................................................................... 17
Hardware Installation.................................................................................................................. 18
About “User Upgrade Optional” and “Manufacture Upgrade Optional”… ....................................................................... 19
JP14 Clear CMOS Data ................................................................................................................................................20
CPU Installation ............................................................................................................................................................21
CPU Jumper-less Design ..............................................................................................................................................23
CPU and Housing Fan Connector (with H/W Monitoring) ..............................................................................................28
RIMM Sockets ............................................................................................................................................................... 30
Front Panel Connector .................................................................................................................................................. 34
ATX Power Connector ................................................................................................................................................... 35
2
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
STBY LED and BOOT LED ...........................................................................................................................................36
AC Power Auto Recovery .............................................................................................................................................. 37
IDE and Floppy Connector ............................................................................................................................................ 38
JP18 Promise ATA133 Enable/Disable Jumper ............................................................................................................. 40
IrDA Connector .............................................................................................................................................................41
AGP (Accelerated Graphic Port) Expansion Slot ...........................................................................................................42
AGP Protection Technology........................................................................................................................................... 43
CNR (Communication and Network Riser) Expansion Slot............................................................................................ 44
Support 10/100 Mbps LAN onboard .............................................................................................................................. 45
JP13 LAN Enable/Disable Jumper ................................................................................................................................46
PC99 Color Coded Back Panel ..................................................................................................................................... 47
JP28 USB Keyboard/Mouse Wakeup Select Jumper..................................................................................................... 48
Support The 2nd and 3rd USB2.0 Port ............................................................................................................................49
S/PDIF (Sony/Philips Digital Interface) Connector......................................................................................................... 50
Chassis Intrusion Sensor .............................................................................................................................................. 51
CD Audio Connector ..................................................................................................................................................... 52
AUX-IN Connector ........................................................................................................................................................ 53
Front Audio Connector ..................................................................................................................................................54
Dr. LED Connector........................................................................................................................................................ 55
3
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
JP15/JP16 Dr. Voice Language Select Jumpers ........................................................................................................... 57
JP2 Speaker and Buzzer Select Jumper .......................................................................................................................58
Battery-less and Long Life Design ................................................................................................................................ 59
Over-current Protection ................................................................................................................................................. 60
Resettable Fuse ............................................................................................................................................................ 61
2200µF Low ESR Capacitor ..........................................................................................................................................62
Layout (Frequency Isolation Wall) ................................................................................................................................. 63
Fansink on North Bridge ............................................................................................................................................... 64
Vivid BIOS technology................................................................................................................................................... 65
Open JukeBox Player.................................................................................................................................................... 66
The noise is gone!! ---- Silent PC .................................................................................................................................. 70
Driver and Utility ......................................................................................................................... 73
Auto-run Menu from Bonus CD Disc ............................................................................................................................. 74
Installing Intel IAA Driver............................................................................................................................................... 75
Installing LAN Driver .....................................................................................................................................................76
Installing Onboard Audio Driver.....................................................................................................................................79
AOConfig Utility............................................................................................................................................................. 82
PHOENIX-AWARD BIOS ................................................................................................................ 82
About BIOS Function Description… .............................................................................................................................. 83
4
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
How To Use Phoenix-Award™ BIOS Setup Program ....................................................................................................84
How To Enter BIOS Setup............................................................................................................................................. 86
BIOS Upgrade under Windows environment ................................................................................................................. 87
Overclocking ................................................................................................................................ 89
VGA Card & Hard Disk.................................................................................................................................................. 90
Glossar y ....................................................................................................................................... 91
AC97............................................................................................................................................................................. 91
ACPI (Advanced Configuration & Power Interface) .......................................................................................................91
AGP (Accelerated Graphic Port) ................................................................................................................................... 91
AMR (Audio/Modem Riser)............................................................................................................................................ 92
AOpen Bonus Pack CD ................................................................................................................................................. 92
APM (Advanced Power Management)........................................................................................................................... 92
ATA (AT Attachment) .....................................................................................................................................................92
ATA/66 ..........................................................................................................................................................................92
ATA/100 ........................................................................................................................................................................ 93
ATA/133 ........................................................................................................................................................................ 93
BIOS (Basic Input/Output System) ................................................................................................................................93
Bus Master IDE (DMA mode) ........................................................................................................................................93
CNR (Communication and Networking Riser)................................................................................................................ 94
5
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
CODEC (Coding and Decoding) .................................................................................................................................... 94
DDR (Double Data Rated) SDRAM ...............................................................................................................................94
DIMM (Dual In Line Memory Module)............................................................................................................................ 94
DMA (Direct Memory Access)........................................................................................................................................ 95
ECC (Error Checking and Correction) ...........................................................................................................................95
EDO (Extended Data Output) Memory ..........................................................................................................................95
EEPROM (Electronic Erasable Programmable ROM).................................................................................................... 95
EPROM (Erasable Programmable ROM) ...................................................................................................................... 95
EV6 Bus ........................................................................................................................................................................ 96
FCC DoC (Declaration of Conformity) ...........................................................................................................................96
FC-PGA (Flip Chip-Pin Grid Array)................................................................................................................................ 96
Flash ROM .................................................................................................................................................................... 96
FSB (Front Side Bus) Clock ..........................................................................................................................................97
I2C Bus.......................................................................................................................................................................... 97
IEEE 1394..................................................................................................................................................................... 97
Parity Bit ....................................................................................................................................................................... 98
PBSRAM (Pipelined Burst SRAM)................................................................................................................................. 98
PC-100 DIMM ............................................................................................................................................................... 98
PC-133 DIMM ............................................................................................................................................................... 98
6
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
PC-1600, PC-2100 or PC-2700 DDR DRAM .................................................................................................................99
PCI (Peripheral Component Interface) Bus ...................................................................................................................99
PDF Format................................................................................................................................................................... 99
PnP (Plug and Play) ...................................................................................................................................................... 99
POST (Power-On Self Test) ........................................................................................................................................ 100
RDRAM (Rambus DRAM) ........................................................................................................................................... 100
RIMM (Rambus Inline Memory Module) ...................................................................................................................... 100
SDRAM (Synchronous DRAM) .................................................................................................................................... 100
Shadow E2PROM ........................................................................................................................................................ 101
SIMM (Single In Line Memory Module) ....................................................................................................................... 101
SMBus (System Management Bus) ............................................................................................................................. 101
SPD (Serial Presence Detect)..................................................................................................................................... 101
Ultra DMA ................................................................................................................................................................... 102
USB (Universal Serial Bus) ......................................................................................................................................... 102
USB2.0 (Universal Serial Bus) .................................................................................................................................... 102
VCM (Virtual Channel Memory)................................................................................................................................... 103
ZIP file......................................................................................................................................................................... 103
Troubleshooting......................................................................................................................... 104
Technical Support ..................................................................................................................... 108
7
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
Product Registration ................................................................................................................. 111
How to Contact Us .................................................................................................................... 112
8
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
YYoouu MMuusstt NNoottiiccee
Adobe, the Adobe logo, Acrobat is trademarks of Adobe Systems Incorporated.
AMD, the AMD logo, Athlon and Duron are trademarks of Advanced Micro Devices, Inc.
Intel, the Intel logo, Intel Celeron, Pentium II, Pentium III are trademarks of Intel Corporation.
Microsoft, Windows, and Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
All product and brand names used on this manual are used for identification purposes only and may be the registered
trademarks of their respective owners.
All of the specifications and information contained in this manual are subject to change without notice. AOpen reserves the right
to revise this publication and to make reasonable changes. AOpen assumes no responsibility for any errors or inaccuracies that
may appear in this manual, including the products and software described in it.
This documentation is protected by copyright law. All rights are reserved.
No part of this document may be used or reproduced in any form or by any means, or stored in a database or retrieval
system without prior written permission from AOpen Corporation.
Copyright
©
1996-2002, AOpen Inc. All Rights Reserved.
9
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
BBeeffoorree YYoouu SSttaarrtt
This Online Manual will introduce to the user how this product is installed. All useful information will be described in later
chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved
in PDF format
free download from Adobe web site
Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing, you can print it by A4 paper
size and set 2 pages per A4 sheet on your printer. To do so, choose File > Page Setup and follow the instruction of your printer
driver.
Thanks for the help of saving our earth.
, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD or you can get
.
10
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
OOvveerrvviieeww
Thank you for choosing AOpen AX4T-533 Pro motherboard. This motherboard is Intel® Pentium 4 (Willamette/Northwood)
motherboard (M/B) based on the ATX form featuring the Intel
AX4T-533 Pro supports Intel
supports 400/533MHz Front Side Bus (FSB)
AGP performance, it has one AGP slot and supports AGP 4X mode and pipelined spilt-transaction long burst transfer up to
1066MB/sec. The MCH component provides Direct RDRAM interface that has dual Direct RDRAM channels support
PC-600/800/1066 RDRAM operation and maximum up to 2GB. The on-board IDE controller supports Ultra DMA
mode. Further flexibility can be achieved by taking advantage of the Communication and Network Riser (CNR)
allows audio and modem configuration on a single baseboard design. Besides, AX4T-533 Pro has an AC97
onboard, providing high performance and magic surround stereo sound to let
people enjoy working with it. Now, let’s enjoy all features
AX4T-533 Pro.
®
®
Pentium® 4 1.4GHz~2.8+GHz CPU. With Intel® QDR (Quad Data Rate) technology, AX4T-533 Pro
clock and provides up to 3.2GB/s data bandwidth between CPU and chipset. In
850E chipset. As high performance chipset built in the M/B,
66/100/133
card option that
CODEC chipset
rom AOpen
f
11
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
FFeeaattuurree HHiigghhlliigghhtt
CPU
Supports Intel® Socket 478 Pentium® 4 1.4GHz~2.8+GHz with 400/533MHz system bus designed for Socket 478 technology.
Chipset
The Intel® 850E chipset supports dual-channel RDRAM memory, delivering the most performance and headroom to maximize
the performance of Pentium 4 processor-based systems. Its Memory Control Hub (MCH) delivers dual RDRAM memory
channels and a 400/533 MHz system bus, providing the latest graphics support through 1.5V AGP4X technology. The enhanced
I/O Controller Hub (ICH2) delivers twice the I/O bandwidth over traditional bridge architecture and provides dedicated data paths
to fully optimize the additional bandwidth.
Expansion Slots
Including five 32-bit/33MHz PCI, one CNR and one AGP slots. The PCI local bus throughput can be up to 132MB/s. Of five PCI
slots provided, AX4T-533 Pro supports five master PCI slots for arbitration and decoding functions. The Communication &
Nectworking Riser (CNR) slot provided from AX4T-533 Pro supports CNR interface for a Modem/Audio card. The Accelerated
Graphics Port (AGP) specification provides a new level of video display sophistication and speed. The AGP video cards support
data transfer rate up to 1066MB/s. As AX4T-533 Pro motherboard includes one AGP expansion slot for a bus mastering AGP
graphic card, for AD and SBA signaling, AX4T-533 Pro can support AGP 4X mode.
12
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
Memory
Provides four 184-pin RDRAM RIMM socket that support up to 2GB of PC-600/800/1066 compliant DRDRAM (Direct Rambus
DRAM). You may install 64, 128, 256 or 512MB with ECC (Error Checking and Correction) RDRAM RIMM modules into each
socket.
Ultra DMA 33/66/100/133 Bus Mater IDE
Comes with an on-board PCI Bus Master IDE controller with four connectors that supports eight IDE devices, supports Ultra
DMA 33/66/100/133, PIO Modes 3 and 4 and Bus Master IDE DMA Mode 4, and supports Enhanced IDE devices.
On-board AC97 Sound
AX4T-533 Pro uses AC97 sound chip. This on-board audio includes a complete audio recording and playback system.
Four USB Connectors
AX4T-533 Pro provides eight ports, four USB connectors (four USB1.1 and four USB2.0 ports) for USB interface devices such
as mouse, keyboard, modem, scanner, etc.
13
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
Power Management/Plug and Play
AX4T-533 Pro supports the power management function that confirms to the power-saving standards of the U.S. Environmental
Protection Agency (EPA) Energy Star program. It also offers Plug-and-Play
thus making system user-friendlier.
, which helps save users from configuration problems,
1MHz Stepping CPU Frequency Adjustment
Provides “1MHz Stepping CPU Frequency Adjustment” function in the BIOS. This magic function allows you to adjust CPU FSB
frequency from 100~248MHz by 1MHz stepping adjustment, and helps your system get maximum performance.
Hardware Monitoring Management
Supports CPU or system fans status, temperature and voltage monitoring and alert, through the on-board hardware monitor
module.
Enhanced ACPI
Fully implement the ACPI standard for Windows® 98/ME/2000/XP series compatibility, and supports Soft-Off, STR (Suspend to
RAM, S3), STD (Suspend to Disk, S4), WOM (Wake On Modem), WOL (Wake On LAN) features.
Super Multi-I/O
AX4T-533 Pro provides two high-speed UART compatible serial ports and one parallel port with EPP and ECP capabilities.
UART2 can also be directed from COM2 to the Infrared Module for the wireless connections.
14
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
QQuuiicckk IInnssttaallllaattiioonn PPrroocceedduurree
This page gives you a quick procedure on how to install your system. Follow each step accordingly.
1.
Installing CPU and Fan
2.
Installing System Memory (RIMM)
3.
Connecting Front Panel Cable
4.
Connecting IDE and Floppy Cable
5.
Connecting ATX Power Cable
6.
Connecting Back Panel Cable
7.
Power-on and Load BIOS Setup Default
8.
Setting CPU Frequency
9.
Reboot
10.
Installing Operating System (such as Windows 98)
11.
Installing Driver and Utility
15
r
per
®
r
r
guag
r
r
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
JP13 LAN Enable/Disable
Realtek LAN Controlle
Realtek ALC650 CODEC
Front Audio Connector
32-bit PCI Expansion Slot
x5(Master)
JP2 Speaker/Buzzer
4Mbit Flash ROM BIOS
JP18 Promise ATA133
Enable/Disable Jumper
Front Panel Connector
JP14 CMOS Clear Jum
Chassis Intrusion Detector
CD-IN Connector
AUX-IN Connector
CNR Expansion Slot
AGP Expansion Slot
Select Jumper
SYSFAN3 Connector
S/PDIF Connector
Supports USB2.0
Connectors
ATA66/100/133 IDE
Connector x2
USB1.1 Connectors
ATA33/66/100 IDE
Connector x2
FDD Connector
Dr.LED Connector
Motherboard Map
PC99 Colored Back Panel
4-pin 12V ATX Power
CPUFAN1 Connector
JP28 Keyboard/Mouse
Wakeup
478-pin CPU socket with
Voltage and Frequency
Auto-detection that supports
® ®
Intel
Pentium 4
1.4~2.8GHz CPU
Low ESR Capacitors
184-pin RIMM Socket x4
supports PC-600/800/1066
RDRAM maximum up to
2GB
Intel
850E chipset
Wake On LAN Connector
ATX Power Connecto
JP15, JP16 Dr. Voice
16
Lan
IrDA Connecto
SYSFAN2 Connecto
e Selection Jumpe
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
BBlloocckk DDiiaaggrraamm
RIMM Socket x2
400/533MHz
System Bus
AGP Slot
Floppy Disk Drive x2
PC-600/800/1066
Direct RDRAM Up to
2GB
RIMM Socket x2
Dual Channel RDRAM
data tran sfer ring rate
up to 3.2GB/s
E
1stUSB Port
USB
Connector
x6
2ndUSB Port
2ndUSB Port
32-bit PCI Slot x5
PCI Bus data
transferring rate up to
133MB/s
Primary
Channel
Secondary
Channel
Low Pin
Count
Super
I/O
17
AC97
CODEC
AC’97 Link
Firmware Hub
Serial Port x2
33/66/100/133
Flash EEPROM
Parallel Port
ATA
IDE Drive x4
Audio CODEC
Modem CO DEC
CNR Slot
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
HHaarrddwwaarree IInnssttaallllaattiioonn
This chapter describes jumpers, connectors and hardware devices of this motherboard.
Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and
other components. Always observe the following precautions before you install a system component.
1. Do not remove a component from its protective packaging until you are ready to install it.
2. Wear a wrist ground strap and attach it to a metal part of the system unit before handling a
component. If a wrist strap is not available, maintain contact with the system unit throughout any
procedure requiring ESD protection.
18
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
AAbboouutt ““UUsseerr UUppggrraaddee OOppttiioonnaall”” aanndd ““MMaannuuffaaccttuurree UUppggrraaddee
OOppttiioonnaall””……
When you read this online manual and start to assemble your computer system, you may notice that some of the functions are
marked as “User Upgrade Optional” or “Manufacture Upgrade Optional”. Although all of AOpen’s motherboards have included
many amazing and powerful features, sometimes not every user is familiar with these powerful features. As a result of this we
define features that can be upgraded by users as “User Upgrade Optional”. You can upgrade these functions by purchasing
additional devices. As for functions that cannot be upgraded by users, we define them as “Manufacture Upgrade Optional”. If
need be, you can contact our local distributors or resellers to purchase “Manufacture Upgrade Optional” components, and again
you are also welcome to visit our official website at www.aopen.com
for detail information.
19
(
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
JJPP1144 CClleeaarr CCMMOOSS DDaattaa
You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below.
1. Turn off the system and unplug the AC power.
2. Remove ATX power cable from connector PWR2.
3. Locate JP14 and short pins 2-3 for a few seconds.
4. Return JP14 to its normal setting by shorting pin1 & pin2.
5. Connect ATX power cable back to connector PWR2.
Pin 1
1
Clear CMOS
1
Normal Operation
Default)
Tip: When should I Clear CMOS?
1. Boot fail because of overclocking…
2. Forget password…
3. Troubleshooting…
20
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
CCPPUU IInnssttaallllaattiioonn
This motherboard supports Intel® Pentium® 4 1.4~2.4GHz Socket 478 series CPU. Please follow steps below to finish CPU
installation. Be careful of CPU orientation when you plug it into CPU socket.
1. Pull up the CPU socket level and
up to 90-degree angle.
2. Locate Pin 1 in the socket and look for a black dot or cut
edge on the CPU upper interface. Match Pin 1 and cut edge,
then insert the CPU into the socket.
Note: These pictures are for example only; they may not look exactly the same as the motherboard you purchased.
CPU socket
Lever
CPU pin 1 and
cut edge
CPU cut edge
21
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
3. Press down the CPU socket level and finish CPU installation.
Note: The CPU you purchased may look different from the one shown here.
CPU cut edge
Note: This socket supports
Micro-FC-PGA2 package CPU, which
is the latest CPU package developed
by Intel. Other forms of CPU package
cannot be fitted in.
Note: If you do not match the CPU
socket Pin 1 and CPU cut edge well, it
may damage the CPU.
Note: P4 CPU tends to produce higher
temperature; for better heat dissipation,
we recommend you to install this
motherboard with a bigger housing.
Besides, by doing so you can prevent
components from colliding.
22
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
CCPPUU JJuummppeerr--lleessss DDeessiiggnn
CPU VID signal and SMbus clock generator provide CPU voltage auto-detection and allows the user to set the CPU frequency
through the BIOS setup
designs are eliminated. There will be no worry of wrong CPU voltage detection.
, therefore no jumpers or switches are used. The disadvantages of the Pentium based jumper-less
Intel® Socket 478
Pentium 4
CPU VID signal
Power Regulator
(Automatically generates CPU voltage)
CPU voltage
Clock Generator
CPU Freq. Ratio
BIOS
Controlled
Circuit
23
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
AAOOppeenn ““WWaattcchh DDoogg TTiimmeerr””
and POST again. With this special feature, you can easily overclock your system to get a higher system performance without
removing the system housing and save the hassle from setting the jumper to clear CMOS data when system hangs.
AOpen
Watch Dog
Timer
AOpen provides a special and useful feature on this motherboard for overclockers. When you
power-on the system, the BIOS will check last system POST
enable “Watch Dog Timer” function immediately, and set the CPU FSB
user’s settings stored in the BIOS. If system failed in BIOS POST, the “Watch Dog Timer” will
reset the system to reboot in five seconds. Then, BIOS will detect the CPU’s default frequency
Enable/Disable Signal
from BIOS
Countdown about
5 seconds if fails
in POST
Reset Signal
Clock Generator
status. If it succeeded, the BIOS will
frequency according to
BIOS
CPU ID Signal
CPU
24
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
SSeettttiinngg CCPPUU FFrreeqquueennccy
This motherboard is CPU jumper-less design, you can set CPU frequency through the BIOS setup, and no jumpers or switches
are needed.
BIOS Setup > Frequency/Voltage Control > CPU Clock Ratio
CPU Ratio
CPU FSB
8x, 9x, 10x, 11x, ……, 22x, 23x, 24x
100-248MHz by 1MHz stepping
Warning: Intel® 850E chipset supports maximum
400MHz (100MHz*4) /533MHz (133MHz*4) system
bus and 66MHz AGP clock, higher clock setting may
cause serious system damage.
Home
y
Tip: If your system hangs or fails to boot
because of overclocking, simply use <Home>
key to restore the default setting.
25
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
SSuuppppoorrtteedd CCPPUU FFrreeqquueennccyy
Core Frequency = CPU Bus Clock * 4 * CPU Ratio
PCI Clock = CPU Bus Clock / Clock Ratio
AGP Clock = PCI Clock x 2
Northwood CPU
Pentium 4 1.6G 1600MHz 100MHz 400MHz 16x
Pentium 4 1.6G 1600MHz 133MHz 533MHz 12x
Pentium 4 1.7G 1700MHz 133MHz 533MHz 13x
Pentium 4 1.8G 1800MHz 100MHz 400MHz 18x
Pentium 4 2.0G 2000MHz 100MHz 400MHz 20x
Pentium 4 2.2G 2200MHz 100MHz 400MHz 22x
Pentium 4 2.26G 2260MHz 133MHz 533MHz 17x
Pentium 4 2.4G 2400MHz 100MHz 400MHz 24x
Pentium 4 2.4G 2400MHz 133MHz 533MHz 18x
Pentium 4 2.53G 2530MHz 133MHz 533MHz 19x
Pentium 4 2.66G 2660MHz 133MHz 533MHz 20x
Pentium 4 2.80G 2800MHz 133MHz 533MHz 21x
CPU Core
Frequency
FSB Clock System Bus Ratio
Note: Since the latest
processor, Northwood, would
detect the clock ratio
automatically, you may not be
able to adjust the clock ratio in
BIOS manually.
26
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
Willamette CPU CPU Core Frequency FSB Clock System Bus Ratio
Pentium 4 1.8G 1800MHz 100MHz 400MHz 18x
Pentium 4 1.9G 1900MHz 100MHz 400MHz 19x
Pentium 4 2.0G 2000MHz 100MHz 400MHz 20x
Celeron CPU CPU Core Frequency FSB Clock System Bus Ratio
1.7G 1700MHz 100MHz 400MHz 17x
1.8G 1800MHz 100MHz 400MHz 18x
Warning: Intel® 850E chipset supports maximum 400MHz (100MHz*4) /
533MHz (133MHz*4) system bus and 66MHz AGP clock; higher clock
setting may cause serious system damage.
27
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
CCPPUU aanndd HHoouussiinngg FFaann CCoonnnneeccttoorr ((wwiitthh HH//WW MMoonniittoorriinngg))
Plug in the CPU fan cable to the 3-pin CPUFAN1 connector. If you have chassis fan, you can also plug it on SYSFAN2 or
SYSFAN3 (without H/W monitoring) connector.
SYSFAN2 Connector
CPUFAN1 Connector
SENSOR
+12V
GND
GND
+12V
SENSOR
SYSFAN3 Connector
GND
+12V
SENSOR
Note: Some CPU fans do not
have sensor pin, so that they
cannot support hardware
monitoring function.
28
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
HHooww ttoo IInnssttaallll CCPPUU HHeeaattssiinnkk aanndd FFaann
This motherboard comes with a retention module attached on the CPU socket when shipped, we strongly recommend you to
install AOpen special designed CPU Fan as shown below on the retention module for better heat dissipation. Please install the
CPU Fan correctly as the following pictures shown.
1. Gently put the CPU Fan down on the retention
module with clips aligning correctly to the four
corners.
Note: The picture above may look different from the product you purchased.
2. Pressing down the four clips with force one by one on the retention
module.
Clip
29
AAXX44TT--553333 PPrroo OOnnlliinnee MMaannuuaall
RRIIMMMM SSoocckkeettss
This motherboard has four 184-pin RIMM sockets that allow you to install PC600, PC800 and PC1066 RDRAM up to 2GB.
AX4T-533 Pro will detect the RDRAM speed automatically while system is in POST
type manually by BIOS setup program. Please note that 400MHz FSB doesn’t support RIMM PC1066.
, but it still allows you to select the RDRAM
Note: Based on Intel 850E chipset specification,
AX4T-533 Pro has dual memory channel. Please note that
when you insert RIMM modules, you have to insert them
into RIMM 1 and 4, and have terminators inserted into
RIMM 2 and 3. Or you can insert RIMM modules into
RIMM 2 and 3, and have terminators inserted into RIMM 1
and 4.
RIMM2
RIMM1
RIMM3
RIMM4
30
