10 inch HD TFT LCD capacitive touch screen with a resolution
1024*768 pixels
-2-
Voltage Supply voltage: 5V Charging voltage: 5V
Current
Battery used
Power adapter
Charging time
Battery use time
(Under the condition
that the battery is full y
charged in a normal
temperature)
External dimensions
Dimension (L×W×H) 10.0 x 7.6 x 0.51 in (25.5 x 19.2 x 1.3 cm )
Weight 1.58 lbs (0.718kgs) (with battery)
Ports Mini USB 2.0 high speed port, OTG, 3.5mm headset
Environmental conditions
Operating
temperature
Storage temperature -20°C ~ 55°C
Max. humidity
Supported OS Windows2000/XP/Windows 7/Vista, Macin tosh OS X
Note: Windows 2000+SP1/SP2 is not supported by this product. The user should upgrade to SP3
or above. This product does not guarant ee all video formats are playable. Even if some formats
are listed in the instructions, they m ay be not play properly, due to some video particul arities..
Max. current for playback is 1.5A DC.
Max. current for charging is 1.3A DC.
Built-in lithium-ion polymer rechargea ble battery, 3.7V,
7000mAh
AC input:100-240V 50/60H z DC input:5V 2.5A
It takes about 7 hours for the battery to be f ully charged when
the provided charger is used while po wered-down. The
charging time may vary depending on the remaining battery
level.
Note: Do not charge the battery for more than 1 2 hours
continuously.
Audio: About 50 hours
Video: About 7 hours
Web browsing: About 7 hours
0°C ~ 40°C
90% RH (non-condensation)
-3-
A
K
Chapter 2 Buttons and Appearance
BC D
E
F
A. Build-in Microphone B. Operation indicator
C. Power button D. Volume +/- buttons
E. Front camera F. Touch screen
G. Headset jack H. HDMI jack
I. Mini USB port (connecting to PC)J. USB HOST port (Connecting to USB drive)
K. Power cable jack L. Reset button
M. MicroSD (TF) card slot N. Rear camera
O. Flash
G
H
I
J
L
M
P. Audio speaker
N
O
P
-4-
Note 1: During operation, sounds will be autom atically output from the Audio speaker if there is
audio output.
Note 2: In the Instructions, “Press” means pressing a button while “Press and Hold” means
continuously pressing a button for 2 ~ 3 seconds.
-5-
Chapter 3 EasyConfig
When first using the tablet breeze,the Eas yConfig window will pop up. It includes Language,
Date/Time and Wi-Fi settings.
Touch "Next" to setup language, and th en choose a language you want.
Touch "Next" to setup date, time zone an d time.
-6-
Tap "Next" to go to the Wi-Fi settings interfac e.
Touch "Menu icon ( ) -> Scan" to search for the available wireless network s in the vicinity.
Touch the desired wireless network nam e to connect to it. You will be prompted, if a password is
required.
1. If static IP address needs to be enter ed, click on “show advanced options to sh ow “IP settings”.
Touch the pop-up menu and select “stat ic”. Then enter the IP address, gateway, net work mask,
and DNS information required for such Wi-Fi network connections.
2. If you use dynamic IP address k eep the default "DHCP" in the “IP settings” opt ion.
Note: The word "Connected" displayed und er the network name indicates a successful
connection.
Afterwards you can surf the Internet, connec t to email services, etc.
-7-
A
G
Chapter 4 Basic Operations
4.1 Main interface
After booting and unlocking, you can go to the main interface (as shown below).
A. Quick search boxTouch to begin search
B. Voice Search Touch for voice search
C. Apps icon Touch to go to Apps and Widgets Interface
D. Main interface Main interface.
E. Back icon Touch to go back one screen
F. Home icon Touch to return to the home screen at any time.
G. Go to recent apps
H. Notification bar Touch for details on status, time, settings , etc.
4.2 Booting up
Press and hold the Power button for a f ew seconds. After the boot screen is shown (f or about 40
seconds), the unlock interface is sho wn. Touch and hold the unlock icon at the m iddle right of the
screen and drag it rightward to the “open lock” icon to unlock it.
Note: Touch and hold the unlock icon at the m iddle right of the screen and drag it leftward to the
Camera icon to enter directly into camera mode.
E
F
Touch to show thumbnails of your recent Apps. T ouch a
thumbnail to select it or fli ck a thumbnail left or right to
remove from list. Slide up to scr oll through list.
CB
D
H
-8-
4.3 Shutdown
In any mode, Press and hold the Power button for about 2 seconds. The device shutdown window
will appear:
a. Power off: Touch to turn off the product.
b. Airplane mode: Touch to turn on or turn of f Airplane mode.
c. Silent mode: Touch to turn on or turn off sound.
Note 1: If the battery is low, the product wil l shutdown automatically.
Note 2: If the product freezes during operat ion, press and hold the Power button for 6 to 10
seconds to force shutdown.
4.4 Network
To surf the Internet wirelessly, make s ure the Wi-Fi wireless network signals are present an d set
the Wi-Fi network connection. There are t wo wa ys of going to the “Wireless & Networks” settings
interface:
a. Touch the notification icon at the bottom r ight corner of the main interface, touch the popup
window and touch “Wi-Fi”.
b. In the “Apps” interface, touch settings icon to go t o the settings interface, and then touch
“Wi-Fi ”.
Note 1: For detailed settings, refer to “9.1 Wireless & Network Settings”.
4.5 Standby Mode
Standby: During use, you can press the power button to enter into standby mode to save battery
power and lock the key and screen.
When the tablet is in standby mode witho ut power adapter plugged in, the operation indicator
flashes slowly. On the contrary, when the tab let is in standby mode with power adapter plugged in,
if the battery isn’t full, the operation ind icator flashes fast, once the battery is fully c harged, the
operation indicator will always be on.
Wake up: When the device is in standby mode, pres s the Power button , after the screen lights up,
touch and hold the unlock icon at the m iddle right of the screen and drag it rightward to the “ open
lock” icon to unlock it.
4.6 Reset
If the product crashes during operat ion, you can push the Reset button (w ith a paper clip) to reset
-9-
the system.
Note: Under normal operation, do not use the R eset button as the Shutdown button.
4.7 Connecting to PC and file transfer
Connecting to PC:
1. While the product is on, plug the smaller end of the provided USB cable to the MINI USB port on
the side of it, and the larger end of it to a USB port on PC.
2. If the "Media device (MT P)" option is selected, (in Storage Settings / menu / USB computer
connection), the device is connected as a media device and you can trans fer any files on
Windows PC, or using "Android File Transfer" on a Macintosh PC.
3. If the “Camera (PTP)” option is selected, de vice connected as a camera” and you can transfer
only photos.
4. If the “Mass Storage” option is selected, (in St orage Settings / menu / USB computer
connection), the USB connected interf ace will pop up on the tablet with the option to “Turn on USB
storage”. Tap the button "Turn on USB st orage” to connect. When the message changes to “T urn
off USB storage”, the connection has suc cessfully been established.
The tablet (and SD card if installed) will be mounted on your computer as mass storage devices.
You may access their data directly on your PC (W indows or Macintosh).
Disconnecting from PC:
Touch the "Safely Remove Hardware" ic on at the bottom right corner of the Windows PC screen
to remove the device safely on PC. On a M acintosh, just "eject drives" from desk top.
Then tap “Turn off USB storage” button on the tablet to disconnect tablet from com puter.
Note: File transfer requires: Windows X P system need Windows Media Player 11 or greater than
11 supported, while Mac system may need to install MTP software packages. (* "Android File
Transfer" for Mac OS X is available at www.android.com/filetransf er
4.8 Volume adjustment
Media volume: Adjust the volume f or playing music and video.
Alarm:Adjust the volume of alarm .
Notification volume: Adjust the vo lume of notification ringtones.
.)
-10-
4.8.1 Adjusting the media volume
There are three ways of going to the “Media Volume” adjustment interface:
·In any interface, press or press and hold the Volume +/- button on the top of the product to a djust
the media volume.
·In any interface, touch the notification bar , touch to pop up the quick settings window, and t hen
touch the media volume bar to adjust t he volume.
·In the apps interface, touch “Settings -> S ound -> Volume” , touch the media volume bar to
adjust the volume after the Volume window ap pears.
4.8.2 Adjusting the alarm volume
· In the apps interface, touch “Settings -> Sound - > Volume”, touch the alarm volume bar to adjust
the volume after the Volume window ap pears.
4.8.3 Adjusting the notification volume
In the apps interface, touch “Settings -> S ound -> Volume”, touch the notification volum e bar to
adjust the volume after the Volume window ap pears.
4.9 Charging
When the battery is low, the provided adapter can be used to charge it.
1. If the product is powered on during charging , the status bar will show the charging icon ( ).
After the battery is fully charged, the b ar will show the full battery icon (
2. If the product is shutdown d uring charging, the large charging ic on interface will be displayed.
After the battery is fully cha rged, the full battery icon ( ) will be shown; in the large charging
icon interface, press the Power button ac cording to the prompts to turn on.
Note 1: Check the detailed charging per centage through “Settings -> About Tablet -> St atus ->
Battery Level”.
Note 2: To extend battery life, avoid char ging the battery frequently when it is in high l evel.
(Example: more than 90%) It is not recomm ended to charge the product at this time; if charging is
performed at this time, the percentage sho wn may not be 100%. This is normal.
Note 3: Once a “Low battery” message is dis played, the tablet should be charged as soon as
possible.
).
4.10 Touch screen operations
Tip: The display used in this product is a capacitive multi touch screen. When using, you can
-11-
operate it by touching the correspond ing icons on the display with finger to ena ble the
corresponding functions.
Touch
Touch the screen icons to select. W hen you want to use the on-screen keyboard to type, or pr ess
an on-screen icons, just touch them us ing your finger.
Touch and hold
Touch the screen icons continuousl y until the option expands.
Slide
Place and slide your finger on the scr een. Slide your finger up or down to scroll u p or down; or if
the list has a scroll bar, slide your f inger up or down in the list to page down or up; when you are
browsing pictures, slide your finger to the left or to the right to view the previous or next picture.
MultiTouch
While surfing the Internet or browsing pictures.
Zoom in:Touch the screen with two fingers, and slide two fingers together.
Zoom out:Touch the screen with two fingers, and slide two fingers together apa rt.
4.11 HDMI output
When the product is on, plug the smaller en d of the HDMI cable to the HDMI port on the side, and
the larger end to the HDMI port of TV. T he device will enter into HDMI mode automaticall y.
Note: When you are in HDMI mode, you can control th e system through USB mouse, USB
keyboard, Bluetooth mouse and Bluetooth keyboard.
4.12 Search icon
In the main interface, touch the “Search” icon to search for the relevant information us ing the
browser.
-12-
Chapter 5 Common Features
5.1 Landscape/Portrait display switching
1. In the “Settings” interface, touch “Acces sibility ->Auto-rotate screen.” When the “√” s ymbol
appeared, the Landscape/Portrait screen d is play switching is on; when the “√” sym bol
disappeared, the Landscape/Portrait scr een display switching is off.
2. Hold this product vertically with your hands and tilt it to the left or right. When it i s tilted to a
position 90° to the horizontal plane, t he gravity sensor built in the product senses the action and
the screen switches to Portrait mode fr om Landscape mode.
On the contrary, when it is tilted to a position 0° to the horizontal plane, the scr een switches to
Landscape mode from Portrait mode.
Tip: This product supports 4-direction rot ation display.
Note 1: For gravity sensing (displa y orie ntation), the screen orientation will not change if this
product is placed on the level and statio nary surface, regardless of how you rotate the pr oduct.
Note 2: For some interfaces, such as other third-party apps interface, gra vity sensing will be
disabled.
5.2 Using virtual keyboard to type
Touch any text input box to pop up the virtual k eyboard as shown below. Use this keyboard to type
any text or characters.
5.2.1 Android keyboard
-13-
A
Tip: During the input process, you can m ove the cursor by touching a position.
5.2.2 Editing text
The typed text can be edited.
When there is text in the input field, touch and hold th e input field (or touch and hold the show box
in the keyboard) to open the Edit Text m enu. Touch the options in the menu to edit the text.
B
C
I
J
D
E
F
G
A. Show box: Show the text typed. Touch a nd hold this box to display the Edit Text
menu for you to cut, copy, and paste the text.
B. Tab:Touch this key to switch to next input table. Touch Shift key and then touc h
this key to switch to previous position.
C. Touch this key to switch between num eric keypad and symbol keyboard;
For numeric keypad and symbol ke yboard, touch the “~\{” key to display the
special symbols (such as ~, ±, ÷, ×,e tc.).
D. Shift:Touch this key to switch bet ween uppercase and lowercase text.
E. Touch this key to switch between input method and input languages.
F. Touch this key to close keyboard.
G. Touch this key to use voice recogn ition to input text.
H. Touch this key to input space.
I. Touch to delete the edited text.
J. Touch to ensure input and go to next s tep.
Select all text typed
Select all
Cut Cut text typed
Copy Copy text typed
H
-14-
Paste Paste cut or copied text
Share Share the selected text via Bluetooth, G mail or Email.
5.3 Notification bar
The notification icon appears when a m essage is received, PC is connected, or music is played.
You can open the notification bar to chec k for messages and played music.
5.3.1 Opening notification bar
After a new notification icon appears in the notification bar, touch the notificati on bar to open the
notification bar.
5.3.2 Closing notification panel
Touch any space except for notificat ion bar to close it.
5.4 Recently run apps
Touch the recent apps icon in the main i nterface to go to show the background apps. T ouch the
icon in the window to open the correspo nding app.
Touch the app in the window and slide your finger towards right to close the correspond ing app.
5.5 Changing wallpaper
In the main interface, touch and hol d a blank space, choose the desire wal lpaper from “Live
Wallpapers”, “Gallery” or “W allpapers”.
5.6 Power control
In the apps interface, slide your finger toward left to go to the Widgets interface, then c ontinue
sliding to the next widgets interface, find “Power c ontrol” widgets. Touch and hold the widgets icon
to move it to main interface, as the pictur e show below:
-15-
A
B
A. Wireless network on/off Touch to turn on or off the wirel ess network.
B. Bluetooth T ouch to turn on or off the Bluetooth.
C. Sync icon
D. Brightness adjustment
icon
Touch to set whether the wireless network can be
used together with other programs.
Touch to adjust the screen brightness.
DC
-16-
A
G
Chapter 6 Apps
Make sure the Wi-Fi wireless network connection is established to use the following
functions.
6.1 Apps interface
Touch the Apps & Widgets icon at the right cor ner of the main interface to go to the Apps interface,
as shown below:
6.2 Browser
Open the browser to enjoy a colorful experience. You can also access news, wea ther forecast,
and sports or traffic information when n eeded.
6.2.1 Opening browser
In the “Apps” interface, touch “Browser” to o pen a webpage.
B C D E
F
H
-17-
A. Back icon Touch to go to previous webpage.
B. Next icon Touch to go to next webpage.
C. Refresh icon Touch to refresh the current webpage.
D. Close icon Touch to close the current t ab.
E. Add icon Touch to open a new tab.
F. Delete text/Add
bookmark icon
G. Menu icon Touch to show menu options.
H. Bookmark icon Touch to go to bookmark interface.
Tip: When you touch a webpage link in an e-mail or message, the browser will be ope ned
automatically.
6.2.2 Going to a webpage
1. Type a URL using the keyboard.
2. Touch the “Go” icon at the right of the v irtual keyboard to open a webpage.
6.2.3 Setting a home page
1. Touch the menu icon and touch “Settin g-> General-> Set home page”.
2. Touch “Current page”, “Blank page”, “D efault page”, “Most visited sites” or enter the URL of the
webpage to set them as home page.
Touch the back icon to return to the previous page. Touch the “+” icon, to open a new tab and you
can go to the newly set home page.
6.2.4 Browsing a webpage
A browser provides many functions, a llowing you to browse a webpage as you do on a PC.
You can simultaneously open several pa ges and touch one of them to browse.
You can slide your finger around the sc reen to browse other areas of webpage.
You can also zoom in or out of a web page by sliding two fingers together or apart for easier
browsing.
Open new browser tab
You can open several browser tabs, a llowing you to browse between several web sites easily. Up
to 16 browser tabs can be opened.
To open a new tab, touch the menu icon, and touch “New tab” to open a new browser tab and go
to the preset home page.
Switching between browser tabs
Touch “x” to delete the text in the table. /Touch “☆” to
add the current webpage to bookmark .
-18-
Touch the tab title to view the correspon ding tab.
Selecting link in webpage
The selected link will be put in a blue box.
·Touch it to open a webpage.
·Touch and hold to open the Actions m enu, Open, Open in new tab, Save link, Cop y link URL
and Select text.
Selecting text in webpage
Touch and hold the text in webpage, the selected sl ider and menu option will display, slide the left
and right slider to select the text f or easier copying or sharing.
Saving webpage
You can save webpage for offline r eading. In browser interface, touch menu icon and touch “Save
for off line reading”.
Finding text on a webpage
1. When browsing a webpage, touch the m enu icon and touch “Find on Page”
2. Type the item to be found. After the content is typed, the sh ade of the text of the matches is
highlighted in blue. Touch “
to finish finding.
6.2.5 Managing bookmarks
Bookmarks can be stored while browsing a webpage. In the browser interface, touch “Book mark”
icon to go to the bookmarks managem ent interface where there are three tabs: BOOKMARK S,
HISTORY and SAVED PAGES.
BOOKMARKS: Bookmarks management interface.
” or “ ” to skip forward or backward on e match. Touch “Done”
-19-
HISTORY: History webpage interface.
SAVED PAGES: Show the list of saving webpage.
Adding bookmark
Touch “☆” to add the current webpage to book mark.
Opening bookmark
In the “Bookmark” interface, perform an y of th e following steps to open a bookmark:
· Touch the bookmark you want to open.
· Touch and hold the bookmark you want to open, and touch “Open” or “Open in new window”.
Editing bookmark
1. In the bookmark interface, touch and h old the bookmark you want to edit.
2. Touch “Edit Bookmark” in the options to s how the Edit Bookmark window.
3. Enter your desired changes and touch “ OK” to finish editing.
Using bookmark
Touch and hold a bookmark in the bookm ark list to pop up the Actions option: Open,
Open in New tab, Edit bookmark, Add Shortc ut to Home, Share Link, Copy Link URL,
Delete bookmark, and set as homepage.
6.2.6 Other functions
In the browser interface, touch the “Men u” icon to perform more operations:
Refresh, Forward, New tab, New incognito ta b, Share page, Find on Page, Request desktop site,
Save for offline reading, Page inf o and Settings.
6.3 Video player
In the “Apps” interface, touch “Video” to go to the video file list.
-20-
A
K
G
6.3.1 Video playing
In the file list, slide your finger up and down to find the videos you want to play. Touch one to play.
J
Touch the screen to show the Hide menu:
A. Add video bookmark B. Adjust screen br ightness
C. Touch: Previous video file
Touch and hold: Rewind
E. Touch:Next video file
Touch and hold: Fast forward
G. Displaying floating video
H. Return to the video list J/K. Decrease/increase volume
I. More
B
C
D
Delete Bookmark
And Play from
beginning
Delete
bookmark
Play mode Select Repeat mode.
Subtitle Select
Audio Track
Select
F
E
D. Play/pause
F. Screen extension:Touch to select, Full
Screen, Normal,16:9, 4:3
Touch to display the video in float ing mode.
Touch and drag to reposition and pinch t o
resize. To close, drag and sling (thro w) the
video window to right or left edges of screen.
Touch this option to delete the video bookmarks
and play from the beginning of the title.
Delete the video bookmarks and continue
playing.
Select one subtitle while there is m ore than one
kind of subtitle in the video.
Select one audio track while ther e is more than
one kind of audio track in the video.
H
L
I
-21-
Help Tips icon function
L. Play progress
bar
Note 1: It takes a longer time to start pla ying a larger formatted video file. Convert video f iles that
exceed the max. resolution supported b y the unit.
Note 2: For some supported video sources, a f ew video files that are partly damaged m ay not be
played by the unit. Convert them on the PC a nd play the converted files on unit.
Note 3: This product can not guarantee that all video files are supported. While som e are
recognizable in the system and pla yed, not all features may be supported; such as f ast forward
and rewind, may not be used by individual video files.
6.3.2 Delete video
In the video file list, touch and h old the video you want to delete, then touch “Yes” in reply to “Sure
to delete this video?”.
6.4 Audio player
In the “Apps” interface, touch “Music” to go to the audio file list.
Artists Sort by “Artist”
Albums Sort by “Album”
Songs
Playlists Display the play list
Now playing Go to the currently played music file
Return Return t o the Play interface
Touch any position of the play progress bar to skip to this position;
Touch and hold it to move to any posit ion to continue playing.
Display the all music stored on built-in Flash memory, SD card
and USB device
-22-
A
6.4.1 Playlist
In the music file list, touch “playlists ” to go to the playlist.
Touch and hold “Recently added” to pla y or edi t the time of the “Recently added” list.
In the music file list, touch and hold a song or a folder , then touch “Add to playlist” to add the song
to a new playlist or other playlist.
Tip: You cannot delete the “Recently adde d” list.
6.4.2 Playing audio
Touch the music you want to played and go t o the music playing interface.
C
BI D
A. Play list Touch to open the playlist.
B. Shuffle Playing songs at random mode.
C. Play mode
Stop after the end song is played.
Repeat playing all songs in the current directory.
Repeat the current song.
E
F
G
H
-23-
D. LRC Touch to show or hide lyrics.
E. File info
F. Rewind
/previous
G. Play/pause Play/pause music.
H. Fast forward
/next
I. Play progress
bar
Note: Keep the .lrc file name consiste nt with the audio file name, copy them to a sam e folder in
tablet.
6.4.3 Sound effects
In the music playing interface, touch the m enu icon and touch “Sound effects” to go to sound
effects settings interface.
Slide the slider switch at the top r ight corner to turn on and off sound effects .
To select pre-set music type equalizer s ettings, touch the drop-down menu that show the cur rent
“type” selected. Select your preferr ed sound effects by choosing a type of music t ype from the
menu or by sliding your finger up and do wn on the sound effect frequency bars.
Note: Few MP3/WMA audio files that are specifically encoded may not be played b y the pr oduct.
Convert them using an audio conversion too l and download the converted files to the pro duct to
play.
When the network connection is establis hed, touch it to check
the link information about the current ly played music file.
Touch: Switch to the previous song.
Touch and hold: Rewind.
Touch: Switch to the next song.
Touch and hold: Fast forward.
Touch any position of the play progress bar to skip to this position;
Touch and hold it to move to any posit ion to continue playing.
-24-
A
6.5 Picture browser
In the “Apps” interface, touch “Galler y” to go t o the picture list.
Tip: The system will automatically searc h for all pictures on Flash memory, SD car d and USB
device and display them as folders .
6.5.1 Browsing pictures
In the directory, touch the pictures you want to browse to open the picture browsing interf ace.
Touch the screen to pop up or hide the menu:
CB
A. Share icon
B. Trash can Delete the current pict ure.
C. Menu Touch to show the menu options.
Share the current picture through Bluetooth , Picasa, Gmail,
or Drive.
-25-
Touch the menu icon to show the menu options
Slideshow Automatically browse pictures.
Edit Touch to edit the current picture.
Rotate left
Rotate right
Crop Crop current picture.
Set picture as Set the picture as Wallpaper background or Contact photo
Details Show the name of the picture file, its resolution, etc.
Tip1: When browsing pictures, you can s lide your finger to the left or right rapidl y to switch to the
previous or next picture.
Tip2: When browsing pictures, you can zoom in or zoom out the picture by sliding two fingers
together or apart.
6.5.2 Picture file operation
In the picture list, touch and hold a picture or a folder to pop up the Multi-choice operation list.
Rotate the picture 90° counter-clock wise. Touch this icon to rotate
the picture counter-clockwise in the foll owing order: 90°, 180°, 270°
and restore.
Rotate the picture 90° clockwise. Touch th is icon to rotate the picture
clockwise in the following order: 90°, 18 0°, 270° and restore.
-26-
A
A. Done Finish the operation.
B. X items selected
C. Share
D. Delete Delete the selected pictures .
E. Menu Touch to show more options.
BE
Show the number of the selected picture. Touch a picture
to be selected or unselected
Share the pictures through Picasa, Blu etooth, Gmail or
Email.
6.6 Camera
Touch the camera icon to go to the cam era interface.
Touch "
" icon for camera mode, touch "" icon for video record mode, touch “ ” for
panorama mode.
Slide along the arc icon to zoom in or out.
Touch "
" icon to take photo or start recording video. Touch “ ” to end recording video.
" icon to switch between front camer a and rear camera.
Touch "
Take photos
Image Size File Size
5M (2592 X 1944)
3M (2048 X 1536)
2M (1600 X 1200)
1M (102 4 X 768)
VGA (640 X 480)
QVGA (320 X 240)
D
C
-27-
Recording Videos
Note: You can view and edit the photograph s and recording videos on your computer in path:
AOC TABLET: \Nand Flash \DCIM\Camera\
Mode File Size
Default 640 X 480
-28-
Chapter 7 Apps
In the main interface, click “Apps” icon to g o to the “Apps” interface in which the installed a pps will
be shown.
7.1 Moving a program icon to another interface
To create a program alias icon and m ove it to other interfaces, touch and hold the program icon
and the screen will switch to last int erface viewed. Then place the icon at a des ired position and
release.
7.2 Deleting a program icon
In the main interface, touch and hold t he program icon you want to remove. When the “X” icon
appears at top of the screen, drag program icon to “X” to delete it.
7.3 Adding a Widget
In the “Widgets” interface, touch and hol d a widget you want to add and the screen will s witch to
the last interface viewed. Then place the widgets at the desired position and release.
7.4 Creating a folder
Create a folder in the interface to store the app icons or controls. To make a new folder on your
Home screen, stack one app icon on top of another. Then to add more program icons to a folder,
touch and hold a program icon on the screen and drag it to the folder.
Tip: To delete a folder, refer to the steps d escribed in “Deleting a program icon”.
7.5 Renaming a folder
Touch the folder and the name of the folder will display. Touch the name to rename the folder .
-29-
Chapter 8 Common Tools
8.1 E-mail
When you use the e-mail for the first time, you need to create an e-mail account first.
1. Enter the address and password for your e-mail account and touch “Next”.
2. Select an account type. Touch “POP3” f or a POP3 account.
3. Touch “POP3 Server” and “Port”, enter “ pop.+ account suffix” and port number. For ex ample, if
the e-mail account is 123456@163.com
“110”. Then touch “Next”.
Note: If you select IMAP Account in step 2, t ouch “IMAP Server” and enter“IMAP.163.com”.
and the port number is 110, enter “pop.163.c om” and
-30-
4. Touch “SMTP Server” and “Port”, enter “s mtp.+ account suffix” and port number, f or example
“smtp.163.com”.Then touch “Next”.
5. Set the account options and touch “Next” t o finish settings.
Note: Since the e-mail service providers may vary, configure the server settings ba sed on the
actual e-mail account. This product can support the accounts provided by the popular e-mail
service providers, such as Yahoo, So hu, etc.
8.1.1 Opening e-mail
In the “apps” interface, touch “E-mail” to e nter.
-31-
Tip 1: By default, this product can be used t o browse the inbox after the e-mail app has
synchronized with email provider. All e-mails you rece ived will be put into the inbox.
Tip 2: Touch “ ” icon to send or receive a new e-mail and synchronize your e-mails with your
e-mail accounts.
8.1.2 Creating and sending e-mails
1. Touch the “ ” (Com pose) icon at the top right of the E-mail interface.
2. Next to “To”, enter the e-mail address of the receiver.
Tip: If you want to send a carbon copy or a blind carbon cop y e-mail to other recipients, touch
“+CC/BCC.
3. Enter the e-mail subject and compos e your e-mail.
Tip: If you want to add a picture attachm ent, touch the “ ” (paper clip) icon, selec t the picture
you want to attach, and touch it to conf irm or touch the “Cancel” icon to cancel.
4. After composing your e-mail, touch “S end”.
-32-
Tip: When you compose your e-mail, touc h the “Save draft” or back icon to save your e-mail to
Draft.
8.1.3 Receiving and reading e-mail
When a new e-mail is received, the not ification bar will show the new
Perform one of the following to read your e-mail:
· Touch the notification bar, and touch the new e-mail to rea d.
· Touch the unread e-mails in the Inbox to r ead.
8.1.4 Replying / Forwarding e-mail
Open an e-mail, touch “ ” icon to reply, touch “ ” icon to reply all and touch “ ” icon to
forward the email.
8.1.5 Managing e-mail
Touch and hold an e-mail to show t he menu:
e-mail
( ) icon.
-33-
“ ” Delete Delete an e-mail
“ ” Mark as read/unread The unread e-m ails in the Inbox are highlighted with
Menu Touch to show more options.
8.1.6 Email Settings
In the e-mail interface, touch the menu icon, and touch “Settings” to go to the e-mail s ettings
interface. Touch “Add Account” to add a n ew e-mail account.
Note: You can set several e-mail ac counts. The default account will show whenever you perform
e-mail apps.
Account name Dis play and change an account name
Your name Display and change the sender ’s name of the account.
Signature Display you signature at the bottom of your em ail.
Quick responses Edit text that you frequently insert when composing email.
Default account Send e-mails from this account b y default.
Inbox check
frequency
E-mail notifications Notify in Notification bar when e-m ail arrives
Choose ringtone Set the ringtone used whe n an e-mail is received
Incoming settings Display and change the r eceiving server settings
Outgoing settings Display and change the se nding server settings
Remove account Remove user account.
8.2 Recorder
In the “Apps” interface, touch “Sound Rec” to go to t he record interface.
Touch “ ” to start recording or “ ” to stop recording.
white background.
Set the interval of receiving e-m ails. There are six options
available: Never, Every 5 minutes, Ever y 10 m inutes, Every
15 minutes, Every 30 minutes, and Ever y hour .
After recording is finished, touch “ ”
-34-
to play the just recorded file. Touch “Done” to s ave the just recorded file or touch “Discard” to not
save the
recorded file.
Note 1: The recorded file can be autom atically saved in flash so that you can find them in the
AudioPlayer “ playlists ->My recordings” to play.
Note: The naming rule of the recorded f ile: recording_Year+Month+Date+serial n umber.
8.3 Alarm
In the “Apps” interface, touch “Clock” to the clock interface.
Touch “Set alarm” to enable the alarm func tion.
8.3.1 Set alarm
1. Touch the preset alarm to select an alar m or touch “Add alarm” to add new alarm.
2. Touch “Time”, and set the time for the al arm. Slide your finger up and down to adjus t the time,
and touch “Set” to complete.
3. Touch “Repeat,” select the date you want th e alarm to ring, and touch “OK”.
4. Touch “Ringtone” and select alarm ringtone. After selection, the ringtone will be played
temporarily.
5. Touch the “Label”, set the name of the a larm.
6. Touch the “Done” icon to go back to the alarm interface.
Tip: Touch “ □ ” to turn on or turn off the alarm.
-35-
Note: When it is shut down, the alarm is not affected.
8.3.2 Delete alarm
Touch and hold the alarm you want to de lete and touch “Delete alarm -> OK” to delet e it.
8.4 Calculator
In the apps interface, touch the “Calculator” icon to go to the calculator interface.
You can perform the basic math operati ons by this calculator.
8.5 Explorer
In the “Apps” interface, touch “Explorer” t o go to the Explorer interface that includes the fol lowing
options:
T ouch to return to the root directory.
Home
Level Up Touch to return to the u pper level directory.
Multi Touch to select multiple f iles.
Editor Allow you to Copy, delete, move, paste, r ename or send files.
NewFolde Create a ne w folder.
Back Back to the previous operation.
Next Back to the next oper ation.
Note: This product complies with the f at32 file system. When you name a file, do not us e special
characters, or you may not rename it la ter.
8.6 Installing apps
1.Copy the setup file to your PC. (Make sure the format of the setup file is xxx.apk format
supported by this product.)
2.Connect the device to PC using USB ca ble.
3.Copy the setup file xxx.apk to the device.
4.Disconnect the device from PC.
5.Activate Explorer.
6.Locate the xxx.apk file and touch it to open.
7.Install the app according to the on-sc reen prompts.
8.After completion, you will see the i nstalled app in the apps interface.
8.7 Uninstall app
1. In the apps interface, touch and hold the a pp you want to uninstall.
2. Move the app to trash can and touch “ OK” to uninstall it.
Tip: You cannot delete the pre-install ed factory default app on this product.
-36-
Chapter 9 Settings
In apps interface, touch the “Settings” ico n to go to the “Settings” interface.
9.1 WIRELESS & NETWORK Settings
9.1.1 Wi-Fi network connection
Connection
1. Touch “Wi-Fi” to enter into W i-Fi settings interface.
2. Slide the slider to right to enable W i-Fi and scans for available wireless networks.
3. Touch the desired wireless network name to connect to it. You will be prompted, if a pas sword
is required.
4. If static IP address needs to be e ntered, touch “show advanced options” for more options. Then
click on “show advanced options to sho w “IP s ettings”. Touch the pop-up menu and select “static”.
Then enter the IP address, gateway, net work m ask, and DNS information required for such Wi-Fi
network connections.
5. If you use dynamic IP address k eep the default "DHCP" in the “IP settings” opt ion.
Note: The word "Connected" displayed und er the network name indicates a successful
connection.
Afterwards you can surf the Internet, connec t to email services, etc.
Note 1: When you connect Wi-Fi for the f irst time and the prompt “Failed” appears, discon nect
Wi-Fi and reconnect it. When you in put an incorrect password and the prompt “Authe ntication
problem” appears, touch the network and touc h “Forget”, then connect with correct password.
-37-
Note 2: You do not have to re-enter the pas sword when you re-connect to the previously
connected wireless network that is encr ypted, unless you reset the product to the factor y settings.
Note 3: Auto search for Wi-Fi is perf ormed, i.e., no additional steps are required to c onnect to the
Wi-Fi network. For some closed wireless networks, the username or password may be req uired.
Note 4: The availability of W i-Fi signals may depend on the distance, infrastruc ture, and objects
through which a signal must pass.
Scan
Touch "Menu icon ( ) -> Scan" icon at the top right corner of screen to search for the available
wireless networks in the vicinity.
Advanced settings
Network notificationSelect to notify you when an open network is available.
Keep Wi-Fi on during
sleep
MAC address Shows the tablet’s Wi-Fi MAC address
IP address Shows the tab let’s IP address
Checking status of wireless network
You can check the status of the currentl y con nected Wi-Fi through the following methods:
·Status bar
After the product is connected to the
wireless network, the status bar shows the
Wi-Fi icon “ ” and signal strength (the
number of the bars lighting up).
·Wi-Fi network
In the network connection interface, touch “W i-Fi settings” and touch the currently connected
wireless network to show the inform ation, such as name, status, speed, signal strength, an d
security.
Tip1: If you want to remove the network settings, touch “Forget” in this window. If you want t o
connect to this network, the settings shou ld be configured again.
Connecting to other Wi-Fi networks
In the “Wi-Fi” settings interface, touch “+” ic on at the top right corner, enter the correspond ing
Choose under which condition (Alwa ys, Only when
plugged in or Never) to keep W i-Fi on when tablet is in
standby mode.
-38-
network settings, and touch “Save”.
Tip 2: Not all wireless networks are connecte d to the Internet. Some wireless network s may be
connected to several computers and cann ot be connected to the Internet.
9.1.2 Bluetooth connection
Turn on Bluetooth
1. Touch “Bluetooth” to enter into Bluetoo th interface.
2. Slide the slider to right to enable B luetooth and the Bluetooth zone show the nam e of the
available Bluetooth device.
3. Tap the menu icon at the top right of s creen.
Rename Device
Touch to change the name of your device.
Visibility timeout
Touch to choose how long (2 minutes, 5minutes, 1 hour or Ne ver time out) to keep your device in
discoverable mode. Touch the name of your device in “Bluetooth” settings interfa ce to make the
other device can search to your device.
SEARCH FOR DEVICES
Touch “SEARCH FOR DEVICES” to search f or the available Bluetooth device in the v icinity.
Paring
Touch one of the available devices. The tablet will pop up the “Bluetooth pairing reques t” window
and provide a four (4) digit num ber pairing code to enter on the device to be paire d. After entering
-39-
the same paring code, touch “Ok” to finish the paring process.
Connection
If you want to use Bluetooth keyboard or he adset, touch name of the device to connect.
9.1.3 Data usage
Show the usage per app statistics in per da y.
9.1.4 More
VPN: Add VPN network.
Portable hotspot: (Only for tablets with 3G/4G connections or USB Network Interface Card)
Mobile networks: 3G or 2G networks can be used via 3G Dong le.
9.2 DEVICE Settings
9.2.1 Sound
Volumes
Default notification Set your default notification ringtone.
Touch sounds Play sound when touc h screen.
Screen lock sounds
9.2.2 Display
Brightness
Wallpaper
Sleep
Font size
Music, video,
games &
other media
Notifications
Alarms
Adjust the screen brightness. Touc h the brightness bar
to adjust the volume level and touc h “OK” to save.
Choose wallpaper from Gallery, Live Wallpapers or
Wallpapers.
Select the delay time before the scree n automatically
closes. There are six options
available: 15 seconds, 30 seconds, 1 m inute, 2 minutes,
5 minutes,10 minutes, 30 minutes.
Set the font size of tablet. There are four options
available: Small, Normal, Large and H uge.
Set the media volume for music and video .
Touch the volume bar to adjust the volum e
level.
Set the notification volume by touc hing the
volume bar to adjust the volume level.
Set the alarm volume by touching the
volume bar to adjust the volume level.
Play sounds when locking and
Un-locking the screen.
-40-
9.2.3 HDMI
Turn on HDMI
HDMI Resolution Select the desire HDMI resolution to output.
Screen Zoom Slide the slider to adjust the zoom of HDMI output.
Screen Timeout
9.2.4 Screenshot Setting
Select delay time to capture
the screen
Set the location of screenshot
storage
Show the screenshot button
in the status bar
9.2.5 Storage
INTERNAL
STORAGE
NAND
FLASH
After SD card and USB drive plugged in, the following options will appear.
SD card
Selected to enable HDMI .
Select the delay time before the scree n automatically
closes.
Screenshot will be delayed according to the
Total space
Apps Show the used space of the apps.
Available
Total space
Apps Show the used space of the apps.
Pictures, videos
Available
Erase storage
Total space
Available Show the free space on the SD card.
Unmount storage Safely remove the SD card loc ally.
Erase storage Erase all data on the SD card.
selected time.
Set a location to store the screenshots.
Click on check-box to display the shortc uts
screenshot camera-icon on status bar.
Show the total capacity of the Internal
Memory.
Show the remaining free space of the da ta
memory.
Show the total capacity of the built-in Flash
memory.
Show the used space of pictures and
videos.
Show the remaining free space of the Nand
Flash.
Erases all data on the Nand Flash , such as
music and photos.
Show the total capac ity of the SD card.
-41-
Total space Sho w the total capacity of the USB drive.
USB Disk
Touch the menu icon at the top right cor ner of screen, touch “USB computer connection.
CONNECT AS
9.2.6 Battery
It shows the status of battery and the elapsed t im e of use
9.2.7 Apps
Manage and delete installed apps: For un install apps, clear data, clear cache, clear default and
force stop.
9.3 PERSONAL Settings
9.3.1 Location services
Google’s location
service
Location & Google
search
9.3.2 Security
Screen lock Lock screen with Slide, Face Unlock, Pattern, PIN , or
Automatically lock Set the dela y tim e to run automatically lock after sleep.
Power button
instantly locks
Owner info Show the inf ormation user want you display on lock screen.
Make passwords
visible
Device
administrators
Available Show the free space o n the USB drive.
Unmount storage Safely remove the USB dri ve locally.
Erase storage Erase all data on the USB drive.
Media device
(MTP)
Camera(PTP)
Mass Storage
Select to allow Google’s location ser vice to collect
approximate location data from Wi-Fi or m obile networks.
Select to allow Google to use location f or improved search
results and other services.
Password.
Selected to instantly lock the screen af ter power button
press.
After this feature is enabled, the pass word is shown when
the keyboard is used to type it.
View or deactivate device administrators.
It lets you transfer files on Windows, or
using Android File Transfer on MAC.
It lets you transfer photos using cam era
software.
Use Mass Storage to share files (Mac or
Windows).
-42-
Unknown sources Select to allow installation of non-Market apps .
Trusted credentials Display trusted CA certificates
Install form SD card Install certificates f rom SD card
Clear credentials Remove all certificates.
9.3.3 Language & input
9.3.4 Backup & reset
Select languag e for device
Language
Spell checker Selec t to enable spellchecker.
Personal dictionary Add & remove words form user dictionar y
Default Set the default input method.
Android keyboard Touch settings icon to set Android keyboard.
Google voice typing Select to enable Google voice typin g.
Voice Search T ouch to set language , SafeSearch, Block offensive
Text-to-speech
output
Pointer speed Set the pointer speed of (optiona l) mouse and trackpad.
Backup my data
Backup account Choose the backup Google Account.
Automatic restore
Factory data reset Erases all data on tablet.
words and show hints.
Touch to set the preferred engine, s et the speed at which
the text is spoken, and ect.
Select to back up app data, Wi-Fi pas swords and other
Google settings.
After reset tablet, restore backed up setti ngs and data
from Google Account.
9.4 ACCOUNTS Settings
SYNC: Selected the options to turn on sync.
ADD ACCOUNT: Touch “+ADD ACCOUNT” to add corporate, Em ail or Google account.
9.5 SYSTEM Settings
9.5.1 Data & Time
Automatic Use network-provided tim e.
Set date Set year, month and day.
Set time Set hour and minute.
Select time zone Select the time zone.
Use 24-hour format Show 12-hour or 24-hour format
Choose date formatSelect the f ormat used for date display.
-43-
9.5.2 Accessibility
Identify Gesture Can collect all text you t ype , except passwords.
Talk Back Slide the slider to the right to enable the talk back.
Large text Select to show large text.
Auto-rotate screen
Speak passwords Allow spoken passwords
Text-to-speech
output
Touch & hold delay Set touch & hold delay to Short, Medium or Long tim e.
Enhance web
accessibility
9.5.3 About device
This option allows you to check inf orm ation about the battery status, Legal information, Model
number, Android version, Kernel version and Build nu mber.
When talkback is on, tablet provid es spoken feedback to
help blind and low-vision users .
When feature is checked on, the Landsc ape/Portrait
switching feature is enabled.
This product supports 4-direction rotat ion display.
Touch to set the text-to-speech settings.
Touch to forbid or allow Apps to install scripts from Google
-44-
Chapter 10 Using Micro SD (TF) Card
The external card supported by this prod uct is a Micro SD card, through which the capacity of
storage can be expanded. To install, i nsert the Micro SD card into the slot with the silk screen
lettering facing towards the back of tablet. Push into card slot until it is full y inserted and locks
inside the product. To remove Micro SD c ard, press the Micro SD card inward to ejec t it.
Note:
·Insert cards face-down into the card slot.
· Do not bend the card. The card should be in a protected case, when not in use.
· Keep the chip clean and avoid dust and chemicals.
· Format new Micro SD cards before first use.
· Avoid insertion and removal of the Micro SD card while in use to avoid damage or losing data.
· This product does not support the write-protect feature of Micro SD cards.
· Back up files on card before deleting data to avoid possible loss due to errors.
-45-
Chapter 11 About the Battery and Power
This product uses a built-in 7000mAh pol ym er lithium battery. When the provided power adapter is
connected, the battery is automaticall y charged.
When you charge this product for the f irst time, it is recommended to shutdown the prod uct and
charge it continuously for more than 8 hour s for optimal battery use.
When using a new product, the batter y should be fully charged and totally discharged f or the first
three times, to activate set a battery’s id eal lifecycle.
If charging is performed while the prod uct is in use, it takes a longer time to charge.
Charging time: Typically takes about 7 hours to charge. The actual time depends on the batt ery
level when starting to charge.
It is recommended to fully charge and disc harge the product once every 3 months to extend t he
lithium battery life.
Do not plug the charger into the electric out let when the product is not also connected to it
When tablet will not be used for an extende d period of time, fully charge the battery bef ore
storing. It should also be charged and dis charged about every three months.
If the battery ever gets too hot, the chargin g protection circuit will automatically open th e charging
circuit to protect the lithium batter y and the tablet.
When the battery is low, charge before us ing. When it is running out of power, charge the
machine using the provided charger.
Charge it if:
A. The battery charging icon indicat es that battery power is almost exhausted / reall y lo w
B. The system automatically shuts down . It also shuts down quickly after reboot.
C. After you press buttons, there is no resp onse.
-46-
Chapter 12 Firmware Updating / Resetting to Factory
For Firmware Updating:
1. Go to for the website (www.aoc.com or www.breezetablet.com ) to download the current / latest
firmware for your device..
2. Follow the instructions provided f or the model of AOC tablet being updated.
For Resetting to Factory:
Go to Settings \ Backup & reset a select “Fac tory data reset”. (This will erase all data on tablet! )
Another way to reset to factory settings is to:
a. Shut down the tablet and make sur e the USB and power cables are unplugged.
b. Press Power button and "+" buttons tog ether for 3 seconds.
c. Wait up to 15 seconds, until see Andr oid robot (on it's back).
d. Press and hold "+" and then press the "-" button. This will cause the tablet will go into the
"Android system recovery interface"
e. Select “wipe data/factory reset” or “r eboot system now”. (Navigate menu by press ing volume
up/down (“+” / “-”) buttons.)
f. Press the power button to perform s election.
The tablet will be restored to factor y defau lts and all data on device will be erased.
Note: During the upgrade / resetting process , it is best to have the device plugged into electric
power, using the supplied power adapt er.
.
-47-
Chapter 13 Frequently Asked Questions
· Product cannot be turned on or boots-up abnormally
There are various ways to recover/rese t the tablet once a problem has occurred:
① Plug the AC adapter and see if powers up; (because battery may be low on power).
② Another option is to press and hold the Power button for 6 to 10 seconds , to restart.
③ If above two methods do not restore the tablet to normal operating state;
a. Shut down the tablet and make sure the USB and p ower cables are unplugged.
b. Press Power button and "+" buttons tog ether for 3 seconds.
c. Wait up to 15 seconds, until see Android robot (on it's back ).
d. Press and hold "+" and then press the "-" button. This will cause the tablet will g o into the
"Android system recovery interface"
e. Select “wipe data/factory reset” or “reboot s ystem now”. (Navigate menu by pressing
volume up/down (“+” / “-”) buttons.)
f. Press the power button to perform s election.
The tablet will be restored to factor y defaults and all data on device will be erased.
· No sounds from headset
Check if the volume is set to 0 (lo west).
Check if the headset is properly conn ected (plugged all the way in).
· Loud / static noises
Check if the plug of the headset is cl ean. Dirt may result in noise.
Check if the file being played f or possible damage. Play other music files to confirm this. If it is
damaged,it may cause loud noises or sound skipping.
