AOC MW0812 User Manual

Table of Contents

CHAPTER 1 PRODUCT OVERVIEW .....................................................................................1

1.1 Functions overview..................................................................................................1

1.2 Notes .........................................................................................................................1

1.3 Packaging list...........................................................................................................2

1.4 Technical specifications..........................................................................................3

CHAPTER 2 BUTTONS AND APPEARANCE.......................................................................5

CHAPTER 3 EASYCONFIG....................................................................................................7

CHAPTER 4 BASIC OPERATIONS .....................................................................................11

4.1 Booting up ..............................................................................................................11

4.2 Shutdown................................................................................................................11

4.3 Network...................................................................................................................11

4.4 Locking key ............................................................................................................12

4.5 Reset........................................................................................................................12

4.6 Connecting to PC and file transfer.......................................................................12

4.7 Volume adjustment ................................................................................................ 12

4.7.1 Adjusting the media volume ......................................................................13

4.7.2 Adjusting the alarm volume .......................................................................13

4.7.3 Adjusting the notification volume .............................................................13

4.8 Charging .................................................................................................................13

4.9 Touch screen operations ......................................................................................14

4.10 Search button.......................................................................................................14

CHAPTER 5 COMMON FEATURES ....................................................................................15

-1-

5.1 Landscape/Portrait display switching .................................................................15

5.2 Using virtual keyboard to type .............................................................................16

5.2.1 Android keyboard........................................................................................16

5.2.2 Editing text...................................................................................................16

5.3 Notification panel...................................................................................................17

5.3.1 Opening notification panel.........................................................................17

5.3.2 Closing notification panel ..........................................................................17

5.4 Recently run applications .....................................................................................17

5.5 Changing wallpaper...............................................................................................18

5.6 Power control .........................................................................................................18

CHAPTER 6 MAIN INTERFACE...........................................................................................19

6.1 Main interface.........................................................................................................19

6.2 Applications interface............................................................................................20

6.3 Browser...................................................................................................................21

6.3.1 Opening browser.........................................................................................21

6.3.2 Going to a webpage ....................................................................................21

6.3.3 Setting a home page ...................................................................................21

6.3.4 Browsing a webpage...................................................................................21

6.3.5 Managing bookmarks..................................................................................23

6.3.6 Other functions............................................................................................24

6.4 Video player............................................................................................................26

6.4.1 Video playing ...............................................................................................26

6.4.2 Delete video .................................................................................................28

6.5 Audio player ...........................................................................................................28

6.5.1 Playlist..........................................................................................................29

6.5.2 Playing audio ...............................................................................................29

6.5.3 Sound effects...............................................................................................31

6.6 Picture browser......................................................................................................32

6.6.1 Browsing pictures.......................................................................................32

6.6.2 Picture file operation...................................................................................34

-2-

CHAPTER 7 APPLICATIONS...............................................................................................36

7.1 Moving a program icon of the interface...............................................................36

7.2 Deleting a program icon........................................................................................36

7.3 Restoring a program icon .....................................................................................36

7.4 Adding a program icon..........................................................................................36

7.5 Adding a Widget.....................................................................................................37

7.6 Creating a folder.....................................................................................................37

7.7 Renaming a folder..................................................................................................37

CHAPTER 8 COMMON TOOLS ...........................................................................................38

8.1 E-mail.......................................................................................................................38

8.1.1 Opening e-mail.............................................................................................39

8.1.2 Creating and sending e-mails ....................................................................39

8.1.3 Receiving and reading e-mail.....................................................................40

8.1.4 Replying or forwarding e-mail....................................................................40

8.1.5 Managing e-mail ..........................................................................................41

8.1.6 Create new account.....................................................................................41

8.1.7 Account settings .........................................................................................41

8.1.8 Delete e-mail account .................................................................................42

8.2 Recorder .................................................................................................................42

8.3 Alarm.......................................................................................................................43

8.3.1 Set alarm ......................................................................................................44

8.3.2 Add alarm .....................................................................................................44

8.3.3 Delete alarm .................................................................................................44

8.3.4 Alarm settings..............................................................................................44

8.3.5 Changing alarm display..............................................................................44

8.4 Calculator................................................................................................................45

8.5 Explorer...................................................................................................................45

8.6 Installing applications ...........................................................................................45

-3-

8.7 Uninstall application..............................................................................................45

CHAPTER 9 SETTINGS .......................................................................................................47

9.1 Wireless & network settings.................................................................................47

9.2 Settings...................................................................................................................51

9.2.1 Wireless & networks ...................................................................................51

9.2.2 Sound ...........................................................................................................51

9.2.3 Display..........................................................................................................52

9.2.4 Security ........................................................................................................52

9.2.5 Applications ................................................................................................. 53

9.2.6 Accounts & sync .........................................................................................53

9.2.7 Privacy.......................................................................................................... 53

9.2.8 Storage .........................................................................................................53

9.2.9 Language & keyboard.................................................................................54

9.2.10 Voice input & output .................................................................................54

9.2.11 Accessibility...............................................................................................54

9.2.12 Date & time.................................................................................................55

9.2.13 Touch screen calibration..........................................................................55

9.2.14 About device..............................................................................................55

CHAPTER 10 USING MICRO SD (TF) CARD......................................................................56

CHAPTER 11 CONNECTING TO USB DRIVE ....................................................................57

CHAPTER 12 ABOUT THE BATTERY AND POWER.........................................................58

CHAPTER 13 FIRMWARE UPDATING / RESETTING TO FACTORY ...............................59

CHAPTER 14 FREQUENTLY ASKED QUESTIONS ...........................................................60

CHAPTER 15 TROUBLESHOOTING...................................................................................62

-4-

Chapter 1 Product Overview

1.1 Functions overview

z 8 inch wide screen True Color TFT touch screen with a high resol ution of 800*600

pixels.

z Surf the Internet wirelessly via W i-Fi to enjoy the Internet on the go.

z Support all mainstream e-mail servic es for more convenient e-mail sending and

receiving.

z Switching between portrait m ode and landscape mode is possible through gravity

sensing. Four-direction rotation disp lay is supported.

z Support Video Player, Audio Player, Photo Browser and Shelves.

z Equipped with a built-in microphone, enab ling audio-recording.

z Eco settings enables the brightness to be freely adjusted.

1.2 Notes

z Do not use the unit in an overly hot, cold , wet, or dusty environment. Do not expose it

to sunlight.

z Try not to use this unit in an environment with a strong magnetic field or static

electricity.

z Avoid dropping this unit or strong impacts.

z The adapter of this product should not be dropped and splashed with liquid. Any

object filled with liquid, such as a vas e, should not be placed on the top of it.

z There are no user-serviceable parts inside the product. Do not dismantle this unit.

Otherwise, the warranty may be voided. Contac t servicing personnel if you need

help.

z The battery life may vary depending on th e use condition and production time.

z It is not allowed to replace the batter y of the product yourself. Do not dism antle the

unit yourself. Explosion may occur if the battery is not properly replaced. Contact the

-1-

professional servicing personnel.

z As the workmanship of motherboard m anufacturers are different from each other, it

is recommend to perform charging using the adapter provided, instead of using the

USB port of the motherboard, to ensure ch arging stability.

z The long life of a lithium batter y is due to its much smaller memory effects than that

of the regular Nickel-Cadmium battery. But if the lithium battery is degrading, contact

the local Service Center directly.

z If the battery is improperly replaced, an explosion may occur. Only use the same

brand battery or equivalent for replacement.

z The company is not liable for the data loss or d eletion on machine resulting from the

misuse of software, improper operation of the battery, servicing, other accidents, or

other indirect loss thereof.

z The actual product may be different from that described in the Instructions due to the

software update. These Instructions are for inform ational purposes only.

z This being a mobile product, we recom mend you back-up your data regularly.

1.3 Packaging list

AOC Breeze Tablet Unit X1

USB cable X1

Power adapter X1

Quick Start Guide X1

About the Touchscreen X1

Warranty Statement X1

Touch Pen X2 Note: The actual accessories provided with the product may vary.

-2-

1.4 Technical specifications

Basic specifications

Model no. AOC Tablet MW0812

Installed OS

Processor (CPU) ARM Cortex-A8,Cpu Frequency Up To 1G Hz

Memory 512MB

WLAN

Bluetooth

Storage capacity Built-in 4GB Flash Memory

Expansion cards Micro S D (TF) card, up to 32 GB.

LCD

Audio output

Power specifications

Voltage Supply voltage: 5V Charging voltage: 5V

Current

Battery used

Power adapter

Charging time

Android OS 2.3

WI-FI IEEE 802.11b/g/n

Bluetooth 2.1 + EDR

8 inch HD TFT LCD touch screen (resistive single to uch) with a resolution of 800*600 pixels

Headset: Stereo output; internal speak ers: Mixed output.

Max. current for playback is 1A DC.

Max. current for charging is 1A DC.

Built-in lithium-ion polymer rechargea ble battery, 3.7V,

4800mAh

AC input：100-240V 50/60Hz DC input ：5V 2.5A

It takes about 7 hours for the battery to be f ully charged

when the provided charger is used with power-down. The

charging time may vary depending on the remaining

battery level.

Note: Do not charge the battery for more than 12 ho urs

when the charger is used.

-3-

Battery use time

(Under the condition

that the battery is full y

charged in a normal temperature)

External dimensions

Dimension (L×W×H) 8.46 x 5.7 x 0.57 in (21.5 x 14.65 x 1.45 cm)

Weight 1.16 lbs (0.525kg) (with battery)

Port Mini USB 2.0 high speed port, OTG , 3.5mm headset

Environmental conditions

Operating

temperature

Storage temperature

Max. humidity

Supported OS Windows2000/XP/Windows 7/Vista, Macintosh OS X]

Note: Windows 2000＋SP1/SP2 is n ot supported by this product. The user should

upgrade to SP3 or above. This product do es not guarantee all video formats are

playable. Even if some formats are listed in the Instructions, they may be not properly

played. This is normal.

Audio: About 18 hours

Video: About 6 hours

Web browsing: About 7 hours

0°C ~ 40°C

-20°C ~ 55°C

90% RH (non-condensation)

-4-

Chapter 2 Buttons and Appearance

C. Operation indicator

D. Home button: Press to return to the main in terface; press and hold to bring

out the 8 applications recently run.

E. M button (Menu button): Open the corresponding menu. G. Built-in MIC Recording H. Touch screen (“Screen”) I. External speaker

B. Volume “+” and “-” buttons A. Power button

F. Back button

-5-

J K

J. Headset jack

L. OTG port (connecting to USB

drive)

N. Power cable jack O. Reset button

Note 1: During operation, sounds will be autom atically output from the external

speaker if there is audio output.

Note 2: In the Instructions, “Press” means tapping a button while “Press and Hold”

means continuously pressing a button f or 2 ~ 3 seconds.

Note 3: The Volume “+” and “-” icons, Back icon, and Menu icon function as th e

“volume adjustment button”, “back button” and “menu button” on the top and front of the unit.

You can make selections based on your preferences. They will not be described in the

sections below.

-6-

K. MINI USB port (connecting

to PC)

M. TF card slot

Chapter 3 EasyConfig

When first using the tablet breeze，t he EasyConfig window will pop up. It includes Language,

Date/Time, Calibration and Wi-Fi settings .

Tap “Click” to setup language, then choose a la nguage you want. If the settings take effect,

the “Default Language” bar will show the c hoice.

-7-

Tap “Click” to go to “Date & time settings ” interface to setup date, time zone and time.

Tap “Click” to setup calibration, then set the touch points according to the steps in the

on-screen prompt.

When the calibration setting is succ essful, the wi-fi settings window will pop up.

-8-

Press the M button to configure the “Scan” or “Advanced” settings for Wi-Fi network.

Scan: Search for the available wire less networks in the vicinity.

Advanced settings:

1. Tap “Advanced” to set the network addres s within the IP locale.

2. Select “Use static IP” to configure the n etwork settings and enter the IP address, gateway,

-9-

network mask, and DNS1 required for W i-Fi network connection.

After configuration, press the M button, tap "Save" to exit to the the wi-fi settings interface with

saving.

Note: When you use dynamic IP address es, you do not have select “Use static IP addresses” to configure the network settings.

Tap the wireless network you want to connec t to. If the connection status under the name of

wireless network shows “Connected”, the n etwork connection is successfully. Then tap “End”

to finished the easyconfig.

-10-

Chapter 4 Basic Operations

4.1 Booting up

Press and hold the Power button for abo ut 2 seconds. After the boot screen is shown

(for about 1 minute), the unlock interf ace is shown. Tap and hold the unlock icon at the

bottom left corner of the screen and drag it upward to the dot to unlock it. Once

unlocked, the main Interface will be sh own.

4.2 Shutdown

In any mode, Press and hold the Power butto n for about 2 seconds. The device

shutdown options will appear:

a. Tap “Power off” to turn off the product.

b. Tap “Silent mode” to turn on or turn off all sound except media & alarms.

Note 1: If the battery is low, the product will shutdown automatically.

Note 2: If the product is connected to the char ger, disconnect the charger and perform

the shutdown operation again.

Note 3: If the product crashes during operat ion, press and hold the Power button for 6

seconds to force shutdown.

Note 4: During operation, press the Power b utton for 1 second to enter Standby mode.

4.3 Network

To surf the Internet wirelessly, make s ure the Wi-Fi wireless network signals are

present and set the Wi-Fi network connec tion. There are two ways of going to the

“Wireless & Networks” settings in terface:

a. Press the M button in the main interf ace and tap “Settings->Wireless & Networks”.

b. In the main interface, tap the “

and tap “Settings->Wireless & Network s”.

Note 1: Turn on Wi-Fi in an area where the W i-Fi wireless network signals are present.

After successful connection, you can surf the Internet through your browser.

” icon at the right to go to the applica tions interface,

-11-

Note 2: For detailed settings, refer to “ 8.1 Network Connection” .

4.4 Locking key

During use, you can lock the keypad to loc k the keys and touch screen to avoid

accidental operation.

Lock: Press the Power button to lock .

Unlock: Press the Power button. After th e screen lights up, tap and hold the unlock

icon at the bottom left corner of the scr een and drag it upward to the dot to unlock it.

Once unlocked, the main Interface will be shown.

4.5 Reset

If the product crashes during operation, you can tap the Reset button on the si de to

reset the system.

Note: Under normal operation, do not use the R eset button as the Shutdown button.

4.6 Connecting to PC and file transfer

When the product is on, plug the smaller end of the provided USB cable to the MINI USB

port on the side, and the larger end to the USB port of PC for the use of the removable disk

and data transfer. Then the USB connected i nterface will pop up, tap “Turn on USB storage”.

When the word changed to “Turn off USB s torage”, the connection is successful. You may

copy music and video files t o the product directly without using third party programs. F inally,

tap the "Safely Remove Hardware" icon at the bottom right corner of the PC screen to

remove the device safely.

Note: After the product is connected to PC , you can still surf the Internet via Wi-Fi but

you cannot play video, music, pict ures, or recording voice involving the Flash drive

and TF card.

4.7 Volume adjustment

Media volume: Adjust the volume f or playing music and video.

Alarm：Adjust the volume of alarm .

Notification volume: Adjust the vo lume of notification ringtones.

-12-

4.7.1 Adjusting the media volume

There are two ways of going to the “Media Volume” adjustment interface:

·In any interface, press or press and hold th e Volume +/- button on the top of the

product to adjust the media volume.

·In the main interface, press the M button, t ap “Settings -> Sound -> Volume” , tap the

media volume bar to adjust the volum e after the Volume window appears.

4.7.2 Adjusting the alarm volume

There are two ways of going to the “Alarm Volume”adjustment interface:

·In the main interface, press the M button, tap “Settings -> Sound -> Volume”, tap the alarm

volume bar to adjust the volume af ter the Volume window appears.

·In the alarm application, press the M button, tap “settings -> Alarm volume”, tap the alarm

volume bar to adjust the volume.

4.7.3 Adjusting the notification volume

In the main interface, press the M button , tap “Settings -> Sound -> Volume”, tap the

notification volume bar to adjust the volume after the Volume window

appears.

4.8 Charging

When the battery is low, the provided adapter can be used to charge it.

1. If the product is powered on during char ging, the status bar will show the charging

icon ( ). After the battery is full y charged, the bar will show the f ull battery icon

(

2. If the product is shutdown duri ng charging, the large charging icon interface will be

displayed. After the battery is full y charged, the full battery icon( )will be shown; in

the large charging icon interface, pres s the Power button according to the prompts to turn on.

Note 1: Check the detailed charging percentag e through “Settings->About

Device->Status->Battery Level”.

Note 2: To extend battery life, avoid char ging the battery frequently when it is in high

-13-

level. (example: more than 90%) It is not r ecommended to charge the product at this

time; if charging is performed at this t ime, the percentage shown may not be 100%.

This is normal.

Note：Please charge timely to ensure the device works well, when the batter y is low.

4.9 Touch screen operations

Tip: The display used in this product is a resistive single touch screen. When using,

you can operate it by using the buttons on its body or tapping the corresponding

buttons on the display with a pen or fing er to enable the corresponding functions.

Tap

Tap the screen buttons to release. W hen you want to use the on-screen keyboard to

type, or press the on-screen buttons, touch t hem using your finger.

Tap and hold

Touch the screen button continuously unt il the option expands.

Slide

Place and slide your finger on the scr een. Slide your finger up or down to scroll up or

down; or if the list has a scroll bar, sl ide your finger up or down in the list to page down

or up; when you are browsing pictures, slide your finger to the left or to the right to

view the previous or next picture.

4.10 Search button

In the main interface, press the M button and tap the “Search” button to search for the

relevant information using the browser .

-14-

Chapter 5 Common Features

5.1 Landscape/Portrait display switching

1. In the “Settings” interface, tap “Settings -> Display ->Auto-rotate screen. ” When

the “√ ” symbol appeared, the Landscape/P ortrait screen display switching is on;

when the “√” symbol disappeared, the Landscape/ Portrait screen display switching is

off.

2. Hold this product vertically with your hands and tilt it to the left or right. When it is

tilted to a position 90° to the horizo ntal plane, the gravity sensor built in the product

senses the action and the screen switches to Portrait mode from Landscape mode.

On the contrary, when it is tilted to a pos ition 0° to the horizontal plane, the screen

switches to Landscape mode from Por trait mode.

Tip: This product supports 4-direction rot ation display.

Note 1: For gravity sensing (displa y orientation), the screen orientation will not change

if this product is placed on the level and stationary surface, regardless of how you

rotate the product.

Note 2: For some interfaces, such as the main interf ace, video player interface, and online

video interface (full screen m ode), gravity sensing will be disabled.

-15-

5.2 Using virtual keyboard to type

Tap any text input box to pop up the virtua l keyboard as shown below. Use this

keyboard to type any text or characters.

5.2.1 Android keyboard

B C

A. Show box: Show the text typed. Tap and hold this box to display the Edit

Text menu for you to cut, copy, and paste the tex t. Switching between input methods is also possible.

B. Tap this button to switch between upper case and lowercase text.

C. Tap this button to switch between num eric keypad and symbol keyboard;

For numeric keypad and symbol ke yboard, tap the ATL button to display the special symbols (such as ~, ±, ÷, ×,e tc.).

D. Tap this button to input space. E. Tap to delete the edited text.

Tip: During the input process, you can m ove the cursor by tapping a position.

5.2.2 Editing text

The typed text can be edited.

When there is text in the input field, tap a nd hold the input field (or tap and hold the

show box in the keyboard) to open the Edi t Text menu. Tap the options in the menu to

edit the text.

-16-

D E

Select word Select one word Select all Select all text typed Cut Cut text typed Copy Copy text typed Paste Paste cut or copied text

Input method Select the Input method

Add “*” to dictionary

Add the text you type to the dictionary.

5.3 Notification panel

The notification icon appears when a m essage is received, PC is connected, or music

is played. You can open the notificati on panel to check for messages and played music.

5.3.1 Opening notification panel

After a new notification icon appears in the status bar, tap and hold the status bar and

slide your finger downward to open the notification panel.

Tip: In the interface, press the M button and tap “Notifications” to open the notification

panel.

5.3.2 Closing notification panel

Tap the control bar at the bottom of the notification panel and slide your finger up on

the screen or press the Back button.

5.4 Recently run applications

Press and hold the Home button to show th e 8 applications recently run. Tap the icon

in the window to open the corresponding application.

-17-

+ 50 hidden pages
