Aoc LM727 User Manual
TABLE OF CONTENTS
FOR YOUR SAFETY -------------------------------------------------- 1
SAFETY PRECAUTIONS -------------------------------------- 2
SPECIAL NOTES ON LCD MONITORS ------------------- 3
BEFORE YOU OPERATE THE MONITOR --------------------- 3
FEATURES -------------------------------------------------------- 3
PACKING LIST --------------------------------------------------- 3
CONTROLS AND CONNECTORS -------------------------- 5
ADJUSTING THE VIEWING ANGLE ----------------------- 6
OPERATING INSTRUCTIONS ------------------------------------- 7
GENERAL INSTRUCTIONS ---------------------------------- 7
HOW TO ADJUST A SETTING ------------------------------ 9
ADJUSTING THE PICTURE ---------------------------PLUG AND PLAY ----------------------------------------------- 12
TECHNICAL SUPPORT(FAQ) ----------------------------------- 13
ERROR MESSAGE & POSSIBLE SOLUTION ------ 14
HOW TO INSTALL INF & ICM FILE ----------------------- 15
APPENDIX --------------------------------------------------------------16
SPECIFICATIONS ------------------------------------------ 16-17
FACTORY PRESET TIMING TABLE ---------------------CONNECTOR PIN ASSIGNMENT ------------------------ 19
10-11
18
Before operating the monitor, please read this manual thoroughly. This manual
should be retained for future reference.
FCC Class B Radio Frequency Interference Statement
WARNING: (FOR FCC CERTIFIED MODELS)
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
NOTICE:
1. The changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
2. Shielded interface cables and AC power cord, if any, must be used in order
to comply with the emission limits.
3. The manufacturer is not responsible for any radio or TV interference caused
by unauthorized modification to this equipment. It is the responsibilities of
the user to correct such interference.
As an
ENERGY STAR
meets the
WARNING:
ENERGY STAR
®
Partner our company has determined that this product
®
guidelines for energy efficiency.
To prevent fire or shock hazard, do not expose the monitor to rain or moisture.
Dangerously high voltages are present inside the monitor. Do not open the
cabinet. Refer servicing to qualified personnel only.
1
PRECAUTIONS
z Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen
sink, laundry tub, swimming pool or in a wet basement.
z Do not place the monitor on an unstable cart, stand, or table. If the monitor
falls, it can injure a person and cause serious damage to the appliance. Use
only a cart or stand recommended by the manufacturer or sold with the
monitor. If you mount the monitor on a wall or shelf, use a mounting kit
approved by the manufacturer and follow the kit instructions.
z Slots and openings in the back and bottom of the cabinet are provided for
ventilation. To ensure reliable operation of the monitor and to protect it from
overheating, be sure these openings are not blocked or covered. Do not
place the monitor on a bed, sofa, rug, or similar surface. Do not place the
monitor near or over a radiator or heat register. Do not place the monitor in a
bookcase or cabinet unless proper ventilation is provided.
z The monitor should be operated only from the type of power source indicated
on the label. If you are not sure of the type of power supplied to your home,
consult your dealer or local power company.
z The monitor is equipped with a three-pronged grounded plug, a plug with a
third (grounding) pin. This plug will fit only into a grounded power outlet as a
safety feature. If your outlet does not accommodate the three-wire plug, have
an electrician install the correct outlet, or use an adapter to ground the
appliance safely. Do not defeat the safety purpose of the grounded plug.
z Unplug the unit during a lightening storm or when it will not be used for long
period of time. This will protect the monitor from damage due to power surges.
z Do not overload power strips and extension cords. Overloading can result in
fire or electric shock.
z Never push any object into the slot on the monitor cabinet. It could short
circuit parts causing a fire or electric shock. Never spill liquids on the monitor.
z Do not attempt to service the monitor by yourself; opening or removing covers
can expose you to dangerous voltages and other hazards. Please refer all
servicing to qualified service personnel.
z To ensure satisfactory operation, use the monitor only with UL listed
computers which have appropriate configured receptacles marked between
100 - 240V AC, Min. 5A.
z The wall socket shall be installed near the equipment and shall be easily
accessible.
z For use only with the attached power adapter (Output 12Vdc) which have
UL, CSA listed license
2
SPECIAL NOTES ON LCD MONITORS
The following symptoms are normal with LCD monitor and do not indicate a
problem.
NOTES
• Due to the nature of the fluorescent light, the screen may flicker during initial
use. Turn off the Power Switch and then turn it on again to make sure the
flicker disappears.
• You may find slightly uneven brightness on the screen depending on the
desktop pattern you use.
• The LCD screen has effective pixels of 99.99% or more. It may include
blemishes of 0.01% or less such as a missing pixel or a pixel lit all of the time.
• Due to the nature of the LCD screen, an afterimage of the previous screen
may remain after switching the image, when the same image is displayed for
hours. In this case, the screen is recovered slowly by changing the image or
turning off the Power Switch for hours.
• When the screen becomes black or flashing, or cannot illuminate any more,
contact your dealer or service center to replace parts. Don’t repair the screen
by yourself!
BEFORE YOU OPERATE THE MONITOR
FEATURES
• 43.2cm(17”) TFT Color LCD Monitor
• Crisp, Clear Display for Windows
• Recommened Resolutions: 1280 X 1024 @60Hz
• EPA ENERGY STAR
• Ergonomic Design
• Space Saving, Compact Case Design
CHECKING THE CONTENTS OF THE PACKAGE
The product package should include the following items:
1. LCD Monitor
2. Owner's Manual
3. Power Cord & Signal cable
4. External Adapter
5. Driver-Disk
®
3
POWERCORD:
1. Make sure that the power cord is the correct type required in your area.
2. This LCD monitor has an External universal power supply that allows
operation in either 100/120V AC or 220/240V AC voltage area (No user
adjustment is required.)
3. Connect the AC-power cord into your LCD monitor’s External Adapter input
socket, and then plug the other end of External adapter to LCD monitor’s DCpower-input. The AC-power cord may be connected to either a wall power
outlet or the power outlet socket on your PC, depending on the type of power
cord supplied with your LCD monitor.
4
CONTROLS AND CONNECTORS
SIGNAL CABLE
Connecting the Signal Cable: the LCD monitor comes with a built-in signal
cable. Plug the signal cable′s 15-pin connector into the computer's VGA port and
tighten the two screws on the cable connector.
Connecting the Power Cord: Plug the AC-p ower cord into the External Adapter.
Then plug the DC-jack power cable into DC-IN Inlet.
Caution: If the AC outlet is not grounded (with three holes), install the proper
grounding adapter (not supplied).
Figure 1 Connecting Cables
1. Signal Cable 2. DC-Jack Power Cable
3. AC Power Cord 4. External Adapter
