AOC H428PW Schematic

42’’ Flat Wide Monitor AOC H428Pw

Service

Service

Service

Description Page Description Page

Table Of Contents.......……..............................…........1

Important Safety Notice.......................................……......2

Revision List…………........................................……......3

1. General Specification….............................………........4

2. Operating Instructions…...………………….……….......5

2.1.Front Buttons and Connections…….………….….....5

2.2.OSD Function……..…...…………………….………...7

3. Input/Output Specification…………....................…....11

4. Mechanical Instructions…………………….................12

5. Repair Flow Chart ……………………….…….…….....15

6 PCB Layout ………………..………………....….......17

6.1.Main Board…………..…………..……….……….......17

Table Of Contents

6.2.Power Board……..…………..………….……….......20

6.3. Key Board…..…………………………….……….......23

6.4.IR Board…………..………………..……….......23

7.Adjustment………..…………………........................24

8. Block Diagram.………….............................................25

9. Schematic………………....…….……..………………..26

9.1 Main Board…….……………..….…………….….......26

9.2. Power Board………………….……….………….......36

9.3.Key Board……….……….……….………….......38

9.4. Tuner Board…………..….…….…….………….........39

10. Exploded View..………………...........................…..40

11. BOM list.………….........................…..……………….41

SAFETY NOTICE

ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE

CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING

ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.

CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

1

42’’ Flat Wide Monitor AOC H428Pw
Important Safety Notice

Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service

procedures recommended by AOC and described in this service manual are effective methods of performing service

operations. Some of these service operations require the use of tools specially designed for the purpose. The

special tools should be used when and as recommended.

It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in

order to minimize the risk of personal injury to service personnel. The possibility exists that improper service

methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE

NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in

which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not

undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not

recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the

equipment will be jeopardized by the service method selected.

Hereafter throughout this manual, AOC Company will be referred to as AOC.

WARNING

Use of substitute replacement parts, which do not have the same, specified safety characteristics might create

shock, fire, or other hazards.

Under no circumstances should the original design be modified or altered without written permission from AOC.

AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.

Servicer assumes all liability.

FOR PRODUCTS CONTAINING LASER:

DANGER-Invisible laser radiations when open AVOID DIRECT EXPOSURE TO BEAM.

CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may

result in hazardous radiation exposure.

CAUTION -The use of optical instruments with this product will increase eye hazard.

TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S

REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF

THIS SERVICE MANUAL.

Take care during handling the LCD module with backlight unit

-Must mount the module using mounting holes arranged in four corners.

-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.

-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to

the panel.

-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).

-Make certain that treatment person’s body is grounded through wristband.

-Do not leave the module in high temperature and in areas of high humidity for a long time.

-Avoid contact with water as it may a short circuit within the module.

-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may

damage the panel.)

2

42’’ Flat Wide Monitor AOC H428Pw

Revision List

Version Release Date Revision Instructions TPV Model

A00 Aug.-27-2008 Initial Release J42RMNNSW1A4NN

3

42’’ Flat Wide Monitor AOC H428Pw

1. General Specification

4

42’’ Flat Wide Monitor AOC H428Pw

2. Operating Instructions

2.1 Front Buttons and Connections

2.1.1 Front Buttons

5

42’’ Flat Wide Monitor AOC H428Pw

2.1.2 Connections

6

42’’ Flat Wide Monitor AOC H428Pw

2.2 OSD Function

7

42’’ Flat Wide Monitor AOC H428Pw

8

42’’ Flat Wide Monitor AOC H428Pw

9

42’’ Flat Wide Monitor AOC H428Pw

10

42’’ Flat Wide Monitor AOC H428Pw

3. Input/Output Specification

3.1 Connectors

AC Power : Monitor rear side

Analog RGB : Monitor rear side / Data Cable : 15-pin D-sub female

Pin – Assignment of 15-pin D-sub:

1 Red Video 9 5V

2 Green Video 10 Sync Ground

3 Blue Video 11 Not Used

4 Not Used 12 Serial Data for DDC

5 Ground 13 H-Sync.

6 Red Ground 14 V-Sync.

7 Green Ground 15 Serial Clock for DDC

8 Blue Ground

S-Video (Y/C) : Monitor rear side : 4 Pin Mini-DIN female

Composite Video : Monitor rear side : RCA female

Component video : Monitor rear side : RCA female

Audio : Monitor rear side : RCA female (Red/White)

(right channel/left channel )

3.2 Factory Preset Timing table

Vertical Horizontal Dot Sync Polarity Presence Screen Mode

Dots × Lines

720 ×400 70.1 31.5 28.322 NEG POS YES YES YES YES

640 ×480

800x 600

1024x768 60.0 48.363 80.000 NEG NEG YES YES YES YES

1360x768 59.79 47.72 84.75 NEG POS YES YES YES YES

1440x900(R) 59.978 65.317 106.5 POS NEG YES YES YES YES

1280x768 59.870 47.776 79.500 NEG POS YES YES YES YES

1280x1024 60.020 63.981 108.000 POS POS YES YES YES YES

1680X1050 59.884 64.674 119.000 POS POS YES YES YES YES

Frequency Frequency

(Hz) (kHz) (MHz) (4:3) (16:9)

59.9 31.5 25.175 NEG NEG YES YES YES YES

72.8 37.9 31.500 NEG NEG YES YES YES YES

75.0 37.5 31.500 NEG NEG YES YES YES YES

60.0 37.9 40.000 POS POS YES YES YES YES

72.2 48.1 50.000 POS POS YES YES YES YES

75.0 46.87 49.500 POS POS YES YES YES YES

clock

Horizontal Vertical Horizontal Vertical Normal FULL

11

42’’ Flat Wide Monitor AOC H428Pw

4. Mechanical Instructions

1. Prepare: put the monitor on a soft,clean and flat surface as figure 1.

Figure 1

2. Remove the base as figure 2.

3. Remove the rear cover as figure 3.

Figure 2

Figure 3

12

42’’ Flat Wide Monitor AOC H428Pw

13

42’’ Flat Wide Monitor AOC H428Pw

4. Remove the main board,power board and AC socket as figure 4.

Figure 4

5. The end.

Figure 5

14

42’’ Flat Wide Monitor AOC H428Pw

5. Repair Flow Chart

5.1 No Power

No LED

Check the 5V power supply

Check the 300V voltage

Check IC931 power supply

5.2 No picture（LED green）

Check key board

NG

OK

NG

Replace relevant component

NG

Check F901,NR901,C905

NG

Check Q931,T931,D931,D933

Check key board and remote control

No picture

OK

OK

NG

Replace key board and
remote control

Check the power supply circuit

OK

Check U403(MCU)

NG

Replace U403

OK

Check I2C

NG

Replace I2C component

15

42’’ Flat Wide Monitor AOC H428Pw

t

5.3 No Display（LED green）

Check the backlight

NG NG

OK

Check LVDS connector

and LVDS cable

Check 24V
power supply

OK

Check PS signal

NG

OK

Check power board

OK

Check U403

OK

NG

Check U401

5.4 Abnormal Picture

Check signal source

Check signal-filter circuit

OK

NG

Replace U403

Replace U401

OK

Check Panel

NG

NG

Check BL-ON/OFF signal

NG

Check Q705、Q704

NG

Replace Panel

Reset the signal source or signal cable

Replace filer capacity of inductance

NG

Replace Q705、Q704

OK

AV/SV

Check the interface to
U401 circui

PC signal

OK

Check U401

OK

Check panel

HDMI SIGNAL

NG

NG

Replace U401

Replace panel

16

Check U507

NG

NG

Replace the revelant
component

Replace U507

42’’ Flat Wide Monitor AOC H428Pw

6. PCB Layout

6.1 Main Board

715T2968-1

17

42’’ Flat Wide Monitor AOC H428Pw

18

42’’ Flat Wide Monitor AOC H428Pw

19

42’’ Flat Wide Monitor AOC H428Pw

6.2 Power Board

715T2802 1

20

42’’ Flat Wide Monitor AOC H428Pw

21

42’’ Flat Wide Monitor AOC H428Pw

22

42’’ Flat Wide Monitor AOC H428Pw

6.3 Key Board

715T2876 1

6.4 IR Board

715T2877 1 2

23

42’’ Flat Wide Monitor AOC H428Pw

7. Adjustment

How to enter into the factory mode:

Turn on the TV, press MENU key with remote control, then press number key 1 Æ 9 Æ 9 Æ 9. It will achieve

the factory mode.

And It is no need to adjust the white balance.

24

42’’ Flat Wide Monitor AOC H428Pw

A

8. Block Diagram

PP-SCL &SDA

PC

RGB

HDMI1

HDMI2

COMPONENT

AV1

AV2

SV1

SV2

TMDS

TMDS

74HC4052D
IIC SWITCH

U103

PS321

U507

HDCP

U509

Y Pb Pr

AV1 CVBS

AV2 CVBS

SV2 Y C

ISP-SCL & SDA

SCL&SDA

EEPROM

U404

TMDS

DSCL& DSDA

KSCL& KSDA

MCU

NT68F631

U403

DECODER

SCALER

NT7263

MX25L4005AMC

U510

VIDEO

&

U401

CVBS OUT

LVDS

Panel

HDMI R&L

AUDIO

DECODER

U603

I2S

LINE OUT

HP R&L

LR

JACK

AV1

AV2

Component Audio

PC Audio

V1 Audio

AV2 Audio

DAC

U105

25

I2S

Amplifier

U606

PT2308

U605

SPEAKER

Earphone

42’’ Flat Wide Monitor AOC H428Pw

9. Schematic Diagram

9.1 Main Board

715T2968 1

MAIN 5V

INT_IR7

MCU _VC C

5VP

ADC07

CONN

CN702

(5V STAND BY)

C766

0.1uF

680 OHM 1/10WR701

0 OHM 1/10WR702

R703 NC

100 OHM 1/10WR704

MAIN 5V

(5V STAND BY)

+5VP

5VP

1
2
3
4
5
6
7
8
9
10
11
12

150 OHML701

1

8

2

7

3

6

45

300 OHM
LP701

0.1uF C702

BL

600 OHML702

BL_BRI

600 OHML703

C706

0.1uF

C707

0.1uF

R785
NC

Q711
NC

24VP

+12VP

24VP

R787
NC

1
2
3
4

0.1uF C703

Q709
NC

S
S
S
G

0.1uF C704

BACKLIGH T5

L724
300 OHM

D
D
D
D

R786
NC

0.1uF C705

MAIN24V

8
7
6
5

1
2
3
4
5
6
7
8

100pF C701

R705

47K OHM 1/10W

+12VP

CN701

CONN

BL

C714

0.1uF

5

4

L725

300 OHM

BRIGHTNESS7

L704
NC/L

47K OHM 1/10W

TP70 1

1

3

C719

0.1uF

Q704

MMBT390 4

R709

TP70 3

TP702

12VP

R713
47K OHM 1/10W

R706

100K OHM 1/10W

Q702
MMBT390 4

MAIN 5V

R710
1K OHM 1/10W

R711

R712
10K OHM 1/10W

TP704

Q701
AO4411

1

S

2

S

3

S

4

G

10K OHM 1/10W

C730

0.1uF

R714
22K OHM 1/10W

BL_BRI10K OHM 1/10W

C715
22UF/10V

12VP

TP70 5

R722

PANEL_ON7

22K OHM 1/10W

MAIN 12V

8

D

7

D

6

D

5

D

R715

5VP

R783
10K OHM 1/10W

R788
NC

+5VP

Q710
MMBT390 4

L712 ノ　 37",42",47"
L705

ノ　

26",32"

300 OHM

L712

R720
10K OHM 1/10W

R721
100K OHM 1/10W

Q705
MMBT3904

22K OHM 1/10W

R784

22K OHM 1/10W

(for panel T1,T2 )

L706
NC/L

1

5

3

4

L726

300 OHM

R718

POWER_ON 7

1 2

C721

0.068uF

C720

0.1uF

NCL705

R716
47K OHM 1/10W

100K OHM 1/10W

Q707
MMBT3904

5VP

Q706
AO4411

R717

5V:1200mA

8

D

S

7

D

S

6

D

S

5

D

G

Q708
AO4411

1

S

2

S

3

S

4

G

C774 NCC731 NC

C775

0.1uF

R723

10K OHM 1/10W

MAIN 5V

8

D

7

D

6

D

5

D

PANEL_VCC

R719

3.3K OHM 1/10W

1
2
3
4

5VP

U703

MAIN 2V5

200mA

C712

0.1uF

+

C713
220uF/10V

GND

MAIN 5V

100uF/1 6V

C708

U701

3 2

VIN VOUT

+

GND

1

絬 隔 瓜 絪 腹

Key Component

MAIN 3V3

900mA

+

C709

C710

0.1uF

220uF/10V

T P V ( Top Victory Electronics Co . , Ltd. )

T2968-G-X-X-13-080627

01 POWER

Date

26

C711

100uF/1 6V

MAIN 5V

AIC1084-25PETR-R

3 2

+

U705

VIN VOUT

1

C722

0.1uF

MAIN 12V

+

C723

10uF/50V

U704

AZ1117H-ADJ -E1

3

VIN

1

ADJ

620 OHM 1% 1/4W

2

VOUT

R724

120 OHM 1/10W

R725

+8V

+

C725

C724

0.1uF

10uF/50V

AP1084D18LA

ADJ(GND )

VOUT

VIN

MAI N3 V3

OEM MODEL Size

TPV MOD EL

PCB NAME

123

+

C716

100uF/16V

Sheet

R743
0 OHM 1/10W

H428Pw

J428MNNSW1A4N C

715T2968-G

211Friday , June 27, 2008

of

MAIN 1V8

NCR742

600mA

+

C717

C718

0.1uF

220uF/10 V

A3

Rev

<

称爹

称爹

>

42’’ Flat Wide Monitor AOC H428Pw

MCU_RX7

HS

2.2K OHM 1/10W

1 2

R106

VGA_EDID7

VS

ZD127

RLZ6.8B

C197

VPORT0603100KV05

CN102

PHONEJAC K

PP_SDA

R104 510 OHM 1/10W

PP_SCL

ZD126

C195
10pF

RLZ6.8B

1 2

R107

2.2K OHM 1/10W

VGA

NC

R194

R195

4.7K OHM 1/10W

PP_SCL
PP_SDA

R196

18K OHM 1/10W

ZD106

VPORT0603100KV05

ZD107

3

2
1

PC AUDIO INPUT

R132

L108 120 OHM

L109 120 OHM

R133
75 OHM 1/10W

S1_C3

S1_Y3

75 OHM 1/10W

ZD101 VPORT0603100KV05

ZD102 VPORT0603100KV05

R101 100 OH M 1/10W

R102 100 OH M 1/10W

L127 60 OHM

L128 60 OHM

R105 100 OH M 1/10W

C196
10pF

C198

0.22uF

U102

8

4.7K OHM 1/10W

12

12

C117

0.001uF

C118

0.001uF

VCC

7

WP

6

SCL

M24C02-WMN6TP

L104 15 0 OHM

L105 15 0 OHM

A0
A1
A2

GNDSDA

S_VIDEO 1 IN

C127

C128

68pF

68pF

1 2

12

12

ZD108

1
2
3
45

ISP_SDA7

ISP_SCL7

VPORT0603100KV05

ZD103

12

SDA4,5, 7

PP_SDA

SCL4, 5,7

PP_SCL

PC_R

PC_L

R192

NC

VPORT0603100KV05

R163

R164

ISP_SW7

ISP_POW

PC_R 9

PC_L 9

R193

NC

ZD109

1 2

VPORT0603100KV05

VGA INPUT

CN101

1716

1229-0Z4-15S-H0 1

1

11

6
2

12

7
3

13

8
4

14

9
5

15

10

R130 0 OHM 1/10W
R131 0 OHM 1/10W

MCU_VCC

C168

0.1uF

U103
74HC4052D

12

X0

14

X1

15

X2

11

X3

NC

1

Y0

5

Y1

2

Y2

4

Y3

NC

10

A

9

B

6

EN

7

VEE

16

VDD

C116

0.1uF

1

6

4 5

2 3

CN103 DIN JACK

R108 100 OHM 1/10W

12

12

ZD105

ZD104

VPORT0603100KV05

8

HS

13

X

3

Y

GND

75 OHM 1/10W

ISP_POW

VPORT0603100KV05

1 2
3 4
5 6

9 8
11 10
13 12

VS

PP_SDA

PP_SCL

S2_C3

S2_Y3

R189

L101 32 OHM

L102 32 OHM

L103 32 OHMR103 510 OHM 1/10W

MCU _TX 7

5VP

C1945.6pF

C1935.6pF

C1925.6pF

1

2

D102

12

SCS140V

D105
BAT54C

3

VGA

U101

1A 1Y
2A 2Y
3A 3Y
4A 4Y
5A 5Y
6A 6Y

74LVC14ADT

GNDVCC

CVBS_OUT3

AV1_CVBS3

R170 200 OHM 1/10W
R171 200 OHM 1/10W

714

R141

75 OHM 1/10W

R191

0 OHM 1/10W

S_VIDEO 2 IN(side)

L125 120 OHM

L126 120 OHM

R190
75 OHM 1/10W

C187
68pF

C188
68pF

ZD124

1 2

1

1

2

I0_R 3

I0_G 3

I0_B 3

D104
BAV99

5VP

3

D106
BAV99

2

5VP

D103
BAV99

3

R11075 OHM 1% 1/ 10W

R10975 OHM 1% 1/ 10W

R11175 OHM 1% 1/10 W

EMI Add_8/27

Novatek auto scan_10/9

I0_HS 3
MCU_HS 7
MCU_VS 7
I0_VS 3

AV1 INPUT & AV OUTPUT

CN106

ZD119

VPORT0603100KV0 5

4

2

6

C129

68pF

1 2

CN108

DIN JACK

JACK

32

C140
68pF

65981

ZD122

1 2

3

1

5

1 2

VPORT0603100KV05

L110
120 OHM

12

VPORT0603100KV05

ZD125

VPORT0603100KV05

ZD110

L119 120 OHM

1

3

2

5VP

L113

HD_L

4

VPORT0603100KV0 5

HD_L9

HD_R9

7

ZD123

1 2

絬 隔 瓜 絪 腹

Key Component

600 OHM

ZD113

R134

NC

1 2

VPORT0603100KV05

L114

HD_R

600 OHM

ZD114

R135

NC

1 2

VPORT0603100KV05

ZD112

ZD111

C132

C133

470pF

470pF

1 2

1 2

VPORT0603100KV05

VPORT0603100KV05

L123 600 OHM

L124 600 OHM

C143

C144
220pF

R139

R144

NC

R140

0 OHM 1/10W

220pF

VPORT0603100KV0 5

AV2_CVBS3

75 OHM 1/10W

T P V ( Top Victory Electronics Co . , Ltd. )

T2968-G-X-X- 13-080627

02 I NPU T/OU TPUT

Date

COMPONENT INPUT

CN105

JACK

1

2

6

4

C130

4.7uF/ 16V

C131

4.7uF/ 16V

R183

47K OHM 1/ 10W

AV1_R

AV1_R 9

AV1_L

AV1_L 9

R145

NC

CN111

JACK

ZD118

1 2

VPORT0603100KV05

OEM MOD EL Size

TPV MOD EL

PCB NAME

Sheet

L111

600 OHM

L112

600 OHM

C134
220pF

C135
220pF

L118 120 O HM

L115 120 OHM

ZD115

C136
68pF

1 2

VPORT0603100KV05

L116 120 OHM

ZD116

1 2

VPORT0603100KV05

ZD117

1 2

VPORT0603100KV05

R181
680 OHM 1/10W

R182
680 OHM 1/10W

Q106
2SD1757K

4.7K OHM 1/10W

R188
47K OHM 1/10W

C137
68pF

L117 120 OHM

C138
68pF

C181

4.7uF/ 16V

C182

4.7uF/ 16V

R185

4.7K OHM 1/10W

R186
47K OHM 1/10W

R187

5

9

10

3

7

8

R184

47K OHM 1/ 10W

Q107
2SD1757K

AV2 INPUT(SIDE)

79461

C139

68pF

325

8

600 OHM

L120

L121

600 OHM

C142

C141

ZD120

ZD121

1 2

VPORT0603100KV05

H428PW

J428MNNSW 1A4N C

715T2968-G

of

311Friday , June 27, 2008

220pF

220pF

1 2

VPORT0603100KV05

LINEOU T_L

LINEOU T_R

R142
NC

HD_Y 3

R136
75 OHM 1/10W

HD_PB 3

R137
75 OHM 1/10W

HD_PR 3

R138
75 OHM 1/10W

LINEOU T_L 9

LINEOU T_R 9

LI NEO UT_MU TE 7 ,9

AV2_L

AV2_L 9

AV2_R

AV2_R 9

R143

NC

Rev

称爹

<

称爹

A3

>

27

42’’ Flat Wide Monitor AOC H428Pw

C769
NC

NC

+5VIF

+

L722 NC

U106

NC

1

SWC

2

SWE

3 6

TCA P VCC

4

GND

R776

I0_R2

I0_G2

I0_B2

HD_PR2

HD_Y2

HD_PB2

IF

IF_SW7

C755
NC

NC

8

DC

7

PK

5

COMP

R777

NC

R146
100 OHM 1/10W
R147

R148
100 OHM 1/10W
R149
100 OHM 1/10W
R150
100 OHM 1/10W
R151
100 OHM 1/10W
R152

I0_HS2

I0_VS2

100 OHM 1/10W

R155

100 OHM 1/10W

R156

100 OHM 1/10W

R157

100 OHM 1/10W

R158
100 OHM 1/10W
R159
100 OHM 1/10W
R160
100 OHM 1/10W
R161

D702 NC

R781

NC

L720
NC

28

R778

C770

NC

100 OHM 1/10W

100 OHM 1/10W

NC

R780

R779
NC

1 2

L721 NC

+

C771

NC

C160 0.1uF

C161

+5VT

Q506
NC

I0R0+

I0G0+

I0SOG0

I0B0+

I0G1+

I0SOG1

I0B1+

0.1uF

SW

絬 隔 瓜 絪 腹

Key Component

C145 0.047uF

C146 0.047uF

C147 0.047uF

C148 0.047uF

C149 0.047uF

C150 0.047uF

C151 0.047uF

R153 100 OHM 1/10W

R154 100 OHM 1/10W

C152 0.047uF I0R1+

C153 0.047uF

C154 0.047uF

C155 0.0047uF

C156 0.047uF

C157 0.047uF

C159 NC

+5VT

MAIN 12V

57

65

69

255

I0R0+

256

I0R0-

253

I0G0+

252

I0SOG0

254

I0G0-

250

I0B0+

251

I0B0-

1

I0HS0

2

I0VS0

245

I0R1+

246

I0R1-

243

I0G1+

242

I0SOG1

244

I0G1-

240

I0B1+

241

I0B1-

247

I0RMDSCV

239

I0BMDSCV

U401C
NT7263

C162 0.1uF

C163 0.1uF

C164 0.1uF

C165 0.1uF

T P V ( Top Victory Electronics Co . , Ltd. )

Date

66

70

SIF-

VIF-

SIF+

VIF+

I0/I1 Block

31

T2968-G-X-X-13- 080627

03 TUNER/IF,I0/I1

I1ADC1-

I1ADC2-

I1ADC3-

40

35

44

12.12.07
USED NT72631
CHANGE "C"
R123 100 OHM
R121 510 OHM
R122 0 OHM
DELETE "D" ALL

73

PEAK

VAFC

I1VSOUT

I1ADC0-

26

22 OHM 1/10W

54

59

64

71

TOP

AFD

REFIN

I1Cr/SCARTR1

I1Y /SCAR TG1

I1Cb/SCARTB1

I1Y2/SCARTY1

I1HSOUT

I1YOUT

25

48

D

R162

D

+

C169

10uF/50V

OEM MO DEL Size

TPV MOD EL

PCB NAME

Sheet

56

VPLL

FMPLL

72

TAGC

62

SSIF

61

MON O

60

IFY_OUT

C175 N CI1Y0

47

I1Y0

I1Y1

C176 0.1u F

46

I1Y1

I1Y3

C177 0.1u F

43

I1Y3

C178 0.1u F

36

I1C0

I1C0

33

39

30

42

51

34

41

32

45

52

D

R113

D

Q108
MMBT3904

R116
56 OHM 1/10W

D

R115

of

C

Y

C

C

Y

C

Y

C

1K OHM 1/ 10W

MMBT39 06

47 OHM 1/ 8W

C166 N C

C179 0.1u F

C185 0. 1uFC158 0.047uF

C186 0. 1uF

R124

0 OHM 1/10W

NC
R123

Q105

D

C

R117

NC
R122

D

2.2K OHM 1/10W

SCARTR 0

SCARTG0

SCARTB0

SCARTY 0

SCARTFB0

SCARTFB1

D

C167
22pF

R112

47K OHM 1/ 10W

D

R114

33K OHM 1/ 10W

H428PW

J428MNNSW1A4N C

715T2968-G

411Friday , June 27, 20 08

D

0 OHM 1/10W

R120

R125

NC

S-VIDEO2

+5VT

C

C

R121
NC

1000UF/ 16V

75 OHM 1/ 10W

R119

TV_CVBS

AV2_CVBS 2

S1_Y 2

S1_C 2

AV1_CVBS 2

S2_C 2

S2_Y 2

D

+

C170

100uF/16V

+

C171

Rev

称爹

TV_C VBS

CVBS_OUT 2

R118
100K OHM 1/10W

A3

<

称爹

>

R167 47 OHM 3W

MAIN12V

R168 47 OH M 3W

ATV TUNER

ANT IN

121314

R793 0 OH M 1/8W

R794 0 OH M 1/8W

R795 0 OH M 1/8W

R796 0 OH M 1/8W

R798 0 OH M 1/8W

R799 0 OH M 1/8W

R797 0 OHM +-5% 1/4W

R745
NC

R746 NC

trace 15mil Jhonson_1025

1112 conn delete

SDA_A7

SCL_A7

U707

AP1117D50LA

3 2

VI VO

+

C726

100uF/16V

TU701

AGC

AS

SCL

SDA

BP

AFC

BT

15

R773 NC

R748 NC

R749 NC

+

1

3

4

5

7

8

9

11

IF

C746 NC

C747 NC

R747 NC

C772
NC

C748 NC

C749 NC

GND

C727

0.1uF

1

AGC1

C737
NC

C738

NC

+30V

+

C773

NC

C741

NC

VIF1

VIF2

TP70 6

10

11 14

12 13

SIF9

R730

R731 NC

R732 NC

C736 NC

R733 NC

R734 NC

R735 NC

R736 NC

C739 NC

C740 NC

+5VIF

R739
NC

R741
NC

IF DECODER

U708
NC

1

VIF1

2

VIF2

3

IC/OP1

4

FMPLL

5

DEEM

6

AFD

7

DGND

8

AUO

9

TOP

FM1/SDA

FM0/SCL TAGC

QSSO/SIOMADVIF0/NC

C728

100uF/16V

NC

+

L713 NC

+

IF

SIF2

SIF1

VAGC/OP2

AFC

VP

VPLL

AGND

CVBS

MUTE/VAGC

REF

TV_CVBS / TV_MONO trace change to 15mil

C729

0.1uF

AGC

R737
NC

24

SIF2

23

SIF1

22

21

20

19

C751 NC

18

17

16

15

R755 NC

+5VT

+5VT

+5VT

SCL_A 7

SDA_A 7

+5VT

R738
NC

+5VIF

R753 NC

C753 NC

NCC776

+30V

R774

NC

ZD701
NC

1 2

12345

IF

SW

INPUT

12345

IF

SW

R750 NC

R751 NC

C750 NC

R752 NC

C752 NC

X70 1
NC

R754 NC

picture improve_1002
Trace 15mil Jhonson_1025

L723
NC

C768

NC

U709
NC

INPUT

SWITCHING INPUT

CHIP CARRIER -GROUND

OUTPU T

OUTPU T

–

筳

U710
NC

SWITCHING INPUT

CHIP CARRIER-GROUND

OUTPUT

OUTPUT

+5VT

TV_C VBS

AGC

+

–

癸ぇ丁

筳

GND

VIF1

VIF2

癸ぇ丁

GND

SIF1

SIF2

TO IO/I1 CVBS

R782
NC

D701

NC

R775

NC

C754

NC

42’’ Flat Wide Monitor AOC H428Pw

5VP

NC

R506

18K OHM 1/10W

U501

VCC
WP
SCL

GNDSDA

M24C02-WMN6TP

10
9

7

HDMIA_RX1-

10

HDMIA_RX1+

9

7

HDMIA_RX2­HDMIA_RX2+

C504

0.22uF

A0

VCC

A1

WP

A2

SCL

GNDSDA

OUT1
OUT2

OUT3

GND

GND

3

8

OUT1
OUT2

OUT3

GND

GND

3

8

MAI N5V

C502

0.22uF

1

A0

2

A1

3

A2

45

HDMIA_RXC­HDMIA_RXC+

HDMIA_RX0­HDMIA_RX0+

　кで皌璶

1
2
3
45

10
9

7

10
9

7

HDMI_B+SW7

100 OHM

HDMIB_RXC­HDMIB_RXC+

HDMIB_RX0­HDMIB_RX0+

HDMIB_R X1­HDMIB_R X1+

HDMIB_R X2­HDMIB_R X2+

　кで皌璶

29

MAI N3V 3

100OHM

R548 NC

HDMIB_SDA
HDMIB_SCL

HDMIB_RXC­HDMIB_RXC+
HDMIB_RX0­HDMIB_RX0+
HDMIB_RX1­HDMIB_RX1+
HDMIB_RX2­HDMIB_RX2+

HDMIA_SDA
HDMIA_SCL

HDMIA_RXC­HDMIA_RXC+
HDMIA_RX0­HDMIA_RX0+
HDMIA_RX1­HDMIA_RX1+
HDMIA_RX2­HDMIA_RX2+

L509 300 OHM

Q505
NC

62

63
64

67
68
70
71
73
74
76
77

80

11
12
14
15

SDA2,5,7
SCL2,5,7

Q504
NC

36KOHM +-5% 1/16W

R552

36KOHM +-5% 1/16W

1

HPD2

SDA2
SCL2

B21
A21
B22
A22
B23
A23
B24
A24

HPD1

2

ASDA

3

ASCL

5

B11

6

A11

8

B12

9

A12
B13
A13
B14
A14

S1/SDA_ CTL

22

21

500 OHM 1% 1/10W

T2968-G-X-X-13-080 627

04 PS321 HDMI SW

R547 NC

HDMIB_POW

HDMIA_POW

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

HDMI_SW

+

C505
22uF/16V

R551

20

79

PC1/POWD N

PC0/I2C _RST

PS321

REXT

NC

S2/SCL_C TL

OE#/STAND BY

18

19

42

R520

4.7K OHM 1/10W

C506

0.1uF

R558

10K OHM 1/10W

33

27

56

50

43

61

69

75

VCC

VCC

VCC

VCC

VCC

POW1

POW3

POW2

GND

GND

GND

I2C_CTL_EN

GND

GND

GND

4

10

16

37

36

30

24

47

R553

HDMI_SW

OEM MO DE L Size

TPV MOD EL

PCB NAME

Sheet

C508

C509

0.1uF

0.1uF

10K OHM 1/10W

40

HPD_SINK

39

SDA_SINK

38

SCL_SINK

35

Z1

34

Y1

32

Z2

31

Y2

29

Z3

28

Y3

26

Z4

25

Y4

60

CEXT

41

POW_SI NK

58

A34

57

B34

55

A33

54

B33

52

A32

51

B32

49

A31

48

B31

46

SCL3

45

SDA3

44

HPD3

23

GND

GND

U507

72

78

R554

4.7K OHM 1/ 10W

H428PW

J428MNNSW1A4N C

715T2968-G

of

511Friday , June 27 , 2008

13

17

VCC

VCC

GND

GND

59

53

C507

0.1uF

HDMI_SW

7

VCC

VCC

S3/I2C _ADDR

GND

EDID _BRG_EN

GND

65

66

R557
NC

C511

C510

0.1uF

0.1uF

R549

DSDA
DSCL

HDMI_RXC- 5
HDMI_RXC+ 5
HDMI_RX0- 5
HDMI_RX0+ 5
HDMI_RX1- 5
HDMI_RX1+ 5
HDMI_RX2- 5
HDMI_RX2+ 5

C521 2.2uF 16V Y 5V

R556
NC

R555

4.7K OHM 1/10W

HDMI_SW

C513

C512

0.1uF

0.1uF

R550

10K OHM 1/10W

DSDA 5
DSCL 5

HDMI_POW 5

Rev

称爹

A3

<

称爹

>

HDMI-1 INPUT

HDMI-2 INPUT

HDMIB_DET7

R514

HDMI_WP

4.7K OHM 1/10W

HDMIA_RX1­HDMIA_RX1+

HDMIA_RX2­HDMIA_RX2+

4.7K OHM 1/10W

HDMIB_RXC-

HDMIB_RXC+

HDMIB_RX0+

HDMIB_RX2-

Q502
MMBT39 04

4.7K OHM 1/10W

R513

4.7K OHM 1/10W

HDMIB_RX1­HDMIB_RX1+

HDMIB_RX2+

HDMI_EDID7

MAI N5V

5VP

R502

R510

R515
NC
R516
0 OHM 1/10W

C501
NC

20K OHM 1/ 10W

R503

1K OHM 1/10W

1

2

L501 90 ohm

1

2

L504 90 ohm

1

2

L503 90 ohm

1

2

L502 90 ohm

MAI N5V

5VP

R517
NC
R518
0 OHM 1/10W

20K OHM 1/ 10W

R511

1K OHM 1/10W

1

2

L505 90 ohm

1

2

L508 90 ohm

1

2

L507 90 ohm

1

2

L506 90 ohm

Q501

MMBT39 04

CN501

SHLD_GN D2
SHLD_GN D1

DDC_GND

CSHLD0
DSHLD2
DSHLD1
DSHLD0

TMDSC+

TMDS D2-

TMDS D2+

TMDS D1-

TMDS D1+

TMDS D0-

TMDS D0+

HDMI

1K OHM 1/10W

CN502

SHLD_GN D2
SHLD_GN D1

DDC_GND

CSHLD0
DSHLD2
DSHLD1
DSHLD0

TMDSC+

TMDS D2-

TMDS D2+

TMDS D1-

TMDS D1+

TMDS D0-

TMDS D0+

HDMI

R501

1K OHM 1/10W

26

SHLD5

25

SHLD4

24

SHLD3

23

SHLD2

22

SHLD1

21
20

17
11
8
5
2

14

NC

18

VCC5

19

HPD

13

CEC

16

SDA

15

SCL

12

TMDSC-

10

3
1

6
4

9
7

R509

26

SHLD5

25

SHLD4

24

SHLD3

23

SHLD2

22

SHLD1

21
20

17
11
8
5
2

14

NC

18

VCC5

19

HPD

13

CEC

16

SDA

15

SCL

12

TMDSC-

10

3
1

6
4

9
7

Q503

MMBT39 04

CEC

HDMIA_POW

HDMIA_SDA
HDMIA_SCL

HDMIB_POW

HDMIB_SDA
HDMIB_SCL

HDMIA_DET7

C503

NC

4

3

4

3

4

3

4

3

R504 1K OHM 1/10W

1

2

1

2

4

3

4

3

4

3

4

3

D501

BAT54C

D502

BAT54C

3

R507

HDMIA_RXC­HDMIA_RXC+

HDMIA_RX0­HDMIA_RX0+CEC

3

R512

4.7K OHM 1/ 10W

R505

R508

U502 RClam p0524P.TCT

1
2

4
5 6

U503 RClam p0524P.TCT

1
2

4
5 6

HDMI_WP

HDMIB_RX0-

8
7
6

IN1

OUT1

IN2

OUT2

IN3

OUT3

IN4 OUT4

GND

GND

3

8

IN1

OUT1

IN2

OUT2

IN3

OUT3

IN4 OUT4

GND

GND

3

8

8
7
6

U505 RClam p0524P.TCT

1

IN1

2

IN2

4

IN3

5 6

IN4 OUT4

U506 RClam p0524P.TCT

1

IN1

2

IN2

4

IN3

5 6

IN4 OUT4

U504

M24C02-WMN6TP

42’’ Flat Wide Monitor AOC H428Pw

LVDS OUTPUT

MAI N3V 3

CN201

R528 1K OHM 1/10W

R529 1K OHM 1/10W

R530 10K OHM 1/10W

VCC

NC

E1

WC

E2

SCL

VSSSDA

U509
M24C04-WMN6TP

RP505

4

5

3

6

2

7

1

8

RP507

4

5

3

6

2

7

1

8

NC

FSI
FWP
FHOLD
FSO

HDMI_R

10K OHM 1/10W

C522

0.22uF

1
2
3
45

R128

MAI N3V 3

HD_MCLK
HD_SCK
HD_WS
HD_SD

HD_MCLK
HD_SCK
HD_WS
HD_SD

FSCK

FCE

1K OHM 1/10W

HDMI_HDCP7

R527

HDMI_MCLK19
HDMI_SCK19
HDMI_WS19
HDMI_SD19

I4_D5_FSC K

FCS

PD_FLASH7

KSCL
KSDA

I4_D6_U TRX

I4_D7_UTTX

I4_D0_FS I
I4_D1_FW P
I4_D2_FH OLD
I4_D3_FS O

8
7
6

HDMI_MCLK

HDMI_SC K

HDMI_WS

HDMI_SD

22 OHM +-5% 1/16W

HDMI_MCLK1

HDMI_SC K1

HDMI_WS1

HDMI_SD 1

CN503
NC

3

2

1

RP506

4

5

3

6

2

7

1

8

22 OHM +-5% 1/16W

R531 22 OHM 1/10W

R532 22 OHM 1/10W

R533 NC

HDMI_R9

HDMI_WS
HDMI_SD
HDMI_SC K

C12110uF/50V

+

FCE
FSI
FWP

R534 1K OHM 1/10W

R535 NC

　кで皌璶

100OHM

HDMI_RXC-4
HDMI_RXC+4
HDMI_RX0-4
HDMI_RX0+4
HDMI_RX1-4
HDMI_RX1+4
HDMI_RX2-4
HDMI_RX2+4

DSCL4
DSDA4

HDMI_POW4

X502 28.322MHZ

R538

C515
15pF

MAI N3V 3

1
2
3
4
5
6
7 8

KSCL
KSDA

HD_SD
HD_WS
HD_SCK
HD_MCLK

C514
NC

12

1M OHM 1/10W

I4_D0_FS I
I4_D1_FW P
I4_D2_FH OLD
I4_D3_FS O

I4_D5_FS CK
I4_D6_U TRX
I4_D7_U TTX

FCS

L510 120 OHM

U510

1

CS

VCC

2

SO

HOLD

3

WP

SCK

4 5

GND SI

MX25L4005AMC

U105

DGND
LRCLK
DIN

FORMAT

BCLK

DEEMPH

MUTE

VOUTL
VOUTR
AGND CAP

WM8521HCGED/ RV

DVDD

MCL K

AVDD

8
7
6

C122

0.1uF

C516
15pF

C119

14
13
12
11
10
9

197
198
200
201
203
204
206
207

212
213

214
215

195

217

219
221
222
223

218

191

190

224
225
226
228
229
230
232
233
234

9
10
11
13
14
15
16
18
19
20

C517 4.7uF/ 16V

C518 0. 1uF

FHOLD
FSCK
FSO

0.1uF

+

10uF/50V

U401B
NT7263

RC­RC+
RX0­RX0+
RX1­RX1+
RX2­RX2+

DSCL
DSDA

KSCL
KSDA

RSVD

PWR5V

SD
WS
SCK
HMCLK

SPDIF

HAXO

HAXI

I2D0/HAD0
I2D1/HAD1
I2D2/HAD2
I2D3/HAD3
I2D4/HAD4
I2D5/HAD5
I2D6/HAD6
I2D7/HAD7
I2CLK/HALE

I4D0/FSI
I4D1/FWP#
I4D2/FHOLD#
I4D3/FSO
I4D4
I4D5/FSCK
I4D6/UTRX
I4D7/UTTX
I4CLK
FCS#

+

C120

10uF/50V

C126 10uF/50V

+

C124

0.1uF

C123

HDMI/DP Block

120 OHM

+

C125

10uF/50V

LVDSC0+
LVDSC0­LVDSC1+
LVDSC1­LVDSC2+
LVDSC2­LVDSC3+
LVDSC3-

LVDSCLK0+

LVDSCLK0-

LVDSC4+

LVDSC4-

LVDSC5+

LVDSC5-

LVDSC6+

LVDSC6-

LVDSC7+

LVDSC7-

LVDSCLK1+

LVDSCLK1-

GPIO0
GPIO1
GPIO2

GPIO3
GPIO4/PW M4
GPIO5/PW M5

GPIO6
GPIO7/PW M7
GPIO8/PW M8

HRST#

HIRQ

HSDA/HRD#

HSCL/HWR#

HSEL

HTYPE

TEST

L106

L107

120 OHM

HDMI_MCLK

HDMI_L

R129

10K OHM 1/10W

108
109
106
107
104
105
100
101
102
103

96
97
94
95
92
93
88
89
90
91

23
24
81
82
83
84
236
237
238

76

77

78

80

8

75

21

4

XI

5

XO

WXGA-PANEL

LVDS0+
LVDS0­LVDS1+
LVDS1­LVDS2+
LVDS2­LVDS3+

LVDS3-

LVDSCLK0+
LVDSCLK0-

LVDS4+
LVDS4­LVDS5+
LVDS5­LVDS6+
LVDS6­LVDS7+
LVDS7­LVDSCLK1+
LVDSCLK1-

R543 0 OHM 1/10W

R544 0 OHM 1/10W

SYS_R STn 7

INT_726X 7

SDA 2, 4,7

SCL 2,4,7

X503 12MHz

R542
1M OHM 1/10W

C519
33pF

MAI N3V 3

MAIN12V

HDMI_L 9

30

1080P-PANEL

DCR_ON7

8mil

BACKLIGHT-Contronal

BACKLIGHT 1

ODSEL_ON

R539 NC

R540 1K OHM 1/10W

R541 N C

C520
33pF

絬 隔 瓜 絪 腹

Key Component

LVDS0+
LVDS1+
LVDS2+

(#1,GND1)

R202 0 OHM

R201

NC

PANEL_VCC

MAI N3V 3

OSC_OUT 7

璶綼　

R541
OSC_OUT=12mil,

T P V ( Top Victory Electronics Co . , Ltd. )

Date

X503

璶　

T2968-G-X-X-13-080627

05 NT7263 HDMI,LVD S

DCR

(#10,NC)

L201

GND

LVDSCLK0+

LVDS3+
LVDS4+
LVDS5+
LVDS6+

(#26,GND5)

LVDSCLK1+

(#37,GND8)

LVDS7+

(#43,GND10)
(#45,GND12)

300 OHM

1 2

+

CONN

(#13,FC RO0+)
(#15,FC RO1+)
(#17,FC RO2+)
(#18,GND1)
(#20,FC CLK+)
(#8,RPF,GND9)(#18,GND3)
(#23,FC RO3+)
(#29,SC RO0+)
(#31,SC RO1+)
(#33,SC RO2+)
(#34,GND3)
(#36,SC CLK+)
(#10,DGMEN,GND11)
(#39,SC RO3+)
(#7,LVDS SEL)

(#45,GND5)
(#47,GND7)
(#49,+12V)
(#51,+12V)

C201

100uF/16V

2
4
6

8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40

VGA GND#1

VGA GND#2

VGA GND#3

VGA GND#4

VGA GND#5

VGA GND#6

HDMI GND#1

HDMI GND#2

HDMI GND#3

HDMI GND#4

HDMI GND#5

HDMI GND#6

SOUND GND#6

HDMI GND#7

VGA GND#7

HDMI GND#8

HDMI GND#9

VGA GND#9

HDMI GND#10

HDMI GND#11

HDMI GND#12

OEM MODEL Size

H428PW

TPV MO DEL

J428MNNSW1A4N C

715T2968-G

PCB NAME

Sheet

611Friday , June 27, 2008

of

(#12,FC RO0-)

1

(#14,FC RO1-)

3

(#16,FC RO2-)

5

(#21,GND2)

7

(#19,FC CLK-)

9

(#9,ODSEL,GND10)

11

(#22,FC RO3-)

13

(#28,SC RO0-)

15

(#30,SC RO1-)

17

(#32,SC RO2-)

19

(#37,GND4)

21

(#35,SC CLK-)

23

(#11,DGREN,GND12)

25

(#38,SC RO3-)

27
29
31

(#44,GND6)

33

(#46,GND8)

35

(#48,+12V)

37

(#50,+12V)

39

(#42,GND9)
(#44,GND11)
(#46,GND13)

R210 0 OH M +-5% 1/4W

R211 0 OH M +-5% 1/4W

R212 0 OH M +-5% 1/4W

R213 0 OH M +-5% 1/4W

R214 0 OH M +-5% 1/4W

R215 0 OH M +-5% 1/4W

R216 0 OH M +-5% 1/4W

R217 0 OH M 1/10W

R218 0 OH M 1/10W

R219 0 OH M +-5% 1/4W

R220 0 OH M +-5% 1/4W

R221 0 OH M +-5% 1/4W

R227 0 OH M 1/10W

R222 0 OH M +-5% 1/4W

R223 0 OH M +-5% 1/4W

R225 0 OH M +-5% 1/4W

R226 0 OH M +-5% 1/4W

R228 0 OH M +-5% 1/4W

R229 0 OH M +-5% 1/4W

R230 0 OH M +-5% 1/4W

R231 0 OH M +-5% 1/4W

LVDS0­LVDS1­LVDS2-

(#11,GND2)

LVDSCLK0-

(#21,GND4)

LVDS3­LVDS4­LVDS5­LVDS6-

(#27,GND6)

LVDSCLK1-

(#34,GND7)

LVDS7-

(#9,EN_DBL)

Rev

称爹

DCR

ODSEL_ON

A3

<

称爹

>

42’’ Flat Wide Monitor AOC H428Pw

8mil

6mil

12mil

D

MA[0..11]

MBA0
MBA1

MCA S
MRA S
MWE
MCS

MDQ S0

B

MDQ S1

B

R408 22 OHM 1/10W

MCK E CKE

MCL K

R409 22 OHM 1/10W

R411
220 OHM 1/10W

MCL Kn

R410 22 OHM 1/10W

RP401 22 OHM +-5% 1/16W

MA0
MA1
MA2
MA3

RP402 22 OHM +-5% 1/16W

MA4
MA5
MA6
MA7

RP403 22 OHM +-5% 1/16W

MA8
MA9
MA11

MA10

R402 22 OHM 1/10W
R403 22 OHM 1/10W

RP404 22 OH M +-5% 1/ 16W

R404 0 OHM 1/10W
R405 0 OHM 1/10W
R406 1K OHM 1/10W
R407 1K OHM 1/10W

R401

1
2
3
4

1
2
3
4

1
2
3
4

1
2
3
4

22 OHM 1/10W

8
7
6
5

8
7
6
5CA3

8
7
6
5

8
7
6
5

DQS0

DQS1

DQS2

DQS3

CLK0

CLKn

C403

0.1uF

29
30
31
32
35
36
37
38
39
40
41

28
26
27

44
45
46
51

23
22
21
16

24

VDDA

C404
10uF/10V

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A11

A10/AP
BA0
BA1

CKE
CK
CK
UDQS

RAS
CAS
WE
LDQS

CS0

VDDA

11833

VDD0

VSS0

664834

VDD1

VSS1

VDD2

VSS2

VDDQA

39155561

VDDQ0

VSSQ0

VSSQ1

612525864

C405

0.1uF

DQ0

VDDQ1

VDDQ2

VDDQ3

VDDQ4

DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15

NC
NC

UDM

LDM

VREF

VSSQ2

VSSQ3

VSSQ4

C406

0.1uF

R431 0 OHM 1/10W

C408

C407

0.1uF

0.1uF

2

MD0

4

MD1

5

MD2
MD3

7

MD4

8

MD5

10

MD6MA6

11
13

MD7

54

MD8
MD9

56
57

MD1 0

59

MD1 1

60

MD1 2
MD1 3

62
63

MD1 4

65

MD1 5

19
50

47
20

49

C411

0.1uF

A0
A1
A2

C402

A4
A5
A6
A7

A8
A9
A11
A12

A10

U401A
NT7263

A0

144

MA0

146

A1

MA1

A2

147

MA2

A3

148

MA3

A4

153

MA4

A5

154

MA5

156

A6

MA6

157

A7

MA7

A8

158

MA8

159

A9

MA9

A10

143

MA10

161

A11

MA11

A12

162

MA12

141

MBA0

142

MBA1

135

MCAS#

136

MRAS#

138

MWE #

139

MCS #

123

MDQ S0

134

MDQ S1

173

MDQ S2

185

MDQ S3

155

MCKE#

149

MCL K+

150

MCL K-

MMU Block

MDQ 0
MDQ 1
MDQ 2
MDQ 3
MDQ 4
MDQ 5
MDQ 6
MDQ 7
MDQ 8

MDQ 9
MDQ 10
MDQ 11
MDQ 12
MDQ 13
MDQ 14
MDQ 15
MDQ 16
MDQ 17
MDQ 18
MDQ 19
MDQ 20
MDQ 21
MDQ 22
MDQ 23
MDQ 24
MDQ 25
MDQ 26
MDQ 27
MDQ 28
MDQ 29
MDQ 30
MDQ 31

112
114
116
117
118
120
121
122
133
132
130
129
128
127
126
124
171
170
169
168
167
165
164
163
174
176
177
178
180
181
183
184

RP405

75 OHM 1/16W

RP406

75 OHM 1/16W

RP407

75 OHM 1/16W

RP408

75 OHM 1/16W

1

8
7
6
5
8
7
6
5
5
6
7
8
5
6
7
8

MD0
MD1

2
3

MD2

4

MD3
MD4

1
2

MD5
MD6

3
4

MD7

4

MD8
MD9

3
2

MD1 0

1

MD1 1
MD1 2

4
3

MD1 3
MD1 4

2

MD1 5

1

A

MD[0..15]

6mil

MA[0..11]

C401

0.1uF

0.1uF

MAI N2V5

MBA0
MBA1

MCK E
MCL K
MCL Kn

MDQ S1

MRA S
MCA S
MWE
MDQ S0

MCS

HY B25DC256160CE-5

R430 0 OHM 1/10W

MA0
MA1
MA2
MA3
MA4
MA5

MA7
MA8
MA9
MA11

MA10

U402

VDDQA

C410
10uF/10V

C409

0.1uF

MAI N2V5

MD[0..15]

DDR_VREF 8

R412 1K OHM 1/10W

R413

1K OHM 1/10W

MAI N2V5

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

T2968-G-X-X-13-080627

06 NT7263 MMU/D DR

Date

OEM MOD EL Size

TPV MO DE L

PCB NAME

H428PW

J428MNNSW 1A4N C

715T2968-G

Sheet

of

711Friday , June 27, 2008

Rev

称爹

A3

称爹

>

<

31

42’’ Flat Wide Monitor AOC H428Pw

5VP

R672

12K OHM 1/10W

R680

10K OHM 1/10W

D401

1 2

SCS140V

R434

300 OHM 1/10W

CN403

NC

MAI N5V

D603
LL4148

ISP_POW

U406

AZ431AN-AE1

MCU_VCC

D403

LL4148

1
2

MAIN12V

C6116

+

100uF/16V

C6117

0.1uF

Q403
MMBT3904

1K OHM 1/10W

R436

R414

100K OHM 1/10W

5VP

C414
10uF/10V

OSC_OUT5

C418 0.47uF /25V

U404

1

E0

2

E1E2WC

3
4

VSS

M24C32-WMN6TP

D604 SCS140V

1 2

D602 SCS140V

1 2

R668

10K OHM 1/10W

R673 47K OH M 1/ 10W

Q608

MMBT39 06

C6114

0.1uF

R435

3.3K OHM 1/10W

R418 NC

BRIGHTNESS1
HDMI_HDCP5
HDMI_EDID4

AUDIO_RESET9

SYS_RSTn5
PD_FLASH5

ISP_SCL2
ISP_SDA2

POWER_ON1
PANEL_ON1

ADC1

R450 NC
R415 4.7K OHM 1/10W
R416 10K OHM 1/10W

8

VCC

7
6

SCL

5

SDA

+

C6115

330uF/16V

R677

10K OHM 1/10W

R681

3.3K OHM 1/10W

+

C412 100uF/ 16V

C413 0.1uF

ISP_SW2

SCL2,4,5
SDA2, 4,5

MCU_HS2
MCU_VS2

X403 12MHz

C415
33pF

MCU_VCC

VGA_EDID
SCL
SDA

Q605
MMBT39 04

AZ431AN-AE1

S3

1M OHM 1/10WR417

U607

MCU_VCC

CN401

1

2

3

CONN

2K OHM 1/10W

R669

44

43
42
40

25
26
27
28

19
18
34
35

10

32
33

20

21

C416
33pF

2
6
7
8
9

U403

VDD

PA0/PWM2
PA4*/PWM6*
PA5*/PWM7*
PA6*/PWM8*
PA7*/PWM9*

PC0*
PC1*
PC3

PB4*/SCL0*
PB5*/SDA0*
PB6*/SCL1*
PB7*/SDA1*

PE1
PE0
PD2
PD1

RSTB

NC1
NC2

OSCO

OSCI

ZD604RLZ3.3B

R676
NC

NT68F631ALG

PA2/PWM4
PA3/PWM5
PA1/PWM3

PB0/ADC0
PB1/ADC1

PB2/ADC2/INTE0
PB3/ADC3/INTE1

P30/RXD
P31/TXD

P34/T0
P35/T1

PC2/SOGI

5VP

R419

2.7K OHM 1/10W

SDA_A3

5VP

R422

3

2

Q402
BSN20

3

R699

4.7K OHM 1/10W

D601
NC

R679
47K OHM 1/10W

2.7K OHM 1/10W

SCL_A3

12

1

R678
NC

PC4
PC5
PC6
PC7
PD0
PD3
PD4
PD5

PD6

GND

Q401
BSN20

3

D

BSN20

G

39
38
37
36
1
31
30
29

4
5
3

23
24

14
15

11
13

16
17

41

12
22

MCU_VCC

1

MCU _VC C

1

2

S

VGA_EDID

2

10K OHM 1/10W

AMP24V

R437
NC

NCR438

R789 22 OHM 1/ 10W
R790 22 OHM 1/ 10W
R791 22 OHM 1/ 10W
R792 22 OHM 1/ 10W

VDDP1 8
HDMIA_DET 4
HDMIB_DET 4
IF_SW 3

AMP_FAULT 10

TXD

MUTE

R420

10 OHM 1/10W

R421 NC

R423

10 OHM 1/10W

R424 NC

Q606
MMBT39 04

VGA_EDID 2
DCR_ON 5

ADC0 1

R451

R452

R670

4.7K OHM 1/10W

DCR_ON

ADC0

ADC1

R432 22 OHM 1/1 0W

RXD

R671

Q607
MMBT39 04

R439
NC

MCU_RX 2

MCU_TX 2

22 OHM 1/10W

22 OHM 1/10W

SDA_T

SCL_T

R674

10K OHM 1/10W

LI NEO UT_MU TE 2 ,9

INT_726X 5
INT_IR 1

Q405

NC

S0

S2

HDMI_B+SW 4

3

2

1

CN402
NC

SCL_T

SDA_T

SDA_T 9,10

SDA 2,4, 5

SCL_T 9,10

SCL 2,4, 5

2.2K OHM 1/1 0W

Q604

MMBT39 04

MCU_VCC

NCR440

NCR441

R667

ISP_SW

HDMIA_DET
HDMIB_DET

ADC1

MUTE

BRIGHTNESSS1
DCR_ON
AMP_FAULT
VGA_EDID

HDMI_HDCP
HDMI_EDI D
VDDP1

IF_SW

SCL_T
SDA_T
PANEL_ON
POWER_ ON

ISP_SCL
ISP_SDA
SCL
SDA

HDMI_B+SW
S2
S1

S0
PD_FLASH
SYS_R STn
S3

MUTE

R666

10K OHM 1/10W

R447 4.7K OH M 1/10W

R442 4.7K OH M 1/10W
R443 4.7K OH M 1/10W
R444 4.7K OH M 1/10W
R445 4.7K OH M 1/10W

RP410

3.3 KOHM +-5% 1/16W

R453 3.3K OHM 1/10W
R454 3.3K OHM 1/10W
R455 3.3K OHM 1/10W

R446 3.3K OHM 1/10W

RP412

1KOHM +-5% 1/16W

3.3 KOHM +-5% 1/16W

R456 3.3K OHM 1/10W
R457 3.3K OHM 1/10W
R458 3.3K OHM 1/10W
R459 3.3K OHM 1/10W

R425

1K OHM 1/10W

PHONE_DET9

R460

10K OHM 1/10W

R675
47K OHM 1/10W

1

8

2

7

3

6

4

5

1

8

2

7

3

6

4

5

RP413

1

8

2

7

3

6

4

5

RP414

1

8

2

7

3

6

4

5

D404 NC

D405 LL4148

D406 LL4148

EARPHON E_MUTE 9

MCU_VCC

MUTE="L"

R427
100K OHM 1/10W

MCU _VC C

R426

4.7K OHM 1/10W

AMP_MUTE 9

Q404
MMBT39 04

C

3904

B

E

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

32

T2968-G-X-X-13-080 627

Date

OEM MO DE L Size

H428PW

TPV MODEL

J428MNNSW1A4N C

715T2968-G07 MCU

PCB NAME

Sheet

of

811Fri day, June 27, 2008

Rev

称爹

A3

42’’ Flat Wide Monitor AOC H428Pw

burn in mode control use

VDDC1V8

C420

0.1uF

C421

0.1uF

MAI N3 V3

MAI N3 V3

MAI N1 V8

R433
0 OHM 1/10W

MAI N3 V3

C422

C423

0.1uF

0.1uF

L406 300 OHM

L407 300 OHM

+

VDDA_PLLI F

C424

C425

0.1uF

0.1uF

C441
22UF/ 10V

C445
22UF/ 10V

L408 300 OHM

C449

100uF/16V

C450

100uF/16V

3V3_1

C453
22UF/ 10V

L417 300 OHM

L418 300 OHM

C426

0.1uF

+

C427

0.1uF

C442

0.1uF

VDDP17

L403 300 OHM

C428

22UF /10V

C443

0.1uF

C446

0.1uF

186

C451

0.1uF

53

C452

0.1uF

55

87

C454

0.1uF

86

VDDAI F

VDDA_PLLI F

C444

0.1uF

NC

6

VDDA_PLLI 0

3

VSSA_PLLI0
VSSA_PLLIF

VDDA_PLLI F

VDDA_PLLLV

VSSA_PLLLV

L419
NC

248

VDDAI 0

MAI N1 V8

VDDAI F

C447

0.1uF

503738

VDDAI 1

VDDAI 1

VSSAI0

249

VDDP

6749

VDDAI FVSSAI1

C429

0.1uF

3V3_1

VSSAI1

98

VDDALV

VSSAIF

63

58

C430

C431

0.1uF

0.1uF

L409 120 OHM

C448

VDDC1V8

0.1uF

7

2785113

140

VDDC18

VDDC18

VDDC18

VDDC18

VSSALV

VSSAIF

VSSAIF

68

12

99

L404
300 OHM

C433
22UF/ 10V

C432

0.1uF

DDR_VREF6

MAI N2 V5

MAI N3 V3

VDDP

175

211

227

1774216

VDDP

VDDC18

VDDC18

VDDP

VDDC18

VDDC18

Power Block

GND

GND

GND

GND

GND

GND

GND

2279115

MAI N1 V8

GND

125

137

152

166

179

L414 300 OHM

231

VDDP

VDDP

GND

GND

220

R178
0 OHM 1/10W

R428 NC

VDDM

119

VDDM

GND

235

131

1V8_1

145

VDDM

196

MAI N3V3

160

VDDM

AGND

202

VDDM

R429 NC

172

182

151

VDDM

VDDM

VDDM

MVREF

AGND

VCC18_H AUD

AGND

208

209

C469

0.1uF

C470 22UF/10V

C434

0.1uF

C417 0.1uF

187

VDDAH

C435

C436

0.1uF

0.1uF

199

205

VDDA18_PLLHAUD

AVDD

AVDD

VSSA18_PLLHAUD

VSSA_PLLT

GND_HAUD

193

210

C471

0.1uF

C472 22U F/10V

C437

0.1uF

C459

C458

0.1uF

0.1uF

VDDA18_XTAL

VDDA_PLLI1

VSSA_PLLI1

VSSA_PLLM

VDDA_PLLM

VDDA_PLLT

194

L415 300 OHM

C438

0.1uF

C460

0.1uF

U401D
NT7263

C439

0.1uF

C440

L410 300 OHM

C461
22UF/ 10V

188

189

192

28

29
111

110

L405 300 OHM

22UF/ 10V

C462

0.1uF

C463

0.1uF

1V8_1

C465

0.1uF

C467

0.1uF

MAI N3 V3

MAI N2 V5

MAI N3 V3

L411 300 OHM

C464
22UF/ 10V

L412 300 OHM

C466
22UF/ 10V

C468
22UF/ 10V

L413 300 OHM

MAI N1V8

MAI N1V8

MAI N1 V8

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

33

T2968-G-X-X-13-080627

Date

OEM MODEL Size

TPV MODEL

PCB NAME

H428PW

J428MNNSW 1A4N C

715T2968-G08 NT7263 POWER

Sheet

911Friday , J une 27, 2008

of

Rev

称爹

B

42’’ Flat Wide Monitor AOC H428Pw

8V

15mA

SC1

SC2

SC3

SC4

SC5

AV1

AV2

COMPONE NT

VGA

HDMI D/A

HD_R2
HD_L2

HDMI_R5
HDMI_L5

AV2_R2
AV2_L2

AV1_R2
AV1_L2

PC_R2
PC_L2

HD_R
HD_L

HDMI_R
HDMI_L

AV2_R
AV2_L

AV1_R
AV1_L

PC_R
PC_L

C630

220pF

C634

220pF

C642

220pF

C651

220pF

C661

220pF

HP_R

HP_L

LINEOUT_MUTE2, 7

3.3V

1.8V

STV8351F Address (pin48)

L

H

C626 2.2UF 10V
C627 2.2UF 10V

C631

220pF

C632 2.2UF 10V
C633 2.2UF 10V

C635

220pF

C636 2.2UF 10V
C639 2.2UF 10V

C643

220pF

C649 2.2UF 10V
C650 2.2UF 10V

C652

220pF

C659 2.2UF 10V
C660 2.2UF 10V

C662

220pF

C675

4.7uF/16V

C679

4.7uF/16V

Write

80h(*)
84h

100mA

275mA

300mA

825mA

Read

81h(*)
85h

C644 0.1uF/16V
C645 10uF/16V

C646 0.1uF/16V
C647 10uF/16V

+8V

FB606

220 OHM

R628

4.7K OHM 1/10W

R631

47K OHM 1/10W

R637

4.7K OHM 1/10W

R639

47K OHM 1/10W

R602 15K OHM 1/10W
R603 15K OHM 1/10W

R605 15K OHM 1/10W
R606 15K OHM 1/10W

R608 15K OHM 1/10W
R610 15K OHM 1/10W

R613 15K OHM 1/10W
R614 15K OHM 1/10W

R619 15K OHM 1/10W
R620 15K OHM 1/10W

45mA

C6122

0.1uF/16V

C655

0.1uF/16V

Q602
MMBT3904

Q603
MMBT3904

AMPD1V8

C606

C607

0.1uF/16V

0.1uF/16V

AMP3V3

AU_8V

C654

+

10uF/16V

FB608

220 OHM

SIF3

C676

4.7uF/16V

3.9K OHM 1/10W

R629 100K OHM 1/10W

C680

4.7uF/16V

3.9K OHM 1/10W

R638 100K OHM 1/10W

C608

C609

0.1uF/16V

0.1uF/16V

25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

+

C668

0.1uF/16V

C670 56pF

C673

0.001uF

R627

R635

R640

3.9K OHM 1/10W

C611

C610

0.1uF/16V

0.1uF/16V

26272829303132333435363738394041424344454647484950

NC
NC

VSD33_CONV

VDD33_CONV
GND_SA
NC
NC
SC5_IN_R
SC5_IN_L
SC2_OUT_R
SC2_OUT_L
GND33_LS
VCC33_LS
SC2_IN_R
SC2_IN_L
VBG
VREFA
SC1_IN_R
SC1_IN_L
GND33_SC
VCC33_SC
SC3_OUT_R
SC3_OUT_L
GND_H
VCC_H
SC1_OUT_R
SC1_OUT_L

SC4_IN_R

SC4_IN_L

100999897969594939291908988878685848382818079787776

C665

10uF/16V

FB613

10uH +-10%

1 2

R625

6.8K OHM 1/10W

10uF/16V

C612

0.1uF/16V

C628 0.01uF
C629 0.01uF

NC

LS_C

SCL_FLT

SCR_FLT

SC3_IN_L

SC3_IN_R

MONO_IN

GND18_IF

VCC18_IF

GNDPW_IF

SIF2_P

SIF_N

C666

0.01uF

R696
560 OHM 1/10W

+5VT

U605

1

OUT1

VDD

2

IN1-

OUT2

3

IN1+

IN2-

4 5

VSS IN2+

PT2308-S(L)

R636

3.9K OHM 1/10W

C681

AMP1V8

C613

+

0.1uF/16V

NC

NC

LS_L

LS_R

U603

STV8318F

SIF_P

VSS18_ADC

VDD18_ADC

GND_PSUB

C667

0.22uF

C669

0.022uF

L601
120 OHM

C671

0.1uF

8
7
6

6.8K OHM 1/10W

FB601

220 OHM

C602

10uF/16V

L602 180uH

L603 180uH

NC

NC

LS_SUB

HP_LSS_L

HP_LSS_R

IRQ

BUS_EXP

VSS18

VDD18

I2SA_DATA

C601

0.001uF

HDMI_SD15
HDMI_WS15
HDMI_SCK15
HDMI_MCLK15

C672

10uF/16V

R630

NC

NC

VSS18_CONV

I2SA_LR_CLK

I2SA_SCLK

I2S_DATA3

C6780.001uF

A1V8

VSS18

VDD18

HP_DET

ADR_SEL

VDD18_CONV

I2SD_DATA

I2SO_DATA1

I2SO_LR_CLK

I2SO_SCLK

I2SO_DATAO

S/PDIF_BY PASS

S/PDIF_OU T

VDD33_IO1

VSS33_IO1

CK_TST_CTRL

VSS18
VDD18

CLK_SEL

XTALIN_CLKXTP

XTALOUT_ CLK XTM

VCC18_CLK1
GND18_CLK1
GND18_CLK2
VCC18_CLK2

VSS33_IO2

VDD33_IO2

I2S_PCM_CLK

I2S_DATA2

I2S_DATA1

I2S_DATA0

I2S_LR_CLK

I2S_SCLK

C674

+

C677

+

R632

100 OHM 1/10W

C614

0.1uF/16V

47uF/16V

47uF/16V

AMP3V3

C615

C616

0.1uF/16V

0.1uF/16V

C625

C624

0.01uF

0.01uF

R604 0 OHM 1/10W

51

SCL

52

SDA

53

RST

54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75

R690

0 OHM 1/10W

R633
100 OHM 1/10W

FB602

220 OHM

C603

+

C617

0.1uF/16V

10uF/16V

C623 1uF/16V

AMP1V8

I2C and AMP_RESETN GND

R607 100 OHM 1/10W
R609 100 OHM 1/10W
R611 100 OHM 1/10W

C6118 1uF/25V

R691 100 OHM 1/10W

IEC958O

R612 100 OHM 1/10W

C648 30PF J 50V

X601

27.000MHz

C653 22pF

1 2

C657

C656

0.1uF/16V

0.1uF/16V

R621 0 OHM 1/10W
R622 0 OHM 1/10W

R623

0 OHM 1/10W

PHONE_DET7

EARPHONE_MUTE7

NCR626

A3V3

MAIN 5V

AMPD1V8

FB607

220 OHM

6

D1

5

S1

NDC7002N

+

AMP_MUTE

AMPD3V3

C663

0.001uF

U604

G1
S2
G2D2

NCR634

FB603

220 OHM

C604
10uF/16V

I2SO_WS
I2SO_SCLK
I2SO_D0

C664

0.001uF

R624

10K OHM 1/10W

1
2
34

C618

0.1uF/16V

HP_LC619 1uF/16V

HP_R

AUDIO_RESET7

A3V3

AMPD1V8

+

AMP_MUTE 7

SCL_T
SDA_T

AMP_RESETN 10

I2SO_WS 10
I2SO_SCLK 10
I2SO_D0 10

AUDIO_RESET

LINEOUT_L
LINEOUT_R

I2SO_PCLK

LP601

8
7
6

600OHM

FB604

220 OHM

C605
10uF/16V

SCL_T 7,10
SDA_T 7, 10

LINEOUT_L 2
LINEOUT_R 2

I2SO_PCLK 10

1
2
3
45

817263

CP601

470pF

A1V8AMPD3V3

MAIN 5V

C637

100uF/16V

AMP3V3

R618 NC

EARPHONE AMP

12

54

VPORT0603100KV05

G1084-33T43UF TO252

U602

VOUTVIN

+

C620

100uF/16V

R615

NC

R697 NC

12

ZD601

VPORT0603100KV05

GND

1

U601
AP1117D18LA

ADJ(GND)

VOUT

VIN

A3V3 A1V8

123

C640

+

0.1uF

R617 NC

Q601
MMBT3904

AMP3V3

AMP3V3

R695

NC

R694 NC

C6120
NC(C1206)

CN602

1
5
4
3
2
7
6

12

ZD603

ZD602

PHONEJACK

VPORT0603100KV05

23

C641

0.1uF

AMP3V3

800mA

Q609
NC

A3V3

+

C622

0.1uF

C638

+

100uF/16V

R616
470K OHM 1/10W

C658

2.2uF 16V Y5V

C621
220uF/10V

AMP_RESETN 10

T P V ( Top Victory Elec tronics Co . , Ltd. )

T2968-G-X-X-13-080627

絬 隔 瓜 絪 腹

Key Component

09 AUDIO PROC ESSOR STV8318_NEW

Date

34

OEM MODEL Size

H428PW

TPV MOD EL

J428MNNSW1A4N C

715T2968-G

PCB NAME

Sheet

10 11Friday , June 27, 2008

of

C

Rev

称爹

>

<

称爹

42’’ Flat Wide Monitor AOC H428Pw

MAI N12 V

MAI N24 V

USE FB612 12V VCC and U606 STA559BW
USE FB609 24V VCC and U606 STA335BW

AMP3V3

R601 3. 3 OHM +-5% 1/10W

PLL_FILTER

PLL_GND

R650 0 OH M 1/ 10W
R651 0 OH M 1/ 10W
R652 0 OH M 1/ 10W
R653 0 OH M 1/ 10W
R654 100 OH M 1/10W
R655 0 OH M 1/ 10W
R656 100 OH M 1/10W
R657 100 OH M 1/10W

R659 3. 3 OHM +-5% 1/10W

C6104

0.1uF/ 16V

C6121

1uF/25V

R682 0 OHM 1/8W

R683 0 OHM 1/8W

R684 0 OHM 1/8W

R685 0 OHM 1/8W

R686 0 OHM 1/8W

R687 0 OHM 1/8W

R688 0 OHM 1/8W

R692 0 OHM 1/8W

R693 0 OHM 1/8W

R698 0 OHM 1/8W

AMP3V3

R645

10K OHM 1/10W

PLL_Vdd

U606

20

TWA RN /OU T4B

21

Vdd_DIG

22

GND_DIG

23

PWRDN

24

PLL_Vdd

25

PLL_FILTER

26

PLL_GND

27

XTI

28

BICKI

29

LRCKI

30

SDI

31

RESET

32

INT_LINE

33

SDA

34

SCL

35

GND_DIG

36

Vdd_DIG

STA335BW

OUT3A/DD X3AEAPD/OU T4A
OUT3B/DD X3B

GND

Vdd

GND_REG

OUT1A

GND1

Vcc1
OUT1B
OUT2A

VCC2
GND2

OUT2B

Vcc_REG

VSS

TEST_MODE

GND_SU B

AMP24V

R641

NC

L604 22uH +-25%

C687

R643

22 OHM 1/4W

C691

C692

AMP24V

1819
17
16

C695 0.1uF

15
14
13
12
11
10
9
8
7
6

C6102 0.1uF

5
4
3
2

SA

1

LOUT­ROUT+

LOUT+

ROUT-

330pF

R661

22 OHM 1/4W

C6110

330pF

0.1uF

22uH +-25%

L605

C6101

0.1uF

L606 22uH +-25%

C6109

0.1uF

22uH +-25%

L607

C6113

0.1uF

0.1uF

R644

6R2 1/4W 5%

C694

0.1uF

R649

6R2 1/4W 5%

C6105

0.1uF

R662

6R2 1/4W 5%

C6112

0.1uF

R665

6R2 1/4W 5%

C689

0.47uF

C6107

0.47uF

AMP24V

R642

NC

R646

NC

R647

NC

R658

NC

R660

NC

R663

NC

R664

NC

AMP24V

AMP24V

C688

0.001uF

C693

0.001uF

C6106

0.001uF

C6111

0.001uF

C690

0.001uF

C6108

0.001uF

4
3
2
1

CN601

CONN

L

L+
L­R+
R-

R

AMP3V3

C696

0.1uF/ 16V

I2SO_D09
AMP_MUTE7

C6123

NC

FB610

1 2

600 OHM

FB611

1 2

600 OHM

I2SO_D0
AMP_MUTE

C683

+

0.1uF

PLL_Vdd

C697

0.1uF/ 16V

U608

1

A

2

B

3 4

GND Y

SN74LVC1G0 8DCKR

C684

0.1uF

R648 2.2K OH M 1/10W

C698

C699

NC

4700PF50V

AMP3V3

5

VCC

C685

1uF

AMP_RESETN9

C6119

0.1uF/16V

C686

I2SO_PCLK9
I2SO_SCLK9
I2SO_WS9

AMP_FAULT7

FB612

1 2

C682

+

1 2

1000UF/ 35V

C6100

680pF/2 5V

I2SO_PCLK

I2SO_SCLK
I2SO_WS

AMP_RESETN
AMP_FAULT
SDA_T
SCL_T

C6103

0.1uF/ 16V

NC

FB609

300 OHM

AMP24V

1uF

SDA_T7, 9
SCL_T7,9

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

T2968-G-X-X-13-080627

Date

OEM MODEL Size

TPV MOD EL

PCB NAME

H428PW

J428MNNSW1A4N C

715T2968-G10 A UDI O AMP STA335W_NEW

of

11 11Friday , June 27, 2008

Sheet

Rev

称爹

B

35

42’’ Flat Wide Monitor AOC H428Pw

9.2 Power Board

715T2802 1

36

42’’ Flat Wide Monitor AOC H428Pw

37

42’’ Flat Wide Monitor AOC H428Pw

9.3 Key Board

715T2876 1

38

42’’ Flat Wide Monitor AOC H428Pw

9.4 IR Board

715T2877 1 2

39

42’’ Flat Wide Monitor AOC H428Pw

10. Exploded View

H428Pw

40

42’’ Flat Wide Monitor AOC H428Pw

11. BOM List

J42RMNNSW1A4NN

Location Part No. Description Remark

001T6021 1 SCREW
033T 465 1 CLIP JIONTER
044T3231 15531 EVA
045T 76 28 C PE BAG FOR MANUAL
049T 51 1A ERADICATOR
050T 500 1 CABLE TIE
050T 500 1 CABLE TIE
052T 1150 C BLACK TAPE
052T 1185 MIDDLE TAPE FOR CARTON
052T 1186 SMALL TAPE
052T 1211 A ADHESIVE TYPE
052T 2191 A TAPE
078T 499 1 G SPEAKER 8 OHM 11W 156X30MM
089T 17356G553 AUDIO CABLE
089T 725GAA DB D-SUB
089T402A15NIS1 POWER CORD
095T801312D 50 HARNESS 12P-12P 180MM
095T8014 4D547 WIRE HARNESS 4P(PLUG)-B&R+B&W
095T8014 8D 73 HARNESS 8P-4P+3P 1100MM
095T801413D 32 HARNESS 13P-12P 550MM
095T801413D 33 HARNESS 13P-12P 550MM
095T801851D 5 HARNESS 51P-40 300MM

098TRABD3NEACC REMOTE CONTROL RL57A

0M1T 930 6 47 CR3 SCREW
0M1T 940 6120 SCREW
0M1T 940 16 47 CR3 SCREW M4X6
0M1T1730 8120 SCREW
0M1T1730 10120 SCREW
0Q1T 930 8 47 CR3 SCREW
0Q1T 930 8120 SCREW
0Q1T 940 12 47 CR3 T4X12 SCREW
0Q1T 940 20 47 CR3 SCREW
705TQ834335 BEZEL ASS'Y
0Q1T 930 6120 SCREW
A33J0304 GMG1L0100 COVER_FUNC
A33J0305 QV 1L0100 BUTTON_FUNC
A33J0306 1 1C0100 POWER LENS
A33J0307 ED 1C0100 LENS_IR
A34J0541 GMB1L0130 BEZEL TV42W-8A1
705TQ834336 STAND ASS'Y
0M1T 130 6120 SCREW
0Q1T 130 10120 SCREW
A15J0301101 BASE BRACKET
A34J0544 GM 1L0100 STAND COVER A1
A34J0545 GM 1L0133 BASE S1
A37J0060011 HINGE
Q12T6300 25 1 FOOT PAD
Q12T6300 25 1 FOOT PAD

41

42’’ Flat Wide Monitor AOC H428Pw

705TQ834337 REAR COVER ASS'Y
A15J0282101 BKT-VESA-BTM
A34J0542 GM 2A0100 REAR COVER 42"

E750 750TVMT0H1111N PANEL V420H1-L11 TW CMO

E750 750TVMT0H1113N PANEL V420H1-L11 C1 NH CMO 2nd source

756TQ8CB NS001 MAIN BOARD-CBPFRN3SQ6
U403 056T1125177 NT68F631ALG PLCC-44
U510 056T1133526 IC MX25L4005AMC-12G SOP-8

SMTF-U403 100TANMM005S11 MCU ASSY-056T1125177
SMTF-U510 100TANMM004S11 MCU ASSY-056T1133526

A15J0297101 QUICK RELEASE

A15J0298101 STAND BRACKET

A15J0299101 PCB BRACKET

A15J0302101 VESA BRACKET

A15J0343101 FIX BRACKET

A15J0344101 FIX BRACKET

A34J0543 GM 1L0100 NECK COVER

ADPC24250BB1 ADAPTER BOARD T2802-1-X-X-1-080812

040G 45762412B CBPC LABEL

009T6005 1 GROUND TERMINAL

CN903 033T327812D WAFER 12P PLUG
CN902 033T380213B Y CONNECTOR
CN904 033T380213B Y CONNECTOR

051G 6 4503 GLUE_RTV

IC904 056G 139 7 1 IC EL817MA M-TYPE
IC905 056G 139 7 1 IC EL817MA M-TYPE
IC907 056G 139 7 1 IC EL817MA M-TYPE

R969 061G 3J158 59 0.15 OHM +-5% 3W

RV901 061T 46 17 VARISTOR 560V TNR14V561K

R913 061T153M108 59 RST MOFR 0.1 OHM +-5% 3WS
R914 061T153M108 59 RST MOFR 0.1 OHM +-5% 3WS
C904 063T107K474 TS CAP X2 0.47UF K 275VAC UTX
C901 063T107K474 TS CAP X2 0.47UF K 275VAC UTX
C904 063T107K474 US X2 CAP 0.47UF K 275VAC
C901 063T107K474 US X2 CAP 0.47UF K 275VAC
C948 063T210J2735C2 MPP 27NF J 1000V
C948 063T210J2735CC CAP MPPS 27NF 1000V 5%
C905 063T210K105BCN MPP CAP 1UF 520V P=15MM

C905 063T213J105GFA MPF CAP 2nd source

C905 063T213J105GFC CAP MPE 1UF J 450V 2nd source
C958 065T305K2212E3 Y2 CAP 220PF / 250V 10%
C957 065T305K2212E3 Y2 CAP 220PF / 250V 10%
C903 065T305K2212E3 Y2 CAP 220PF / 250V 10%
C902 065T305K2212E3 Y2 CAP 220PF / 250V 10%
C958 065T305K2212EM 221PF 10% 250V BY MURATA
C957 065T305K2212EM 221PF 10% 250V BY MURATA
C903 065T305K2212EM 221PF 10% 250V BY MURATA
C902 065T305K2212EM 221PF 10% 250V BY MURATA
C956 065T306K6812BM Y1 CAP 680PF 10% 250VAC KX
C955 065T306K6812BM Y1 CAP 680PF 10% 250VAC KX
C956 065T306K6812BP Y1 680PF M 250VAC

42

42’’ Flat Wide Monitor AOC H428Pw

C955 065T306K6812BP Y1 680PF M 250VAC
C951 065T306M1022B3 Y1 CAP 1000PF +-20% 250VAC CD SERIES
C933 065T306M1022B3 Y1 CAP 1000PF +-20% 250VAC CD SERIES
C921 067G215A1024KV EC 1000UF 25V 12.5*20MM
C935 067T215A1026KV EC 1000UF 35V 12.5*25MM
C936 067T215A1026KV EC 1000UF 35V 12.5*25MM
C923 067T215A4713KV EC 470UF 16V M 10*12MM
C918 067T215A4714KV EC 470UF 25V 10*16MM
C937 067T215A4716KV EC 470UF 35V M 10*16MM

C908 067T315Z12115K

C907 067T315Z12115K

L903 073L 174 49LSG LINE FILTER
L901 073L 174 49LSG LINE FILTER
L902 073L 174 52 LG CHOKE COIL

L904 073T 174119 L PFC CHOKE 600UH PT-009490 2nd source
L904 073T 174119 N PFC CHOKE 600UH YUVA-841
L907 073T 253197 H CHOKE COIL 3.0UH
L907 073T 253197 L CHOKE COIL 3.0UH CC-009425
T901 080TL32T 5 L X'FMR 1.9MH PT-009424
T901 080TL32T 5 N X'FMR 1.9MH YUVA-827

T902 080TL42T 14 L X'FMR 600UH PT-009533 2nd source
T902 080TL42T 14 YS X'FMR 600UH YS04160152

CN901 087T 501 44 DL AC SOCKET 3PIN + 2 SCREW HOLE V/T

705TQ757014 Q902/Q903 ASS`Y
Q902 057T 667 24 STP20NM60 FP
Q903 057T 667 24 STP20NM60 FP

0M1T1730 10120 SCREW

Q90G0099 1 HEAT SINK

705TQ757015 Q901 ASS'Y
Q901 057T 667 52 FET 2SK4100LS-T 7A/650V TO-220FI(LS)

090G6084 1 GP HEAT SINK

0M1T1730 8120 SCREW

705TQ761020 NR901 ASS'Y

NR901 061T 58050 WL GP

Q09T 203 8 PIN

705TQ793024 D904/D901 ASS'Y

012T 372 2 SILICON

Q904 057T 667 25 STW20NM60

D901 093T 220 20 STTH15R06FP TO-220FP 2nd source
D901 093T 220 33 DIODE FMXA-1106S

0M1T1730 10120 SCREW

0M1T1730 10120 SCREW

Q90T0097A01 HEAT SINK

705TQ793025 D907 ASS'Y

090G6084 1 GP HEAT SINK

D907 093T 60298

0M1T1730 8120 SCREW

705TQ793026 BD901 ASS'Y

BD901 093T 50460 18 D10XB60

0M1T1730 10120 SCREW

CAP 105℃ 120UF M 450V
CAP 105℃ 120UF M 450V

RST NTCR 5 OHM +-15% 5A 13MM
THINKING

DIODE SBT15006JST 15A/60V
TO-220ML(LS)

43

42’’ Flat Wide Monitor AOC H428Pw

Q90T0148 1 HEAT SINK

705TQ793027 D916&D917&D906 ASS'Y

D906 093T 60298

D916 093T 60306 DIODE FMEN-230A 30A/100V TO-220
D917 093T 60306 DIODE FMEN-230A 30A/100V TO-220

D916 093T 60314

D917 093T 60314

0M1T1730 10120 SCREW

Q90T0148 1 HEAT SINK

IC902 056T 379 79 IC LD7522PS SOP-8
IC901 056T 379104 IC ICE2PCS02G PG-DSO-8
IC903 056T 665 10 1 IC RESONANT L6599DTR SO-16N ST

Q907 057T 417 12 T TRA 2N3904S-RTK/PS SOT-23 KEC
Q906 057T 417 12 T TRA 2N3904S-RTK/PS SOT-23 KEC
Q908 057T 417 12 T TRA 2N3904S-RTK/PS SOT-23 KEC
R932 061G0805244 RST CHIPR 240 KOHM +-5% 1/8W
R929 061G1206105 1M 1206
R930 061G1206105 1M 1206
R931 061G1206105 1M 1206
R935 061G1206154 RST CHIPR 150K OHM +-5% 1/4W
R934 061G1206154 RST CHIPR 150K OHM +-5% 1/4W
R933 061G1206154 RST CHIPR 150K OHM +-5% 1/4W
R905 061G1206225 RST CHIPR 2.2 MOHM +-5% 1/4W
R906 061G1206225 RST CHIPR 2.2 MOHM +-5% 1/4W
R920 061G1206225 RST CHIPR 2.2 MOHM +-5% 1/4W
R916 061G1206430 3F RST CHIPR 430 KOHM +-1% 1/4W
R918 061G1206430 3F RST CHIPR 430 KOHM +-1% 1/4W
R982 061G1206430 3F RST CHIPR 430 KOHM +-1% 1/4W
R980 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R961 061T0805100 2F RST CHIPR 10 KOHM +-1% 1/8W
R973 061T0805100 2F RST CHIPR 10 KOHM +-1% 1/8W
R919 061T0805100 2F RST CHIPR 10 KOHM +-1% 1/8W
R944 061T0805101 RST CHIPR 100 OHM +-5% 1/8W
R964 061T0805101 RST CHIPR 100 OHM +-5% 1/8W
R921 061T0805102 RST CHIPR 1KOHM +-5% 1/4W
R943 061T0805102 RST CHIPR 1KOHM +-5% 1/4W
R945 061T0805102 RST CHIPR 1KOHM +-5% 1/4W
R951 061T0805102 RST CHIPR 1KOHM +-5% 1/4W
R954 061T0805102 RST CHIPR 1KOHM +-5% 1/4W
R970 061T0805102 RST CHIPR 1KOHM +-5% 1/4W
R942 061T0805103 RST CHIPR 10 KOHM +-5% 1/8W
R937 061T0805103 RST CHIPR 10 KOHM +-5% 1/8W
R911 061T0805103 RST CHIPR 10 KOHM +-5% 1/8W
R977 061T0805104 RST CHIPR 100 KOHM +-5% 1/8W
R940 061T0805154 RST CHIPR 150 KOHM +-5% 1/8W
R976 061T0805200 1F RST CHIPR 2KOHM +-1% 1/8W
R946 061T0805202 RST CHIPR 2 KOHM +-5% 1/8W
R975 061T0805205 2F RST CHIPR 20.5KOHM +-1% 1/8W
R917 061T0805220 RST CHIPR 22 OHM +-5% 1/8W

DIODE SBT15006JST 15A/60V
TO-220ML(LS)

DIODE SBR25010JST 25A/100V
TO-220ML(LS)
DIODE SBR25010JST 25A/100V
TO-220ML(LS)

2nd source

44

42’’ Flat Wide Monitor AOC H428Pw

R936 061T0805220 RST CHIPR 22 OHM +-5% 1/8W
R965 061T0805220 RST CHIPR 22 OHM +-5% 1/8W
R967 061T0805220 RST CHIPR 22 OHM +-5% 1/8W
R909 061T0805220 RST CHIPR 22 OHM +-5% 1/8W
R950 061T0805221 RST CHIPR 220 OHM +-5% 1/8W
R952 061T0805221 RST CHIPR 220 OHM +-5% 1/8W
R960 061T0805240 2F RST CHIPR 24 KOHM +-1% 1/8W
R947 061T0805242 RST CHIPR 2.4 KOHM +-5% 1/8W
R949 061T0805242 RST CHIPR 2.4 KOHM +-5% 1/8W
R953 061T0805272 RST CHIPR 2.7 KOHM +-5% 1/8W
R959 061T0805273 RST CHIPR 27 KOHM +-5% 1/8W
R904 061T0805332 RST CHIPR 3.3 KOHM +-5% 1/8W
R979 061T0805332 RST CHIPR 3.3 KOHM +-5% 1/8W
R963 061T0805390 1F RST CHIPR 3.9KOHM +-1% 1/8W
R939 061T0805471 RST CHIPR 470 OHM +-5% 1/8W
R974 061T0805510 1F RST CHIPR 5.1KOHM +-1% 1/8W
R941 061T0805513 RST CHIPR 51 KOHM +-5% 1/8W
R966 061T0805513 RST CHIPR 51 KOHM +-5% 1/8W
R968 061T0805513 RST CHIPR 51 KOHM +-5% 1/8W
R978 061T0805513 RST CHIPR 51 KOHM +-5% 1/8W
R962 061T0805514 RST CHIPR 510KOHM +-5% 1/8W
R948 061T0805560 2F RST CHIPR 56KOHM +-1% 1/8W
R972 061T0805750 1F RST CHIPR 7.5KOHM +-1% 1/8W

JR907 061T1206000 RST CHIPR 0 OHM +-5% 1/4W
JR906 061T1206000 RST CHIPR 0 OHM +-5% 1/4W
JR905 061T1206000 RST CHIPR 0 OHM +-5% 1/4W
JR904 061T1206000 RST CHIPR 0 OHM +-5% 1/4W
JR903 061T1206000 RST CHIPR 0 OHM +-5% 1/4W
JR902 061T1206000 RST CHIPR 0 OHM +-5% 1/4W
JR901 061T1206000 RST CHIPR 0 OHM +-5% 1/4W

R958 061T1206205 RST CHIPR 2 MOHM +-5% 1/4W
R957 061T1206205 RST CHIPR 2 MOHM +-5% 1/4W
R956 061T1206205 RST CHIPR 2 MOHM +-5% 1/4W
R915 061T1206221 RST CHIPR 220 OHM +-5% 1/4W
R903 061T1206334 RST CHIPR 330 KOHM +-5% 1/4W
R902 061T1206334 RST CHIPR 330 KOHM +-5% 1/4W
R901 061T1206334 RST CHIPR 330 KOHM +-5% 1/4W
R928 061T1206470 RST CHIPR 47 OHM +-5% 1/4W
R927 061T1206470 RST CHIPR 47 OHM +-5% 1/4W
R924 061T1206479 RST CHIPR 4.7 OHM +-5% 1/4W
R971 061T1206512 RST CHIPR 5.1KOHM +-5% 1/4W
C952 065T0805102 31 1000PF 50V NPO
C912 065T0805102 32 CHIP 1000PF 50V X7R 0805
C929 065T0805102 32 CHIP 1000PF 50V X7R 0805
C947 065T0805102 32 CHIP 1000PF 50V X7R 0805
C942 065T0805102 32 GP CHIP 1000P 50VX7R 0805
C950 065T0805103 32 10NF/50V/0805/X7R
C931 065T0805104 22 0.1UF +-10% 25V X7R 0805
C949 065T0805104 22 0.1UF +-10% 25V X7R 0805
C934 065T0805104 22 0.1UF +-10% 25V X7R 0805
C932 065T0805104 22 0.1UF +-10% 25V X7R 0805

45

42’’ Flat Wide Monitor AOC H428Pw

C926 065T0805104 22 0.1UF +-10% 25V X7R 0805
C920 065T0805104 32 CHIP 0.1UF 50V X7R
C924 065T0805104 32 CHIP 0.1UF 50V X7R
C938 065T0805104 32 CHIP 0.1UF 50V X7R
C944 065T0805104 32 CHIP 0.1UF 50V X7R
C914 065T0805104 32 CHIP 0.1UF 50V X7R
C911 065T0805105 22 CHIP 1UF 25V X7R 0805
C943 065T0805105 22 CHIP 1UF 25V X7R 0805
C925 065T0805105 22 GP CHIP 1UF 25V X7R
C922 065T0805105 37 CHIP 1UF 50V Y5V
C939 065T0805105 37 CHIP 1UF 50V Y5V
C940 065T0805221 31 220PF 50V NPO
C913 065T0805223 22 CHIP 0.022UF 25V X7R 0805
C941 065T0805224 32 0805.0.22UF.K.50V.X7R
C910 065T0805472 22 CHIP 0.0047UF 25V X7R 0805
C930 065T0805473 32 CHIP 0.047UF 50V X7R
C917 065T1206102 72 CHIP 1000PF 500V X7R
C945 065T1206104 32 CHIP 0.1UF 50V X7R 1206
D915 093T 6432V LL4148-GSO8 SMD BY VISHA
D914 093T 6432V LL4148-GSO8 SMD BY VISHA
D913 093T 6432V LL4148-GSO8 SMD BY VISHA
D912 093T 6432V LL4148-GSO8 SMD BY VISHA
D911 093T 6432V LL4148-GSO8 SMD BY VISHA
D909 093T 6432V LL4148-GSO8 SMD BY VISHA
D908 093T 6432V LL4148-GSO8 SMD BY VISHA
D902 093T 6432V LL4148-GSO8 SMD BY VISHA

ZD901 093T 39S 15 T RLZ15B
ZD905 093T 39S 15 T RLZ15B
ZD904 093T 39S 24 T RLZ 5.6B LLDS

L904 006G 31 4 1.7MM RIVET

CN901 006G 31501 EYELET

T902 006G 31502 1.5MM RIVET
IC906 056T 158 12 KIA431A-AT/P
IC908 056T 158 12 KIA431A-AT/P

R922 061G 30347852T GP RST FUSER 0.47OHM +-5% 1W
R955 061T 30310852T GP 0.1 OHM 1W FUSE RESISTOR
R923 061T152M10452T RST MOFR 100KOHM +-5% 2WS
R938 061T152M12952T RST MOFR 1.2OHM +-5% 2WS
C915 065G 2K152 1T6213 CAP CER 1500PF K 2KV
C909 067G215A4704KT EC 47UF 25V 5*11MM
C946 067G215A4704KT EC 47UF 25V 5*11MM
C927 067T215A1007KT EC 10UF 50V 5*11MM
C928 067T215A1017KT EC 100UF 50V 8*12MM

C919 067T215A2214KT EC 220UF 25V 8*12MM
FB905 071T 55 9 T BEAD 3.5*6*0.8
FB904 071T 55 9 T BEAD 3.5*6*0.8
FB903 071T 55 9 T BEAD 3.5*6*0.8
FB907 071T 55 29 BEAD
FB906 071T 55 29 BEAD
FB901 071T 55 29 BEAD

F901 084T 55 4 FUSE 382-5A 250V WICKMANN

46

42’’ Flat Wide Monitor AOC H428Pw

D910 093T 5250S52T AU02Z

D918 093T1080 252T DIODE SARSO1-V1 SANKEN

D905 093T1080 252T DIODE SARSO1-V1 SANKEN

J920 095T 90 23 JUMP WIRE
J919 095T 90 23 JUMP WIRE
J918 095T 90 23 JUMP WIRE
J917 095T 90 23 JUMP WIRE
J915 095T 90 23 JUMP WIRE
J914 095T 90 23 JUMP WIRE
J913 095T 90 23 JUMP WIRE
J912 095T 90 23 JUMP WIRE
J911 095T 90 23 JUMP WIRE
J910 095T 90 23 JUMP WIRE
J909 095T 90 23 JUMP WIRE
J908 095T 90 23 JUMP WIRE
J907 095T 90 23 JUMP WIRE
J906 095T 90 23 JUMP WIRE
J905 095T 90 23 JUMP WIRE
J904 095T 90 23 JUMP WIRE
J903 095T 90 23 JUMP WIRE
J902 095T 90 23 JUMP WIRE
J901 095T 90 23 JUMP WIRE
F902 095T 90 23 JUMP WIRE
J941 095T 90 23 JUMP WIRE
J940 095T 90 23 JUMP WIRE
J939 095T 90 23 JUMP WIRE
J938 095T 90 23 JUMP WIRE
J937 095T 90 23 JUMP WIRE
J936 095T 90 23 JUMP WIRE
J934 095T 90 23 JUMP WIRE
J933 095T 90 23 JUMP WIRE
J932 095T 90 23 JUMP WIRE
J931 095T 90 23 JUMP WIRE
J929 095T 90 23 JUMP WIRE
J927 095T 90 23 JUMP WIRE
J926 095T 90 23 JUMP WIRE
J925 095T 90 23 JUMP WIRE
J924 095T 90 23 JUMP WIRE
J923 095T 90 23 JUMP WIRE
J922 095T 90 23 JUMP WIRE
J921 095T 90 23 JUMP WIRE

715T2802 1

006G 31 4 1.7MM RIVET

L905 S73G25391V CHOKE COIL ASS'Y
L906 S73G25391V CHOKE COIL ASS'Y

L907 S73T253197V TRANSFORMER ASS'Y
CN702 033T327812D WAFER 12P PLUG
CN401 033T3802 3 WAFER EH-3
CN601 033T3802 4B Y CONNECTOR
CN701 033T3802 8B Y CONNECTOR

POWER PCB 200X200X1.6MM CEM-1 2OZ
S/S

47

42’’ Flat Wide Monitor AOC H428Pw

CN201 033T8027 40 WAFER 40P 2.0MM DIP

040T 45762412B CBPC LABEL

R167 061T153M470 59 RST MOFR 47 OHM +-5% 3WS
R168 061T153M470 59 RST MOFR 47 OHM +-5% 3WS
C682 067T215S102 6K 1000UF 35V

C171 067T215S1023KV

L607 073T 253158 H CHOKE COIL 22UH+/-25%

L606 073T 253158 H CHOKE COIL 22UH+/-25%

L605 073T 253158 H CHOKE COIL 22UH+/-25%

L604 073T 253158 H CHOKE COIL 22UH+/-25%
CN106 088T 78 1364S RCA JACK 2*3 Y/W/R+Y/W/R V/A
CN105 088T 78 1365S RCA JACK 3+2 G/B/R+ W/R V/A
CN111 088T 7813A19C RCA JACK 1*3 R/W/Y
CN108 088T 100 11 CL MINI DIN JACK 4P+ SWITCH
CN108 088T 100 11 ST MINI DIN JACK 4P+ SWITCH 2MJ-0602-005
CN103 088T 100 15 ST MINI DIN JACK 4PIN V/A
CN102 088T 30252C PHONE JACK 3.5MM 3P V/A GREEN
CN102 088T 30252S PHONE JACK 3.5MM 3P V/A GREEN

CN602 088T 302901 S

CN101 088T 35315FTNA

CN101 088T 35315FVSC

X403 093T 2251B J NXS12.000AC30F-BT-2

X503 093T 2251B J NXS12.000AC30F-BT-2

X601 093T 2264B J XTL NXS27.000AC16F-KAB5 HC-49/US

X502 093T 2279B H CRYSTAL 28.322MHZ 14P HC-49S

C689 064T701J4740AT 0.47UF 50V

C6107 064T701J4740AT 0.47UF 50V

C602 067T 305100 3T 10UF 16V
C603 067T 305100 3T 10UF 16V
C604 067T 305100 3T 10UF 16V
C605 067T 305100 3T 10UF 16V
C654 067T 305100 3T 10UF 16V
C665 067T 305100 3T 10UF 16V
C724 067T 305100 7T 10UF
C723 067T 305100 7T 10UF
C169 067T 305100 7T 10UF
C126 067T 305100 7T 10UF
C125 067T 305100 7T 10UF
C123 067T 305100 7T 10UF
C121 067T 305100 7T 10UF
C120 067T 305100 7T 10UF
C170 067T 305101 3T 100UF 16V 105C
C201 067T 305101 3T 100UF 16V 105C
C412 067T 305101 3T 100UF 16V 105C
C449 067T 305101 3T 100UF 16V 105C
C450 067T 305101 3T 100UF 16V 105C
C728 067T 305101 3T 100UF 16V 105C
C726 067T 305101 3T 100UF 16V 105C
C716 067T 305101 3T 100UF 16V 105C

EC 105℃ CAP 1000UF M 16V

PHONE JACK 3.5MM 7P BLACK
2SJ-W48A-001
D-SUB CONN V 15P F (WITH SCREW
UNLOCKED)
D-SUB 15PIN VERTICAL CONN WITH
SCREW

48

42’’ Flat Wide Monitor AOC H428Pw

C711 067T 305101 3T 100UF 16V 105C
C708 067T 305101 3T 100UF 16V 105C
C638 067T 305101 3T 100UF 16V 105C
C637 067T 305101 3T 100UF 16V 105C
C620 067T 305101 3T 100UF 16V 105C

C6116 067T 305101 3T 100UF 16V 105C

C505 067T 305220 3T

C718 067T 305221 2T

C713 067T 305221 2T

C710 067T 305221 2T

C621 067T 305221 2T

C6115 067T 305331 3T

C674 067T 305470 3T

C677 067T 305470 3T

040T 457624 1B CPU LABEL
U704 056T 133 30AAC IC AZ1117H-ADJ-E1
U406 056T 158501 IC AS431AN-E1 SOT23
U607 056T 158501 IC AS431AN-E1 SOT23
U601 056T 563 50 AP1117D18LA T0252-3L
U707 056T 563 51 AP1117D50LA T0252-3L
U703 056T 563 56 AP1084D18LA TO-252-3L
U602 056T 563 75 G1084-33T43UF TO-252
U705 056T 563 96 IC AIC1084-25PETR-R TO-252
U701 056T 563121 IC G1084-33TU3UF TO-263T
U603 056T 593 29 1 IC STV8318F TQFP-100
U606 056T 593 32 IC STA335BW13TR POWERSSO36
U103 056T 614 1 IC 74HC4052D PHILIPS
U402 056T 615913 IC HYB25DC256160CE-5 TSOPII66
U605 056T 616 3 PT2308S SO-8 PTC
U507 056T 634 19 IC PS321TQFP80G TQFP-80
U105 056T 647 18 IC WM8521HCGED/RV SOIC-14
U505 056T 662 10 IC RCLAMP0524P.TCT
U506 056T 662 10 IC RCLAMP0524P.TCT
U502 056T 662 10 IC RCLAMP0524P.TCT
U503 056T 662 10 IC RCLAMP0524P.TCT
U403 056T1125177 NT68F631ALG PLCC-44
U401 056T1126 35 IC NT7263 LQFP-256
U509 056T1133 32 M24C04-WMN6TP
U504 056T1133 34 M24C02-WMN6TP
U501 056T1133 34 M24C02-WMN6TP
U102 056T1133 34 M24C02-WMN6TP
U510 056T1133526 IC MX25L4005AMC-12G SOP-8
U404 056T113353A M24C32-WMN6TP
U101 056T4LVC 14 P 74LVC14ADT
U608 056T4LVCG08 TI IC SN74LVC1G08DCKR SC70-5
U604 056T566N600 NDC7002N SOT-6 FAIRCHILD
Q108 057T 417511 TRA MMBT3904 BLUE ROKET
Q710 057T 417511 TRA MMBT3904 BLUE ROKET
Q707 057T 417511 TRA MMBT3904 BLUE ROKET
Q705 057T 417511 TRA MMBT3904 BLUE ROKET
Q704 057T 417511 TRA MMBT3904 BLUE ROKET

EC 105℃ 22UF M 16V
CAP 105℃ 220UF M 10V
CAP 105℃ 220UF M 10V
CAP 105℃ 220UF M 10V
CAP 105℃ 220UF M 10V
CAP 105℃ 330UF 16V
EC 105℃ 47UF M 16V
EC 105℃ 47UF M 16V

49

42’’ Flat Wide Monitor AOC H428Pw

Q702 057T 417511 TRA MMBT3904 BLUE ROKET
Q607 057T 417511 TRA MMBT3904 BLUE ROKET
Q606 057T 417511 TRA MMBT3904 BLUE ROKET
Q605 057T 417511 TRA MMBT3904 BLUE ROKET
Q604 057T 417511 TRA MMBT3904 BLUE ROKET
Q603 057T 417511 TRA MMBT3904 BLUE ROKET
Q602 057T 417511 TRA MMBT3904 BLUE ROKET
Q601 057T 417511 TRA MMBT3904 BLUE ROKET
Q503 057T 417511 TRA MMBT3904 BLUE ROKET
Q502 057T 417511 TRA MMBT3904 BLUE ROKET
Q501 057T 417511 TRA MMBT3904 BLUE ROKET
Q404 057T 417511 TRA MMBT3904 BLUE ROKET
Q403 057T 417511 TRA MMBT3904 BLUE ROKET
Q608 057T 417512 TRA MMBT3906 BLUE ROKET
Q105 057T 417512 TRA MMBT3906 BLUE ROKET
Q106 057T 419 8 T TRA 2SD1757K 0.5A/15V SC-59
Q107 057T 419 8 T TRA 2SD1757K 0.5A/15V SC-59
Q401 057T 600 54 FET BSN20 SOT-23 PHILIPS
Q402 057T 600 54 FET BSN20 SOT-23 PHILIPS
Q701 057T 763 3 AO4411L SO-8 BY AOS SMT
Q706 057T 763 3 AO4411L SO-8 BY AOS SMT
Q708 057T 763 3 AO4411L SO-8 BY AOS SMT

RP413 061T 125102 8 RST CHIP AR 8P4R 1KOHM +-5% 1/16W
RP401 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R
RP402 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R
RP403 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R
RP404 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R
RP505 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R
RP506 061T 125220 8 CHIP ARRAY 220HM 1/16W 8P4R
RP410 061T 125332 8 RST CHIPR AR 8P4R 3.3KOHM +-5% 1/16W
RP412 061T 125332 8 RST CHIPR AR 8P4R 3.3KOHM +-5% 1/16W
RP414 061T 125332 8 RST CHIPR AR 8P4R 3.3KOHM +-5% 1/16W
RP405 061T 125750 8 RST CHIP AR 8P4R 75 OHM +-5% 1/16W
RP406 061T 125750 8 RST CHIP AR 8P4R 75 OHM +-5% 1/16W
RP407 061T 125750 8 RST CHIP AR 8P4R 75 OHM +-5% 1/16W
RP408 061T 125750 8 RST CHIP AR 8P4R 75 OHM +-5% 1/16W

R623 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R622 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R621 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R604 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R544 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R543 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R518 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R516 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R650 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R651 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R652 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R653 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R655 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R690 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R702 061T0603000 RST CHIPR 0 OHM +-5% 1/10W

50

42’’ Flat Wide Monitor AOC H428Pw

R743 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R120 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R124 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R130 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R131 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R140 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R178 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R191 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R202 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R217 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R218 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R227 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R404 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R405 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R430 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R431 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R433 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R420 061T0603100 CHIP 10OHM 1/16W
R423 061T0603100 CHIP 10OHM 1/16W
R721 061T0603100 3F RST CHIPR 100KOHM +-1% 1/10W
R611 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R609 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R607 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R161 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R160 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R159 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R158 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R157 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R156 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R155 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R154 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R153 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R152 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R151 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R101 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R102 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R105 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R108 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R146 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R147 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R148 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R149 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R150 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R704 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R691 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R657 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R656 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R654 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R633 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R632 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R612 061T0603101 RST CHIPR 100 OHM +-5% 1/10W

51

42’’ Flat Wide Monitor AOC H428Pw

R511 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R509 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R504 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R503 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R501 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R435 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R425 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R413 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R412 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R527 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R528 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R529 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R534 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R540 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R710 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R407 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R406 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R113 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R128 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R129 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R416 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R460 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R530 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R549 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R550 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R558 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R624 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R645 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R666 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R668 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R671 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R674 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R677 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R680 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R711 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R712 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R715 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R720 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R723 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R783 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R118 061T0603104 RST CHIPR 100KOHM +-5% 1/10W
R414 061T0603104 RST CHIPR 100KOHM +-5% 1/10W
R427 061T0603104 RST CHIPR 100KOHM +-5% 1/10W
R629 061T0603104 RST CHIPR 100KOHM +-5% 1/10W
R638 061T0603104 RST CHIPR 100KOHM +-5% 1/10W
R706 061T0603104 RST CHIPR 100KOHM +-5% 1/10W
R717 061T0603104 RST CHIPR 100KOHM +-5% 1/10W
R417 061T0603105 RST CHIPR 1MOHM +-5% 1/10W
R538 061T0603105 RST CHIPR 1MOHM +-5% 1/10W
R542 061T0603105 RST CHIPR 1MOHM +-5% 1/10W
R724 061T0603121 RST CHIPR 120 OHM +-5% 1/10W

52

42’’ Flat Wide Monitor AOC H428Pw

R672 061T0603123 RST CHIPR 12 KOHM +-5% 1/10W
R602 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R603 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R605 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R606 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R608 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R610 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R613 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R614 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R619 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R620 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
R506 061T0603183 RST CHIPR 18 KOHM +-5% 1/10W
R196 061T0603183 RST CHIPR 18 KOHM +-5% 1/10W
R171 061T0603201 RST CHIPR 200 OHM +-5% 1/10W
R170 061T0603201 RST CHIPR 200 OHM +-5% 1/10W
R669 061T0603202 RST CHIPR 2 KOHM +-5% 1/10W
R510 061T0603203 CHIPR 20K OHM+-5% 1/10W
R502 061T0603203 CHIPR 20K OHM+-5% 1/10W
R532 061T0603220 CHIP 22OHM 1/10W
R531 061T0603220 CHIP 22OHM 1/10W
R452 061T0603220 CHIP 22OHM 1/10W
R451 061T0603220 CHIP 22OHM 1/10W
R432 061T0603220 CHIP 22OHM 1/10W
R410 061T0603220 CHIP 22OHM 1/10W
R409 061T0603220 CHIP 22OHM 1/10W
R408 061T0603220 CHIP 22OHM 1/10W
R792 061T0603220 CHIP 22OHM 1/10W
R791 061T0603220 CHIP 22OHM 1/10W
R790 061T0603220 CHIP 22OHM 1/10W
R789 061T0603220 CHIP 22OHM 1/10W
R162 061T0603220 CHIP 22OHM 1/10W
R401 061T0603220 CHIP 22OHM 1/10W
R402 061T0603220 CHIP 22OHM 1/10W
R403 061T0603220 CHIP 22OHM 1/10W
R411 061T0603221 CHIP 220OHM 1/16W
R106 061T0603222 CHIP 2.2K OHM 1/16W
R107 061T0603222 CHIP 2.2K OHM 1/16W
R117 061T0603222 CHIP 2.2K OHM 1/16W
R648 061T0603222 CHIP 2.2K OHM 1/16W
R667 061T0603222 CHIP 2.2K OHM 1/16W
R784 061T0603223 CHIP 22KOHM 1/16W
R722 061T0603223 CHIP 22KOHM 1/16W
R718 061T0603223 CHIP 22KOHM 1/16W
R714 061T0603223 CHIP 22KOHM 1/16W
R422 061T0603272 CHIP 2.7KOHM 1/16W
R419 061T0603272 CHIP 2.7KOHM 1/16W
R434 061T0603301 RST CHIPR 300OHM +-5% 1/10W
R436 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R446 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R453 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R454 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W

53

42’’ Flat Wide Monitor AOC H428Pw

R455 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R456 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R457 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R458 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R459 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R681 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R719 061T0603332 RST CHIPR 3.3 KOHM +-5% 1/10W
R114 061T0603333 RST CHIPR 33 KOHM +-5% 1/10W
R601 061T0603339 F RST CHIPR 3.3 OHM +-5% 1/10W FENGHUA
R659 061T0603339 F RST CHIPR 3.3 OHM +-5% 1/10W FENGHUA
R551 061T0603363 RST CHIP 36K 1/10W 5%
R552 061T0603363 RST CHIP 36K 1/10W 5%
R627 061T0603392 CHIP 3.9KOHM 1/16W
R635 061T0603392 CHIP 3.9KOHM 1/16W
R636 061T0603392 CHIP 3.9KOHM 1/16W
R640 061T0603392 CHIP 3.9KOHM 1/16W
R512 061T0603472 CHIP 4.7KOHM 1/16W
R513 061T0603472 CHIP 4.7KOHM 1/16W
R514 061T0603472 CHIP 4.7KOHM 1/16W
R553 061T0603472 CHIP 4.7KOHM 1/16W
R554 061T0603472 CHIP 4.7KOHM 1/16W
R555 061T0603472 CHIP 4.7KOHM 1/16W
R628 061T0603472 CHIP 4.7KOHM 1/16W
R637 061T0603472 CHIP 4.7KOHM 1/16W
R670 061T0603472 CHIP 4.7KOHM 1/16W
R699 061T0603472 CHIP 4.7KOHM 1/16W
R443 061T0603472 CHIP 4.7KOHM 1/16W
R442 061T0603472 CHIP 4.7KOHM 1/16W
R426 061T0603472 CHIP 4.7KOHM 1/16W
R415 061T0603472 CHIP 4.7KOHM 1/16W
R195 061T0603472 CHIP 4.7KOHM 1/16W
R194 061T0603472 CHIP 4.7KOHM 1/16W
R187 061T0603472 CHIP 4.7KOHM 1/16W
R185 061T0603472 CHIP 4.7KOHM 1/16W
R507 061T0603472 CHIP 4.7KOHM 1/16W
R447 061T0603472 CHIP 4.7KOHM 1/16W
R445 061T0603472 CHIP 4.7KOHM 1/16W
R444 061T0603472 CHIP 4.7KOHM 1/16W
R508 061T0603472 CHIP 4.7KOHM 1/16W
R716 061T0603473 CHIP 47KOHM 1/16W
R713 061T0603473 CHIP 47KOHM 1/16W
R709 061T0603473 CHIP 47KOHM 1/16W
R705 061T0603473 CHIP 47KOHM 1/16W
R679 061T0603473 CHIP 47KOHM 1/16W
R675 061T0603473 CHIP 47KOHM 1/16W
R673 061T0603473 CHIP 47KOHM 1/16W
R639 061T0603473 CHIP 47KOHM 1/16W
R631 061T0603473 CHIP 47KOHM 1/16W
R188 061T0603473 CHIP 47KOHM 1/16W
R186 061T0603473 CHIP 47KOHM 1/16W
R184 061T0603473 CHIP 47KOHM 1/16W

54

42’’ Flat Wide Monitor AOC H428Pw

R183 061T0603473 CHIP 47KOHM 1/16W
R112 061T0603473 CHIP 47KOHM 1/16W
R616 061T0603474 RST CHIPR 470 KOHM +-5% 1/10W
R520 061T0603500 0F RST CHIPR 500 OHM +-1% 1/10W
R103 061T0603511 RST CHIPR 510 OHM +-5% 1/10W
R104 061T0603511 RST CHIPR 510 OHM +-5% 1/10W
R116 061T0603560 9F RST CHIPR 56 OHM +-1% 1/10W
R696 061T0603561 RST CHIPR 560 OHM +-5% 1/10W
R181 061T0603681 RST CHIPR 680 OHM +-5% 1/10W
R182 061T0603681 RST CHIPR 680 OHM +-5% 1/10W
R701 061T0603681 RST CHIPR 680 OHM +-5% 1/10W
R630 061T0603682 RST CHIPR 6.8KOHM +-5% 1/10W
R625 061T0603682 RST CHIPR 6.8KOHM +-5% 1/10W
R190 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R189 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R141 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R139 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R138 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R137 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R136 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R133 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R132 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R119 061T0603750 RST CHIPR 75 OHM +-5% 1/10W
R109 061T0603750 9F CHIP 75OHM 1/10W 1%
R110 061T0603750 9F CHIP 75OHM 1/10W 1%
R111 061T0603750 9F CHIP 75OHM 1/10W 1%
R682 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R683 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R684 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R685 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R686 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R687 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R688 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R692 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R693 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R698 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R793 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R794 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R795 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R796 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R798 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R799 061T0805000 RST CHIPR 0 OHM +-5% 1/8W
R115 061T0805470 RST CHIPR 47 OHM +-5% 1/8W
R210 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R211 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R212 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R213 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R214 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R215 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R216 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R219 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA

55

42’’ Flat Wide Monitor AOC H428Pw

R220 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R221 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R222 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R223 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R225 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R226 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R228 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R229 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R230 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R231 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R797 061T1206000 F RST CHIPR 0 OHM +-5% 1/4W FENGHUA
R643 061T1206220 RST CHIPR 22 OHM +-5% 1/4W
R661 061T1206220 RST CHIPR 22 OHM +-5% 1/4W
R725 061T1206620 0F RST CHIPR 620 OHM +-1% 1/4W
R665 061T1206629 RST CHIP 6R2 1/4W 5%
R662 061T1206629 RST CHIP 6R2 1/4W 5%
R649 061T1206629 RST CHIP 6R2 1/4W 5%
R644 061T1206629 RST CHIP 6R2 1/4W 5%
C195 065T0603100 31 GP CHIP 10PF 50V NPO
C196 065T0603100 31 GP CHIP 10PF 50V NPO
C701 065T0603101 31 CHIP 100PF 50V NPO
C117 065T0603102 31 CHIP 1000PF 50V NPO
C118 065T0603102 31 CHIP 1000PF 50V NPO
C601 065T0603102 32 CHIP 1000PF 50V X7R

C6106 065T0603102 32 CHIP 1000PF 50V X7R

C693 065T0603102 32 CHIP 1000PF 50V X7R
C690 065T0603102 32 CHIP 1000PF 50V X7R
C688 065T0603102 32 CHIP 1000PF 50V X7R
C678 065T0603102 32 CHIP 1000PF 50V X7R
C673 065T0603102 32 CHIP 1000PF 50V X7R
C664 065T0603102 32 CHIP 1000PF 50V X7R
C663 065T0603102 32 CHIP 1000PF 50V X7R

C6111 065T0603102 32 CHIP 1000PF 50V X7R
C6108 065T0603102 32 CHIP 1000PF 50V X7R

C666 065T0603103 32 CHIP 0.01UF 50V X7R
C629 065T0603103 32 CHIP 0.01UF 50V X7R
C628 065T0603103 32 CHIP 0.01UF 50V X7R
C625 065T0603103 32 CHIP 0.01UF 50V X7R
C624 065T0603103 32 CHIP 0.01UF 50V X7R
C613 065T0603104 12 MLCC 0603 0.1UF K 16V X7R

C6122 065T0603104 12 MLCC 0603 0.1UF K 16V X7R

C612 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C612 065T0603104 12 MLCC 0603 0.1UF K 16V X7R

C6119 065T0603104 12 MLCC 0603 0.1UF K 16V X7R

C697 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C668 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C657 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C656 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C655 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C646 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C644 065T0603104 12 MLCC 0603 0.1UF K 16V X7R

56

42’’ Flat Wide Monitor AOC H428Pw

C618 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C618 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C617 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C617 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C616 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C616 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C615 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C615 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C614 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C611 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C611 065T0603104 12 MLCC 0603 0.1UF K 16V X7R

C6104 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C6103 065T0603104 12 MLCC 0603 0.1UF K 16V X7R

C610 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C610 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C609 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C609 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C608 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C608 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C607 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C607 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C606 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C613 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C614 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C696 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C606 065T0603104 12 MLCC 0603 0.1UF K 16V X7R
C458 065T0603104 32 CHIP 0.1UF 50V X7R
C459 065T0603104 32 CHIP 0.1UF 50V X7R
C460 065T0603104 32 CHIP 0.1UF 50V X7R
C462 065T0603104 32 CHIP 0.1UF 50V X7R
C463 065T0603104 32 CHIP 0.1UF 50V X7R
C465 065T0603104 32 CHIP 0.1UF 50V X7R
C467 065T0603104 32 CHIP 0.1UF 50V X7R
C469 065T0603104 32 CHIP 0.1UF 50V X7R
C471 065T0603104 32 CHIP 0.1UF 50V X7R
C506 065T0603104 32 CHIP 0.1UF 50V X7R
C507 065T0603104 32 CHIP 0.1UF 50V X7R
C508 065T0603104 32 CHIP 0.1UF 50V X7R
C509 065T0603104 32 CHIP 0.1UF 50V X7R
C510 065T0603104 32 CHIP 0.1UF 50V X7R
C511 065T0603104 32 CHIP 0.1UF 50V X7R
C512 065T0603104 32 CHIP 0.1UF 50V X7R
C513 065T0603104 32 CHIP 0.1UF 50V X7R
C518 065T0603104 32 CHIP 0.1UF 50V X7R
C430 065T0603104 32 CHIP 0.1UF 50V X7R
C431 065T0603104 32 CHIP 0.1UF 50V X7R
C432 065T0603104 32 CHIP 0.1UF 50V X7R
C434 065T0603104 32 CHIP 0.1UF 50V X7R
C435 065T0603104 32 CHIP 0.1UF 50V X7R
C436 065T0603104 32 CHIP 0.1UF 50V X7R
C437 065T0603104 32 CHIP 0.1UF 50V X7R

57

42’’ Flat Wide Monitor AOC H428Pw

C438 065T0603104 32 CHIP 0.1UF 50V X7R
C439 065T0603104 32 CHIP 0.1UF 50V X7R
C442 065T0603104 32 CHIP 0.1UF 50V X7R
C443 065T0603104 32 CHIP 0.1UF 50V X7R
C444 065T0603104 32 CHIP 0.1UF 50V X7R
C446 065T0603104 32 CHIP 0.1UF 50V X7R
C447 065T0603104 32 CHIP 0.1UF 50V X7R
C448 065T0603104 32 CHIP 0.1UF 50V X7R
C451 065T0603104 32 CHIP 0.1UF 50V X7R
C452 065T0603104 32 CHIP 0.1UF 50V X7R
C454 065T0603104 32 CHIP 0.1UF 50V X7R

C6101 065T0603104 32 CHIP 0.1UF 50V X7R

C703 065T0603104 32 CHIP 0.1UF 50V X7R
C704 065T0603104 32 CHIP 0.1UF 50V X7R
C705 065T0603104 32 CHIP 0.1UF 50V X7R
C706 065T0603104 32 CHIP 0.1UF 50V X7R
C707 065T0603104 32 CHIP 0.1UF 50V X7R
C709 065T0603104 32 CHIP 0.1UF 50V X7R
C712 065T0603104 32 CHIP 0.1UF 50V X7R
C714 065T0603104 32 CHIP 0.1UF 50V X7R
C717 065T0603104 32 CHIP 0.1UF 50V X7R
C719 065T0603104 32 CHIP 0.1UF 50V X7R
C720 065T0603104 32 CHIP 0.1UF 50V X7R
C722 065T0603104 32 CHIP 0.1UF 50V X7R
C725 065T0603104 32 CHIP 0.1UF 50V X7R
C727 065T0603104 32 CHIP 0.1UF 50V X7R
C729 065T0603104 32 CHIP 0.1UF 50V X7R
C730 065T0603104 32 CHIP 0.1UF 50V X7R
C766 065T0603104 32 CHIP 0.1UF 50V X7R
C775 065T0603104 32 CHIP 0.1UF 50V X7R

C6102 065T0603104 32 CHIP 0.1UF 50V X7R
C6105 065T0603104 32 CHIP 0.1UF 50V X7R
C6109 065T0603104 32 CHIP 0.1UF 50V X7R
C6112 065T0603104 32 CHIP 0.1UF 50V X7R
C6113 065T0603104 32 CHIP 0.1UF 50V X7R
C6114 065T0603104 32 CHIP 0.1UF 50V X7R
C6117 065T0603104 32 CHIP 0.1UF 50V X7R

C622 065T0603104 32 CHIP 0.1UF 50V X7R
C640 065T0603104 32 CHIP 0.1UF 50V X7R
C641 065T0603104 32 CHIP 0.1UF 50V X7R
C671 065T0603104 32 CHIP 0.1UF 50V X7R
C683 065T0603104 32 CHIP 0.1UF 50V X7R
C684 065T0603104 32 CHIP 0.1UF 50V X7R
C687 065T0603104 32 CHIP 0.1UF 50V X7R
C691 065T0603104 32 CHIP 0.1UF 50V X7R
C694 065T0603104 32 CHIP 0.1UF 50V X7R
C695 065T0603104 32 CHIP 0.1UF 50V X7R
C702 065T0603104 32 CHIP 0.1UF 50V X7R
C401 065T0603104 32 CHIP 0.1UF 50V X7R
C186 065T0603104 32 CHIP 0.1UF 50V X7R
C185 065T0603104 32 CHIP 0.1UF 50V X7R

58

42’’ Flat Wide Monitor AOC H428Pw

C179 065T0603104 32 CHIP 0.1UF 50V X7R
C178 065T0603104 32 CHIP 0.1UF 50V X7R
C177 065T0603104 32 CHIP 0.1UF 50V X7R
C176 065T0603104 32 CHIP 0.1UF 50V X7R
C168 065T0603104 32 CHIP 0.1UF 50V X7R
C165 065T0603104 32 CHIP 0.1UF 50V X7R
C164 065T0603104 32 CHIP 0.1UF 50V X7R
C163 065T0603104 32 CHIP 0.1UF 50V X7R
C162 065T0603104 32 CHIP 0.1UF 50V X7R
C161 065T0603104 32 CHIP 0.1UF 50V X7R
C160 065T0603104 32 CHIP 0.1UF 50V X7R
C124 065T0603104 32 CHIP 0.1UF 50V X7R
C122 065T0603104 32 CHIP 0.1UF 50V X7R
C119 065T0603104 32 CHIP 0.1UF 50V X7R
C116 065T0603104 32 CHIP 0.1UF 50V X7R
C429 065T0603104 32 CHIP 0.1UF 50V X7R
C427 065T0603104 32 CHIP 0.1UF 50V X7R
C426 065T0603104 32 CHIP 0.1UF 50V X7R
C425 065T0603104 32 CHIP 0.1UF 50V X7R
C424 065T0603104 32 CHIP 0.1UF 50V X7R
C423 065T0603104 32 CHIP 0.1UF 50V X7R
C422 065T0603104 32 CHIP 0.1UF 50V X7R
C421 065T0603104 32 CHIP 0.1UF 50V X7R
C420 065T0603104 32 CHIP 0.1UF 50V X7R
C402 065T0603104 32 CHIP 0.1UF 50V X7R
C403 065T0603104 32 CHIP 0.1UF 50V X7R
C405 065T0603104 32 CHIP 0.1UF 50V X7R
C406 065T0603104 32 CHIP 0.1UF 50V X7R
C407 065T0603104 32 CHIP 0.1UF 50V X7R
C408 065T0603104 32 CHIP 0.1UF 50V X7R
C409 065T0603104 32 CHIP 0.1UF 50V X7R
C411 065T0603104 32 CHIP 0.1UF 50V X7R
C413 065T0603104 32 CHIP 0.1UF 50V X7R
C623 065T0603105 17 CHIP 1UF 16V Y5V
C619 065T0603105 17 CHIP 1UF 16V Y5V
C619 065T0603105 17 CHIP 1UF 16V Y5V

C6121 065T0603105 25 CHIP 1UF 25V X5R
C6118 065T0603105 25 CHIP 1UF 25V X5R

C515 065T0603150 31 CHIP 15PF 50V NPO
C516 065T0603150 31 CHIP 15PF 50V NPO
C653 065T0603220 31 CHIP 22PF 50V NPO
C167 065T0603220 32 CHIP 22PF 50V X7R
C651 065T0603221 31 CHIP 220PF 50V NPO
C643 065T0603221 31 CHIP 220PF 50V NPO
C642 065T0603221 31 CHIP 220PF 50V NPO
C635 065T0603221 31 CHIP 220PF 50V NPO
C634 065T0603221 31 CHIP 220PF 50V NPO
C631 065T0603221 31 CHIP 220PF 50V NPO
C630 065T0603221 31 CHIP 220PF 50V NPO
C144 065T0603221 31 CHIP 220PF 50V NPO
C143 065T0603221 31 CHIP 220PF 50V NPO

59

42’’ Flat Wide Monitor AOC H428Pw

C142 065T0603221 31 CHIP 220PF 50V NPO
C141 065T0603221 31 CHIP 220PF 50V NPO
C135 065T0603221 31 CHIP 220PF 50V NPO
C652 065T0603221 31 CHIP 220PF 50V NPO
C661 065T0603221 31 CHIP 220PF 50V NPO
C662 065T0603221 31 CHIP 220PF 50V NPO
C134 065T0603221 31 CHIP 220PF 50V NPO
C669 065T0603223 32 CHIP 0.022UF 50V X7R 0603
C667 065T0603224 22 CHIP CAP 0.22UF 25V X7
C522 065T0603224 32 MLCC 0603 0.22UF K 50V X7R
C504 065T0603224 32 MLCC 0603 0.22UF K 50V X7R
C502 065T0603224 32 MLCC 0603 0.22UF K 50V X7R
C198 065T0603224 32 MLCC 0603 0.22UF K 50V X7R
C521 065T0603225 17 CHIP 2.2UF 16V Y5V
C658 065T0603225 17 CHIP 2.2UF 16V Y5V
C626 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C627 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C632 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C633 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C636 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C639 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C649 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C650 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C659 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C660 065T0603225A5K Y CAP CHIP 0603 2.2UF K 10V X5R
C648 065T0603300 31 CHIP 0603 30PF J 50V NPO
C520 065T0603330 31 CHIP 33PF 50V NPO
C519 065T0603330 31 CHIP 33PF 50V NPO
C416 065T0603330 31 CHIP 33PF 50V NPO
C415 065T0603330 31 CHIP 33PF 50V NPO
C692 065T0603331 32 CHIP 330PF 50V X7R

C6110 065T0603331 32 CHIP 330PF 50V X7R

C132 065T0603471 31 CHIP 470PF 50V NPO
C133 065T0603471 31 CHIP 470PF 50V NPO
C155 065T0603472 32 CHIP 4700PF 50V X7R
C699 065T060347232K Y CAP CHIP 0603 4700PF K 50V X7R
C156 065T0603473 32 CHIP 0.047UF 50V X7R
C154 065T0603473 32 CHIP 0.047UF 50V X7R
C153 065T0603473 32 CHIP 0.047UF 50V X7R
C152 065T0603473 32 CHIP 0.047UF 50V X7R
C151 065T0603473 32 CHIP 0.047UF 50V X7R
C150 065T0603473 32 CHIP 0.047UF 50V X7R
C149 065T0603473 32 CHIP 0.047UF 50V X7R
C148 065T0603473 32 CHIP 0.047UF 50V X7R
C147 065T0603473 32 CHIP 0.047UF 50V X7R
C146 065T0603473 32 CHIP 0.047UF 50V X7R
C145 065T0603473 32 CHIP 0.047UF 50V X7R
C157 065T0603473 32 CHIP 0.047UF 50V X7R
C158 065T0603473 32 CHIP 0.047UF 50V X7R
C670 065T0603560 31 CHIP 56PF 50V NPO
C192 065T0603569 31 CHIP 5.6PF 50V NPO

60

42’’ Flat Wide Monitor AOC H428Pw

C193 065T0603569 31 CHIP 5.6PF 50V NPO
C194 065T0603569 31 CHIP 5.6PF 50V NPO
C188 065T0603680 31 CHIP 68PF 50V NPO
C187 065T0603680 31 CHIP 68PF 50V NPO
C140 065T0603680 31 CHIP 68PF 50V NPO
C139 065T0603680 31 CHIP 68PF 50V NPO
C138 065T0603680 31 CHIP 68PF 50V NPO
C137 065T0603680 31 CHIP 68PF 50V NPO
C136 065T0603680 31 CHIP 68PF 50V NPO
C128 065T0603680 31 CHIP 68PF 50V NPO
C127 065T0603680 31 CHIP 68PF 50V NPO
C129 065T0603680 32 CHIP 68PF 50V X7R

C6100 065T0603681 21 CHIP 680PF 25V NPO

C721 065T0603683 32 CHIP 0.068UF 50V X7R
C685 065T0805105 37 CHIP 1UF 50V Y5V
C686 065T0805105 37 CHIP 1UF 50V Y5V
C672 065T0805106 15 CHIP 10UF 16V X5R 0805
C681 065T0805106 15 CHIP 10UF 16V X5R 0805
C414 065T0805106 A5 CHIP 10UF 10V X5R 0805
C410 065T0805106 A5 CHIP 10UF 10V X5R 0805
C404 065T0805106 A5 CHIP 10UF 10V X5R 0805
C418 065T0805474 22 CHIP 0.47UF 25V X7R
C680 065T0805475 15 CHIP 4.7UF 16V X5R
C679 065T0805475 15 CHIP 4.7UF 16V X5R
C676 065T0805475 15 CHIP 4.7UF 16V X5R
C675 065T0805475 15 CHIP 4.7UF 16V X5R
C517 065T0805475 15 CHIP 4.7UF 16V X5R
C182 065T0805475 15 CHIP 4.7UF 16V X5R
C181 065T0805475 15 CHIP 4.7UF 16V X5R
C131 065T0805475 15 CHIP 4.7UF 16V X5R
C130 065T0805475 15 CHIP 4.7UF 16V X5R
C647 065T1206106 17 CHIP 10UF 16V Y5V
C645 065T1206106 17 CHIP 10UF 16V Y5V
C715 065T1206226 A5 CHIP 22UF 10V X5R
C472 065T1206226 A5 CHIP 22UF 10V X5R
C470 065T1206226 A5 CHIP 22UF 10V X5R
C468 065T1206226 A5 CHIP 22UF 10V X5R
C466 065T1206226 A5 CHIP 22UF 10V X5R
C464 065T1206226 A5 CHIP 22UF 10V X5R
C461 065T1206226 A5 CHIP 22UF 10V X5R
C453 065T1206226 A5 CHIP 22UF 10V X5R
C445 065T1206226 A5 CHIP 22UF 10V X5R
C441 065T1206226 A5 CHIP 22UF 10V X5R
C440 065T1206226 A5 CHIP 22UF 10V X5R
C433 065T1206226 A5 CHIP 22UF 10V X5R
C428 065T1206226 A5 CHIP 22UF 10V X5R

CP601 065T600M471 8T CHIP ARRAY 470PF 8P

U509 070GHDCP500HDC HDCP CODE

LP701 071T 56A301 8K CHIP BEAD ARRAY 300 OHM

L101 071T 56F320 K CHIP BEAD 32 OHM 0805
L103 071T 56F320 K CHIP BEAD 32 OHM 0805

61

42’’ Flat Wide Monitor AOC H428Pw

L102 071T 56F320 K CHIP BEAD 32 OHM 0805
L701 071T 56G151 B BEAD 0805 150 OHM
L105 071T 56G151 B BEAD 0805 150 OHM
L104 071T 56G151 B BEAD 0805 150 OHM
L726 071T 56G301 EA CHIP BEAD 300 OHM 0805
L725 071T 56G301 EA CHIP BEAD 300 OHM 0805
L724 071T 56G301 EA CHIP BEAD 300 OHM 0805
L712 071T 56G301 EA CHIP BEAD 300 OHM 0805
L509 071T 56G301 EA CHIP BEAD 300 OHM 0805
L418 071T 56G301 EA CHIP BEAD 300 OHM 0805
L417 071T 56G301 EA CHIP BEAD 300 OHM 0805
L415 071T 56G301 EA CHIP BEAD 300 OHM 0805
L414 071T 56G301 EA CHIP BEAD 300 OHM 0805
L413 071T 56G301 EA CHIP BEAD 300 OHM 0805
L412 071T 56G301 EA CHIP BEAD 300 OHM 0805
L411 071T 56G301 EA CHIP BEAD 300 OHM 0805
L410 071T 56G301 EA CHIP BEAD 300 OHM 0805
L408 071T 56G301 EA CHIP BEAD 300 OHM 0805
L407 071T 56G301 EA CHIP BEAD 300 OHM 0805

FB609 071T 56G301 EA CHIP BEAD 300 OHM 0805

L201 071T 56G301 EA CHIP BEAD 300 OHM 0805
L403 071T 56G301 EA CHIP BEAD 300 OHM 0805
L404 071T 56G301 EA CHIP BEAD 300 OHM 0805
L405 071T 56G301 EA CHIP BEAD 300 OHM 0805
L406 071T 56G301 EA CHIP BEAD 300 OHM 0805
L127 071T 56U600 CHIP BEAD 60 OHM 0805

L128 071T 56U600 CHIP BEAD 60 OHM 0805
FB610 071T 56Z601 CHIP BEAD 600 OHM
FB611 071T 56Z601 CHIP BEAD 600 OHM

L702 071T 56Z601 CHIP BEAD 600 OHM

L703 071T 56Z601 CHIP BEAD 600 OHM
LP601 071T 57G601TSB IND CHIP BEAD 1206 600OHM TECSTAR

L118 071T 59B121 K CHIP BEAD

L119 071T 59B121 K CHIP BEAD

L125 071T 59B121 K CHIP BEAD

L126 071T 59B121 K CHIP BEAD

L409 071T 59B121 K CHIP BEAD

L510 071T 59B121 K CHIP BEAD

L601 071T 59B121 K CHIP BEAD

L117 071T 59B121 K CHIP BEAD

L116 071T 59B121 K CHIP BEAD

L115 071T 59B121 K CHIP BEAD

L110 071T 59B121 K CHIP BEAD

L109 071T 59B121 K CHIP BEAD

L108 071T 59B121 K CHIP BEAD

L107 071T 59B121 K CHIP BEAD

L106 071T 59B121 K CHIP BEAD

L124 071T 59B601 MA CHIP BEAD

L123 071T 59B601 MA CHIP BEAD

L121 071T 59B601 MA CHIP BEAD

L120 071T 59B601 MA CHIP BEAD

62

42’’ Flat Wide Monitor AOC H428Pw

L114 071T 59B601 MA CHIP BEAD

L113 071T 59B601 MA CHIP BEAD

L112 071T 59B601 MA CHIP BEAD

L111 071T 59B601 MA CHIP BEAD
FB601 071T2012221 2Y CHIP BEAD 0805 220OHM +-25% 2A
FB602 071T2012221 2Y CHIP BEAD 0805 220OHM +-25% 2A
FB603 071T2012221 2Y CHIP BEAD 0805 220OHM +-25% 2A
FB604 071T2012221 2Y CHIP BEAD 0805 220OHM +-25% 2A
FB606 071T2012221 2Y CHIP BEAD 0805 220OHM +-25% 2A
FB607 071T2012221 2Y CHIP BEAD 0805 220OHM +-25% 2A
FB608 071T2012221 2Y CHIP BEAD 0805 220OHM +-25% 2A

L602 073T 62181 180UH +-10%

L603 073T 62181 180UH +-10%

FB613 073T 6310010M

L508 073T253S 6 T

L507 073T253S 6 T

L506 073T253S 6 T

L505 073T253S 6 T

L504 073T253S 6 T

L503 073T253S 6 T

L502 073T253S 6 T

L501 073T253S 6 T

CN501 088T 340 21 VN HDMI HEADER 21P V/A
CN502 088T 340 21 VN HDMI HEADER 21P V/A

D105 093T 60230 BAT54C BY MCC
D501 093T 60230 BAT54C BY MCC

D502 093T 60230 BAT54C BY MCC
ZD111 093T 64 37 N V-PORT-0603-100K V05
ZD110 093T 64 37 N V-PORT-0603-100K V05
ZD109 093T 64 37 N V-PORT-0603-100K V05
ZD108 093T 64 37 N V-PORT-0603-100K V05
ZD107 093T 64 37 N V-PORT-0603-100K V05
ZD106 093T 64 37 N V-PORT-0603-100K V05
ZD105 093T 64 37 N V-PORT-0603-100K V05
ZD104 093T 64 37 N V-PORT-0603-100K V05
ZD103 093T 64 37 N V-PORT-0603-100K V05
ZD102 093T 64 37 N V-PORT-0603-100K V05
ZD101 093T 64 37 N V-PORT-0603-100K V05
ZD112 093T 64 37 N V-PORT-0603-100K V05
ZD603 093T 64 37 N V-PORT-0603-100K V05
ZD602 093T 64 37 N V-PORT-0603-100K V05
ZD601 093T 64 37 N V-PORT-0603-100K V05
ZD125 093T 64 37 N V-PORT-0603-100K V05
ZD124 093T 64 37 N V-PORT-0603-100K V05
ZD123 093T 64 37 N V-PORT-0603-100K V05

CHIP INDUCTOR 0603 10UH+-10%
MICROGATE
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00
SMD CHOKE 90 OHM
ACM2012D-900-2P-T00

63

42’’ Flat Wide Monitor AOC H428Pw

ZD122 093T 64 37 N V-PORT-0603-100K V05
ZD121 093T 64 37 N V-PORT-0603-100K V05
ZD120 093T 64 37 N V-PORT-0603-100K V05
ZD119 093T 64 37 N V-PORT-0603-100K V05
ZD118 093T 64 37 N V-PORT-0603-100K V05
ZD117 093T 64 37 N V-PORT-0603-100K V05
ZD116 093T 64 37 N V-PORT-0603-100K V05
ZD115 093T 64 37 N V-PORT-0603-100K V05
ZD114 093T 64 37 N V-PORT-0603-100K V05
ZD113 093T 64 37 N V-PORT-0603-100K V05

D403 093T 6432V LL4148-GSO8 SMD BY VISHA

D405 093T 6432V LL4148-GSO8 SMD BY VISHA

D406 093T 6432V LL4148-GSO8 SMD BY VISHA

D603 093T 6432V LL4148-GSO8 SMD BY VISHA

D103 093T 6433S DIODE BAV99 SEMTECH

D104 093T 6433S DIODE BAV99 SEMTECH

D106 093T 6433S DIODE BAV99 SEMTECH
ZD126 093T 39S 10 T RLZ6.8B LLDS
ZD127 093T 39S 10 T RLZ6.8B LLDS
ZD604 093T 39S 98 T DIODE RLZ3.3B LL-34 ROHM

D401 093T 60S 34 T DIODE SCS140V 1A/40V SC-76

D602 093T 60S 34 T DIODE SCS140V 1A/40V SC-76

D604 093T 60S 34 T DIODE SCS140V 1A/40V SC-76

715T2968 1 MAIN PCB 193X225X1.6MM F-4 1OZ D/S
D102 093T 60S 34 T DIODE SCS140V 1A/40V SC-76
C417 065T0603104 32 CHIP 0.1UF 50V X7R

Q85T0076101 SHIELDING
U606 Q90T6068 2 GP HEAT SINK

A15J0287201 BKT-IO-CHINA

0Q1T 930 8 47 CR3 SCREW

Q40T000262431A SIDE LABEL

IRPF8AA9 IR BOARD T2877-D-2-X-1-080711

U1 056T 627 7 FM-6038TM2-5AN

CN1 033T8032 4F HR CONNECTOR

Q1 057T 417 6 PMBS3906/PHILIPS-SMT
R1 061T0603101 RST CHIPR 100 OHM +-5% 1/10W
R5 061T0603102 RST CHIPR 1KOHM +-5% 1/10W
R3 061T0603103 RST CHIPR 10KOHM +-5% 1/10W
R2 061T0805152 RST CHIPR 1.5 KOHM +-5% 1/8W
R4 061T0805182 RST CHIPR 1.8 KOHM +-5% 1/8W
C3 065T0603101 31 CHIP 100PF 50V NPO
C4 065T0603104 32 CHIP 0.1UF 50V X7R
C5 065T0603104 32 CHIP 0.1UF 50V X7R
C2 065T0603104 32 CHIP 0.1UF 50V X7R

C1 065T0805475 A5 CHIP 4.7UF 10V X5R
FB1 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608
FB2 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608
FB3 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608

LED1 081T 14 24 EL CHIP LED BLUE/DARK RED

D1 093T 6432V LL4148-GSO8 SMD BY VISHA

D2 093T 6432V LL4148-GSO8 SMD BY VISHA

64

42’’ Flat Wide Monitor AOC H428Pw

715T2877 1 2 IR PCB 30X24X1.6MM FR-4 D/S
KEPF8AA3 KEPC BOARD T2876-1-X-X-1-080309

CN1 033T3802 3H WAFER 3P RIGHT ANGLE
SW3 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW2 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW1 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW7 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW6 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW5 077T 600 1GCJ TACT SWITCH TSPB-2 -NP
SW4 077T 600 1GCJ TACT SWITCH TSPB-2 -NP

R5 061T0603000 RST CHIPR 0 OHM +-5% 1/10W
R4 061T0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R2 061T0603180 1F RST CHIPR 1.8 KOHM +-1% 1/10W
R8 061T0603220 2F RST CHIPR 22 KOHM +-1% 1/10W
R6 061T0603330 1F RST CHIPR 3.3 KOHM +-1% 1/10W
R3 061T0603390 0F RST CHIPR 390 OHM +-1% 1/10W
R7 061T0603680 1F RST CHIPR 6.8 KOHM +-1% 1/10W
R1 061T08052201FF RST CHIPR 2.2KOHM +-1% 1/8W FENGHUA
C2 065T0603104 32 CHIP 0.1UF 50V X7R

L1 071T 56U601 MA CHIP BEAD 0805 600 OHM 1000MA
L2 071T 56U601 MA CHIP BEAD 0805 600 OHM 1000MA

D1 093T 6433P BAV99

715T2876 1 KEY PCB 111X15X1.6MM FR-1 S/S
Q36T 600 35 17 GP NONWOVEN FABRIC
Q36T 600 46 1 NONWOVEN FABRIC
Q40T 42061522B RATING LABEL
Q40T000267362A IO LABEL
Q44T3231 21 11 EVA WASHER
Q44T3231 21 30 EVA WASHER
Q44T3231 21 45 EVA WASHER
Q44TN005 5 1A U TYPE SHEET FOR BASE
Q44TN005101 EPS CUSHION
Q44TN005201 EPS CUSHION
Q44TN005301 EPS CUSHION
Q44TN005401 EPS CUSHION
Q44TN00561513A B 42" TV BOTTOM CARTON
Q44TN00561513A T 42" TV TOP CARTON
Q44TN005BLO001 PAPER SHEET
Q44TN005BLO002 PAPER SHEET
Q45G 77 5 PE PACKING
Q45T 99609 60 EPE COVER FOR BASE
Q45T 99609 71 EPE COVER FOR MONITOR
Q50T 500523 CABLE TIE
Q52T 1213607 ALUMINUM FOIL TAPE
0M1T6022500 SCREW
Q41T4201615 9A MANUAL
Q41T780B61524A WARRANTY CARD
Q45T 76 28NV2 R PE BAG FOR CLAMP
040T 58162435A LABEL
Q26T 800504 2 BARCODE

65

42’’ Flat Wide Monitor AOC H428Pw

66
