1
客户
机种名
销售地区
AOC 2217V
中国大陆
首次发布日期
TC82MPNYUWACHI
TC82MPNDUWA4HNE
: 8/2008
2
目录
1.安全与注意事项 -------------------------------------------------------------------------------------------------------- 03
2.技术规格 ----------------------------------------------------------------------------------------------------------------- 05
3.操作说明及工厂模式调整 -------------------------------------------------------------------------------------------- 08
4. ISP 升级流程 ----------------------------------------------------------------------------------------------------------- 12
5.故障处理流程 ----------------------------------------------------------------------------------------------------------- 16
6.电气方框图 -------------------------------------------------------------------------------------------------------------- 19
7. PCB 分布图 ------------------------------------------------------------------------------------------------------------ 20
8.线路图 -------------------------------------------------------------------------------------------------------------------- 26
9.爆炸图 -------------------------------------------------------------------------------------------------------------------- 35
10. BOM -------------------------------------------------------------------------------------------------------------------- 36
3
1.安全与注意事项
FCC 注意事项
FCC B 类无线电频率干扰声明 警告：（对于 FCC 认证的型号）
注意： 本设备已经通过测试，符合 FCC 规定第 15 部分有关 B 类数字设备的限制。这些限制可有效地
防止在居住区使用本设备时产生有害的干扰。本设备会产生、使用并且辐射无线电波，如果不按照说明来
安装和使用，则可能对无线电通信产生有害的干扰。但是，我们并不保证在某些特定位置安装本设备后不
会产生干扰。如果本设备的确对无线电或电视节目接收产生有害干扰（可通过打开和关闭本设备来确定是
否存在干扰），我们希望用户采取下列一项或几项措施来消除干扰：
1. 改变接收天线的方向或位置。
2. 增加本设备和接收器之间的距离。
3. 将本设备和接收器分别接到不同的电路电源插座。
4. 咨询经销商或专业的无线电 / 电视技术人员以寻求帮助。
注意事项：
1. 如果未经有关方面（负责是否符合标准）的明确许可而进行修改或改动，用户将被取消使用本设备的权
利。
2. 应使用屏蔽的接口电缆和交流电源线（如果有）以便符合辐射限制。
3. 制造商对于因未经授权修改本设备而导致的任何无线电和电视干扰不承担责任。解决此类干扰是用户的
责任。
WEEE 声明
欧盟的私人住宅用户对垃圾设备的处理
产品或其包装上的这个标记表示的是，该产品不得与您其他的家庭垃圾一起处理。相反，将您的垃圾设备
交给指定的收集点，使废弃电器设备得以回收，是您的责任。您在处理垃圾设备时将其分类收集与回收，
有助于保护天然资源，并在回收利用时，保护人体健康与环境。有关您可以将垃圾设备放在何处回收的更
多信息，请联系您所在城市的办公室，您购买产品的家庭垃圾处理服务处或商店。
预防措施
警告：如果不按本文档所述使用控件、进行调整或执行其它任何过程，可能导致电击、触电和 / 或机
械伤害。
请阅读这些预防措施，并遵照这些说明来连接和使用计算机监视器。
预防措施
4
不要使监视器靠近有水的地方，如浴缸、洗脸盆、厨房水池、洗衣盆、游泳池或潮湿的地下室等。
不要将监视器放置在不稳定的推车上、平台上或桌子上。如果监视器掉落，可能会造成人员伤害并
导致设备严重损坏。仅使用制造商推荐的或随监视器一起销售的推车或平台。如果将监视器挂在墙
上或架子上，应使用制造商认可的安装工具并按照工具说明进行操作。
机壳后部和底部的槽和开口用于通风目的。为确保监视器可靠运行而不会过热，切勿阻塞或覆盖这
些开口。不要将监视器放置在床、沙发、地毯或类似的表面上。不要将监视器放置在暖气片或热调
节器上面或附近位置。不要将监视器放置在书柜或橱柜中，除非通风良好。
监视器只应使用标签上注明的电源类型。如果您不了解家中的电源类型，请与经销商或当地电力公
司联系。
本监视器配备有一个三相接地插头，其中一个端头接地。为安全起见，该插头应插入接地的电源插
座中。如果三相插头不能插入您的插座，请找电工安装一个正确的插座，或使用适配器将设备安全
接地。不要改变接地插头的安全功能。
遇有雷雨天气或长时间不使用时，应拔掉设备的电源线。这样做可以防止因电压突变而损坏监视器。
不要使电源板或延长线过载。过载可能导致火灾或电击。
切勿将任何异物塞入监视器机壳的开槽内。否则会导致电路短路而引起火灾或电击。切勿使液体溅
落到监视器上。
不要自行维修监视器，打开或拆卸机盖时有高压或其它危险。请委托专业维修人员来进行所有维修
工作。
为确保正常运行，本监视器只应与 UL 列出的计算机一起使用，这些计算机的的插座经过正确配置
并且标记有 100 - 240V AC, Min. 5A 。
墙壁电源应安装在靠近设备的地方并且便于插拔电源线。
仅限使用列有 UL、CSA 授权标记之连接电源变压器(针对带外置电源适配器的产品)。
5
LCD 面板
市场型号
2217V
驱动系统
TFT 彩色 LCD
可视尺寸
558mm 对角
像素间距
0.282mm(H) x 0.282mm(V)
视频
R, G, B 模拟接口,DVI 接口
独立同步
行 /场 TTL
显示颜色
16.7M 色彩
点时钟
165 MHz
分辨率
水平扫描范围
30 kHz - 83 kHz
水平扫描尺寸（最大）
473.76mm
垂直扫描范围
56 Hz - 75 Hz
垂直扫描尺寸（最大）
296.1mm
预设的最佳分辨率
1680 x 1050 (60 Hz)
预设的最高分辨率
1680 x 1050 (60 Hz)
即插即用
VESA DDC2B/CI
输入连接器
D-Sub 15 针,DVI-D
输入视频信号
模拟： 0.7Vp-p（标准），75 OHM，正极性 和 TMDS ,DVI-D
电源
100~240VAC, 50/60Hz
功率消耗
开机 < 49 W
离机 < 2 W
物理 特性
连接器类型
15- 针 Mini D-Sub ,DVI-D
信号电缆类型
可分离
尺寸和重量：
高度 (含底座)
403.4 mm
宽度
505.8mm
深度
210mm
重量（仅监视器）
4.8 kg
重量（含包装）
6.4 kg
环境
温度
工作时
0°- +50°
非工作时
-20°- +60°
湿度：
工作时
10% - 85%（非凝露）
非工作时
5% - 80%（非凝露）
海拔高度
工作时
0~3000m (0~10000 ft)
非工作时
0~5000m (0~15000 ft)
2. 技术规格
一般规格
6
标准
分辨率
水平频率(kHZ)
垂直频率(Hz)
Dos-mode
640×400 @70Hz
31.469
70.087
VGA
640×480 @60Hz
31.469
59.940
Mac-mode
640×480 @67Hz
35.000
66.667
VGA
640×480 @72Hz
37.861
72.809
VGA
640×480 @75Hz
37.500
75.000
Dos-mode
720×400 @70Hz
31.469
70.087
SVGA
800×600 @56Hz
35.156
56.250
SVGA
800×600 @60Hz
37.879
60.317
SVGA
800×600 @72Hz
48.077
72.188
SVGA
800×600 @75Hz
46.875
75.000
VESA-Mode
848×480 @60Hz
31.020
60.000
Mac-mode
832×624 @75Hz
49.725
74.551
XGA
1024×768 @60Hz
48.363
60.004
Mac-mode
1024×768 @60Hz
48.780
60.001
XGA
1024×768 @70Hz
56.476
70.069
IBM-mode
1024×768 @72Hz
57.515
72.100
XGA
1024×768 @75Hz
60.023
75.029
Mac-mode
1024×768 @75Hz
60.241
74.927
IBM-mode
1152×864 @75Hz
67.500
75.000
XGA
1280×768 @60Hz
47.396
59.995
XGA
1280×768 @60Hz
47.776
59.870
XGA
1280×768 @75Hz
60.289
74.893
VESA-Mode
1280×960 @60Hz
60.000
60.000
SXGA
1280×1024 @75Hz
63.981
60.020
SXGA
1280×1024 @75Hz
79.976
75.025
WXGA
1440×900 @75Hz
55.935
59.887
WXGA
1440×900 @75Hz
70.635
74.984
WSXGA
1680×1050 @60Hz
65.290
59.954
预设显示模式
7
1
5
6
10
11
15
管脚号
信号电缆的 15 针一端
1
视频 - 红色
2
视频 - 绿色
3
视频 - 蓝色
4
N.C.
5
检测电缆
6
GND-R
7
GND-G
8
GND-B
9
+5V
10
接地
11
N.C.
12
DDC- 串行数据
13
H- 同步
14
V- 同步
15
DDC- 串行时钟
管脚号
信号名称
管脚号
信号名称
管脚号
信号名称
1
TMDS 数据 2-
9
TMDS 数据 1-
17
TMDS 数据 0-
2
TMDS 数据 2+
10
TMDS 数据 1+
18
TMDS 数据 0+
3
TMDS 数据 2/4 屏蔽
11
TMDS 数据 1/3 屏蔽
19
TMDS 数据 0/5 屏蔽
4
TMDS 数据 4-
12
TMDS 数据 3-
20
TMDS 数据 5-
5
TMDS 数据 4+
13
TMDS 数据 3+
21
TMDS 数据 5+
6
DDC 时钟
14
+5V 电源
22
TMDS 时钟屏蔽
7
DDC 数据
15
接地（对于 +5V ）
23
TMDS 时钟 +
8
N.C.
16
热插拔检测
24
TMDS 时钟 -
接头引脚分配
8
3. 操作说明及工厂模式调整
外部控制
按电源开关即可开关显示器。其它功能按键位于前面板 下方 。通过调节这些功能键可得到您需要的画面。
* 接好电源线。
* 将信号线接到 PC 机显卡
* 打开显示器把开关打到开机位置，电源指示灯亮。
1 亮度情景模式 / 向上
2 信号源切换(自动调整) / 向下
3 对比度 / 向左
4 动态对比度 / 向右
5 菜单 / 电源开关
使用 OSD 调整
按菜单（电源）键启动 OSD 主画面。 通过上下左右键浏览次级菜单, 按菜单（电源）键进入次级菜单
进入次级菜单后, 用上下键选择子项目, 左右键选择数值增加减小; 按菜单(电源)键返回上级菜单.
如果您想调整其它任何功能，请重复步骤 1-2 。
在主菜单画面下, 选择 “退出” 图标, 再按出菜单(电源)键退出 OSD 画面.
OSD 锁定功能： 要锁定 OSD ，请在显示器关闭时按住 向左 按钮，然后按电源按钮打开显示器。 要解锁
OSD ，请在显示器关闭时按住 向左 按钮，
然后按电源按钮打开显示器。
亮度情景模式快捷键: 当没有 OSD菜单时, 连续按 Eco快捷键可选择不同的亮度情景模式(部分机型可能不适
用).
对比度快捷键: 当没有 OSD 菜单时, 按对比度快捷键( )激活对比度调整菜单, 按 或 调节对比度大小
动态对比度快捷键 :当没有 OSD 菜单时, 连续按动态对比度快捷键 ( ) 开启或关闭动态对比度功能.
信号源快捷键: 当没有 OSD 菜单时, 按信号源快捷键激活信号源功能(仅针两种输入信号及以上机型) . 连续
按信号源切换键来选择信息栏中显示的信号源，按菜单键调整为选择的信号源。
自动调整快捷键: 当没有 OSD 菜单时,持续按自动调整快捷键 2 秒启动自动调整功能
连续按住菜单(电源)键至 2 秒关闭电源.
9
明亮度
调整数值
说明
亮 度
0-100
调整显示亮度
对比度
0-100
调整显示对比度
Eco Mode
标准
正常使用模式
节能
文本应用模式
网络
网络应用模式
游戏
游戏应用模式
电影
观赏电影应用模式
运动
观赏户外运动模式
伽玛
伽玛 1
调整为伽玛值 1
伽玛 2
调整为伽玛值 2
伽玛 3
调整为伽玛值 3
DCR
禁用
关闭动态对比度
启用
开启动态对比度
图象设置
时钟
0-100
调整图片时钟以降低垂直线噪声
相位
0-100
调整图片相位以降低水平线噪声
功能控制说明
10
水平位置
0-100
调整图片的水平位置
垂直位置
0-100
调整图片的垂直位置
色温
暖色温
6500K
设置为暖色温
常规色
7300K
设置为常规色温
冷色温
9300K
设置为冷色温
sRGB
设置为 sRGB
使用者设定
红
微调红色色温
绿
微调绿色色温
蓝
微调蓝色色温
色彩增强
全色增强
禁用/启用
开启或关闭全色增强模式
自然肤色
禁用/启用
开启或关闭自然肤色模式
绿茵场景
禁用/启用
开启或关闭绿色增强模式
蔚蓝风景
禁用/启用
开启或关闭蓝色增强模式
自动检测
禁用/启用
开启或关闭自动增强模式
演示
禁用/启用
开启或关闭左画面演示
窗口增亮
窗口尺寸
14-100
调整窗口尺寸大小
亮 度
0-100
调整窗口亮度
对比度
0-100
调整窗口增强对比度
水平位置
0-100
调整水平窗口位置
垂直位置
0-100
调整垂直窗口位置
增亮
禁用/启用
开启或关闭增亮窗口
OSD 设置
水平位置
0-100
调整 OSD 水平位置
垂直位置
0-100
调整 OSD 垂直位置
OSD 显示时间设定
5-120
调整 OSD 显示时间
透明度
0-100
调整 OSD 透明度
语言
选择 OSD 语言
其它
输入选择
自动
自动检测输入信号
模拟
选择输入为模拟信号源
数字
选择输入为数字信号源
HDMI
选择输入为 HDMI 信号源(仅针对有
HDMI 接口的机种)
自动调整
是或者否
自动调整画面
画面比例
宽屏或 4:3
选择宽屏或 4:3 显示格式
DDC-CI
是或者否
打开/关闭 DDC-CI 支持
显示信息
显示输入信号信息
重置
重置
是或者否
恢复到出厂设置
退出
退出
退出 OSD
11
状态
LED 颜色
开机模式
绿色或蓝色
离机模式
橙色或红色
请注意：
1) 如果产品只有单一信号输入, OSD 中的 "输入选择" 项目不可调整
2) 如果产品屏幕比例是 4:3 或者输入分辨率是宽屏模式, OSD 中的 "图像比例" 项目不可调整
3) 当动态对比度, 色彩增强, 窗口增亮任意一项功能启动, 另外 2 项功能将被自动关闭.
LED 指示灯
工厂模式调整
进入工厂模式方法：
机器应处于开机状态，关断输入的220V电源，先按住MENU键，然后接通电源，这时画面会出现“Auto Level”后画
面会进行自动调整。同时按MENU键，插拔电源，OSD菜单位于屏的左上角。
a.基本调整:
设置对比度 为 50.
设置亮度 为 80.
b.增益调整:
调整9300K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择9300K进行R G B增益调整
x = 283 ±20, y = 297 ±20, Y = 200 ±30 cd/m2
调整7300K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择7300K进行R G B增益调整
x = 301 ±20, y = 317 ±20, Y = 200 ±30 cd/m2
调整6500K色温
1、选中“AUTO LEVEL”先进行底光栅自动调整
2、按“MENU”选择 6500K 进行 R G B 增益调整
x = 313 ±20, y = 329 ±20, Y = 200 ±30 cd/m2
c.调整完毕直接关闭电源。
12
4. ISP 升级流程
13
14
15
16
无供电
按下电源键看画面是否正常
重新插插头然后检查输入 12V 和
5V 是否正常
检查 U701 PIN2=1.8V;U702 PIN2=3.3V
检查适配器及升压板部分和交流电源
输入
检查 X401 晶振是否正常
检查或者替换 CN701,U701, U702
替换 U401
替换 X401
OK
OK
OK
NG
NG
NG
NG
5.故障处理流程
无供电
17
无画
检查信号线
更换信号线
检查 U701 PIN2=1.8V
U702 PIN2=3.3V
更换 U401
检查 X401 震荡波是否正常
更换 U701, U702
OK
OK
OK
OK
NG
NG
检查 CN405的 HS/VS是否正常
更换 X401
检查相关回路
NG
NG
无画 (LED 橙色)
18
OSD 画面不稳定及不可调整
按键板是否连接正常
连接好按键板
按键开关是否正常
替换按键开关
OK
NG
NG
按键板是否正常
替换按键板
OK
NG
OK
检查主板
白屏
检查 Q703 的基极是否
为低电平
检查 X401 的晶振是否正常
检查 Q1 是否损坏或者 CN7
虚焊
检查相关元件
替换 PANEL
检查相关元件
替换 U401
OK
OK
OK
替换 X401
OK
NG
NG
NG
NG
检查 U401 复位电路是否正常
白屏
OSD 画面不稳定及不可调整
19
+5V
VCC3.3
VCC3.3D
TSUMU5RBWHQ SCHEMATIC
1
2217v B
1.2 5Monday, January 21, 2008
715G2670-1
<称爹>
1.2 TOP
G2670-1-X-X-5-080121
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
PB[18..23]
B3
3.INPUT
RIN
GIN
BIN
VSYNC
GNDR
GNDG
GNDB
DET_INPUT
HSYNC
SOG
B+
CLK-
HDCP_RST
CLK+
R+
G+
R-
B-
G-
DDCA_SDA
DDCA_SCL
DDCD_SDA
DDCD_SCL
DDC_WP
+5V
PA[2..7]
PA[14..19]
+5V
B5
5.PANEL INTERFACE
+5V
PA[2..7]
PA[8..13]
ESP
PA[14..19]
PB[0..5]
PB[6..11]
GPO[0..5]
OSP
Vin
PB[12..15]
VCC3.3D
on_PANEL
DCDC_ON
VCM_PWM
PB[18..23]
GPO[0..5]
PB[12..15]
+5V
PB[0..5]
B2
2.POWER
on_BACKLIGHT
Adj_BACKLIGHT
VCC1.8
VCC3.3D
+5V
VCC3.3
13.8V VOLUME
AUDIO_MUTE
VCC3.3D
+5V
B4
4.SCALER
RIN
GIN
SOG
BIN
GNDR
GNDG
GNDB
HSYNC
VSYNC
Adj_BACKLIGHT
VCC1.8
VCC3.3
PA[2..7]
PA[8..13]
R+
R-
G-
G+
B+
BCLK+
CLKDDCD_SDA
DDCD_SCL
HDCP_RST
DDCA_SDA
DDCA_SCL
DET_INPUT
on_BACKLIGHT
on_Panel
+5V
PA[14..19]
PB[0..5]
PB[6..11]
ESP
OSP
DCDC_ON
PB[12..15]
DDC_WP
VCM_PWM
PB[18..23]
GPO[0..5]
VOLUME
AUDIO_MUTE
PA[8..13]
VCC1.8
13.8V
VCC3.3
PB[6..11]
VCC1.8
RSDS OUTPUT
13.8V
WSXGA+/ UXGA
6. 电气方框图
7.PCB 分布图
7.1 主板
20
21
7.2 电源板
715G2510 2
22
715G2538 4
23
24
7.3 按键板
25
22" LCD Color Monitor AOC 2217V
VCC3.3
BL_ON
13.8V
1
2217v B
2 5Monday, January 21, 2008
715G2670-1
<称爹>
2. POWER
G2670-1-X-X-5-080121
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
CN701
CONN
1
2
3
4
5
6
7
8
9
10
+5V3,4,5
Q703
PMBS3904
U702
AP1117E33LA
23
1
4
OUTIN
GND
4
+5V
VCC1.8 5
VCC3.3D
C704
0.1uF/16V
VCC3.3
U701
3 2
1
VI VO
GND
Adj_BACKLIGHT 4
C711
0.1uF/16V
C709
0.1uF/16V
R708
10K 1/16W
R712
4K7 1/16W
GND
BL_ON
VCC3.3D
5
D704
SS14
VCC1.8
C714
0.1uF/16V
R711
10K 1/16W
VCC3.3
+5V
13.8V
+5V
3,4,5
+5V
R701
VCC3.3 4
C706
0.01uF/25V
VOLUME 4
+
C712
100uF/16V
C701
0.1uF/16V
AUDIO_MUTE 4
on_BACKLIGHT 4
GND
D701 & D704
19" Footprint: 2.5mm X 2.5mm
22" Footprint: From 2.5mm X 2.0mm
chnage to 2.5mm X 2.5mm
C713
0.1uF/16V
+5V
FB413 600 OHM
D701
GS1D
8. 线路图
8.1 主板
715G2670 1
26
R437 470R 1/16W
G- 4
D409
RLZ5.6B
C433 0.047uF
R467 10R 1/16W
FB412
0R05 1/10W 5%
C453
0.1uF/16V
DET_INPUT 4
R468 10R 1/16W
R451
10K 1/16W
D404
BAV99
3
1
2
GNDG 4
FB410
0R05 1/10W 5%
GNDR 4
R449
2K2 1/16W
C435 1000pF
R461
10K 1/16W
R465 10R 1/16W
R443 100R 1/16W
ESD_5V
D406
RLZ5.6B
+5V 2,4,5
D408
RLZ5.6B
C439
0.1uF/16V
C434 0.047uF
R442 100R 1/16W
GREEN-
DET_DVI
D412
RLZ5.6B
DVI5V
C445
0.1uF/16V
C454
0.1uF/16V
R459
10K 1/16W
+5V
DCLK-
R453 100R 1/16W
C436 0.047uF
HPD
D415
UDZS5.6B
C444
0.1uF/16V
R458 2K2 1/16W
U404
M24C02-WMN6TP
1
2
3
45
6
7
8
A0
A1
A2
VSSSDA
SCL
WP
VCC
DDCA_SDA4
D410
UDZS5.6B
R463 10R 1/16W
D416
UDZS5.6B
DDCA_SCL4 DDC_WP 4
PC5V
R482 NC
SCL_VGA
DAT1-
C442
33pF
PC5V
DDCD_SCL4
BLUE-
D422
BAV99
3
1
2
DVI5V
PC5V
VSI
D419
BAV99
3
1
2
SOG 4
FB409 150 OHM
DVI5V
+5V
C437 0.047uF
RED+
C441
0.1uF/16V
DAT0-
R445 1K 1/16W
CLK- 4
+5V
D413
BAV70
3
1
2
SCL_DVI
U405
M24C02-WMN6TP
1
2
3
45
6
7
8
A0
A1
A2
VSSSDA
SCL
WP
VCC
RED-
B+ 4
CLK+ 4
R460
10K 1/16W
HDCP_RST 4
C452
0.1uF/16V
R481
NC
DCLK+
SDA_VGA
BLUE+
C440
0.1uF/16V
BIN 4
GNDB 4
R+ 4
R456 100R 1/16W
D417
BAV99
3
1
2
R446 1K 1/16W
DAT2-
D423
BAV99
3
1
2
RIN 4
ESD_5V
D411
RLZ5.6B
C449
0.1uF/16V
R448
2K2 1/16W
VSYNC 4
G+ 4
R438
75R 1/16W
R- 4
C438 0.047uF
R444
4.7K OHM 1/16W
C451
0.1uF/16V
+5V
B- 4
DDCD_SDA4
Q405
NC
D407
BAV70
3
1
2
C432 0.047uF
HSI
R435 56 OHM 1/16W
CN405
DB15
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
17
16
D425
UDZS5.6B
CN406
JACK
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
26
25
DAT2-
DAT2+
2/4shield
DAT4-
DAT4+
DDC SCL
DDC SDA
VSYNC
DAT1-
DAT1+
1/3shield
DAT3-
DAT3+
+5V
SYNC GND
HPD
DAT0-
DAT0+
0/5shield
DAT5-
DAT5+
clk shield
clk+
clk-
GND
GND
C443
220pF 50V
DET_DVI
R440
75R 1/16W
D418
BAV99
3
1
2
R464 10R 1/16W
D424
BAV99
3
1
2
R439
75R 1/16W
R457 10K 1/16W
DAT1+
R469 10R 1/16W
GIN 4
D414
UDZS5.6B
C447
0.1uF/16V
R462 10R 1/16W
HSYNC 4
SDA_DVI
DAT0+
1
2217v Custom
3 5Monday, January 21, 2008
715G2670-1
<称爹>
3. INPUT
G2670-1-X-X-5-080121
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
R436 56 OHM 1/16W
D405
BAV99
3
1
2
C450
0.1uF/16V
D420
BAV99
3
1
2
R454 100R 1/16W
GREEN+
DDC_WP 4
+5V
R466 10R 1/16W
FB411
0R05 1/10W 5%
R441 100R 1/16W
DAT2+
R452
10K 1/16W
D403
BAV99
3
1
2
D421
BAV99
3
1
2
VGA_CON
R470
1K 1/16W
R455 100R 1/16W
R450
10K 1/16W
C448
0.1uF/16V
R434 56 OHM 1/16W
C446
0.1uF/16V
R447 1K 1/16W
22" LCD Color Monitor AOC 2217V
27
22" LCD Color Monitor AOC 2217V
AVDD_3.3
R-3
on_BACKLIGHT 2
R426
10K 1/16W
VCC1.82
VDDC_1. 8
DDCD _SCL3
C429
0.1uF/16V
D428
NC
C427
0.1uF/16V
RA1P
VCC3.3
KEY1
C421 22pF
VCM_PWM 5
PB10
C457
0.1uF/16V
HDCP_R ST 3
R407
0R05 1/16W
MSCL
MWP
MSCL
PB18
PB21
R405 22K 1/16W
X401
14.31818MHz
C423 22pF
VCC3.32
AVDD_1.8
PA19
R429 100R 1/16W
PB13
POWER
C419
0.1uF/16V
D401
UDZS5. 6B
AUDIO_MUTE 2
GPO5
+5V
VCC3.3
VCC1.8
PB4
CN403
CONN
1
2
3
4
5
6
C404
0.1uF/16V
GPO2
VSYNC3
R404
10K 1/16W
U403
M24C04-WMN6TP
1
2
3
45
6
7
8
NC
E1
E2
VSSSDA
SCL
WC
VCC
C412
0.1uF/16V
1
2217v Custom
4 5Monday, January 21, 2008
715G2670-1
<称爹>
4. SCALER
G2670-1-X-X-5-080121
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Elect ronics C o . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
C411
0.1uF/16V
R408
10K 1/16W
GPO3
GPO1
R489
10K 1/16W
VCC3.32
GNDG3
VDDP_3.3
PB1
R423 4K7 1/16W
FB401
0R05 1/10W 5%
U406
NC/MAX810STRG
1
2
3
GND
VCC
RESET
RIN3
C458
0.1uF/16V
CLK-3
VCC3.3
VCC3.3
PA13
DDC_W P 3
PB7
R406
10K 1/16W
MWP
R424
10K 1/16W
B+3
GPO4
R483 NC
PB20
GNDB3
R490
10K 1/16W
PA2
R+3
PB11
PA4
DDCD _SDA3
PA15
PA8
U402
SST25LF020A
1
2
3
4 5
6
7
8
CE#
SDO
WP#
VSS SDI
SCK
HOLD#
VDD
LED_G
Exchange with pin 118 - Max
20070425 / 20070524
VCC3.3
PA[14..19]
FB405
600 OHM
VCC1.82
PA18
C416
0.1uF/16V
R413
10K 1/16W
DDCA_SD A3
VCC3.3
PB0
PA3
DET_INPUT 3
VCC3.3
GPO0
R428 100R 1/16W
C456
0.1uF/16V
LED_A
PB3
PB[6..11] 5
PA6
DDCA_SC L3
PA10
C410
0.1uF/16V
G+3
Reset Circuit
KEY2
R425
10K 1/16W
C401
0.1uF/16V
AVDD_3.3
C426
0.1uF/16V
R487
10K 1/16W
R419 470R 1/16W
PB[0..5] 5
PA7
C409
0.1uF/16V
C406
0.1uF/16V
C428
0.1uF/16V
G-3
FB402
600 OHM
R403 390 OHM 1/16W
R427 100R 1/16W
PA[2..7] 5
R421 470R 1/16W
TSUMU5RBWHQ-LF
28
25
26
23
27
24
22
32
33
7
31
30
41
43
42
44
48
74
128
127
77
78
79
80
81
82
85
86
87
88
90
91
92
93
94
95
73
72
71
1
11
9
10
12
13
8
15
16
18
19
172949
110
67
34
109
119
35
36
5
6
14
112
37
68
120
121
122
124
125
38
39
117
3
4
50
76
64
65
636675
70
69
102
118
126
62
20
84
83
123
2
46
47
45
21
111
89
51
40
61
60
59
58
57
56
55
53
54
52
100
98
103
104
97
99
101
96
113
105
107
116
115
106
114
108
RIN0P
GIN0P
SOGIN0
BIN0P
RIN0M
GIN0M
BIN0M
HSYN C0
VSYNC 0
REXT
REFP
REFM
SDO
SCK
CSZ
SDI
GPIO_P24/PWM2
LLV6P/BA3N
XIN
XOUT
LLV5N/GA1P
LLV5P/GA1N
LLV4N/GA2P
LLV4P/GA2N
LLV3N/GA3P
LLV3P/GA3N
LLV1N/RA2P
LLV1P/RA2N
LLV0N/RA3P
LLV0P/RA3N
RLV6N/C LKAP
RLV6P/CLKAN
RLV5N/C LKBP
RLV5P/CLKBN
RLV4N/BB1P
RLV4P/BB1N
LLV6N/BA3P
NC/BA2N
NC/BA2P
GND
GND
B+
BG+
G-
AVDD_33
R+
RCK+
CK-
GND
GND
GND
VDDC
VDDP
MODE
VCTRL
VDDP
DDCA_SD A/RS232_TX
DDCA_SC L/RS232_RX
DDCD _SDA
DDCD _SCL
AVDD_33
VDDP
GPIO_P23/PWM1
GPIO_P04
GPIO_P00/SAR0
GPIO_P01/SAR1
GPIO_P02/SAR2
GPIO_P06
GPIO_P07
I2C_MDA
I2C_MCL
RST
GPIO_P15
GPIO_P16
VDDC
VDDC
VDDP
VDDP
GND
GND
GND
NC/BA1N
NC/BA1P
BYPASS
GPIO_P25
VDDC
VDDP
AVDD_33
LLV2P/RA1N
LLV2N/RA1P
GPIO_P03/SAR3
GPIO_P14/PWM0
GPIO_P43
GPIO_P42
GPIO_P44
AVDD_18
GND
GND
VDDP
VDDP
GPO[0]
GPO[1]
GPO[2]
GPO[3]
GPO[4]
GPO[5]
GPO[6]
ESP
OSP
AVDD_MEM PLL/VDDP
RLV1N/GB1P
RLV2N/BB3P
RLV0N/GB2P
RLV0P/GB2N
RLV3P/BB2N
RLV2P/BB3N
RLV1P/GB1N
RLV3N/BB2P
NC/R B2P
NC/GB3P
NC/R B1P
NC/R B3N
NC/R B3P
NC/GB3N
NC/R B2N
NC/R B1N
PB22
R474
3.9K OHM 1/ 16W
R433
NC
Q403
PMBS3906
PB6
C420
0.1uF/16V
VCC1.8
PB[6..11]
MSDA
Q406
NC
PB5
PB2
CLKAP
ESP
+
C408
10uF/25V
LED_G
GIN3
GPO[0..5] 5
LED_A
PB[0..5]
PA9
R420 100R 1/16W
PB15
C422
0.1uF/16V
PA16
C431
NC
C402
0.1uF/16V
D402
UDZS5. 6B
R486
NC
PA12
HSYN C3
SOG3
PA[14..19] 5
OSP 5
BB1P
PA[2..7]
C417
0.1uF/16V
C425
0.22uF/16V
R411 100R 1/16W
R488 100R 1/16W
on_PANEL 5
adj_BACKLIGHT 2
PA[8..13] 5
Q402
PMBS3904
VDDP_3.3
AVDD_1.8
GB1P
VDDC_1. 8
+
C403
10uF/25V
R422 4K7 1/16W
B-3
AVDD_3.3
PB[18..23] 5
POWER
PA17
PA11
WP
DCDC _ON 5
R475
3.9K OHM 1/ 16W
C407
0.1uF/16V
+
C418
10uF/25V
BIN3
CLK+3
ESP 5
R415
10K 1/16W
RB1P
+5V
C405
0.1uF/16V
VCC3.3
GPO[0..5]
MSDA
PB[12..15]
C414
0.1uF/16V
PB8
PB14
PB19
GNDR3
D427
NC
PA[8..13]
PA5
R418 100R 1/16W
C413
0.1uF/16V
C430
0.1uF/16V
PB[12..15] 5
VOLUME 2
PB9
C415
0.1uF/16V
Q401
PMBS3906
BA1P
PB[18..23]
FB403
600 OHM
WP
OSP
KEY1
+5V
PB23
PB12
KEY2
PA14
R410
0R05 1/16W
R499 100R 1/16W
GA1P
28
22" LCD Color Monitor AOC 2217V
13.8V
STB
PA19
PB0
FG1P
POL
BSTH
PB14
FG0P
FB2P
BB1P
CKV1
1
BSTH
C78
0.01uF/25V
PB2
BB2N
BG2N
FG1P
BB1N
GPO0
FR0P
GVOFF
BB0P
R1
10K 1/16W
VCC3.3D2
PA[14..19]4
PB3
BCKN
BB2P
BB0P
DCDC_ON4
C3
0.1uF/16V
FCKP
ESP
FR0N
BR1P
PB11
PA10
PB21
OE1
1
+5V2,3,4
GPO5
BCKN
BR1N
PB22
BR0N
PB[0..5]
PB18
FB0N
PB[18..23]
PB[0..5]4
PB9
GPO[0..5]4
FR1P
BSTH1
1
VCC3.3D
BR1N
FG0P
BG2N
C4
0.1uF/16V
PB15
FR0N
PB23
VCM_PWM4
BG0N
PB1
ESP4
FG2P
BG1N
R2
10K 1/16W
PA[2..7]4
Q2
PMBS3904
PA[8..13]4
PA8
FR1N
PA3
FG1N
PA12
BG0P
PB[12..15]
PA9
FB2N
PB[18..23]4
FG2P
OE
Q1
PMBS3904
PB[12..15]4
VCC3.3D
BR2P
PA6
GVOFF
FR1N
PB6
STV1
1
BG2P
CKV
Port Back and Front R/B swap ,
DATA P/N swap,
CLK P/N swap
BG0P
BR0P
GVOFF
BB2N
OSP4
on_PANEL
BG2P
PB4
FG1N
FB2N
PA5
FB0P
FB2P
FB0N
FCKP
GPO3
FB1P
VCC3.3D
R9 4K7 1/16W
FG2N
FSTH
FR0P
BR2P
BR2N
FG2N
PA11
STV
FSTH1
1
R4 4K7 1/16W
FR2P
PA14
STB1
1
PA15
OSP
PA16
PA18
+
C77
10uF/25V
PA7
PB5
FB1P
PA13
FR2N
GPO2
BR1P
POL1
1
PB8
BB0N
BR0N
STV
FSTH
PB12
BB1N
BG1P
PB19
R6
10K 1/16W
PA[14..19]
PA[8..13]
POL
BB2P
CKV
C76
0.1uF/16V
STV
FB1N
FSTH
BG1P
POL
CN6
CONN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
VCM_PWM1
1
+5V
FCKN
FG0N
BR2N
PA2
BB1P
FG0N
PA17
GVOFF1
1
STB
OE
PB13
CKV
FCKN
PB20
FB1N
R7
10K 1/16W
PB10
BR0P
PB[6..11]
FR1P
PA[2..7]
CN7
CONN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
BSTH
GPO1
BCKP
GPO4
BCKP
FR2P
PB[6..11]4
1
2217v Custom
5 5Tuesday, April 15, 2008
715G2670-1
<称爹>
5. PANEL INTERFACE
G2670-1-X-X-5-080121
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
BG0N
BB0N
STB
PA4
+
C75
10uF/25V
BG1N
VCM_PWM
FB0P
GPO[0..5]
FR2N
PB7
OE
29
22" LCD Color Monitor AOC 2217V
8.2 Power Board
715G2510 2
30
22" LCD Color Monitor AOC 2217V
31
22" LCD Color Monitor AOC 2217V
D901
PS102R
L903
1.1uH
R904
4K7 1/4W 5%
R913
NC
VAR901
NC
R919100 OHM 1/4W
IC901
TEA1530AT
1
2
3
4 5
6
7
8
Vcc
GND
PROTECT
CTRL SEN SE
DRIVER
HVS
DRAIN
R931
8K2 1/8W 5%
R902
680K OHM 1/4W +-5%
R911
1K 1/8W 5%
C924
0.01uF/16V
Q901
STP10NK70ZFP
Q902
PMBS3904
R932
4K7 1/4W 5%
R936
NC
+
C905
100uF450V
+12V
ZD901
NC
1 2
R908
100K OHM 2W
R905
NC
!
CN901
SOCKET
12
3
R924
1K5 1/10W 5%
L901
4.0mH
124
3
R901
680K OHM 1/4W +-5%
R910
10R 1/4W 5%
C907
0.1uF
PWPC942SEE1 B
19'LCD
B
2 3Monday, June 23, 2008
715G2538 4
<称爹>
02.POWER
G2538-4-X-X-1-080530
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
L901
4.0mH
124
3
C928
0.0012uF
R930
2.4K 1% 1/10W
HS1
HEAT SINK(D 906)
1
2
D906
SP10100
1
2
3
!
R917
1K 1/8W 5%
R916
1K5 1/8W 5%
R925
1K 1/10W 1%
R927
3.6K 1% 1/10W
C921
0.0047UF/ 400V
R928
1K 1/4W
R961 100 OHM 1/4W
R929
1K 1/8W 5%
C901
1000pF
C916
0.1uF
!
R912
22K 1% 1/8WR915
220K 1/8W 5%
R922
1K 1/4W 5%
L904
1.1uH
R921
1K 1/4W 5%
D916
LL4148WP
t
NR901
NTCR
C912
0.001uF
R914
0.22 OHM 2W
GND1
GND
1
2
+
C939
1000uF25V
!
L902
L
1
4
2
3
ZD902
RLZ TE-11 16B
F902
0 OHM 1/4W
R909
10R 1/4W 5%
D915
LL4148WP
R933
4K7 1/4W 5%
!
R962 100 OHM 1/4W
D900
PR1007R
C931
0.1uF
ON/OFF
C909
0.22uF/50V
HS3
HEAT SINK(Q901)
1
2
+
C915
470uF/16V
FB901
BEAD
12
C903
0.47UF
+5V
C902
1000pF
+14V
C911
1uF/25V
VCC
FG
R920100 OHM 1/4W
D903
BAW56
3
2
1
FG
+
C908
22uF/50V
R918100 OHM 1/4W
D905
NC
1
2
3
C910
0.001uF
T901
POWER X'FMR
4
7
9
5
6
4
6
11
10
8
12
1
3
+
C918
680uF25V
HS2
NC
1
2
4.0A/250V
R907
NC
-
+
BD901
KBP208G
2
1
3
4
R935 100 OHM 1/4W
C906
1500pF 2KV
C938
1500pF 2KV
R967
0 OHM 1/4W
FG
ZD922
RLZ5.1B
1 2
!
F901
4A/250V
IC904
KIA431A-AT/P
R940
33K 1/10W 1%
R906
NC
ZD921
RLZ TE-11 16B
R926
10K 1/10W 1%
+
C922
470UF/25V
R903
680K OHM 1/4W +-5%
DIM
CN902
WIRE HARN ESS
1
2
3
4
5
6
7
8
9
D907
31DQ06FC3
IC903
PC123X2YFZOF
12
43
R942
1K 1/10W 1%
R923
1K 1/4W 5%
R938
10K 1/8W 5%
C929
0.001uF
+5V
+
C917
680uF/25V
C930
0.1uF
715G2538 4
32
22" LCD Color Monitor AOC 2217V
R803
1M 1/10W 5%
R813
10K 1/10W 1%
C816
0.0022uF
F801
0 OHM 1/4W
D801
BAV99
3
1
2
C838
1500PF50V
D817
LL4148WP
R826
1K 1/10W 1%
D804
BAV99
3
1
2
DIM
R858
15R 1/4W 5%
R815
1K5 1/10W 1%
R862
1M 1/10W 5%
C805
0.1uF
R828
10K 1/10W 1%
PWPC942SEE1
B
19'LCD
Custom
3 3Monday, June 23, 2008
715G2538 4
<称爹>
03.INVER TER
G2538-4-X-X-1-080530
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Elect ronics C o . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
CN803
CONN
1
2
Q803
P5506HVG
1
2
3
4 5
6
7
8
S1
G1
S2
G2 D2
D2
D1
D1
Q811
PMBS3904
R863
NC
R853
68K 1% 1/10W
R823
3K6 1/10W 5%
C835
NC
D814
LL4148WP
Q805
PDTC144WK
Q807
PMBS3904
Q802
P5506HVG
1
2
3
4 5
6
7
8
S1
G1
S2
G2 D2
D2
D1
D1
D802
BAV99
3
1
2
R861
390KΩ 1% 1/10W
C839
1500PF50V
Q812
PMBS3906
1
23
R809
1K 1/10W 1%
C820
220pF50V
R801
1K5 1/10W 1%
R857
15R 1/4W 5%
R825
22R 1/8W 5%
C815
0.0022uF
R811
2.4K 1% 1/10W
R837
47K 1/8W 5%
+12V
C834
0.1uF/25V
R805
NC
C822
1uF/25V
R814
1K5 1/10W 1%
D803
BAV99
3
1
2
Q804
PMBS3906
1
23
IC801
TL494
1
2
3
4
5
6
7
8 9
10
11
12
13
14
15
16
IN1+
IN1FB
DTC
CT
RT
GND
C1 E1
E2
C2
VCC
CONT
VREF
IN2-
IN2+
R824
1K 1/10W 1%
R802
NC
C819
0.0022uF
Q810
RK7002
CN804
CONN
1
2
C845
2.2uF/16V
R810
51K 1/8W Q809
RK7002
Q808
PDTA144WK
R832
10K 1/10W 1%
R818
1K 1/10W 1%
D808
BAW56
3
1
2
C
B
E
C841
1500PF50V
Q806
PMBS3904
R817
10K 1/10W 1%
R850
0R05 1/8W
D809
LL4148WP
C811
10pF/6KV
R835
1M 1/10W 5%
C823
0.0022uF
C824
0.1uF
JR803
0R05 1/4W 5%
C817
NC
T802
POWER X'FMR
1
4
8
3
7 9
C801
10pF/6KV
R820
47K 1/10W 1%
+
C803
470uF/25V
R808
10K 1/10W 1%
C821
0.1uF/25V
R812
1K 1/10W 1%
R855
15R 1/4W 5%
R841
68K 1% 1/10W
R851
9.1K OHM 1/ 10W
C846
NC
D806
LL4148WP
R807
47K 1/10W 1%
R839
0R05 1/8W
R833
10K 1/10W 1%
D805
BAW56
3
1
2
C
B
E
R856
15R 1/4W 5%
Q801
PMBS3904
C840
1500PF50V
R819
3K6 1/10W 5%
R827
1K 1/10W 5%
R821
1K 1/10W 1%
R804
100R 1/8W 5%
T801
POWER X'FMR
1
4
8
3
7 9
ON/OFF
C807
0.1uF/25V
R822
1K 1/10W 1%
CN802
CONN
1
2
R806
68K 1% 1/10W
CN801
CONN
1
2
C842
0.01uF
R831
2.4K 1% 1/10W
R816
1K5 1/10W 1%
+
C802
470uF/25V
R834
10K 1/10W 1%
R829
22R 1/8W 5%
C825
0.1uF/25V
R854
68K 1% 1/10W
33
C001
0.001uF
Q002
PMBS3904ZD007
MLVS0603M04
1 2
ZD001
RLZ36B
1 2
Q001
PMBS3904
SW001
SW
21
3 4
5
AMBER
BLUE
SW005
SW
1
3 4
2
5 6
R005
4K7 1/10W 5%
GNDZD008
MLVS0603M04
1 2
R002 0R05 1/10W 5%
POWER_ KEY
ZD004
RLZ36B
1 2
C008
0.001uF
LED_GRN#
R001 2K 1/10W
C003
0.001uF
LED_RED#
GND
LED_RED#
R003 2K 1/10W
C004
0.001uF
GND
GND
MENU
R006
4K7 1/10W 5%
LED_RED#
UP
LED_RED#
ZD002
RLZ36B
1 2
C007
0.001uF
CN001
CONN
1
2
3
4
5
6
OK
N.A. B
G2217 B
2 2Friday , May 23, 2008
715G2932-B-1
<称爹>
2. Key -Pad-Switch
G2932-B-X-X-1-071106
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬
隔 瓜 絪 腹
R004 1K 1/10W 5%
C002
0.001uF
ZD006
MLVS0603M04
1 2
LED_GRN#LED_GRN# LED_GRN#
GND
C009
0.001uF
ZD005
RLZ36B
1 2
DC_POWERON
LBADC1
SW004
SW
21
3 4
5 SW002
SW
21
3 4
5
LBADC2
SW003
SW
21
3 4
5
C005
0.001uF
DOWN
C006
0.001uF
22" LCD Color Monitor AOC 2217V
8.3 按键板
34
9. 爆炸图
35
点位
组件
对象描述
备注
040G 58160811A
GREEN DOT LABEL
040G 58162461A
EPA LABEL
044GH600 1
HANDLE 2
050G 600 4
HANDLE 1
052G 1150 C
INSULATING TAPE
052G 1186
SMALL TAPE
052G 1207 A
CONDUCTIVE TAPE 45MM *25MM *0.08MM
052G 1209 A
200MINIUM TAPE
052G6019 1
INSULATING TAPE
070GHDCP500HDC
HDCP CODE
E08903
089G1745GAA AC
DVI CABLE
2nd source
E08903
089G1745HAA AC
DVI CABLE
089G176E 36 2
FFC CABLE 36P 162MM P0.5
E08901
089G414A15N IS
POWER CORD
E08901
089G414A15N LS
POWER CORD
2nd source
095G8014 6D 52
HARNESS 6P-6P 200MM
0M1G 930 6 47 CR3
SCREW
0M1G1730 6120
SCREW,42-D020523
0M1G1730 6120
SCREW,42-D020523
0M1G1730 6120
SCREW,42-D020523
0Q1G 330 8120
SCREW 3X8MM 42A9930017/ 42-D002093
0Q1G 930 16 47 CR3
SCREW
705GQ834137
22" LCD STAND-BASE ASS'Y
A34G0289ABJ 1B
STAND
M037
A37G0031 6
HIGNE
AM1G1740 12 47 CR3
SCREW
Q12G6600 8
PORON FOOT
Q34G0243AEV 1M 33
BASE
Q34G0244 X2 1B
BASE-RING 7S10
M037
SA37G00316
HINGE ASS'Y
015F0031610
BRACKET
015F0031620
SUPPORT
028F0620090
SHAFT
002F0605100
SCREW NUTS M6.0*P1.0 白色
004F0612051 00
WASHER
004F061210M 00
METAL WASHERS12.0*6.03*4.70H
004F061210T 00
METAL WASHERS12.0*8.00*1.6H
004F061210T 01
METAL WASHERS12.0*4.72*1.0T
004F0612151 02
WASHER
E750
750GLVC0KZ111N
PANEL TPM220Z1-M01 D1A FQ TPV
A15G0245201
SHIELDING
A15G0246101
K22W_IO_BKT
A15G0247101
K22W_HINGE_BKT
A33G0173ABJ 1L 32
CABLE CLAMP
A33G0338 GM 1L
FUNCTION BUTTON
A34G0294ABJAAB
REAR COVER22"
A34G0647AEVB1X0130
BEZEL(L22WA-7K12)
AM1G1740 12 47 CR3
SCREW
10. BOM
TC82MPNYUWACHI
36
CBPC82MPACQ1
CONVERSION BOARD G2670-1-X-X-5-080121
040G 45762412B
CBPC LABEL
CN403
033G3802 6
WAFER
CN701
033G3802 10
PLUG
C77
067G305V100 4
10UF +-20% 25V
C403
067G305V100 4
10UF +-20% 25V
C408
067G305V100 4
10UF +-20% 25V
C418
067G305V100 4
10UF +-20% 25V
C75
067G305V100 4
10UF +-20% 25V
C712
067G305V101 3
105 摄氏度 100UF M 16V
CN405
088G 35315F H
D-SUB 15PIN
CN406
088G 35424F C
DVI 24PIN CONN F 附螺丝
X401
093G 2253B H
XAT01431AFI1H-3OHX AT-49 14.31818MHZ
CN6
033G8019 36 J
CONNECTOR
CN7
033G8019 36 J
CONNECTOR
U401
056G 562173
IC TSUMU5RBWHQ-LF PQFP-128
U701
056G 56327A
IC AP1117E18LA SOT223-3L ANACHIP
U702
056G 585 4A
IC AP1117E33L-13
U403
056G1133 32
IC M24C04-WMN6TP SO8
U404
056G1133 34
M24C02-WMN6TP
U405
056G1133 34
M24C02-WMN6TP
U402
056G1133
81(WA8MPTCMHQ1)
SST25LF020A-33-4C-SAE
Q1
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q2
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q402
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q703
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q401
057G 417 6
PMBS3906/PHILIPS-SMT(06)
Q403
057G 417 6
PMBS3906/PHILIPS-SMT(06)
R407
061G0402000
RST CHIPR 0 OHM +-5% 1/16W
R410
061G0402000
RST CHIPR 0 OHM +-5% 1/16W
R469
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R468
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R467
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R466
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R465
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R464
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R463
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R462
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R411
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R418
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R420
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R427
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R428
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R429
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R441
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R442
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R443
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R453
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R454
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R455
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
37
R456
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R488
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R499
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R446
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R445
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R447
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R470
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R424
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R415
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R413
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R408
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R406
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R404
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R2
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R1
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R711
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R459
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R457
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R452
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R451
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R460
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R461
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R487
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R489
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R490
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R6
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R7
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R708
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R450
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R426
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R425
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R448
061G0402222
RST CHIPR 2.2 KOHM +-5% 1/16W
R449
061G0402222
RST CHIPR 2.2 KOHM +-5% 1/16W
R458
061G0402222
RST CHIPR 2.2 KOHM +-5% 1/16W
R405
061G0402223
RST CHIPR 22 KOHM +-5% 1/16W
R403
061G0402390 0F
RST CHIP 390R 1/16W 1%
R474
061G0402390 1F
RST CHIPR 3.9KOHM +-1% 1/16W
R475
061G0402390 1F
RST CHIPR 3.9KOHM +-1% 1/16W
R437
061G0402471
RST CHIPR 470 OHM +-5% 1/16W
R421
061G0402471
RST CHIPR 470 OHM +-5% 1/16W
R419
061G0402471
RST CHIPR 470 OHM +-5% 1/16W
R4
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R422
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R423
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R9
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R712
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R444
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R434
061G0402560
RST CHIP 56R 1/16W 5%
R435
061G0402560
RST CHIP 56R 1/16W 5%
R436
061G0402560
RST CHIP 56R 1/16W 5%
R440
061G0402750
RST CHIPR 75 OHM +-5% 1/16W
38
R439
061G0402750
RST CHIPR 75 OHM +-5% 1/16W
R438
061G0402750
RST CHIPR 75 OHM +-5% 1/16W
FB401
061G0603000
RST CHIPR 0 OHM +-5% 1/10W
FB410
061G0603000
RST CHIPR 0 OHM +-5% 1/10W
FB411
061G0603000
RST CHIPR 0 OHM +-5% 1/10W
FB412
061G0603000
RST CHIPR 0 OHM +-5% 1/10W
C435
065G0402102 32
1000PF +-10% 50V X7R
C706
065G0402103 22
CHIP 0.01UF 25V X7R
C78
065G0402103 22
CHIP 0.01UF 25V X7R
C429
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C413
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C414
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C415
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C416
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C417
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C419
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C420
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C422
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C426
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C427
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C428
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C453
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C454
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C456
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C457
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C458
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C701
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C704
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C709
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C711
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C713
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C714
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C76
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C452
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C430
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C439
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C440
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C441
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C444
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C445
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C446
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C447
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C448
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C449
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C450
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C451
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C412
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C3
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C4
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C401
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C402
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
39
C404
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C405
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C406
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C407
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C409
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C410
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C411
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C423
065G0402220 31
CHIP 22PF 50V NPO
C421
065G0402220 31
CHIP 22PF 50V NPO
C443
065G0402221 31
CAP:CER 220PF 5% 50V SM
C425
065G0402224A5T
MLCC 0402 0.22UF K 10V X
C442
065G0402330 31
CHIP CAP 0402 33PF J 50V NPO
C438
065G0402473 12
CHIP 0.047UF 16V X7R
C437
065G0402473 12
CHIP 0.047UF 16V X7R
C436
065G0402473 12
CHIP 0.047UF 16V X7R
C434
065G0402473 12
CHIP 0.047UF 16V X7R
C433
065G0402473 12
CHIP 0.047UF 16V X7R
C432
065G0402473 12
CHIP 0.047UF 16V X7R
FB409
071G 56G151 MD
CHIP BEAD
FB413
071G 56U601 MA
CHIP BEAD 0805 600 OHM 1000MA
FB405
071G 56U601 MA
CHIP BEAD 0805 600 OHM 1000MA
FB403
071G 56U601 MA
CHIP BEAD 0805 600 OHM 1000MA
FB402
071G 56U601 MA
CHIP BEAD 0805 600 OHM 1000MA
D413
093G 64 42 P
BAV70 SOT23 BY PAN JIT
D407
093G 64 42 P
BAV70 SOT23 BY PAN JIT
D403
093G 6433P
BAV99
D404
093G 6433P
BAV99
D405
093G 6433P
BAV99
D417
093G 6433P
BAV99
D418
093G 6433P
BAV99
D419
093G 6433P
BAV99
D420
093G 6433P
BAV99
D421
093G 6433P
BAV99
D422
093G 6433P
BAV99
D423
093G 6433P
BAV99
D424
093G 6433P
BAV99
D406
093G 39S 24 T
RLZ 5.6B LLDS
D408
093G 39S 24 T
RLZ 5.6B LLDS
D409
093G 39S 24 T
RLZ 5.6B LLDS
D411
093G 39S 24 T
RLZ 5.6B LLDS
D412
093G 39S 24 T
RLZ 5.6B LLDS
D416
093G 39S 34 T
UDZSNP5.6B ROHM
D415
093G 39S 34 T
UDZSNP5.6B ROHM
D414
093G 39S 34 T
UDZSNP5.6B ROHM
D410
093G 39S 34 T
UDZSNP5.6B ROHM
D425
093G 39S 34 T
UDZSNP5.6B ROHM
D401
093G 39S 34 T
UDZSNP5.6B ROHM
D402
093G 39S 34 T
UDZSNP5.6B ROHM
D701
093G1020 1 S
GS1D
D704
093G2004 2
DIODE SR24
715G2670 1
MAIN BOARD PCB
40
KEPC7QK5
KEY BOARD
CN001
033G3802 6H
WAFER 6P RIGHT ANGLE PITCH 2.0
SW003
077G 600 2A CJ
TACT SWITCH 4PIN
SW002
077G 600 2A CJ
TACT SWITCH 4PIN
SW001
077G 600 2A CJ
TACT SWITCH 4PIN
SW004
077G 600 2A CJ
TACT SWITCH 4PIN
SW005
077G610D 1 WB
TACT SW+LED
GND2
095G 900630
WIRE HARNESS
Q001
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q002
057G 417 4
PMBS3904/PHILIPS-SMT(04)
R002
061G0603000
RST CHIPR 0 OHM +-5% 1/10W
R004
061G0603102
RST CHIPR 1K OHM +-5% 1/10W
R003
061G0603202
RST CHIPR 2 KOHM +-5% 1/10W
R001
061G0603202
RST CHIPR 2 KOHM +-5% 1/10W
R005
061G0603472
RST CHIPR 4.7K OHM +-5% 1/10W
R006
061G0603472
RST CHIPR 4.7K OHM +-5% 1/10W
C006
065G0603102 32
1000PF +-10% 50V X7R
C007
065G0603102 32
1000PF +-10% 50V X7R
C008
065G0603102 32
1000PF +-10% 50V X7R
C009
065G0603102 32
1000PF +-10% 50V X7R
C001
065G0603151 32
CHIP 150PF 50V X7R
C002
065G0603151 32
CHIP 150PF 50V X7R
C003
065G0603151 32
CHIP 150PF 50V X7R
C004
065G0603151 32
CHIP 150PF 50V X7R
C005
065G0603151 32
CHIP 150PF 50V X7R
ZD008
093G 64 59 SU
ESD MLVS0603M04 0603
ZD007
093G 64 59 SU
ESD MLVS0603M04 0603
ZD006
093G 64 59 SU
ESD MLVS0603M04 0603
ZD001
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
ZD002
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
ZD004
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
ZD005
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
715G2932 2
KEPC PCB FR4 25X66X1.6MM DS
E750
LCM220Z1M01A01
PANEL 22W M220Z1PS1 D1A TPV
PWPC8C42OQEB
POWER BOARD G2510-2-X-X-27-080411
040G 45762412B
CBPC LABEL
GND1
009G6005 1
GROUND TERMINAL
CN801
033G8021 2E F
WAFER
CN802
033G8021 2E F
WAFER
CN803
033G8021 2E F
WAFER
CN804
033G8021 2E F
WAFER
CN801
033G8021 2E U
INVERT CONNECTOR
CN802
033G8021 2E U
INVERT CONNECTOR
CN803
033G8021 2E U
INVERT CONNECTOR
CN804
033G8021 2E U
INVERT CONNECTOR
051G 6 4503
GLUE_RTV
IC903
056G 139 3A
IC PC123Y22FZ0F
NR901
061G 58080 WT
8 OHM NCT
R908
061G152M104 64
100KOHM 5% 2W
R914
061G152M43852T
RST MOF 0R43 5% 2W
C903
063G 10747410V
0.47UF 275VAC ARCO
41
C903
063G107K474 6S
CAP X2 0.47UF K 275VAC
C811
065G 6J5096ET
CAP CER 5PF J 6KV
C801
065G 6J5096ET
CAP CER 5PF J 6KV
C902
065G306M1022BM
Y1.CAP.001UF 250VAC MURATA
C901
065G306M1022BM
Y1.CAP.001UF 250VAC MURATA
C921
065G306M4722BP
4700PF +-20% 400VAC
C905
067G 40J10115K
EC CAP 100UF 450V 18*35MM
C922
067G215D4714KV
E.C 105℃ CAP 470UF M 25V ED SERIES
C803
067G215D4714KV
E.C 105℃ CAP 470UF M 25V ED SERIES
C802
067G215D4714KV
E.C 105℃ CAP 470UF M 25V ED SERIES
C918
067G215D6814KV
CAP 105℃ 680UF M 25V
C917
067G215D6814KV
CAP 105℃ 680UF M 25V
C940
067G215S1023KV
105℃ 1000UF M 16V
C939
067G215S1023KV
105℃ 1000UF M 16V
C915
067G215S4713KV
EC 105℃ CAP 470UF M 16V
C905
067G305T10115H
ELCAP 105℃ 100UF M 450V
L902
073G 174 65 H
LINE FILTER
L901
073G 174 76 L
CHOKE COIL LI TAI LF-002923
L904
073G 253191 L
CHOKE COIL 1.1UH CC-007802
L903
073G 253191 L
CHOKE COIL 1.1UH CC-007802
T901
080GL17T 39 L
X'FMR 510UH PT-007269
T802
080GL22T 1 H
XFMR INVERTER 86.7UH DADON
T801
080GL22T 1 H
XFMR INVERTER 86.7UH DADON
T802
080GL22T 1 DN
X'FMR 86.7UH TK.2003U.101
T801
080GL22T 1 DN
X'FMR 86.7UH TK.2003U.101
CN901
087G 501 37 S
AC INLET ST-01DG-B2K-K
BD901
093G 50460 28
BRIDGE DIODE KBP208G LITEON
BD901
093G 50460510
2KBP08M 2A 800V
CN902
095G 82510D 1
HARNESS 10P-10P(SCN) 110MM
705GQ9KA 57001
Q901 ASS'Y
051G 200 1
OIL FOR DISAPPEAR
Q901
057G 667 30
2SK2645
090G6263 1
HEAT SINK
0M1G1730 8120
SCREW
705GQ9KA 93001
D906 ASS"Y
051G 200 1
OIL FOR DISAPPEAR
D906
093G 60218
SB10100FCT
D906
093G 60267
SP10100
0M1G1730 8120
SCREW
Q90G0117 2
HEAT SINK
705GQ9KA 93002
D905 ASS"Y
051G 200 1
OIL FOR DISAPPEAR
090G6084 1
HEAT SINK
D905
093G 60257
DIODE SB1060FCT ITO-220AB BY PAN JIT
D905
093G 60278
DIODE SP1060 ITO-220 SECOS
0M1G1730 8120
SCREW
IC801
056G 379 22
IC TL494IDR SOIC-16
IC901
056G 379 76
IC LD7552BPS SOP-8
Q903
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q811
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q807
057G 417 4
PMBS3904/PHILIPS-SMT(04)
42
Q806
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q801
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q804
057G 417 6
PMBS3906/PHILIPS-SMT(06)
Q812
057G 417 6
PMBS3906/PHILIPS-SMT(06)
Q809
057G 759 2
RK7002
Q810
057G 759 2
RK7002
Q808
057G 760 4B
PDTA144WK SOT346
Q805
057G 760 5B
PDTC144WK SOT346
Q802
057G 763 6
AO4828L
Q803
057G 763 6
AO4828L
Q803
057G 763 14
AM9945N
Q802
057G 763 14
AM9945N
R827
061G0603100 0F
RST CHIPR 100 OHM +-1% 1/10W
R942
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R926
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R824
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R822
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R821
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R818
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R812
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R809
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R832
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R833
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R807
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R817
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R828
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R834
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R820
061G0603103
RST CHIPR 10 KOHM +-5% 1/10W
R835
061G0603105
RST CHIPR 1M OHM +-5% 1/10W
R862
061G0603105
RST CHIPR 1M OHM +-5% 1/10W
R801
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R814
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R815
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R816
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R861
061G0603150 3F
RST CHIPR 150 KOHM +-1% 1/10W
R930
061G0603240 1F
RST CHIPR 2.4 KOHM +-1% 1/10W
R860
061G0603242
RST CHIPR 2.4 KOHM +-5% 1/10W
R927
061G0603330 1F
RST CHIPR 3.3KOHM +-1% 1/10W
R940
061G0603430 2F
RST CHIPR 43 KOHM +-1% 1/10W
R823
061G0603470 2F
RST CHIPR 47 KOHM +-1% 1/10W
R863
061G0603470 2F
RST CHIPR 47 KOHM +-1% 1/10W
R859
061G0603472
RST CHIPR 4.7K OHM +-5% 1/10W
R851
061G0603560 2F
RST CHIPR 56 KOHM +-1% 1/10W
R802
061G0603560 2F
RST CHIPR 56 KOHM +-1% 1/10W
R803
061G0603564
RST CHIPR 560 KOHM +-5% 1/10W
R841
061G0603680 2F
RST CHIPR 68K OHM +-1% 1/10W
R853
061G0603683
RST CHIPR 68K OHM +-5% 1/10W
R854
061G0603683
RST CHIPR 68K OHM +-5% 1/10W
JR801
061G0805000
RST CHIPR 0 OHM +-5% 1/8W
JR806
061G0805000
RST CHIPR 0 OHM +-5% 1/8W
R808
061G0805100 2F
RST CHIPR 10KOHM +-1% 1/8W
43
R831
061G0805100 2F
RST CHIPR 10KOHM +-1% 1/8W
R915
061G0805100 3F
RST CHIPR 100KOHM +-1% 1/8W
R804
061G0805101
1ST CHIPR 100 OHM +-5% 1/8W
R826
061G0805102
RST CHIPR 1K OHM +-5% 1/8W
R943
061G0805102
RST CHIPR 1K OHM +-5% 1/8W
R925
061G0805102
RST CHIPR 1K OHM +-5% 1/8W
R938
061G0805103
RST CHIPR 10K OHM +-5% 1/8W
R924
061G0805151
RST CHIPR 150 OHM +-5% 1/8W
R825
061G0805220
RST CHIPR 22 OHM +-5% 1/8W
R829
061G0805220
RST CHIPR 22 OHM +-5% 1/8W
R839
061G0805220
RST CHIPR 22 OHM +-5% 1/8W
R850
061G0805220
RST CHIPR 22 OHM +-5% 1/8W
R837
061G0805473
RST CHIPR 47K OHM +-5% 1/8W
R810
061G0805560 2F
RST CHIPR 56 KOHM +-1% 1/8W
JR802
061G1206000
RST CHIPR 0 OHM +-5% 1/4W
JR803
061G1206000
RST CHIPR 0 OHM +-5% 1/4W
JR804
061G1206000
RST CHIPR 0 OHM +-5% 1/4W
JR901
061G1206000
RST CHIPR 0 OHM +-5% 1/4W
JR902
061G1206000
RST CHIPR 0 OHM +-5% 1/4W
F801
061G1206000 4
RST CHIPR 0 OHM +-5% 1/4W
R910
061G1206100
RST CHIPR 10 OHM +-5% 1/4W
R918
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R919
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R920
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R935
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R961
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R962
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R946
061G1206102
RST CHIPR 1K OHM +-5% 1/4W
R945
061G1206102
RST CHIPR 1K OHM +-5% 1/4W
R944
061G1206102
RST CHIPR 1K OHM +-5% 1/4W
R941
061G1206102
RST CHIPR 1K OHM +-5% 1/4W
R855
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R856
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R857
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R858
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R912
061G1206221
RST CHIPR 220 OHM +-5% 1/4W
R904
061G1206304
RST CHIPR 300K OHM +-5% 1/4W
R932
061G1206304
RST CHIPR 300K OHM +-5% 1/4W
R933
061G1206304
RST CHIPR 300K OHM +-5% 1/4W
R909
061G1206519
RST CHIPR 5.1 OHM +-5% 1/4W
R901
061G1206684
RST CHIPR 680K OHM +-5% 1/4W
R902
061G1206684
RST CHIPR 680K OHM +-5% 1/4W
R903
061G1206684
RST CHIPR 680K OHM +-5% 1/4W
C807
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C821
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C825
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C834
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C842
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C815
065G0603222 22
CHIP 2200PF 25V X7R
C816
065G0603222 22
CHIP 2200PF 25V X7R
C819
065G0603222 22
CHIP 2200PF 25V X7R
44
C823
065G0603222 22
CHIP 2200PF 25V X7R
C932
065G0805102 32
CHIP 1000P 50VX7R 0805
C928
065G0805102 32
CHIP 1000P 50VX7R 0805
C930
065G0805104 32
CAP CHIP 0805 0.1UF K 50V X7R
C924
065G0805104 32
CAP CHIP 0805 0.1UF K 50V X7R
C916
065G0805104 32
CAP CHIP 0805 0.1UF K 50V X7R
C907
065G0805104 32
CAP CHIP 0805 0.1UF K 50V X7R
C824
065G0805104 32
CAP CHIP 0805 0.1UF K 50V X7R
C805
065G0805104 32
CAP CHIP 0805 0.1UF K 50V X7R
C822
065G0805105 22
CAP CHIP 0805 1UF K 25V X7R
C841
065G080515231Y
MLCC 0805 1500PF J 50V NPO
C840
065G080515231Y
MLCC 0805 1500PF J 50V NPO
C839
065G080515231Y
MLCC 0805 1500PF J 50V NPO
C838
065G080515231Y
MLCC 0805 1500PF J 50V NPO
C820
065G0805221 31
CAP CHIP 0805 220PF J 50V NPO
C845
065G0805225 12
CAP CHIP 0805 2.2UF K 16V X7R
C909
065G0805471 21
CAP CHIP 0805 470PF J 25V NPO
C912
065G1206102 72
CAP CHIP 1206 1000PF K 500V X7R
C929
065G1206102 72
CAP CHIP 1206 1000PF K 500V X7R
D804
093G 64 33
DIO SIG SM BAV99 (PHSE)R
D803
093G 64 33
DIO SIG SM BAV99 (PHSE)R
D802
093G 64 33
DIO SIG SM BAV99 (PHSE)R
D801
093G 64 33
DIO SIG SM BAV99 (PHSE)R
D813
093G 6432S
IN4148W
ZD801
093G 39S 10 T
RLZ6.8B BY ROHM
ZD906
093G 39S 20 T
RLZ22B LLDS
ZD922
093G 39S 25 T
RLZ5.1B LLDS
ZD905
093G 39S 44 T
RLZ18B LLDS
ZD902
093G 39S 61 T
DIODE RLZ16B ROHM
ZD921
093G 39S 61 T
DIODE RLZ16B ROHM
D915
093G 64S511SEM
IN4148W
D903
093G 64S511SEM
IN4148W
D817
093G 64S511SEM
IN4148W
D814
093G 64S511SEM
IN4148W
D812
093G 64S511SEM
IN4148W
D809
093G 64S511SEM
IN4148W
D808
093G 64S511SEM
IN4148W
D807
093G 64S511SEM
IN4148W
D806
093G 64S511SEM
IN4148W
D805
093G 64S511SEM
IN4148W
D916
093G 64S511SEM
IN4148W
CN901
006G 31500
EYELET
T901
006G 31502
1.5MM RIVET
NR901
006G 31502
1.5MM RIVET
IC904
056G 158 12
KIA431A-AT/P TO-92
C938
065G 1K152 1T
1.5NF/1KV Z5F+-10%
C906
065G 2K152 1T6921
1.5NF/2KV Y5P +-10%
C908
067G 2152207NT
KY50VB22M-TP5 5*11
J810
071G 55 9 T
FERRITE BEAD
FB901
071G 55 29
FERRITE BEAD
F903
084G 56 4W
FUSE 4.0A 250V
45
F901
084G 56 4W
FUSE 4.0A 250V
D900
093G 6026T52T
RECTIFIER DIODE FR107
D900
093G 6026W52T
FR107
D901
093G 6038P52T
PS102R
D901
093G 6038T52T
FR103
715G2510 2
POWER BOARD PCB
HS1
Q85G0002 1
SHIELD_MAIN
L902
S73G17465V
LINE FILTER ASS'Y
034FPF20P01
BOBBIN
L902
S73G17465VW
LINE FILTER ASS'Y
L901
S73G17476V
LINE FILTER ASS'Y
L904
S73G25391V1
CHOKE COIL ASS'Y
L903
S73G25391V1
CHOKE COIL ASS'Y
Q20G6038 3 30
COSMETIC FUN KEY
Q20G6047201 30
POWER COVER WITH LENS
Q33G0203 1 1C0100
LENS
Q36G 600517
DUSTER CLOTH
Q40G 22N61544A
RATING LABEL
Q40G000262464A
VISTA LABEL 10X14.6MM
Q41G780A61577A
QSG
Q44GC021 1
EPS(L)
Q44GC021 2
EPS(R)
Q44GC021615 6A
22 LCD AOC CARTON
Q45G 77 5
PE PACKING
Q45G 88606 16 R
PE BAG FOR CLAMP
Q45G 88607 34
PE BAG FOR BASE
Q45G 88609 74 R
EPE BAG FOR MONITOR
Q52G 1185 99
BIG CARTON TAPE FOR AOC
Q41G7800615C32
WARRANTY CARD
Q45G 76 28 RN R
PE BAG MANUAL
Q70G220161517B
CD MANUAL
040G 58162435A
P/N LABEL FOR MANUAL PE BAG
040G 581689 4A
BARCODE LABEL FOR 1
点位
组件
对象描述
026G 800504 H
BARCODE
040G 45760819A
DATE/MODEL LABEL
040G 58162435A
P/N LABEL FOR MANUAL PE BAG
050G 600 3
HANDLE2
050G 600 4
Handle 1
052G 1150 C
INSULATING TAPE
052G 1186
SMALL TAPE
052G 1207 A
Conductive Tape 45mm *25mm *0.08mm (单导）
052G6019 1
INSULATING TAPE
E08902
089G 715HAA D2
SIGNAL CABLE
E08907
089G176J 55 1A
FFC CABLE 55PIN
E08901
089G414A15N IS
POWER CORD
E09503
095G8014 6XE20
HARNESS 6P-6P 200mm
TC82MPNDUWA4HNE
46
0D1G 930 8 47 CR3
SCREW
0D1G1730 8120
SCREW
0M1G1730 6120
SCREW,42-D020523
0Q1G 930 8120
screw
0Q1G 930 16 47 CR3
SCREW
705GQ834137
22" LCD STAND-BASE ASS'Y
750GLV220KZ143N000
PANEL TPM220Z1-PS3 C1A WH TPV
A15G0247101
K22W_HINGE_BKT
A33G0173ABJ 1L 32
CABLE CLAMP
A34G0294ABJAAB
REAR COVER22"
A34G0647AEDB1B0102
BEZEL
AM1G1740 12 47 CR3
SCREW
CBPC82MPA1H1
MAIN BOARD
H12G6200 11
rubber pad
H40G 22N615 5A
22 RATING LABEL
H41G7800615 7E
WARRANTY BOOKLIST
H41G780061557A
QSG
H44GC065615 5A
22 LCD CARTON
H45G 77 6
PE PACKING
H45G 87 4 H A
PE BAG FOR BASE
H45G 87 18 12
EPE_COVER_MONITOR
H70G200861514A
22 CD MANUAL
KEPC8HA6
KEY BOARD
PWPC7C42CQDJ
POWER BOARD G2538-4-X-X-26-080611
Q15G0267 H 6
MAIN FRAME
Q20G6038 3 30
COSMETIC FUN KEY
Q20G6047201 30
Power Cover with lens
Q36G 600517
duster cloth
Q44GC065 1
EPS
Q44GC065 2
EPS
Q45G 76 28 H A
PE BAG FOR MANUAL
Q52G 1185 99
BIG CARTON TAPE FOR AOC
A34G0289ABJ 1B
STAND
A37G0031 6
higne
AM1G1740 12 47 CR3
SCREW
Q34G0243AED 1B 30
BASE
Q34G0244 X2 1B
BASE-RING 7S10
CN701
033G3802 9
WAFER 9P RIGHT ANELE PITCH
CN403
033G3802 6B Y W
WAFER
040G 45762412B
CBPC LABEL
R702
061G152M51964L
RST MOFR 5.1OHM +-5% 2WS
C403
067G305V100 3
105 摄氏度 10UF +-20% 16V
C408
067G305V100 3
105 摄氏度 10UF +-20% 16V
C418
067G305V100 3
105 摄氏度 10UF +-20% 16V
C461
067G305V101 3
105 摄氏度 100UF M 16V
C703
067G305V101 3
105 摄氏度 100UF M 16V
C712
067G305V101 3
105 摄氏度 100UF M 16V
CN405
088G 35315F HD
D-SUB CONN F ATTACHED SCREW
CN406
088G 35424F D
DVI 24PIN CONN F ATTACHED SCREW
X401
093G 2253B H
XAT01431AFI1H-3OHX AT-49 14.31818MHZ
CN407
033G801955Y H HC
0.5 PITCH 55P SMT
47
U401
056G 562211
IC TSUMU5REHQ-LF PQFP-128
U701
056G 56327A
IC AP1117E18LA SOT223-3L ANACHIP
U702
056G 585 4A
IC AP1117E33L-13
U405
056G1133 34
M24C02-WMN6TP
U404
056G1133 34
M24C02-WMN6TP
U402
056G1133 81
SST25LF020A-33-4C-SAE
U403
056G1133 89
IC AF24BC16-SI 16K SOIC-8
Q411
057G 417517
LMBT3906LT1G SOT-23 BY LRC
Q403
057G 417517
LMBT3906LT1G SOT-23 BY LRC
Q401
057G 417517
LMBT3906LT1G SOT-23 BY LRC
Q402
057G 417518
LMBT3904LT1G SOT-23 BY LRC
Q703
057G 417518
LMBT3904LT1G SOT-23 BY LRC
Q412
057G 763501
FET AM2321P ANALOG POWER
R410
061G0402000
RST CHIP MAX 0R05 1/16W
R407
061G0402000
RST CHIP MAX 0R05 1/16W
R469
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R468
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R467
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R466
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R465
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R464
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R463
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R462
061G0402100
RST CHIPR 10 OHM +-5% 1/16W
R499
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R488
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R456
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R455
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R454
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R453
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R443
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R442
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R441
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R429
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R428
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R427
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R420
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R418
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R411
061G0402101
RST CHIPR 100 OHM +-5% 1/16W
R470
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R447
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R446
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R445
061G0402102
RST CHIPR 1 KOHM +-5% 1/16W
R711
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R708
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R497
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R494
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R493
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R490
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R489
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R487
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R461
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
48
R457
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R404
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R406
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R408
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R413
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R415
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R424
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R425
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R426
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R452
061G0402103
RST CHIPR 10 KOHM +-5% 1/16W
R448
061G0402222
RST CHIPR 2.2 KOHM +-5% 1/16W
R449
061G0402222
RST CHIPR 2.2 KOHM +-5% 1/16W
R458
061G0402222
RST CHIPR 2.2 KOHM +-5% 1/16W
R405
061G0402223
RST CHIPR 22 KOHM +-5% 1/16W
R403
061G0402390 0F
RST CHIP 390R 1/16W 1%
R474
061G0402390 1F
RST CHIPR 3.9KOHM +-1% 1/16W
R475
061G0402390 1F
RST CHIPR 3.9KOHM +-1% 1/16W
R419
061G0402471
RST CHIPR 470 OHM +-5% 1/16W
R421
061G0402471
RST CHIPR 470 OHM +-5% 1/16W
R437
061G0402471
RST CHIPR 470 OHM +-5% 1/16W
R712
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R496
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R460
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R459
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R451
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R450
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R444
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R423
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R422
061G0402472
RST CHIPR 4.7 KOHM +-5% 1/16W
R495
061G0402513
RST CHIP 51K 1/16W 5%
R436
061G0402560
RST CHIP 56R 1/16W 5%
R435
061G0402560
RST CHIP 56R 1/16W 5%
R434
061G0402560
RST CHIP 56R 1/16W 5%
R438
061G0402750
RST CHIPR 75 OHM +-5% 1/16W
R439
061G0402750
RST CHIPR 75 OHM +-5% 1/16W
R440
061G0402750
RST CHIPR 75 OHM +-5% 1/16W
FB401
061G0603000
RST CHIP MAX 0R05 1/10W
FB410
061G0603000
RST CHIP MAX 0R05 1/10W
FB411
061G0603000
RST CHIP MAX 0R05 1/10W
FB412
061G0603000
RST CHIP MAX 0R05 1/10W
R491
061G0805391
RST CHIPR 390 OHM 5% 1/8W
C435
065G0402102 32
1000PF +-10% 50V X7R
C454
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C453
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C452
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C451
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C450
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C449
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C448
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C447
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C445
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
49
C441
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C440
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C456
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C457
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C458
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C462
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C465
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C701
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C704
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C709
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C711
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C713
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C714
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C439
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C401
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C402
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C404
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C405
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C406
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C407
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C409
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C410
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C411
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C412
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C413
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C430
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C429
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C428
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C427
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C426
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C422
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C420
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C419
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C416
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C415
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C414
065G0402104 15
MLCC 0402 0.1UF K 16V X5R
C463
065G0402105 A5
CAP 0402 1UF K 10V X5R
C443
065G0402221 31
CAP:CER 220PF 5% 50V SM
C446
065G0402224 A5
MLCC 0402 CAP 0.22UF K 10V X5R
C444
065G0402224 A5
MLCC 0402 CAP 0.22UF K 10V X5R
C425
065G0402224 A5
MLCC 0402 CAP 0.22UF K 10V X5R
C417
065G0402224 A5
MLCC 0402 CAP 0.22UF K 10V X5R
C421
065G0402270 31
0402 27PF J 50V NPO
C423
065G0402270 31
0402 27PF J 50V NPO
C442
065G0402330 31
CHIP CAP 0402 33pF J 50V NPO
C438
065G0402473 12
CHIP 0.047uF 16V X7R
C437
065G0402473 12
CHIP 0.047uF 16V X7R
C436
065G0402473 12
CHIP 0.047uF 16V X7R
C434
065G0402473 12
CHIP 0.047uF 16V X7R
C433
065G0402473 12
CHIP 0.047uF 16V X7R
C432
065G0402473 12
CHIP 0.047uF 16V X7R
50
FB409
071G 56G151 MD
CHIP BEAD
FB402
071G 56K121 M
CHIP BEAD
FB403
071G 56K121 M
CHIP BEAD
FB405
071G 56K121 M
CHIP BEAD
FB421
071G 56K121 M
CHIP BEAD
D413
093G 64 42 P
BAV70 SOT23 BY PAN JIT
D407
093G 64 42 P
BAV70 SOT23 BY PAN JIT
D424
093G 6433P
BAV99
D423
093G 6433P
BAV99
D422
093G 6433P
BAV99
D421
093G 6433P
BAV99
D420
093G 6433P
BAV99
D419
093G 6433P
BAV99
D418
093G 6433P
BAV99
D417
093G 6433P
BAV99
D405
093G 6433P
BAV99
D404
093G 6433P
BAV99
D403
093G 6433P
BAV99
D412
093G 39S 24 T
RLZ 5.6B LLDS
D411
093G 39S 24 T
RLZ 5.6B LLDS
D409
093G 39S 24 T
RLZ 5.6B LLDS
D408
093G 39S 24 T
RLZ 5.6B LLDS
D406
093G 39S 24 T
RLZ 5.6B LLDS
D425
093G 39S501 T
LUDZS5.6BT1G BY LRC
D410
093G 39S501 T
LUDZS5.6BT1G BY LRC
D416
093G 39S501 T
LUDZS5.6BT1G BY LRC
D415
093G 39S501 T
LUDZS5.6BT1G BY LRC
D414
093G 39S501 T
LUDZS5.6BT1G BY LRC
D402
093G 39S501 T
LUDZS5.6BT1G BY LRC
D401
093G 39S501 T
LUDZS5.6BT1G BY LRC
D704
093G2004 2
DIODE SR24
715G2670 1 2
MAIN BOARD PCB FR4 80x67x1.6mm DS
CN001
033G3802 6H
WAFER 6P RIGHT ANGLE PITCH 2.0
SW003
077G 600 3A HJ
TACT SW 4P TSDBYB2
SW002
077G 600 3A HJ
TACT SW 4P TSDBYB2
SW001
077G 600 3A HJ
TACT SW 4P TSDBYB2
SW004
077G 600 3A HJ
TACT SW 4P TSDBYB2
SW005
077G610D 1 NA
TACT SW+LED
GND1
009G6005 1
GROUND TERMINAL
CN804
033G8021 2E U
INVERT CONNECTOR
CN803
033G8021 2E U
INVERT CONNECTOR
CN802
033G8021 2E U
INVERT CONNECTOR
CN801
033G8021 2E U
INVERT CONNECTOR
040G 45762412B
CBPC LABEL
IC903
056G 139 3A
IC PC123Y22FZ0F
NR901
061G 58120 WT
NTCR 12OHM 20% 2A SCK-122
C903
063G107K474 6S
CAP X2 0.47UF K 275VAC
C811
065G 6J5096ET
CAP CER 5PF J 6KV
C801
065G 6J5096ET
CAP CER 5PF J 6KV
C902
065G305M1022BP
Y2 1000PF M 250VAC Y5P
C901
065G305M1022BP
Y2 1000PF M 250VAC Y5P
51
C921
065G306M4722BP
4700PF +-20% 400VAC
C802
067G215D4714KV
E.C 105℃ CAP 470UF M 25V ED SERIES
C803
067G215D4714KV
E.C 105℃ CAP 470UF M 25V ED SERIES
C918
067G215D6814KV
CAP 105℃ 680uF M 25V
C917
067G215D6814KV
CAP 105℃ 680uF M 25V
C939
067G215S1024KV
EC 105℃ CAP 1000UF M 25V
C915
067G215S4713KV
EC 105℃ CAP 470UF M 16V
C905
067G215Z12115K
ELCAP 105℃ 120UF M 450V
L902
073G 174 65 H
LINE FILTER
L901
073G 174 76 V
LINE FILTER 4mH MIN
L903
073G 253 91 V1
CHOKE COIL 1.1uH
L904
073G 253 91 V1
CHOKE COIL 1.1uH
CN901
087G 501 32 DL
AC SOCKET DIP 3PIN+2PIN GROUND
CN902
095G8014 9X 57
WIRE HARNESS 9P(SCN)-9P(PH) 210mm
705G 193 57 01
Q901 ASS'Y
705G 193 93 01
D906 ASS'Y
705GQ9KA 93002
D905 ASS"Y
HS4
H85G0002 1
SHIELD
T901
S80GL19T23V
TRANSFORMER ASS'Y
T801
S80GL19T24V
TRANSFORMER
T802
S80GL19T24V
TRANSFORMER
BD901
093G 50460 28
BRIDGE DIODE KBP208G LITEON
Q002
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q001
057G 417 4
PMBS3904/PHILIPS-SMT(04)
R002
061G0603000
RST CHIP MAX 0R05 1/10W
R004
061G0603102
RST CHIPR 1K OHM +-5% 1/10W
R003
061G0603202
RST CHIPR 2 KOHM +-5% 1/10W
R001
061G0603202
RST CHIPR 2 KOHM +-5% 1/10W
R006
061G0603472
RST CHIPR 4.7K OHM +-5% 1/10W
R005
061G0603472
RST CHIPR 4.7K OHM +-5% 1/10W
C009
065G0603102 32
1000PF +-10% 50V X7R
C008
065G0603102 32
1000PF +-10% 50V X7R
C007
065G0603102 32
1000PF +-10% 50V X7R
C006
065G0603102 32
1000PF +-10% 50V X7R
C005
065G0603151 32
CHIP 150PF 50V X7R
C004
065G0603151 32
CHIP 150PF 50V X7R
C003
065G0603151 32
CHIP 150PF 50V X7R
C002
065G0603151 32
CHIP 150PF 50V X7R
C001
065G0603151 32
CHIP 150PF 50V X7R
ZD007
093G 64 59 SU
ESD MLVS0603M04 0603
ZD006
093G 64 59 SU
ESD MLVS0603M04 0603
ZD008
093G 64 59 SU
ESD MLVS0603M04 0603
ZD005
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
ZD004
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
ZD002
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
ZD001
093G 39S 45 T
DIODE ZENER RLZ36B ROHM
715G2932 2
KEY BOARD PCB FR4 25x66x1.6MM DS
Q901
057G 667 21
STP10NK70ZFP
090G6263 1
HEAT SINK
0M1G1730 8120
SCREW
D906
093G 60218
SB10100FCT
52
0M1G1730 8120
SCREW
Q90G6274 2
HEAT SINK
051G 200 1
OIL FOR DISAPPEAR
090G6084 1 GP
HEAT SINK
D905
093G 60257
DIODE SB1060FCT ITO-220AB BY PAN JIT
0M1G1730 8120
SCREW
IC801
056G 379 22
IC TL494IDR SOIC-16
IC901
056G 379 71
IC TEA1530AT/N2 so-8 nxp
Q902
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q811
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q807
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q806
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q801
057G 417 4
PMBS3904/PHILIPS-SMT(04)
Q804
057G 417 6
PMBS3906/PHILIPS-SMT(06)
Q812
057G 417 6
PMBS3906/PHILIPS-SMT(06)
Q809
057G 759 2
RK7002FD5T116 SOT-23 BY ROHM
Q810
057G 759 2
RK7002FD5T116 SOT-23 BY ROHM
Q808
057G 760 4B
PDTA144WK SOT346
Q805
057G 760 5B
PDTC144WK SOT346
Q802
057G 763 6
AO4828L
Q803
057G 763 6
AO4828L
R942
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R925
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R826
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R824
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R822
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R821
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R818
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R812
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R809
061G0603100 1F
RST CHIPR 1 KOHM +-1% 1/10W
R926
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R834
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R833
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R832
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R828
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R817
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R813
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R808
061G0603100 2F
RST CHIPR 10K OHM +-1% 1/10W
R862
061G0603105
RST CHIPR 1M OHM +-5% 1/10W
R835
061G0603105
RST CHIPR 1M OHM +-5% 1/10W
R816
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R815
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R814
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R801
061G0603150 1F
RST CHIPR 1.5 KOHM +-1% 1/10W
R924
061G0603152
RST CHIPR 1.5 KOHM +-5% 1/10W
R811
061G0603240 1F
RST CHIPR 2.4 KOHM +-1% 1/10W
R831
061G0603240 1F
RST CHIPR 2.4 KOHM +-1% 1/10W
R930
061G0603240 1F
RST CHIPR 2.4 KOHM +-1% 1/10W
R861
061G0603300 2F
RST CHIPR 30 KOHM +-1% 1/10W
R940
061G0603330 2F
RST CHIPR 33K OHM +-1% 1/10W
R927
061G0603360 1F
RST CHIPR 3.6K OHM +-1% 1/10W
53
R819
061G0603362
RST CHIPR 3.6 KOHM +-5% 1/10W
R823
061G0603362
RST CHIPR 3.6 KOHM +-5% 1/10W
R827
061G0603362
RST CHIPR 3.6 KOHM +-5% 1/10W
R805
061G0603470 2F
RST CHIPR 47 KOHM +-1% 1/10W
R820
061G0603470 2F
RST CHIPR 47 KOHM +-1% 1/10W
R803
061G0603564
RST CHIPR 560 KOHM +-5% 1/10W
R854
061G0603680 2F
RST CHIPR 68K OHM +-1% 1/10W
R806
061G0603680 2F
RST CHIPR 68K OHM +-1% 1/10W
R807
061G0603680 2F
RST CHIPR 68K OHM +-1% 1/10W
R841
061G0603680 2F
RST CHIPR 68K OHM +-1% 1/10W
R853
061G0603680 2F
RST CHIPR 68K OHM +-1% 1/10W
R851
061G0603820 1F
RST CHIPR 8.2 KOHM +-1% 1/10W
R850
061G0805100
RST CHIPR 10 OHM +-5% 1/8W
R839
061G0805100
RST CHIPR 10 OHM +-5% 1/8W
R804
061G0805101
1ST CHIPR 100 OHM +-5% 1/8W
R911
061G0805102
RST CHIPR 1K OHM +-5% 1/8W
R917
061G0805102
RST CHIPR 1K OHM +-5% 1/8W
R929
061G0805102
RST CHIPR 1K OHM +-5% 1/8W
R938
061G0805103
RST CHIPR 10K OHM +-5% 1/8W
R810
061G0805150 2F
RST CHIPR 15 KOHM +-1% 1/8W
R916
061G0805152
RST CHIPR 1.5 KOHM +-5% 1/8W
R829
061G0805220
RST CHIPR 22 OHM +-5% 1/8W
R825
061G0805220
RST CHIPR 22 OHM +-5% 1/8W
R912
061G0805220 2F
RST CHIPR 22 KOHM +-1% 1/8W
R915
061G0805224
RST CHIPR 220 KOHM +-5% 1/8W
R837
061G0805473
RST CHIPR 47K OHM +-5% 1/8W
R931
061G0805822
RST CHIPR 8.2 KOHM +-5% 1/8W
JR901
061G1206000
RST CHIP MAX 0R05 1/4W
JR801
061G1206000
RST CHIP MAX 0R05 1/4W
JR802
061G1206000
RST CHIP MAX 0R05 1/4W
JR803
061G1206000
RST CHIP MAX 0R05 1/4W
JR804
061G1206000
RST CHIP MAX 0R05 1/4W
JR805
061G1206000
RST CHIP MAX 0R05 1/4W
JR807
061G1206000
RST CHIP MAX 0R05 1/4W
JR808
061G1206000
RST CHIP MAX 0R05 1/4W
JR809
061G1206000
RST CHIP MAX 0R05 1/4W
F801
061G1206000 4
RST CHIP MAX 0R05 1/4W
F902
061G1206000 4
RST CHIP MAX 0R05 1/4W
R967
061G1206000 4
RST CHIP MAX 0R05 1/4W
R909
061G1206100
RST CHIPR 10 OHM +-5% 1/4W
R910
061G1206100
RST CHIPR 10 OHM +-5% 1/4W
R918
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R962
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R961
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R935
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R920
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R919
061G1206101
RST CHIPR 100 OHM +-5% 1/4W
R921
061G1206102
RST CHIPR 1k OHM +-5% 1/4W
R922
061G1206102
RST CHIPR 1k OHM +-5% 1/4W
R923
061G1206102
RST CHIPR 1k OHM +-5% 1/4W
R928
061G1206102
RST CHIPR 1k OHM +-5% 1/4W
54
R856
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R858
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R857
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R855
061G1206150
RST CHIPR 15 OHM +-5% 1/4W
R904
061G1206472
RST CHIPR 4.7K OHM +-5% 1/4W
R933
061G1206472
RST CHIPR 4.7K OHM +-5% 1/4W
R932
061G1206472
RST CHIPR 4.7K OHM +-5% 1/4W
R903
061G1206684
RST CHIPR 680K OHM +-5% 1/4W
R902
061G1206684
RST CHIPR 680K OHM +-5% 1/4W
R901
061G1206684
RST CHIPR 680K OHM +-5% 1/4W
C924
065G0603103 32
CAP CHIP 0603 0.01UF K 50V X7R
C842
065G0603103 32
CAP CHIP 0603 0.01UF K 50V X7R
C807
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C821
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C825
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C834
065G0603104 22
CAP CHIP 0603 0.1UF K 25V X7R
C815
065G0603222 32
CHIP 2200PF 50V X7R
C816
065G0603222 32
CHIP 2200PF 50V X7R
C819
065G0603222 32
CHIP 2200PF 50V X7R
C823
065G0603222 32
CHIP 2200PF 50V X7R
C910
065G0805102 32
CHIP 1000P 50VX7R 0805
C820
065G080510231G
CHIP CAP 0805 1000PF G 50V NPO
C805
065G0805104 32
CAP CHIP 0805 0.1uF K 50V X7R
C824
065G0805104 32
CAP CHIP 0805 0.1uF K 50V X7R
C907
065G0805104 32
CAP CHIP 0805 0.1uF K 50V X7R
C916
065G0805104 32
CAP CHIP 0805 0.1uF K 50V X7R
C930
065G0805104 32
CAP CHIP 0805 0.1uF K 50V X7R
C931
065G0805104 32
CAP CHIP 0805 0.1uF K 50V X7R
C822
065G0805105 22
CAP CHIP 0805 1uF K 25V X7R
C928
065G0805122 31
CHIP CAP 0805 1200PF J 50V NPO
C841
065G0805152 31
1.5nF/50V
C840
065G0805152 31
1.5nF/50V
C839
065G0805152 31
1.5nF/50V
C838
065G0805152 31
1.5nF/50V
C911
065G0805224 22
CAIP CAP 0.22 uF 25V X7R
C909
065G0805224 22
CAIP CAP 0.22 uF 25V X7R
C845
065G0805225 12
CAP CHIP 0805 2.2UF K 16V X7R
C929
065G1206102 72
CAP CHIP 1206 1000PF K 500V X7R
C912
065G1206102 72
CAP CHIP 1206 1000PF K 500V X7R
D903
093G 64 38 P
BAW56
D808
093G 64 38 P
BAW56
D805
093G 64 38 P
BAW56
D806
093G 6432S
1N4148W
D817
093G 6432S
1N4148W
D915
093G 6432S
1N4148W
D916
093G 6432S
1N4148W
D809
093G 6432S
1N4148W
D814
093G 6432S
1N4148W
D803
093G 6433P
BAV99
D804
093G 6433P
BAV99
D802
093G 6433P
BAV99
55
D801
093G 6433P
BAV99
ZD922
093G 39S 25 T
RLZ5.1B LLDS
ZD902
093G 39S 61 T
DIODE RLZ16B ROHM
ZD921
093G 39S 61 T
DIODE RLZ16B ROHM
CN901
006G 31500
EYELET
T901
006G 31502
1.5MM RIVET
NR901
006G 31502
1.5MM RIVET
IC904
056G 158 10 T
IC AS431AZTR-E1 TO-92
R908
061G152M10452T6W56
RST MOFR 100KOHM 5% 2WS
R914
061G152M22852T6W56
RST MOFR 0.22 OHM +-5% 2WS
C938
065G 2K152 1T6921
1.5NF/2KV Y5P +-10%
C906
065G 2K152 1T6921
1.5NF/2KV Y5P +-10%
C908
067G215Y2207KT
CAP 105℃ 22UF M 50V KINGNICHI
FB901
071G 55 29
FERRITE BEAD
F901
084G 55 1W
FUSE 4A 250V Wickmann
D901
093G 6038P52T
PS102R
D900
093G1100 1152T
DIODE PR1007R 1A/1000V DO-41
715G2538 4
POWER BOARD PCB FR-1 160*124MM SS
56
Loading...
