22" LCD Color Monitor AOC 210S
Service
Service
Service
Horizontal Frequency
30-83 KHz
TABLE OF CONTENTS
Description Page Description Page
Table Of Contents.......……..............................…........1
Revision List.…........................................……......2
Important Safety Notice.……..................……......3
1.Monitor Specification..............................………........4
2.LCD Monitor Description…………………………….......5
3.Operation Instruction…………...............……...........6
3.1.General Instructions...........................…...........6
3.2.Control Button…………….…..............……...............6
3.3.OSD Menu…………….…...........................…............7
4.Input/Output Specification............……………............9
4.1.Input Signal Connector............………….................9
4.2.Factory Preset Display Modes..........................10
4.3.Panel Specification.....………………..................11
5.Block Diagram…..…...................…………................13
5.1.Software Flow Chart……..…………....….......13
SAFETY NOTICE
5.2.Electrical Block Diagram……………..….......15
6.Schematic……………......................................17
6.1 Main Board……..............................................17
6.2 Power Board....……....................................21
7.PCB Layout..………….......................................23
7.1.Main Board………........................................23
7.2 Power Board....……....................................26
7.3.Key Board…………….....................................28
8.Maintainability……….......................................29
8.1.Equipments and Tools Requirement...............29
8.2.Trouble Shooting…………..............................30
9.White-Balance, Luminance adjustment.............36
10.Monitor Explode View………..…….…............38
11.BOM List…………………………………............39
12.Different Parts List………………………………54
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
1

22" LCD Color Monitor AOC 210S
Revision List
Version Release Date Revision History TPV Model Name
TC6MMADBWQA5HP
A00 Jan.12, 2007 Initial release
TC6MMANQWQACHP
TC6MMANPWQXMHP
2

22" LCD Color Monitor AOC 210S
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performing service
operations. Some of these service operations require the use of tools specially designed for the purpose. The special
tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics may create shock,
fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from AOC. AOC
assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may result
in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)
3

22" LCD Color Monitor AOC 210S
1. Monitor Specifications
Driving system TFT Color LCD
LCD Panel
Response time (type) 5ms for CMO panel
Input
Power Consumption
Display Color 16.7M
Dot Clock 165MHz
Contrast Ratio 700:1
White Luminance 300cd/m
Max. Resolution 1680 x 1050
Size
Pixel pitch 0.282mm( H )x 0.282mm( V )
Viewable angle 170˚ (H) 160˚ (V)
Video R,G,B Analog Interface
Sync. Type H/V TTL
H-Frequency 30kHz – 83kHz
V-Frequency 55-75Hz
Active <49W
Standby <1W
2
558mm ( 22")
Plug & Play VESA DDC2BTM
Power Source 100~240VAC,47~63Hz
Input Connector
Input Video Signal Analog:0.7Vp-p(standard),75 OHM, Positive
Maximum Screen
Size
Environmental
Considerations
15-pin Mini D-Sub
Horizontal : 473.76mm
Vertical: 296.1mm
Operating Temp:0°C to 50°C
Storage Temp: -20°C to 60°C
Operating Humidity: 10% to 80%
4

22" LCD Color Monitor AOC 210S
2. LCD Monitor Description
The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic,
brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each
voltage.
Power board
Include: adapter, inverter)
AC-IN
100V-240V
Monitor Block Diagram
CCFL Drive.
Main Board
Key Board
Flat Panel and
CCFL backlight
HOST Computer
RS232 Connector
For white balance
adjustment in factory
mode
Video signal, DDC
5

22" LCD Color Monitor AOC 210S
3. Operating Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control buttons are located at the front of the panel
of the monitor.
By changing these settings, the picture can be adjusted to your personal preferences.
The power cord should be connected.
-
Connect the video cable from the monitor to the video card.
-
Press the power button to turn on the monitor, the power indicator will light up.
-
3.2 Control Buttons
3.2.1 Key Control
3.2.2 Key Function
1. DDC-CI
2. Auto Config
3. Eco Mode/ down
4. Up
5. Menu / Enter
6. Power Button & Indicator
OSD Settings
• Press DDC-CI button continuously for 7 seconds to turn on the DDC-CI function.
• Press the MENU-button to activate the OSD window.
• Press+ or - to navigate through the functions. Once the desired function is highlighted, press the MENU
button to activate it. If the function selected has a sub-menu, press or again to navigate through the
sub-menu functions. Once the desired function is highlighted, press MENU-button to activate it.
• Press+ or - to change the settings of the selected function. To exit and save, select the exit function. If you
want to adjust any other function, repeat steps 2-3.
• OSD Lock Function: To lock the OSD, press and hold the MENU button while the monitor is off and then
press power button to turn the monitor on. To un-lock the OSD - press and hold the MENU button while the
monitor is off and then press power button to turn the monitor on.
6

22" LCD Color Monitor AOC 210S
3.3 OSD Menu
Function Control Illustration
Luminance
Brightness Backlight Adjustment
Contrast Contrast from Digital-register.
Standard Standard Mode
Eco mode
Gamma
DCR
Image Setup
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Sports Sports Mode
Gamma1 Adjust to Gamma1
Gamma2 Adjust to Gamma 2
Gamma3 Adjust to Gamma 3
Off Disable dynamic contrast ratio
On Enable dynamic contrast ratio
Clock
Focus
H.Position Adjust the verticalposition of the picture.
V.Position Adjust the horizontal position of the picture.
Color Temp.
Warm Recall Warm Color Temperature from EEPROM.
Adjust picture Clock to reduce Vertical-Line
noise.
Adjust Picture Phase to reduce Horizontal-Line
noise
7

22" LCD Color Monitor AOC 210S
Normal
Cool Recall Cool Color Temperature from EEPROM.
sRGB Recall sRGB Color Temperature from EEPROM.
User-B Blue Gain from Digital-register
User-G Green Gain Digital-register.
User-R Red Gain from Digital-register
User
User-Y Yellow Gain from Digital-register
User-C Cyan Gain from Digital-register
User-M Magenta Gain from Digital-register
Color Boost
Full Enhance on or off Disable or Enable Full Enhance Mode
Nature Skin on or off Disable or Enable Nature Skin Mode
Green Field on or off Disable or Enable Green Field Mode
Sky-blue on or off Disable or Enable Sky-blue Mode
Recall Normal Color Temperature from
EEPROM.
AutoDetect on or off Disable or Enable AutoDetect Mode
Demo on or off Disable or Enable Demo
Picture Boost
Frame Size Adjust Frame Size
Brightness Adjust Frame Brightness
Contrast Adjust Frame Contrast
Hue Adjust Frame Hue
Saturation Adjust Frame Saturation
Position Adjust Frame Position
Bright Frame on or off Disable or Enable Bright Frame
OSD Setup
H.Position Adjust the verticalposition of OSD
V.Position Adjust the horizontal position of OSD
Timeout Adjust the OSD Timeout
Language Select the OSD language
Extra
Input Select
Auto Config Auto adjust the picture to default
Reset yes or no Reset the menu to default
Information
Digital Select Digital Sigal Source as Input
Analog Select Analog Sigal Source as Input
Show the information of the main image and
sub-image source
8

22" LCD Color Monitor AOC 210S
4. Input/Output Specification
4.1 Input Signal Connector
Analog connectors
Pin No. Description Pin No. Description
1. Video-Red 9. +5V
2. Video-Green 10. Detect Cable
3. Video-Blue 11. NC
4. NC 12. DDC-Serial Data
5. GND 13. H-Sync
6. GND-R 14. V-Sync
7. GND-G 15. DDC-Serial clock
8. GND-B
VGA connector layout
15
6
11 15
10
9

22" LCD Color Monitor AOC 210S
4.2 Factory Preset Display Modes
VESA MODES
Horizontal Vertical
Mode Resolution Total
640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
VGA
SVGA
XGA
640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500
640x480@75Hz 840 x 500 37.500 N 75.00 N 31.500
800x600@56Hz 1024 x 625 35.156 N/P 56.250 N/P 36.000
800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
800x600@72Hz 1040 x 666 48.077 P 72.188 P 50.000
800x600@75Hz 1056x625 46.875 P 75.000 P 49.500
1024x768@60Hz 1344x806 48.363 N 60.004 N 65.000
1024x768@70Hz 1328x806 56.476 N 70.069 N 75.000
1024x768@72Hz 1304x798 57.7 P 72 P 78.4
1024x768@75Hz 1312x800 60.023 P 75.029 P 78.750
1280x1024@60Hz 1688x1066 63.981 P 60.020 P 108.000
Frequency
+/- 0.5kHz
Nominal
Sync
Polarity
Nominal
Freq.
+/- 1 Hz
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
1280x1024@70Hz 74.4 P 70 P 124.9
SXGA
WSXGA 1680x1050@60Hz 2240x1089 65.29 N 59.95 P 146.25
Horizontal Vertical
DOS 720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
DOS 640x350@70Hz 800 x 449 31.469 P 70.087 N 25.175
XGA 1024x768@72Hz 1304 x 798 57.515 P 72.1 P 75.000
VGA 640x480@67Hz 864x525 35.000 N 66.667 N 30.240
SVGA 832x624@75Hz 1152x667 49.725 N 74.551 N 57.2832
XGA 1024x768@60Hz 1312x813 48.780 N 60.001 N 64.000
1024x768@75Hz 1328x804 60.241 N 74.927 N 80.000
1280x1024@72Hz 77.9 P 72 P 134.6
1280x1024@75Hz 1688x1066 79.976 P 75.025 P 135.000
1280x960@60Hz 1800x1000 60 P 60 P 108
IBM MODES
MAC MODES
10

22" LCD Color Monitor AOC 210S
4.3 Panel Specification
4.3.1 General Features
The M220Z1-L01 model is a 22 inch wide TFT-LCD module with a 4-CCFL Backlight Unit and a 30-pin
2ch-LVDS interface. This module supports 1680 x 1050 WSXGA+ (16:10 wide screen) mode and displays
up to 16.7 millions colors. The inverter module for the Backlight Unit is not built in.
4.3.2 Features
- Super wide viewing angle
- High contrast ratio
- Fast response time
- High color saturation (EBU Like Specifications)
- WSXGA+ (1680 x 1050 pixels) resolution
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
4.3.3 Display Characteristics
11

22" LCD Color Monitor AOC 210S
4.3.4 Optical Characteristics
4.3.5 Electrical Characteristics
(1) TFT-LCD
(2) Backlight
12

22" LCD Color Monitor AOC 210S
5. Block Diagram
5.1 Software Flow Chat
1
2
N
4
5
Y
6
7
Y
Y
N
N
3
18
9
10
Y
N
N
12
Y
14
19
N
13
15
11
17
N
Y
N
Y
16
Y
13

22" LCD Color Monitor AOC 210S
1) MCU initialize.
2) Is the EPROM blank?
3) Program the EPROM by default values.
4) Get the PWM value of brightness from EPROM.
5) Is the power key pressed?
6) Clear all global flags.
7) Are the AUTO and SELECT keys pressed?
8) Enter factory mode.
9) Save the power key status into EPROM.
Turn on the LED and set it to green color.
Scalar initializes.
10) In standby mode?
11) Update the lifetime of back light.
12) Check the analog port, are there any signals coming?
13) Does the scalar send out an interrupt request?
14) Wake up the scalar.
15) Are there any signals coming from analog port?
16) Display "No connection Check Signal Cable" message. And go into standby mode after the message
disappear.
17) Program the scalar to be able to show the coming mode.
18) Process the OSD display.
19) Read the keyboard. Is the power key pressed?
14

22" LCD Color Monitor AOC 210S
5.2 Electrical Block Diagram
5.2.1 Main Board
Panel Interface
Flash Memory
PM25LV010-25 SCE
(U402)
24LC16B/SNG
SDA
SCL
EEPROM
(U403)
Scalar TSUMU58WHJ-LF
(Include MCU, ADC, OSD)
Crystal
14.318MHZ
(X401)
(CN101)
(U401)
H sync
V sync
RGB
D-Sub
Connector
(CN405)
Key Control
Interface
(CN403)
EEPROM
M24C02
(U404)
VGA_SDA,
SCL
VGA
15

22" LCD Color Monitor AOC 210S
5.2.2 Inverter/Power Board
AC input
EMI filter
Bridge
Rectifier
and Filter
Transformer
Rectifier
diodes
Lamp
Start Circuit: R927、R928、R929
PWM
Control IC
Output
Circuit
Feedback
Circuit
Transformer
Over
Voltage
Feedback
Circuit
MOSFET
PWM
Control IC
ON/OFF
Control
DIM
DIM
CN903
24V
12V
ON/OFF
16

22" LCD Color Monitor AOC 210S
6. Schematic
6.1 Main Board
715G2186-1
+5V
C701
0.1uF
+12V
+12V
C706
0.1uF
on_Panel4
SOT-223
U701
3 2
VI VO
GND
NC
1
+5V
1 2
C707
+
NC
C709
0.1uF
+3V3
R716
NC
C703
+
NC
L702
120 OHM
GND
GND
GND
GND
C710
+
100uF/ 25V
10K 1/10W
R717
10K 1/10W
R725 4.7K 1/10W
C718
NC
+5V
11
C704
NC
1
3
5
7
9
3,4
CONN
+3V3
CN701
+5V
R714
2
4
6
8
10
12
Q706
NC
+5V
+5V3,4
D704
SR24
C713
0.1uF
Reservation schematicfor blacklight off have
panel on solution.
BL_ADJ
+12V
GND
GND
+3V3
R715
NC
PMBS3906
R713 NC
R709 15K 1/10W
C711
0.1uF
R723
10K 1/10W
Q705
TO-263
U702
3
VIN
1
ADJ
AIC 1084-33PM
+5V
+
R708
10K 1/10W
Q703
PMBS3904
C715
0.022uF
VOUT
C722
22uF/ 50V
R710 N C
VLCD
C719
0.1uF
C717
100uF/ 25V
2
+
100uF/ 25V
R705
4.7K 1/10W
C708
NC
R712
4.7K 1/10W
Q704
AO3401
R721
0 1/10W
+
C712
VLCD 5
+5V
10K 1/10W
VCC3.3
C714
0.1uF
+5V
+3V3
R727
R702
51 1/10W
VCC1.8
+
R703
2K 1/10W
VCC3.3 4
VCC3. 3 4
R701
1K 1/10W
Q701
PMBS3904
+5V
R711
10K 1/10W
R722
NC
Tit le
D702
LL4148
R706 NC
R704
100 1/10W
R707
4.7K 1/10W
C702
4.7uF /50V
D701
GS1D
Q702
PZT2907A
VCC3. 3
Adj_BACKLI GHT 4
on_BACKLIGH T 4
POWER
Size Docum ent Number Rev
Custom
Date : Sheet
715G2186-1
25Thursday , Oct ober 12, 2006
VCTRL 4
VCC1.8 4
of
B
17

22" LCD Color Monitor AOC 210S
1716
CN406
RGB GND
SYN C GND
DDC SDA
JACK
HSYNC
VSYN C
DDC SCL
+5V
HPD
1/3s hield
2/4s hield
0/5s hield
clk shield
DAT0+
DAT0-
DAT1+
DAT1-
DAT2+
DAT2-
DAT3+
DAT3-
DAT4+
DAT4-
DAT5+
DAT5-
clk+
clk-
GND
GND
32
31
R
G
B
CN405
11
12
13
14
15
1 2
25
26
27
29
28
8
15
6
7
14
16
11
3
19
22
18
17
10
9
2
1
13
12
5
4
21
20
23
24
HSI
VSI
D408
ZMM5V6
RED+ FB410 0 1/ 10W
1
6
RED-
2
GREEN+
GREEN-
7
3
BLUE+
BLUE-
8
4
9
5
10
DB15
SCL_DVI
SDA_DVI
DVI5V
HPD
DAT0+
DAT0DAT1+
DAT1DAT2+
DAT2-
DCLK+
DCLK-
VGA_CON
1 2
2
PC5V
PC5V
D406
ZMM5V6
1 2
2
C439
0.047uF
FB409 430 OHM
D409
ZMM5V6
+5V
R472
NC
1 2
3
3
D417
BAV99
C447
C448
1
2
0.1uF
0.1uF
D403
BAV99
1
1
3
D404
BAV99
2
C440
0.047uF
1 2
3
D419
BAV99
C449
1
2
0.1uF
3
R471
10K 1/10W
R458 100 1/ 10W
D426
ZMM5V6
D418
BAV99
1
D414
ZMM5V6
2
0.1uF
3
2
C441
0.047uF
R448
2.2K 1/10W
DET_DVI 4
3
D420
BAV99
C450
2
1
D405
BAV99
FB411 0 1/ 10W
FB412 0 1/ 10W
75 1/10W
ESD_5V
1
C442
22pF
R455 100 1/ 10W
R456 100 1/ 10W
D415
ZMM5V6
1 2
3
D421
BAV99
C451
1
2
0.1uF
R438
R446 1K 1/ 10W
R449
2.2K 1/10W
D416
ZMM5 V6
1 2
3
3
D422
BAV99
C453
C452
1
2
0.1uF
0.1uF
R439
75 1/ 10W
R447 1K 1/ 10W
C443
220pF
D411
ZMM5V6
1 2
DVI5V
3
D423
BAV99
C454
2
1
0.1uF
R434 56 1/ 10W
R435 56 1/ 10W
R436 56 1/ 10W
R437 470 1/ 10W
R440
75 1/ 10W
R441 100 1/ 10W
R442 100 1/ 10W
R443 100 1/ 10W
+5V
R444
10K 1/ 10W
D410
ZMM5 V6
1 2
D412
ZMM5 V6
1 2
R457 10K 1/10W
C445
0.1uF
R462 10 1/ 10W
R463 10 1/ 10W
R464 10 1/ 10W
R465 10 1/ 10W
R466 10 1/ 10W
R467 10 1/ 10W
R468 10 1/ 10W
R469 10 1/ 10W
D424
BAV99
1
+5V 2,4
R445 100 1/ 10W
Q406
NC
R401
NC
ESD_5V
B+ 4
B- 4
G+ 4
G- 4
R+ 4
R- 4
CLK+ 4
CLK- 4
C432 0. 047uF
C433 0. 047uF
C434 0. 047uF
C435 0. 001uF
C436 0. 047uF
C437 0. 047uF
C438 0. 047uF
SCL_VGA
SDA_VGA
HDCP_RST 4
+5V
R470
1K 1/ 10W
D425
RLZ36B
1 2
RIN 4
GIN 4
BIN 4
SOG 4
GNDR 4
GNDG 4
GNDB 4
PC5V
10K 1/10W
R451
10K 1/ 10W
R461
R460
10K 1/10W
10K 1/ 10W
INPUT
R452
+5V
1
2
D407
BAV70
3
U404
8
7
6
+5V
DVI5V
1
2
D413
BAV70
3
8
7
6
R473
NC
A0
VCC
A1
WP
A2
SCL
GNDSDA
M24C02-WMN6TP
U405
A0
VCC
A1
WP
A2
SCL
GNDSDA
M24C02-WMN6TP
715G2186-1
C444
0.1uF
1
2
3
45
DDC_WP 4
C446
1
0.1uF
2
3
45
DDC_WP 4
B
of
35Thursday , October 12 , 2006
DET_VGA 4
HSYNC 4
VSYN C 4
R450
10K 1/10W
R453 100 1/ 10W
R454 100 1/ 10W
DDCA_SDA4
DDCA_SCL4
DDCD_SDA4
DDCD_SCL4
R459
10K 1/10W
Tit le
Size Document Number Rev
B
Date: Sheet
18

22" LCD Color Monitor AOC 210S
GND
62
40
59
114
54
VDDP
VDDP
VDDP
GPIO_P14/P WM0
GPIO_P22/P WM1
GPIO_P24/P WM2
GPIO_P00/SAR0
GPIO_P01/SAR1
GPIO_P02/SAR2
GPIO_P03/SAR3
GPIO_P13/P WM2
GND
113
FB407
NC
FB408
NC
1
3
5
7
9
11
13
87
VDDP
CN404
VDDP
112
107
VDDP
VDDP
LVACKP
LVACKM
LVBCKP
LVBCKM
GPIO_P04
GPIO_P25
GPIO_P06
GPIO_P07
GPIO_P15
GPIO_P16
I2C_MCL
I2C_MDA
GPIO_P47
GPIO_P46
GPIO_P45
GPIO_P44
GPIO_P43
GPIO_P42
VCTRL
VDDP
NC
LVA4P
LVA4M
LVA3P
LVA3M
LVA2P
LVA2M
LVA1P
LVA1M
LVA0P
LVA0M
LVB4P
LVB4M
LVB3P
LVB3M
LVB2P
LVB2M
LVB1P
LVB1M
LVB0P
LVB0M
VDDP
VDDP
VDDP
VDDP
+12V
+5V
2
4
6
8
10
12
14
103
75
76
PA0
77
PA1
78
79
PA2
PA3
80
PA4
81
PA5
82
PA6
83
PA7
84
PA8
85
PA9
86
89
90
PB0
91
PB1
92
PB2
93
PB3
94
PB4
95
PB5
96
PB6
97
PB7
98
99
PB8
PB9
100
2
36
51
73
109
R411 100 1/10W
119
R418 100 1/10W
120
R420 100 1/10W
121
122
R422 4. 7K 1/10W
123
R423 4. 7K 1/10W
124
125
3
4
VDDP
60
65
66
71
39
38
C458
0.1uF
VCC3.3
50
49
48
47
R491 NC
46
45
HDCP_WP
+12V 2
+5V 2,3
R484
NC
R488 100 1/10W
C457
R424
0.1uF
10K 1/ 10W
C459
0.1uF
R492
HDCP_SCL
NC
HDCP_SDA
HDCP_RST3
on_BACKLIGHT 2
R499 NC
+5V
R485
NC
AUDIO_STBY
AUDIO_MUTE
OUT-R+
OUT-R-
VCC3.3
C460
0.1uF
VCTRL 2
PA[0..9]
PB[0..9]
Volume
WP
AUDIO_STBY
AUDIO_MUTE
R425
10K 1/ 10W
R428 100 1/ 10W
R429 100 1/ 10W
R481
NC
KEY_B
LED_G
KEY_AUTO
KEY_RI GHT
POWER
OUT-L+
OUT-L-
PA[0..9] 5
PB[0..9] 5
POWER
KEY1
KEY2
R426
10K 1/10W
R427 100 1/10 W
VCC3.3
R482
NC
Q405
NC
CN403
1
3
5
7
9
11
13
15
CONN
DET_VGA 3
on_PANEL 2
adj_BACKLIGHT 2
DET_DVI 3
8
7
6
R483
NC
2
4
6
8
10
12
14
16
VCC
WP
SCL
24LC16B/SN G
FB405
R413
GNDSDA
C462
NC
(Source)
AVDD_MEMPLL_33
600 OHM
FB404
600 OHM
4.7uF/50V
10K 1/10W
A0
A1
A2
C416
0.1uF
AVDD_18
+
C464
R405
22K 1/ 10W
10K 1/ 10W
VCC3.3
R414
120 1/ 10W
Q401
PMBS3906
R421 0 1/ 10W
C425
1
0.22uF
2
3
45
KEY_A
LED_G
POWER
KEY_AU TO KEY_C
C455
0.1uF
VCC3.3
VCC1.8
U403
KEY_A
LED_A
KEY_MENU KEY_LEFT
KEY_LEFT
KEY_C
OUT-R+
OUT-R-
R406
C426
0.1uF
LED_G
LED_A
POWER
KEY2
KEY1
C427
0.1uF
0.1uF
LED_G
1
3
5
7
9
C422
VCC3.32
C428
0.1uF
CN402
NC
Q402
PMBS3904
R475
3.9K 1/10W
C429
0.1uF
2
4
6
8
10
10K 1/10W
VCC3.3
LED_A
KEY_MENU
KEY_RI GHT
VCC3.3
R408
D401
1 2
RLZ36B
FB403
VDDP
600 OHM
+
C408
10uF/50V
VCC1.82
DDC_WP 3
VCC3.3
R409
120 1/10W
Q403
PMBS3906
R419 0 1/10W
R474
3.9K 1/10W
R476
1KΩ 1/10W
R477
1KΩ 1/10W
C430
D402
RLZ36B
0.1uF
1 2
Tit le
Size Document Number Rev
Custom
Date: Sheet
C409
0.1uF
LED_A
R500
0Ω 1/10W
C410
0.1uF
VCC1.8
VCC3.3
R478
1KΩ 1/10W
R479
1KΩ 1/10W
SCALER
C411
0.1uF
FB401
600 OHM
4.7uF/ 50V
FB402
600 OHM
R480 NC
C403
C412
0.1uF
C407
0.1uF
C413
C419
0.1uF
0.1uF
VDDC
+
C404
0.1uF
AVDD_33
C414
0.1uF
KEY_AUTO
KEY_RI GHT
KEY_A
KEY_B
KEY_MENU
KEY_LEFT
KEY_C
715G2186-1
C405
0.1uF
C420
0.1uF
C415
0.1uF
C406
0.1uF
C461
0.1uF
C402
0.1uF
B
of
45Thursday , October 12, 20 06
+5V
DDCA_SDA3
DDCA_SCL3
C417
0.22uF
C418
10uF/50V
Res e t
Circuit
VCC3.3
R489
10K 1/ 10W
VCC3.3
R486
NC
+5V
+
R404
10K 1/ 10W
U406
NC
RSTVCC
GND
1
C463 NC
U407
1
A0
2
A1
3
A2
4 5
GND SDA
NC
Volume
R49010K 1/ 10W
DDCD_SDA3
DDCD_SCL3
AVDD_33
8
7
3
4 5
R487
10K 1/10W
14.31818MHz
23
VCC
WP
SCL
R410 NC
RIN3
GNDR3
GIN3
GNDG3
SOG3
BIN3
GNDB3
HSYNC3
VSYNC3
R+3
R-3
G+3
G-3
B+3
B-3
CLK+3
CLK-3
R403 390 1/1 0W
U402
VDD
HOLD#
WP#
VSS SDI
PM25LV010-25SCE
C421 22pF
X40 1
C423 22pF
VDDP
10K 1/10W
VCC3.3
8
7
R493 N C
6
R494 N C
R495 N C
For HDCP
R402
NC
SDO
CE#
SCK
WP
R407
NC
R415
+5V
C401
0.1uF
2
1
6
R501
0Ω 1/10W
R502
0Ω 1/10W
R412
NC
Q407
NC
AVDD_33
28
RIN0P
27
RIN0M
25
GIN0P
24
GIN0M
26
SOGIN0
23
BIN0P
22
BIN0M
32
HSYNC0
33
VSYNC 0
34
DDCA_SDA/RS232_TX
35
DDCA_SCL/RS232_RX
9
RX2P
10
RX2N
12
RX1P
13
RX1N
15
RX0P
16
RX0N
18
RXCKP
19
RXCKN
5
DDCD_SDA
6
DDCD_SCL
7
REXT
31
REFP
30
REFM
41
SDO
42
CSZ
43
SCK
44
SDI
108
RST
128
XIN
127
XOU T
102
BYPASS
C456
0.1uF
37
MODE
57
NC
56
NC
55
NC
61
NC
64
NC
67
NC
70
NC
118
NC
110
NC
111
NC
115
NC
116
NC
117
NC
R416
R417
NC
NC
HDCP_SCL
HDCP_SDA
R431 NC
R433 NC
8
GND
1
11
R496
NC
HDCP_WP
R497
NC
+5V
AVDD_33
GND
VDDC
14
53
20
AVDD_33
AVDD_33
GND
GND
GND
172952
7288101
R430
NC
R432 NC
Q404
NC
VDDC
GND
AVDD_18
AVDD_MEMPLL_33
104
74
126
21
58
VDDP
VDDC
VDDC
VDDC
AVDD_18
TSUMU58WJ
LVDS
GND
GND
GND
GND
GND
GND
GND
106
105
686963
OUT-L+
OUT-L-
C431
NC
19

22" LCD Color Monitor AOC 210S
CN101
PA[0..9]4
PB[0..9]4
PA[0..9]
PB[0..9]
PA0
PA1
PA2
PA3
PA4
PA6
PA7
PA8
PA9
PB0
PB1
PB2
PB3
PB4
PB5
PB6
PB7
PB8
PB9
LVA3P
LVA3M
LVACKP
LVACKM
LVA2P
LVA2M
LVA1P
LVA0P
LVA0M
LVB3P
LVB3M
LVBCKP
LVBCKM
LVB2P
LVB2M
LVB1P
LVB1M
LVB0P
LVB0M
LVB0M
LVB1M
LVB2M
LVBCKM
LVB3M
LVA0M
LVA1M
LVA2MLVA1M
LVACKM
LVA3M
22uF/50V
C720
RXO0RXO1RXO2RXOCRXO3RXE0RXE1RXE2RXECRXE3-
VLCD
L703
120 OHM
1 2
+
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
CONN
R720
150 1/4W
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
VLCD 2
R719
150 1/4W
RXO0+
RXO1+
RXO2+
RXOC+
RXO3+
RXE0+
RXE1+
RXE2+
RXEC+
RXE3+
C721
0.1uF
LVB0P
LVB1P
LVB2P
LVBCKP
LVB3P
LVA0PPA5
LVA1P
LVA2P
LVACKP
LVA3P
Tit le
PA NEL INTERFA CE
Size D ocum ent N umber Rev
A
Date: Sheet
715G2186-1
of
55Thursday , Oct ober 12, 2006
20
B

22" LCD Color Monitor AOC 210S
6.2 Power Board
715G2101-2
R905 100 1/4W
SP10150
4
3
2
1
+
10
12
14
R906 100 1/ 4W
R907 100 1/ 4W
D907
3
2
1
100 1/ 4W
+
C951
470UF/50V
D801
C958
N.C
CN903
2
4
6
8
CONN
+
+
C952
N.C
SBM84PT
5.25~5.3V
0.06~3A
100mVpp/ 20MHz
1
3
5
7
9
11
13
C953
470UF/50V
+5V
L954
2.13uH
L801
22uH
R804
D802
22 1/ 4W
N.C
C810
0.001uF
R802
62K 1/ 10W
R803
20K 1/ 10W
+5V
R957
220 2W
C957
0.1uF
D950
28.1V(26.7~29.5V)
SMAJ24A
1 2
12V
L953
95G 90 23
C804
0.001uF
C805
470pF
+
+
C806
470uF/16V
C955
N.C
R9757
2K 1/ 4W
+12V'
+
D9553
LL4148
D9757
LL4148
D9756
LL4148
R9758
3.3K 1/4W
PMBS3904
C807
470uF/16V
Q957
+12V
F904
95G 90 23
43
22.0~30V
0~1.4A
240mVpp/20MHz
C808
0.001uF
ZD9753 MTZJ T-72 33B
1 2
ZD9755 MTZJ6. 2B
1 2
ZD9754 MTZJ T-72 15B
1 2
VCC1
R9760
6.8K 1/16W
12
PC953
PC123X2YFZOF
R9759
2K 1/ 4W
+24V
+12V
11.4~13.0V
0.05~1A
150mVpp/20MHz
C9753
0.47uf 16v
PF
+24V
+5V
+12V
Q958
2N5060RLRAG
R901
680K 1/ 4W
L904
L
C911
N.C
1
C901
1000PF/250V
C915
N.C
2
1
3
1 2
R911
N.C
R912
N.C
R913
N.C
VCC3
N.C
R930
NC
R914
N.C
C919
N.C
BD901
4
GBU805
3
-+
2
3
L902
JUMP WIRE
4
VR901
varistor
R902
R903
680K 1/ 4W
680K 1/ 4W
C907
0.22uF/275V
L901
142
7.0mH
C906
0.22uF/275V
1000PF/250V
C902
CN901
SOCKET
3
J928
0
J927
0
7 6
R918
NC
IC901
8 7
VCC OUT
3 4
MUL I S
GND ZCD
COMP
1
2
6 5
C916
N.C
RT901
NTCR
L903
L
F901
FUSE
C908
1
2
3
4
8
7
6
5
L952
95G 90 23
ON/OFF
R965
C966
0.001uF
S
S
S
G
AO4411L
IC801
LM3485
VIN
PGATE
PWGND
ADJ
+12V
DIM
SRF20200C
Q801
D
D
D
D
ISENSE
AGND
0.001uF
R964
NC
100 1/ 4W
R966
3
1
8
7
6
5
FB
N.C
D952
2
Q902
STP10NK70ZFP
R941
0.2 2W
1
3
4
6
C802
1uF/25V
R801
36KΩ 1/10W
T901
POWER X'FMR
C905
3300PF/250V
C803
0.001uF
7
10
11
12
9
8
C809
0.1uF
D901
95G 90 23
L911
N.C
.
1 10
R919
N.C
D903
N.C
FB
C917
N.C
VCC3
R961
NC
N.C
2
Q901
N.C
1
R925
N.C
3
R920
N.C
R921
N.C
C918
N.C
R926
N.C
Q955
NC
R959
NC
R962
NC
12
43
PC952
N.C
Q956
NC
C921
+
+
R923
R924
N.C
R939
N.C
R963
NC
C912
100uF/450V
N/C
1
2
12
3
C920
0.001uF
R908 10 1/4W
C940
22uF/50V
Q954
NC
4 5
ZD952
N.C
PF
+
12V
ON/OFF
IC902
RT
COMP
CS
GNDOUT
LD7575PS
TL431ACLPR
R958
0 1/8W
ZD951
0.1uF
HV
NC
VCC
43
TL951
R927
4.7K 1/4W
C913
0.0022uF/1KV
R928
4.7K 1/4W
R929
4.7K 1/4W
8
7
6
VCC1
R951
470 1/ 4W
12
PC951
PC123X2YFZOF
R954
2.4K 1/10W
3
1
R953 2.7K 1/10W
2
VCC1
+
C970
N.C
12V
R904
33K 1/ 10W
D906
FR107
C8530.1uF
CN801
CONN
R940
100K 2W
D905 LL4148
10 1/ 4W
C930
470pF
+12V'
C961
0.1uF
1
2
3
4
5
6
7
8
9
10
11
12
13
D904
FR107
R938
R952
12K 1/ 4W
R943
470 1/ 4W
5V/2.5A
+24V
R956
130K 1/ 10W
+
C801
220uF/25V
Title
22" LCD Monitor
Size Doc ument Number Rev
G2101-1-X-X-1-060815
Date: Sheet of
1
11Tuesday, Augus t 15, 2006
21

22" LCD Color Monitor AOC 210S
CN801
1
C801
5pF/3KV
T801
5 7
C809
N.C
2 8
POWER X'FMR
N.C
J209
C803
5pF/3KV
T803
C824
5 7
N.C
2 8
POWER X'FMR
NC
N.C
J211
J210
T804
5 7
2 8
POWER X'FMR
N.C
J212
T805
5 7
2 8
POWER X'FMR
C804
5pF/3KV
C838
N.C
C805
5pF/3KV
C845
N.C
D820
RB050L-40
Q803
AM4541
G2P D2P
S2P
D2P
G1N
D1N
S1N
D1N
D821
RB050L-40
D822
G2P D2P
S2P
D2P
G1N
D1N
S1N
D1N
D823
N.C
D824
Q805
N.C
4 5
G2P D2P
3
S2P
D2P
2
G1N
D1N
1
S1N
D1N
D825
N.C
D826
RB050L-40
4 5
G2P D2P
3
S2P
D2P
2
G1N
D1N
1
S1N
D1N
D827
RB050L-40
C807 1uF
C808 N.C
6
7
8
C816 N.C
C817 1uF
6
Q804
7
N.C
8
J212
0 1/4W
C834 N.C
C836 1uF
C840 1uF
6
7
8
C841
N.C
6
Q806
7
AM4541
8
+24V
ON/OFF
IC_DIM
R810
0Ω 1/10W
R812
DIM
200K 1/16W
C822
0.1uF
R815
75K 1/10W
OPT2
OPT3
OPT4
R813
200K 1/10W
C829
R821 NC
RK7002
C821
C823
R818 NC
C828
1uF/25V
C832 0.1uF
C837
NC
R824
39K 1/10W
D815
LL4148
D816
LL4148
D817
LL4148
C814
0.1uF
2MΩ 1/8W
1uF/25V
0.47UF/16V
C854
0.1uF
R801
2.4KΩ 1/4W
Q801
DTA144WKA
Q807
ZD803
RLZ5.6B
OVP
1 2
10 1/4W
R846
0 1/8W
C835
0.0068uF
R840
1MΩ 1/10W
R816
C818
1uF/25V
1
2
3
4 17
5
6
7
8
9
10
R831
1M 1/ 8W
R838
1MΩ 1/10W
C852
0.1uF/50V
R841
C855
1MΩ 1/10W
0.1uF
IC801
CTIMR
OVP
ENA
SST RT
VDDA
GNDA
REF
RT1
FB
CMP
OZT1060GN
R802
100 1/4W
Q802
PMBS3904
R809
Q811
RK7002
Q812
RK7002
Q813
RK7002
C819
1uF/25V
R825
N.C
VDD
10K 1/10W
NDR_B
PDR_A
PDR_C
NDR_D
PGND
LPWM
VDD
R811
CT
LCT
DIM
43K 1/10W
C850
NC
C847
0.1uF
D810
LL4148
10K 1/10W
20
19
18
16
15
14
13
12
11
R827
Q809
RK7002
C831
470UF/50V
+
C843
C826 220pF
R819 NC
R820 51K 1/8W
IC_DIM
R845
33K 1/8W
RJ202
0Ω 1/10W
R830
51K 1/10W
R835
10K 1/16W
NC
+
R826
0Ω 1/10W
C815
0.1uF
C830
C827 0.1uF
RJ203
N.C
R836
0.0068uF
C833 0.1uF
R844
0Ω 1/10W
R834
1K 1/10W
NC
Q808
PMBS3906
R806
10KΩ 1/8W
ZD802
RLZ5.6B
R805
ZD801
10KΩ 1/8W
RLZ5.6B
1 2
1 2
4 5
3
2
1
N.C
4 5
3
2
1
N.C
C820
0.0047uF
C825
0.0047uF
C839
0.0047uF
C846
0.0047uF
R839
1M 1/16W
3
D801
BAV99
1
2
3
D806
BAV99
1
2
3
D808
BAV99
1
2
3
D809
BAV99
1
2
OVP
C853
0.1uF
3
D805 BAV99
1
3
D807 BAV99
1
3
1
R814
1KΩ 1/8W
2
R822
1KΩ 1/8W
2
OPT6
R829
1KΩ 1/8W
D812
BAV99
2
2
OPT2
CONN
R804
1KΩ 1/8W
3
D803
BAV99
N.C
R803
R807
1
2
470 1/10W
CN802
1
2
OPT3
CONN
N.C
R808
R817
470 1/10W
CN803
1
2
OPT4
CONN
N.C
R848
R823
470 1/10W
CN804
1
2
CONN
N.C
R849
R832
470 1/10W
D819
OPT6
LL4148
Q815
RK7002
R843
C857
1MΩ 1/10W
0.1uF
Titl e
Size D ocument Number Rev
<Doc>
C
G2101-1-X-X-1-060815
Date: Sheet
<RevC ode><Title>
1
13Tuesday, Augus t 15, 2006
of
22

22" LCD Color Monitor AOC 210S
8. Maintainability
8.1 Equipments And Tools Requirement
1. Voltmeter.
2. Oscilloscope.
3. Pattern Generator.
4. DDC Tool with an IBM Compatible Computer.
5. Alignment Tool.
6. LCD Color Analyzer.
7. Service Manual.
8. User Manual.
29

22" LCD Color Monitor AOC 210S
8.2 Trouble Shooting
8.2.1 Main Board
No power
Press power key and look
if the picture is normal
NG
Please reinsert and make sure
the AC of 100-240 is normal
OK
NG
Reinsert or check the
Adapter/Inverter
section
Measure U702 PIN2=3.3V
D701 (-) =1.8V
OK
NG
Check CN701 or replace
U702,Q702 or D701
X401 oscillate waveforms
are normal
OK
NG
Replace X401
Replace U401
30

22" LCD Color Monitor AOC 210S
(2). No Picture
No picture
Measure U702 PIN2=3.3V
D701(-)=1.8V
OK
NG
Replace U702, Q702 or
D701
X401 oscillate waveforms are normal
OK
NG
Replace X401
Check if the sync signal from
computer is output and video cable
OK
NG
Input the sync signal of
computer, or change
Replace U401
31

22" LCD Color Monitor AOC 210S
(3). White screen
Check Correspondent
com
onent.
White screen
Measure Q704 base
is high level?
OK
Check Q704 is broken or
CN101 solder?
NG
OK
Replace Panel
NG
X401 oscillate
waveform is normal
NG
OK
Check reset circuit of
U401 is normal
NG
OK
Replace U401
Replace X401
Check Correspondent
com
onent.
32

22" LCD Color Monitor AOC 210S
8.2.2 Power/Inverter Board
1.) No power
Check CN903 pin2, 4 = 12V
NG
Check AC line volt 110V or 220V
OK
NG
Check AC input
Check the voltage of C912 (+)
OK
NG
Check bridge rectified circuit and F901 circuit
Check start voltage for the pin8 of IC902
OK
NG
Check R927, R928, R929 and Change IC902
Check the auxiliary voltage is bigger than
10V and smaller than 20V
OK
NG
1) Check IC902
2) Check IC902 over current protect circuit
Check IC902 pin5 PWM wave
OK
NG
Check IC902
Check Q902, D907, D952, PC951 and T901
33

22" LCD Color Monitor AOC 210S
2.) W / LED, No Backlight
Check CN903 pin2 = 12V
OK
NG
Check adapter or MB
Check ON/OFF signal
OK
NG
Check Interface board
Check IC801 pin5=5V
OK
NG
Change Q801 or Q802
Check IC801 PIN18, 17 have the output of square wave at short
OK
NG
Check C826, R820 and IC801
Check D820, D821, D826 and D827 have the output of
square wave at short time.
OK
NG
Check Q803, Q806
Check the input wave of pin2 & pin5 for T801, T803, T804 and T805
OK
NG
Check C807, C817, C836, C840
Check the output of T801, T803, T804 and T805
OK
NG
Check T801, T803, T804 and T805
Check connecter & lamp
34

22" LCD Color Monitor AOC 210S
8.2.3 Keypad Board
Is Key Pad Board connecting normally?
OSD is unstable or not working
Y
Is Button Switch normally?
Y
Is Key Pad Board normally?
Y
N
Connect Key Pad Board
N
Replace Button Switch
N
Replace Key Pad Board
Check Main Board
35

22" LCD Color Monitor AOC 210S
9. White- Balance, Luminance Adjustment
Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment.
Before started adjust white balance , please set the Chroma-7120 MEM Channel 3 to Warm (6500K)
color, MEM Channel 4 to Normal (7300K) color, MEM Channel 9 to Cool (9300K) color , and MEM
Channel 10 to sRGB color ( our Warm color parameter is x = 313 ±20, y = 329 ±20, Y=180cd/m
Normal color parameter is x = 301 ±20, y = 317 ±20, Y=180cd/m
= 297 ±20, Y=180cd/m
2
; sRGB color parameter is x = 313 ±20, y = 329 ±20, Y= 180cd/m2)
2
; Cool color parameter is x = 283 ±20, y
How to setting MEM channel you can reference to chroma 7120 user guide or simple use “ SC” key and
“ NEXT” Key to modify xyY value and use “ID” key to modify the TEXT description Following is the procedure
to do white-balance adjust .
2. Setting the color temp. you want
A. MEM.CHANNEL 3 (Warm color):
Warm color temp. parameter is x = 313 ±20, y = 329 ±20, Y=180cd/ m
2
B. MEM.CHANNEL 4 (Normal color):
Normal color temp. parameter is x = 301 ±20, y = 317 ±20, Y=180cd/ m
2
2
;
C. MEM.CHANNEL 9 (Cool color):
Cool color temp. parameter is x = 283 ±20, y = 297 ±20, Y=180cd/m
D. MEM.CHANNEL 10 (sRGB color):
2
sRGB color temp. parameter is x = 313 ±20, y = 329 ±20, Y= 180cd/m2
3. Into Factory mode of AOC 210S:
Press the MENU button, pull out the power cord, and then plug the power cord. Then the factory OSD will be at the
left top of the panel.
4. Bias adjustment:
Set the Contrast
to 50; Adjust the Brightness to 80.
5. Gain adjustment:
Move cursor to “-F-” and press MENU key
A. Adjust Warm (6500K) color-temperature
1. Switch the chroma-7120 to RGB-Mode (with press “MODE” button)
2. Switch the MEM.channel to Channel 3 (with up or down arrow on chroma 7120)
3. The LCD-indicator on chroma 7120 will show x = 313 ±20, y = 329 ±20, Y=180cd/m
2
4. Adjust the RED of color3 on factory window until chroma 7120 indicator reached the value R=100
5. Adjust the GREEN of color3 on factory window until chroma 7120 indicator reachedthe value G=100
6. Adjust the BLUE of color3 on factory window until chroma 7120 indicator reached the value B=100
7. Repeat above procedure (item 4,5,6) until chroma 7120 RGB value meet the tolerance =100±2
B. Adjust Normal (7300K) color-temperature
1. Switch the chroma-7120 to RGB-Mode (with press “MODE” button)
2. Switch the MEM.channel to Channel 4(with up or down arrow on chroma 7120)
3. The LCD-indicator on chroma 7120 will show x = 301 ±20, y = 317 ±20, Y=180cd/m
2
4. Adjust the RED of color3 on factory window until chroma 7120 indicator reached the value R=100
36

22" LCD Color Monitor AOC 210S
5. Adjust the GREEN of color3 on factory window until chroma 7120 indicator reachedthe value G=100
6. Adjust the BLUE of color3 on factory window until chroma 7120 indicator reached the value B=100
7. Repeat above procedure (item 4,5,6) until chroma 7120 RGB value meet the tolerance =100±2
C. Adjust Cool (9300K) color-temperature
1. Switch the Chroma-7120 to RGB-Mode (with press “MODE” button)
2. Switch the MEM. Channel to Channel 9 (with up or down arrow on chroma 7120)
3. The LCD-indicator on chroma 7120 will show x = 283 ±20, y = 297 ±20, Y=180cd/m
4. Adjust the RED of color1 on factory window until chroma 7120 indicator reached the value R=100
5. Adjust the GREEN of color1 on factory window until chroma 7120 indicator reached the value G=100
6. Adjust the BLUE of color1 on factory window until chroma 7120 indicator reached the value B=100
7. Repeat above procedure (item 4,5,6) until chroma 7120 RGB value meet the tolerance =100±2
D. Adjust sRGB color-temperature
1. Switch the chroma-7120 to RGB-Mode (with press “MODE” button)
2. Switch the MEM.channel to Channel 10 (with up or down arrow on chroma 7120)
3. The LCD-indicator on chroma 7120 will show x = 313 ±20, y = 329 ±20, Y= 180cd/m
2
2
4. Adjust the RED of color3 on factory window until chroma 7120 indicator reached the value R=100
5. Adjust the GREEN of color3 on factory window until chroma 7120 indicator reachedthe value G=100
6. Adjust the BLUE of color3 on factory window until chroma 7120 indicator reached the value B=100
7. Repeat above procedure (item 4,5,6) until chroma 7120 RGB value meet the tolerance =100±2
E. Turn the Power-button off to quit from factory mode.
37

22" LCD Color Monitor AOC 210S
11. BOM List
TC6MMADBWQA5HP
Location Part No. for TPV Description
040G 152509 RECYCLE LABEL
040G 152512 RECYCLE LABEL
045G 88606 S PE BAG FOR BASE
045G 88626 8 PE BAG FOR MONITOR
052G 1186 SMALL TAPE
052G 1211 A 165MINIUM TAPE
052G6025 11926 MYLAR
089G 725HAA550 SIGNAL CABLE
089G404A15N IS POWER CORD
095G801410D544 WIRE HARNESS
095G8018 3D558 LVDS CABLE
0M1G 130 4120 SCREW M3X5
0M1G 130 4120 SCREW M3X5
0M1G 130 4120 SCREW M3X5
0M1G 130 6120 SCREW M3X6
0M1G 340 8 47 CR3 SCREW
0M1G 340 10 47 CR3 SCREW
0M1G 930 6 47 CR3 SCREW
0M1G1140 6128 CR3 SCREW
0M1G1730 6120 SCREW
0M1G1730 6120 SCREW
0M1G1730 6120 SCREW
0Q1G6027 1 SCREW
705GQCK0P34007 22" LCD STAND COVER-BASE ASS'Y
750GLMC0Z1111N PANEL LCD M220Z1-L01 CMO
A15G0028 1 VESA BKT
A15G0077TL1 2 MAIN FRAME
A15G0078 2 4 IO-BRACKET
A33G0079 GM 1L CABLE CLAMP
A33G0112 GN 1L KEY PAD
A33G0113 1 1C LENS
A34G0113 GNA3B BEZEL(22")
A85G0026 1 SHIELD
CBPC6MMAA5Q1 MAIN BOARD
KEPC6QC6P KEY BOARD
PWPCC44ME1P POWER BOARD
Q12G6300 18 RUBBER
39

22" LCD Color Monitor AOC 210S
Q34G0112 GMA4B REAR COVER(22")
Q44GC004 1 EPS(L)
Q44GC004 2 EPS(R)
Q44GC004615 3A CARTON
Q52G6020 30 PROTECT FILM
Q52G6025 13 63 MYLAR
Q40G 22N615 3A Rating label
Q26G 800504 2 BAR CODE LABEL
040G 58162435A LABEL
Q45G 88609 34 EPE COVER
041G780061553A TCO'03 CARD
041G780061554A SERVICE CENTER LIST
Q45G 76 28 RN R PE BAG MANUAL
Q41G7800615A67 qsg
Q70G2201615 2A cd manual
050G 600 4 HANDLE 1
044GH600 1 handle2
052G 1185 MIDDLE TAPE
Q52G 1185 65 AOC MIDDLE TAPE
012G 394 3 RUBBER FOOT
0Q1G 130 6120 SCREW (T3X6)
A34G0115 GM 1B STAND
A34G0189 GM 1B 20 BASE
A37G0007 6 HINGE
AQ1G1740 12120 SCREW
Q15G0020 2 BASE BRACKET
CN403 033G8027 10 WAFER 2*5P 2.0MM R/A
CN701 033G8027 12 WAFER 2*6P 2.0MM R/A
CN101 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE
040G 457624 1B LABEL-CPU
040G 45762412B CBPC LABEL
C408 067G215L100 7N KY50VB10M-L 5*11.5
C418 067G215L100 7N KY50VB10M-L 5*11.5
C710 067G215L101 4N KY25VB100M-L 6.3*11
C712 067G215L101 4N KY25VB100M-L 6.3*11
C717 067G215L101 4N KY25VB100M-L 6.3*11
C722 067G215Y2207NV KY50VB22M-CC3 5*11
C464 067G215Y2207NV KY50VB22M-CC3 5*11
C720 067G215Y2207NV KY50VB22M-CC3 5*11
C702 067G215Y479 7N LOW ESR EC 4.7 UF 50V NC
40

22" LCD Color Monitor AOC 210S
C403 067G215Y479 7N LOW ESR EC 4.7 UF 50V NC
CN405 088G 35315F H D-SUB 15PIN
X401 093G 22 53 H 14.31818MHZ/30PF/49US
CN801 033G8021 2E U WAFER
CN802 033G8021 2E U WAFER
CN803 033G8021 2E U WAFER
CN804 033G8021 2E U WAFER
040G 45762420A LABEL 25x6mm
051G 6 4502 RTV
PC951 056G 139 3A PC123Y22FZOF
PC953 056G 139 3A PC123Y22FZOF
PC951 056G 139 3B PC123 Y82FZ0F
PC953 056G 139 3B PC123 Y82FZ0F
VR901 061G 46 6 TNR10V471K CHEMICON
C906 063G 10722410S X2 CAP 0.22UF 275VAC
C907 063G 10722410S X2 CAP 0.22UF 275VAC
C801 065G 3J5096ET 5PF 5% SL 3KV
C803 065G 3J5096ET 5PF 5% SL 3KV
C804 065G 3J5096ET 5PF 5% SL 3KV
C805 065G 3J5096ET 5PF 5% SL 3KV
C902 065G306M1022BM Y1.CAP.001UF 250VAC MURATA
C901 065G306M1022BM Y1.CAP.001UF 250VAC MURATA
C902 065G306M1022BP 1000PF Y1.CAP
C901 065G306M1022BP 1000PF Y1.CAP
C903 065G306M2222BP 2200PF +-20% 400VAC
C905 065G306M3322BM 3300PF +-20% 250VAC
C905 065G306M3322BP 3300PF 20%
C912 067G215S10115K 100UF 450V
C912 067G215S10115N PAG450VB100-M-L18*35.5MM
C912 067G305R10115H
FB903 071G 55 29 FERRITE BEAD
ELCAP 105℃ 100UF M 450V
L901 073G 174 65 H LINE FILTER
L901 073G 174 65 LS LINE FILTER BY LISHIN
L954 073G 253171 LS CHOKE COIL 3.3UH
L954 073G 253171 YS IND CHOKE 2.13uH+-20% TOP NATION
L902 073L 174 48 LG LINE FILTER
T801 080GL20T 9 DN TRANSFORMER
T803 080GL20T 9 DN TRANSFORMER
T804 080GL20T 9 DN TRANSFORMER
T805 080GL20T 9 DN TRANSFORMER
41

22" LCD Color Monitor AOC 210S
T901 080GL20T 21 T X'FMR 400uH SRW3220PQ-T41V016 TDK
CN901 087G 501 32 S AC SOCKET
BD901 093G 50460900 BRIDEGE DIODE GBU408 LITEON
D904 093G1100 952T UF4007
CN903 095G801414W682 WIRE HARNESS
705GQC1 57001 Q902 ASSA'Y
705GQC1 61001 R941 ASSA'Y
705GQC1 61002 R940 ASSA'Y
705GQC1 93001 D907 ASSA'Y
705GQC1 93002 D952 ASSA'Y
705GQCK0 61003 RT901 ASS'Y
705GQCK0 96001 R957 ASSA'Y
CN931 DCPF1205A7P DC TO DC BOARD
U401 056G 562149 IC TSUMU58WHJ-LF PQFP-128
U702 056G 563 7 IC AIC1084-33PMTR-R AIC
U404 056G1133 34 M24C02-WMN6TP
U402 056G1133 63 IC PM25LV010-25 SCE SOIC-8 PMC
U403 056G113356A 24LC16B/SNG SOIC-8PIN
Q703 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q701 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q402 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q401 057G 417 6 PMBS3906/PHILIPS-SMT(06)
Q705 057G 417 6 PMBS3906/PHILIPS-SMT(06)
Q403 057G 417 6 PMBS3906/PHILIPS-SMT(06)
Q702 057G 417 17 T PZT2907A
Q704 057G 763 1 A03401 SOT23 BY AOS(A1)
R721 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R500 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R421 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R419 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
FB412 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
FB411 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
FB410 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R476 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R477 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R478 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R479 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R453 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R429 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R428 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
42

22" LCD Color Monitor AOC 210S
R454 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R488 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R704 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R445 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R441 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R442 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R443 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R427 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R420 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R418 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R411 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R446 061G0603102 RST CHIP 1K 1/10W 5%
R447 061G0603102 RST CHIP 1K 1/10W 5%
R470 061G0603102 RST CHIP 1K 1/10W 5%
R701 061G0603102 RST CHIP 1K 1/10W 5%
R717 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R714 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R711 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R708 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R492 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R490 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R489 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R487 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R452 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R451 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R450 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R444 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R426 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R425 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R424 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R415 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R413 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R408 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R406 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R404 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R723 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R727 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R414 061G0603121 RST CHIPR 120 OHM +-5% 1/10W
R409 061G0603121 RST CHIPR 120 OHM +-5% 1/10W
R709 061G0603153 RST CHIPR 15KOHM +-5% 1/10W
43

22" LCD Color Monitor AOC 210S
R502 061G0603200 RST CHIPR 20 OHM +-5% 1/10W
R501 061G0603200 RST CHIPR 20 OHM +-5% 1/10W
R703 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W
R448 061G0603222 RST CHIPR 2.2 KOHM +-5% 1/10W
R449 061G0603222 RST CHIPR 2.2 KOHM +-5% 1/10W
R405 061G0603223 RST CHIPR 22 KOHM +-5% 1/10W
R403 061G0603390 0F RST CHIPR 390 OHM +-1% 1/10W
R474 061G0603392 RST CHIPR 3.9 KOHM +-5% 1/10W
R475 061G0603392 RST CHIPR 3.9 KOHM +-5% 1/10W
R437 061G0603471 RST CHIPR 470 OHM +-5% 1/10W
R422 061G0603472 RST CHIPR 4.7KOHM +-5% 1/10W
R423 061G0603472 RST CHIPR 4.7KOHM +-5% 1/10W
R705 061G0603472 RST CHIPR 4.7KOHM +-5% 1/10W
R707 061G0603472 RST CHIPR 4.7KOHM +-5% 1/10W
R712 061G0603472 RST CHIPR 4.7KOHM +-5% 1/10W
R725 061G0603472 RST CHIPR 4.7KOHM +-5% 1/10W
R702 061G0603510 RST CHIPR 51 OHM +-5% 1/10W
R434 061G0603560 RST CHIPR 56 OHM +-5% 1/10W
R435 061G0603560 RST CHIPR 56 OHM +-5% 1/10W
R436 061G0603560 RST CHIPR 56 OHM +-5% 1/10W
R438 061G0603750 RST CHIPR 75 OHM +-5% 1/10W
R439 061G0603750 RST CHIPR 75 OHM +-5% 1/10W
R440 061G0603750 RST CHIPR 75 OHM +-5% 1/10W
R720 061G1206151 RST CHIPR 150 OHM +-5% 1/4W
R719 061G1206151 RST CHIPR 150 OHM +-5% 1/4W
C435 065G0603102 32 1000PF +-10% 50V X7R
C407 065G0603104 32 CHIP 0.1UF 50V X7R
C406 065G0603104 32 CHIP 0.1UF 50V X7R
C405 065G0603104 32 CHIP 0.1UF 50V X7R
C409 065G0603104 32 CHIP 0.1UF 50V X7R
C410 065G0603104 32 CHIP 0.1UF 50V X7R
C411 065G0603104 32 CHIP 0.1UF 50V X7R
C455 065G0603104 32 CHIP 0.1UF 50V X7R
C456 065G0603104 32 CHIP 0.1UF 50V X7R
C457 065G0603104 32 CHIP 0.1UF 50V X7R
C458 065G0603104 32 CHIP 0.1UF 50V X7R
C459 065G0603104 32 CHIP 0.1UF 50V X7R
C460 065G0603104 32 CHIP 0.1UF 50V X7R
C461 065G0603104 32 CHIP 0.1UF 50V X7R
C701 065G0603104 32 CHIP 0.1UF 50V X7R
44

22" LCD Color Monitor AOC 210S
C709 065G0603104 32 CHIP 0.1UF 50V X7R
C711 065G0603104 32 CHIP 0.1UF 50V X7R
C713 065G0603104 32 CHIP 0.1UF 50V X7R
C714 065G0603104 32 CHIP 0.1UF 50V X7R
C719 065G0603104 32 CHIP 0.1UF 50V X7R
C721 065G0603104 32 CHIP 0.1UF 50V X7R
C412 065G0603104 32 CHIP 0.1UF 50V X7R
C413 065G0603104 32 CHIP 0.1UF 50V X7R
C414 065G0603104 32 CHIP 0.1UF 50V X7R
C415 065G0603104 32 CHIP 0.1UF 50V X7R
C416 065G0603104 32 CHIP 0.1UF 50V X7R
C419 065G0603104 32 CHIP 0.1UF 50V X7R
C420 065G0603104 32 CHIP 0.1UF 50V X7R
C422 065G0603104 32 CHIP 0.1UF 50V X7R
C426 065G0603104 32 CHIP 0.1UF 50V X7R
C427 065G0603104 32 CHIP 0.1UF 50V X7R
C428 065G0603104 32 CHIP 0.1UF 50V X7R
C429 065G0603104 32 CHIP 0.1UF 50V X7R
C430 065G0603104 32 CHIP 0.1UF 50V X7R
C444 065G0603104 32 CHIP 0.1UF 50V X7R
C404 065G0603104 32 CHIP 0.1UF 50V X7R
C402 065G0603104 32 CHIP 0.1UF 50V X7R
C401 065G0603104 32 CHIP 0.1UF 50V X7R
C442 065G0603220 31 CER1 0603 NP0 50V 22P PM
C443 065G0603221 32 CHIP 220PF 50V X7R
C715 065G0603223 32 CHIP 0.022UF 50V X7R 0603
C425 065G0603224 22 CHIP 0.22UF 25V X7R
C417 065G0603224 22 CHIP 0.22UF 25V X7R
C441 065G0603473 32 CHIP 0.047UF 50V X7R
C440 065G0603473 32 CHIP 0.047UF 50V X7R
C439 065G0603473 32 CHIP 0.047UF 50V X7R
C438 065G0603473 32 CHIP 0.047UF 50V X7R
C437 065G0603473 32 CHIP 0.047UF 50V X7R
C436 065G0603473 32 CHIP 0.047UF 50V X7R
C434 065G0603473 32 CHIP 0.047UF 50V X7R
C433 065G0603473 32 CHIP 0.047UF 50V X7R
C432 065G0603473 32 CHIP 0.047UF 50V X7R
C423 065G0603560 31 CHIP 56PF 50V NPO
C421 065G0603560 31 CHIP 56PF 50V NPO
L702 071G 56K121 CHIP BEAD
45

22" LCD Color Monitor AOC 210S
L703 071G 56K121 CHIP BEAD
FB405 071G 56Z601 CHIP BEAD 600 OHM 0805
FB404 071G 56Z601 CHIP BEAD 600 OHM 0805
FB403 071G 56Z601 CHIP BEAD 600 OHM 0805
FB402 071G 56Z601 CHIP BEAD 600 OHM 0805
FB401 071G 56Z601 CHIP BEAD 600 OHM 0805
FB409 071G 59B121 TB160808B
D406 093G 39149 MLL5232B BY FULL POWER SMT
D408 093G 39149 MLL5232B BY FULL POWER SMT
D409 093G 39149 MLL5232B BY FULL POWER SMT
D410 093G 39149 MLL5232B BY FULL POWER SMT
D411 093G 39149 MLL5232B BY FULL POWER SMT
D412 093G 39149 MLL5232B BY FULL POWER SMT
D405 093G 64 33 DIO SIG SM BAV99 (PHSE)R
D404 093G 64 33 DIO SIG SM BAV99 (PHSE)R
D403 093G 64 33 DIO SIG SM BAV99 (PHSE)R
D407 093G 64 42 P BAV70 SOT-23
D702 093G 6432P LL4148
D425 093G 39S 45 T DIODE ZENER RLZ36B ROHM
D402 093G 39S 45 T DIODE ZENER RLZ36B ROHM
D401 093G 39S 45 T DIODE ZENER RLZ36B ROHM
D701 093G1020 1 S GS1D
D704 093G2004 2 SR24/PANJIT-SMT
715G2186 1 MAIN BOARD PCB
CN1 033G8034 9A GP WAFER
SW101 077G 604 2 TO TACT 5W BY TOUKE TS-9-TMG-553
SW102 077G 604 2 TO TACT 5W BY TOUKE TS-9-TMG-553
SW103 077G 604 2 TO TACT 5W BY TOUKE TS-9-TMG-553
SW104 077G 604 2 TO TACT 5W BY TOUKE TS-9-TMG-553
SW105 077G 604 2 TO TACT 5W BY TOUKE TS-9-TMG-553
SW106 077G 604 2 TO TACT 5W BY TOUKE TS-9-TMG-553
D107 081G 14501 KT CHIP LED
D109 093G 39P599 T MM3Z5V6B
D108 093G 39P599 T MM3Z5V6B
D106 093G 39P599 T MM3Z5V6B
D105 093G 39P599 T MM3Z5V6B
D104 093G 39P599 T MM3Z5V6B
D101 093G 39P599 T MM3Z5V6B
D102 093G 39P599 T MM3Z5V6B
D103 093G 39P599 T MM3Z5V6B
46

22" LCD Color Monitor AOC 210S
D104 093G 39S 34 T UDZS5.6B
D106 093G 39S 34 T UDZS5.6B
D105 093G 39S 34 T UDZS5.6B
D109 093G 39S 34 T UDZS5.6B
D108 093G 39S 34 T UDZS5.6B
D103 093G 39S 34 T UDZS5.6B
D102 093G 39S 34 T UDZS5.6B
D101 093G 39S 34 T UDZS5.6B
715G2112 2 KEY BOARD PCB
Q902 057G 667 21 STP10NK70ZFP
Q902 057G 667516 FET 2SK3673 TO-220 FUJI
0M1G1730 8120 SCREW
HS1 Q90G0010 1 HEAT SINK
R941 061G152M20858F RST MOFR 0.2OHM +-5% 2W
FOR
R941
R940 061G152M10458F 100K OHM 5% 2W
FOR
R940
D907 093G 60239 FME-210B T0-220
D907 093G 60245 SP10150
D907 093G 60261 DIODE
0M1G1730 8120 SCREW
HS4 Q90G0012 1 HEAT SINK
D952 093G 60244 SRF20200C
D952 093G 60283 DIODE MBRF20200CT 20A/200V ITO-220AB
0M1G1730 8120 SCREW
HS2 Q90G0011 1 HEAT SINK
RT901 061G 58030 W
096G 29 10 H.S. TUBE
096G 29 6 H.S. TUBE
096G 29 6 H.S. TUBE
NTCR 3 欧 5A
R957 061G152M22158F RST MOFR 220OHM +-5% 2W
096G 29 6 H.S. TUBE
CN801 033T800913Z H PIN HEADER 1*13 R/A
C806 067T215Y4713NV LOW ESR 470UF 16V NCC
C807 067T215Y4713NV LOW ESR 470UF 16V NCC
C806 067T215Y4713RV
C807 067T215Y4713RV
C801 067T405V221 4P
DC1205A7SMTP DC TO DC BOARD FOR SMT
IC902 056G 379 61 LD7575PS SOP-8
EC 105℃ 470UF M 16V YXG SERIES 8*16MM
EC 105℃ 470UF M 16V YXG SERIES 8*16MM
105℃ 220UF M 25V
47

22" LCD Color Monitor AOC 210S
IC801 056G 608 7 OZT1060GN SOIC-20
Q802 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q957 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q808 057G 417 6 PMBS3906/PHILIPS-SMT(06)
Q815 057G 759 2 RK7002
Q813 057G 759 2 RK7002
Q812 057G 759 2 RK7002
Q811 057G 759 2 RK7002
Q809 057G 759 2 RK7002
Q807 057G 759 2 RK7002
Q801 057G 760 4 DTA144WKA BY ROHM SMT
Q801 057G 760 4A DTA144WN3/S SOT-23
Q806 057G 763 40 FET AM4541C-T1-PF SOIC-8 ANALOG POWER
Q803 057G 763 40 FET AM4541C-T1-PF SOIC-8 ANALOG POWER
R810 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R826 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R844 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
RJ202 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R834 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W
R843 061G0603100 4F RST CHIPR 1 MOHM +-1% 1/10W
R841 061G0603100 4F RST CHIPR 1 MOHM +-1% 1/10W
R840 061G0603100 4F RST CHIPR 1 MOHM +-1% 1/10W
R838 061G0603100 4F RST CHIPR 1 MOHM +-1% 1/10W
R809 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R811 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W
R839 061G0603120 1F RST CHIPR 1.2KOHM +-1% 1/10W
R956 061G0603130 3F RST CHIPR 130KOHM +-1% 1/10W
R813 061G0603200 3F RST CHIPR 200KOHM +-1% 1/10W
C821 061G0603205 RST CHIPR 2 MOHM +-5% 1/10W
R954 061G0603242 RST CHIPR 2.4 KOHM +-5% 1/10W
R953 061G0603270 1F RST CHIPR 2.7 KOHM +-1% 1/10W
R904 061G0603330 2F RST CHIPR 33 KOHM +-1% 1/10W
R827 061G0603330 2F RST CHIPR 33 KOHM +-1% 1/10W
R824 061G0603393 RST CHIPR 39 KOHM +-5% 1/10W
R830 061G0603510 2F RST CHIPR 51 KOHM +-1% 1/10W
R835 061G0603620 1F RST CHIPR 6.2KOHM +-1% 1/10W
R815 061G0603750 2F RST CHIPR 75KOHM +-1% 1/10W
R846 061G0805000 0 OHM 1/10W
R958 061G0805000 0 OHM 1/10W
R806 061G0805100 2F RST CHIPR 10KOHM +-1% 1/8W
48

22" LCD Color Monitor AOC 210S
R805 061G0805100 2F RST CHIPR 10KOHM +-1% 1/8W
R804 061G0805102 CHIP 1KOHM 1/10W
R814 061G0805102 CHIP 1KOHM 1/10W
R822 061G0805102 CHIP 1KOHM 1/10W
R829 061G0805102 CHIP 1KOHM 1/10W
R831 061G0805105 1MOHM 1/10W
R812 061G0805200 3F RST CHIPR 200 KOHM +-1% 1/8W
R845 061G0805333 RST CHIPR 33 KOHM +-5% 1/8W
R807 061G0805470 0F RST CHIPR 470 OHM +-1% 1/8W
R817 061G0805470 0F RST CHIPR 470 OHM +-1% 1/8W
R823 061G0805470 0F RST CHIPR 470 OHM +-1% 1/8W
R832 061G0805470 0F RST CHIPR 470 OHM +-1% 1/8W
R820 061G0805620 2F RST CHIPR 62 KOHM +-1% 1/8W
JR905 061G1206000 0 OHM 1/8W
JR219 061G1206000 0 OHM 1/8W
JR214 061G1206000 0 OHM 1/8W
JR213 061G1206000 0 OHM 1/8W
JR212 061G1206000 0 OHM 1/8W
JR211 061G1206000 0 OHM 1/8W
JR210 061G1206000 0 OHM 1/8W
JR207 061G1206000 0 OHM 1/8W
JR206 061G1206000 0 OHM 1/8W
JR205 061G1206000 0 OHM 1/8W
JR201 061G1206000 0 OHM 1/8W
R908 061G1206100 10 OHM 1/8W
R816 061G1206100 10 OHM 1/8W
R938 061G1206100 10 OHM 1/8W
R939 061G1206100 3F RST CHIPR 100 KOHM +-1% 1/4W
R802 061G1206101 100 1206
R905 061G1206101 100 1206
R906 061G1206101 100 1206
R907 061G1206101 100 1206
R917 061G1206103 10 KOHM 1/8W
R9759 061G1206202 RST CHIPR 2 KOHM +-5% 1/4W
R9757 061G1206202 RST CHIPR 2 KOHM +-5% 1/4W
R801 061G1206242 RST CHIPR 2.4 KOHM +-5% 1/4W
R964 061G1206470 47 1206
R965 061G1206470 47 1206
R966 061G1206470 47 1206
R943 061G1206471 470 1206
49

22" LCD Color Monitor AOC 210S
R927 061G1206472 RST CHIPR 4.7 KOHM +-5% 1/4W
R928 061G1206472 RST CHIPR 4.7 KOHM +-5% 1/4W
R929 061G1206472 RST CHIPR 4.7 KOHM +-5% 1/4W
R9760 061G1206682 RST CHIPR 6.8 KOHM +-5% 1/4W
R901 061G1206684 RST CHIPR 680 KOHM +-5% 1/4W
R902 061G1206684 RST CHIPR 680 KOHM +-5% 1/4W
R903 061G1206684 RST CHIPR 680 KOHM +-5% 1/4W
JR901 061L1206000 CHIPR 0 OHM +-5% 1/8W
C852 065G0603104 32 CHIP 0.1UF 50V X7R
C853 065G0603104 32 CHIP 0.1UF 50V X7R
C967 065G0603104 32 CHIP 0.1UF 50V X7R
C961 065G0603104 32 CHIP 0.1UF 50V X7R
C957 065G0603104 32 CHIP 0.1UF 50V X7R
C857 065G0603104 32 CHIP 0.1UF 50V X7R
C855 065G0603104 32 CHIP 0.1UF 50V X7R
C854 065G0603104 32 CHIP 0.1UF 50V X7R
C847 065G0603104 32 CHIP 0.1UF 50V X7R
C833 065G0603104 32 CHIP 0.1UF 50V X7R
C832 065G0603104 32 CHIP 0.1UF 50V X7R
C827 065G0603104 32 CHIP 0.1UF 50V X7R
C822 065G0603104 32 CHIP 0.1UF 50V X7R
C815 065G0603104 32 CHIP 0.1UF 50V X7R
C814 065G0603104 32 CHIP 0.1UF 50V X7R
C920 065G0603223 32 CHIP 0.022UF 50V X7R 0603
C930 065G0603471 31 CAP:CER 470PF 5%50V SMT 0603
C846 065G0603472 32 CHIP 4700PF 50V X7R
C839 065G0603472 32 CHIP 4700PF 50V X7R
C825 065G0603472 32 CHIP 4700PF 50V X7R
C820 065G0603472 32 CHIP 4700PF 50V X7R
C9753 065G0603474 12 MLCC 0603 0.47UF K 16V X7R
C828 065G0603474 12 MLCC 0603 0.47UF K 16V X7R
C835 065G0603682 32 CHIP 0.0068UF 50V X7R 0603
C830 065G0603682 32 CHIP 0.0068UF 50V X7R 0603
C829 065G0805105 22 CHIP 1UF 25V X7R 0805
C823 065G0805105 22 CHIP 1UF 25V X7R 0805
C819 065G0805105 22 CHIP 1UF 25V X7R 0805
C818 065G0805105 22 CHIP 1UF 25V X7R 0805
C826 065G080522131G 220PF 50V NPO 2%
C966 065G1206102 72 CHIP 1000PF 500V X7R
C908 065G1206102 72 CHIP 1000PF 500V X7R
50

22" LCD Color Monitor AOC 210S
ZD951 065G1206104 32 CHIP 0.1UF 25V X7R 1206
C840 065G1206105 32 CHIP 1UF 50V X7R 1206
C836 065G1206105 32 CHIP 1UF 50V X7R 1206
C817 065G1206105 32 CHIP 1UF 50V X7R 1206
C807 065G1206105 32 CHIP 1UF 50V X7R 1206
D815 093G 6432S IN4148W
D816 093G 6432S IN4148W
D817 093G 6432S IN4148W
D819 093G 6432S IN4148W
D905 093G 6432S IN4148W
D9553 093G 6432S IN4148W
D9757 093G 6432S IN4148W
D810 093G 6432S IN4148W
D9553 093G 6432V LL4148-GSO8
D905 093G 6432V LL4148-GSO8
D819 093G 6432V LL4148-GSO8
D9757 093G 6432V LL4148-GSO8
D9756 093G 6432V LL4148-GSO8
D810 093G 6432V LL4148-GSO8
D815 093G 6432V LL4148-GSO8
D816 093G 6432V LL4148-GSO8
D817 093G 6432V LL4148-GSO8
D805 093G 6433P BAV99
D806 093G 6433P BAV99
D807 093G 6433P BAV99
D808 093G 6433P BAV99
D801 093G 6433P BAV99
D803 093G 6433P BAV99
D809 093G 6433P BAV99
D812 093G 6433P BAV99
ZD802 093G 39S 24 T RLZ 5.6B LLDS
ZD803 093G 39S 24 T RLZ 5.6B LLDS
ZD801 093G 39S 24 T RLZ 5.6B LLDS
D950 093G 39S 99 T TVS SMAJ24A SMA
D827 093G3004 4 RB050L-40
D826 093G3004 4 RB050L-40
D821 093G3004 4 RB050L-40
D820 093G3004 4 RB050L-40
034FPF20P01 BOBBIN
IC801 056T 133 32 NS LM3485
51

22" LCD Color Monitor AOC 210S
Q801 057T 763 3 AO4411L SO-8 BY AOS SMT
Q801 057T 763 4 RSS050P03
R803 061T0603200 2F RST CHIPR 20 KOHM +-1% 1/10W
R801 061T0603360 2F RST CHIPR 36 KOHM +-1% 1/10W
R802 061T0603620 2F RST CHIPR 62 KOHM +-1% 1/10W
R804 061T1206220 RST CHIPR 22 OHM +-5% 1/4W
C804 065G060310332K CAP CHIP 0603 10N 50V X7R +/-10%
C803 065T0603102 32 CHIP 1000PF 50V X7R
C809 065T0603104 32 CHIP 0.1UF 50V X7R
C805 065T0603471 31 CHIP 470PF 50V NPO
C808 065T0805102 32 CHIP 1000P 50VX7R 0805
C810 065T0805102 32 CHIP 1000P 50VX7R 0805
C802 065T0805105 22 CHIP 1UF 25V X7R 0805
L801 073T M5822020T 22UH +-20%
D801 093T8004 2 SBM84PT
715T1278 4 PCB
CN901 006G 31500 EYELET
Q902 006G 31502 1.5MM RIVET
T901 006G 31502 1.5MM RIVET
C912 006G 31502 1.5MM RIVET
L901 006G 31502 1.5MM RIVET
T801 006G 31502 1.5MM RIVET
T803 006G 31502 1.5MM RIVET
T804 006G 31502 1.5MM RIVET
T805 006G 31502 1.5MM RIVET
RT901 006G 31502 1.5MM RIVET
L902 006G 31502 1.5MM RIVET
TL951 056G 158 2 T TL431ACLPR TO-92 3PIN
TL951 056G 158 4 T H431BA
Q958 057G 566 1 2N5060RLRAG
Q958 057G 566 4 MCR100-6SCR
R951 061G 17147152T RST CFR 470 OHM +-2% 1/4W
R9758 061G 17233252T 3.3K 1/4W
R952 061G 20012352T RST MFR 12KOHM +-1% 1/4W
C913 065G 1K152 1T6052 1.5nF /1K Y5P+-10%
C940 067G215Y2207KT
FB901 071G 55 29 FERRITE BEAD
FB902 071G 55 29 FERRITE BEAD
F901 084G 55 7W FUSE 3.15A 250V Wickmann
ZD9754 093G 3916652T MTZJ15B (13.89-14.62)
CAP 105℃ 22UF M 50V KINGNICHI
52

22" LCD Color Monitor AOC 210S
ZD9753 093G 3917252T MTZJ33B
ZD9755 093G 3952552T ZENER MTZJ T 6.2B
D906 093G 6026T52T RECTIFIER DIODE FR107
D906 093G 6026W52T FR107
715G2101 2 POWER BOARD PCB
53

22" LCD Color Monitor AOC 210S
12. Different Parts List
Diversity of TC6MMANPWQXMHP compared with TC6MMADBWQA5HP
Location Part No. Description
026G 800504 3 BARCODE LABEL
041G780061518B EASE PROGRAM
041G780061541A AOC-Kensington Card
041G780061545B WARRANTY BOOKLET
089G 725GAA550 SIGNAL CABLE
089G402A15N IS POWER CORD
089G402A15N LS POWER CORD
089G402A15N YH POWER CORD
A33G0112 GM 1L KEY PAD
A34G0113 GNB3B BEZEL(22")
Q34G0112 GMB4B REAR COVER(22")
Q40G 22N615 6A Rating label
Q44GC004615 5A CARTON
Q45G 76 28 C R PE BAG
Q41G7800615A69 MEXICO Center list
Q40G000261555A POP label
Diversity of TC6MMANQWQACHP compared with TC6MMADBWQA5HP
Location Part No. Description
089G402A15N YH POWER CORD
A33G0112 GM 1L KEY PAD
A34G0113 GNB3B BEZEL(22")
Q34G0112 GMB4B REAR COVER(22")
Q44GC004615 6A CARTON
041G780061513B INPUT NOT SUPPORT CARD
041G780061518B EASE PROGRAM
041G780061532C SA CENTER LIST
041G780061541A AOC-Kensington Card
041G780061545B WARRANTY BOOKLET
Q45G 76 28 C R PE BAG
026G 800504 3 BARCODE LABEL
Q40G 22N615 5A Rating label
089G402A15N IS POWER CORD
089G402A15N LS POWER CORD
089G 725GAA550 SIGNAL CABLE
Q40G000261555A POP label
54
