Antop AT-103 User Manual

PAPER THIN
INDOOR HDTV ANTENNA

AT-103

INSTRUCTIONS

INSTRUCTIONS

Your Paper Thin Indoor HDTV TV Antenna AT-103 can be used anywhere indoors: at Home
or even with your Mobile Home/RV. ANTOP’s New Generation Digital Technology allows you
the flexibility to set up your antenna in various locations and still receive a great digital
reception.

Following are instructions for indoor installation. Read through all instructions prior to begin­ning installation procedure.

Note:

better reception. Install the antenna as high as possible, and preferably with a clear path
between the antenna and the TV station transmitters. Trees, buildings, mountains, etc.,
can all impact the performance of any antenna.

A higher mounting location positioned towards the broadcast tower may result in

1 / Connecting

Connect the coaxial cable to the ANTENNA/CABLE IN connector on the back of the TV or
converter box.

Indoor TV Antenna

ANT/IN

CABLE IN

1

Back of TV

2 / Setting and Scanning

In the TV’s setup menu, set the mode to “Antenna” or “Air”, then, set TV to “Scan” for channels.
Consult the TV manual for detailed instructions.

1

CHANNEL SCAN

2

scanning for channels

3/ Locating and Placing

Test the antenna in multiple locations to find the best one before mounting the antenna. A high
location or positioning the antenna toward the broadcast tower may result in better reception.

Window Mounting

Table Lying

Wall Mounting

4/Mounting

Secure the antenna with the provided double sided sticker on any non-metallic structure, or with
the double sided suction cup on smooth surface.

2
