battery type: Alkaline Manganese (Mercury free)
battery size: IEC: LR6; JIS: AM-3; ANSI: AA; MN1500; Mignon
chemical system: Zn / KOH-H2O / MnO
2
Conditions
nominal voltage: 1.5 V
open circuit voltage: 1.57...1.62 V new battery
1.55...1.62 V after 1 year storage at 20°C
capacity all measurements at 20°C ambient
rated: 2700 mAh discharge at 10mA load; 24hours/day
End Voltage (EV): 0.8V
2400 mAh discharge at 75ohms load; 24hours/day
End Voltage (EV): 0.8V
minimum: 2200 mAh discharge at 35mA constant current
End Voltage (EV): 0.8V
700 mAh discharge at 1000mA constant current
End Voltage (EV): 0.8V
typical service output (new batteries)
≥ 330 cycles discharge at 1000mA; EV: 0.9V
discharge 10s/m 1h/d
≥ 79
h load resistor: 43ohms; EV: 0.9V
discharge 4h/d
≥ 38
min discharge at 1000mA; EV: 0.9V
discharge 24h/d
≥ 17.5 h load resistor: 10ohms; EV: 0.9V
discharge 24h/d
≥ 6.2 h discharge at 250mA; EV: 0.9V
discharge 1h/d
internal resistance: ≤ 0.25 Ω at 1kHz, sine wave measurement
full battery
shelf life: 7 years under proper storage conditions
leakage resistance
over discharge: no leakage 10ohms continuous discharge for 48h; ta: 20°C; RH: 60±15%
high temperature: no leakage store 20days at ta: 60°C; RH:90±5%
ambient temperature
range: - 10...50 °C
recommended storage
conditions: 5....25 °C ambient temperature
45...75 % rel. humidity
mechanical specifications
cell dimensions
diameter d1: 14.4 - 0.5 mm
diameter d2: 5.4 - 0.5 mm
height h1: 50.4 - 0.5 mm
height h2: 1.7 - 0.5 mm
weight: 23 ± 2 g
package
dimensions: 72 x 29 x 51 mm
weight (incl. batteries): 233 ± 5 g
43
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice
author / date
supplier no.
Ansmann Industrial Alkaline Battery
AA - size 10pcs box
1502-0006
701381
TG / 25.02.2015
ANSMANN Specifications for model:
data sheet no. / part no.
