Anritsu 37397D Programming Manual

Download

SERIES

37XXXD

VECTOR NETWORK ANALYZER

PROGRAMMING MANUAL

490 JARVIS DRIVE · MORGAN HILL, CA 95037-2809

P/N: 10410-00262

REVISION: A

PRINTED: SEPTEMBER 2004

WARRANTY

The ANRITSU product(s) listed on the title page is (are) warranted against defects in materials and workmanship for one year from the date of shipment. ANRITSU's obligation covers repairing or replacing products which prove to be defective during the warranty period. Buyers shall prepay transportation charges for equipment returned to ANRITSU for warranty repairs. Obligation is limited to the original purchaser. ANRITSU is not liable for con sequential damages.

LIMITATION OF WARRANTY

The foregoing warrantydoes not apply to ANRITSU connectors that have failed due to normal wear. Also,the warranty does not apply to defects resulting from improper or inadequate maintenance by the Buyer,unauthorized modification or misuse,oroperation outside of the environmental specifications of the product. No other warranty is expressed or implied, and the remedies provided herein are the Buyer's sole and exclusive remedies.

TRADEMARK ACKNOWLEDGEMENTS

V Connector and K Connector are registered trademarks of ANRITSU Company. Windows,Excel,QuickBASIC,C,andQuick C are registered trademarks of Microsoft Corporation.

NOTICE

ANRITSU Company has prepared this manual for use by ANRITSU Company personnel and cus tomers as a guide for the proper installation, operation and maintenance of ANRITSU Company equipment and computer programs.The drawings, specifications, and information contained herein are the property of ANRITSU Company,and any unauthorized use or disclosure of these drawings, specifications, and information is prohibited; they shall not be reproduced, copied, or used in whole or in part as the basis for manufacture or sale of the equipment or software programs without the prior written consent of ANRITSU Company.

UPDATES

Updates to this manual, if any, may be downloaded from the Anritsu Internet site at:

http://www.anritsu.com

Part 1 — GPIB Interface

Chapter 1 — Series 37XXXD GPIB Programmer Interface

This chapter provides an introduction to the 37XXXD GPIB programmer interface and GPIB commu nications.

Chapter 2 — GPIB Programming Basics

This chapter provides programming information, including equipment and controller setup and ele mental GPIB programming techniques.

Chapter 3 — Series 37XXXD Programming Examples

This chapter provides sample program elements that demonstrate common 37XXXD operations. These sample elements are useful as an aid in developing 37XXXD programs.

Part 2 — GPIB Function Groups

Chapter 4 — Measurement Functions

This chapter provides a detailed description of the 37XXXD specific GPIB commands that control the various data display and measurement control functions of the 37XXXD.

Chapter 5 — Calibration Functions

This chapter describes the 37XXXD error correction (calibration) functions and the commands used to implement a measurement calibration. It also describes the AutoCal function and provides a listing of applicable commands.

Chapter 6 — Markers and Limits Functions

This chapter describes commands used for data analysis, which consists of markers and limits function commands.

Chapter 7 — Remote-Only Functions

This chapter describes 37XXXD functions that support operations typically required when in the remote-only (GPIB) mode. The commands described consist of data transfer, error reporting, SRQ/status reporting, 488.2 common commands, and synchronization.

Chapter 8 — System Functions

This chapter describes the commands used to implement certain system functions. They consist of hard copy, system state, save/recall, disk function, and diagnostics commands.

Chapter 9 — Special Applications Functions

This chapter describes the commands used to implement special measurement functions. They con sist of time domain, multiple source, sweep control, rear panel output, CW sweep, gain compression, Millimeter Wave System commands.

37XXXD PM i

Part 3 — Programming Reference

Chapter 10 — Command Dictionary

This chapter provides an alphabetically-ordered, dictionary-type listing and description of all 37XXXD GPIB programming commands. The listing for each command includes relevant details about the command.

Chapter 11 — Instrument Data

This chapter provides general (non-command specific) tabular information for the 37XXXD. Much of this information is presented in Chapters 4 through 10, but is provided in this chapter for easy access.

Chapter 12 — Error Messages

This chapter provides a list of all Error Messages including those related to remote-only (GPIB) operation of the 37XXXD.

Part 4 — Supplemental Data

Appendix A — Introduction to the IEEE 488 Bus

This appendix contains an introduction to the IEEE 488 Bus (GPIB). This material is intended to as sist new users in understanding GPIB basics.

Appendix B — GPIB Quick Reference Guide

This appendix provides a quick reference to all 37XXXD GPIB commands. Each reference lists the command name, a brief description of the command function, and a reference to the pertinent Chapter in this manual.

ii 37XXXD PM

Part 1 The GPIB Interface

This part consists of three chapters that describe how the IEEE- 488 (GPIB) interface is implemented within the 37XXXD Vector Network Analyzer and how to perform basic GPIB communications operations.

Chapter 1 – briefly describes the 37XXXD GPIB programmer

interface and describes the communication to and from the interface during remote-only (GPIB) operation of the 37XXXD.

Chapter 2 – provides a tutorial for performing basic GPIB op

erations such as sending and receiving messages, synchronizing instrument operations, setting timeouts, and status checking.

Chapter 3 – provides sample program elements to familiarize

the user with 37XXXD programming techniques.They are also useful as an aid in developing 37XXXD programs.

Chapter 1 Series 37XXXD GPIB Programmer Interface

Table of Contents

1-1 MANUAL SCOPE .........................1-3

1-2 INTRODUCTION .........................1-3

1-3 RELATED MANUALS.......................1-3

1-4 REMOTE OPERATION ......................1-3

GPIB Setup Menu ......................1-4

Interface Connection.....................1-5

Local Operation Key .....................1-5

Remote Operation LED Indicators .............1-7

1-5 GPIB COMMUNICATION ....................1-8

Bus Interface Function Messages..............1-8

37XXXD Specific Messages .................1-8

Separator

Characters ..........................1-9

Terminator

Character...........................1-9

GPIB Error

Conditions ..........................1-9

Testing the 37XXXD GPIB Operation ...........1-10

1-6 IEEE 488.2 SUMMARY .....................1-11

Chapter 1 Series 37XXXD GPIB Programmer Interface

1-1 MANUAL SCOPE This manual provides IEEE 488 bus (GPIB) programming information

and data for all models of the Series 37000C Vector Network Analyzer. It contains the entire command set for programming all features. Con sequently,not all of the codes documented in this manual apply to all models within the series (372XXD, 373XXD). The reader needs to be aware of the feature set available within the model for which program ming is being written. Feature set information is documented in the applicable operation manual (OM) for any particular model.

1-2 INTRODUCTION This chapter contains a brief introduction to the 37XXXD GPIB inter-

face and programming environment.

1-3 RELATED MANUALS The series contains an operation manual, a maintenance manual, and

a GPIB Quick Reference Guide (Appendix B). ANRITSU Part numbers and manual titles are given below:

Manual Title Part Number

37XXXD Operation Manual (OM) 10410-00261

37XXXD Maintenance Manual (MM) 10410-00264

37XXXD GPIB Quick Reference Guide 10410-00263

1-4 REMOTE OPERATION The following sections describe the 37XXXD facilities for remote oper

ation. The 37XXXD fully supports the IEEE 488.2–1992 GPIB standard. All

37XXXD front panel functions (except Power on/off and GPIB Test) can be controlled remotely using the GPIB commands listed in this manual and an external computer equipped with an IEEE 488 GPIB controller. When in the GPIB operating mode,the 37XXXD VNA func tions as both a listener and a talker.

37XXXD PM 1-3

REMOTE OPERATION GENERAL INFORMATION

GPIB Setup Menu The 37XXXD VNA GPIB address defaults to 6. This value may be

changed via the Utility Menu key's GPIB ADDRESSES menu (below).

Utility Menu

Figure 1-1. GPIB Address Menu

MENU U1

SELECT UTILITY

Channels

Measurement

Display

Enhancement

FUNCTION OPTIONS

GPIB ADDRESSES

NETWORK SETUP

DISPLAY INSTRUMENT PARAMETERS

DISK UTILITIES

CAL COMPONENT UTILITIE S

AUTOCAL UTILITIE S

COLOR CONFIG

DATA ON(OFF) DRAWING

BLANK FREQ INFORMATION

MENU GP7

GPIB ADDRESSES

IEEE 488.2 GPIB INT ERFACE

ADDRESS 6

DEDICATED GPIB INT ERFACE

EXTERNAL SOURCE 1

EXTERNAL SOURCE 2 5

PLOTTE R 8

POWER MET ER 23

FREQUENCY COUNTER 7

SET DA TE/TIME

PRESS <ENTER >

TO SELECT

OR TURN ON/OFF

1-4 37XXXD PM

GENERAL INFORMATION REMOTE OPERATION

Interface Connection Connect your external controller to the IEEE 488.2 GPIB interface

connector on the rear panel (left). A pinout listing of this connector is contained in Figure 1-2.

GPIB

IEEE488.2

Refertomanual

SH1

AH1

SR1

RL1

PP1

DC1

DT1

Dedicated

Communications

forGPIBAddress

GPIB

Peripherals

CAUTION

WARNING

NOOPERATORSERVICE-

ABLEPARTSINSIDE.

>18Kg

REFERSERVICINGTO QUALIFIEDPERSONNEL.

HEAVYWEIGHT

SH1

AH1

IEEE488.2

ExternalSCSI-2Hard DiskDrive

In 5dBm50±Ω

Ext

AnlgIn

ExternalI/O

BiasFuses

Port1

U S

E S

S E

F.5A250V

GPIB

SR1

RL1

PP1

DC1

DT1

GPIB connector

GPIB

Dedicated

10MHzRef

AnlgOut

Out 5dBm50±Ω

Ext

Port2

E S U F

TestSet

ControlOut

CAUTION

TerminateUnused

+20dBMMAX,0VDC

Inputs

AVOIDSTATICDISCHARGE

IFInputs<270 MHz

a1 a2b1 b2

Ext

Trigger

Do not connect your external GPIB controller to the “Dedi

CAUTION

FORCONTINUEDFIRE PROTECTIONREPLACE ONLYWITHSPECIFIED TYPEANDRATEDFUSE.

-LINEINPUT 400VAMAX

48-63Hz

85-264VAC REPLACEFUSEONLYWITH SAMETYPEANDRATING

F U

S E

F U S

cated GPIB Interface” connector (located below the “IEEE

488.2 GPIB interface” connector (left). This dedicated GPIB port is used by the 37XXXD to control external GPIB devices,such as a plotter,second frequency source,

NOTE

frequency counter,or a power meter.

The GPIB system can accommodate up to 15 devices at any one time. To achieve maximum performance on the bus,proper timing and volt

age level relationships must be maintained. If either the cable length between separate instruments or the accumulated cable length be

tween all instruments is too long, the data and control lines cannot be driven properly and the system may fail to perform. The following guidelines should be observed:

No more than 15 instruments may be installed on the bus (in-

cluding the controller). Total accumulative cable length (in meters) may not exceed two

times the number of bus instruments or 20 meters—whichever is less.

Individual cable length should not exceed 4 meters.

2/3 of the devices must be powered on.

Devices should not be powered on while bus is in operation (that is; actively sending or receiving messages, data, etc.).

Minimize cable lengths to achieve maximum data transfer rates.

Local Operation Key Press the Ret Loc key (below) to quickly restore the 37XXXD to local

operation. Local operation will be restored unless the 37XXXD is pro grammed for local lockout; the Local Lockout LED indicator will be lit.

Channels

Measurement

Display

Enhancement

Clear

Ret Loc

37XXXD PM 1-5

REMOTE OPERATION GENERAL INFORMATION

12 11 10

9 8 7 6 5 4 3 2 1

24 23 22 21 20 19 18 17 16 15 14 13

Pinout Diagram

PIN NAME DESCRIPTION

1-4 DIO 1 thru DIO 4 Data Input/Output. Bits are HIGH with the data is logical 0 and LOW when the data is

logical 1.

5EOIEnd Or Identify. A low-true state indicates that the last byte of a multibyte message

has been placed on the line.

6DAVData Valid. A low-true state indicates that the talker has (1) sensed that NRFD is

LOW, (2) placed a byte of data on the bus, and (3) waited an appropriate length of time for the data to settle.

7 NRFD Not Ready For Data. A high-true state indicates that valid data has not yet been ac

cepted by a listener.

8 NDAC Not Data Accepted. A low-true state indicates that the current data byte has been ac

cepted for internal processing by a listener.

9 IFC Interface Clear. A low-true state places all bus instruments in a known state—such

as, unaddressed to talk, unaddressed to listen, and service request idle.

10 SRQ Service Request. A low-true state indicates that a bus instrument needs service from

the controller.

11 ATN Attention. A low-true state enables the controller to respond to both it's own lis

ten/talk address and to appropriate interface messages — such as, device clear and serial poll.

12 Shield Ground Point.

13-16 DIO 5 thru DIO 8 Data Input/Output. Bits are high with the data is logical 0 and LOW when the data is

logical 1.

17 REN Remote Enable. A low-true state enables bus instruments to be operated remotely,

when addressed.

18-

Figure 1-2. Pinout Diagram, IEEE 488.2 GPIB Connector

GND Logic ground.

1-6 37XXXD PM

GENERAL INFORMATION REMOTE OPERATION

Channels

Measurement

Display

Enhancement

GPIB

Remote

Talk

Listen

SRQ

Local Lockout

Remote Operation

LED Indicators

GPIB Remote Indicators (above) signal operational status of the GPIB, as described below:

Remote:

Lights when the 37XXXD switches to remote (GPIB) control. It remains lit until the unit returns to local control.

Talk:

Lights when you address the 37XXXD to talk and remains lit until unaddressed to talk.

Listen:

Lights when you address the 37XXXD to listen and remains lit until unaddressed to talk.

SRQ:

Lights when the 37XXXD sends a Service Request (SRQ) to the exter nal controller.The LED remains lit until the 37XXXD receives a serial poll or until the controller resets the SRQ function.

Local Lockout:

Lights when a local lockout message is received. The LED remains lit until the message is rescinded. When lit, you cannot return the 37XXXD to local control via the front panel.

Audible Indicators A single beep is issued as follows:

(1) on a GPIB error, (2) when a user warning is issued (see Chapter 12, Operational Error

Messages)

(3) when a test limit line has been exceeded, if the limits testing beep

function has been set (see Chapter 6) (4) on system reset. (5) any time the user's attention is required, such as at the end of a

calibration step.

37XXXD PM 1-7

GPIB COMMUNICATION GENERAL INFORMATION

1-5 GPIB COMMUNICATION The following sections present a short summary of 37XXXD GPIB

communication. Subjects covered are program messages, separa tor/termination characters,status reporting, and GPIB error condi tions and corresponding 37XXXD responses. Refer to Chapter 7, Re mote-Only Operation, for detailed description of these topics.

The primary GPIB messages that effect 37XXXD operation consist of two major groups; Bus Interface Function messages, and Instrument Specific messages.

Bus Interface

Function Messages

These are low level bus messages defined by IEEE 488.1. A discussion of these messages is beyond the scope of this programming manual. For further information, please refer to your GPIB controller documen tation and/or to IEEE 488.1 Standards documents.Also refer to Ap pendix A at the end of this Programming Manual for a brief primer on the GPIB Interface.Table 1-1 summarizes some of the key Interface Function Messages and the 37XXXD response to them.

Table 1-1. IEEE-488 Interface Function Messages

Interface Function

Message

DCL SDC

GTL Go To Local Yes Returns the 37XXXD to local (front panel) control.

GET Group Execute Trig-

IFC Interface Clear No Stops the 37XXXD GPIB from talking/listening.

LLO Local Lockout No Disables the front panel RETURN TO LOCAL key.

REN Remote Enable No Places the 37XXXD in remote when addressed to listen.

Message Function

Device Clear Selected Device Clear

ger

Addressed

Command

Yes

Yes Executes a string of commands defined by the IEEE 488.2

Resets the 37XXXD GPIB communication functions. Resets the 37XXXD GPIB communication functions.

common command *DDT. A GET is also done by using the *TRG command (see Chapter 10, Command Dictionary).

37XXXD VNA Response

37XXXD Specific

Messages

The 37XXXD specific GPIB messages (also known as commands, que ries, and mnemonics) are used to control 37XXXD front panel func

tions. They also provide for remote only operations such as data transfers, status reporting and service request generation, error re porting, and instrument-to-application program timing synchroniza

tion. Refer to Chapter 10, Command Dictionary; Appendix B, Quick Refer

ence Guide; and Chapters 4-9 for information on all 37XXXD com

mands. The commands are organized both alphabetically and by command function groups.There are many examples throughout this manual to assist you in learning and using a desired command.

Most 37XXXD commands are three character contractions of their functional descriptions.Examples include: OM1 (Output Marker 1),

1-8 37XXXD PM

GENERAL INFORMATION GPIB COMMUNICATION

IFV (input Frequency List), TRS (Trigger Sweep), WFS (Wait for a Full Sweep), OFD (Output Final [display format] Data), and PFS (Print Full Screen).

Numeric parameter entry commands must be followed by a numeric value. These commands can optionally accept a units or suffix termi nator mnemonic. For example, SRT 2 GHZ (set start frequency to 2 GHz.)

Query commands,typically ending in a question mark (?), are used to inquire about the state of a particular instrument function. Many 37XXXD setup commands have corresponding query commands listed in the same section as the basic setup command. An example is the

MK1? query.It outputs the setting of Marker 1 Frequency,where the MK1 command sets Marker 1 frequency.

IEEE 488.2 Common commands, which always start with the asterisk character (*), are defined by the IEEE 488.2 Standard. They are used to implement many standard instrument GPIB operations such as querying when an operation completes, status reporting,self test, and querying the instrument identification string. These commands are described throughout the Programming Manual in the specific funtional group where they are used. A consolidated listing of these commands can be found in Table 1-2, item 12 below and in Chapter 7. An example IEEE 488.2 Common command is the *IDN? query (Output Instrument ID String.)

Separator

Characters

Terminator

Character

GPIB Error

Conditions

Separator characters are used to delimit program message elements sent to or received from the 37XXXD. The permitted characters: semicolon (;), comma (,), and space ( ) and their usage is shown below.

Character Used to separate

;

Space A command, its numerical entry value, and suffix mnemonic.

Multiple commands and multiple output response messages.

Multiple ASCII data elements for a single command.

The only allowed terminator character for 37XXXD GPIB messages is the linefeed character (0A, decimal 10).

The 37XXXD responds to GPIB errors in the following manner:

A beep is issued.

An error message is displayed on the screen.

A bit is set in the Standard Event Status Register, and, if en

abled, an SRQ is generated.

37XXXD PM 1-9

GPIB COMMUNICATION GENERAL INFORMATION

An entry is written into the non-volatile Service Log describing

the error condition, along with time and date and, often, details helpful in handling the error.When full, error entries at the bot tom of the log are removed to make room for new entries.

If the error is GPIB related, the error message and the offending

program message, if applicable, can be output over the GPIB via a query command. The previous error, if any, is also available via another query.

The bits set in the Standard Event Status Register for GPIB errors are as follows:

Bit 5 - Command Error (CME)

Invalid syntax, unrecognized command or command arguments, separaters or terminators that do not conform to correct IEEEE 488.2 formats. The 37XXXD will ignore the remainder of commands in that

program message.

Bit 4 - Execution Error (EXE)

This bit is set if: (1) A data entry parameter is out of range or not applicable. (2) Action is impossible. (3) Action is not possible in the current context or instrument state, or

if a required option is not fitted.

Testing the 37XXXD

GPIB Operation

Bit 3 - Device Dependent Error (DDE)

This bit is set if a valid requested action failed due to an instrument specific error condition, such as attempting to access a bad floppy disk.

Bit 2 - Query Error (QYE)

This bit is set if the 37XXXD cannot provide the requested data. For example, if an output is attempted when no data has been requested or available,or if the output buffer is cleared due to sending more com mands when data from a previous request has not yet been output.

Refer to Chapter 12, Error messages, for a listing of all 37XXXD error messages (including GPIB errors).

The following test can be used to check your GPIB cable and 37XXXD GPIB connectors.

1. Disconnect all GPIB cables from the 37XXXD.

2. Connect your GPIB cable between the two GPIB connectors on the

37XXXD rear panel.

3. Invoke the test from the front panel as follows: Option Menu key,

DIAGNOSTICS,PERIPHERAL TESTS,GPIB TEST.The test will run for a few seconds, then report the result on the front panel dis play.

1-10 37XXXD PM

GENERAL INFORMATION IEEE 488.2 SUMMARY

1-6 IEEE 488.2 SUMMARY Table 1-2 provides answers to the “Device Documentation Require

ments” listed in the IEEE Standard 488.2-1992. It is also a good sum mary of the GPIB operational characteristics of the 37XXXD.

Table 1-2. 37XXXD IEEE 488.2 Standard Documentation Summary (1 of 3)

Number Requirement Item Implementation in VNA

1 Interface Function Subsets Implemented SH1, AH1, T6, L4, SR1, RL1, PP1, DC1, DT1, C0, E2.

2 Device behavior when the user (unit) GPIB address

is set outside of the 0–30 range

3 When is a user address change recognized? New address is accepted and entry color remains

4 Description of settings at power-on The front panel setup that was in effect prior to power

VNA returns an Out-of-Range error, issues an audible beep, and the entry color on front panel menu display is changed to red. Entered address is not accepted.

green.

down will be restored, except: the 37XXXD will be taken out of hold if it was previously set. Periodic IF Cal will be returned to timed operation.

Memories saved:

1. GPIB address

2. Internal hardware calibration data

3. Information reported via the *IDN? and *OPT? queries.

4. Calibration coefficients

5. Normalized trace data

6. Stored front panel setups

Memories Cleared:

1. Service Request message.

2. Standard event status register (except the Power-On bit is set)

3. Extended event status register

4. Limit pass/fail status register

5. Enable registers for items 2 thru 4, above.

6. GPIB input and output queues.

7. Trigger action for *TRG and GET reset to null.

Data Transfer:

1. Data transfer is reset to MSB first for numerical array data transfers.

2. Data transfer format is reset to default, ASCII mode (FMA) for numerical array transfers.

3. Data pair format for OFD/IFD/OM1-OM6 commands is set to default (off) mode. (See command DPR0.)

Menu Displayed:

Setup Menu

37XXXD PM 1-11

IEEE 488.2 SUMMARY GENERAL INFORMATION

Table 1-2. 37XXXD IEEE 488.2 Standard Documentation Summary (2 of 3)

Number Requirement Item Implementation in VNA

5 Message exchange options

a. Size and behavior of input buffer a. Default size = 3 KByte. Size increases to required

amount, as needed, for <Arbitrary Block> transfers.

b. Queries that return more than one <RESPONSE MESSAGE UNIT>

c. Queries that generate a response when parsed c. All d. Queries that generate a response when read d. None e. Commands that are coupled e. None

6 Functional elements used in construction of device-

specific commands.

For the <Indefinite Length Arbitrary Block> data ele ments, the input buffer size for that element is 64 Kbyte. Attempting to program more data than 64 KByte will cause a loss of all data for that ele ment. A DDE error message will be issued to indi cate this condition. For <Definite Length Arbitrary Block> data elements, an attempt is made to set the buffer size for that element to the size indicated in the header. If there is insufficient system memory available at the time, all data for that element is lost. A DDE error message will be issued to indicate this condition.

b. None

See command descriptions.

7 Buffer size limitations 37XXXD Attempts to allocate amount required; sets

DDE error if not possible. (See 5a., above)

8 <PROGRAM DATA> elements that may appear

within an <expression>

9 Response syntax for queries See command descriptions.

10 Description of device-to-device message transfer

traffic that does not follow the rules for <RESPONSE MESSAGES>

11 Size of block data responses Variable, See command descriptions for details.

12 IEEE.488.2 Common commands and queries that

are implemented

13 State of VNA following the successful completion of

the Calibration query

14 Maximum length of the block used to define the trig

ger macro (1.) The method of interpreting *TRG within a *DDT command sequence (2.)

N/A (expressions are not used)

None

*CLS, *DDT, *DDT?, *ESE, *ESE?, *ESR?, *IDN?, *IST?, *OPC, *OPC?, *OPT?, *PRE, *PRE?, *RST, *SRE, *SRE?, *STB?, *TRG, *TST?, *WAI

Normal State

1. 255 characters.

2. On execution, the 37XXXD returns a command error and ignores the rest of the string.

1-12 37XXXD PM

GENERAL INFORMATION IEEE 488.2 SUMMARY

Table 1-2. 37XXXD IEEE 488.2 Standard Documentation Summary (3 of 3)

Number Requirement Item Implementation in VNA

15 Maximum length and complexity of macro labels;

maximum length of block used to define a macro; and how recursion is handled during macro expan sion, if macro commands are implemented.

16 Response to common query *IDN?. ANRITSU, <Model>, <SN>, <SW revision>

17 Size of the protected user data storage area, if the

*PUD command or *PUD? query are implemented.

18 Size of resource description, if the *RDT command

or *RDT? query are implemented.

19 States affected by *RST, *LRN?, *RCL, and *SAV. *RST = default state (see Chapter 11),

20 Scope of the self test performed by *TST? command. Fully automated internal hardware testing/reporting.

21 Additional status data structures used in status re-

porting.

22 Statement describing whether each command is

overlapped or sequential.

23 Functional criteria that is met when an operation

complete message is generated in response to that command.

N/A

*LRN, *RCL, *SAV not implemented

Failure results, if any, are written to the internal nonvolatile service log for user access.

Limits Event Status and Extended Event Status registers; refer to Chapter 7 for details.

All commands are sequential.

N/A – No overlapped commands.

24 Descriptions used for infinity and not-a-number. N/A

37XXXD PM 1-13/1-14

Chapter 2 GPIB and Ethernet Programming Basics

Table of Contents

2-1 INTRODUCTION .........................2-3

2-2 EQUIPMENT AND CONFIGURATION .............2-3

Required Equipment.....................2-3

Configuration.........................2-4

2-3 GPIB PROGRAM ELEMENTS ..................2-5

National Instruments GPIB Interface ...........2-5

Definitions ..........................2-5

2-4 INITIALIZING THE GPIB ....................2-6

2-5 SHUTTING DOWN THE GPIB SYSTEM ............2-6

2-6 DETECTING GPIB ERRORS...................2-7

Full Error Detection .....................2-7

Limited Handling Error Detection .............2-7

NI488 Global Variables ...................2-7

Example ...........................2-7

2-7 GPIB OPERATION TIME OUT..................2-8

Example ...........................2-8

2-8 SENDING GPIB COMMANDS ..................2-9

Example: ...........................2-9

37XXXD Commands Used..................2-9

2-9 RECEIVING GPIB DATA ....................2-10

Example: ..........................2-10

Error Handling:.......................2-10

37XXXD Commands Used .................2-11

Table of Contents (Continued)

2-10 GPIB SRQ HANDLING .....................2-11

Calculating the Binary Weighted Bit Value........2-11

Enabling Service Request .................2-11

Example...........................2-11

Commands Used ......................2-12

NI488 RQ Functions ....................2-12

2-11 COMPLETE GPIB OPERATIONS ...............2-13

Example 1..........................2-13

Example 2..........................2-13

37XXXD Commands Used .................2-14

2-12 ETHERNET PROGRAMMING .................2-15

Ethernet and GPIB Differences ..............2-15

Ethernet Communication Steps ..............2-16

Example Program......................2-23

2-2 37XXXD PM

Chapter 2 GPIB and Ethernet Programming Basics

2-1 INTRODUCTION This chapter contains a brief introduction to GPIB and Ethernet

programming techniques and describes procedures to be used when preparing programs for the 37XXXD VNA. It includes information about equipment requirements and configuration for GPIB control of the 37XXXD VNA, and many programming tips.

2-2 EQUIPMENT AND

CONFIGURATION

Required Equipment The following equipment represents a minimum GPIB controllable

Familiarity with manual (front panel) operation of the 37XXXD is as sumed. (Throughout this section, the 37XXXD VNA is referred to sim ply as “37XXXD”.) A complete description of front panel operation is contained in the appropriate 372XXD or 373XXD Vector Network Analyzer System Operation Manual.

The GPIB programming examples contained in this chapter assume the equipment listed below is present and configured as described.

37XXXD VNA system:

A 37XXXD Vector Network Analyzer.

A computer/controller that supports the IEEE 488 GPIB stan dard. The examples in this chapter address the IBM compatible computers.

An IEEE-488 GPIB interface (built in, or add-in peripheral card) with appropriate driver software. The National Instruments GPIB IEEE-488.2 interface is assumed for all examples in this chapter.

Appropriate software (any of the following):

Microsoft QuickBASIC, version 4.0 (or later)

Microsoft “C”, version 5.1 or later, or Quick C, version 2.5.

Any other programming language, or application software, that supports the IEEE 488 GPIB interface (Pascal, Fortran, etc.).

A GPIB cable (preferably 2 meters long).

37XXXD PM 2-3

EQUIPMENT AND CONFIGURATION GPIB PROGRAMMING BASICS

To:

IEEE 488.2 Interface

From:

IEEE 488.2 Interface

Connector

Figure 2-1. Model 37XXXD Shown Connected to an IEEE 488.2 Controller

The IBM PC and National Instruments GPIB interface were chosen for demonstrating the 37XXXD GPIB operation in this manual. Any other GPIB controller that conforms to the IEEE 488 standard can be used to interface to the 37XXXD.

Connector

NOTE

Channels

Measurement

Display

Enhancement

Configuration Configure the 37XXXD as shown in Figure 2-1. Apply power to the

37XXXD and allow the system software to load from disk. Once the

GPIB

IEEE488.2

Refertomanual

SR1

RL1

SH1

AH1

DC1

DT1

Dedicated

Peripherals

Communications

PP1

GPIB

WARNING

NOOPERATORSERVICE-

ABLEPARTSINSIDE.

REFERSERVICINGTO QUALIFIEDPERSONNEL.

forGPIBAddress

CAUTION

>18Kg

HEAVYWEIGHT

IEEE488.2

SH1

AH1

ExternalSCSI-2Hard DiskDrive

10MHzRef

In 5dBm50

Ext

AnlgOut

AnlgIn

ExternalI/O

BiasFuses

Port1

U S E

E S U

S E

F.5A250V

GPIB

SR1

RL1

PP1

DC1

DT1

GPIB connector

GPIB

Dedicated

TestSet

ControlOut

CAUTION

TerminateUnused

+20dBMMAX,0VDC

Inputs

AVOIDSTATICDISCHARGE

IFInputs<270 MHz

Out 5dBm50

a1 a2b1 b2

Ext

Trigger

CAUTION

FORCONTINUEDFIRE PROTECTIONREPLACE ONLYWITHSPECIFIED TYPEANDRATEDFUSE.

-LINEINPUT 400VAMAX

48-63Hz

85-264VAC REPLACEFUSEONLYWITH SAMETYPEANDRATING

software has finished loading and start-up testing is complete, the 37XXXD is ready to be remotely controlled via the GPIB. It is impor tant to note that the 37XXXD will not respond to GPIB commands un

til the 37XXXD system software has been loaded.

Connect a GPIB cable from the computer/controller to the rear panel

Port2

U S

E S U

F U

S E

IEEE 488.2 GPIB connector (left). Apply power to the computer/controller and load the appropriate pro

gramming language software (QuickBASIC, “C”, etc.). The default GPIB address for the 37XXXD (6) is assumed for all exam

ples in this chapter.

2-4 37XXXD PM

GPIB PROGRAMMING BASICS GPIB PROGRAM ELEMENTS

2-3 GPIB PROGRAM

ELEMENTS

Instruments GPIB

National

Interface

The discussions in this chapter demonstrate basic GPIB programming concepts that are typical elements of most GPIB application programs.

The controller used to demonstrate these concepts is the National In struments 488.2 GPIB Interface which will be referred to as NI488 throughout this chapter.

NOTE

Regardless of the controller used, consult its documenta tion and software distribution disks for complete details and examples on setup and use of the controller's hard ware and interface software functions.

Throughout this chapter references will be made to variables, con stants, and controller function calls declared in the NI488 file that your application uses to interface to the GPIB controller. This file is decl.h for C and qbdecl.bas for QuickBASIC,and it must be in cluded in your GPIB program. Consult your documentation for the files used for other environments.

Including and compiling the appropriate NI488 file when preparing your application is what allows use of the NI488 GPIB interface procedures and function calls in your program. Also, the file named gpib.com must be installed in memory upon bootup of your computer. Typically, access to this file is through your system configuration file (that is,config.sys for DOS based computers).

The gpib.com is what allows your GPIB program to physically interface to the installed GPIB controller and to execute GPIB function calls during operation.

NOTE

Consult your controller's documentation for complete de tails on software and hardware setup, test, and use prior to proceeding with the following discussion. Knowledge of your controller and its operation will be assumed from this point forward.

Definitions The following definitions apply for the remainder of this chapter:

board = 0, Active controller board number

address = 6, GPIB address of the instrument.

Address List = addresList, list of GPIB addresses terminated with the NI488 constant NOADDR. For our examples the list con sists of two elements (6, NOADDR).

37XXXD PM 2-5

INITIALIZING THE GPIB GPIB PROGRAMMING BASICS

2-4 INITIALIZING THE GPIB Initializing is the process of directing your controller to take control of

the bus (become CIC — Controller In Charge) and setting the GPIB software to initial default settings.

NOTE

Default initial installation configuration is assumed for the NI488 hardware and software.

2-5 SHUTTING DOWN THE

GPIB SYSTEM

NI488 does this by sending an interface clear to the desired board us ing:

SendIFC(board)

The board will become CACS (Active controller). NI488 software al lows use of up to 4 controllers. The board specified by the SendIFC() function must be designated CIC – Controller In Charge in its setup and configuration. See NI488 config utility in NI488 documentation.

SendIFC() is also useful anytime you want to insure that your GPIB controller has control over the bus, the GPIB software is in its default parameters, and GPIB of all instruments on the bus is cleared and in idle state.

The following NI488 functions are also useful when initializing your application.

To place all instruments in remote state,use:

EnableRemote(board, addressList)

To clear GPIB operation of all instruments use:

DevClearList(board, addressList)

An important step in quitting a GPIB application is to shut down the GPIB interface. For the NI488 this is done by

Insuring that you have control over the bus.

Clearing all instruments' GPIB and placing them in an idle state.

Releasing the controller GPIB software and hardware.

Implement the above by sending:

SendIFC(board) ibonl(board, 0)

2-6 37XXXD PM

GPIB PROGRAMMING BASICS DETECTING GPIB ERRORS

2-6 DETECTING GPIB

ERRORS

Full Error Detection Full error detection and handling is an invaluable debugging tool that

Limited Handling

Error Detection

NI488 Global

Variables

It is important to use error checking code throughout your application program. Error checking usually does not significantly impact the speed of a GPIB application. This is because the GPIB bus operations are I/O operations whose execution time depends on a handshake pro cess. This process is typically much slower than executing (error checking) code in your computer's memory.

should be used to its fullest during development of your application. Error detection with at least a limited amount of handling should be

used after each GPIB I/O operation in your final program. This will in sure predictable operation of your application, proper system control, and accurate data processing.

The NI488 interface maintains three global variables useful in deter mining correct GPIB operations. These variables are updated after, and reflect the condition of, the last GPIB call to the interface. The variables are:

IBSTA

This variable provides the latest bus activity status; that is,errors, completions, time outs, etc.

q IBERR

This variable provides information on the type of error, if an error was reported in IBSTA.

IBCNT/IBCNTL

The number of data bytes transferred on the bus in the last operation. IBCNTL is the “long integer” version of IBCNT.

Example Error checking for the NI488 interface is as follows. After each GPIB

call, the IBSTA is checked for errors using the NI488 declared con stant EERR - in BASIC, or ERR in C. If true, the gpiberr() function is called to decode and display the global variables IBSTA, IBERR, and IBCNT. For example,for QuickBASIC,the following code is inserted af ter a GPIB call:

IF IBSTA% AND EERR THEN

CALL gpiberr (error during GPIB operation)

END IF

NOTE

The NI488 disks and documentation contain the source listing of the gpiberr() function. This function should be copied into your code and used after each GPIB function call. Use the example programs provided on the NI488 dis tribution disks.Note that gpiberr() can also be modified to fit a particular application's requirements.

37XXXD PM 2-7

GPIB OPERATION TIME OUT GPIB PROGRAMMING BASICS

2-7 GPIB OPERATION

TIME OUT

Setting GPIB time out is necessary to allow for lengthy instrument op erations to complete before the application program continues with its processing. (Refer to section 2-1, Waiting for Instrument Operations to Complete.)

Example The NI488 time out is set using the ibtmo() interface call, as follows:

ibtmo(instrument_handle, timeout_setting)

Where:

instrument_handle = The value returned by the ibfind() or

ibdev() interface call for the instrument. timeout_setting = A value that disables or sets the time out

setting. NI488 uses declared constants to represent the allowable time out settings,for example, the T100s constant is 100 seconds, T30ms is 30 milliseconds, TNone is 0, etc. The complete list is in the NI488 include file for your language (qbdecl.bas, decl.h).

NOTE

Consult NI488 documentation and distribution disks for information and an example on using ibtmo(), ifbind(), and ibdev().

2-8 37XXXD PM

GPIB PROGRAMMING BASICS SENDING GPIB COMMANDS

2-8 SENDING GPIB

COMMANDS

GPIB controllers provide for sending GPIB commands to an instru ment (or the controller itself if its address is used). The NI488 uses several commands,the most common is:

Send (board, address, buffer, numBytes, eot_mode)

Where:

board, address = see section 2-3 for definitions.

buffer = String of one or more instrument specific GPIB com

mands from the defined list in the instrument's GPIB documenta tion.

buffer = String of one or more instrument specific GPIB com

mands from the defined list in the instrument's GPIB documenta tion.

numBytes = The number of bytes contained in the buffer.

eot_mode = The method used to signal end of transmission. This

is typically done using ASCII linefeed character 0A hex (10 decimal) and then setting EOI state (end of transmission) on the bus. The NI488 defines the following constants for use to setup end of transmission methods:

n NLend - Linefeed with EOI

DABend - EOI only

NULLend -Do nothing to mark end of transmission

Example: Send the 37XXXD at address 6, the commands “CH2;DSP;MAG”, from

37XXXD Commands

Used

controller number 0, using the linefeed with EOI to mark the end of transmission:

Send (0, 6, “CH2;DSP;MAG”,11,NLend)

The above example uses the following commands defined in the 37XXXD command set:

CH2 - sets active channel to 2,

DSP - displays only the active channel on the

whole screen,

MAG - displays the active channel's data in log magnitude format (dB).

NOTE

The semicolon (;) is used to separate the different com

mands.

37XXXD PM 2-9

RECEIVING GPIB DATA GPIB PROGRAMMING BASICS

2-9 RECEIVING GPIB DATA In order to receive data from an instrument over the GPIB, you must

first instruct the instrument to output the desired data. You do this by using one of the instrument's defined data output commands and the controller Send() function (see section 2-8, “Sending commands”).

The instrument must then be given permission to start sending data (talk). The NI488 call to do this is:

Receive(board, address, buffer, numBytes,

eod_mode)

Where:

board, address = see section 2-3 for definitions.

buffer = The name of the memory address of the buffer where

the received data is to be placed. Typically this is an array of type characters (a string). Although, for binary data transfers, the NI488 software will accept an array of almost any type; that is. integer, floating point, etc.

numBytes = The maximum number of bytes to read from the in-

strument. Insure that “buffer” above is of at least this size. eod_mode = The method used to signal the controller to stop re-

ceiving data. Typically the NI488 constant STOPend is used (EOI state – end of transmission – set with the last byte). If you want to stop receiving when a certain transmission terminator character is received, then use the hex value of that character instead of the STOPend.

Example: Use the NI488 controller number 0, to send the 37XXXD at address 6,

the command “ONP” using the line feed with EOI to mark end of transmission:

Send(0, 6, “ONP”, 3, NLend)

Upon receiving a data output command, the 37XXXD will prepare the data requested and wait for the controller to put it in the talk state so it can put the data out on the bus. This is done by:

numBytes = 20

Receive(0, 6, buffer, numBytes, STOPend)

Error Handling: The number of bytes actually sent on the bus can now be retrieved

from the NI488 interface software by immediately storing the value of the IBCNT global variable in a program variable as follows:

actualReceivedBytes = IBCNT

2-10 37XXXD PM

GPIB PROGRAMMING BASICS GPIB SRQ HANDLING

37XXXD Commands

Used

If we expected an exact number of bytes to be received, we can com pare the requested number of bytes “numBytes” with the actual re ceived “actualReceievedBytes” and take some corrective action if they do not match. You should do this before continuing to the data process ing section of the program:

If numBytes ISNOTEQUALTO actualReceivedBytes then

Call gpiberr(”incorrect number of bytes received”)

END IF

NOTE

Consult your programming language syntax for the opera tor used to check in-equality, to use in place of ISNOTE QUALTO.

The above example uses the following commands defined in the 37XXXD command set:

ONP – Outputs the number of data points in the current sweep. It

will output the number represented in ASCII format.

2-10 GPIB SRQ HANDLING Controllers use a dedicated line on the GPIB to detect if an instrument

has requested service.An instrument sets this line when a predetermined set of conditions inside it have been met. These conditions are selected and programmed into the instrument by setting the Service Request Enable Register to a decimal value that corresponds to the bit values which, when true, will generate an SRQ. This is a binary weighted decimal value in the range 0 – 255.

Value

The decimal value of a bit in a register is equal to the number 2 raised to a power equal to the bit number. For example, the decimal value of bit 4 in the Service Request Enable Register is 2 raised to the power 4 which is: 2

To enable service request in the 37XXXD,use the command *SRE Service Request Enable,with the desired value.

when it has data to send, then output the number of points in the cur rent sweep. We need to enable bit 4 (MAV), Message Available, in the Service Request Enable Register,so a service request will be gener ated when the data is ready. The decimal value of bit 4 is 16 (2

The NI488 Send() function is used to send the 37XXXD at address 6, the commands “*SRE 16;ONP” (12 ASCII bytes), from controller num ber 0, using the linefeed with EOI to mark end of transmission:

= 16. Similarly, the decimal value of bit 0 is: 20=1.

Send(0, 6, “*SRE 16;ONP”, 12, NLend)”

= 16).

Calculating the Bi

nary Weighted Bit

Enabling Service

Request

Example Command the 37XXXD to request service; that is,generate an SRQ,

37XXXD PM 2-11

GPIB SRQ HANDLING GPIB PROGRAMMING BASICS

Commands Used The above example uses the following commands defined in the

37XXXD command set:

*SRE – Sends a Status Request Enable mask. ONP – Outputs the number of sweep points.

NI488 RQ Functions The following NI488 functions are useful in handling SRQ operations.

Consult your NI488 documentation for full details.

To test for occurrence of SRQ:

TestSRQ(board, SRQset)

Where:

SRQset contains 1 if SRQ is set, or 0 if it is not.

To wait for occurrence of SRQ and report if it was set:

WaitSRQ(board, SRQset)

Where:

· SRQset contains 1 if SRQ was set within the time out allowed, or 0 if it was not. (See section 2-8, Setting GPIB Operation Time Out.)

q To find out which instrument is requesting service (set SRQ), in-

struct the controller to perform a serial poll and return the results as follows:

FindRQS(board, addressList, statusByte)

Where:

statusByte = The status byte of the first requester found is returned in this variable.

The index in addressList that contains the address of the instrument requesting service is returned in the IBCNT global variable.

To read out the SRQ byte from an instrument:

ReadStatusByte(board, address, statusByte)

To parallel poll, see the following functions in the NI488 docu

mentation.

PPoll()

PPollConfig()

PPollUnconfig()

2-12 37XXXD PM

GPIB PROGRAMMING BASICS COMPLETE GPIB OPERATIONS

2-11 COMPLETE GPIB

OPERATIONS

Example 1 Command the 37XXXD to perform a sweep and hold then place an

Instruments often require a period of time to complete certain opera tions such as disk I/O, measurement sweep, data preparation, etc.. Your application program must allow the instrument time to complete these operations and be able to detect when operations are completed.

The simplest mechanism for synchronizing operations over the GPIB involve using the *OPC? -Operation Complete query and the *OPC Operation Complete command.

ASCII “1" in its output buffer (*OPC?) when done. The NI488 Send() function is used to send the 37XXXD at address 6,

the commands,”HLD;TRS;WFS;*OPC?”, from controller number 0, using the linefeed with EOI to mark end of transmission. The Re ceive() function is then used to hold the program from continuing processing until it receives the output of the *OPC command (or times out):

buffer = “HLD;TRS;WFS;*OPC?”

Send(0, 6, buffer, 17, NLend)

oneByte = 1

Receive(0, 6, buffer, oneByte, STOPend)

NOTE

The time out must be set high enough to allow the sweep to complete (see “Setting time outs” in section 2-8).

Example 2 Now we will modify the above example to request service when bit 4

(MAV) in the Status Byte Register is set (*SRE 16) to let the program know when the *OPC? data is ready to be output. This overcomes the time out problem but it does increase program complexity.

buffer = “*SRE 16;HLD;TRS;WFS;*OPC?”

Send(0, 6, buffer, 25, NLend)

SRQset = 0

WHILE (SRQset = 0)

WaitSRQ(board, SRQset)

ReadStatusByte(board, address, statusByte)

oneByte = 1

Receive(0, 6, buffer, oneByte, STOPend)

NOTE

TestSRQ() can be used instead of WaitSRQ() to check for the occurrence of SRQ in the WHILE loop. This would allow your program to perform other tasks while waiting for SRQ inside the WHILE loop.

37XXXD PM 2-13

COMPLETE GPIB OPERATIONS GPIB PROGRAMMING BASICS

37XXXD Commands

Used

Examples 1 and 2 above used the following commands defined in the 37XXXD command set:

*SRE - sends a Status Request Enable value. HLD - places VNA into hold mode

TRS - triggers a sweep. Since the VNA is already

in hold mode, the hold mode is changed to single sweep and hold.

WFS - waits one full sweep and stops *OPC? - outputs an ASCII “1” when operation is

complete

NOTE

Refer to Chapter 7, Remote Only Operations for more in formation and examples on status reporting and service request generation.

2-14 37XXXD PM

GPIB PROGRAMMING BASICS ETHERNET PROGRAMMING

2-12 ETHERNET

PROGRAMMING

Ethernet and GPIB

Differences

The syntax of programming the Lightning D Series VNA over the Ethernet is the same as the syntax of programming the VNA over the GPIB.Most of the commands supported over GPIB are supported over the Ethernet and the data returned from queries is in the same format as that of the GPIB.

During communication over the GPIB, the start and end of a program message are well defined and important. On reception of a program message, the VNA does nothing until the message has been completely received (an end message indicator is detected). With TCP/IP communication, the concept of the end of a message is somewhat blurred. Consider what happens when you receive a Web page over the Internet. The reception of a Web page takes place over a period of time where different elements are received until the viewer is unable to perceive any further change.

Because all Anritsu VNAs assert the EOI line at the end of a program message during GPIB data transfer,a user can receive GPIB data as rapidly as is possible until the EOI signal is detected. Ethernet communications has no such thing as an EOI line; therefore, the user must employ some other mechanisms to find the end of a program message. IEEE488.2 provides just such a mechanism by allowing the instrument receiving the data to discover the end of the program message by either scanning for the end message byte during reception of ASCII data, and/or utilizing the byte count in arbitrary block headers during binary data transfer.

NOTE

The Arbitrary Length Arbitrary Block header format of IEEE488.2 requires the EOI signal; therefore, this form of arbitrary block cannot be used with TCP/IP communication. Anritsu VNAs do not send this type of arbitrary block, so reception of VNA data is not affected by this issue.

A GPIB device does not send data out without first being addressed to talk, and the data transfer mode set. Over TCP/IP, there is no waiting to be addressed to talk. The VNA has no idea whether the controller is actually listening or not. The data is just simply sent out whenever it appears in the output routine.

37XXXD PM 2-15

ETHERNET PROGRAMMING GPIB PROGRAMMING BASICS

A technique commonly used to measure the bus transfer speed was to command the VNA to output Bitmap image data, or some other large piece of data, and then wait several seconds to insure that the data had been completely generated and ready to go. Then the controller would read the data in as fast as possible while keeping track of the elapsed time. This technique does not work at all over TCP/IP because the data comes out whether the controller is reading or not. What would happen is that the communications channel would be hopelessly blocked with individual messages bouncing back and forth over the Ethernet in a flurry of activity, finally dying out when their transfer timeout occurred. To prevent this, The controller should start listening for data as soon as it is done sending the query message.

IEEE488.2 specifies that all output data is thrown away when a new program message is received before the previously generated data is read completely.The embedded operating system employed in the VNA does not provide a mechanism to throw away TCP/IP data that has been buffered up to be output, short of closing the socket. Of course, if the VNA is receiving data on the socket, closing the socket is not a good idea. Therefore, the data is allowed to linger and will be available until it is completely read out.

Ethernet

Communication Steps

If the VNA input routine has to wait long periods of time without receiving any commands,it will periodically transmit a null byte to test if the connection is still alive. This can cause several leading null bytes in the VNA data. Leading null bytes are known as WHITE space and are permitted in a 488.2 response. So,when receiving data, be sure to check for the leading null characters.

In order to communicate over the Ethernet using TCP/IP and the Winsock dll, a program must perform the following steps:

1 - Load the Winsock dll at the start of the program 2 - Create a local socket for Ethernet communication using the TCP

protocol 3 - Connect the local socket to the VNA 4 - Write commands to the VNA and Read data back as necessary 5 - Close the local socket when done 6 - Unload the Winsock dll at the end of the program An example program etherapp.cpp is included at the end of the

chapter; we will be discussing the important parts of it in this section.

2-16 37XXXD PM

GPIB PROGRAMMING BASICS ETHERNET PROGRAMMING

Step 1. Load the Winsock dll at the start of the program.

The Winsock library includes a function that loads the dll. The version must be specified when the call is made. The code that loads Winsock

2.2 is shown below:

// Load Winsock // status = TRUE; winsockok = TRUE; if (WSAStartup(MAKEWORD(2,2), &wsd) != 0) {

printf("Failed to load Winsock library!\n"); status = FALSE; winsockok = FALSE;

}

Where: wsd is a WSADATA structure. The structure is unimportant to us

since it is only referenced when the Winsock dll is loaded and nowhere else in the program. Notice there are 2 flags associated with loading the dll.

status is a variable that starts out with the value TRUE. If anything goes wrong,it is set FALSE.The intent of status is to bypass any subsequent program operations,seemingly to cause the program to immediately exit.

winsockok is a variable that starts out TRUE, but if the dll loading fails for some reason, it is nice to know when it comes time to unload the dll.

37XXXD PM 2-17

ETHERNET PROGRAMMING GPIB PROGRAMMING BASICS

Step 2. Create a local socket for Ethernet communication using the TCP

protocol. The socket is created using the function socket() which returns the

socket handle sock. If the value of sock is INVALID_SOCKET the function call failed. We should not try to access this socket value.Use the variable status to prevent any further access.

// Create the socket

if (status == TRUE)

{

sock = socket(AF_INET, SOCK_STREAM,IPPROTO_TCP); if (sock == INVALID_SOCKET) {

printf("socket() failed: %d\n", WSAGetLastError()); status = FALSE;

}

NOTE

Do not try to create the socket if the status is FALSE.If we fail to create the socket, we set the status as FALSE. SOCK_STREAM is the type of socket used with TCP and IPPROTO_TCP is the protocol used with TCP.The argument AF_INET is always used regardless.

2-18 37XXXD PM

GPIB PROGRAMMING BASICS ETHERNET PROGRAMMING

Step 3. Connect the local socket to the VNA.

This step is actually two steps. The first is to send the connection request to the VNA using the function connect(), as follows:

// Connect to the VNA // if (status == TRUE) {

// Set up the VNA address first // The port number is always 5000

// vna.sin_family = AF_INET; vna.sin_port = htons(Port); vna.sin_addr.s_addr = inet_addr(ipaddr); // Now connect // if (connect(sock, (struct sockaddr *)&vna, sizeof(vna)) == SOCKET_ERROR) {

printf("connect() failed: %d\n",

WSAGetLastError());

status = FALSE; }

The second part of the connect is to get the VNA acceptance status back from the VNA.

NOTE

We must look at the return code for the function call recv() to see if it failed. If that is OK, we have to check if the VNA refused the connection. Lightning has two available sockets it can assign. If both of those are in use by someone else. The acceptance message will be:

000 Connection refused

37XXXD PM 2-19

ETHERNET PROGRAMMING GPIB PROGRAMMING BASICS

The following example shows how to get the VNA acceptance status back from the VNA:

// Get the connection OK from the VNA // will be one message as below // 100 Connection accepted - 23 bytes // 000 Connection refused - 22 bytes if (status == TRUE) {

ret = recv(sock, idn_buff, sizeof(idn_buff), 0); if (ret == SOCKET_ERROR)

{ printf("recv() failed: %d\n", WSAGetLastError()); status = FALSE;

} // Test if connection is accepted else {

// Print out response

idn_buff[ret] = 0;

printf("%s\n", idn_buff);

// Set flags

if (strncmp(idn_buff, "100 Connection accepted",

23) != 0)

status = FALSE; }

}

2-20 37XXXD PM

GPIB PROGRAMMING BASICS ETHERNET PROGRAMMING

Step 4. Write the commands to the VNA and read back the data as necessary.

For this particular example there are also two steps, to send a command and to receive an ASCII response back.

// Send the query // if (status == TRUE) {

sprintf(say_buff, " %s \n", message); ret = send(sock, say_buff, strlen(say_buff), 0); if (ret == SOCKET_ERROR) {

printf("send(%s) failed: %d\n", message, WSAGetLastError());

status = FALSE; } else printf("Sent '%s' %d bytes\n", message, ret);

}

The second part is to receive the response.

NOTE

It is a little more complex since we have to loop until a line feed is received. This is the clue that an ASCII response is complete. Notice at the lower section where the response is printed, leading nulls are skipped over. As mentioned earlier, the receive code may be sending these periodically.

// Receive the response // if (status == TRUE) {

byte_count = 0; done_flag = FALSE; aux_ptr = idn_buff; while ((done_flag == FALSE) && (status == TRUE)) {

ret = recv(sock, aux_ptr, sizeof(idn_buff), 0);

if (ret == SOCKET_ERROR)

{

37XXXD PM 2-21

ETHERNET PROGRAMMING GPIB PROGRAMMING BASICS

printf("recv() failed: %d\n", WSAGetLastError());

status = FALSE; } else {

// Do a test for the line feed at the end

aux_ptr[ret] = 0;

end_ptr = strchr(aux_ptr, (int)'\n');

// Bump up to the end of the received stuff

// Update the running byte count

aux_ptr += ret;

byte_count += ret;

// If a line feed was found, we are done

if (end_ptr != NULL)

{

done_flag = TRUE; // Overwrite the line feed at the end *end_ptr = 0; }

} } // If we received something print it out if (status == TRUE) {

// Bump over any leading nulls

aux_ptr = idn_buff;

while(*aux_ptr == 0) aux_ptr++;

// Print out the ltrimmed string

printf("RECV [%d bytes]: '%s'\n", byte_count,

aux_ptr);

} }

2-22 37XXXD PM

GPIB PROGRAMMING BASICS ETHERNET PROGRAMMING

Step 5. Close the local socket when done.

Closing the socket is very important. If you close the socket, it will be detected almost immediately by the VNA, any lingering data is cleared, and the memory is returned to the memory pool. More importantly,the socket will be closed making it available for another connection later.Lightning only has two sockets it can use to connect. If these sockets are not closed, communication will come to a screeching halt. Eventually, a VNA socket will be closed when the receive code sends a null byte, but this normally takes several seconds. Be sure to CLOSE THE SOCKET when you are done with it. It is good programming practice to take care of loose ends before closing a program.

// Close the socket if it was created if (sock != INVALID_SOCKET) closesocket(sock);

Step 6. Unload the Winsock dll at the end of the program.

This is another one of those loose ends that you must take care of.If the Winsock dll is not unloaded, it leaves a process still running, even though the program has terminated. In most cases, this running process will not permit a new instance of the program, evidenced by clicking on the program and nothing happening. Be sure to UNLOAD THE WINSOCK DLL when you are done with it.

// Unload the Winsock dll if it was loaded if (winsockok == TRUE) WSACleanup();

Example Program Unlike all those example Winsock TCP/IP programs you find on the

internet, this program was specifically written for a Lightning VNA using Microsoft Visual Studio 6.0. You might want to try it and see how easy it is to write TCP/IP applications.

This is a console program. You can open a DOS window, change to the directory where you have the program and type:

etherapp onp;oid 172.26.208.126

If the device whose address is 172.26.208.126 is a VNA, you will get something similar to the following displayed on the screen:

100 Connection accepted Sent 'onp;oid' 10 bytes RECV [49 bytes]: '401;37247A,0.040000,20.000000,-15.00,0.00,004.81'

Here is the source code for the program:

37XXXD PM 2-23

ETHERNET PROGRAMMING GPIB PROGRAMMING BASICS

// Etherapp.cpp // A simple console application that performs sends a // query command to the vna and gets the response back // Be sure to link this with the library ws2_32.lib // winsock2.h is part of windows #include <winsock2.h> #include <ctype.h> #include <string.h> #include <stdio.h> #include <stdlib.h> #define TRUE 1 #define FALSE 0 int main(int argc, char **argv) {

short status; short winsockok; short done_flag; WSADATA wsd; SOCKET sock; int ret; int byte_count; unsigned short Port; struct sockaddr_in vna; char ipaddr[32]; char message[128]; char say_buff[256]; char idn_buff[256]; char *aux_ptr; char *end_ptr; // The query command we will be sending // Port = 5000; // Take the query from the command line // if (argc > 1) strcpy(message, argv[1]); else strcpy(message, "*IDN?"); // Take the vna ip address from the command line //

2-24 37XXXD PM

GPIB PROGRAMMING BASICS ETHERNET PROGRAMMING

if (argc > 2) strcpy(ipaddr, argv[2]); else strcpy(ipaddr, "172.26.208.131"); // Load Winsock // status = TRUE; winsockok = TRUE; if (WSAStartup(MAKEWORD(2,2), &wsd) != 0) {

printf("Failed to load Winsock library!\n"); status = FALSE;

winsockok = FALSE; } // Create the socket, and attempt to connect to the server // if (status == TRUE) {

sock = socket(AF_INET, SOCK_STREAM, IPPROTO_TCP);

if (sock == INVALID_SOCKET)

{

printf("socket() failed: %d\n", WSAGetLastError()); status = FALSE;

} } // Connect to the VNA // if (status == TRUE) {

// Set up the VNA address first

vna.sin_family = AF_INET;

vna.sin_port = htons(Port);

vna.sin_addr.s_addr = inet_addr(ipaddr);

// Now connect

if (connect(sock, (struct sockaddr *)&vna, sizeof(vna)) == SOCKET_ERROR)

{

printf("connect() failed: %d\n", WSAGetLastError()); status = FALSE;

37XXXD PM 2-25

ETHERNET PROGRAMMING GPIB PROGRAMMING BASICS

} // Get the connection OK from the VNA // will be one message as below // 100 Connection accepted - 23 bytes // 000 Connection refused - 22 bytes if (status == TRUE) {

ret = recv(sock, idn_buff, sizeof(idn_buff), 0); if (ret == SOCKET_ERROR) {

printf("recv() failed: %d\n", WSAGetLastError());

status = FALSE; } // Test if connection is accepted else {

// Print out response

idn_buff[ret] = 0;

printf("%s\n", idn_buff);

// Set flags

if (strncmp(idn_buff, "100 Connection accepted", 23) != 0)

status = FALSE;

}

} } // Send the query // if (status == TRUE) {

sprintf(say_buff, " %s \n", message);

ret = send(sock, say_buff, strlen(say_buff), 0);

if (ret == SOCKET_ERROR)

{

printf("send(%s) failed: %d\n", message, WSAGetLastError());

status = FALSE; } else printf("Sent '%s' %d bytes\n", message, ret);

}

2-26 37XXXD PM

GPIB PROGRAMMING BASICS ETHERNET PROGRAMMING

// Receive the response // if (status == TRUE) {

byte_count = 0; done_flag = FALSE; aux_ptr = idn_buff; while ((done_flag == FALSE) && (status == TRUE)) {

ret = recv(sock, aux_ptr, sizeof(idn_buff), 0); if (ret == SOCKET_ERROR) {

printf("recv() failed: %d\n", WSAGetLastError());

status = FALSE; } else {

// Do a test for the line feed at the end

aux_ptr[ret] = 0;

end_ptr = strchr(aux_ptr, (int)'\n');

// Bump up to the end of the received stuff

// Update the running byte count

aux_ptr += ret;

byte_count += ret;

// If a line feed was found, we are done

if (end_ptr != NULL)

{

done_flag = TRUE; // Overwrite the line feed at the end *end_ptr = 0;

} }

} // If we received something print it out if (status == TRUE) {

// Bump over any leading nulls aux_ptr = idn_buff;

37XXXD PM 2-27

ETHERNET PROGRAMMING GPIB PROGRAMMING BASICS

while(*aux_ptr == 0) aux_ptr++; // Print out the ltrimmed string printf("RECV [%d bytes]: '%s'\n", byte_count, aux_ptr);

} } // Close the socket if it was created if (sock != INVALID_SOCKET) closesocket(sock); // Unload the Winsock dll if it was loaded if (winsockok == TRUE) WSACleanup(); return 0;

}

2-28 37XXXD PM

Chapter 3 Series 37XXXD Programming Examples

Table of Contents

3-1 INTRODUCTION .........................3-3

3-2 37XXXD PROGRAMMING EXAMPLES .............3-3

3-3 EXAMPLE 1 ............................3-4

3-4 EXAMPLE 2 ............................3-6

3-5 EXAMPLE 3 ............................3-8

3-6 EXAMPLE 4 ...........................3-10

3-7 EXAMPLE 5 ...........................3-11

3-8 EXAMPLE PROCEDURE 1 ...................3-12

3-9 EXAMPLE FUNCTION 1 ....................3-13

3-10 EXAMPLE PROCEDURE 2 ...................3-14

Chapter 3 Series 37XXXD Programming Examples

3-1 INTRODUCTION This chapter contains example programs to familiarize the user with

37XXXD programming.Familiarity with manual (front panel) opera tion of the 37XXXD is assumed. Throughout this section, the 37XXXD VNA is referred to simply as “37XXXD.”A complete description of front panel operation is contained in the 37XXXD Vector Network An alyzer System Operation Manual.

3-2 37XXXD PROGRAMMING

EXAMPLES

Also, it is assumed that you have read Chapters 1 and 2 and are famil iar with the information they contain. This information describes the various syntax and functions used in the example sequences presented throughout the chapter.This includes: Send, Receive, IBCNT,IBERR, ISNOTEQUALTO,and others.

The main sequences for five example 37XXXD programs are listed and explained in the following pages. In these examples, the NI488 function calls are abbreviated; refer to Chapter 2 and the NI488 documentation for full details. Refer to the 37XXXD Command Function groups and the Command listings in this manual for complete details on 37XXXD command operations.

NOTE

The functions and procedures called from the example se quences in sections 3-3 through 3-7 are provided at the end of this chapter in sections 3-8 through 3-10.

The intent of these example program sequences is to provide algo rithms useful when programming various features of the 37XXXD. You are encouraged to study these algorithms, copy them into your pro gramming environment, and tailor them for your language and appli cation.

37XXXD PM 3-3

EXAMPLE 1 PROGRAMMING EXAMPLES

3-3 EXAMPLE 1 This example sequence lists and explains some common 37XXXD oper

ations.

Setup display and sweep frequencies

Send (0,6,“CH2;DSP;MPH;SRT 40 MHZ;STP 20 GHZ”,NLend)

Setup markers

Send (0,6,“MK1 40 MHZ;MK2 20 GHZ”,NLend)

Read and store current instrument setup

Request instrument setup string

Send (0,6,“OFP”,NLend)

Read instrument setup string

Receive(instrSetup, MAXSIZE, STOPend)

Get number of bytes transferred3

sizeInstrSetup = IBCNT

NOTE

Program variables instrSetup and sizeInstrSetup will be used later with the IFP command to input the saved setup string.

Read sweep frequencies

Trigger and wait for full sweep then hold

Send (0,6,“HLD;TRS;WFS”,NLend)

Wait for operations to complete (See “Wait for Instr()” example, page 3-12.)

WaitForInstr()

Request sweep frequencies (OFV): Use floating point (64 bit) binary format (FMB), Least Signifi cant Byte first ordering (LSB for IBM/compatible PCs only).

Send (0,6,“LSB;FMB;OFV”,NLend)

Get number of bytes to read: See Chapter 7, “Data Transfer” section for details on <Arbi trary Block> data transfers and structure of the header used to precede and give number of bytes in data block. (See “Get NumBytes( )” example, page 3-13.)

numBytes = GetNumBytes(address, headerString)

Read frequencies freqArray is a floating point double precision array of up to 1601 elements.

Receive(freqArray, numBytes, STOPend)

3-4 37XXXD PM

PROGRAMMING EXAMPLES EXAMPLE 1

Check for complete transfer

if (numBytes ISNOTEQUALTO IBCNT then

gpiberr(“Could not read freq list correctly”)

Reset instrument

Send reset command

Send (0,6,“*RST”,NLend)

Wait for operations to complete (page 3-12)

WaitForInstr()

Download and restore a previously saved setup

Command instrument to receive a setup string. Use

“NULLend” (see Chapter 2, section 2-9.)

Send (0,6,“IFP ”,NLend)

NOTE

The space after the IFP command is needed to separate it from the setup string, which follows.

Send the setup string. Use “NLend” (see Chapter 2, section

2-9.)

Send (0,6,(instrSetup, sizeInstrSetup),NLend)

Check if all data was sent correctly

if (sizeInstrSetup ISNOTEQUALTO IBCNT then

gpiberr(“Error sending setup string”)

Select instrument Marker 1 active

Send (0,6,“MR1”,NLend)

Read measurement trace

Trigger and wait for full sweep then hold

Send (0,6,“TRS;WFS;HLD”,NLend)

Wait for operations to complete (page 3-12)

WaitForInstr()

Request trace data: in final trace graph type values (OFD), in floating point (32 bit) binary format (FMC). Use Least significant Byte first or dering (LSB, for IBM/compatible PCs only)

Send (0,6,“LSB;FMC;OFD”,NLend)

37XXXD PM 3-5

EXAMPLE 2 PROGRAMMING EXAMPLES

Get number of bytes to read (page 3-13)

numBytes = GetNumBytes

Read out the trace data values.

Receive(traceData, numBytes, STOPend)

Check if all data was transferred

if (numBytes ISNOTEQUALTO IBCNT then

gpiberr(“Could not receive data.”)

Calculate number of sweep points in data string

POINTSIZE is 8 bytes for data transfers using the FMB for mat and 4 bytes if using the FMC format. See Chapter 7, “Data Transfer Commands.”

numFreqs = numBytes / POINTSIZE

Put instrument(s) in local to allow use of front panel

EnableLocal(board, addressList)

3-4 EXAMPLE 2 This example sequence lists and explains 37XXXD commands used for

automated 12 Term Calibration.

Display instructions to operator on computer screen

PRINT “Install 33KFKF Phase Equal Insertable on

PRINT “Install 3670K502 Thru Line female side to

PRINT “so the new Port 2 is the male end of the

PRINT “Shape the end of the thru so it is near

PRINT “(Press a key when ready)”

Set up calibration parameters

Send (0,6,“SCM;LTC;C12;ISN”,NLend)

Set up calibration frequencies

Send (0,6,“DFC;FRS 1 GHZ;FRI 100 MHZ;FRP 41;FIL;DFD”,NLend)

Set up connectors and loads

Send (0,6,“P1C;CFK;P2C;CMK;BBL”,NLend)

Begin calibration data collection

Send (0,6,“BEG”,NLend)

Wait for operations to complete (page 3-12)

WaitForInstr()

Port 1”

Port 2”

thru”

Port 1”

3-6 37XXXD PM

PROGRAMMING EXAMPLES EXAMPLE 2

Instruct operator via the controller screen...

To connect ISOLATION DEVICES between Ports 1 and 2 and wait for him; then measure devices. (See TakeCalData(),pg 3-14).

PRINT “Connect ISOLATION DEVICES between

PRINT “Press ENTER when ready” TakeCalData()

Instruct operator via the controller screen....

To connect BROADBAND LOADS between Ports 1 and 2 and wait for him; then measure devices.

PRINT “Connect BROADBAND LOADS between

PRINT “Press a key when ready” TakeCalData()

Instruct operator via the controller screen....

To connect OPEN to Port 1 and SHORT to Port 2 and wait for him; then measure devices.

PRINT “Connect OPEN to Port 1 and SHORT

PRINT “Press a key when ready” TakeCalData()

Ports 1 and 2”

Ports 1 and 2.”

to Port 2”

Instruct operator via the controller screen....

To connect SHORT to Port 1 and OPEN to Port 2 and wait for him; then measure devices.

PRINT “Connect SHORT to Port 1 and OPEN

PRINT “Press a key when ready” TakeCalData()

Instruct operator via the controller screen....

to Port 2

To connect Port 1 and Port 2 with the reminder to NOT INSTALL ADDITIONAL THRU LINES/ADAPTERS BETWEEN PORTS, and wait for him; then measure devices.

PRINT “Connect Port 1 and Port 2 but

PRINT “Press a key when ready” TakeCalData()

DO NOT INSTALL ADDITIONAL THRU LINES/ADAPTERS BETWEEN PORTS

37XXXD PM 3-7

EXAMPLE 3 PROGRAMMING EXAMPLES

3-5 EXAMPLE 3 This example sequence lists and explains 37XXXD commands for

transferring calibration error terms/coefficients.

Setup a Frequency Response Transmission Calibration.

Set up calibration parameters

Send (0,6,“SCM;LTC;CFT”,NLend)

Set up calibration frequencies

Send (0,6,“DFC;FRS 1 GHZ;FRI 100 MHZ;FRP 41;FIL;DFD”,NLend)

Begin calibration data collection

Send (0,6,“BEG”,NLend)

Wait for operations to complete (page 3-12)

WaitForInstr()

Instruct operator via the controller screen...

To connect THRU LINE between Ports 1 and 2 and wait for him.

PRINT “Connect THRU LINE between

PRINT “Press ENTER when ready”

Ports 1 and 2"

Measure thruline (page 3-12).

TakeCalData()

Read Calibration Coefficient Data from instrument and store the 488.2 data transfer header which is useful for sending the same size data array back to the 37XXXD later. Also calculate and store the number of frequency points read in.

Request the error term/coefficient array (OC1) in 64 bit Float ing Point format (FMB), Least Significant Byte order (LSB, for PCs only). See Chapter 7, “Data Transfer Commands” for the error terms returned by the OCx series commands.

Send (0,6,“LSB;FMB;OC1”,NLend)

Get number of bytes contained in the data string and store the header read from the 37XXXD into calHeader (string of charac ters). See GetNumBytes(), page 3-13.

numBytes = GetNumBytes(address, calHeader)

Read calibration data values calData is an 82 element double precision floating point array.

Receive(calData, numBytes, STOPend)

3-8 37XXXD PM

PROGRAMMING EXAMPLES EXAMPLE 3

Check if all data was transferred

if (numBytes ISNOTEQUALTO IBCNT) then

gpiberr(“Could not receive data.”)

Store number of calibration data bytes transferred

calDataSize = IBCNT

Calculate number of frequency points in the data trace if de

sired. POINTSIZE is 8 bytes for data transfer using the FMB format. See Chapter 7, “Data Transfer Commands.” The divi sion by two is because each data point represents a complex data pair (real, imaginary).

numFreqs = (CalDataSize / 2) / POINTSIZE

Send Calibration Coefficient Data to instrument

Simulate a Transmission Calibration

Command the 37XXXD to apply transmission calibration coef ficients to data (AFT), then input the calibration coefficient ar ray for transmission error term (IC1), in 64 bit Floating Point format (FMB), Least Significant Byte order (LSB, for use with PCs only). Use “NULLend” (see Chapter 2, section 2-9.)

Send (0,6,“AFT;LSB;FMB;IC1”,NLend)

NOTE

Note the space after the IC1 command; it is needed to separate it from the calibration coefficient data array, which follows.

Send cal coefficient #1 data transfer header (same one that was received from the OC1 transfer). Use “NULLend” (see Chapter 2, section 2-9.)

calHeaderSize = LENGTHOFSTRING(calHeader) Send (0,6, (calHeader, calHeaderSize, NULLend),NLend)

NOTE

Consult your compiler documentation for a function that returns length of a string.

Check for proper transfer

if (CalHeaderSize ISNOTEQUALTO IBCNT) then

gpiberr(“Data not sent properly”

Send cal coefficient #1 data. Use “NLend” (see Chapter 2, sec

)

tion 2-9.)

Send (0,6,(calData, calDataSize),NLend)

37XXXD PM 3-9

EXAMPLE 4 PROGRAMMING EXAMPLES

Check for proper transfer

if (calDataSize ISNOTEQUALTO IBCNTl then

gpiberr(“Data not sent properly”)

Wait for operation to complete (page 3-12)

WaitForInstr()

Turn on/apply error correction

Send “CON”

3-6 EXAMPLE 4 This is an example sequence showing data string input to the

37XXXD.The string sent below is used to set hardcopy data output la bels.

The 37XXXD requires the double quote characters (“ ”) to delimit ASCII strings being sent to it. That is, to send a string called mystring you would actually send programming languages also delimit a character string with double quotes. In order to send the 37XXXD a quote(“)asaregular character, you must precede it with the backslash (\) character in the C language and with a quote character (”) in BASIC.

“

mystring”.This presents a problem since

NOTE

A 37XXXD ASCII string may also be delimited using a single quote character(')atthebeginning and end of the string.In which case,the backslash (\) for C and the double quote (“) in BASIC are not required.

Define DUT Model in the data label. The following command sequence needs to be sent to the 37XXXD:

LMS “4_8_FILTER”

If using C use this syntax

Send (0,6,“LMS \”4_8_FILTER\”“,NLend)

If using BASIC use this syntax

Send (0,6,“LMS ““4_8_FILTER”””,NLend)

Here the same command sequence can be sent with the single quotes (' ') without the need for additional character as above.

Send (0,6,“LMS '4_8_FILTER'”,NLend)

If shutting down the GPIB immediately after this series of com mands, then you must also make the controller wait for the 37XXXD to completely receive this data before shut down.

WaitForInstr()

3-10 37XXXD PM

PROGRAMMING EXAMPLES EXAMPLE 5

3-7 EXAMPLE 5 This example sequence lists and explains 37XXXD commands for

37XXXD internal disk operations.

Sweep, and store channel 1 trace data to memory

Send (0,6,“CH1;S11;CH3;S21;WFS;CH1;STD”,NLend)

Store trace memory data to hard disk

The following command sequence needs to be sent to the 37XXXD:

Send (0,6,“SAVE 'C:\CH1_S21.NRM'”,NLend)

Wait for operations to complete (page 3-12)

WaitForInstr()

Output channels 1 Tabular Data to instrument floppy disk

Send (0,6,“SAVE 'A:\CH1_S21.DAT'”,NLend)

Wait for operations to complete

WaitForInstr()

Save Front Panel and Calibration setup to hard disk

Send (0,6,“SAVE 'C:\SETUP1.CAL'”,NLend)

Wait for operations to complete

WaitForInstr()

Reset system to default state

Send (0,6,“*RST”,NLend)

Recal Front Panel and Calibration setup from hard disk

Send (0,6,“RECALL 'C:\SETUP1.CAL'”,NLend)

Wait for operations to complete

WaitForInstr()

Recall channel trace/noramlization data from hard disk to CH3

Send (0,6,“CH3; RECALL 'C:\CH1_S21.NRM'; WFS”,NLend)

Wait for operations to complete

WaitForInstr()

Delete channel 1 trace/normalization data file from hard disk

Send (0,6,“DEL 'C:\CH1_S21.NRM'”,NLend)

Wait for operations to complete

WaitForInstr()

37XXXD PM 3-11

EXAMPLE PROCEDURE 1 PROGRAMMING EXAMPLES

3-8 EXAMPLE PROCEDURE 1 This example sequence provides coding for the Wait for Instr () proce

dure used earlier in this chapter's example sequences.

NOTE

Do not use this procedure if the instrument was com manded to output data that has yet to be read by the program since the *OPC? query will, in itself,output data (the character “1” )when done with previous op eration.

Set GPIB time out limit to insure enough time is allowed for in

strument operations to complete. See ibtmo() in the NI488 documentation for details.

ibtmo(instrument_handle, T1000s)

Send the Operation Complete query

Send (0,6,“*OPC?“,NLend)

Wait for instrument to output the ASCII character “1”

numBytes=1 Receive(buffer, numBytes, STOPend)

Restore default time out limit

ibtmo(instrument_handle, T10s)

3-12 37XXXD PM

PROGRAMMING EXAMPLES EXAMPLE FUNCTION 1

3-9 EXAMPLE FUNCTION 1 This example sequence provides coding for the GetNumBytes() func

tion used earlier in this chapter's example sequences. GetNumBytes() reads the 37XXXD output buffer and returns the

number of data bytes to be transfered in the ensuing <Arbitrary Block> data string (see Chapter 7, “Data Transfers”). It does this by reading out and decoding the string data header. It will copy the header read out of the 37XXXD into headerString so the calling pro gram can use it in cases where the same data block will be sent back to the 37XXXD,i.e., OC1/IC1.

NOTE

Consult your programming language documentation for string functions to copy,concatenate,and return value of string.

Read the first byte in the instrument output buffer. Buffer is a

temporary array of characters of size 10.

numBytes = 1 Receive(buffer, numBytes, STOPend)

Check to be sure it is the “#” character then copy it to header-

String

if (buffer[0] ISNOTEQUALTO '#') then

gpiberr(“Invalid data string”)

else COPY(buffer, headerString)

Read second header byte from the instrument output buffer and append it (concatenate) to headerString

numBytes = 1 Receive(buffer, numBytes, STOPend) CONCATENATE(buffer, headerstring)

Save the buffer value as a number...

numBytes = VALUEOF(buffer)

NOTE

This number is the next set of bytes to read. Those bytes when taken as a number will yield the number of actual data bytes contained in the binary string.

Read the number of bytes indicated by numBytes and append them (concatenate) to headerString

Receive(buffer, numBytes, STOPend) CONCATENATE(buffer, headerString)

Save the buffer value as a number numBytes = VALUEOF(buffer)

NOTE

numBytes is the number of bytes, of actual data re quested, waiting in the output buffer of the 37XXXD.

37XXXD PM 3-13

EXAMPLE PROCEDURE 2 PROGRAMMING EXAMPLES

Return number of bytes to calling program

Return numBytes

NOTE

At this point headerString is exactly the same as the data transfer header output by the 37XXXD. Recall that this is useful to the calling program in cases where the same data read out is to be sent back to the instrument.

3-10 EXAMPLE

PROCEDURE 2

This example sequence provides coding for the TakeCalData() proce

dure used earlier in this chapter's example sequences. The TakeCalData() procedure will wait for the operator to press a key

on the computer then measure the cal standard installed.

Wait for operator to press a key on computer when he is ready

WAITUNTIL (key is pressed)

NOTE

Consult your compiler documentation for a function that waits for a key to be pressed.

Take cal data then go on to next calibration step

Send (0,6,“TCD;NCS”,NLend)

Wait for operation to complete (page 3-12)

WaitForInstr()

3-14 37XXXD PM

Part 2 GPIB Function Groups

This part consists of six chapters that relate the 37XXXD GPIB commands to functional groups. Tables within each group provide command descriptions and relationships to front panel keys and their associated menu functions.

Chapter 4 – describes the commands and suffix mnemonics that

relate to Measurement Functions.

Chapter 5 – describes the commands that relate to Calibration

Functions.

Chapter 6 – describes the commands that relate to Markers and

Limits Functions.

Chapter 7 – describes the commands that relate to Remote-Only

Functions.

Chapter 8 – describes the commands that relate to System Func

tions.

Chapter 9 – describes the commands that relate to Special Ap

plications Functions.

Chapter 4 Measurement Functions

Table of Contents

4-1 INTRODUCTION .........................4-3

4-2 SUFFIX CODES ..........................4-3

4-3 CHANNELS GROUP .......................4-5

4-4 DISPLAY GROUP .........................4-6

Display Mode Function: ......................4-6

Trace Memory Function:......................4-6

Limits Function: ..........................4-6

Scale Functions: ..........................4-6

Graph Type Functions: ......................4-7

4-5 MEASUREMENT GROUP ....................4-9

4-6 ENHANCEMENT GROUP ...................4-12

Chapter 4 Measurement Functions

4-1 INTRODUCTION This chapter describes the measurement function commands (and suf

fix mnemonics) that control the channel control, measurement control, display control, and enhancement group functions.

NOTE

See Chapter 9, Special Applications Functions for meas urement applications.

4-2 SUFFIX CODES Many 37XXXD GPIB commands require a following numeric value (or

values) that quantify the 37XXXD operational parameters being con trolled (i.e., frequency, power, etc). These numeric values are scaled to the following units as appropriate:

DECIBELS METERS SECONDS

DEGREES OHMS VOLTS

HERTZ

All numeric data entries can be followed by an optional suffix mnemonic (see example). The suffix mnemonics for the 37XXXD are listed in Table 4-1. These mnemonics define a weighting factor that is applied to the associated numeric data value. (They perform the same function as the data entry termination keys on the 37XXXD front panel.) Fur thermore, suffix mnemonics imply unit type, thus enhancing the read ability of application programs.

Example: "SRT 2 GHz”

37XXXD PM 4-3

SUFFIX CODES MEASUREMENT FUNCTIONS

Table 4-1. Numeric Data Suffix Mnemonics

Code Parameter Type Weighting Factor

DB, DBL, DBM Power 1.0

DEG Phase 1.0

RAD Phase

HZ Frequency 1.0

KHZ Frequency 10E+3

MHZ Frequency 10E+6

GHZ Frequency 10E+9

REU Real 1.0

IMU Imaginary 1.0

STime1.0

MS Time 10E-3

US, USC Time 10E-6

NS, NSC Time 10E-9

PS, PSC Time 10E-12

FS Time 10E-15

M, MTR Distance 1.0

CM, CMT Distance 10E-2

MM, MMT Distance 10E-3

OHM Impedance 1.0

V, VLT Voltage 1.0

MV Voltage 10E-3

K, KS Temperature Degrees Kelvin

XM3 Unitless 10E-3

XX1 Unitless 1.0

XX3 Unitless 10E+3

180

4-4 37XXXD PM

MEASUREMENT FUNCTIONS CHANNELS GROUP

4-3 CHANNELS GROUP The commands listed in Table 4-2 perform two separate sets of

functions:

Select the currently active channel (CH1–CH4). The active chan

Table 4-2. Channel Command Group

nel is that channel to which any subsequent channel-based com mands are applied. Select single or multi-channel display mode (commands D13,

D14, D24, DSP,T13, and T24). Commands T13 and T24 each pro duce a single display frame containing overlaid traces for the two channels specified.

Front Panel

Key/Function

Ch1 key CH1 Selects channel 1 as active channel.

Ch2 key CH2 Selects channel 2 as active channel.

Ch3 key CH3 Selects channel 3 as active channel.

Ch4 key CH4

Display Key/menus, Display Mode, Display Mode menus

Command Description

Selects channel 4 as active channel.

CHX?

D13 Selects dual channel display, channels 1 & 3.

D14 Selects quad display, all four channels.

D24 Selects dual channel display, channels 2 & 4.

DSP Selects single channel display, using the currently active channel.

DSP? Channel display mode query.

T13 Selects overlaid dual channel (1 & 3) display (one display frame).

T24 Selects overlaid dual channel (2 & 4) display (one display frame).

Active channel query.

37XXXD PM 4-5

DISPLAY GROUP MEASUREMENT FUNCTIONS

4-4 DISPLAY GROUP The Display key offers menu selections that provide Display Mode,

Trace Memory,Limits,Scale, and Graph Type functions, all of which are described below.

Display Mode

Function:

Trace Memory

Function:

Limits Function: This function is closely related to the Marker key functions; therefore,

Scale Functions: This function provides for resolving measurement values. There are se

This function provides selections for the display mode: Single, Dual 1&3, Dual 2&4, Overlay 1&3, Overlay 2&4, or Four Channel.

This function provides a sequence of menus that provide memory and math functions.Memory functions allow viewing of Data, Memory, Data & Memory,Data times Memory, Store Memory, and Disk Opera tions. Math functions provide Add, Substract, Multiply,and Divide op erations.

it is described in Chapter 7, along with markers.

lections for Log or Linear Magnitude, Phase,Smith Chart, Group De lay,Real or Imaginary.The operation of these commands are obvious, except for SCL, REF, and OFF.

SCL Command

This command sets the scaling-per-division characteristics of the graph on the active channel. The associated data value determines the resultant scaling factor.The SCL command can also be used to set the scaling on Smith chart type display as follows:

VAL U E SCALING

–3 Sets a 3 dB compressed scale

0 Sets the normal Smith chart scale 10 Sets a 10 dB expanded scale 20 Sets a 20 dB expanded scale 30 Sets a 30 dB expanded scale

REF Command

This command selects the graticule line of the active channel data dis play on which to place the "REFERENCE LINE." The Reference Line is the graticule line to which the caret points on the 37XXXD display, or graph. (Lines 0, 4, and 8 are the bottom, middle, and top of the graph respectively.)

NOTE

There is no reference line defined for Smith charts, in verted Smith charts,and linear polar or log polar displays.

OFF Command

This command sets the value of the offset associated with the "REFER ENCE LINE" in the data graph display.

4-6 37XXXD PM

MEASUREMENT FUNCTIONS DISPLAY GROUP

Changing the scaling-per-division (SCL), the Reference Line position (REF), or the offset value (OFF) in the bottom (secondary) graph of a two graph display is accomplished by using the appropriate suffix mnemonic for that graph, as shown in the table below. For example: to set the scaling value for the phase display of a log/phase type graph, use:

"SCL 20 DEG".

Graph Type

Functions:

Command

LogMag/Phase LinMag/Phase Real/Imaginary

SCL/OFF DEG/RAD DEG/RAD IMU

REF DEG DEG IMU

This function provides for selecting any of the various type of display graphs: Log or Linear Magnitude, Phase, Real, Imaginary, Log or Lin ear Polar, Smith Chart (Impedance), Smith Chart (Admittance), Group Delay, Power Out, SWR, Log Magnitude and Phase, Linear Magnitude and Phase, Real and Imaginary.

The usage of most of these commands is obvious, except SME, ISE, SMC and ISC.

All the commands in the Display Group act on the currently selected active channel (see section 4-3, Channels Group).

Both the SME and ISE commands require an associated data value to be included with the command (Table 4-3). The allowable data values for these commands are: 0, 10, 20, and 30. The example below selects a 20 dB expanded Smith chart on the active channel.

Graph Type

NOTE

Example: "SME 20 DBL"

Commands SMC and ISC also require an associated data value to be included with the command. The allowable data values for these com mands are 0 and 3. The example below selectsa3dBcompressed Smith chart on the active channel.

Example: "SMC 3 DBL"

The Display key commands are listed in Table 4-3.

37XXXD PM 4-7

DISPLAY GROUP MEASUREMENT FUNCTIONS

Table 4-3. Display Group Commands (1 of 2)

Command Description

ADD Select addition as trace math for active channel APR Enter group delay aperture setting on active channel APR? Output group delay aperture setting on active channel ASC Autoscale the active channel display ASP Enter polar stop sweep position angle ASP? Output polar stop sweep position angle AST Enter polar start sweep position angle AST? Output polar start sweep position angle DAT Display data only on active channel DAT? Output trace memory display mode DIA Select air as active dielectric DIE Enter a dielectric value DIM Select microporous teflon as active dielectric DIP Select polyethylene as active dielectric DIT Select Teflon as active dielectric DIV Select division as trace math for active channel DIX? Output dielectric constant DLA Select group delay display for active channel DNM Display data normalized to trace memory on active channel DTM Display measurement data and trace memory on active channel GRF? Output graph type for active channel IMG Select imaginary display for active channel ISC Enter scale and select inverted compressed Smith Chart display ISE Enter scale and select inverted expanded Smith Chart display ISM Select normal inverted Smith Chart for active channel LIN Select linear magnitude display for active channel LPH Select linear magnitude and phase display for active channel MAG Select log magnitude display for active channel MEM Display trace memory on active channel MIN Select subtraction as trace math for active channel MOSET Enter constant offset log magnitude for active channel MOSET? Output constant offset log magnitude for active channel MPH Select log magnitude and phase display for active channel MTH? Output trace math math type MUL Select multiplication as trace math for active channel OFF Enter offset value for top graph of active channel OFF2 Enter offset value for bottom graph of active channel OFF2? Output offset value for bottom graph of active channel OFF? Output offset value for top graph of active channel PCP Select measurement phase polar chart mode PCS Select sweep position polar chart mode PCX? Output polar chart mode PHA Select phase display for active channel PHO Enter phase offset for display channel PHO? Output phase offset for display channel PLG Select log polar display for active channel PLR Select linear polar display for active channel POSET Enter constant offset phase for active channel POSET? Output constant offset phase for active channel POW Select power out display for active channel

4-8 37XXXD PM

MEASUREMENT FUNCTIONS MEASUREMENT GROUP

Table 4-3. Display Group Commands (2 of 2)

Command Description

RDA Select automatic reference delay calculation RDD Enter reference delay in distance for active channel RDD? Output reference delay in distance for active channel RDT Enter reference delay in time for active channel RDT? Output reference delay in time for active channel REF Enter reference line for top graph of active channel REF2 Enter reference line for bottom graph of active channel REF2? Output reference line for bottom graph of active channel REF? Output reference line for top graph of active channel REL Select real display for active channel RIM Select real and imaginary display for active channel SCL Enter Scale Resolution for top graph of active channel SCL2 Enter Scale Resolution for bottom graph of active channel SCL2? Output Scale Resolution for bottom graph of active channel SCL? Output Scale Resolution for top graph of active channel SETUP Display setup menu SMC Enter scale and select compressed Smith Chart display SME Enter scale and select expanded Smith Chart display SMI Select normal Smith Chart for active channel STD Store trace to memory on active channel SWR Select SWR display for active channel

4-5 MEASUREMENT GROUP The commands listed in Table 4-4 control sweep and test signal

funcions. This inicludes frequency, power, attenuation, Hold functions, and Trigger/IF calibration.

Table 4-4. Measurement Group Commands (1 of 3)

Command Description

AH0 Turn automatic DUT protection off AH1 Turn automatic DUT protection on AHX? Output automatic DUT protection on/off status BH0 Turn bias off while in hold BH1 Turn bias on while in hold BHX? Output bias on/off during hold status CNTR Enter center frequency CNTR? Output center frequency CTN Continue sweeping from current point CWDEC Subtract 1 from the current CW index CWF Enter CW frequency and turn CW on CWF? Output CW frequency CWI Enter index for CW frequency and turn CW on CWI2F? Output frequency for index given CWI? Output current index number CWINC Add 1 to the current CW index CWN2I Add N to the current CW index

37XXXD PM 4-9

MEASUREMENT GROUP MEASUREMENT FUNCTIONS

Table 4-4. Measurement Group Commands (2 of 3)

Command Description

CWON Turn CW on at current CW frequency CWON? Output CW on/off status CWP Enter number of points drawn in CW CWP? Output number of points drawn in CW CWSRT Set CW frequency to the start frequency CWSTP Set CW frequency to the stop frequency EANAIN Measure External Analog In on active channel FHI Set data points to 1601 FIL Fill defined discrete frequency range FLO Set data points to 101 FME Set data points to 401 FP0 Turn flat power correction off FP1 Turn flat power correction on FRC Clear all defined discrete frequency ranges FRI Enter Discrete Fill increment frequency FRP Enter Discrete Fill number of points FRS Enter Discrete Fill start frequency HC0 Disable internal IF calibration HC1 Enable internal IF calibration and trigger an IF calibration HCT Trigger an IF calibration HCX? Output internal IF calibration enable/disable status HLD Put sweep into hold mode HLD? Output the sweep hold status HLDX? Output hold mode (continue, restart, or single sweep) IFP Enter current front panel setup IFV Enter frequency values IS1 Enter front panel setup 1 IS10 Enter front panel setup 10 IS2 Enter front panel setup 2 IS3 Enter front panel setup 3 IS4 Enter front panel setup 4 IS5 Enter front panel setup 5 IS6 Enter front panel setup 6 IS7 Enter front panel setup 7 IS8 Enter front panel setup 8 IS9 Enter front panel setup 9 LA1 Select a1 = Ra as phase lock for parameter being defined LA2 Select a2 = Rb as phase lock for parameter being defined LAX? Output phase lock selection for parameter being defined NP101 Set data points to 101 NP1601 Set data points to 1601 NP201 Set data points to 201 NP401 Set data points to 401 NP51 Set data points to 51 NP801 Set data points to 801 ONDF Output number of discrete frequencies PTP Enter the target power for flat power correction PTP? Output the target power for flat power correction PW1 Enter external source 1 power level PW1? Output external source 1 power level PW2 Enter external source power level PW2? Output external source power level

4-10 37XXXD PM

MEASUREMENT FUNCTIONS MEASUREMENT GROUP

Table 4-4. Measurement Group Commands (3 of 3)

Command Description

PWR Enter internal source power level PWR? Output internal source power level RH0 Select RF off in hold mode RH1 Select RF on in hold RHX? Output RF on/off during hold status RT0 Turn retrace rf off RT1 Turn retrace rf on RTX? Output retrace rf on/off status S11 Measure S11 on active channel S12 Measure S12 on active channel S21 Measure S21 on active channel S22 Measure S22 on active channel SA1 Enter port 1 source attenuator value SA1? Output port 1 source attenuator value SA1MAX? Output port 1 source attenuator max value SAMP2 Use 2 samplers for measurements SAMP3 Use 3 samplers for measurements SAMP? Output the number of samplers used for measurements SELSP Select S-Parameter test set operation SPAN Enter frequency span SPAN? Output frequency span SRC2? Output external source 2 existence information SRT Enter start frequency SRT? Output start frequency STP Enter stop frequency STP? Output stop frequency SWP Return to normal sweep mode SWP? Output sweep mode SWPDIR? Output instantaneous sweep direction forward/reverse SXX? Output s parameter or user defined parameter of active channel TA2 Enter port 2 test attenuator value TA2? Output port 2 test attenuator value TA2MAX? Output port 2 test attenuator max value TEX Select external measurement triggering TIN Select internal measurement triggering TRS Trigger/restart sweep TXX? Output trigger source WFS Wait full sweep until all display data is valid

37XXXD PM 4-11

ENHANCEMENT GROUP MEASUREMENT FUNCTIONS

4-6 ENHANCEMENT GROUP The commands listed in Table 4-5 control the data enhancement func

tions of the 37XXXD, which include IF bandwidth, averaging,and smoothing. These functions are the same as those controlled by the 37XXXD front panel Enhancement key group.

NOTE

Most of the commands associated with the Options Menu key are contained in Chapter 9, Special Applications Func tions. However, the Triggers and I.F. Cal commands are contained in Table 4-4 in section 4-5, Measurement Con trol.

Table 4-5. Enhancement Group Commands

Command Description

AOF Turn averaging off AOF? Output averaging on/off status AON Turn averaging on AVG Enter averaging count and turn on AVG? Output averaging count AVGCNT? Output the current sweep-by-sweep average sweep count IF1 Select 10 Hz IF bandwidth IF2 Select 100 Hz IF bandwidth IF3 Select 1 KHz IF bandwidth IF4 Select 10 KHz IF bandwidth IFA Select 30 KHz IF bandwidth IFM Select 10 Hz IF bandwidth IFN Select 1 KHz IF bandwidth IFR Select 100 Hz IF bandwidth IFX? Output IF bandwidth MEASDLY Set Measurement Delay time MEASDLY0 Disable Measurement Delay MEASDLY1 Enable Measurement Delay MEASDLY? Output Measurement Delay time MEASDLYX? Output Measurement Delay on/off status PTAVG Set averaging type to point-by-point averaging RSTAVG Reset the sweep-by-sweep averaging sweep count SOF Turn off smoothing SOF? Output smoothing on/off status SON Enter smoothing value and turn on SON? Output smoothing value SPLN Select normal source lock polarity SPLR Select reverse source lock polarity SPLX? Output source lock polarity normal/reverse status SPR0 Turn spur reduction off SPR1 Turn spur reduction on SPRX? Output spur reduction on/off status SWAVG Set averaging type to sweep-by-sweep averaging SWAVG? Output averaging type (sweep-by-sweep or point-by-point)

4-12 37XXXD PM

Chapter 5 Calibration Functions

Table of Contents

5-1 INTRODUCTION .........................5-3

5-2 RELATED COMMANDS .....................5-3

5-3 REQUIRED COMMAND SEQUENCE .............5-4

5-4 FUNCTIONAL COMMANDS ..................5-6

5-5 EXAMPLE PROGRAM ......................5-8

5-6 FLAT TEST PORT.........................5-9

Flat Test Port Power Calibration Coefficients ..........5-9

5-7 CALIBRATION COMMANDS ..................5-11

5-8 AUTOCAL FUNCTIONS.....................5-15

Chapter 5 Calibration Functions

5-1 INTRODUCTION This chapter describes the 37XXXD S-Paremter error correction (cali

bration) functions.It describes the commands used to perform the fol lowing:

Specify the calibration method, type, standards, and parameters.

Control the calibration data-taking process.

NOTES

See Measurement/Test Signals Group for a description

of the flat test port power calibration commands.

· The 37XXXD calibration functions require operator intervention. However,it is possible to use the external controller to guide the operator through the calibration process using a suitable program containing the calibration commands described in this chapter.

5-2 RELATED COMMANDS Related, non-calibration commands used during the calibration pro-

cess are described in Table 5-1. The use of these commands, in relation to calibration activities,is described throughout this chapter,where appropriate. These command sets are fully described in their respective chapters as indicated in Table 5-1.

NOTE

See ICx and OCx series commands in the Data Transfer group (Chapter 7) for information on inputting and output ting calibration terms coefficients (error terms).

37XXXD PM 5-3

REQUIRED COMMAND SEQUENCE CALIBRATION FUNCTIONS

Table5-1. Related Commands

Command Command Function Group

5-3 REQUIRED COMMAND

SEQUENCE

FHI, FLO, FME NP51–NP1601

SRT, STP, CWF, DFQ, DFD, FRS, FRI, FRP, FIL, FRC

IFV, ICx, OCx Data Tranfer Group (Ch 8)

*OPC, *OPC? IEEE 488.2 Group, Synchronization

All Measurement, Test Signals (Ch 5)

All Display, Graph Type (Ch 5)

All Display, Scaling (Ch 5)

AVG, A O F. AON

IFA, IFN, IFR, IFM, IF1–IF4

CH1–CH4 Channels Group (Ch 5)

Measurement Group, Data Points (Ch 5)

Measurement Group, Frequency (Ch 5)

(Ch 8)

Enhancement, Averaging (Ch 5)

Enhancement, Video IF Bandwidth (Ch 5)

A program used to control the calibration process must follow a specific order for the GPIB calibration commands that are used. Table 5-2 lists this acceptable order.

5-4 37XXXD PM

CALIBRATION FUNCTIONS REQUIRED COMMAND SEQUENCE

Table 5-2. Calibration Command Ordering

Order Item Typical Commands Used

1 Calibration Type C12, C8R, C8T, CRB, CRF, CRR, CBT, CFT, CRT

2 Calibration Method SCM, OCM, LCM, TCM

3 Line Type LTC, LTW, LTU

4 Isolation Usage ISN, ISF

5 Data Points NOC, DFC, TDC, CWC

6 Frequency:*

Sweep Discrete Fill User Defined List** CW

7 Test Port Connector

Connector Type

User Defined Connector Offset-Short Values

8 Reflection Pairing MAT, MIX

9 Load Type / Parameters SLD, BBL, BBZ, BBZL

10 Through Parameters TOL, TLZ

11 LRL Band LR2, LR3

12 LRL Parameters RM1, RRP, LL1, LL2, LL3, LM2, LM3, BPF, ROL, RLZ, RGZ

13 Reference Impedance LLZ

14 Test Signals* PWR, SA1, TA2

15 Flat Test Port

Calibration *

16 Microstrip Parameters U10, U15, U25, USW, SBT, SBD, USE, USZ

17 Waveguide Param's WKI, WKD, WCO, WSH1, WSH2

18 Begin Calibration

(Data Collection)

19 Take Cal Data TCD, TC1, TC2

20 Next Cal Step NCS

SRT, STP DFQ, DFD, FRS, FRI, FRP, FIL, FRC, IFV

P1C, P2C CMS, CFS, CMK, CFK, CMV, CFV, CMC, CFC, CM2, CF2, CMN, CFN, CM3, CF3, CNG CND, COO, COS, CC0, CC1, CC2, CC3, CL0, CL1, CL2, CL3 SH1, SH2

PTP, PTS, SFC, FP0, FP1

BEG

* Refer to Chapter 5, "Measurement Group" for details on these commands. ** See Chapter 8, Measurement Points Data Transfer Commands) CWF

37XXXD PM 5-5

FUNCTIONAL COMMANDS CALIBRATION FUNCTIONS

5-4 FUNCTIONAL

COMMANDS

Commands used for special types of calibrations are described in Table 5-3. The commands are used to invoke options and non-standard cali bration procedures,and to simulate a calibration process.

Table 5-3. Functional Commands Listing (1 of 2)

Command Function Description

NOC Specify Normal Sweep

Calibration

DFC Specify Discrete Fre

quency Calibration

CWC Specify CW Calibration This command sets up a continuous wave (CW) calibration. Use CWF to

P1C, P2C Set up to Specify Port 1

(PIC) or Port 2 (P2C) Standards

CND Other Connector Specifica-

tion

SLD, BBL Specify Sliding Load or

Broad Band Load for Cali bration

LM2, LM3 These commands are used to select a match for the second or the third

A12, A8T, A8R, ARF, AFT, ARB, ARR, ABT, ART

Calibration simulation These commands simulate the completion of a calibration. The Axx series

This command sets up a normal frequency range calibration.

This command sets up a calibration at discrete frequencies only. Use dis crete fill commands to input frequency list for calibration. Refer to Chapter 5, Measurement Functions, section 5-4.

Alternatively, the IFV command allows for a frequency list input of calibra tion frequencies. Refer to “Data Transfer Commands Group (Chapter 8),” for more details.

input CW frequency.

This command specifies Port 1 or Port 2 as the port to which subsequent connector-related commands will apply. Example:

“P1C;CFK;P2C;CMK”

This sequence of commands sets up a female K connector for port 1 (P1C CFK) and a male K connector for port 2 (P2C CMK).

This command allows a non-standard connector to be specified. This is the same as selecting OTHER from the front panel menu. When specifying the CND command, the connector offset for the open and/or short device and the capacitance coefficients for the open device also need to be entered to characterize the connector.

Thie SLD command specifies a sliding load. The data-taking process for

the load includes six slide positions. If any frequencies are below 2 GHz, you must also use a broadband load.

device respectively during a LRM type calibration.

commands must be followed with the corresponding calibration error term coefficients using the ICx commands (see Chapter 8).

The Axx series commands match up with corresponding calibration type commands. For example, A12 simulates C12, A8T simulates C8T, etc.

NOTE

If you attempt to apply a calibration without first having entered calibration coefficient data, the error correction may not be ap plied (as indicated by the Apply Cal LED being momentarily turned on, then off).

5-6 37XXXD PM

CALIBRATION FUNCTIONS FUNCTIONAL COMMANDS

Table 5-3. Functional Commands Listing (2 of 2)

Command Function Description

CON, COF Turn on/off vector error

correction

BEG, TC1, TC2, TCD, NCS, KEC, RPC

U10, U15, U25

MAT, MIX Load match for Reflection

Calibration Sequencing and Control commands

Calibration Kit selection commands

devices measurement sequences

These commands are not used during calibration. They are used during normal measurements to apply the current calibration error correction to the measured data (CON) or to turn off error correction calibration (COF).

These commands are used to start and control the data-taking process. KEC will keep existing calibration error corrections and return to the measurement mode. Command TC1 takes calibration data for the current (calibration) standard for port 1 using a separate forward measurement sweep. Command TC2 performs the same function for port 2 using a separate (reverse) sweep. (Note that command TCD performs these iden tical operations, using consecutive forward and reverse measurement sweeps.)

Using the TC1 and TC2 commands allows one calibration standard of eachtypetobeusedforbothports.

These commands are used to select 10, 15, or 25 mil UTF calibration kits respectively. These calibration kits are used to perform a 37XXXD calibration for microstrip device measurements.

The MAT (MATched) command changes the measurement sequence for the standard 12 term, coaxial, two-channel calibration so that the “open” measurements are performed in sequence, followed by the “short” measurements. The MIX (MIXed) command returns to the normal sequence for a two-channel 12 term calibration.

37XXXD PM 5-7

EXAMPLE PROGRAM CALIBRATION FUNCTIONS

5-5 EXAMPLE PROGRAM The following is an example of how to set up a calibration sequence for

the 37XXXD VNA:

"SCM;LTC;C12;DFC;FRS 1.0 GHZ;FRI 100 MHZ;FRP 41 XX1; FIL;DFD;P1C;CFK;P2C;CMK;BBL;BEG"

This example code sets up a calibration using standard calibration mode (SCM), coax cable media (LTC), and 12-term calibration type (C12). A discrete set of points is defined for frequency operation start ing at 1 GHz (FRS 1.0 GHZ), spaced 100 MHz apart (FRI 100 MHZ), at 41 consecutive points (FRP 41 XX1). This range is confirmed or "filled" ( FIL), then completed (DFD).

The Port 1 test port connector is defined as a female type K connector (P1C CFK) and the Port 2 test port connector is defined as a male K type connector (P2C CMK). Broadband loads are selected as the de fault load type (BBL). The BEG command instructs the 37XXXD to begin the calibration-data-taking-process.

The calibration control program should contain commands to control the data-collection portion of the calibration process. Typical commands used for this process are:

Take Calibration Data for Current Standard (TCD,orTC1,or TC2)

Go on to the Next Calibration Step (NCS)

Averaging On and Set to Value (AVG)

Set IF Bandwidth to 10 Hz (IF1)

Set IF Bandwidth to 100 Hz (IF2)

Set IF Bandwidth to 1 KHz (IF3)

Set IF Bandwidth to 10 KHz (IF4)

Any Graph Type Specification or Scaling Change

Active Channel Specification (CH1–CH4)

The TCD (or TC1,orTC2) and NCS commands control the data-tak

ing process.Commands AVG, IFN, IFR, IFA, and IFM control the data-enhancement function used for a particular measurement (refer to Chapter 3, section 5-6, Enhancement Commands).

Before the TCD (or TC1,orTC2) and NCS commands are invoked in the program, the system operator must be instructed to perform the exact steps necessary to setup the calibration sequence for the type of 37XXXD calibration to be used. An example program segment to con

tinue the 12-term calibration started in the previous example is shown on the next page. This example program segment is written in HP-BA SIC.

The calibration control program should determine if the 37XXXD is ready for the next step of the calibration sequence before prompting the system operator to connect new calibration standards to the test

5-8 37XXXD PM

CALIBRATION FUNCTIONS FLAT TEST PORT

ports. This can be done by monitoring the status byte of the 37XXXD or by waiting for the operation to complete after executing the NCS command.

For example, the commands in the following example instruct the 37XXXD to take calibration data (TCD), go to the next calibration step (NCS), then output the number "1" (*OPC?). When the controller is able to read the number "1" from the 37XXXD, the calibration step is complete.

260 OUTPUT 706;"TCD;NCS;*OPC?" 270 ENTER 706; N$ ! READ AND DISCARD ASCII '1' WHEN STEP IS COMPLETE 280 DISP "CALIBRATION STEP COMPLETE"

5-6 FLAT TEST PORT Signal source power correction data produced during this type of

37XXXD calibration is used to flatten the signal power output from the test set port(s) over a specified frequency range. This feature is used to provide flat test stimulus signals to the device-under-test while performing normal measurements.

Flat Test Port Power Calibration Coefficients

This process requires operator intervention. The system operator is guided through a sequence of operations and measurements that make up the flat test port calibration sequence. Before attempting to write a GPIB controlled program to produce this calibration sequence, first become thoroughly familiar with the manual procedure.

Flat test port calibrations require considerable time to perform. The time required is dependent upon the number of points selected; For these calibrations,the GPIB timeout value must be increased accord ingly, or the control program must generate an appropriate time delay before executing subsequent commands. See the documentation for your GPIB controller for timeout-setting procedures.

The commands listed in Table 5-4 are used to invoke and control flat test port calibrations.

The coefficients are input and output using the following codes:

IFPC – Enter the power sweep linearity calibration coefficients

OFPC – Output the power sweep linearity calibration coeffi cients

These codes would be useful in applications where there is no power meter to hook up to the 37000 to perform the calibration normally, or the power meter is not one of the ones that the 37000 has been pro grammed to interface with.

The code OFPC outputs an arbitrary block of binary or ASCII data de pending on the output mode selected with the codes FMA, FMB, FMC,

37XXXD PM 5-9

FLAT TEST PORT CALIBRATION FUNCTIONS

LSB and MSB.See the description of these codes in Chapter 10. See Chapter 10, section 10-3 for a description of the arbitrary block format. Each coefficient represents the adjustment in dB (correct to a hun dredth of a dB) required to achieve the correct power at the particular frequency point. There will be as many coefficients as there are fre quency points in the sweep. If a VNA does not currently have a valid power sweep linearity calibration in place when the OFPC is received, an arbitrary block will be sent with zeros for each coefficient.

The code IFPC is used to input coefficients into the VNA and set up a valid flat test port power calibration. The coefficients are contained in an arbitrary block, which follows IFPC.The makeup of the arbitrary block is identical to the one described above. The VNA must be pro grammed with the appropriate number of frequency points prior to re ceiving IFPC. If the number of coefficients in the arbitrary block does not match what would be required by the current VNA setup, the data will be rejected and an error message displayed on the screen and re corded in the service log.

Table 5-4. Flat Test Port Power Commands

Commands Description

PTP Enter target power for calibration.

PTP? Output target power for calibration.

PTS Selects the number of frequency points (1 – 65) to be skipped between each measured point on

the power measurement sweep. It therefore determines the number of points measured on each sweep .

PTS? Skipped points for flat test port power calibration query.

SFC Starts the flat test port calibration sequence.

FP1 Causes the flat test port power correction data to be used during normal measurement mode.

FP0 Turns off the flat test port power correction for normal measurement mode.

FPX? Flat power ON / OFFstatus query.

IFPC Enter the power sweep linearity calibration coefficients

OFPC Output the power sweep linearity calibration coefficients

5-10 37XXXD PM

CALIBRATION FUNCTIONS CALIBRATION COMMANDS

5-7 CALIBRATION

COMMANDS

Table 5-5 provides a listing of the commands used to perform measure ment calibrations.Unless otherwise noted, all front panel menus men tioned in Table 5-5 are accessed by first pressing the Begin Cal key.

Table 5-5. Calibration Commands (1 of 4)

Command Description

A12 Simulate 12-term calibration A8R Simulate 1-path 2-port calibration reverse path A8T Simulate 1-path 2-port calibration forward path ABT Simulate trans freq response calibration forward and reverse AFT Simulate transmission frequency response calibration forward path ARB Simulate reflection only calibration both ports ARF Simulate reflection only calibration port 1 ARR Simulate reflection only calibration port 2 ART Simulate trans freq response calibration reverse path BBL Select broadband load for calibration BBZ Enter broadband load impedance for calibration BBZL Enter broadband load inductance for calibration BEG Begin taking calibration data BPF Enter break point frequency for 3 line LRL calibration C12 Select 12 term calibration C8R Select 1-path 2-port calibration reverse path C8T Select 1-path 2-port calibration forward path CBT Select trans freq response calibration forward and reverse CC0 Enter capacitance coefficient 0 for open CC1 Enter capacitance coefficient 1 for open CC2 Enter capacitance coefficient 2 for open CC3 Enter capacitance coefficient 3 for open CF1 Select female 1.0 mm connector for current port CF2 Select female 2.4mm connector for current port CF3 Select female GPC-3.5 connector for current port CF716 Select female 7/16 connector for current port CFC Select female TNC connector for current port CFK Select female K connector for current port CFN Select female Type N connector for current port CFN75 Select Female type N 75-ohm connector for current port CFS Select female SMA connector for current port CFSP Select Special Female connector for current port CFSPA Select Band A special female connector for current port CFSPB Select Band B special female connector for current port CFSPC Select Band C special female connector for current port CFT Select trans freq response calibration forward path CFV Select female V connector for current port CL0 Enter inductive coefficient 0 for short CL1 Enter inductive coefficient 1 for short CL2 Enter inductive coefficient 2 for short CL3 Enter inductive coefficient 3 for short CM1 Select male 1.0 mm connector for current port CM2 Select male 2.4mm connector for current port CM3 Select male GPC-3.5 connector for current port CM716 Select male 7/16 connector for current port

37XXXD PM 5-11

CALIBRATION COMMANDS CALIBRATION FUNCTIONS

Table 5-5. Calibration Commands (2 of 4)

Command Description

CMC Select male TNC connector for current port CMK Select male K connector for current port CMN Select male N connector for current port CMN75 Select Male type N 75-Ohm connector for current port CMS Select male SMA connector for current port CMSP Select Special Male connector for current port CMSPA Select Band A special male connector for current port CMSPB Select Band B special male connector for current port CMSPC Select Band C special male connector for current port CMV Select male V connector for current port CMX? Output calibration method CND Select user specified connector for current port CNG Select GPC-7 connector for current port COF Turn error correction off CON Turn error correction on CON? Output error correction on/off status COO Enter offset for open for user specified connector (Standard Calibration) COS Enter offset for short for user specified connector CRB Select reflection only calibration both ports CRF Select reflection only calibration port 1 CRR Select reflection only calibration port 2 CRT Select trans freq response calibration reverse path CSF? Output cal start frequency CTF? Output cal stop frequency CWC Select CW frequency calibration data points CXX? Output calibration type DFC Select discrete frequency calibration data points DFD Done specifying discrete frequency ranges DFQ Enter single discrete frequency IC2 Input Calibration Coefficient 2 IC3 Enter calibration coefficient 3 IC4 Enter calibration coefficient 4 IC5 Enter calibration coefficient 5 IC6 Enter calibration coefficient 6 IC7 Enter calibration coefficient 7 IC8 Enter calibration coefficient 8 IC9 Enter calibration coefficient 9 ICA Enter calibration coefficient 10 ICB Enter calibration coefficient 11 ICC Enter calibration coefficient 12 ICD Enter corrected data for active channel parameter ICF Enter front panel setup and calibration data ICL Enter all applicable calibration coefficients for cal type IFD Enter final data for active channel parameter ISF Exclude isolation ISN Include isolation KEC Keep existing calibration data LCM Select LRL calibration method LL1 Enter length of line 1 for LRL calibration LL2 Enter length of line 2 for LRL calibration LL3 Enter length of line 3 for LRL calibration

5-12 37XXXD PM

CALIBRATION FUNCTIONS CALIBRATION COMMANDS

Table 5-5. Calibration Commands (3 of 4)

Command Description

LLZ Enter line impedance for LRL calibration LM2 Select a match for the second device during a LRM type calibration LM3 Select a match for the third device during a LRM type calibration LMZ Enter match impedance for LRM calibration LMZ? Output match impedance for LRM calibration LMZL Enter match inductance for LRM calibration LMZL? Output match inductance for LRM calibration LR2 Specify 2 line LRL calibration LR3 Specify 3 line LRL calibration LTC Select coaxial transmission line for calibration LTU Select microstrip transmission line for calibration LTW Select waveguide transmission line for calibration LTX? Output line type MAT Select matched reflective devices during cal MIX Select mixed reflective devices during calibration NCS Go to next calibration step NOC Select normal calibration data points O3CM Select Triple Offset Short calibration method OCM Select offset short calibration method ONCT Output number of cal terms for current calibration P1C Select port 1 for connector specification P1C? Output port 1 connector type P1P? Output approximate power level at port 1 P2C Select port 2 for connector specification P2C? Output port 2 connector type PSP Enter number of power sweeps for flat power correction (obsolete) PSP? Output number of power sweeps for flat power correction (obsolete) PTS Enter number of points to be skipped during flat power correction PTS? Output number of points to be skipped during flat power correction RGZ Select reflective device greater than Z0 RLZ Select reflective device less than Z0 RM1 Select reference plane at line 1 midpoint ROL Enter reflective device offset length RPC Repeat previous calibration RRP Select reference plane at reflection plane SBD Enter substrate dielectric for microstrip calibration SBT Enter substrate thickness for microstrip calibration SCM Select standard calibration method SFC Perform flat test port calibration SH1 Set offset short 1 or 2 offset length for offset short calibration SH2 Set offset short 1 or 2 offset length for offset short calibration SLD Select sliding load for calibration TC1 Take calibration data for port 1 TC2 Take calibration data for port 2 TCD Take calibration data on one or both ports as necessary TCM Select the TRM calibration method TDC Select time domain harmonic frequency calibration data points TLZ Enter through line impedance for calibration TOL Enter through offset length for calibration U10 Select 10 mil UTF calibration kit

37XXXD PM 5-13

CALIBRATION COMMANDS CALIBRATION FUNCTIONS

Table 5-5. Calibration Commands (4 of 4)

Command Description

U15 Select 15 mil UTF calibration kit U25 Select 25 mil UTF calibration kit USE Enter effective dielectric for microstrip calibration USW Enter microstrip width for microstrip calibration USZ Enter microstrip impedance for microstrip calibration WCO Enter waveguide cutoff frequency for user defined kit WKD Select user defined waveguide calibration kit WKI Select installed waveguide calibration kit WSH1 Enter waveguide short offset 1 for user defined kit WSH2 Enter waveguide short offset 2 for user defined kit WSH3 Enter waveguide short 3 offset for user defined kit

5-14 37XXXD PM

CALIBRATION FUNCTIONS AUTOCAL FUNCTIONS

5-8 AUTOCAL FUNCTIONS This function requires an optional AutoCal â module that provides an

automated method for performing fast, repeatable high-quality cali brations. The AutoCal module is inserted between the VNA test ports to perform the calibration. The commands for implementing this func tion remotely are provided in Table 5-6.

Table 5-6. List of AutoCal Commands (1 of 2)

Command Description

ABORTCAL Abort calibration in progress and keep existing calibration data ACAA Set AutoCal standard to assurance ACADPL Enter AutoCal adapter length ACADPL? Output AutoCal adapter length ACADR Set AutoCal type to adapter removal ACAL1R2 Set adapter removal port configuration to ADAPT & L=1 and R=2 ACAR1L2 Set adapter removal port configuration to ADAPT & R=1 and L=2 ACARP? Output AutoCal adapter removal port configuration ACDEF Select default AutoCal isolation averaging factor ACF2P? Output AutoCal full 2 port configuration ACF2TC Set AutoCal 2 port thru type to calibrator ACF2TT Set AutoCal 2 port thru type to true thru ACF2TX? Output AutoCal 2 port thru type selection ACHFD Save AutoCal characterization data to floppy disk ACHHD Save AutoCal characterization data to hard disk ACIAF Enter user AutoCal isolation averaging factor ACIAF? Output user AutoCal isolation averaging factor ACIAX? Output AutoCal isolation averaging factor omit/default/user selection ACISO Enter AutoCal isolation averaging number ACISO? Output AutoCal isolation averaging number ACL1AR2 Set adapter removal port configuration to L=1 and ADAPT & R=2 ACL1R2 Set AutoCal full 2 port configuration to L=1 and R=2 ACLO Enter AutoCal load averaging number ACLO? Output AutoCal load averaging number ACLOAD Set AutoCal standard to load ACOMIT Omit using AutoCal isolation averaging factor ACOPEN Set AutoCal standard to open ACP1? Output AutoCal S11 port configuration ACP1L Set AutoCal S11 port configuration to left ACP1R Set AutoCal S11 port configuration to right ACP2? Output AutoCal S22 port configuration ACP2L Set AutoCal S22 port configuration to left ACP2R Set AutoCal S22 port configuration to right ACPL Set AutoCal S11 port configuration to left ACPR Set AutoCal S11 port configuration to right ACR1AL2 Set adapter removal port configuration to R=1 and ADAPT & L=2 ACR1L2 Set AutoCal full 2 port configuration to R=1 and L=2 ACRFL Enter AutoCal reflection averaging number ACRFL? Output AutoCal reflection averaging number ACS11 Set AutoCal type to S11 ACS22 Set AutoCal type to S22 ACSF2P Set AutoCal type to full 2 port

37XXXD PM 5-15

AUTOCAL FUNCTIONS CALIBRATION FUNCTIONS

Table 5-6. List of AutoCal Commands (2 of 2)

Command Description

ACSHORT Set AutoCal standard to short ACSTD? Output AutoCal standard ACSW Enter AutoCal switch averaging number ACSW? Output AutoCal switch averaging number ACTHRU Set AutoCal standard to thru ACTU Enter AutoCal thru averaging number ACTU? Output AutoCal thru averaging number ACTUAVG Enter AutoCal thru update averaging number ACTUAVG? Output AutoCal thru update averaging number ACTULS Apply last thru update cal setup ACX? Output AutoCal type BEGAC Start AutoCal BEGCH Start AutoCal characterization BEGTU Start AutoCal thru update IACCHAR Input AutoCal characterization data from the GPIB OACCHAR Output AutoCal characterization data to the GPIB TACD Take AutoCal data

5-16 37XXXD PM

Chapter 6 Markers and Limits Functions

Table of Contents

6-1 INTRODUCTION .........................6-3

6-2 MARKERS .............................6-3

6-3 LIMITS...............................6-7

Single (Non-Segmented) Limits..................6-7

Segmented Limits .........................6-8

Limits Example ..........................6-8

Limits Pass/FailTesting ......................6-8

Chapter 6 Markers and Limits Functions

6-1 INTRODUCTION This chapter describes markers and limits commands. 6-2 MARKERS The commands listed in Table 6-1 (next page) control the location and

display of the markers and the functions related to the markers.A full description of each command mnemonic is contained in Chapter 11, Command Dictionary.

A marker is turned on whenever any of the following conditions occur: q When the marker is set to a value

Example: "MK2 20 GHZ"

q When the marker is selected for readout

Example: "MR2"

q When the marker is selected as the delta reference marker (left)

Example: "DR2 4.5632 GHZ"

MMN and MMX Commands — The MMN and MMX commands move the active marker to the minimum and maximum trace values on the active channel, respectively. There must be an active marker selected for these command to execute.

Example: "WFS;MR1;MMX"

This code instructs the 37XXX to:

Wait for a full sweep of data to be present (WFS)

Turn on marker 1 and select it for readout (MR1)

Move marker 1 to the maximum value of the trace on the active channel (MMX)

37XXXD PM 6-3

MARKERS MARKERS/LIMITS FUNCTIONS

Table 6-1. Marker Commands (1 of 3)

Command Description

AMKR Select active marker on all channels marker mode BWL3 Set bandwidth loss value to 3 dB BWLS Enter bandwidth loss value BWLS? Output bandwidth loss value DR1 Select Marker 1 as Delta Reference Marker DR2 Select Marker 2 as Delta Reference Marker DR3 Select Marker 3 as Delta Reference Marker DR4 Select Marker 4 as Delta Reference Marker DR5 Select Marker 5 as Delta Reference Marker DR6 Select Marker 6 as Delta Reference Marker DRF Turn delta reference mode on DRO Turn delta reference mode off DRO? Output delta reference mode on/off status DRX? Output delta reference marker number DSF0 Disable filter shape factor calculation DSF1 Enable filter shape factor calculation DSFX? Output filter shape factor calculation enable/disable status DSQ0 Disable filter Q calculation DSQ1 Enable filter Q calculation DSQX? Output filter Q calculation enable/disable status FLTBW? Output filter bandwidth FLTC? Output filter center frequency FLTL? Output filter loss at reference value FLTQ? Output filter Q FLTS? Output filter shape factor FMKR Select filter parameters marker mode M1C Set CW mode at marker 1 frequency M1E Set sweep/zoom end to marker 1 frequency distance or time M1S Set sweep/zoom start to marker 1 frequency distance or time M2C Set CW mode at marker 2 frequency M2E Set sweep/zoom end to marker 2 frequency distance or time M2S Set sweep/zoom start to marker 2 frequency distance or time M3C Set CW mode at marker 3 frequency M3E Set sweep/zoom end to marker 3 frequency distance or time M3S Set sweep/zoom start to marker 3 frequency distance or time M4C Set CW mode at marker 4 frequency M4E Set sweep/zoom end to marker 4 frequency distance or time M4S Set sweep/zoom start to marker 4 frequency distance or time M5C Set CW mode at marker 5 frequency M5E Set sweep/zoom end to marker 5 frequency distance or time M5S Set sweep/zoom start to marker 5 frequency distance or time M6C Set CW mode at marker 6 frequency M6E Set sweep/zoom end to marker 6 frequency distance or time M6S Set sweep/zoom start to marker 6 frequency distance or time MK1 Enter marker 1 frequency distance or time and turn on MK1? Output marker 1 frequency distance or time MK2 Enter marker 2 frequency distance or time and turn on MK2? Output marker 2 frequency distance or time MK3 Enter marker 3 frequency distance or time and turn on

6-4 37XXXD PM

MARKERS AND LIMITS MARKERS FUNCTIONS COMMANDS

Table 6-1. Marker Commands (2 of 3)

Command Description

MK3? Output marker 3 frequency distance or time MK4 Enter marker 4 frequency distance or time and turn on MK4? Output marker 4 frequency distance or time MK5 Enter marker 5 frequency distance or time and turn on MK5? Output marker 5 frequency distance or time MK6 Enter marker 6 frequency distance or time and turn on MK6? Output marker 6 frequency distance or time MKRC Select interpolated marker functionality MKRD Select discrete marker functionality MKRX? Output interpolated/discrete marker functionality MKSL Marker search left MKSR Marker search right MKT0 Turn marker tracking off MKT1 Turn marker tracking on MKTX? Output marker tracking on/off status MMN Move active marker to minimum trace value MMX Move active marker to maximum trace value MO1 Turn off marker 1 MO2 Turn off marker 2 MO3 Turn off marker 3 MO4 Turn off marker 4 MO5 Turn off marker 5 MO6 Turn off marker 6 MOF Turn marker display off MON Turn marker display on MON? Output marker display on/off status MR1 Turn marker 1 on and make it the active marker MR1? Output marker 1 on/off status MR2 Turn marker 2 on and make it the active marker MR2? Output marker 2 on/off status MR3 Turn marker 3 on and make it the active marker MR3? Output marker 3 on/off status MR4 Turn marker 4 on and make it the active marker MR4? Output marker 4 on/off status MR5 Turn marker 5 on and make it the active marker MR5? Output marker 5 on/off status MR6 Turn marker 6 on and make it the active marker MR6? Output marker 6 on/off status MRM Display the Marker Readout menu MRX? Output active marker number MSFH Enter high loss value for shape factor calculation MSFH? Output high loss value for shape factor calculation MSFL Enter low loss value for shape factor calculation MSFL? Output low loss value for shape factor calculation MSR0 Select 0 as reference for marker search and bandwidth calculation MSRD Select delta reference marker as reference for marker search and bandwidth calculation MSRM Select maximum as reference for marker search and bandwidth calculation MSRX? Output reference selection for marker search and bandwidth calculation NMKR Select normal markers on active channel marker mode SMKR Select marker search marker mode

37XXX PM 6-5

MARKERS MARKERS AND LIMITS COMMANDS FUNCTIONS

Table 6-1. Marker Commands (3 of 3)

Command Description

SRCH Enter marker search value SRCH? Output marker search value XMKR? Output marker mode

6-6 37XXX PM

Anritsu 37397D Programming Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table Of Contents

Part 1 The GPIB Interface

Chapter 1 Series 37XXXD GPIB Programmer Interface

Chapter 3 Series 37XXXD Programming Examples

Part 2 GPIB Function Groups

Chapter 4 Measurement Functions

Chapter 5 Calibration Functions

Chapter 6 Markers and Limits Functions
