Optical Smoke Alarm
User Manual
SA700-AE-UK
www.angeleye.com
14
0086
0086-CPR-597993
Smoke alarm devices
EN 14604:2005
DOP:13/02
BS EN 14604: 2005
Licence No: KM597992
GN3563R1
SA700-AE-UK Optical Smoke Alarm
A Sprue Brand
Sprue Safety Products Ltd.
Vanguard Centre, Coventry CV4 7EZ UK
Technical Support: 0800 141 2561 / EIRE dial 1-800 523171
Email: technicalsupport@sprue.com
Web: www.sprue.com
2
CONTENTS
Features . . . . . . . . . . . . . . 4
Positioning . . . . . . . . . . . . 4
Installation. . . . . . . . . . . . .6
Alarm Test . . . . . . . . . . . . . 7
Alarm Pause. . . . . . . . . . . .8
Note: This user manual is also available in large text and other formats.
Please email: technicalsupport@sprue.com or call 0800 141 2561 for
further information.
Battery Replacement . . . . . . . 8
Troubleshooting. . . . . . . . . .9
Maintenance. . . . . . . . . . . 10
Disposal . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . 11
3
FEATURES
• Battery Operated.
• Operating Light (RED) - flashes
approximately every 45 seconds
confirming unit is powered.
• Low Battery Warning - unit ‘beeps‘
approximately every 45 seconds for at
least 30 days when the battery needs
replacing.
• Low Battery Warning Silence - silence
the low battery chirp for 10 hours.
• Alarm Pause - silence your smoke
alarm by momentarily pressing the test
button, ideal for nuisance alarms.
• Sensitivity Test Button - test sensitivity,
circuitry, battery, horn.
• Loud 85 Decibel Piezo Electric Alarm -
automatically resets when hazardous
condition has passed.
• Easy Installation - fixings supplied.
POSITIONING
WARNING: Your AngelEye smoke alarm
can be installed into a new build property
as additional protection to an existing
smoke detection system only. It cannot be
used as a substitute for a hard wired system
as required in new build properties. In this
4
type of property the building regulations
require alarms to be interlinked. You can
obtain further information from your local
fire service or building control department
at your local council offices. These sources
generally provide advice on new builds or
projects that require planning permission.
Your smoke alarm typically meets the
minimum requirements for family living
units in existing buildings, as long as at
least one unit is installed on each floor/
level of your property. In order to achieve
the earliest fire warning, we recommend
that a smoke alarm is fitted in all rooms
where the temperature is normally
between 4°C (40°F) and 38°C (100°F).
BEDROOMBEDROOM HALL
DINING ROOM
CELLAR
EXISTING HOMES
MINIMUM RECOMMENDATIONS
RECOMMENDED FOR ADDITIONAL
PROTECTION
NOTE: Kitchens should be covered by a
self contained heat detector.
LOUNGE
WARNING: The alarm positions shown
are based on typical homes. Construction
and layout of individual dwellings will
vary, so this should be regarded only as a
