Page 1
Ionisation Smoke Alarm
User Manual
SA300-AE-UK
www.angeleye.com
Page 2
14
0086-CPR-597993
Smoke alarm devices
EN 14604:2005
DOP: 13/03
BS EN 14604:2005
License No: KM597992
GN3561R1
SA300-AE-UK Ionisation Smoke Alarm
A Sprue Brand
Sprue Safety Products Ltd.
Vanguard Centre, Coventry CV4 7EZ UK
Technical Support: 0800 141 2561 / EIRE dial 1-800 523171
Email: [email protected]
Web: www.sprue.com
2
Page 3
CONTENTS
Features . . . . . . . . . . . . . . 4
Positioning . . . . . . . . . . . . 4
Installation. . . . . . . . . . . . .6
Alarm Test . . . . . . . . . . . . . 6
Alarm Pause. . . . . . . . . . . .7
Note: This user manual is also available in large text and other formats.
Please email: [email protected] or call 0800 141 2561 for
further information.
Battery Replacement . . . . . . . 7
Troubleshooting. . . . . . . . . .8
Maintenance. . . . . . . . . . . .9
Disposal . . . . . . . . . . . . . . 9
Warranty . . . . . . . . . . . . . 10
3
Page 4
FEATURES
• Battery Operated.
• Operating Light (RED) - flashes
approximately every 45 seconds
confirming unit is powered.
• Low Battery Warning - unit ‘beeps‘
approximately every 45 seconds for at
least 30 days when the battery needs
replacing.
• Sensitivity Test Button - tests sensitivity,
circuitry, battery, horn.
• Loud 85 Decibel Piezo Electric Alarm -
automatically resets when hazardous
condition has passed.
• Easy Installation - fixings supplied.
projects that require planning permission.
Your smoke alarm typically meets the
minimum requirements for family living
units in existing buildings, as long as at
least one unit is installed on each floor/
level of your property. In order to achieve
the earliest fire warning, we recommend
that a smoke alarm is fitted in all rooms
where the temperature is normally
between 4°C (40°F) and 38°C (100°F).
WARNING: The alarm positions shown
are based on typical homes. Construction
and layout of individual dwellings will
vary, so this should be regarded only as a
guide. Check with your local fire station for
further guidance.
POSITIONING
WARNING: Your AngelEye smoke alarm
can be installed into a new build property
as additional protection to an existing
smoke detection system only. It cannot be
used as a substitute for a hard wired system
as required in new build properties. In this
type of property the building regulations
require alarms to be interlinked. You can
obtain further information from your local
fire service or building control department
at your local council offices. These sources
generally provide advice on new builds or
4
BEDROOMBEDROOM HALL
DINING ROOM
CELLAR
LOUNGE
EXISTING HOMES
MINIMUM RECOMMENDATIONS
RECOMMENDED FOR ADDITIONAL
PROTECTION
NOTE: Kitchens should be covered by a
self contained heat detector.
Page 5
Multi-family or mixed occupant
residence (Tenancy building, student
accommodation)
Your smoke alarm can be used in
individual flats and bedsits, providing the
same conditions are met as for a singlefamily residence. However, there must
already be a primary fire detection system
that meets regulatory requirements
for common areas such as lobbies
and hallways.
As a minimum, smoke alarms should
be located between sleeping areas and
potential sources of fire such as living
rooms and kitchens. In single storey
homes, a smoke alarm should be installed
in the hallway, as close as possible to the
living accommodation. In single storey
homes with two separate sleeping areas, a
minimum of two smoke alarms is required,
one outside each sleeping area. In multilevel or split level homes, as a minimum
a smoke alarm should be installed on the
ground floor between the staircase and
any rooms in which a fire might start and
on each storey in circulation areas which
form part of the escape route (normally
hallways and landings).
Install smoke alarms in circulation areas
at a distance no greater than 7.5 m from
the farthest wall, no greater than 7.5 m
from a door to any room in which a fire
might start and no greater than 7.5 m from
the next smoke alarm. If it is necessary
to place a smoke alarm on a wall, always
locate the detection element of the
alarm 150 mm to 300 mm (6 to 12 inches)
below the ceiling, and the bottom of the
alarm above the level of doors and other
openings. In rooms with sloped ceilings
install smoke alarms 900 mm (3 feet) from
the highest point of the ceiling. ‘Dead air’
at the peak of a ceiling may prevent smoke
from reaching the alarm in time to provide
an early warning.
Institutions and Hotels
This includes motels, hospitals, day care
facilities, long-term health care facilities,
boarding houses and dormitories. Your
SA300-AE-UK smoke alarm can be
used in individual sleeping / resident
rooms, providing the same conditions
are met as for a single-family residence.
However, there must already be a
primary fire detection system that meets
regulatory requirements for common
areas such as lobbies and hallways. Use
of the SA300-AE-UK smoke alarm in
common areas may not provide sufficient
fire warning to residents or meet
regulatory requirements.
Commercial and Industrial Premises
This smoke alarm is not intended for any
non-residential, commercial or industrial
application, nor for any other purpose
than described above.
5
Page 6
Mobile Homes and Caravans
This smoke alarm is suitable for
use in mobile homes and caravans.
In caravans:
1. The preferred position for fitting
the smoke alarm is horizontally on
the ceiling in the living area. Avoid
proximity to the kitchen.
2. An additional smoke alarm may be
fitted in one or more bedrooms.
3. DO NOT locate in kitchen or bathroom
area. Cooking fumes and high humidity
can trigger nuisance alarms.
4. DO NOT locate smoke alarms close to
exhaust fans or air conditioning units,
which could draw smoke away from
the alarm.
In mobile homes:
1. If only one smoke alarm is to be fitted,
it should be located horizontally on the
ceiling, either in the living room or the
hall, but not in the proximity of either
kitchen or bathroom.
2. Additional alarms can be fitted
in bedrooms.
3. DO NOT locate alarm close to exhaust
fans or air conditioning.
INSTALLATION
1. Open the cover and handle unit with
care to avoid damage.
2. Locate keyhole slots.
3. Mark holes through alarm base. Then
remove alarm. Drill two 4.75 mm holes.
4. DO NOT drill with alarm still in position
as this will contaminate the unit with
dust.
5. Insert the plastic anchors. Screw alarm
base to mounting surface.
6. NOTE: When wall mounting a unit,
ensure that the keyhole fixing slots are
positioned with the narrow aperture
uppermost, to prevent the unit from
being dislodged.
ALARM TEST
Connect the battery. Remove the
activation tab. Check LED operating light
flashes approximately every 45 seconds in
standby mode.
Firmly press the test button in the centre
and release. The unit will give an audible
alarm consisting of 3 loud beeps. Alarm
may continue for up to 10 seconds after
button is released.
6
Page 7
Test the sounder, battery and circuitry
by pressing and releasing the Test /
silence button to confirm that the alarm
is operating properly. The alarm should
sound as soon as the Test button is
pressed, and the Alarm LED will illuminate
red indicating that the sounder is working
and the battery is providing power to the
unit. This test should be performed on a
weekly basis.
WARNING: You should test your smoke
alarm every week.
WARNING: The electronic test button
provides a full test of the unit’s
functionality. DO NOT try to test the alarm
with a naked flame, as this may present a
potential fire hazard in itself.
ALARM PAUSE
Abnormal air conditions may cause the
highly sensitive smoke alarm to give
a ‘false’ alarm. Do not disconnect the
batteries. If no fire is apparent, ventilate
the room and operate the ‘Alarm Pause’
feature by pressing the test button.
WARNING: If there is any question as to
the cause of an alarm, always assume that
this is due to an actual fire and follow your
fire emergency plans. Do not assume the
alarm is a nuisance alarm.
BATTERY
REPLACEMENT
Your alarm requires one 9 volt battery
to power the smoke detector portion of
the unit. Recommended batteries are:
GP1604A or GP1604P, Duracell MN1604 or
MX1604, Eveready 1222.
When the battery reaches the end of
its normal life, a low battery warning
(intermittent beeping, for at least 30 days)
will indicate the need for its replacement.
Under normal use, the battery powering
the smoke alarm should last approximately
one year.
7
Page 8
TROUBLESHOOTING
Problem Solution
• If testing immediately after first activating the alarm or replacing the battery,
Your smoke alarm
does not sound during
testing
The operating light
remains steadily on
or off
Your smoke alarm is
beeping intermittently
you should allow a few seconds for the alarm to settle before testing.
• Make sure you push the centre of the test button firmly.
• If the alarm has been recently fitted and it still fails to self test
then contact Technical Support on: 0800 141 2561 or e-mail:
[email protected].
• Inspect for obvious damage.
• Check the unit contains the recommended battery type and that it is properly
connected.
• If in doubt, contact Technical Support on: 0800 141 2561 or e-mail:
[email protected].
• This indicates that the battery is low and needs replacing.
• Refer to the ‘Battery Replacement’ section of this manual.
8
Page 9
MAINTENANCE
Your smoke alarm has been designed
to be as maintenance-free as possible,
however there are several things you
must do to keep it working properly.
CAUTION: Your smoke alarm is a sealed
electrical device and no attempt should
be made to open the case. Attempting
to open the case will invalidate
your warranty.
Cleaning
As a minimum your smoke alarm should
be cleaned once every 3 months using
your vacuum cleaner fitted with the soft
brush attachment.
WARNING: Your smoke alarm may false
alarm when it is being cleaned using a
vacuum cleaner.
IMPORTANT: Do not use solvents or
cleaners on your smoke alarm, as they
may cause damage to the sensor or
circuitry. The unit can be wiped with a
slightly damp cloth.
CAUTION: Do not paint the smoke
alarm as this may block the openings and
prevent smoke from entering the sensor.
Storage in low humidity, and certain
transportation conditions, may cause
electrostatic charges to build up in
the alarm system housing. Although
harmless, they may increase the length
of time that the horn sounds upon battery
insertion or test button operation. The
condition may be cleared by gently wiping
the inside and outside of the plastic cover
with a clean, damp cloth.
DISPOSAL
RADIOACTIVE CONTENTS
The SA300-AE-UK utilises a tiny amount of radioactive
material, 0.9 microcuries (33 kilobecquerels) of
Americium 241, to detect smoke. This material is
in the form of a sealed source and represents no
hazard whatsoever to anyone installing or using the
smoke alarm. Any stray particles would be unable to
‘penetrate through the dead layer of skin and thus
do not constitute an external hazard.’ (Radiation
Protection Guidance for Scientists and Physicians).
This ionisation smoke alarm has been rigorously
tested by the National Radiological Protection Board
to ensure absolute safety.
Waste electrical products should not be disposed
of with your other household waste. The alarm is
ideally suited for disposal within the waste electronic
and electrical equipment (WEEE) recycling scheme.
Please recycle where facilities exist. Check with
your local authority, retailer or contact our Technical
Support team for recycling/disposal advice, as
regional variations apply.
WARNING: Do not burn or dispose of
in fire.
WARNING: If your alarm is dropped or damaged, as
a precaution, it should be removed from the building.
9
Page 10
WARRANTY
Sprue Safety Products Ltd warrants to the original
purchaser that its enclosed smoke alarm be free
from defects in materials and workmanship under
normal residential use and service for a period of 5
(five) years from the date of purchase. Provided it is
returned with postage prepaid and proof of purchase
date, Sprue Safety Products Ltd hereby warrants that
during the 5 (five) years period commencing from
the date of purchase Sprue Safety Products Ltd, at its
discretion, agrees to replace the unit free of charge.
The warranty on any replacement SA300-AE-UK
alarm, will last for the remainder of the period of the
original warranty in respect of the alarm originally
purchased – that is from the date of original purchase
and not from the date of receipt of the replacement
product. Sprue Safety Products Ltd reserves the right
to offer an alternative product similar to that being
replaced if the original model is no longer available
or in stock. This warranty applies to the original retail
purchaser from the date of original retail purchase
and is not transferable. Proof of purchase is required.
This warranty does not cover damage resulting
from accident, misuse, disassembly, abuse or lack
of reasonable care of the product, or applications
not in accordance with the user manual. It does not
cover events and conditions outside of Sprue Safety
Products Ltd’s control, such as Acts of God (fire,
severe weather etc.). It does not apply to retail stores,
service centres or any distributors or agents. Sprue
Safety Products Ltd will not recognise any changes to
this warranty by third parties.
Sprue Safety Products Ltd shall not be liable for any
incidental or consequential damages caused by the
breach of any expressed or implied warranty. Except
to the extent prohibited by applicable law, any
implied warranty of merchantability or fitness for a
particular purpose is limited in duration for 5 (five)
years.
10
This warranty does not affect your statutory rights.
Except for death or personal injury, Sprue Safety
Products Ltd shall not be liable for any loss of use,
damage, cost or expense relating to this product
or for any indirect, or consequential loss, damages
or costs incurred by you or any other user of this
product.
Page 11
11
Page 12
Loading...
