Andis Slii, SL3, AE User Manual

SL3

SLII

AE

LITERATURE PACKET #04969

Item pictured may differ from actual product

El artículo ilustrado puede diferir del producto real

Il est possible que l’article sur la photo soit différent du produit réel

Use & Care Instructions

ENGLISH

Please read the following instructions before using your new Andis
trimmer. Give it the care that a fine precision built instrument deserves
and it will give you years of service.

5. Keep the cord away from heated surfaces.

6. Never drop or insert any object into any opening.

7. Do not use outdoors or operate where aerosol (spray)
products are being used or where oxygen is being
administered.

8. Do not use this appliance with a damaged or broken

IMPORTANT SAFEGUARDS

When using an electrical appliance, basic precautions should always be
followed, including the following: Read all instructions before using the
Andis trimmer.

blade or comb, as injury to the skin may occur.

9. If this trimmer has means for grouding, connect to a
properly grounded outlet only (see grounding instructions).

10. To disconnect turn control to OFF then remove plug from

outlet.

DANGER: To reduce the risk of electric shock:

1. Do not reach for an appliance that has fallen into water.
Unplug immediately.

2. Do not use while bathing or in a shower.

3. Do not place or store appliance where it can fall or be
pulled into a tub or sink. Do not place in or drop into water
or other liquid.

4. Always unplug this appliance from the electrical outlet
immediately after using.

5. Unplug this appliance before cleaning, removing or
assembling parts.

WARNING: To reduce the risk of burns, fire

electric shock, or injury to persons:

An appliance should never be left unattended when plugged in.

1.

2. Close supervision is necessary when this appliance is used
by, on or near children or individuals with certain disabilities.

3. Use this appliance only for its intended use as described in
this manual. Do not use attachments not recommended by
Andis.

4. Never operate this appliance if it has a damaged cord or
plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water. Return the appliance to
an Andis Authorized Service Station for examination and
repair.

2 3

SAVE THESE INSTRUCTIONS

THIS PRODUCT INTENDED FOR PROFESSIONAL USE

These instructions only apply to trimmers with a 2-prong plug:

To reduce the risk of electric shock, this appliance has a polarized plug
(one blade is wider than the other). This plug will fit in a polarized outlet
only one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician to install the proper
outlet. Do not change the plug in any way.

GROUNDING INSTRUCTIONS

These instructions only apply to trimmers with a 3-prong plug:

This appliance should be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. This appliance is equipped with a
cord having a grounding wire with an appropriate grounding plug.
The plug must be plugged into an outlet that is properly installed and
grounded in accordance with all local codes and ordinances.

Tab for

Grounding Screw

Adapter

Grounded

Grounded

Outlet Box

Adapter

Tab for

Grounding Screw

Adapter

Metallic

Screw

Outlet

Grounded

Pin

Grounded
Outlet Box

FIGURE A

Metallic

Screw

Grounded
Outlet Box

FIGURE B

OIL

Adapter

Adapter

Tab for

Grounding Screw

FIGURE C

BLADE SCREWS

DANGER: Improper use of the grounding plug can result in a

risk of electric shock. If repair or replacement of the cord or plug is
necessary, do not connect the grounding wire to either flat-blade
terminal. The wire with insulation having an outer surface that is green
with or without yellow stripes is the grounding wire. Check with a
qualified electrician or serviceman if the grounding instructions are not
completely understood, or if in doubt as to whether the appliance is
properly grounded. Do not modify the plug provided; if it will not fit the
outlet, have the proper outlet installed by a qualified electrician. This
appliance is for use on a nominal 120-volt circuit, and has a grounding
plug (Figure A). A temporary adapter, (Figures B & C) may be used to
connect this plug to a 2-pole receptacle (Figure B) if a properly grounded
outlet is not available. The temporary adapter should be used only until a
properly grounded outlet (Figure A) can be installed by a qualified
electrician. The green colored rigid ear, lug, or the like extending from the
adapter must be connected to a permanent ground such as a properly
grounded outlet-box cover. Whenever the adapter is used, it must be
held in place by a metal screw.

FIGURE EFIGURE D

FIGURE F

OPERATING INSTRUCTIONS

Lower

Blade

Blade

Upper
Blade

Hole in
Upper
Blade

FIGURE G

Blade Screws

Nylon
Roller
(Ball)

HAIR GUARD

FIGURE H

Please read the following instructions before using your new Andis
trimmer. Give it the care that a fine precision built instrument deserves
and it will give you years of service. Before starting trimmer remove blade
guard (some models may not have a blade guard). Plug cord into
electrical outlet, operate at 120 volt, 60 cycle AC electrical current or as
noted on the unit. To start trimmer move switch button to ON position, to
stop, move switch button back to original position. After using your Andis
trimmer, rewrap cord and store in a safe place.

USER MAINTENANCE

Armature

Pin

Blade

Yoke

4 5

POWER
SCREW

FIGURE JFIGURE I

The internal mechanism of your trimmer has been permanently lubricated
at the factory. Other than the recommended maintenance described in
this manual, no other maintenance should be performed, except by
Andis Company or an Andis Authorized Service Station. To find an
Andis Authorized Service Station near you log on to www.andis.com or
contact our customer service department: 1-800-558-9441 (U.S.) or
1-800-335-4093 (Canada).

CARE AND SERVICING OF YOUR ANDIS TRIMMER BLADES

Blades should be oiled before, during, and after each use. If your trimmer
blades leave streaks or slows down, it’s a sure sign blades need oil. The
trimmer should be held in the position shown in Figure D to prevent oil
from getting into motor. Place a few drops of Andis Clipper Oil on the
front and side of the cutter blades (Figure E). Wipe excess oil off blades
with a soft dry cloth. Spray lubricants contain insufficient oil for good
lubrication, but are an excellent blade coolant. Always replace broken or
nicked blades to prevent injury. You can clean the excess hair from your
blades by using a small brush or worn out tooth brush. To clean the
blades we suggest to immerse the blades only into a shallow pan of
Andis Clipper Oil, while the trimmer is running. Any excess hair and dirt
that has accumulated between the blades should come out. After
cleaning, turn your trimmer off and dry blades with a dry cloth and start
clipping again.

REPLACEMENT (REMOVAL) OF BLADE SET FOR
AE TRIMMERS

NOTE: If you are familiar with replacing and adjusting T-Edjer trimmer

blades, please read the following blade replacement instructions. If you
are not familiar with this procedure, please return trimmer to your supplier
or an Andis Authorized Service Station for blade replacement and
adjustment.

To remove blade set from your trimmer, unplug your trimmer from the
electrical outlet. Turn the trimmer upside down so the teeth of blades are
facing down. You may wish to set the trimmer on a flat surface while
performing these operations. Using a philips type screwdriver, unscrew
the two blade screws (Figure F). Remove blade set from trimmer. To install
your new trimmer blade set, align hole in upper blade (smaller of the two
blades) and center over nylon roller (ball) of the trimmer’s tension spring
(Figure G). Align screw holes of lower blade (larger of the two blades) to
armature screw holes. While holding blade in place, replace blade screws;
do not tighten down completely. Turn trimmer over and align the blade
set parallel to the trimmer’s upper housing.

upper blade, loosen (with standard screwdriver) hair guard screws slightly
and adjust hair guard away from the upper blade approximately 1/32".
Tighten down hair guard screws.

REPLACEMENT (REMOVAL) OF BLADE SET FOR
SLII, SL3 TRIMMERS

Your Andis SLII and SL3 trimmers have a preset tension assembly on the
blade set. To remove blade set from your trimmer, unplug trimmer from
electrical outlet. Turn the trimmer upside down so teeth of blades are
facing down. You may wish to set the trimmer on a flat surface while
performing these operations. Using a philips type screwdriver, unscrew
the two blade screws (Figure F). Remove blade set from trimmer. Install
new blade set, making sure the blade yoke cradles the armature pin on
trimmer (Figure I). There is no need to adjust blade tension before use, as
tension has been preset at the factory. Align screw holes of blade set to
screw inserts on trimmer housing. Replace the screws. Before tightening
down blade screws, check alignment of blade set to housing, making sure
that they are parallel. Tighten down screws.

POWER ADJUSTMENT FOR MODELS SLII AND SL3

Your Andis trimmer has been adjusted to line voltage at the factory.
However, because of voltage variations it may be necessary to adjust the
power setting for your area. If the power adjustment is off, you will usually
notice a “clatter”, when the trimmer is on or introduced into the hair. (It is
normal for your trimmer to “clatter” for an instant when initially turned on).

TO ADJUST YOUR TRIMMER:

1. Oil the blades (Figure E).

2. The power screw is located in the lower part of the housing opposite
the switch (Figure J).

3. Turn your trimmer ON.

4. Using a standard screw driver that fits the slot, turn the powescrew
counter clockwise until the trimmer clatters continuously. Then turn the
screw clockwise carefully until the clatter ceases.

5. Your trimmer is now adjusted to its optimum power setting.

IMPORTANT: Check blade alignment, making sure the teeth of the upper
blade rest slightly below the upper edge of teeth on lower blade. Failure
to check the position of blade may cause cutting or scratching of your
client’s skin when trimming. Tighten down blade screws firmly. If after
turning on the trimmer you notice the hair guard (Figure H) is hitting the

6 7
