Telemark / Telemark-K User Manual
Contents
Introduction ................................................................................................................................................. 3
Brief Overview ............................................................................................................................................. 3
Applications ................................................................................................................................................. 3
Safety Instructions ....................................................................................................................................... 4
Initial Tuning ................................................................................................................................................ 5
Circuit in Details ........................................................................................................................................... 5
Voltage Controlled Oscillators VCO 1 ............................................................................................................ 7
Voltage Controlled Oscillators VCO 2 ............................................................................................................ 8
Sync ............................................................................................................................................................. 9
Mixer ........................................................................................................................................................... 9
Voltage Controlled Filter VCF ..................................................................................................................... 10
Filtering External Sound Sources ................................................................................................................ 11
Envelope Generators.................................................................................................................................. 12
Voltage Controlled Amplifier - VCA ............................................................................................................. 13
Low Frequency Oscillator - LFO .................................................................................................................. 13
Patch Sockets ............................................................................................................................................. 14
Telemark-k Pitch Bend and Mod Wheel...................................................................................................... 16
Telemark-K Rear Panel Audio Connections ................................................................................................. 17
CV/Gate Jacks ............................................................................................................................................ 18
Patch Panel ................................................................................................................................................ 18
No Signal? .................................................................................................................................................. 19
Quick method for zero modulation ............................................................................................................ 19
Expansion .................................................................................................................................................. 19
Internal Calibration of internal VCOs .......................................................................................................... 20
Telemark-k MIDI Data Editing ..................................................................................................................... 21
Parameters and Pages in More Detail ......................................................................................................... 22
Specification .............................................................................................................................................. 24
Warranty ................................................................................................................................................... 29
A
analogue Solution – Telemark – 2014 2 | P a g e
Introduction
Congratulations on buying the Telemark synthesiser. Telemark is part of the Analogue Solutions
range of analogue music equipment. Telemark is a precision electronic musical instrument. It
combines all the often needed music electronic circuitry to make a music synthesiser in one
compact module.
No compromise has been made with the construction of Telemark. Cheaper options in parts have
not been used
Full rugged steel/aluminium case - no plastic mouldings
Good quality smooth potentiometers, fully sealed against dust
Good quality knobs with spun aluminium caps
High grade double sided circuit board
High Quality 16bit DAC for MIDI-CV conversion
Very stable MIDI to CV
Very stable analogue oscillators
Hand built by humans
True retro analogue voice and modulation circuits to give an authentic retro sound
Brief Overview
Telemark is a self-contained TRUE analogue synthesiser. The voice and modulation circuitry is
entirely analogue, using all discrete and op-amp components.
Telemark has a similar sound and specification to the classic Oberheim SEM, but with many
additional features such as MIDI, Noise, sample and hold and more modulation choices. Note
however, Telemark is not intended to be and is not a clone of the SEM. If you want a true SEM
sound, buy a SEM!
Applications
MONO SYNTHESISER
Telemark is for use any time you need analogue sound effects, fat basses, screaming leads, beeps,
tones, zaps, and all the other crazy sounds associated with analogue synthesis. Use in place of
your boring digital synths and DSP soft synths.
EFFECTS PROCESSOR
Telemark has an audio input socket, so you can feed external sounds into the on-board analogue
filters for analogue processing.
A
analogue Solution – Telemark – 2014 3 | P a g e
Safety Instructions
Please read carefully before using:
Only use the correct power adaptor - 230V (or 115V whatever your country needs)
Never handle the adaptor with wet hands
Never excessively bend the adaptor cable or get it trapped or place heavy objects on it. If the
adaptor cable becomes damaged, replace the adaptor.
Ensure the unit is disconnected from the mains before moving or cleaning.
Always disconnect the unit from the mains if there is lightning in your area.
Ensure the unit is on a stable surface, and never place heavy objects on top of it.
Never allow young children or animals to operate the unit or adaptor.
Do not use excessive force when using the controls or inserting cables to the connectors.
The unit should not be operated in the rain or near water and should not be exposed to moisture.
If the unit is brought from a cold environment to a warm one, the unit should be left to reach the
ambient temperature.
Keep away from heat sources, such as radiators, ovens, heaters etc.
Never allow it to get wet. Do not operate it near water, like pools, sinks, bathrooms etc.
Do not place beverages on or near it.
Never open the case or attempt to make repairs. Refer any servicing to qualified service personnel.
Preventing damage to other connected devices;
Telemark has a very high dynamic range. It is capable of produce loud signals of very high and sub-sonic
frequencies that could blow inadequate speakers if played too loud. It is recommended that input levels to
external equipment (mixers, amp's etc.) are kept low when first connected, and then slowly increased to a
useable level.
Maintenance Instructions
Any cleaning of the Telemark case should be done with a clean lint-free cloth. DO
NOT USE SOLVENTS OR CLEANERS, as this will deteriorate the exterior appearance of the
equipment.
Mounting
Mounting does not mean 'place on the wall' or 'to make love to' in this instance. Place
Telemark soundly on any stable surface so he cannot fall off or over, causing it or yourself injury.
POWER
The unit needs a 12 to 15V AC supply, minimum 500mA. DC Power supplies will not work
A
analogue Solution – Telemark – 2014 4 | P a g e
Initial Tuning
Once the MIDI and audio connections have been made it may be necessary to tune in the VCOs to
the rest of your music set-up. Allow a five minute warm up time.
First set up the controls of Telemark to make a simple sound. It is usually best to leave the VCA at
ON. Turn VCO2 to zero volume so you can only hear VCO1.
Play, say, middle C on the keyboard. Using a digital keyboard as a reference, adjust the course or
fine tuning of VCO1 until it plays in tune with your reference.
Finally, turn up VCO2 so both VCOs can be heard. Using the tune controls of VCO2, tune it to VCO1.
Circuit in Details
Here follows details on all the sockets and controls, with brief simplified explanations of what the
circuits do. We have not gone into technical details on how or exactly what each circuit does but
tried to explain each control's function and effect.
This synth has been designed to be simple and intuitive to use, just like the original analogue
synths of the 70s and 80s. There are no multi-layered menus to work through.
Anyone who has used synthesisers before should be familiar with the terms used and therefore be
able to predict their behaviour and how they affect the sound. The best way to learn how to use
Telemark is to go straight ahead and play with it. Reading of this manual may only be necessary
for finer operational detail.
A
analogue Solution – Telemark – 2014 5 | P a g e
A
analogue Solution – Telemark – 2014 6 | P a g e
Voltage Controlled Oscillators VCO 1
EG2 for pitch sweeps. Good for percussion sounds
EXT2
for sound effects and additional modulation
LFO
for vibrato and trill effects
VCO1
for frequency modulation
effects
The voltage controlled oscillators (VCOs 1 and 2) produce the raw audio waveform usually used as the initial source
for sound creation. They provide cyclic audio waveforms that can be pitched. VCOs usually receive treatment from
the VCF to turn their basic tones into pleasant sounds.
FINE TUNE: Controls fine pitch adjustment of VCO1. Use this to
tune VCO1 to your other instruments or VCO2.
TUNE: Controls the course pitch of VCO1. Range is about +/- 2
octaves. Use this to tune VCO1 to your other instruments or to shift
the VCO pitch up or down an octave compared to VC02
MODULATION: This controls the amount of modulation to
either pulse width or pitch from the modulation source selected by
the SOURCE switch.
Turn this knob clockwise in increasing amounts to apply pulse width
modulation (PWM) to the square wave. This will have the effect of
thickening up the VCO sound. Extreme settings of modulation may
result in the sound cutting out (which can be used for creative
effect!). Turn this knob anti-clockwise in increasing amounts to
apply frequency modulation (FM) to VCO1.
In a central position, there will be no modulation to either PW or
Frequency
MODULATION SOURCE rotary switch: This selects the
modulation source for either PWM or FM and is routed to the
control above.
The source options are;
Square wave
PULSE WIDTH: This control allows manual shaping of the pulse
wave output. It alters the pulse width (duty cycle) of the pulse wave.
In a central position a square wave is produced (50% duty cycle). Try
this control and listen to how the tone of the waveform changes.
When using Pulse Width Modulation, it is best to set the Pulse
Width control to centre, otherwise the sound may cut-out (which
can be used for creative effect!).
analogue Solution – Telemark – 2014 7 | P a g e
A
Voltage Controlled Oscillators VCO 2
EG2 for pitch sweeps. Good for percussion sounds
EXT2
for sound effects and additional modulation
LFO
for vibrato and trill effects
VCO1
for frequency modulation
effects
The voltage controlled oscillators (VCOs 1 and 2) produce the raw audio waveform usually used as the initial source
for sound creation. They provide cyclic audio waveforms that can be pitched. VCOs usually receive treatment from
the VCF to turn their basic tones into pleasant sounds.
FINE TUNE: Controls fine pitch adjustment of VCO2. Use this
to tune VCO1 to your other instruments or VCO1.
TUNE: Controls the course pitch of VCO1. Range is about +/-
2 octaves. Use this to tune VCO2 to your other instruments or to
shift the VCO pitch up or down an octave compared to VC01
MODULATION: This controls the amount of modulation to
either pulse width or pitch from the modulation source selected
by the SOURCE switch.
Turn this knob clockwise in increasing amounts to apply pulse
width modulation (PWM) to the square wave. This will have the
effect of thickening up the VCO sound. Extreme settings of
modulation may result in the sound cutting out (which can be
used for creative effect!). Turn this knob anti-clockwise in
increasing amounts to apply frequency modulation (FM) to VCO2.
In a central position, there will be no modulation to either PW or
Frequency
MODULATION SOURCE rotary switch: This selects the
modulation source for either PWM or FM and is routed to the
control above.
The source options are;
Square wave
PULSE WIDTH: This control allows manual shaping of the
pulse wave output. It alters the pulse width (duty cycle) of the
pulse wave. In a central position a square wave is produced (50%
duty cycle). Try this control and listen to how the tone of the
waveform changes. When using Pulse Width Modulation, it is
best to set the Pulse Width control to centre, otherwise the
sound may cut-out (which can be used for creative effect!).
analogue Solution – Telemark – 2014 8 | P a g e
A
Sync
NOISE GENERATOR:
The noise
generato
r produces
whit
e noise
.
SYNC Switch: This switch selects the routings for oscillator
sync. The options are:
1>2 VCO2 slaved to VCO1
LFO>2 VCO2 slaved to LFO
OFF off no sync effect
2>1 VCO1 slaved to VCO2
Oscillator sync is where the master signal will reset the waveform of the slave signal each time the master
waveform starts a new cycle.
Try the different settings and listen to their effect. You may have to modulate the pitch of either VCO1 or VCO2 to
enhance the effect. There is a balancing act between the pitch of the two sound sources (usually the 2 VCOs) to get a
good effect, once found you'll know you've found it!
Mixer
The mixer is used to bring various audio source signals together for filtering. There are 3 mixer controls.
This is like the hiss you hear between radio stations. The signal
is available for filtering via the Noise/EXT4 mixer control.
Noise would be used for sound effects such as breath, wind,
percussion, etc
Saw/Pulse VCO1 level
Turning the control clockwise in increasing amounts sends VCO1s pulse signal to the mixer. Turning the control
anti-clockwise in increasing amounts sends VCO1s sawtooth wave signal to the mixer.
signal is sent from VCO1 to the mixer.
In a central position no
Saw/Pulse VCO2 level
Turning the control clockwise in increasing amounts sends VCO2s pulse wave signal to the mixer. Turning the control
anti-clockwise in increasing amounts sends VCO2s sawtooth wave signal to the mixer. In a central position no
signal is sent from VCO2 to the mixer.
Noise/EXT4 Level
Turning the control clockwise in increasing amounts sends the signal (if any) coming in to the front EXT4 socket to the
mixer. Turning the control anti-clockwise in increasing amounts sends white Noise to the mixer.
position no signal is sent from the Noise generator or EXT4 to the mixer.
In a central
analogue Solution – Telemark – 2014 9 | P a g e
A
Voltage Controlled Filter VCF
-
Frequency
EG1 EG1 is used as a
modulation source. Use for
LFO LFO is used as a modulation source. Use for
VCO2
Pulse wave of VCO2 is used as a modulation
EXT2
Signal at the EXT2 socket is used as a mod
The voltage controlled filter (VCF) is used to alter the tone of the VCOs/Noise and is the heart of what gives
an analogue synth its character.
There are 4 types of filter available;
Low Pass
High Pass
Band Pass
Notch Pass (variable between Low/High)
This sets the cut-off frequency, the point at which
the VCF will start to filter-out harmonics.
- Resonance
Resonance is a feature of adding feedback to the
filter circuit. The output of the filter is fed back
into the filter input. Resonance sets the level of
feedback. As the control is increased to higher
levels the filter will self-oscillate. The oscillation
frequency is set by the frequency control. Use
Resonance to alter the tone of the filter effect. It
can be used to create squidgy sounds and pulse
hits
- MOD SOURCE rotary switch
- Modulation Amount
Turning the control clockwise will increase the
amount that the modulation source selected by
the MOD.SOURCE switch (outlined below) will
modulate the cut-off frequency. Turning the
control anti-clockwise works just like clockwise
except that the modulation signal is inverted
(negative). In a central position the selected
modulation source will not affect cut-off
modulation.
This selects the modulation source that will affect the
filter cut-off and is routed to the control above.
There are 4 modulation sources;
tonal changes.
filter sweeps (wah-wah).
source. Use for effects.
- Notch
This sets the relative mix between the low pass
and high pass filters that is fed to the Filter Type
selection switch (6) Notch position.
analogue Solution – Telemark – 2014 10 | P a g e
source. Use for external filter control.
Cont…
A
LP L
ow Pass:
signals above the cut
-
off
BP Band Pass:
signals above and below the
HP H
igh Pass:
signals below the cut
-
off
Notch
Notch
: signals at the cut
-
off frequency
-
MIDI1
/
MIDI
2 MOD amount
- Filter Type rotary switch
This selects the modulation source that will affect
the filter cut-off
frequency are attenuated 12dB/octave
cut-off frequency are attenuated
12dB/octave.
frequency are attenuated 12dB/octave.
are attenuated 12dB/octave
Turning the control clockwise will increase the
amount that MIDI2 (CV2 MIDI controller/ velocity)
will modulate the cut-off frequency.
Turning the control anti-clockwise will increase
the amount that MIDI1 (CV1 MIDI note/pitch) will
modulate the cut-off frequency.
In a central position MIDI1/2 will not affect cut-off
modulation
Filtering External Sound Sources
External sound sources, such as vocals, guitars, mixer sends, samplers, etc. can be sent through the filter
for extra treatment. Note, mic's and guitars may need pre-amping use if the signal is too quiet.
Simply plug the sound source into the front panel EXT4 socket.
Turn the mixer control Noise/EXT4 to EXT4, and up to a suitable level.
You may wish to return the VCO1 and VCO2 mixer controls to their centre positions so the VCOs cannot be
heard.
Turn the VCA mode switch to ON. This will leave the VCA open so a constant signal can be heard.
Finally, play around with the filter and modulation settings as necessary.
The VCO signals can also be introduced, and use the various VCA modes and envelopes if you wish to
contour the sound level and add additional effects.
Note; The rear panel input sockets are wired direct to the mixer input.
analogue Solution – Telemark – 2014 11 | P a g e
A
EG1 ASR
EG1 ASR
Envelope Generators
EG1 is an ASR (attack / sustain / release) envelope
generator. Use it to modulate various parameters
of the synthesiser. EG1 is generally assigned for
use with modulating VCO1 and the filter cut-off.
ATTACK
Controls the Attack time. This is the rate at which
the envelope signal will take to reach full level
when the MIDI note/key pressed.
DECAY
Controls the Decay / Release time - the time it
take the envelope signal to return to zero when
the key is released.
SUSTAIN
Controls the level the envelope will hold at when
a key is pressed and the attack cycle has
completed.
EG2 is just the same as EG1. EG2 is generally
assigned for use with modulating VCO2 and the
VCA.
ATTACK
Controls the Attack time. This is the rate at which
the envelope signal will take to reach full level
when the MIDI note/key pressed.
DECAY
Controls the Decay / Release time - the time it
take the envelope signal to return to zero when
the key is released.
SUSTAIN
Controls the level the envelope will hold at when
a key is pressed and the attack cycle has
completed.
analogue Solution – Telemark – 2014 12 | P a g e
A
Voltage Controlled Amplifier - VCA
MIDI
2
/EG
GATE
ON
SQUARE WAVE
MIDI Control (CV2)
TRIANGLE WAVE
SAMPLE and HOLD*
V
OLUME
- This s
ets the output level of Telemark, i.e. the
output
The Voltage Controlled Amplifier (VCA) is the circuit that is used to change the output volume. Normally an envelope
signal would be used to do this, so the sound starts loud then gradually fades away. The filter audio output is hardwired to the VCA signal input.
from the VCA that is sent to the SIGNAL output socket
MODE – Rotary Switch
The VCA can be controlled in 4 modes
When EG2 is selected, the envelope signal of EG2 is used to modulate the VCA level. Use it if you
EG2
require the VCA level to change over time. (Normal use).
When this is selected, EG2 is again used as the modulation source, but the overall envelope
level is in turn controlled by MIDI2 (CV2) This allows velocity / controller dynamics to change
the volume. If MIDI2 source is MIDI volume (controller 7) then MIDI volume changes can be
realised. Typically MIDI Velocity would be the best modulation source.
When GATE is selected, the MIDI note on/off information is used to modulate the VCA. With
this, the VCA level is either off or full on. The audio envelope would be like an organ's, with no
attack or decay time.
When ON is selected, the VCA is left permanently on at full level. Use this setting if you wish to
use the Filter as an effects processor, to process external audio fed into Telemark via the EXT1
socket.
Low Frequency Oscillator - LFO
The Low Frequency Oscillator (LFO) is basically identical to a VCO; it is another oscillator, except that it produces
periodic wave forms of low frequency, typically sub-audio. These slow cyclic waveforms are used for modulating
other circuit parameters, for example, for sweeping the filter cut-off up and down, either slowly for a nice sweep, or
faster for a 'wah-wah' type effect. It could be used to modulate the VCO pitch for vibrato.
The LFO block is grouped together with the VCOs as an LFO is an oscillator just like the VCOs are.
SPEED – This sets the frequency (speed) of the LFO which is indicated by the
LED
MODE – This sets the modulation source that is routed to LFO points for
modulation selection. The options are:
*Sample and Hold (S+H) is a flash term that in this instance basically means a
modulation
completes a cycle (each time the LFO LED lights up a new modulation level is set)
is created that has a new random signal level each time the LFO
analogue Solution – Telemark – 2014 13 | P a g e
A
Patch Sockets
The CV and signal inputs and outputs are fairly straight forward, and typical to those you would find on a modular
synthesiser. This manual doesn’t aim to teach modular synthesis techniques. There are plenty of web resources
where you can learn such techniques.
But briefly we will explain the new sockets found on V2; Sub-Osc and Ring Mod
Sub-Osc
Sub oscillator takes the signal from one of the VCOs, divides it’s frequency by two, giving a waveform that has half
the pitch (ie one octave down). This then can be re-introduced back into the signal chain. This will really beef up the
sound.
The Sub-Osc is a divider. It will also divide clock signals and LFOs.
The basic patch is;
Take either VCO’s Sawtooth audio out and patch to SUB-OSC In.
Then patch either the -1 or -2 octave SUB-OSC outputs to the audio mixer.
Ring-Mod
Ring Mod, again use like on any other modular. Take two audio signals (waveform output of both VCO1 and VCO2
will do!) and patch to the X and Y RINGMOD inputs. Take the RING MOD output and patch into the audio mixer.
A
analogue Solution – Telemark – 2014 14 | P a g e
MIDI Channel Setting (non- keys versions)
MIDI PROG push button
This button is used to set the MIDI channel and CV2 controller.
Works best if you plug a MIDI keyboard direct to program rather than via a DAW.
To change the MIDI channel and CV2 controller;
Press and hold the PROG button.
Press a MIDI key or move a MIDI controller.
Release the key/controller. Then release the PROG button.
The synth will set its MIDI receive channel to the same channel of the MIDI message that was received.
CV2 will be set to Velocity if you used a MIDI key or to the same controller number of the controller that was moved.
A
analogue Solution – Telemark – 2014 15 | P a g e
Telemark-k Pitch Bend and Mod Wheel
PITCH BEND WHEEL
Pitch Bend range can be set via the LCD display. Default value is usually set to +/-2 semitones. The Pitch
Bend MIDI data is sent to the MIDI OUT socket and will also control the on board MIDI to CV converter to
affect the pitch of both VCOs equally.
MOD WHEEL
The mod wheel will send MIDI controller one data to the MIDI Out socket. MIDI2 (CV2) can be set to be
modulated by any controller, therefore can be set to one to be controlled by the mod wheel. This means
that the mod wheel can be used to change, say, filter cutoff.
analogue Solution – Telemark – 2014 16 | P a g e
A
Telemark-K Rear Panel Audio Connections
CV IN: This is a pitch CV input socket if you
want to control Telemark-K’s pitch from an
external synth. Scaling is 1v/Oct.
CV2 IN: This is a CV input socket if you want
to control Telemark-k's the ‘MIDI2’ patch points
(selected via the rotary switches) using an
external synth.
GATE IN: This is a Gate input socket if you
want to trigger the two envelope generators via
an external synth. Triggering is positive 5v or
more signal.
CV Out: The pitch CV signal is fed out here
from the MIDI to CV converter.
CV2 Out: The MIDI2 aux/controller CV signal
is fed out here from the MIDI to CV converter.
GATE Out: The gate signal is fed out here
from the MIDI to CV converter.
HEADPHONE: The signal is mono. Level is
controlled together with the main output socket
level using the volume control on the front panel
EXT1 IN: This an audio input socket to feed
audio signals directly into mixer.
EXT2 IN: This a second audio input socket to
feed audio signals directly into mixer.
VCA OUT: This is the main audio output from
Telemark it is the signal output from the VCA,
post Volume control.
MIDI IN: Plug your MIDI cable in here to all
another MIDI device to control the Telemark.
MIDI THRU: The MIDI data coming into the In
socket is copied to the Thru socket. This is so you
can control additional devices from your MIDI
controller without the need of a MIDI thru box.
The Thru socket will not function when in Poly
mode.
MIDI OUT: Use this socket to allow the
Telemark to control other MIDI devices or use it
as a master keyboard in your MIDI setup.
A
analogue Solution – Telemark – 2014 17 | P a g e
Keyboard Version CV/Gate Jacks
If you insert a jack plug into the CV in or out sockets then the internal connection will be broken.
E.g., if you connect an external CV sequencer or MIDI to CV converter to the CV1, CV2, Gate In sockets, you will
disconnect the Telemark-k internal MIDI-CV converter from the voice circuits. This way you can directly control the
voice circuits from an external device. The internal MIDI-CV converter will still work, and its signals still available from
the CV1, CV2, Gate Out sockets.
Likewise, if you connect the CV1, CV2, Gate Out sockets to an external analogue synth, the internal MIDI-CV converter will
be disconnected from the internal voice circuits.
In summary, the signal flow is such;
Internal MIDI-CV converter -> CV/Gate out Sockets -> CV/Gate In Sockets -> Internal Voice circuits.
By inserting jacks into either the In or Out sockets, you will disconnect the internal MIDI-CV converter from the
voice circuits.
The main signal output is on the rear panel and is oddly labelled VCA OUT. Connect this socket to a spare mixing desk
input channel. If you want to feed external signals into Telemark, use the rear panel EXT1 or EXT2 sockets. Maybe
hardwire it from your desk's effect send.
It is recommended to keep your MIDI and CV/audio cables as short as possible to keep the signal quality as high as
possible. We recommend no more than 3 metre cable lengths.
Patch Panel
Telemark is internally hard wired (pre-patched). Using the patch points will not disconnect any internal connections.
People use the term 'modular synth' a bit too loosely sometimes, often using it to describe any synth that has some
additional jack sockets.
I like to think an accurate classification of Telemark as a 'semi-modular' synth in that you can re-route signals and
introduce external circuits, but is not fully modular as the internal circuits cannot be swapped, removed or new ones
added. The concept of a semi-modular synth is good because you do not need to do any patching to get a good
sound. The front panel rotary switches provide large combinations of possible internal patching. Some further
patches can then be done using the patch points.
Telemark is a MIDI synth, but can just as easily be used entirely from an analogue sequencer. An ideal partner would
be our Oberkorn sequencer. Telemark's envelopes can be triggered individually from Oberkorn's two gate trigger
outputs, and the two VCOs can be controlled from separate sequencer CV outputs.
The patch sockets are clearly labelled and hold no secrets. If you have a basic knowledge of analogue synths then you
will be able to use these sockets with no problem.
A
analogue Solution – Telemark – 2014 18 | P a g e
No Signal?
Check the following…
Your mixing desk / monitoring equipment is on and working correctly.
Check the synth is switched on and that the power adaptor is functioning correctly.
Check it is connected to your monitoring equipment correctly and that the cable is not faulty.
Ensure the output volume is high enough.
Ensure the mixer level controls are turned to some sound source like the VCOs or Noise.
Certain extreme filter settings may filter out all of the signal or produce low level signals. Try adjusting the
filter cut-off.
Certain extreme PW/PWM settings may cause the pulse outputs to cut-out. Try adjusting PW/PWM as
necessary.
Try putting the VCA to ON to hear the raw sound, but if you are using a MIDI keyboard to trigger the
envelopes and VCA, ensure correct MIDI connection, and that the correct channels have been selected.
Quick method for zero modulation
Some of the modulation level controls are zeroed when in the centre position. It is quite easy to zero these controls to
have no modulation. But another quick and sure method to obtain this is the put the modulation source switch to
either EXT1 or EXT2. Assuming you have no signals coming into these rear panel sockets, you will eliminate any
modulation.
Expansion
For the DIY enthusiast and those wishing to invalidate their warranty, most of the signal source and destination points are
indicated on the circuit board. It would be possible with some good skills to bring these points to front panel sockets.
Of course we do not recommend you do this and it will invalidate all warranties.
A
analogue Solution – Telemark – 2014 19 | P a g e
Internal Calibration of internal VCOs
Calibration of Telemark is done at the factory and usually should not need to be changed. Only attempt this yourself
if you are fully confident you can do it. You may just end up ruining the settings, and be aware calibration is
something that we cannot help with other the phone. There are no additional guides we can give by phone to help
that are not already printed here.
Trimmers
There are 3 trimmers per VCO, arranged in a vertical line accessed through small holes in the top panel.
Top trimmer is Tune
Middle is Scale
Bottom is =High End.
VCO1
1. Monitor VCO1.
2. Turn Fine and Course Tune controls to centre.
3. With MIDI connected, play C4.
4. Monitor the VCO1 output, and adjust bottom trimmer (tune) until the pitch of VCO matches your
reference of a 'C' note (reference using guitar tuner, digital keyboard, etc.).
5. Play C3.
6. Adjust the top trimmer (Scale) until it matches your reference of a lower 'C' note.
7. Repeat steps 3 to 6 several times until all is in tune and a good octave is obtained.
8. Play C6 and adjust the middle trimmer (Hi-Track) until it matches your reference.
9. Repeat steps 3 through 8 until all is in tune.
VCO2
1. For VCO2 you repeat the above steps VCO1 can be used as a reference instead of a tuner, using the zero-
beat method.
A
analogue Solution – Telemark – 2014 20 | P a g e
Telemark-k MIDI Data Editing
The keyboard / MIID setup can be edited using the buttons and LCD. All the parameters are self-explanatory, but
details are here.
PAGE, PARAM -10, -1, +10, +1
There are six pages of parameters. Each page contains two sets of parameters.
To scroll through the 6 pages of data press the PAGE button. Each press advances you to the next page and will cycle
back to page 0 once you get to page 6. To move the cursor between the 2 sets of data in each page, press the PARAM
button (parameter). Each press will toggle you between the two available parameters.
To alter a parameter's value, first select the parameter, ensuring the cursor is under the appropriate parameter, then
use the +/- buttons to edit the value.
There are four +/- buttons;
-1 decreases data by 1
+1 increases data by 1
-10 decreases data by 10
+10 increases data by 10
OCT-, OCT+
You can quickly alter the keyboard octave setting +/- four values. Octave setting can also be edited via the LCD. The
octave parameter/buttons are used to transpose the keyboard in whole octaves.
Transpose and Octave parameters only affect the keyboard data. That is the note information sent to the voice
circuits and the data sent to the MIDI Out socket. These parameters will not affect MIDI information received at the
MIDI In socket.
STORING PARAMETERS
The new value of any parameter you edit will be lost if you switch off the machine. So ensure you store the setup
before switching off.
Press the PAGE button until you get to the store page. Then Press OCT+ to store the setup. Then the LCD will revert
back to PAGE0.
If you do not wish to store, then just press PAGE again to return to PAGE0
A
analogue Solution – Telemark – 2014 21 | P a g e
PAGE0
PAGE1
3
4 Transposes the keyboard in semitones upwards.
PAGE2
7
A very fine tune setting. This is used to
trim the internal MIDI
-
CV
PAGE4
9
10 0=off. This means that if you overlap notes, the new note will not re
-
PAGE5
This is the page used to store set
-
up, as described earlier.
Parameters and Pages in More Detail
Page number (0-5) is displayed on the far left as a single digit. The top line shows parameter names, bottom line
show parameter value.
(1)RX.CHAN (2)TX.CHAN
1-16 1-16
(3)TRANSPOSE (4)OCTAVE
000-015 000-003
1 2 Sets the MIDI receive channel for the internal MIDI-CV converter
Sets the MIDI transmit channel of the keyboard.
Transposes the keyboard in 12 semitone increments (i.e. whole
Octaves)
PAGE3
(5)AUX.CC# (6)PB.RANGE
000-127 000-007
(7)F.TUNE (8)P.SCALET
0000-255 000-255
(9)LOCAL (10)RE-TRIG
000-001 000-001
5
Changes the MIDI controller number for CV2 (aux.CV). 127 is used
to set velocity as the source. This setting will affect which MIDI
controller the keyboard or external MIDI will be the source for
modulating CV2 (aux.CV). The controller you set can then be used to
control whatever synth setting is set to MIDI on the front panel, for
example filter cut-off.
6
Pitch bend range. +/- 0-7 semitone range.
DAC. Normally there would be no need to alter this.
This alters the octave spacing for the MIDI-CV converter. This affects
8
the pitch/scaling of the VCOs. Normally there would be no need to
alter this.
This turns on/off Local.
0= off. This means the keyboard will not play the internal voice. The
voice can only be controlled via the CV/Gate sockets or an external
MIDI device such as a sequencer.
1= on. This means the keyboard will play the internal voice.
Either way, the note that you play on the keyboard will be sent
to the MIDI Out socket.
trigger the sound. However, the pitch will change.
1=on. This means that if you overlap notes, the envelopes will
retrigger each time.
STORE SETUP
PRESS +OCT TO STORE
RESTORING FACTORY DEFAULTS
Hold down button 8 (OCT+) whilst turning on the machine to restore factory default settings.
A
analogue Solution – Telemark – 2014 22 | P a g e
Addendum
2 Voice Mode / Poly Chain
From approx August 2013;
Telemark and Leipzig-S synths have modified software to add poly-chain to accommodate one other synth.
This will allow 2 Telemarks to be played together as a single 2 voice polysynth. (4 voice is possible too on request - if
you are lucky enough to own 4 Telemarks!)
To connect them up:
Set the Slave Telemark to MIDI channel 2
Take your keyboard to the MIDI In of the Master Telemark
Connect the MIDI Thru from the Master Telemark to the MIDI In of the Slave Telemark
To activate the Poly mode, Press and hold the MIDI/PROG button whilst powering up the Master Telemark. (do the
same to toggle it back to normal mono mode)
There is no need for the Slave Telemark to have the special software or be in any special mode, just as long as it is
set to Channel 2
There is no charge as such for the new software, but there is a charge to cover the cost of a new CPU, admin', post,
and packing.
note; Pitch bend is not passed through. The poly mod is fairly basic (for example there is no note buffer) but it suffices
as a 'free' extra and works well enough!
A
analogue Solution – Telemark – 2014 23 | P a g e
Specification
VCO1
Fine Tune, Tune, PW Mod, FM, manual PW, Mod Source
controls, Saw out,
VCO2
Fine Tune, Tune, PW Mod, FM, manual PW, Mod Source controls, Saw out,
VCF Low pass filter, High pass filter, Band pass filter, Notch filter, variable Notch
Mixer
Audio source mixer
VCA Mode switch, Output volume
EG1 ASR envelope with trigger LED
EG2 ASR envelope with trigger LED
LFO Speed, Output Mode (Square, Triangle, Gate, External CV)
Noise Generator
White
noise
Sample and Hold
For random modulation effects
16 bit high resolution with auxiliary controller CV2 output
Rotary controls:
Dimensions:
Keyboard version
565mm x 405mm x 135mm (W x D x H)
Weight
Keyboard version 7.7
Kg Power:
Internal mains supply, using IEC power cable
Accessories:
Manual, Mains
adaptor
Telemark-K
Pulse out, Sync
Pulse out, Sync
filter. Cut-off, Resonance, Modulation Amount, Mod Source, MIDI Mod
Keyboard
Wheels
MIDI to CV Converter
Rotary switches
Push button
LEDs
Jack sockets
MIDI Sockets
Velocity sensitive
Mod and Pitch wheels
24
6
5
(6.35mm, mono)
3
Rugged steel construction
A
analogue Solution – Telemark – 2014 24 | P a g e
Telemark
VCO1
Fine Tune, Tune, PW Mod, FM, manual PW, Mod Source controls, Saw out,
VCO2
Fine Tune, Tune, PW Mod, FM, manual PW, Mod Source controls, Saw out,
VCF Low pass filter, High pass filter, Band pass filter, Notch filter, v
ariable Notch
Mixer
Audio source mixer
VCA Mode switch, Output volume
EG1 ASR envelope with trigger LED
EG2 ASR envelope with trigger LED
LFO Speed, Output Mode (Square, Triangle,
Gate, External CV)
Noise Generator
White noise
Sample and Hold
For random modulation effects
16 bit high resolution with auxiliary controller CV2 output
Rotary controls:
Dimensions:
Height:
306
mm
Weight
2.3Kg
Power:
Uses 15VAC, 500mA mains adaptor, 2.1mm DC type barrel plug (draws
Accessories:
Manual, Mains
adaptor (230v)
Pulse out, Sync
Pulse out, Sync
filter. Cut-off, Resonance, Modulation Amount, Mod Source, MIDI Mod
MIDI to CV Converter
24
Rotary switches
Push button
LEDs
Jack sockets
MIDI Sockets
Rugged steel construction
6
2
4
3 (6.35mm, mono)
2
Width: 430mm.
Depth: 140mm
approx. 40mA)
A
analogue Solution – Telemark – 2014 25 | P a g e
Some Patch Examples
Patch examples for beginners. These examples just show the basics, to set you off on the right foot. Please
experiment for yourself and play around. Knob positions have not been shown since these examples concentrate
more on the physical cable patches.
A
analogue Solution – Telemark – 2014 26 | P a g e
A
analogue Solution – Telemark – 2014 27 | P a g e
analogue Solution – Telemark – 2014 28 | P a g e
A
Warranty
Telemark comes with a 1 year (from purchase date) back to base warranty, (i.e. customer must arrange
and pay for carriage to and from Analogue Solutions or the dealer from which purchased).
This warranty shall not apply where the product has been subject to alteration, misuse accident, neglect (such
as extremes of temperature and/or moisture) or to wear resulting from normal use.
At the sole discretion of Analogue Solutions, the warranty is deemed to be void should the unit be or
considered to have been opened or any other modifications or tampering be carried out by unauthorised
parties.
CE Compliance
This unit complies with EU Directives 73/23/EEC and 89/336/EEC.
Standards: EN55103-1, EN55103-2, EN60065
analogue Solution – Telemark – 2014 29 | P a g e
A
A
analogue Solution – Telemark – 2014 30 | P a g e
Telemark-k ‘user manual’
Analogue Solutions
web: www.analoguesolutions.com
web: www.analoguesolutions.co.uk
email: info@analoguesolutions.com
A
analogue Solution – Telemark – 2014 31 | P a g e
Loading...
