Page 1
DATA SHEET
6x3 All-In-One Presentation Switchers with
TM
NX Control (Multi-Format, HDMI, DXLink
Inputs)
DVX-2255HD-SP (FG1906-12) 2x25W 8-Ohm
DVX-2255HD-T (FG1906-14) 75W 70/100V
Overview
The Enova® DVX-2255HD 6x3 All-In-One Presentation Switcher is a unified audio,
video, and control device that replaces the need for numerous individual
components and eliminates the integration and reliability challenges that
accompany them. The compact 3U Presentation Switcher integrates a variety of
different functionality, such as a scaler, analog to digital signal converter, twisted
pair transmitter and amplifier with built-in professional grade audio processing into
a single chassis. With AMX-exclusive features, the DVX-2255HD is a simple to
install, flexible solution, perfectly suited for large and complex conference rooms,
classrooms and auditoriums.
The DVX-2255HD includes the next generation NetLinx Integrated Controller technology, the NX-Series. This new
controller provides a scalable platform for the future by combining high performance, backward compatibility and
extensive network security features.
The DVX-2255HD includes a long list of features to ensure optimal audio and video quality from virtually any
source. The state-of-the-art professional grade audio DSP delivers quality audio throughout a room. The DVX2255HD's multi-format video inputs support analog and digital signals including HDMI with HDCP sources - all in
the same connector. Built-in SmartScale® Technology outputs video that is perfectly scaled for each connected
display, eliminating the integration challenges that can occur when sources and displays have different optimal
resolutions - making the DVX-2255HD easy to specify, easy to install and easy to use.
© 2015 AMX. All rights reserved.
Page 2
2
The Enova DVX's all-in-one architecture also delivers the lowest Total Cost of Ownership in the industry, thanks to
ease of support, maintenance and configuration, as well as reduced hardware and cabling costs.
Common Applications
The DVX-2255HD is ideal for dramatically simplifying AV control and distribution in small to medium-sized
and large conference rooms, boardrooms and classrooms.
With the included DXLink inputs, the DVX-2255HD is perfect for rooms where the AV rack is not near your
source devices and display
The flexible DVX-2255HD is perfect for any complex collaboration space with a mix of analog and digital
sources, multiple displays, or rooms that require support for video conferencing.
The DVX-2255HD is perfect for any room or facility with space constraints, especially those that lack space in
equipment racks.
Features
All-In-One Device – Controller, matrix switcher, scaler, analog to digital converter, amplifier, plus twisted pair
distribution and professional-grade audio DSP – all in a space-saving 3U chassis
Simplicity & Reliability – Replaces the need for numerous individual components and equipment, ensuring
high reliability and saving on configuring and programming costs
Low Total Cost of Ownership – With a consistent platform across a variety of sizes, it is easy to standardize
on the the DVX and reduce costs for hardware, training, support, troubleshooting and sparing
Unrivaled Network Security: Dual NIC – The LAN port is used to connect the master to an external network,
and the ICSLAN ports connect to AMX or third-party AV equipment isolated from the primary network,
providing rock-solid security
IPv6 and wired 802.1x – Supports modern networking standards for internet protocol IPv6 and port-based
Network Access Control utilizing X.509 certificates for access to protected networks
Optimal Video Image Quality Every Time – Exclusive SmartScale Technology automatically scales the image
to the best resolution and video parameters for each display—even for displays of different information—
without manual setup, eliminating the need for costly external scalers
Crystal Clear Audio – Includes an integrated digital signal processor with advanced capabilities like
independent 10-band parametric EQ, independent input gain adjustments and variable compression, allow
precision tuning to match unique source and room attributes
Audio Breakaway – Stereo audio from any analog input or de-embedded from any HDMI input can be
broken away from its associated video, processed through the DSP, and switched independently to any
analog, HDMI or S/PDIF audio output
Audio Matrix Switching – Three independently switched and processed audio paths provide four unique
volume, EQ, ducking and mixing configurations for perfectly tuned room audio as well as integration with
audio/video conferencing, induction loop systems, voice re-enforcement speakers and audio recording
devices
Enhanced Microphone Processing – Independent 3-band parametric EQ, compression, gating, auto-ducking,
and limiting on each microphone input ensures crystal clear communication
Matrix Switching – Freely route any input to any or all outputs without blocking – 6x3 video switcher and 8x3
audio switcher with audio breakaway
AV and Control Over Twisted Pair – Send audio, video, bi-directional control and Ethernet up to 100m over
one standard twisted pair cable
HDMI/HDCP Switching with Simplicity of Analog – End-to-end distribution of HDMI/HDCP without
interruption or key constraints using exclusive InstaGate Pro® Technology
Multi-Format Ports – Built for analog signals - RGBHV, Component, S-Video, and Composite, and digital
HDMI/HDCP and DVI signals - all on the same connector
Enhanced Diagnostics On Serial & IR Ports – Provides real time error feedback when Serial and IR ports are
disconnected or improperly wired
3D Support – Pass through latest video formats including 3D and Deep Color
DXLink™ Twisted Pair Outputs – Send audio, video, bi-directional control and Ethernet to DXLink HDMI
Receivers up to 100m away over one twisted pair cable
DXLink Twisted Pair Inputs – Receive audio and video from DXLink Multi-Format Transmitters and Solecis
Digital Switchers and deliver bi-directional control and Ethernet. In addition the DVX provides power to
Page 3
3
DXLink Multi-Format Transmitters. For more details and helpful cabling information, reference the white
GENERAL
Enclosure
Metal with black matte finish
Dimensions (HWD)
5 3/16" x 17" x 14" (13.2 cm x 43.2 cm x 35.6 cm)
Weight
18.2 lb. (8.26 Kg)
Certifications
FCC Part 15 Class A
CE EN 55022
CE EN 55024
CE EN 60065
IEC 60065
IC CISPR 22 Class A
C-Tick CISPR 22 Class A
LVD EN 60950-1
UL 60065
RoHS
WEEE
Included Accessories
•(1) Power Cord, Universal
•(1) Commoning Strip, Cypher, 8 Pos., 3.5 mm, Phoenix
Connector
•(2) Front Rack Mounting Brackets
•(8) #8-32 x .375 screws
•(4) Rubber feet
•(2) CC-NIRC, IR Emitter with 3.5mm Phoenix
Connector (FG10-000-11)
•(1) CC-DVIM-VGAF, DVI to HD-15 Female Adapter
(FG10-2170-13)
Optional Accessories
CC-DVI-5BNCM, DVI to 5 BNC Male Cable (FG10-2170-
08)
CC-DVI-RCA3M, DVI to 3 RCA Male Cable (FG10-2170-
09)
CC-DVIM-VGAF, DVI to HD-15 Female Adapter (FG102170-13)
CC-DVI-SVID, DVI to S-Video Cable (FG10-2170-10)
CC-3.5ST5-RCA2F, 5-pin 3.5mm Phoenix to 2 RCA
Female Cable (FG10-003-20)
DX-RX, DXLink HDMI Receiver Module (FG1010-500)
DX-TX, DXLink Multi-Format Transmitter Module
(FG1010-310)
DX-TX-DWP-BL/WH, DXLink Multi-Format Decor Style
Wallplate Transmitters (US) (FG1010-325-BL/WH)
DX-TX-WP-BL/WH, DXLink Multi-Format Wallplate
Transmitters (FG1010-320-BL/WH)
SDX-410-DX, 4x1 HDMI Digital Switcher with DXLink
Output (FG1010-304)
SDX-510M-DX, 5x1 Multi-Format Digital Switcher with
DXLink Output (FG1010-315)
SDX-810-DX, 8x1 HDMI Digital Switcher with DXLink
Output (FG1010-308)
EXB-IRS4, ICSLan IR/S Interface, 4 IR/S and 4 Inputs
(FG2100-23)
EXB-COM2, ICSLan Serial Interface, 2 Ports (FG2100-22)
EXB-REL8, ICSLan Relay Interface, 8 Channels (FG2100-
20)
paper titled Cabling for Success with DXLink, or contact your AMX representative
Saves Energy – Includes features that dramatically reduce energy utilization. Use the interactive DVX Energy
Savings Calculator to estimate savings for your particular configuration
Specifications
Page 4
4
EXB-I/O8, ICSLan Input/Output Interface, 8 Channels
(FG2100-21)
EXB-MP1, ICSLan Multi-Port, 1 COM, 1 IR/S, 2 I/O, 1 IR
RX (FG2100-26)
CBL-HDMI-FL HDMI, High Speed Flat Cable with
RedMere® Technology (FG10-2180-16)
CBL-DP-FL, DisplayPort High Speed Flat Cable with
RedMere Technology (FG10-2181-16)
CBL-ETH-FL, Ethernet Cat5e Flat Cable (FG10-2182-16)
CBL-RGB+A-FL RGB with Audio Flat Cable (FG10-2183-
16)
ACTIVE POWER REQUIREMENTS
Power Consumption
80 Watts typical without amplifier
85 to 90 Watts typical average with amplifier
30 Watts typical in low-power mode
Power Connector
IEC Power Cord Connector
100-240 VAC
47-63 Hz
Power Factor Correction (PFC)
Supported, complies with N60555-2 and EN610003-2
ENVIRONMENTAL
Temperature (Operating)
0° C to 40° C (32° F to 104° F)
Temperature (Storage)
-10° C to 70° C (14° F to 158° F)
Humidity (Operating)
5% to 85% RH
Heat Dissipation (Typical)
300 BTU/hr
Heat Dissipation (Standby)
100 BTU/hr
ETHERNET
Connection
(1) RJ-45
Description
10/100 Port RJ-45 connector provides TCP/IP
communication. Auto MDI/MDI-X enabled. Supports
IPv4 and IPv6 networks. Supports HTTP, HTTPS, Telnet,
FTP
Link/Act Indicator
Link/Activity LED (green) blinks when receiving
Ethernet data packets, one on Ethernet RJ-45
connector and one on the front panel
Speed Indicator
Speed LED (yellow) lights On when the connection
speed is 100 Mbps Ethernet connection and turns OFF
when the speed is 10 Mbps
INTEGRATED AMPLIFIER
Integrated Amplifier
DVX-2255HD-SP: 2 x 25 W RMS into 8 Ohms Class D
stereo amplifier (4-ohm stable)
DVX-2255HD-T: 75 W, 70 V / 100 V mono amplifier
ICSLAN
ICSLan Connection
(1) RJ-45, 10/100 Port RJ-45 connector. Auto
MDI/MDI-X enabled. Supports IPv4 and IPv6 networks.
Supports HTTP, HTTPS, Telnet, FTP
ICSLan Link/Active Indicator
ICSLan LED (green) blinks when receiving Ethernet data
packets, one on Ethernet RJ-45 connector and one on
the front panel
Page 5
5
ICSLan Speed Indicator
Speed LED (yellow) lights On when the connection
speed is 100 Mbps Ethernet connection and turns OFF
when the speed is 10 Mbps
ONBOARD MASTER
Controller
Integrated Controller is the equivalent of a NetLink NX2200 Integrated Controller
Memory
•NVRAM: 1 MB
•Memory Card: 16 GB SD
•DDRAM: 1 GB
•Note: Supports external USB Solid State Drive
Processor
1600 MIPS
Program Port
(1) USB Standard B
Configuration Dip Switch
4-Position
ID Pushbutton
Black ID pushbutton for setting IP mode and reverting
to default configuration and firmware It has no effect
on the Internal Switcher Device
Status Indicator
Status LED (green) blinks to indicate that the system is
programmed and communicating properly
Input Indicator
Input LED (yellow) blinks to indicate that the Controller
is receiving data
Output Indicator
Output LED (red) blinks to indicate that the Controller
is transmitting data
USB Host Port
(2) USB Standard A, one on front and one on back, USB
Host port supports Solid State drive for upgrading
firmware, loading code files, copying configuration
data and remote storage
CONTROL PORTS & INDICATORS
AxLink Port (1)
(1) 4-position 3.5mm Screw Terminal, provides data
and power to external AxLink control devices
AxLink Indicator
(1) AxLink LED (green) indicates the state of the AxLink
port
RS-232/422/485 Port
(1) 10-position 3.5mm Screw Terminal
NetLinx Port 1
XON/XOFF (transmit on / transmit off)
CTS/RTS (clear to send/ready to send)
300 - 115,200 baud
RS-232 Port
(3) 5-position 3.5mm Screw Terminal
NetLinx Ports 2-4
XON/XOFF (transmit on / transmit off)
CTS/RTS (clear to send/ready to send)
300 - 115,200 baud
Serial Indicator
(4) sets of LEDs (red/yellow) indicate when serial Ports
1-4 are transmitting and receiving data
IR/Serial
(4) 2-position 3.5mm Screw Terminal
4 IR Transmit / 1-way Serial ports
NetLinx Ports 11-14
Support high-frequency carriers up to 1.142 MHz
4 IR/Serial data signals can be generated
simultaneously
IR/Serial Indicators
(4) LEDs (red) indicate when each of the IR/Serial ports
(11-14) are transmitting control data
I/O Channels
(4) One 6-position 3.5mm Screw Terminal
4-channel binary I/O port for contact closure with each
input being capable of voltage sensing
NetLinx Port 22
Page 6
6
Channels 1-4
I/O Indicator
(4) LEDs (yellow) indicate each of the I/O channels (1-
4) are active
Relays
(4) One 2-position 3.5 mm Screw Terminal, (4) singlepole, single-throw relays
NetLinx Port 21
Channels 1-4
Each relay can switch up to 24 VDC or 28 VAC @ 1 A
Each relay is independently controlled
Relay Indicators
(4) LEDs (red) indicate when each of the relay channels
(1-4) are active (closed)
INTEGRATED MATRIX SWITCHER CONTROL
Switch Pushbutton
Press to enter the SWITCH menu on the LCD display.
Choose to switch audio, video or both from any input
to any output. Press the TAKE pushbutton to
implement the switch
Take Pushbutton
While in the SWITCH menu, press to implement an
audio/video switch. When not in the SWITCH menu,
press to cycle through audio and/or video inputs
LCD Display
Liquid crystal display (2 lines with 20 characters per
line) indicates current volume level and displays the
Video, Audio, and Tools menus
Video Menu Pushbutton
Press to access the Video menu on the LCD display.
Multiple presses cycle through the various VIDEO
menus
Audio Menu Pushbutton
Press to access the Audio menu on the LCD display.
Multiple presses cycle through the various AUDIO
menus
Navigation Pushbuttons
(4) directional buttons for navigating the options in the
Video and Audio menu (on the LCD display)
Status Pushbutton
Press to access the STATUS menu on the LCD display
Exit Pushbutton
Press to exit any menu
Video Mute Pushbutton
Press to mute/un-mute (enable/disable) all video
output displays. Video Mute results in a blank screen
on the output display
Audio Mute Pushbutton
Press to mute/un-mute all audio outputs
INTEGRATED MATRIX SWITCHER
Video Switching
6x3 Matrix Video Switching, any of the 6 inputs can be
routed to any or all of the 3 video outputs
Video Inputs
(2) Multi-Format DVI-I; supports HDMI/HDCP, DVI,
RGB, S-Video, Composite, Component (Y/Pb/Pr)
(2) HDMI; supports HDMI/HDCP
(2) DXLink; supports digital video, HDCP, audio,
Ethernet, bi-directional control and power
Video Outputs
(2) HDMI; supports HDMI/HDCP
(1) DXLink; supports digital video, audio, Ethernet, bidirectional control and power
Video Resolution Support
Supports resolutions up to 1920 x 1200 @ 60Hz. See
Operations Reference Guide for details for each signal
type
Progressive Resolution Support
480p up to 1920x1200 @ 60 Hz
If input is interlaced, all scaled outputs will deinterlace
video to a progressive resolution format. If in scaler
Page 7
7
Bypass mode interlaced input will pass through
unaltered
HDCP Support
Yes, full matrix HDCP support (includes any input to
any or all outputs)
Key Management System
AMX HDCP InstaGate Pro Technology
Key support up to 16 sinks per output, independent of
source device
EDID Management
A preferred EDID can be selected for each input or any
display EDID can be mirrored to any input
independently
Audio Switching
8x3 Matrix Audio Switching. Each of the 3 audio
outputs has independent volume, EQ, ducking, sync
delay and mixing. Any of the 3 audio paths can be
routed to any analog, HDMI or S/PDIF output (each
mirrored DXLink output passes audio sent to its
associated HDMI output)
Audio Inputs
(2) female 1/8” stereo mini-phono jacks; support
unbalanced audio
(2) 3.5 mm 5-position captive-wire terminals; support
balanced (differential) or unbalanced (single-ended)
stereo audio
(2) 3.5 mm 3-pin captive-wire MIC connectors;
supports up to two mono microphones, unbalanced or
balanced audio
(2) HDMI connections support digital audio
(2) DXLink connections support audio from DXLink
transmitters
Audio Outputs
DVX-2255HD-SP (FG1906-12):
(1) Amplified audio output; 4-position captive wire
connector; supports amplified, variable, mono or
stereo audio
(2) Line level audio output; supports balanced or
unbalanced mono or stereo
(1) S/PDIF output; mirrors any of the 3 analog audio
outputs, or 2 HDMI outputs or DXLink output
(2) HDMI connections support digital versions of
analog audio or direct pass-through audio
(1) DXLink outputs support digital version of analog
audio or direct pass-through
DVX-2255HD-T (FG1906-14):
(1) Amplified audio output; 2-position captive wire
connector; supports 70V or 100V mono audio –
connect speakers to either but not both
simultaneously
(2) Line level audio output; supports balanced or
unbalanced mono or stereo
(1) S/PDIF output; mirrors any of the 4 analog audio
outputs, or 4 HDMI outputs (each mirrored DXLink
output passes S/PDIF if sent to its associated HDMI
output)
(2) HDMI connections support digital versions of
analog audio or direct pass-through audio
(1) DXLink outputs support digital version of analog
audio or direct pass-through
Audio Breakaway
Yes, stereo audio from any input can be embedded to
or de-embedded from its associated video, processed
through DSP, and switched independently to any
Page 8
8
analog or HDMI output (DXLink outputs are mirrored
to associated HDMI outputs so they will pass the
associated audio, as will the S/PDIF output which
mirrors one of the other audio outputs)
MULTI-FORMAT VIDEO WITH DVI-I
Multi-Format Input Connections
(2) DVI-I; Ports (1-2)
Multi-Format Supported Video
HDMI/HDCP, DVI/HDCP, RGB, S-Video, Composite,
Component (Y/Pb/Pr)
See specifications for each signal style over DVI-I for
more detail
Pixel Clock (Max)
165 MHz (225 MHz in pass-thru mode up to 1080p)
Input Equalization
Yes
Input Re-Clocking (CDR)
Yes
COMPONENT (Y/Pb/Pr) WITH DVI-I
Input Level
1 Vp-p nominal
Input Impedance
75 Ohms, nominal
Note
Requires DVI-I to 3 RCA Adapter or DVI-I to 5 BNC
Adapter
AC coupled: Insensitive to DC offset
S-VIDEO WITH DVI-I
Input Level
1 Vp-p nominal
Input Impedance
75 Ohms, nominal
Note
Requires DVI-I to S-Video Adapter
AC coupled: Insensitive to DC offset
COMPOSITE WITH DVI-I
Input Level
1 Vp-p nominal
Input Impedance
75 Ohms, nominal
Note
Requires DVI-I to 3 RCA Adapter or DVI-I to 5 BNC
Adapter
AC coupled: Insensitive to DC offset
RGBHV WITH DVI-I
Supported Video
RGBHV, RGBS, RGsB
Input Level
1 Vp-p nominal
Input Impedance
75 Ohms, nominal
Sync Input Level
2 to 5 Vp-p
Sync Input Impedance
2.5 pf Typical, 10 pF Maximum
Note
Requires DVI to HD15 Adapter or DVI-I to 5 BNC
Adapter
DVI WITH DVI-I
Supported Video
DVI 1.0
Sync Input Level
2 to 5 Vp-p
Sync Input Impedance
2.5 pf Typical, 10pF Maximum
Page 9
9
Note
Format: RGB
HDMI WITH DVI-I
HDCP Compliance
Yes
Note
Requires DVI to HDMI Adapter
Signal Types: Supports full matrix switching, video
processing and scaling of 8 bit per color standard Input
video signals. Supports full matrix switching and passthru of all HDMI compliant video signals including 3-D
and Deep Color
HDMI WITH HDMI Type A Female
Input Connections
(2) HDMI Type A Female, Ports (3-4)
Input Signal Type Support
HDMI/HDCP, DVI/HDCP, Display Port ++
Data Rate (Max)
4.95 Gbps (6.75 Gpbs in pass-thru mode up to 1080p)
Pixel Clock (Max)
165 MHz (225 MHz in pass-thru mode up to 1080p)
Input Equalization
Yes
Input Re-Clocking (CDR)
Yes
Output Connections
(2) HDMI Type A Female, Ports (1-2)
Output Signal Type Support
HDMI/HDCP, DVI/HDCP
Output Scaling
SmartScale or Manual Configuration or Bypass
SmartScale output resolution support: All resolutions
between 480p and 1920 x 1200 @ 60 Hz via automatic
SmartScale query of the display's declared EDID
Detailed Timing Definition
Deep Color Support
Scaled Outputs: 24-bit, pass-thru Outputs: 30-bit, 36bit
Color Space Support
Y,Cb,Cr & RGB
3D Format Support
Yes, when in Bypass mode, HDMI primary formats
HDCP Compliance
Yes
Audio Format Support for HDMI
Supports Dolby TrueHD, Dolby Digital, DTS-HD Master
Audio, DTS, L-PCM
Note
DisplayPort ++ requires DisplayPort to HDMI adapter
cable
Supports full matrix switching, video processing and
scaling of 8 bit per color standard Input video signals.
Supports full matrix switching and pass-thru of all
HDMI compliant video signals including 3-D and Deep
Color
Each output can deliver processed and scaled video or
pass-thru video from any video input
Each output can embed audio from any of the 3 analog
audio outputs as Stereo L-PCM or can pass-thru Dolby
TrueHD, Dolby Digital, DTS-HD Master Audio, DTS and
L-PCM audio from the selected video source
DXLINK WITH RJ-45
Input Connections
(2) RJ-45; Ports 5-6
Input Compatible Formats
Digital video, audio, Ethernet, bi-directional control
and power (supported capabilities for DXLink vary by
Page 10
10
connected device, see connected device manual for
more information)
Output Connections
(1) RJ-45; Port (3)
Output Compatible Formats
Digital Video with embedded audio, analog audio,
Ethernet, Bi directional control and power
Supports full matrix switching and pass-thru of all
HDMI compliant video signals including 3D and Deep
Color
Audio Signal Types: Supports Dolby TrueHD, Dolby
Digital, DTS-HD Master Audio, DTS, L-PCM
Output Re-Clocking
Yes
Output Scaling
SmartScale or Manual Configuration or Bypass
Input Connections
(2) RJ-45; Ports (5, 6)
Input Compatible Formats
Digital video, audio, Ethernet, bi-directional control
and power (supported capabilities for DXLink vary by
connected device, see connected device manual for
more information)
HDCP Support
Yes
Twisted Pair Cable Type
Shielded Cat6, Cat6A and Cat7
DXLink twisted pair cable runs for DXLink equipment
shall only be run within a common building where a
common building is defined as: the walls of the
structure(s) are physically connected and the
structure(s) share a single ground reference
For more details and helpful cabling information,
reference the white paper titled Cabling for Success
with DXLink, or contact your AMX representative
Note
Supports full matrix switching, video processing and
scaling of 8 bit per color standard Input video
ANALOG AUDIO
Analog Audio Input Connections
(2) female 1/8” stereo mini-phono jacks; support
unbalanced audio
(2) 3.5 mm 5-position captive-wire terminals; support
balanced (differential) or unbalanced (single-ended)
stereo audio
Input Level (Nominal)
+4 dBu (1.228 Vrms) balanced or -10 dBV (0.3162
Vrms) unbalanced
Input Level (Maximum)
+14 dBu 2 Vrms
Input Impedance
>12 kOhms balanced, >12 kOhms unbalanced
Analog Audio Output Connections
DVX-2255HD-SP (FG1906-12):
(1) Amplified audio output; 4-position captive wire
connector; supports amplified, variable, mono or
stereo audio
(2) Line level audio output; supports balanced or
unbalanced mono or stereo
DVX-2255HD-T (FG1906-14):
(1) Amplified audio output; 2-position captive wire
connectors; supports 70V or 100V mono audio –
connect a speaker to either but not both
simultaneously
(2) Line level audio output; supports balanced or
unbalanced mono or stereo
Volume Control
-100 dB to +0 dB in 1 dB steps
Page 11
11
Balance Control
20 steps each left and right
Output Level (Maximum)
+17 dBu (line level)
Output Impedance
200 Ohms (line level)
Audio Channel Crosstalk
Balanced Line Inputs: -98 dB @ 0 dBV, 20 Hz to 20 kHz
Unbalanced Line Inputs: -70 dB @0 dBV, 20 Hz to 20
kHz
Audio Frequency Response
AMP: 20 Hz to 20 kHz ±0.75 dB @ 8 Ohms
Line: 20 Hz to 20 kHz ±0.1 dB
Audio Input Compression
Independent Compression per input
Attack: 1 to 2000 ms
Release: 10 to 5000 ms
Compression Ratio: 1 to 20
Threshold: -60 to 0 dB
Audio Input Gain Compensation
-24 dB to +24 dB, 1dB steps
Audio Output Equalizer
10-band parametric EQ with variable center frequency,
filter type and Q per band
Center Frequency: 20 Hz to 20 kHz
EQ Gain: -12 to +12 dB
Q: 0.1 to 20
Filter Types: Bell, Base Shelving, Treble Shelving, Low
Pass, High Pass, Band Pass, Band Stop
Audio Output Sync Delay
0 to 200 ms
Audio S/N Ratio
AMP: 85 dB @ 8 Ohms, full output, 1 kHz A-weighted
Line: 105 dB @ 10 dBV, AES17
Audio THD+N
AMP: < 0.15% @ 8 Ohms, 20 Watts, 20 Hz to 20 kHz
Line: 0.003% @ 0 dBV, 1 kHz
Note
Independent EQ, Volume and Balance control per
output
MICROPHONE AUDIO
Microphone Input Connections
(2) 3.5 mm 3-pin captive-wire MIC connectors;
supports up to two mono microphones, unbalanced or
balanced audio
Microphone Input Level (Maximum)
5 dBu
Microphone Input Format Support
Line or Mic level, balanced or unbalanced audio
Microphone Input Impedance
3.5 kOhms, accepts 60 to 600 Ohms sources
Microphone Input Gain
-24 dB to +89 dB, 1 dB steps
Microphone Input Equalizer
3-band parametric EQ with variable center frequency,
filter type and Q
Center Frequency: 20 Hz to 20 kHz
EQ Gain per Band: -12 to +12 dB
Q per band: 0.1 to 20
Filter Types: Bell, Base Shelving, Treble Shelving, Low
Pass, High Pass, Band Pass, Band Stop
Microphone Input Compression
Independent Compression per Microphone
Attack: 1 to 2000 ms
Release: 10 to 5000 ms
Compression Ratio: 1 to 20
Threshold: -60 to 0 dB
Microphone Gating
Independent Gating per Microphone
Attack: 1 to 2000 ms
Release: 10 to 5000 ms
Depth: 0 to 20 dB
Hold Off: 0 to 2000 ms
Threshold: -60 to 0 dB
Microphone Limiter
Independent Limiting per Microphone
Attack: 1 to 2000 ms
Page 12
12
Release: 10 to 5000 ms
Threshold: -60 to 0 dB
Microphone Ducking
Independent Ducking per each of 3 audio paths
Attack: 1 to 2000 ms
Release: 10 to 5000 ms
Attenuation: 0 to 20 dB
Hold Off: 0 to 4000 ms
Threshold: -60 to 0 dB
Microphone Inputs Note
Phantom Power: switchable 48 V to each microphone
@ 8 mA total
S/PDIF DIGITAL AUDIO
S/PDIF Audio Outputs
(1) S/PDIF output; mirrors either of the 2 analog audio
outputs or 2 HDMI outputs or the DXLink output
S/PDIF Audio Output Note
Output can mirror any of the 2 analog audio outputs as
stereo digital audio, or L-PCM, Dolby Digital and DTS
audio being passed-thru to any of the 2 HDMI outputs
or DXLink output
For a more detailed pictorial drawing please visit: http://www.amx.com/products/DVX-2255HD.asp
About AMX by HARMAN
Founded in 1982 and acquired by HARMAN in 2014, AMX® is dedicated to providing AV solutions for an IT World. AMX solves the complexity of
managing technology with reliable, consistent and scalable systems comprising control, video switching and distribution, digital signage and technology
management. AMX systems are deployed worldwide in conference rooms, classrooms, network operation/command centers, homes, hotels,
entertainment venues and broadcast facilities, among others. AMX is part of the HARMAN Professional Group, the only total audio, video, lighting, and
control vendor in the professional AV market. HARMAN designs, manufactures and markets premier audio, video, infotainment and integrated control
solutions for the automotive, consumer and professional markets. Revised 4.28.15. ©2015 Harman. All rights reserved. Specifications subject to change.
www.amx.com | +1.469.624.7400 |800.222.0193
Loading...
