DATA SHEET
TM
Enova® DGX DXLink
AVS-ENOVADGX32-VO-DXLink (FG1058-580)
Twisted Pair Output Board
Overview
The AVS-ENOVADGX32-VO-DXLINK is a HDCP compliant twisted pair cable output
board for the Enova DGX 8, 16, 32 and 64 Digital Media Enclosures. It has four
connections per DXLink Output Board and is designed to transmit audio and video
to DXLink Twisted Pair Receivers while passing bi-directional control and Ethernet
over one standard twisted pair cable up to 100m. DXLink Power is available from
the DXLink Output Board to power DXLink Twisted Pair Receivers.
Common Applications
The Enova DGX DXLink Twisted Pair Output Board is ideal for applications where destination devices are located
up to 100 meters away from the Enova DGX Digital Media Switcher and need to be distributed throughout a
commercial or residential environment.
© 2013 AMX. All rights reserved.
Features
Only One Cable – Send audio and video while passing control, Ethernet and power over one twisted pair
cable
Send HDMI signals up to 100 Meters – Extend the reach of the HDMI with HDCP signals far beyond the
capabilities of typical HDMI cabling
Standard Twisted Pair Cable – Save time and effort in installation by leveraging pre-existing cost effective
twisted pair cable, see the Cabling for Success with DXLink white paper for more details
Hot Swappable – Easily add or replace I/O boards at any time after deployment - the system automatically
recognizes the new configuration and activates the boards
HDCP Compliant
Additional Features
Remotely Powered Receivers - DXLink Power* is available from the DXLink Output Board to power DXLink
Receivers
3D Support - Pass through latest video formats including 3D and Deep Color
Surround Sound Support - Pass through high definition surround sound including Dolby Digital, DTS and up
to 8-channel L-PCM at 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
*Power over DXLink to DXLink Receivers must be supplied by one of the following DXLink Power sourcing devices: Enova
Signal Transport – DXLink w/HDCP
Description
Compatible Formats
Must be used in conjunction with an Enova DGX
8,16,32 or 64 Digital Media Enclosure and DXLink
Twisted Pair Receiver
HDMI Video / Audio / Ethernet / Power and Control
Future Compatible Formats
USB (HID) Keyboard & Mouse *
Signal Type Support
DXLink
DXLink Power
The DXLink Twisted Pair Output Board provides Power
over DXLink
DXLink Twisted Pair Receiver can have power supplied
over twisted pair cable when connected to a DXLink
Output board of the Enova DGX Digital Media Switcher
DXLink Receiver Modules can be powered via DXLink
Power or desktop power supply (ENERGY STAR®
qualified) with power cord
Approved Power over DXLink sourcing devices for
DXLink Twisted Pair Receiver include:
•Enova DGX 8/16/32/64 Digital Media Switcher (with
a DXLink Twisted Pair Output Board installed)
•Compatible Enova DVX All-In-One Presentation
Switcher (3155HD, 3156HD, 2155HD, 3150HD and
2150HD)
•PS-POE-AT-TC High Power PoE Injector
•PDXL-2 Power over DXLink Controller
Use the Enova DGX Configuration Tool located at
AMX.com/enova to determine the power
requirements of a configuration and whether any of
the DXLink Transmitters or Receivers should be
powered with the local power supply. The
configuration tool contains instructions on how to
determine power requirements.
Connectors
(4) RJ-45 Ports
Transport Layer Throughput (Max)
10.2 Gbps
Twisted Pair Cable Type
Shielded Cat6, Cat6A and Cat7
DXLink twisted pair cable runs for DXLink equipment
DGX 8/16/32/64 Digital Media Switcher (with a DXLink Twisted Pair Output Board installed), Compatible Enova DVX All-In-
One Presentation Switcher (3155HD, 3156HD, 2155HD, 3150HD or 2150HD), PS-POE-AT-TC High Power PoE Injector or
PDXL-2 Power over DXLink Controller. AMX only supports the use of these approved Power over DXLink solutions. Other
third party power supplies or non-compatible standard PoE solutions may damage the DXLink equipment. The DXLink
Receiver Module can also be powered via the included desktop power supply (ENERGY STAR® qualified) with power cord
Specifications
shall only be run within a common building where a
common building is defined as: the walls of the
structure(s) are physically connected and the
structure(s) share a single ground reference
For more details and helpful cabling information,
reference the white paper titled Cabling for Success
with DXLink, or contact your AMX representative
Twisted Pair Cable Length
Up to 328 ft (100 m)
Video Data Rate (Max)
4.95 Gbps / 6.75 Gbps
6.75 Gbps supported when the HDMI Output Board
Scaler or DXLink HDMI RX Scaler is in Bypass mode and
format is 1080p60 or less
Video Pixel Clock (Max)
165 MHz / 225 MHz
225 MHz supported when the HDMI Output Board
Scaler or DXLink HDMI RX Scaler is in Bypass mode and
format is 1080p60 or less
Progressive Resolution Support
480p up to 1920x1200 @ 60 Hz
Deep Color Support
24-bit, 30-bit, 36-bit
30-bit, 36-bit supported when the HDMI Output Board
Scaler or DXLink HDMI RX Scaler is in Bypass mode and
format is 1080p60 or less
Color Space Support
RGB 4:4:4
YCbCr 4:4:4 and 4:2:2
Input signal support for YCbCr 4:4:4 and 4:2:2, output
color-space is converted to RGB 4:4:4
3D Format Support
Yes (HDMI Primary Formats, when used with DXLink
Output Boards and the DXLink HDMI RX Scaler is in
Bypass mode)
Frame Packing 1080p up to 24 Hz
Frame Packing 720p up to 50/60 Hz
Frame Packing 1080i up to 50/60 Hz
Top-Bottom 1080p up to 24 Hz
Top-Bottom 720p up to 50/60 Hz
Side-by-Side Half 1080p up to 50/60 Hz
Side-by-Side Half 720p up to 50/60 Hz
Audio Format Support
Dolby TrueHD, Dolby Digital, DTS-HD Master Audio,
DTS, 2 CH through 8 CH L-PCM
Dolby Digital and DTS support up to 48 kHz, 5.1
channels
Audio Resolution
16 bit to 24 bit
Audio Sample Rate
32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192kHz
Local Audio Support
Yes, Insertion and/or Extraction of 2 CH L-PCM
selectable by channel when used in conjunction with
the Enova DGX Audio Insert / Extract Board
HDCP Support
Yes, full matrix HDCP support (includes any input to
any or all outputs)
Key Management System
AMX HDCP InstaGate Pro Technology
Key support up to 16 devices per output, independent
of source device
CEC Support
None
ICSP, TCP/IP, USB, IR, Control Management
Control distribution is managed by the Enova DGX
16/32 Digital Media Switcher on-board NetLinx Master
and Ethernet Switch
Approvals
CE, FCC Class A, UL, cUL, RoHS / WEEE compliant
**This feature will be available upon release of a future firmware update
About AMX
AMX hardware and software solutions simplify the implementation, maintenance, and use of technology to create effective environments. With the increasing number of
technologies and operating platforms at work and home, AMX solves the complexity of managing this technology with reliable, consistent and scalable systems. Our award-winning
products span control and automation, system-wide switching and audio/video signal distribution, digital signage and technology management. They are implemented worldwide in
conference rooms, homes, classrooms, network operation / command centers, hotels, entertainment venues, broadcast facilities, and more. ©2013 AMX. All rights reserved.
Specifications subject to change. Revised 9-July-13.
