AMS 2140 Machinery Health™ Analyzer

User Guide

MHM-97432, Rev 10

May 2019

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Emerson.

Disclaimer

This manual is provided for informational purposes. EMERSON MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Emerson shall not be liable for errors, omissions, or inconsistencies that may be contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. Information in this document is subject to change without notice and does not represent a commitment on the part of Emerson. The information in this manual is not all-inclusive and cannot cover all unique situations.

Patents

The product(s) described in this manual are covered under existing and pending patents.

Contents

Chapter 1 AMS 2140 Machinery Health Analyzer .............................................................................. 1

1.1 AMS 2140 Machinery Health Analyzer overview ............................................................................. 1

1.2 User Guide overview .......................................................................................................................1

1.3 Documentation conventions ......................................................................................................... 1

1.4 Precautions and general maintenance ............................................................................................2

1.5 Technical Support and Customer Service ....................................................................................... 3

Chapter 2 Introduction to the analyzer .............................................................................................5

2.1 Standard equipment ...................................................................................................................... 5

2.2 Front view ...................................................................................................................................... 6

2.3 Top view .........................................................................................................................................7

2.4 Turn on the analyzer for the first time .............................................................................................7

2.5 Use the stand ................................................................................................................................. 8

2.6 Attach the shoulder strap ............................................................................................................... 8

2.7 Battery pack ................................................................................................................................... 9

2.8 External AMS 2140 Battery Charger ..............................................................................................15

2.9 Turn the analyzer on or off ............................................................................................................18

2.10 Home screen ................................................................................................................................19

2.11 Backlight ...................................................................................................................................... 21

2.12 Touchscreen ................................................................................................................................ 21

2.13 Menu navigation ......................................................................................................................... 26

2.14 Settings ........................................................................................................................................26

2.15 Memory card ................................................................................................................................30

2.16 Bluetooth .....................................................................................................................................31

2.17 Utilities .........................................................................................................................................35

2.18 Clean the analyzer ........................................................................................................................38

2.19 AMS 2140 Four-Channel Input Adapter ........................................................................................ 39

2.20 Multiple inputs ............................................................................................................................. 40

2.21 AMS 2140 for use in hazardous locations ......................................................................................41

Chapter 3 Transfer files with AMS 2140 .......................................................................................... 43

3.1 AMS Machinery Manager Data Transfer ........................................................................................43

3.2 Standalone Data Transfer application ...........................................................................................43

3.3 Communication setup ..................................................................................................................44

3.4 Routes and jobs ............................................................................................................................56

3.5 Analyzer firmware and programs ..................................................................................................62

3.6 Screen captures ............................................................................................................................65

3.7 Splash screens ..............................................................................................................................66

3.8 Printing ........................................................................................................................................ 67

Chapter 4 Route ............................................................................................................................ 69

4.1 Route overview ............................................................................................................................ 69

4.2 Manage routes ............................................................................................................................. 72

4.3 Set data collection and display parameters ...................................................................................76

4.4 Tachometers ................................................................................................................................82

4.5 Multiple inputs and measurements .............................................................................................. 84

4.6 Collect route data ........................................................................................................................85

4.7 Notes ...........................................................................................................................................89

MHM-97432 Rev 10 i

Contents

4.8 Plot route data ............................................................................................................................. 91

4.9 Run Analyze to collect data for a route measurement point ..........................................................91

4.10 View the route measurement point setup and history .................................................................. 92

4.11 Route reports ............................................................................................................................... 94

Chapter 5 Plots ...............................................................................................................................97

5.1 View a full screen version of the plot ............................................................................................97

5.2 Select an active plot ..................................................................................................................... 98

5.3 Switch the plot type ..................................................................................................................... 98

5.4 Add or remove a cursor from a plot .............................................................................................. 98

5.5 Change the cursor type ................................................................................................................ 99

5.6 Change the scale of the x and y axis ............................................................................................100

5.7 Expand or compress the X axis ....................................................................................................100

5.8 View the highest frequency peaks on the spectrum plot ............................................................ 100

5.9 Set RPM ......................................................................................................................................101

5.10 View fault frequencies on a plot ................................................................................................. 101

Chapter 6 Analyze and Advanced Analyze .....................................................................................103

6.1 Analyze overview ....................................................................................................................... 103

6.2 Manage jobs ...............................................................................................................................107

6.3 Set display parameters ............................................................................................................... 110

6.4 Multi-input measurements .........................................................................................................111

6.5 Sensors and inputs ..................................................................................................................... 111

6.6 Tachometers ..............................................................................................................................114

6.7 Common data collection parameters ......................................................................................... 116

6.8 Collecting data using an Analysis Expert ..................................................................................... 122

6.9 Collect data using Manual Analyze ............................................................................................. 138

6.10 Listen to live vibration data in Analyze ........................................................................................ 159

6.11 Redo a measurement in Analyze ................................................................................................ 161

6.12 Store data to a route or an Analyze job ....................................................................................... 161

6.13 Review previously collected data in Analyze ............................................................................... 161

6.14 Print an Analyze plot to AMS Machinery Manager .......................................................................162

6.15 Print an Analyze plot to a memory card ...................................................................................... 162

6.16 Reset Analyze defaults ............................................................................................................... 163

Chapter 7 Advanced Laser Alignment ........................................................................................... 165

7.1 Basic and Advanced Laser Alignment Application overview ........................................................ 165

7.2 Set up the laser and sensor .........................................................................................................175

7.3 Manage jobs ...............................................................................................................................186

7.4 Set the job parameters ...............................................................................................................191

7.5 Horizontal alignment ................................................................................................................. 203

7.6 Vertical alignment ......................................................................................................................236

7.7 Straightness measurements .......................................................................................................247

7.8 Plots ...........................................................................................................................................252

7.9 Transfer alignment jobs ..............................................................................................................257

Chapter 8 Advanced Transient ......................................................................................................263

8.1 Advanced Transient overview .....................................................................................................263

8.2 Manage jobs ...............................................................................................................................267

8.3 Sensors and inputs ..................................................................................................................... 269

8.4 Tachometers ..............................................................................................................................271

8.5 Select a section of the full transient waveform ...........................................................................273

8.6 Set the number and type of plots to display in Advanced Transient ............................................ 275

8.7 Set data collection parameters ...................................................................................................276

ii MHM-97432 Rev 10

Contents

8.8 Collect transient data ................................................................................................................. 278

8.9 Plot data in Advanced Transient ................................................................................................. 279

Chapter 9 ODS/Modal ...................................................................................................................281

9.1 ODS/Modal overview .................................................................................................................281

9.2 Manage jobs ...............................................................................................................................285

9.3 Sensors and inputs ..................................................................................................................... 288

9.4 Tachometers ..............................................................................................................................290

9.5 Set up the plots .......................................................................................................................... 292

9.6 Set up the job .............................................................................................................................293

9.7 Collect ODS/Modal data .............................................................................................................298

9.8 Display the data for a ODS/Modal measurement point ...............................................................300

9.9 Print an ODS/Modal plot to AMS Machinery Manager .................................................................301

9.10 Print an ODS/Modal plot to a memory card ................................................................................ 301

Chapter 10 Balance ........................................................................................................................ 303

10.1 Balance overview ....................................................................................................................... 303

10.2 Manage jobs ...............................................................................................................................308

10.3 Job Setup ....................................................................................................................................311

10.4 Sensor Setup .............................................................................................................................. 318

10.5 Measurement Plane Setup .........................................................................................................322

10.6 Weight Plane Setup ....................................................................................................................325

10.7 Acquire Data .............................................................................................................................. 328

10.8 Balance correction ..................................................................................................................... 338

10.9 Trim run ..................................................................................................................................... 340

10.10 One-run balance job ...................................................................................................................344

10.11 Notes ......................................................................................................................................... 345

10.12 Balance summary reports ...........................................................................................................346

10.13 Review Balance data ...................................................................................................................349

10.14 Manually enter data for a Balance job ......................................................................................... 350

10.15 Calculator Mode .........................................................................................................................350

10.16 Tips and additional information ..................................................................................................361

10.17 Balance accessories ....................................................................................................................366

Appendices and reference

Appendix A Technical specifications ................................................................................................377

A.1 Hardware specifications .............................................................................................................377

A.2 Measurement specifications .......................................................................................................378

A.3 Input specifications ....................................................................................................................379

A.4 Connecting to a computer ......................................................................................................... 381

A.5 Waste Electrical and Electronic Equipment .................................................................................381

A.6 FCC ............................................................................................................................................ 381

A.7 Industry Canada .........................................................................................................................382

A.8 Wireless certifications ................................................................................................................ 383

Appendix B View and control your AMS 2140 from a PC .................................................................. 385

B.1 AMS 2140 Remote Display Viewer ..............................................................................................385

B.2 Load the AMS 2140 Remote Display Viewer onto your AMS 2140 ...............................................386

B.3 View and control the AMS 2140 from your PC ............................................................................ 387

B.4 Transfer files while using the AMS 2140 Remote Display Viewer .................................................389

B.5 View the version number of the AMS 2140 Remote Display Viewer ............................................ 390

MHM-97432 Rev 10 iii

Contents

Appendix C Add channels to your AMS 2140 ....................................................................................391

Glossary ........................................................................................................................................... 393

Index ................................................................................................................................................399

iv MHM-97432 Rev 10

AMS 2140 Machinery Health Analyzer

1 AMS 2140 Machinery Health Analyzer

Topics covered in this chapter:

• AMS 2140 Machinery Health Analyzer overview

• User Guide overview

• Documentation conventions

• Precautions and general maintenance

• Technical Support and Customer Service

1.1 AMS 2140 Machinery Health Analyzer overview

The AMS 2140 Machinery Health Analyzer is a portable vibration analyzer that lets you quickly and easily collect data from rotating equipment in process plants, do an on-site analysis of the machine, and export results to the AMS Suite: Machinery Health Manager software for storage and further analysis. You can also collect data using PeakVue technology. The analyzer supports up to four channels to make collecting data faster and more efficient.

™

You can add additional programs to the analyzer to further expand your analysis and troubleshooting capabilities. Add the Advanced Analyze, Balance, Advanced Laser Alignment, ODS/Modal, and Advanced Transient programs at any time.

1.2 User Guide overview

The AMS 2140 Machinery Health Analyzer User Guide is written for Vibration Analysts, Reliability Data Collection Technicians, and Reliability Engineers who monitor rotating machines in a process plant environment.

The User Guide describes how to set up the analyzer, take route and job-based measurements, review the data, and transfer the data to AMS Machinery Manager for storage and analysis. The User Guide is written for the single-channel, dual-channel, and four-channel versions of the AMS 2140. Any differences are noted.

1.3 Documentation conventions

The following conventions are used throughout:

Note

A note paragraph contains special comments or instructions.

MHM-97432 Rev 10 1

AMS 2140 Machinery Health Analyzer

CAUTION!

A caution paragraph alerts you to actions that can have a major impact on the equipment or stored data.

WARNING!

A warning paragraph alerts you to actions that can have extremely serious consequences for equipment and/or personnel.

1.4 Precautions and general maintenance

Any maintenance, repair, or replacement of components not listed below must be performed by specially trained personnel at Emerson authorized service centers. Any damage to the product caused by misuse, abuse, neglect, carelessness or modifications performed by anyone other than Emerson may void the warranty.

Following the precautions listed below, you can perform common maintenance procedures on the AMS 2140 and its accessories.

WARNING!

• An electrostatic discharge is possible when you clean the equipment exterior. When

cleaning the equipment exterior, do not use any abrasive or corrosive chemicals or materials. Do not use petroleum distillates and ketone solvents, for example, acetone, gasoline and kerosene. Use a dry, lint-free towel or cloth dampened with a mild soap and water solution. Clean the analyzer only in a non-hazardous area.

• Charge, remove, and replace the battery pack only in a non-hazardous area.

• Use only Emerson’s battery packs with the AMS 2140. The analyzer will not function if a

non-Emerson battery pack is used. Lithium-Ion batteries have very specific charging requirements. Emerson-supplied power supplies and chargers are designed to work with Emerson’s Lithium-Ion battery pack. Using battery packs other than Emerson’s approved battery packs could not only void the warranty, but could also be hazardous.

Precautions

• To prevent permanent damage to the touchscreen on the AMS 2140, never use

sharp objects or excessive pressure with your fingers or stylus. Lightly tap the screen.

• Use only Emerson’s power supplies and chargers approved for use with the AMS

2140 and Emerson’s battery packs. Using any power supplies and chargers other than Emerson’s approved power supplies and battery packs could not only void the warranty, but will also most likely damage the analyzer or the battery pack.

• Do not change or remove the battery pack in the AMS 2140 with the power supply

connected to the analyzer. The AMS 2140 or battery pack may be damaged.

• Do not use Emerson’s battery packs, power supplies, and chargers with any product

other than their corresponding Emerson product.

2 MHM-97432 Rev 10

AMS 2140 Machinery Health Analyzer

• When charging the AMS 2140 with the battery pack or the battery pack by itself,

ensure the ambient temperature where charging is occurring is 50° F to 95° F (10° C to 35° C).

• When operating the AMS 2140 with the battery pack, ensure the ambient

temperature where the analyzer is being used is -4° F to 122° F ( -20° C to 50° C).

Prevent battery degradation

When storing the AMS 2140 with the battery pack or storing the battery pack by itself for a prolonged period of time:

• Ensure the ambient temperature where the battery pack is located is -4° F to 95° F

( -20° C to 35° C). Due to the chemical composition of Lithium-Ion battery technology, over time there will be some degradation that results in a reduced charge capacity and performance. This degradation is unavoidable and irreversible. Prolonged storage at temperatures outside this range, especially temperatures above the high end, speeds up the degradation process.

• Disconnect the power supply from the AMS 2140 or the battery pack.

• When storing for 1–3 months, Emerson recommends removing the battery pack

from the AMS 2140.

• When storing the battery for longer than three months, contact Technical Support

to learn how to enter storage mode. Storage mode protects the battery during long term storage. In storage mode, the analyzer and battery are non-functional. The analyzer does not power on and the battery LEDs do not operate. Connect the charger to the unit to reactivate the battery.

Note

If you do not enter storage mode, ensure the battery capacity is approximately 40 percent and periodically recharge the battery pack (to approximately 40 percent charge capacity) during storage to ensure the battery does not drain to low levels.

Prevent damage

To prevent damage to the analyzer:

• Do not connect a signal larger than 0 to 24 volts into the Accel input of the AMS

2140.

• Do not connect a signal larger than +/- 24 volts into the Volts / Tach input of the

AMS 2140.

1.5 Technical Support and Customer Service

When you contact Technical Support, be ready with a screen capture of the error message and details such as when and how the error occurred.

Hardware Technical Help

Have the number of the current version of your firmware ready when you call. To view the firmware version of the AMS 2140, select Home > ALT > F1 Version.

MHM-97432 Rev 10 3

AMS 2140 Machinery Health Analyzer

Software Technical Help

Provide the software version numbers of both your Microsoft® Windows operating system and AMS Machinery Manager, and your AMS Machinery Manager serial number. To find AMS Machinery Manager version and serial numbers, select Help > About.

Be at your computer when you call. We can serve you better when we can work through the problem together.

Software Technical Support

Emerson provides technical support through the following for those with an active support agreement:

• Telephone assistance and communication via the Internet.

• Mass updates that are released during that time.

• Interim updates upon request. Please contact Emerson Technical Support for more

information.

Customer Service

Contact Customer Service for all non-technical issues, such as ordering replacement parts.

For Emerson Technical Support and Customer Service Toll Free numbers, email addresses, and hours of operation, please visit http://www.emerson.com/technicalsupport.

4 MHM-97432 Rev 10

2 Introduction to the analyzer

Topics covered in this chapter:

• Standard equipment

• Front view

• Top view

• Turn on the analyzer for the first time

• Use the stand

• Attach the shoulder strap

• Battery pack

• External AMS 2140 Battery Charger

• Turn the analyzer on or off

• Home screen

• Backlight

• Touchscreen

• Menu navigation

• Settings

• Memory card

• Bluetooth

• Utilities

• Clean the analyzer

• AMS 2140 Four-Channel Input Adapter

• Multiple inputs

• AMS 2140 for use in hazardous locations

Introduction to the analyzer

2.1 Standard equipment

Unpack the analyzer and compare the contents of the package to the list below. If you find a discrepancy, contact your local sales representative immediately.

• Firmware media

• Micro USB cable to connect to AMS Machinery Manager

• Power supply to charge the battery pack

• Screen protector

• Shoulder strap

MHM-97432 Rev 10 5

Introduction to the analyzer

Note

The AMS 2140 does not support cables with 25-pin connectors or cables that connect to the Volts/ Tach input from previous Emerson vibration analyzers.

2.2 Front view

AMS 2140 front panelFigure 2-1:

A. Home key—Return to the Home screen from any program.

Reset key—Return to the main menu in a program.

B. C. Function keys—Display menu options. D. Enter key—Select a menu or option. E. Keypad backlight key—Turn on the backlight under the keys. F. LCD backlight key—Set the backlight for the LCD touchscreen. G. Help key—Display Help text for a key. H. Power key—Turn the analyzer on or off, or put the analyzer in standby. I. Battery LED—Green light if the battery pack is charged; amber when charging. J. Status LED—Blue light flashes each time you press a key or option, blinks in power save mode, and

remains solid in standby mode.

K. Arrow keys—Move through menus. L. ALT key—Display an alternate screen, if available. M. Back key—Back up to the main menu in a program.

(1) To comply with relevant safety certifications, the AMS 2140 labeled “ATEX/IECEx Zone 2” does not have a keypad backlight.

(1)

6 MHM-97432 Rev 10

2.3 Top view

ConnectorsFigure 2-2:

A. Power supply connector. B.

Ethernet port.

C. Micro USB port. D. Wireless LED. E. Bluetooth® LED (not present on newer versions).

Introduction to the analyzer

CAUTION!

To prevent damage to the analyzer:

• Do not connect a signal outside the range of 0 to 24 volts into the Accel input of the AMS

2140.

• Do not connect a signal outside the range of +/- 24 volts into the Volts / Tach input of the

AMS 2140.

2.4 Turn on the analyzer for the first time

Activate the battery pack before turning on the analyzer for the first time. The battery pack is shipped in storage mode to protect the battery charge. Connect the provided power supply cord into an outlet and to the analyzer to activate the battery pack.

Procedure

Connect the provided power supply cord into an outlet and to the analyzer.

Note

Refer to precautions for the battery pack and power adapter.

The Battery LED is amber to indicate the battery pack is charging. The analyzer is activated.

Press and hold the power key to turn the analyzer on.

MHM-97432 Rev 10 7

Introduction to the analyzer

The Home screen appears when you turn on the analyzer. The time and date are set to a default value.

To set the time and date, press Home > ALT > F3 Set Time.

2.5 Use the stand

1. To put the stand in the upright position, grab the stand and pull up until the stand locks.

2. To release the stand, place the analyzer face down, grab the base of the stand, and gently pull.

The lock releases, and you can push the stand toward the analyzer.

Release the standFigure 2-3:

2.6 Attach the shoulder strap

1. Press and hold the button on the strap connector, and insert it into the connectors on the sides of the analyzer or the AMS 2140 Four-Channel Input Adapter, if attached.

To release the strap, press and hold the button on the connector and then pull.

8 MHM-97432 Rev 10

2.7 Battery pack

A rechargeable Lithium-Ion battery pack powers the analyzer. A typical charge should last for more than 8 hours of continuous use. The analyzer displays a low-battery warning when the remaining charge reaches a set level; the default is 15 percent. If the battery pack fully discharges, you do not lose any data or settings.

The battery pack is shipped in storage mode to protect the battery charge. Refer to

Section 2.4 to activate the battery pack.

You do not need to discharge or calibrate the battery pack. The hardware optimizes battery pack performance. Contact technical support if you experience any problems or for instructions on how to store or replace the battery pack.

WARNING!

Use only Emerson battery packs with the AMS 2140. The analyzer will not function if a nonEmerson battery pack is used. Lithium-Ion batteries have very specific charging requirements. Emerson power supplies and chargers are designed to work with the Emerson Lithium-Ion battery pack. Using battery packs other than approved Emerson battery packs could not only void the warranty, but could also be hazardous.

Introduction to the analyzer

2.7.1 Access the battery pack

The battery pack is located on the back of the analyzer. To access the battery, remove the six screws that attach it to the analyzer.

MHM-97432 Rev 10 9

Introduction to the analyzer

Six battery pack screwsFigure 2-4:

WARNING!

Remove the battery pack only in a non-hazardous area.

2.7.2 Battery pack and power supply precautions

Understand and follow the precautions below before using the battery pack and power supply.

• Do not use Emerson’s battery packs, power supplies, and chargers with any product

other than their corresponding Emerson product.

• Use only Emerson’s power supplies and chargers approved for use with the AMS

• Do not change or remove the battery pack in the AMS 2140 with the power supply

connected to the analyzer. The AMS 2140 or battery pack may be damaged.

10 MHM-97432 Rev 10

• When charging the AMS 2140 with the battery pack or the battery pack by itself,

ensure the ambient temperature where charging is occurring is 50° F to 95° F (10° C to 35° C).

• When operating the AMS 2140 with the battery pack, ensure the ambient

temperature where the analyzer is being used is -4° F to 122° F ( -20° C to 50° C).

WARNING!

• Use only Emerson’s battery packs with the AMS 2140. The analyzer will not function if a

• Charge, remove, and replace the battery pack only in a non-hazardous area.

2.7.3 View the battery charge level

View the remaining charge level from the analyzer Home screen or from the LEDs on the battery pack.

Introduction to the analyzer

Procedure

Do one of the following:

• From the Home screen, view the remaining battery charge on the lower left side of the

screen.

• Press the button on the inside of the battery pack. Each LED indicates approximately 20

percent remaining charge.

MHM-97432 Rev 10 11

Introduction to the analyzer

Check the remaining charge from the battery packFigure 2-5:

Note

If the battery pack has been placed in storage mode, the LEDs do not operate.

2.7.4 Charge the battery pack

The analyzer is fully operational during charging. As a best practice, charge the battery pack frequently. Emerson recommends you charge the battery pack the night before you intend to use it.

WARNING!

• Use only Emerson-supplied power supplies and chargers approved for use with the AMS

2140 and Emerson battery packs. Using any power supplies and chargers other than approved Emerson power supplies and battery packs could not only void the warranty, but will also most likely damage the analyzer or the battery pack.

• When charging the AMS 2140 with the battery pack or the battery pack by itself, ensure

the ambient temperature where charging is occurring is 50° F to 95° F (10° C to 35° C).

• Charge the battery pack only in a non-hazardous area.

Procedure

Remove the rubber plug on the top of the analyzer.

2. Insert the power supply connector into the analyzer. The analyzer can be powered on or off.

12 MHM-97432 Rev 10

3. Plug the AC connector on the power supply into a standard AC outlet, ranging from 100 VAC to 250 VAC, 50–60 Hz. A full recharge may take four hours.

The back of the analyzer may feel warm during charging. The power supply can remain connected to the analyzer after charging completes. You cannot overcharge the battery pack.

2.7.5 Battery LED indicates charging status

The Battery LED on the front of the analyzer shows the progress when charging the battery pack. The LED is located to the right of the Power key.

Color Battery pack status

Amber Charging

Green Fully charged

2.7.6 Remove or change the battery pack

Introduction to the analyzer

The analyzer gives you unlimited usage by changing the battery pack with a fully charged spare battery pack. When you change the battery pack, the data saved in the analyzer is not affected.

CAUTION!

Do not remove or change the battery pack with the power supply connected to the analyzer. Damage may occur to the analyzer or the battery pack.

WARNING!

• Use only Emerson’s battery packs with the AMS 2140. The analyzer will not function if a

non-Emerson battery pack is used.

• Remove or change the battery pack only in a non-hazardous area.

Procedure

Turn off the analyzer and remove the power supply, if connected.

2. Set the analyzer face down on a level surface.

3. Lift up the stand.

4. On the back of the analyzer, remove the six screws that attach the battery pack to the analyzer.

5. Carefully remove the battery pack from the battery compartment.

6. Insert the new battery pack and ensure it aligns with the contacts inside the battery compartment on the analyzer.

7. Insert and tighten the six screws on the back panel.

MHM-97432 Rev 10 13

Introduction to the analyzer

2.7.7 Battery pack maintenance

To prevent any significant loss of the battery capacity when storing the analyzer with the battery pack or storing the battery pack by itself for a prolonged period of time:

• Ensure the ambient temperature where the battery pack is located is -4° F to 95° F

• Disconnect the power supply from the AMS 2140 or the battery pack.

• When storing for 1–3 months, Emerson recommends removing the battery pack

from the AMS 2140.

• When storing the battery for longer than three months, contact Technical Support

Note

2.7.8 Conserve battery pack power

• Set timers to automatically put the analyzer in standby or turn off the backlight after

a set period of inactivity, such as not pressing any keys or not collecting data. You can also put the analyzer into standby mode by quickly pressing the power key.

• Set the LCD backlight intensity to Medium. If you use the High setting, Emerson

recommends setting the backlight timer to 30 seconds.

These options are available on the General Analyzer Setup screen. Press Home > ALT > F2 General Setup.

The analyzer uses several power modes, or states, to conserve battery pack power. Reference Table 2-1 when setting options on your analyzer that impact battery pack power.

14 MHM-97432 Rev 10

Introduction to the analyzer

Analyzer power mode, status indicator, and power consumptionTable 2-1:

Operation Performance

Real Time

Mode

Power save Blinks blue

Standby Solid blue

Off

Storage Off Charger plug Slowest Extremely low

Status LED Backlight Analyzer

Flashes with key press

Off Off

Off

Clock

Resume operation

Press key or touch screen

Press power button

Response time

Immediate

Fast Low

Slower Very low

Power Consumption

High

Reduced

2.8 External AMS 2140 Battery Charger

The external AMS 2140 Battery Charger lets you charge the battery pack separately from the analyzer. You can charge the battery pack indoors, or you can use the automobile power supply cord to charge the battery in your car. You can charge one battery pack at a time using the external AMS 2140 Battery Charger. A full recharge may take three hours.

To power the external AMS 2140 Battery Charger, insert the power supply cord into the connector on the back of the charger.

Power supply connector and air ventsFigure 2-6:

A. Power supply connector

Air vents

MHM-97432 Rev 10 15

Introduction to the analyzer

• To prevent overheating, ensure the air vents on the back and sides of the charger are

• To prevent damage to the charger and battery pack, do not charge a battery pack in an

• Use the external AMS 2140 Battery Charger only in a non-hazardous area.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

LEDs

WARNING!

clear when charging a battery pack. To ensure proper airflow, allow several inches of clearance around the charger and occasionally inspect the charger vents. Remove any foreign material, such as dust, that may have settled around the vents.

extremely hot or cold location, such as inside an automobile during summer or winter conditions. If the ambient temperature exceeds normal and safe operating limits of 50° F to 95° F (10° C to 35° C), charging stops. In most situations, charging automatically resumes when the ambient temperature is within normal and safe operating limits.

LEDs on the front of the chargerFigure 2-7:

A. Battery LED—Display a green light if the battery pack is fully charged, or an amber LED if the battery

pack is charging. AC Power—Display a green light if the charger is being powered.

2.8.1 Charge the battery pack using the external AMS 2140 Battery Charger

You can charge your battery pack separately from the analyzer. You can use the charger indoors, or you can use the automobile power supply cord to charge your analyzer in your car. You can charge one battery pack at a time. A full recharge may take 3 hours.

Note

If the battery pack is in storage mode, placing the battery pack on the charger will activate the battery pack.

16 MHM-97432 Rev 10

Introduction to the analyzer

WARNING!

• Use only Emerson-supplied power supplies and chargers approved for use with the AMS

• Ensure the air vents on the external AMS 2140 Battery Charger are clear and uncovered.

• When charging the AMS 2140 with the battery pack or the battery pack by itself, ensure

the ambient temperature where charging is occurring is 50° F to 95° F (10° C to 35° C).

• Charge the battery pack only in a non-hazardous area.

Prerequisites

Remove the battery pack from the analyzer. See Section 2.7.6.

Procedure

With the metal contacts on the battery pack facing up, lift the battery pack over the

raised edges and then slide the battery pack into the charger.

Battery pack inserted into the external AMS 2140 Battery ChargerFigure 2-8:

A. Raised edges B.

Battery pack

2. Insert the power supply cord into an outlet and into the connector on the back of

the external AMS 2140 Battery Charger.

Charging begins and the LED is amber. The battery pack is fully charged when the battery LED on the external AMS 2140 Battery Charger changes from amber to green. To check the progress, press the button on the battery pack next to the 5 LEDs. Each LED represents approximately 20 percent charge.

MHM-97432 Rev 10 17

Introduction to the analyzer

3. To remove the battery pack, lift up the battery pack to clear the two raised edges,

and then slide out the battery pack.

2.9 Turn the analyzer on or off

You can set the number of seconds to hold the power key to shut down the analyzer. See

Section 2.14.6.

Procedure

Press and hold the power key

The Home screen appears when you turn on the analyzer. If you were working in a program before shutting down, that program appears.

2.9.1 Hard reboot

Do a hard reboot only if the analyzer is unresponsive.

Procedure

Press and hold the power key for approximately 10 seconds until the analyzer shuts down.

2.9.2 Standby

Standby is similar to the standby mode on a computer. The analyzer is powered on, but the backlight is off to conserve battery power. You can use standby mode to lock the touchscreen and keys when you are carrying the analyzer. You can manually put the analyzer in standby, or you can wait for the standby timer. See Section 2.14.2. The standby timer also shuts off the keypad backlight.

Note

After 60 minutes in standby, the analyzer shuts down. You do not lose any data when this occurs.

to turn the analyzer on or off.

Procedure

To enter standby, quickly press (1 second) the power key , or wait for the standby timer to expire.

The LCD backlight and keypad backlight turn off. The blue LED on the analyzer’s front panel is lit.

To leave standby, quickly press the power key

18 MHM-97432 Rev 10

2.10 Home screen

The Home screen appears when you turn on the analyzer by pressing the power key.

Home screenFigure 2-9:

Introduction to the analyzer

A. An alternate screen (ALT) includes additional options.

Current time and date.

B. C. Bluetooth device connection status (headphones connection icon shown). D. Default splash screen. E. Remaining battery pack charge. F. Number of supported channels for the analyzer. G. Serial number. H. Group number for updating multiple analyzers at one site. I. Available internal memory.

Home screen programs and settings

The Home screen has two alternate screens that display programs and settings. ALT1 or ALT2 appears at the top of the screen and the function keys are outlined in yellow. To switch ALT screens, press the ALT key or the ALT text on the touchscreen.

ALT1 keys

Option Description

F1 Intentionally blank.

F2 File Utility Copy, delete, or move routes or jobs saved in the analyzer internal memory

or a memory card.

F3 Intentionally blank.

F4 Set Display Units Set the default display units for the measurement values and plots.

MHM-97432 Rev 10 19

Introduction to the analyzer

Option Description

F5 Comm Setup Set the communication options to connect the analyzer to AMS Machinery

F6 Program Manager Update the programs, add new programs, delete unused programs, or

F7 Analyze or Adv. Analyze

F8 Route Collect data using a route created in AMS Machinery Manager. You cannot

F9 Balance Balance a machine. Balance is an optional program that you load onto the

F10 Basic Laser Align or Adv. Laser Align

F11 Adv. Transient Collect large, unbroken time waveforms similar to a digital recorder.

F12 ODS/Modal Collect cross channel data for animated analysis of a machine. ODS/Modal is

Manager. You can also set up the Bluetooth functionality.

change the splash screen. A password is required to delete programs.

Collect data using predefined measurements called Analysis Experts, or create your own measurements in Manual Analyze.

create or modify routes on the analyzer.

analyzer.

Align machines. The Basic Laser Alignment Application comes with analyzers that have the wireless option. The Advanced Laser Alignment Application is an optional program that you can load onto the analyzer and has more functions than the Basic application.

Advanced Transient is an optional program that you load onto the analyzer.

an optional program that you load onto the analyzer.

ALT2 keys

Option Description

F1 Version View the versions of the firmware and programs installed on your analyzer.

F2 General Setup Modify settings for the analyzer screen, keys, and print functionality.

F3 Set Time Set the time and date in the analyzer.

F4 Memory Utility View information about the internal memory.

F5 Battery Utility View information about the battery pack.

F6 View Error Log View information about any errors the firmware generated.

F7 Connect For Printing

F8 Intentionally blank.

F9 Intentionally blank.

F10 Intentionally blank.

F11 Intentionally blank.

F12 Intentionally blank.

Connect to AMS Machinery Manager to print files or screen captures.

2.10.1 Return to the Home screen

Press the Home key on the front of the analyzer.

20 MHM-97432 Rev 10

2.11 Backlight

2.11.1 Set the LCD backlight

By default, the analyzer uses the Auto backlight mode to automatically adjust the backlight intensity based on the light in your environment. You can disable the automatic adjustments. You can set a timer to disable the backlight after a period of inactivity. See

Section 2.14.3.

Note

A higher backlight intensity decreases the battery pack life. For optimum battery pack life, set the backlight to the medium setting.

Change the backlight using the LCD backlight key or the General Setup menu on the Home screen.

Procedure

To set the backlight using the LCD backlight key setting.

Introduction to the analyzer

, press the key to select a

Each time you press the key, the backlight changes. The default is Auto.

To set the backlight from the Home screen:

a. Press Home > ALT > F2 General Setup > F8 Set Backlight.

b. Use the up and down arrow keys to select a setting.

c. Press Enter.

2.11.2 Set the keypad backlight

If your area has low light, turn on the keypad backlight to illuminate the analyzer’s keys.

Note

To comply with relevant safety certifications, the AMS 2140 labeled “ATEX/IECEx Zone 2” does not have a keypad backlight.

Procedure

Press the keypad backlight key to turn the light on or off.

2.12 Touchscreen

The touchscreen and function keys let you access the menu options and enter text. If the touchscreen does not respond accurately, calibrate the touchscreen.

MHM-97432 Rev 10 21

Introduction to the analyzer

WARNING!

Clean the touchscreen only in a non-hazardous area. An electrostatic discharge is possible when you clean the equipment exterior. Do not use any abrasive or corrosive chemicals or materials. Do not use petroleum distillates and ketone solvents, for example, acetone, gasoline and kerosene. Use a dry, lint-free towel or cloth dampened with a mild soap and water solution.

Note

To prevent permanent damage to the touchscreen, never use sharp objects or excessive pressure with your fingers or stylus. Lightly tap the screen.

2.12.1 Lock or unlock the touchscreen

You can lock the touchscreen and only use the keys on the front of the analyzer to select menus and options. Lock the screen to prevent inadvertently pressing buttons when you carry the analyzer. You can also put the analyzer in standby to lock the touchscreen.

Procedure

Press Home > ALT > F2 General Setup > F9 Set Touch Screen to lock or unlock the screen.

If you locked the touchscreen, you can still use the buttons on the side of the screen to select options.

2.12.2 Calibrate the touchscreen

Calibrate the touchscreen to respond to your touch. You can use your finger or a stylus. Calibrate if the touchscreen does not respond accurately.

Procedure

1. Press Home > ALT > F2 General Setup > F10 Calibrate Touch Screen.

2. Touch in the center of each crosshair.

3. Press Enter.

2.12.3 Gestures

You can use gestures rather than pressing the keys to select menu options. The gestures match the arrows on the corresponding analyzer keys. You can use gestures on all screens that support the corresponding keys.

Note

You cannot use gestures when the analyzer displays the onscreen keyboard, or when Log is used for the plot axis. The Enter gesture does not work on plots.

Tip

Use consistent pressure when you press in the middle of the touchscreen as indicated below.

22 MHM-97432 Rev 10

Introduction to the analyzer

Task Gesture

Activate a plot Touch the desired plot when the analyzer displays multiple

plots.

Add a cursor Touch anywhere on the plot.

Move a cursor Swipe left or right, or touch anywhere on the plot. On a

waveform, the cursor moves 20 percent of the waveform. On a spectrum, the cursor moves to the next highest peak. To clear a cursor, use the Clear Cursor option on the plot’s ALT screen.

Increase or decrease the plot amplitude

Use upper or lower case characters Swipe up or down.

Scroll items in a list Swipe up or down. This also applies to the options on the

Swipe up or down.

Note

You cannot use gestures for the onscreen keyboard.

Balance main menu.

Gestures

Enter Right arrow (swipe right)

Up arrow (swipe up) Left arrow (swipe left)

Down arrow (swipe down)

MHM-97432 Rev 10 23

Introduction to the analyzer

2.12.4 Onscreen keyboard

If the analyzer’s touchscreen is enabled/unlocked, the analyzer displays an onscreen keyboard when you need to enter alphanumeric or special characters. See Section 2.12.1 for more information on locking or unlocking the touchscreen.

Note

Gestures are not supported when the analyzer displays the onscreen keyboard.

Tap the desired letter or character on the screen. The selected character is highlighted yellow.

Examples of the onscreen keyboardFigure 2-10:

24 MHM-97432 Rev 10

Introduction to the analyzer

Option Description

Show Hidden Text View the characters you enter in the field. Tap the box to enable to disable this

feature. By default, the option is disabled and only the last character you entered is visible. This option appears only when you are prompted to enter a password.

CAPS Change the case to capital or lowercase letters. You can also press the up and

down arrow keys.

ALT Display the alternate characters for a key. You can also press the ALT key on the

analyzer.

BKSP Delete a character.

123& View the keyboard displaying numbers, special characters, and punctuation.

ABCD View the keyboard displaying alpha characters.

CLEAR Delete all characters.

Left and right arrows

ENTER Accept your edits and close the keyboard. You can also press the Enter key on

Move the cursor. You can also touch the screen to move the cursor.

the analyzer.

You can also enter accented or alternate characters. Press and hold a key, and then slide to select the appropriate character.

Example of entering an accented characterFigure 2-11:

MHM-97432 Rev 10 25

Introduction to the analyzer

2.13 Menu navigation

The analyzer has a touchscreen and function keys for navigating and selecting menu options. The menu options appear on the left and right sides of the screen and correspond to the function keys on the analyzer. When you press a key or an option on the touchscreen, a blue status LED flashes on the analyzer’s front panel.

To cancel or return to a previous screen, press the Back key. Press the Home key to return to the Home screen.

2.13.1 ALT screens

Each screen displays up to 12 menu options, but additional options may be available on alternate screens. ALT1 or ALT2 appears at the top of the screen and the function keys are outlined in yellow. To switch screens, press the ALT key or the ALT label on the screen.

2.13.2 Entering text

If a menu option lets you enter text, an onscreen keyboard appears or the analyzer lists a set of characters on the side of the screen. Tap the touchscreen or repeatedly press the key until the desired character appears. Wait until the cursor moves and then enter the next character. See Section 2.12.4 for more information about entering text using the keyboard.

Note

The onscreen keyboard appears only if the touchscreen is enabled/unlocked. By default, the touchscreen is enabled/unlocked.

2.13.3 Display Help

Use the Help key to access information about a menu option or key.

Procedure

Press the Help key .

Press a menu option.

The analyzer displays the Help text for that menu option.

3. Press Enter to close the Help text.

2.14 Settings

View and modify the default global settings from the Home ALT1 or ALT2 screens.

26 MHM-97432 Rev 10

Introduction to the analyzer

2.14.1 Enable or disable the beeper for key presses and status indicators

You can enable or disable the beeper for status indicators or key presses.

Procedure

Press Home > ALT > F2 General Setup.

2. Press F2 Set Keypad Beeper to enable or disable the sound when you press a key.

3. Press F3 Set Status Beeper to enable or disable sounds for alerts and status indicators.

4. Press Enter.

2.14.2 Set the standby timer

To conserve battery pack power, set the timer to automatically put the analyzer in standby after a period of inactivity, such as no data collection or key presses. Standby is similar to the standby mode on a computer. The analyzer is powered on, but the backlight is off to conserve battery power. The standby timer also shuts off the keypad backlight. The standby timer is disabled when the power supply is connected to and powers the analyzer. The blue LED displays on the front of the analyzer when the analyzer is in standby. To leave standby, quickly press the power key.

Note

After 60 minutes in standby, the analyzer shuts down. You do not lose any data when this occurs.

Procedure

Press Home > ALT > F2 General Setup > F4 Set Standby Time.

2. Enter the number of minutes between 1 and 30.

The default is 10 minutes.

3. Press Enter.

2.14.3 Set the backlight timer

To conserve battery pack power, set the timer to automatically turn off the backlight after a specified period of inactivity, such as no data collection or key presses. After the timer expires and the backlight is turned off, press a key or the screen to turn on the LCD backlight and reset the timer. The timer is disabled when the power supply is connected to and powers the analyzer.

In this power save mode, the LCD backlight is off and the blue LED blinks on the front of the analyzer.

Procedure

Press Home > ALT > F2 General Setup > F5 Set Backlight Time.

MHM-97432 Rev 10 27

Introduction to the analyzer

2. Enter the number of seconds between 0 and 120.

A 0 disables this feature. The default is 30 seconds.

Press Enter.

2.14.4 Enable or disable printing to AMS Machinery Manager or a memory card

You can enable or disable printing on the analyzer. When printing is enabled, you can send routes, jobs, and summary reports to AMS Machinery Manager or an inserted SD (Secure Digital) memory card. By default, the analyzer can send files to AMS Machinery Manager.

Procedure

1. Press Home > ALT > F2 General Setup > F6 Set Print Mode.

2. Use the up and down arrow keys to select an option.

Option Description

Send to PC Send files between the analyzer and AMS Machinery Manager. Files

can include routes, jobs, screen captures, splash screens, or summary reports. The default is Send to PC.

Store as BMP on CARD Save the file as a .bmp to the SD memory card.

Store as JPG on CARD Save the file as a .jpg to the SD memory card.

Print Off Disable printing. Print options, such as the F7 Connect For Printing

option on the Home ALT2 screen, are not available.

3. Press Enter.

2.14.5 Set the low-battery warning level

When the battery pack discharges to the specified percent, the analyzer displays a message telling you to recharge the battery pack.

Procedure

Press Home > ALT > F2 General Setup > ALT > F3 Set Warning Level.

2. Enter a percent between 0 and 99.

A 0 disables this feature. The default is 15 percent.

3. Press Enter.

28 MHM-97432 Rev 10

2.14.6 Configure the power key

You can set the number of seconds you must hold the power key to shut down the analyzer. This option does not change the hold time to put the analyzer in standby. Increase the number of seconds to prevent users from accidentally pressing the power key and shutting down the analyzer.

Procedure

Press Home > ALT > F2 General Setup > ALT > F4 Set Hold Time.

2. Enter a number between 1 and 5 seconds.

The default is 3 seconds.

3. Press Enter.

2.14.7 Set the time and date

The analyzer’s time must be within 15 minutes of the computer’s time for the analyzer and computer to communicate successfully. If there is a time conflict, the analyzer prompts you to automatically synchronize the analyzer with the computer’s time.

Introduction to the analyzer

Procedure

1. Press Home > ALT > F3 Set Time.

2. Set the following options.

Option Description

F2 Set Local Time Enter values for the time and date. Use the arrow keys to go to the

next value.

F5 Date Display Format Select the format used for the date.

F6 Time Display Format Select the 12 or 24 hour time format.

F9 Set Time Zone Select the time zone. If the time zone uses Daylight Savings Time, the

analyzer automatically adjusts the time and notifies you of the change.

3. Press Enter.

2.14.8 Set the default display units

You can set the default display units for measurements and plots. You can also select English, SI, or metric units, and the X and Y axis types for graphs.

Note

You can overwrite only the X and Y axes while in other programs.

MHM-97432 Rev 10 29

Introduction to the analyzer

Procedure

2. Use the up and down arrow keys to select an option.

Press Home > F4 Set Display Units.

Option Description

F2 Set Accel Set the acceleration type. Not applicable for the Balance program.

The default is RMS.

F3 Set Veloc Set the velocity units. Not applicable for the Balance program. The

default is Peak.

F4 Set Displace Set the displacement units. Not applicable for the Balance program.

The default is Peak to Peak.

F5 Set Non Standard Set the non-standard data types. Not applicable for the Balance

program. The default is RMS.

F6 Set Units Set to English Units, Metric Units, or SI Units. The default is English Units.

F8 Set dB Ref Configure acceleration, velocity, displacement, non-standard, and

microphone measurements displays for decibel reference. Enter a value between 0.000000001 and 2. Not applicable for the Balance or

Route programs. The dB reference values are loaded with the route.

F10 Change Y Axis Type

F11 Change X Axis Type

F12 Change Hz \ CPM Set the frequency to Hz Units (Hertz) or CPM Units (cycles per minute).

Set the amplitude axis type. Not applicable for the Balance program. The default is Linear.

Set the frequency axis type. Not applicable for the Balance program. The default is Linear.

The default is Hz Units.

3. Press Enter.

2.15 Memory card

You can insert a memory card into the analyzer to store route or job files. You may want to store some routes or jobs on specific cards to stay organized.

Note

For optimal performance, use a SD memory card with a speed class of 10 or higher. To verify the speed class of your memory card, refer to the label on the memory card or the documentation for the memory card.

The memory card slot is located under the battery pack on the back of the analyzer. You must remove the six screws to remove the battery pack and access the memory card slot.

You can use the File Utility to add, copy, move, or delete files from the inserted memory card.

30 MHM-97432 Rev 10

2.15.1 Insert or remove a memory card

WARNING!

• Insert or remove memory cards only when the analyzer is turned off.

• Remove the battery pack only in a non-hazardous area.

Procedure

Ensure the power supply is disconnected from the analyzer.

2. Remove the battery pack from the back of the analyzer. See Section 2.7.6.

3. To insert a memory card, press the memory card, with the metal contacts facing up,

into the memory card slot until it clicks.

Memory card partially inserted into the analyzerFigure 2-12:

Introduction to the analyzer

4. To remove the memory card, push the memory card into the memory card slot until

it clicks and releases.

2.16 Bluetooth

If your analyzer supports Bluetooth® communication, you can listen to live vibration signals from an accelerometer (with the audio not stored), use the Laser Alignment Application, and use an infrared thermometer. If your analyzer supports Bluetooth, a

MHM-97432 Rev 10 31

Introduction to the analyzer

Bluetooth LED is on the top of analyzer (not present on newer versions). See Section 2.3. If your analyzer does not support Bluetooth, the Bluetooth options in the Communication Setup, Route, and Analyze screens are unavailable.

To use Bluetooth receivers, headphones, laser fixtures, and thermometer, enable the Bluetooth radio in the analyzer and then pair and connect to the Bluetooth device. When the radio in the analyzer is enabled, a small Bluetooth icon appears in the upper corner of the screen. The radio remains on until you disable it.

Note

For Bluetooth receivers and headphones, you need an A2DP Bluetooth headphone, or an A2DP Bluetooth receiver and any headphone. You can use the Model 2130 A646 headphones with the Bluetooth functionality in the AMS 2140. You need the adapter cable from Emerson and an A2DP Bluetooth receiver available online or from an electronics store.

Note

For using a Bluetooth infrared thermometer, the TPI Model 377BT Infrared Thermometer and AMS 2140 firmware version 1.3.9.1 or newer is required. To enter temperature using the Bluetooth thermometer, see Section 6.9.11

To help ensure a good connection, make sure the Bluetooth device is charged and located within 30 feet of the analyzer. Also, follow the instructions from the manufacturer of your device. After you pair the device, the analyzer automatically tries to connect to the device.

To listen to data, open the Route or Analyze program and select the Listen To Live Data option after the connection is made.

2.16.1 Enable or disable the Bluetooth radio in the analyzer

If your analyzer is configured for Bluetooth, you can enable or disable the internal radio. After you enable the analyzer’s Bluetooth radio, the analyzer searches for nearby Bluetooth devices that you can pair. The radio remains on until you disable it.

Procedure

Press Home > F5 Comm Setup > F7 Bluetooth Setup.

2. Press F2 Bluetooth to enable or disable the Bluetooth radio.

When the radio is enabled, the

icon appears in the upper corner of the screen.

2.16.2 Bluetooth icons

When you enable the Bluetooth radio in your analyzer or connect to a device, the Bluetooth icon in the upper corner of the screen shows the status of the connection. See the table below for the icons and the descriptions.

32 MHM-97432 Rev 10

Icon Meaning

No icon The Bluetooth radio is disabled/off.

The Bluetooth radio in the analyzer is enabled/on, but the analyzer is not connected to a Bluetooth device.

The analyzer is connected to the Bluetooth laser fixtures.

The analyzer is connected to a Bluetooth temperature probe.

The analyzer is connected to a Bluetooth device.

The Bluetooth audio is distorted (clipping) because the signal exceeds the maximum capacity. (The top and bottom peaks of the signal are removed.) Adjust the signal gain or remove the signal.

2.16.3 Pair a Bluetooth device

Introduction to the analyzer

To establish communication between a Bluetooth device and the analyzer, you must first pair the device. Multiple devices can be paired at the same time.

Prerequisites

• Ensure your device is close to the analyzer (within 30 feet), and the device is in

discoverable mode.

• Ensure the Bluetooth radio in your analyzer is enabled. See Section 2.16.1.

Procedure

Press Home > F5 Comm Setup > F7 Bluetooth Setup.

2. If more than one device is listed, use the up and down arrow keys to select a

Bluetooth device.

3. (Optional) Press F8 Device Info to view information about the device, including

device alias (if you renamed the device), device name, supported protocols, status and device address.

4. Press F7 Pair to pair the selected device.

The analyzer automatically tries to pair and connect to the device using a pin of

0000. If the analyzer connects to the device, a checkmark and Connected appears next to the device. The F7 key changes to Unpair. If the analyzer cannot pair the device using the default pin, enter the pin for the device, and press Enter.

Postrequisites

To start listening to live vibration signal, go to the Route or Analyze programs and press the Listen To Live Data option after the analyzer connects to the paired device.

MHM-97432 Rev 10 33

Introduction to the analyzer

2.16.4 Connect to a paired Bluetooth device

If you have more than one paired Bluetooth device, you can select and connect to a desired device.

Prerequisites

Ensure your Bluetooth device has been paired. See Section 2.16.3.

Procedure

Press Home > F5 Comm Setup > F7 Bluetooth Setup.

2. Use the up and down arrow keys to select a paired device.

3. Press F9 Connect.

A checkmark and Connected appears next to the device name when the analyzer

connects to the device. The

Postrequisites

To start listening to live vibration signal, go to the Route or Analyze programs and press the Listen To Live Data option after the analyzer connects to the paired device .

icon appears in the upper corner of the screen.

2.16.5 Rename a paired Bluetooth device

After you pair a Bluetooth device, you can change the device name that appears on the Bluetooth Setup screen. If you unpair the device, the new name is removed from that device.

Procedure

1. Press Home > F5 Comm Setup > F7 Bluetooth Setup.

2. If more than one device is listed, use the up and down arrow keys to select a

Bluetooth device at the bottom of the screen.

3. Press F3 Rename Device and enter up to 16 characters to change the name of the

device.

4. Press Enter.

2.16.6 View information about a Bluetooth device

You can view the information and settings for a Bluetooth device. This can help identify a Bluetooth device.

Procedure

1. Press Home > F5 Comm Setup > F7 Bluetooth Setup.

2. Use the up and down arrow keys to select a device.

3. Press F8 Device Info.

34 MHM-97432 Rev 10

2.16.7 Unpair a Bluetooth device

If you previously paired a device, you can use the unpair option to remove the device information from the analyzer.

Procedure

Press Home > F5 Comm Setup > F7 Bluetooth Setup.

2. Use the up and down arrow keys to select a paired device.

3. Press F7 Unpair.

2.17 Utilities

2.17.1 File Utility

The File Utility on the Home screen lets you copy, delete, or move routes or jobs saved in the internal memory or memory card. By default, the File Utility shows the files saved in the internal memory. The Set Source Card and Mode keys are available only if you inserted a memory card into the analyzer.

Introduction to the analyzer

View all jobs saved in internal memory or a memory card from the File Utility. Use the up and down arrow keys to scroll through the list of file names.

View all files saved in the analyzer

1. Press Home > F2 File Utility.

2. Use the up and down arrow keys to scroll through the files.

3. To view the files on the memory card, press F10 Set Source Card.

File types and extensions

Note

The AMS 2140 uses different file extensions than the Model 2130.

File extension File type

.ANJ Analyze or Advanced Analyze job

.BJB Balance job

.ODJ ODS/Modal job

.RDA Route Data File (created after a route is activated)

.RDF Route Definition File (an empty route file)

.LJB Alignment job

.TRJ Transient job

MHM-97432 Rev 10 35

Introduction to the analyzer

Copy a route or job file to a memory card or internal memory

2. Press Home > F2 File Utility.

3. Press F8 Mode until F7 displays Copy.

4. Press F10 Set Source Card to select the location of the file to copy.

5. Select the file to copy, and press F9 Select/Unselect File.

6. Press F7 Copy.

Delete a route or job file from the memory card or internal memory

Insert a memory card into the analyzer.

The Source and Destination fields change.

A checkmark appears next to the file.

The file appears at the new location.

Note

Use caution with the Delete option. Deleted data cannot be recovered.

Procedure

Press Home > F2 File Utility.

2. Press F8 Mode until F7 displays Delete.

3. Press F10 Set Source Card to select the location of the file.

4. Select the file to delete, and press F9 Select/Unselect File.

A checkmark appears next to the file.

5. Press F7 Delete.

6. Press Enter to delete the file, or press Back to cancel.

Move a route or a job file to a memory card or internal memory

1. Insert a memory card into the analyzer.

2. Press Home > F2 File Utility.

3. Press F8 Mode until F7 displays Move.

4. Press F10 Set Source Card to select the location of the file to move.

The Source and Destination fields change.

5. Select the file to move, and press F9 Select/Unselect File.

36 MHM-97432 Rev 10

A checkmark appears next to the file.

Press F7 Move.

The file appears at the new location, and is deleted from the previous location.

2.17.2 Memory Utility

The Memory Utility on the Home ALT2 screen lets you control the internal memory. You can view detailed information about the internal memory, clean the memory, erase internal settings, and format disks.

CAUTION!

Use the Memory Utility features only when instructed by technical support. When used improperly, these options can delete important information.

View detailed information about the internal memory

Use this information to troubleshoot issues with the internal memory.

Introduction to the analyzer

Procedure

Press Home > ALT > F4 Memory Utility > F2 Detailed Info.

Defragment the internal memory

Defragment the internal memory to optimize memory storage. No data is deleted during this process.

Note

This operation may take several hours.

Procedure

Press Home > ALT > F4 Memory Utility > F3 Clean Disk.

Clear the internal settings

You can clear the internal settings of the analyzer that are stored in permanent memory. The default settings are loaded the next time you turn on the analyzer.

CAUTION!

Do this operation only if instructed by technical support.

Procedure

Press Home > ALT > F4 Memory Utility > F8 Erase PReg.

MHM-97432 Rev 10 37

Introduction to the analyzer

2. Press Enter.

Format the internal memory

Formatting the internal memory erases all data and programs in the analyzer. When the formatting is complete, the analyzer shuts down. The internal memory includes programs like Route, Analyze, and Balance. All routes, jobs, and data are erased.

Procedure

Press Home > ALT > F4 Memory Utility > F9 Format Disk.

2. Press Enter.

2.17.3 Battery Utility

The Battery Utility on the Home ALT2 screen lets you view detailed information about the battery pack, including the remaining charge and battery voltage.

View the battery status

1. Press Home > ALT > F5 Battery Utility.

The screen indicates if the analyzer is running on battery power or the power supply.

2. Press F3 Show Details for additional diagnostic information, if necessary.

The charge and voltage level decreases as the battery discharges.

Note

Approximate values are displayed and they should be used only as a guideline.

3. Press Enter.

Enter storage mode for long-term storage

When storing the battery for longer than three months, contact Technical Support to learn how to enter storage mode. Storage mode protects the battery during long term storage. In storage mode, the analyzer and battery are non-functional. The analyzer does not power on and the battery LEDs do not operate. Connect the charger to the unit to reactivate the battery.

2.18 Clean the analyzer

WARNING!

An electrostatic discharge is possible when cleaning the equipment exterior. Clean the analyzer only in a non-hazardous area.

38 MHM-97432 Rev 10

Introduction to the analyzer

To clean the exterior of the analyzer, use only a dry, lint-free towel or cloth dampened with a mild soap and water solution. Do not use any abrasive or corrosive chemicals or materials, or any petroleum distillates and ketone solvents (for example, acetone, gasoline and kerosene).

2.19 AMS 2140 Four-Channel Input Adapter

The AMS 2140 Four-Channel Input Adapter expands the capabilities of your AMS 2140 by enabling four inputs.

WARNING!

Use the AMS 2140 Four-Channel Input Adapter in non-hazardous areas only.

The AMS 2140 Four-Channel Input Adapter has two sides that display connectors for Volts and Accel. Each side has a connector labeled To AMS 2140. Use the appropriate Interface cable to connect the AMS 2140 Four-Channel Input Adapter to the AMS 2140. The Accel side has a 5-pin connector. The Volts side has an 8-pin connector.

Connect to the AMS 2140

Attach the AMS 2140 Four-Channel Input Adapter to the shoulder strap connectors on each side of the analyzer, and press the tabs until they click into place. To release the adapter, press the tabs on each side of the AMS 2140 Four-Channel Input Adapter. To attach the shoulder strap, use the connectors on the sides of the AMS 2140 Four-Channel Input Adapter.

Use the appropriate Interface cable to connect the AMS 2140 Four-Channel Input Adapter to the AMS 2140.

Side Required interface cable

Accel A40ADAPTR Accel Interface Cable

Volts A40ADAPTR Tach/Volts Interface Cable

MHM-97432 Rev 10 39

Introduction to the analyzer

Figure 2-13:

AMS 2140 Four-Channel Input Adapter attached to the AMS 2140 without the interface cable

Use with the AMS 2140

The AMS 2140 Four-Channel Input Adapter requires no additional setup, except in the Balance program. For the Balance program, you must enable the mux option to use the AMS 2140 Four-Channel Input Adapter.

To access the other connectors, turn the adapter over and connect to the AMS 2140 using the appropriate Interface cable.

2.20 Multiple inputs

Your analyzer may support up to four channels in each program to simultaneously collect data. To use the multi-channel functionality, set the number of inputs in the Input Setup menu in each program, set up a sensor for each input, and use a connection listed below. For routes, you need to set up the inputs and sensors in AMS Machinery Manager.

Number of inputs Connection options

1 Use a single cable.

2 • Use two single cables on two separate inputs (acceleration only).

• Use a splitter cable on one input.

• Use the AMS 2140 Four-Channel Input Adapter.

40 MHM-97432 Rev 10

Introduction to the analyzer

Number of inputs Connection options

3 • Use a splitter and one single cable on two separate inputs.

• Use the AMS 2140 Four-Channel Input Adapter.

• Use the triaxial accelerometer with a single cable.

4 • Use two splitters on two separate inputs.

• Use the AMS 2140 Four-Channel Input Adapter.

• Use the triaxial accelerometer with a single cable on one accelerometer

input and another cable on the other accelerometer input.

2.21 AMS 2140 for use in hazardous locations

Be aware of the appropriate approvals before operating the AMS 2140 in hazardous locations.

Each AMS 2140 has a label attached to the back of the unit that designates with approval markings the approved locations for use:

Label Approved locations

CSA General Safety Non-rated. Do not use in a hazardous location.

Class I Division 2 Approved for use in a Class I Division 2 hazardous location.

ATEX/IECEx Zone 2 Approved for use in an ATEX/IECEx Zone 2 and Class I Division

2 hazardous location.

Be aware of the following when using the AMS 2140 in a hazardous location:

WARNING!

• The USB port must only be used in a non-hazardous location.

• The Ethernet port must only be used in a non-hazardous location.

• Do not use the Emerson 430 SpeedVue Sensor in a hazardous location.

• The battery must only be charged and/or replaced in a non-hazardous location.

• If a unit shows any sign of damage, please return for repair.

• If leaving the device unattended outdoors, it is recommended to store the unit in a

shaded area or with the LCD facing down.

• The front touch screen must be protected from impact.

• Outputs are intrinsically safe when implemented per drawing D25671 for use in an

ATEX/IECEx Zone 2 hazardous environments.

• Outputs are intrinsically safe when implemented per drawing D25639 for use in a Class I

Division 2 hazardous environment.

MHM-97432 Rev 10 41

Introduction to the analyzer

Refer to Emerson Safety Addendum D25670 for complete information on certifications and conditions of safe use in ATEX/IECEx Zone 2 locations. Only ATEX/IECEx Zone 2 units will include this safety addendum in the package.

Notes

• To comply with relevant safety certifications, the AMS 2140 labeled “ATEX/IECEx Zone 2”

• Emerson 430 SpeedVue Sensor may not be compatible with the AMS 2140 labeled “ATEX/

does not have a keypad backlight.

IECEx Zone 2.” The Emerson 430 is not permitted in hazardous areas; and it may not function with the ATEX-certified AMS 2140 even in a safe area.

42 MHM-97432 Rev 10

Transfer files with AMS 2140

3 Transfer files with AMS 2140

Topics covered in this chapter:

• AMS Machinery Manager Data Transfer

• Standalone Data Transfer application

• Communication setup

• Routes and jobs

• Analyzer firmware and programs

• Screen captures

• Splash screens

• Printing

3.1 AMS Machinery Manager Data Transfer

AMS Machinery Manager Data Transfer lets you manage the files in your analyzer. You need Data Transfer to establish a connection between the AMS Machinery Manager database and the programs in your analyzer so you can transfer vibration data (routes) and job files. Data Transfer allows different levels of interactive functionality with your analyzer depending on the analyzer’s capabilities.

You can do the following:

• Transfer and store routes and jobs between the analyzer and AMS Machinery

Manager.

• Transfer and store routes and jobs between the analyzer and a folder on your

computer.

• Create route definition files and route data files that you can email to others.

• Take a screen capture of any screen in the analyzer.

• Print reports to AMS Machinery Manager.

• Upgrade the firmware or programs in your analyzer.

3.2 Standalone Data Transfer application

If your computer does not have AMS Machinery Manager installed, use the Standalone Data Transfer application to transfer route and job files between an analyzer and a folder on the computer or network. Standalone Data Transfer does not have a database, so all files are transferred to a computer folder. You can also print route reports or plots from the analyzer and transfer firmware or programs to the analyzer.

Standalone Data Transfer is available on your install disk that is included with your analyzer. Follow the prompts in the install wizard.

MHM-97432 Rev 10 43

Transfer files with AMS 2140

Standalone Data Transfer allows different levels of interactive functionality with your analyzer depending on the analyzer’s capabilities.

Analyzers using Ethernet may connect to the Data Transfer Service running on the AMS Machinery Manager server. Enter your AMS Machinery Manager user name and password to access the database list.

Transferring files

Standalone Data Transfer allows you to transfer a route to a file that can be sent to remote locations by email, for example, and then transferred into an analyzer or into the database. This type of file lets you send routes to and from analyzers at remote locations using Standalone Data Transfer instead of an AMS Machinery Manager Client.

To send a file to a remote user, create a route file using AMS Machinery Manager Data Transfer and email the file to the remote location. The remote user can use Standalone Data Transfer to load the file onto a connected analyzer.

To transfer a route or job into the AMS Machinery Manager database, use Standalone Data Transfer to load the file from the analyzer to a files on the computer. Then email the file to the AMS Machinery Manager user, or put the file on a network drive. If you email the file, put the file in the Working Directory to import the file.

Limitations

• You cannot install Standalone Data Transfer on the same computer as AMS

Machinery Manager.

• You cannot create route or job files. You can only transfer files.

• You cannot save files directly to the AMS Machinery Manager database.

3.3 Communication setup

3.3.1 Compatible versions of AMS Machinery Manager

You must use AMS Machinery Manager version 5.61 or newer with the AMS 2140. The analyzer uses a different format for routes, which is not compatible with previous versions of AMS Machinery Manager.

3.3.2 Change the ID of the analyzer

The ID helps you uniquely identify an analyzer. The ID also appears in AMS Machinery Manager Data Transfer when you connect to the analyzer.

Procedure

Press Home > F5 Comm Setup > F2 Change Device ID.

2. Enter up to 20 characters.

3. Press Enter.

4. Press Enter to return to the Home screen.

44 MHM-97432 Rev 10

3.3.3 Set the connection type on the analyzer

You can set the connection type for connecting the analyzer to AMS Machinery Manager. The default is USB. AMS Machinery Manager Data Transfer must have the same connection type selected before connecting to the analyzer.

Ethernet is the fastest connection type, followed by USB.

Note

Setting up the Ethernet or Wireless connections require detailed knowledge of the network. Contact your IT group for assistance.

Procedure

Press Home > F5 Comm Setup > F1 Set Connect Port.

2. Use the up and down arrow keys to select a connection type.

3. Press Enter.

4. If you selected Ethernet or Wireless, press F4 Ethernet Network Setup or F4 Wireless Network Setup and complete the steps below.

5. Press F3 to enable or disable DHCP.

6. If DHCP is disabled, do the following:

Transfer files with AMS 2140

a. Enter the IP address, and press Enter.

b. Enter the submask, and press Enter.

c. Enter the address for the gateway, and press Enter.

d. Press Enter.

7. Press F6 Set Host Info.

8. Enter the following information, if necessary.

Option Description

F4 Set Host Name

F5 Set IP Address

F6 Set Host Port Enter the TCP/IP port number to use to establish communication between

Enter the host name of your computer. This computer should be on your network and it should have AMS Machinery Manager installed. This value must match what is set in AMS Machinery Manager for the Setup Options.

If your network includes a DHCP server (DHCP enabled), enter the computer name. Otherwise, enter the IP Address of the computer. For additional text tools, press the ALT key and different set of characters appears.

Enter the IP address of the host computer.

the analyzer and the host computer. This value must match what is set in AMS Machinery Manager for the Setup Options. Use the default value (10077) unless otherwise directed by technical support.

9. To test the connection, select one of the following:

MHM-97432 Rev 10 45

Transfer files with AMS 2140

• F10 IP Config/all

• F11 Ping by IP

• F12 Ping by Name

10.

Press Enter to return to the Home screen.

3.3.4 Enable the analyzer in Data Transfer

1. Open and log in to AMS Machinery Manager.

2. Click the Data Transfer tab.

3. Click the Enable Device icon and select your analyzer type from the menu.

A device status box with an icon, name, and status appears in the Device(s) waiting for connection panel.

3.3.5 Set the connection type in Data Transfer

1. Enable the analyzer in Data Transfer.

2. In Devices waiting for connection pane, right-click the device status box to select Configure Device.

The analyzer options panel opens on the right side of the screen.

3. Select the connection type.

4. Click Apply.

3.3.6 USB connection

The analyzer can communicate with AMS Machinery Manager using a USB cable. The USB interface is the most common way to transfer files between the analyzer and the AMS Machinery Manager. USB is the default connection type.

To use a USB connection with AMS Machinery Manager, do the following:

• Set the connection type on the analyzer.

• Set the connection type in AMS Machinery Manager.

After you set up the connection, use the Connect For Transfer option in the analyzer's programs to connect to AMS Machinery Manager.

WARNING!

Do not use USB in a Hazardous Location.

46 MHM-97432 Rev 10

Transfer files with AMS 2140

Connect to AMS Machinery Manager using USB

Prerequisites

Ensure you set the connection type on the analyzer.

WARNING!

Do not use USB in a Hazardous Location.

Procedure

Connect the analyzer to the computer using the USB cable.

2. In AMS Machinery Manager, open Data Transfer.

3. Click the Enable Device menu and select your analyzer.

A device status box with an icon, name, and status appears in the workspace.

4. If more than one analyzer is enabled, click a device status box to select an analyzer.

5. Click the Options icon to expand the Options pane.

6. Set the connection type to USB on the analyzer and in Data Transfer.

7. On the analyzer, open a program and select Connect For Transfer using a path below. Choose the program that corresponds to the file type you want to transfer.

Program Key sequence to Connect for Transfer option

Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer

Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer

ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer

Program Manager Home > F6 Program Manager > F8 Connect For Transfer

Route Home > F8 Route > ALT > F9 Route Mgnt > F7 Connect For Transfer

Laser Alignment Home > F10 Adv. Laser Align > ALT > F9 Job Manager > F7 Connect For

Transfer

Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For Transfer

Both the analyzer and AMS Machinery Manager display a message indicating the connection was made. You can now transfer files between the opened program and AMS Machinery Manager.

MHM-97432 Rev 10 47

Transfer files with AMS 2140

3.3.7 Ethernet connection

The analyzer can communicate with AMS Machinery Manager using an Ethernet cable. To use an Ethernet connection with AMS Machinery Manager, do the following:

• Set the connection type on the analyzer and review the Ethernet settings in the F5

Comm Setup menu.

• Set the connection type in AMS Machinery Manager.

After the connection is setup, use the Connect For Transfer option in the analyzer’s programs.

WARNING!

Do not use Ethernet in a Hazardous Location.

Connect to a remote AMS Machinery Manager server

Remote users of the analyzer can use an Ethernet connection to the Data Transfer Service running on the AMS Machinery Manager server. When the analyzer connects to the Data Transfer Service, all communication is driven from the analyzer. Enter your AMS Machinery Manager user name and password to access the database list. For further information concerning the Data Transfer Service, please contact technical support.

Dynamic Host Configuration Protocol (DHCP)

DHCP is an Internet protocol that automates the configuration of computers that use TCP/IP. DHCP automatically assigns IP addresses to deliver TCP/IP stack configuration parameters, such as the subnet mask and default router. DHCP also provides other configuration information.

To use Ethernet with your analyzer, use DHCP or a static IP address. Check with your Information Technology department to see if DHCP is supported. If your workplace does not support DHCP, your Information Technology department needs to provide you a valid IP address, sub mask, and gateway.

Connect to AMS Machinery Manager using Ethernet

Your Ethernet settings depend on your local networks. You may need information and assistance from your IT department. Your computer must have two Ethernet connections. If it does not, use a router or a switch.

WARNING!

Do not use Ethernet in a Hazardous Location.

Prerequisites

Ensure you set the connection type on the analyzer.

48 MHM-97432 Rev 10

Transfer files with AMS 2140

Procedure

Connect the analyzer to the computer using the Ethernet cable.

2. In AMS Machinery Manager, open Data Transfer.

3. Click the Enable Device menu and select your analyzer.

A device status box with an icon, name, and status appears in the workspace.

4. If more than one analyzer is enabled, click a device status box to select an analyzer.

5. Click the Options icon to expand the Options pane.

6. Set the connection type to Ethernet/Wireless on the analyzer and in Data Transfer.

7. On the analyzer, open a program and select Connect For Transfer using a path below. Choose the program that corresponds to the file type you want to transfer.

Program Key sequence to Connect for Transfer option

Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer

Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer

ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer

Program Manager Home > F6 Program Manager > F8 Connect For Transfer

Route Home > F8 Route > ALT > F9 Route Mgnt > F7 Connect For Transfer

Laser Alignment Home > F10 Adv. Laser Align > ALT > F9 Job Manager > F7 Connect For

Transfer

Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For Transfer

Note

If you experience issues when trying to connect, press the F9 IP/release/renew option to reset the DHCP process.

Both the analyzer and AMS Machinery Manager display a message indicating the connection was made. You can now transfer files between the opened program and AMS Machinery Manager.

Connect to a remote AMS Machinery Manager database using Ethernet

Prerequisites

• Ensure you set the connection type on the analyzer.

• Ensure the Data Transfer Service is running on the AMS Machinery Manager server.

• Contact technical support to configure the analyzer to connect to the Data Transfer

Service.

MHM-97432 Rev 10 49

Transfer files with AMS 2140

Do not use Ethernet in a Hazardous Location.

Procedure

2. On the analyzer, open a program and select Connect For Transfer using a path below.

WARNING!

Connect the Ethernet cable to the analyzer and to an Ethernet switch or port.

Choose the program that corresponds to the file type you want to transfer.

Program Key sequence to Connect for Transfer option

Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer

Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer

ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer

Program Manager Home > F6 Program Manager > F8 Connect For Transfer

Route Home > F8 Route > ALT > F9 Route Mgnt > F7 Connect For Transfer

Laser Alignment Home > F10 Adv. Laser Align > ALT > F9 Job Manager > F7 Connect For

Transfer

Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For Transfer

3. Press Dump Data.

The password is case-sensitive, so use the up and down arrows to change the case.

Tip

Store your login. The next time you connect, press Recall Login and enter your four-digit pin. The analyzer displays your stored login information.

5. Enter your four-digit pin, and press Enter.

3.3.8 Wireless connection

If your analyzer supports wireless, you can use it to connect to AMS Machinery Manager Data Transfer to transfer files. If your analyzer supports wireless, a wireless LED is on the top of analyzer. See Section 2.3. To use the wireless functionality, you must enable the wireless radio in your analyzer and connect to a wireless network. After you connect to a wireless network, you can use wireless to connect the analyzer to an AMS Machinery Manager computer. You may need to work with your network administrator or IT group to set up a wireless connection.

Enable or disable the wireless radio in the analyzer

To connect to a wireless network, you must first enable the wireless radio in the analyzer.

50 MHM-97432 Rev 10

Transfer files with AMS 2140

Procedure

Press Home > F5 Comm Setup > F1 Set Connect Port.

2. Use the up and down arrow keys to select Wireless.

3. Press Enter.

When the radio is enabled, the wireless LED on the top of the analyzer turns on and the wireless icon appears in the upper corner of the screen.

Wireless network icons

The analyzer displays one of icons below when you work with a wireless network. The icon appears in the upper corner of the screen. Contact your IT department or see

View information about a wireless network to view the mode for your network.

Infrastructure (Standard) wireless network icon Meaning

The wireless radio is enabled/on, but the analyzer is not connected to a wireless network using Infrastructure (Standard) mode.

The analyzer is connected to a wireless network using Infrastructure (Standard) mode.

The wireless radio did not connect to a wireless network because the authentication/encryption failed. Review the wireless network setup and ensure the network settings are correct.

No icon The wireless radio is disabled/off.

Ad Hoc wireless network icon Meaning

The wireless radio is enabled/on, but the analyzer is not connected to wireless network using Ad hoc mode.

The analyzer is connected to a wireless network using Ad Hoc mode.

The wireless radio did not connect to a wireless network because the authentication/encryption failed. Review the wireless network setup and ensure the network settings are correct.

No icon The wireless radio is disabled/off.

Connect to a wireless network

Prerequisites

Ensure the wireless radio in the analyzer is enabled. See

Enable or disable the wireless radio in the analyzer.

MHM-97432 Rev 10 51

Transfer files with AMS 2140

Ensure your wireless network uses one of the security types below. If your wireless network has a different security type, the analyzer may not connect to your network.

• Open (no encryption/authentication)

• WEP

• WPA™—PSK

• WPA2™—PSK

• WPA™—Enterprise

• WPA2™—Enterprise

Procedure

2. Use the up and down arrow keys to select a wireless network, if more than one is

Press Home > F5 Comm Setup > F8 Wireless Setup.

The analyzer scans for available networks.

listed.

If the analyzer does not list your network, you may need to manually add the network. See Manually add a wireless network.

3. Press F7 Connect.

If you connect to a secure network, you are prompted to enter the appropriate network security credentials. A checkmark appears next to the network name when

the radio is communicating with the router. The wireless icon ( the upper corner of the screen when the analyzer connects to the network.

or ) appears in

Connect to AMS Machinery Manager using wireless

Prerequisites

Ensure the analyzer is connected to a wireless network. See Connect to a wireless network.

Procedure

1. In AMS Machinery Manager, open Data Transfer.

2. Click the Enable Device menu and select your analyzer.

A device status box with an icon, name, and status appears in the workspace.

3. If more than one analyzer is enabled, click a device status box to select an analyzer.

4. Click the Options icon to expand the Options pane.

5. Set the connection type to Ethernet/Wireless on the analyzer and in Data Transfer.

6. On the analyzer, press Home > F5 Comm Setup > F6 Set Host Info.

7. Enter the following information, if necessary.

52 MHM-97432 Rev 10

Transfer files with AMS 2140

Option Description

F4 Set Host Name

F5 Set IP Address

F6 Set Host Port Enter the TCP/IP port number to use to establish communication between

Enter the IP address of the host computer.

the analyzer and the host computer. This value must match what is set in AMS Machinery Manager for the Setup Options. Use the default value (10077) unless otherwise directed by technical support.

8. Press Enter.

On the analyzer, open a program and select Connect For Transfer using a path below. Choose the program that corresponds to the file type you want to transfer.

Program Key sequence to Connect for Transfer option

Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer

Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer

ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer

Program Manager Home > F6 Program Manager > F8 Connect For Transfer

Route Home > F8 Route > ALT > F9 Route Mgnt > F7 Connect For Transfer

Laser Alignment Home > F10 Adv. Laser Align > ALT > F9 Job Manager > F7 Connect For

Transfer

Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For Transfer

Note

If you experience issues when trying to connect, press the F9 IP/release/renew option to reset the DHCP process.

Both the analyzer and AMS Machinery Manager display a message indicating the connection was made. You can now transfer files between the opened program and AMS Machinery Manager.

Manually add a wireless network

You can manually set up a wireless network in the analyzer without being in range of the wireless signal. You can then connect to the network when your analyzer is within range. You may also need to manually set up a network if your analyzer does not see the network.

MHM-97432 Rev 10 53

Transfer files with AMS 2140

Prerequisites

Ensure the wireless radio in the analyzer is enabled.

Procedure

2. Enter the following information.

Press Home > F5 Comm Setup > F8 Wireless Setup > F9 Manage Networks > F1 Add Network.

Option Description

F2 Network Name (SSID)

F3 Infrastructure Mode

F4 Security Select the type of security used for the wireless network. Select Open if

F5 Encryption Type Select the type of encryption mode. This option is available only if you

F6 Security Key Enter the security key (passphrase) for the wireless network. This option

F12 802.1X Auth Enable or disable 802.1X authentication for the wireless network. When

Enter the name of the wireless network that you want to add.

Select Ad Hoc to connect the analyzer to the computer directly through a peer-to-peer wireless connection through each device’s wireless adapter. Select Infrastructure (Standard) to connect to the computer through a standard network with a wireless router or access point.

no authentication is required.

select WPA™-PSK or WPA2™-PSK for the Security option.

is available only if you select WPA™-PSK, WEP (Open), or WPA2™-PSK for the Security option.

802.1X Auth is enabled, you must enter a username, password, and domain when you connect to the network. Depending on your network security settings, the analyzer may automatically enable or disable this option. For example, WPA-PSK networks have 802.1X Auth disabled, while WPA-Enterprise and WPA2-Enterprise networks have 802.1X Auth enabled.

Note

The analyzer supports the Protected EAP (PEAP) protocol.

3. Press Enter.

Depending on your network, you may be prompted to enter your user name, password, and domain information. If the Wireless Authentication screen appears, enter your information and then press Enter. The wireless network appears on the Manage Networks screen.

Edit a wireless network

If your network configuration or security settings change, you can edit the settings in the analyzer. You can also edit the network connection settings. See Section 3.3.3.

54 MHM-97432 Rev 10

Procedure

Press Home > F5 Comm Setup > F8 Wireless Setup > F9 Manage Networks.

2. Use the up and down arrows to select a network.

3. Press F2 Edit Network.

4. Enter the following information.

Option Description

F2 Network Name (SSID)

F3 Infrastructure Mode

F4 Security Select the type of security used for the wireless network. Select Open if

F5 Encryption Type Select the type of encryption mode. This option is available only if you

F6 Security Key Enter the security key (passphrase) for the wireless network. This option

F12 802.1X Auth Enable or disable 802.1X authentication for the wireless network. When

Enter the name of the wireless network.

Select Ad Hoc to connect the analyzer to the computer directly through a peer-to-peer wireless connection through each device's wireless adapter. Select Infrastructure (Standard) to connect to the computer through a standard network with a wireless router or access point.

no authentication is required.

select WPA™-PSK or WPA2™-PSK for the Security option.

is available only if you select WPA™-PSK, WEP (Open), or WPA2™-PSK for the Security option.

Transfer files with AMS 2140

Note

The analyzer supports the Protected EAP (PEAP) protocol.

5. Press Enter.

Remove a wireless network

You can remove a wireless network from the list of networks in the analyzer. If the analyzer is connected to the network, the analyzer disconnects from the network when you press the Remove Network option.

Procedure

Press Home > F5 Comm Setup > F8 Wireless Setup > F9 Manage Networks.

2. Use the up and down arrow keys to select the wireless network you want to remove.

3. Press F3 Remove Network.

4. Press Enter.

MHM-97432 Rev 10 55

Transfer files with AMS 2140

The network is removed from the list of networks in your analyzer.

View information about a wireless network

You can view the settings and information about a wireless network.

Procedure

Press Home > F5 Comm Setup > F8 Wireless Setup.

The analyzer scans for available networks.

2. Use the up and down arrow keys to select a wireless network, if more than one is listed.

3. Press F8 Network Info.

3.4 Routes and jobs

3.4.1 Load a route from AMS Machinery Manager into the analyzer

Prerequisites

Ensure the same connection type is set on the analyzer and in Data Transfer. The Ethernet and Wireless options may require additional setup to connect to the desired computer. See the Ethernet and Wireless sections and your IT group for more information.

Note

You can connect multiple analyzers to AMS Machinery Manager at one time. Each analyzer has a tab on the Data Transfer tab labeled with its ID or name.

Procedure

Use the appropriate cable to connect your analyzer to a computer where AMS Machinery Manager is installed, if you are using a wired connection.

2. In AMS Machinery Manager, open Data Transfer.

3. On the analyzer, press Home > F8 Route > ALT > F9 Route Mgnt.

The Route Management screen displays.

Note

If you have not loaded or activated a route, the Route Management screen opens when you press F8 Route from the analyzer Home screen.

4. Press F7 Connect For Transfer.

56 MHM-97432 Rev 10

Transfer files with AMS 2140

The analyzer connects to AMS Machinery Manager, and a new tab with the analyzer Device ID displays in the Data Transfer tab.

To load a route using AMS Machinery Manager:

a. Select the appropriate database in the Navigator—Data Transfer pane.

b. Drag and drop or copy and paste the desired route to the connected analyzer in

the Data Transfer tab.

The Data Transfer Notification pane displays the progress of the transfer.

6. To load a route using the analyzer:

a. Press F1 Set Storage Location to select internal memory or a SD memory card to

store the route.

b. Press F7 Load Routes.

c. Press F8 or F9 to select a database.

d. Press F10 or F11 to select an area within the database.

e. Press F4 Select Area.

f. Press F8 or F9 to select a route and press F1 Select.

You can select multiple routes.

g. Press F7 Load Route.

If the route is already in the analyzer, an error message appears. Press Enter to continue and overwrite the existing route. You will lose any data stored in the existing route.

7. After the transfer completes, press the Back key to disconnect from AMS Machinery

Manager.

3.4.2 Load multiple routes from AMS Machinery Manager to the analyzer

Load a Multiple Route Load (MRL) file containing multiple routes from an AMS Machinery Manager database. MRL files help you efficiently load multiple routes at one time. Create an MRL file in AMS Machinery Manager.

After you load the routes, the analyzer does not group them using the MRL file. The routes are individual files that you individually transfer back to AMS Machinery Manager after you collect data.

Note

AMS Standalone Data Transfer cannot transfer MRL files.

MHM-97432 Rev 10 57

Transfer files with AMS 2140

Prerequisites

Procedure

2. In AMS Machinery Manager, open Data Transfer.

3. On the analyzer, press Home > F8 Route > ALT > F9 Route Mgnt.

4. Press F7 Connect For Transfer.

Use the appropriate cable to connect your analyzer to a computer where AMS Machinery Manager is installed, if you are using a wired connection.

The Route Management screen displays.

Note

If you have not loaded or activated a route, the Route Management screen opens when you press F8 Route from the analyzer Home screen.

The analyzer connects to AMS Machinery Manager, and a new tab displays the analyzer ID.

To load an MRL using AMS Machinery Manager:

Click the File Transfer

On the File Transfer pane at the bottom of the screen, click the Multiple Route Load

icon.

tab.

c. Drag and drop or copy and paste the desired MRL file to the connected analyzer

in the Data Transfer tab.

The download begins.

6. To load an MRL using the analyzer:

a. Press F1 Set Storage Location to select internal memory or a SD memory card.

b. Press F7 Load Routes.

c. Press F8 or F9 to select MRL File List.

d. Press F10 or F11 to select an MRL file.

e. Press F4 Select MRL File.

The download begins.

7. After the download completes, press Back to disconnect from AMS Machinery

Manager.

58 MHM-97432 Rev 10

Transfer files with AMS 2140

3.4.3 Load a Balance job from AMS Machinery Manager into the analyzer

Prerequisites

Procedure

Use the appropriate cable to connect your analyzer to a computer where AMS

Machinery Manager is installed, if you are using a wired connection.

2. In AMS Machinery Manager, open Data Transfer.

3. On the analyzer, press Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer.

The analyzer connects to AMS Machinery Manager.

4. To load a job using AMS Machinery Manager:

a. Select the appropriate database in the Navigation—Data Transfer pane.

b. Drag and drop or copy and paste the desired job to the connected analyzer in the

Data Transfer tab.

The Data Transfer Notification pane displays the progress of the transfer.

5. To load a job using the analyzer:

a. Press F1 Set Storage Location to select internal memory or a SD memory card.

b. Press F7 Load Jobs.

c. Press F8 or F9 to select a database.

d. Press F10 or F11 to select an area within the database.

e. Press F4 Select Area.

f. Press F8 or F9 to select a job and press F1 Select.

g. Press F7 Load Jobs.

6. After the transfer completes, press the Back key to return to the Job Manager

screen.

3.4.4 Dump a job from the analyzer to AMS Machinery Manager

You can transfer jobs created in the analyzer’s programs to the AMS Machinery Manager database.

MHM-97432 Rev 10 59

Transfer files with AMS 2140

Prerequisites

Procedure

2. In AMS Machinery Manager, open Data Transfer.

3. On the analyzer, press the Connect For Transfer option in the program for the desired

Use the appropriate cable to connect your analyzer to a computer where AMS Machinery Manager is installed, if you are using a wired connection.

job.

Program Key sequence to Connect for Transfer option

Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer

Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer

ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer

Laser Alignment Home > F10 Adv. Laser Align > ALT > F9 Job Manager > F7 Connect For

Transfer

Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For Transfer

The analyzer connects to AMS Machinery Manager.

To transfer the job using AMS Machinery Manager:

a. Select the appropriate database in the Navigation—Data Transfer pane.

b. Drag and drop or copy and paste the desired job to the database in the Data

Transfer tab.

The Data Transfer Notification pane displays the progress of the transfer.

5. To transfer the job using the analyzer:

a. Press F8 Dump Data.

The analyzer lists the default database at the top of the screen.

b. Select one or more jobs you want to transfer, and press F1 Select.

c. To send the jobs to a different database, press F6 Clear Database Info.

d. Press F7 Begin Data Dump.

e. If prompted, select a database and an area in the database, and press F4 Select

Area.

f. If prompted, select the desired equipment, and press F7 Select.

6. After the transfer completes, press the Back key to disconnect from AMS Machinery

Manager and return to the program’s Job Manager or ALT2 screen.

60 MHM-97432 Rev 10

Transfer files with AMS 2140

3.4.5 Dump a route from the analyzer to AMS Machinery Manager

Unless you specify a different database, the analyzer transfers the route back to the same database, area, equipment, and measurement.

Prerequisites

Procedure

Use the appropriate cable to connect your analyzer to a computer where AMS

Machinery Manager is installed, if you are using a wired connection.

2. In AMS Machinery Manager, open Data Transfer.

3. On the analyzer, press Home > F8 Route > ALT > F9 Route Mgnt > F7 Connect For Transfer.

The analyzer connects to AMS Machinery Manager.

4. To transfer a route using AMS Machinery Manager:

a. Select the appropriate database in the Navigator—Data Transfer pane.

b. Drag and drop or copy and paste the desired route to the database in the Data

Transfer tab.

The Data Transfer Notification pane displays the progress of the transfer.

5. To transfer a route using the analyzer:

a. Press F8 Dump Data.

The analyzer lists the default database at the top of the screen.

b. Select the routes to transfer and press F1 Select.

c. To send the routes to a different database, press F6 Force Into Database, and select

a new database.

d. Press F7 Begin Data Dump.

6. After the transfer completes, press the Back key to disconnect from AMS Machinery

Manager and return to the Route Management screen.

3.4.6 Dump a route or job from the analyzer to a folder on a computer

Transfer a file to a folder on your computer using AMS Machinery Manager.

MHM-97432 Rev 10 61

Transfer files with AMS 2140

Prerequisites

Procedure

2. In AMS Machinery Manager, open Data Transfer.

3. In AMS Machinery Manager, click the File Transfer icon.

4. Click the Analyzer Files tab.

5. Click the Working Directory link, and select a folder on the computer to store the file.

6. Click OK.

7. On the analyzer, open a program and select Connect For Transfer using the path

Use the appropriate cable to connect your analyzer to a computer where AMS Machinery Manager is installed, if you are using a wired connection.

The File Transfer pane appears at the bottom of the screen.

below. Select the program based on the type of route or job you want to transfer.

Program Key sequence to Connect for Transfer option

Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer

Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer

ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer

Route Home > F8 Route > ALT > F9 Route Mgnt > F7 Connect For Transfer

Laser Alignment Home > F10 Adv. Laser Align > ALT > F9 Job Manager > F7 Connect For

Transfer

Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For Transfer

The analyzer connects to AMS Machinery Manager.

On the computer, copy and paste or drag and drop one or more files from the top pane displaying the analyzer files to the File Transfer pane at the bottom of the screen.

The file appears in the File Transfer pane and is saved to the folder.

3.5 Analyzer firmware and programs

3.5.1 View the version numbers of the installed firmware and programs

View the versions to identify when you can upgrade the firmware or programs.

62 MHM-97432 Rev 10

Procedure

Press Home > ALT > F1 Version.

2. Review the File Name and File Version columns.

File name Program

XShell.exe Firmware and main menu

Analyze2140.exe Analyze and Advanced Analyze

Balance2140.exe Balance

Route2140.exe Route

Alignment2140.exe Basic or Advanced Laser Alignment

Transient2140.exe Transient

ODSModal2140.exe ODS/Modal

3. Press Enter.

Transfer files with AMS 2140

3.5.2 Upgrade the firmware in the analyzer

Note

Updates to the analyzer programs are not included in the firmware upgrade. You must update the programs separately from the firmware. Call technical support to see if any updates are available.

Prerequisites

Ensure the same connection type is set on the analyzer and in Data Transfer.

Procedure

Copy the new firmware to a folder on your computer.

2. Connect the analyzer to the computer using the USB cable.

3. In AMS Machinery Manager, open Data Transfer.

4. In the Options pane, set the Key Table and Firmware fields to the firmware folder

you created in step 1.

a. In the Key Table field, browse through the folder containing the key table.

b. In the Firmware field, browse through the folder containing the firmware.

c. Click Apply.

5. Turn off the analyzer.

6. Press and hold the Home key and then quickly press the Power key on the analyzer.

The AMS Special Functions Menu appears.

7. Press F2 Update Device Firmware via the USB Port.

MHM-97432 Rev 10 63

Transfer files with AMS 2140

The firmware upgrade begins. Follow the prompts. If the analyzer does not make the connection, turn off the analyzer and go back to step 1.

3.5.3 Add or upgrade the programs in the analyzer

You can add or upgrade multiple programs at one time.

Prerequisites

• Ensure the same connection type is set on the analyzer and in Data Transfer. The

Ethernet and Wireless options may require additional setup to connect to the desired computer. See the Ethernet and Wireless sections and your IT group for more information.

• Update the firmware, if an update is available. You may see an error message if you

try to update or add programs before the firmware is updated.

Procedure

Copy the new programs to a folder on your computer.

2. Use the appropriate cable to connect your analyzer to a computer where AMS

Machinery Manager is installed, if you are using a wired connection.

3. In AMS Machinery Manager, open Data Transfer.

4. In the Options pane, set the Key Table and Firmware fields to the firmware folder

you created in step 1.

a. In the Key Table field, browse through the folder containing the key table.

b. In the Firmware field, browse through the folder containing the firmware.

c. Click Apply.

5. On the analyzer, press Home > F6 Program Manager > F8 Connect For Transfer.

The analyzer displays a message indicating Host Computer Connected and lists the options under the Programs Available for Download section.

Note

If the following message appears, you must update your firmware before continuing: “The host computer has a newer version of the base firmware. You should follow the procedure in your user manual for loading new base firmware before you load any new programs.” The analyzer will not open any programs until you update the firmware. The analyzer may prompt you to update the firmware after you load or update the programs.

6. Press F11 Program or F12 Program or use the up and down arrow keys to highlight a

program, and press F10 Select/Unselect Program to select a program.

Press F9 Start Download.

Wait until all programs in the analyzer are up to date. The download typically takes a few minutes.

8. Press Enter or Reset.

64 MHM-97432 Rev 10

Postrequisites

View the version number for the firmware and programs to ensure the updates were successful.

3.6 Screen captures

3.6.1 Take a screen capture

Prerequisites

• On the analyzer, press Home > ALT > F2 General Setup > F6 Set Print Mode and ensure the

default print mode is set to Send to PC.

• Ensure the same connection type is set on the analyzer and in Data Transfer. The

Ethernet and Wireless options may require additional setup to connect to the desired computer. See the Ethernet and Wireless sections and your IT group for more information.

Procedure

Transfer files with AMS 2140

Use the appropriate cable to connect your analyzer to a computer where AMS Machinery Manager is installed, if you are using a wired connection.

2. In AMS Machinery Manager, open Data Transfer.

3. On the analyzer, press Home > ALT > F7 Connect For Printing.

AMS Machinery Manager connects to the analyzer.

4. Go to the desired screen on the analyzer.

5. In AMS Machinery Manager, click Capture from the toolbar.

Capture buttonFigure 3-1:

6. Save the screen capture when it appears on your screen.

MHM-97432 Rev 10 65

Transfer files with AMS 2140

3.7 Splash screens

3.7.1 Change the default Home screen image (splash screen)

You can change the image (splash screen) on the Home screen to another image, such as your company’s logo.

Prerequisites

• Ensure the same connection type is set on the analyzer and in Data Transfer. The

Ethernet and Wireless options may require additional setup to connect to the desired computer. See the Ethernet and Wireless sections and your IT group for more information.

• Save the image as splash.bmp and with 430 (width) x 380 (height) pixels.

• Save the file to a folder on your PC.

• Limit the color palette for the image to the 256 color (8-bit) palette.

Procedure

Use the appropriate cable to connect your analyzer to a computer where AMS

Machinery Manager is installed, if you are using a wired connection.

2. In AMS Machinery Manager, open Data Transfer.

3. In Data Transfer, click the Options icon and set the Firmware field to the folder

containing the new image.

4. On the analyzer, press Home > F6 Program Manager > F8 Connect For Transfer > F2 Load

New Splash Screen.

5. Press Enter.

3.7.2 Delete the Home screen image (splash screen)

If you added a custom image to the Home screen, you can delete it and return to the default image.

Procedure

Press Home > F6 Program Manager > F2 Delete Splash Screen.

The analyzer deletes the splash screen.

2. Press Enter.

66 MHM-97432 Rev 10

Transfer files with AMS 2140

3.8 Printing

3.8.1 Create a cover page in Device Offline Printing

Prerequisites

Disconnect the analyzer from AMS Machinery Manager.

Procedure

In AMS Machinery Manager, select File > Device Offline Printing.

2. Select Destination > Include Cover Page > New.

The Cover Page Editor dialog appears.

3. To remove a field, select Field and choose the field to remove.

The Report Date and Report fields cannot be removed.

4. To change the image, select Image > Change.

5. To save the cover page, select Save and specify a name and location for the file.

The file is saved with a .CPF file extension.

Postrequisites

Select Destination > Include Cover Page > Existing to select a cover page you have already saved.

3.8.2 Print a plot

Prerequisites

• On the analyzer, press Home > ALT > F2 General Setup > F6 Set Print Mode and ensure the

default print mode is set to Send to PC.

• Ensure the same connection type is set on the analyzer and in Data Transfer. The

Ethernet and Wireless options may require additional setup to connect to the desired computer. See the Ethernet and Wireless sections and your IT group for more information.

Procedure

Use the appropriate cable to connect your analyzer to a computer where AMS Machinery Manager is installed, if you are using a wired connection.

2. In AMS Machinery Manager, open Data Transfer.

3. On the analyzer, display the plot.

4. Press F7 Print Plot.

The analyzer connects to AMS Machinery Manager. The plot is displayed.

5. Click the print icon in the AMS Machinery Manager toolbar to send the plot to the

printer.

MHM-97432 Rev 10 67

Transfer files with AMS 2140

68 MHM-97432 Rev 10
