TIC 300 PRO
High Energy Tic Tracer –
Non Contact
AC Voltage Detector
User Manual
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
TIC 300 PRO
High Energy Tic Tracer –
Non Contact
AC Voltage Detector
User Manual
10/2019, Rev006
©2019 Amprobe.
All rights reserved. Printed in China
English
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
TIC 300 PRO
1) Voltage sensor
2) ON/OFF Button
3) Circuit TEST button
4) HIGH range switch
5) HIGH range LED
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
6) LOW range switch
7) LOW range LED
8) Battery compartment
9) HOT STICK attachment point
10)
Detection Blue LED indicators
CONTENTS
SYMBOLS .......................................................................... 2
UNPACKING AND INSPECTION .......................................3
INTRODUCTION ................................................................ 4
Features ........................................................................ 4
OPERATION .......................................................................5
ON/OFF Button ............................................................. 5
TEST Button .................................................................. 5
Voltage Detection ........................................................6
LOW Range ...................................................................6
HIGH Range .................................................................. 6
Locate breaks in insulated wire & heating elements
Check Outlets and Switches ........................................8
MAINTENANCE AND REPAIR ..........................................9
Cleaning ........................................................................9
Battery Replacement ...................................................9
SPECIFICATIONS ...............................................................10
Sensitivity: LOW Voltage .............................................11
Sensitivity: HIGH Voltage .............................................11
...... 7
1
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
SYMBOLS
MSHA
United States Department of Labor
Mine Safety and Health Administration
�
Refer to the manual
X
Caution Dangerous Voltage
Double insulated
T
In compliance with the United States
Department Of Labor Mine Safety and Health
Administration
Conforms to relevant Australian standards.
Conforms to relevant South Korean EMC standards.
Do not dispose of this product as unsorted
=
municipal waste.
For Use By Trained Personnel Only
Anyone using this instrument should be knowledgeable
and trained about the risks involved with measuring
medium and high voltage, especially in an industrial
setting, and the importance of taking safety precautions
and of testing the instrument before and after using it
to ensure that it is in good working condition.
�
WARNING and PRECAUTIONS
• Use extreme caution when testing live electrical
circuits due to risk of injury from electrical shock.
• Do not exceed the maximum overload limits
(see specifications) or the limits marked on the
instrument itself. Never test voltage more than
122 kV AC RMS.
• When using the HIGH range, the TIC 410A HOT
STICK or equivalent extension pole MUST be used.
• Comply with local and national safety
requirements.
• Use proper protective equipment as required by
local and national authorities.
2
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
• Observe the proper safety precautions when
working with voltages above 33 VAC RMS to avoid
electrical shock hazard.
• Before and after hazardous voltage measurements,
test the TIC 300 PRO by pressing the TEST button
and/or on a known source such as line voltage to
determine proper operation.
• Never ground yourself when taking measurements.
Do not touch exposed circuit elements.
• Do not operate the instrument in an explosive
atmosphere.
• Do not expose this product to rain or moisture. This
increases the risk of fire or electric shock.
•
Do not rely on the TIC 300 PRO for testing shielded wire.
• Do not let the unit make contact with a live line
with voltage higher than 20 kV.
• Three phase feeder cables with conductors close to
each other may self-cancel the electric field and
will not be detected by the TIC 300 PRO tracer.
Verify that the phase conductors are separated
by at least 15 in (38.1 cm) before testing for AC
voltage.
UNPACKING AND INSPECTION
Your shipping carton should include:
1 TIC 300 PRO
1 9 V Alkaline Battery
1 User Manual
1 Carrying Case
If any of the items are damaged or missing, return the
complete package to the place of purchase for an exchange.
3
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
INTRODUCTION
The TIC 300 PRO safely checks for the presence of AC
voltage without making any disconnection in cables,
wall sockets, fuses, circuit breakers, junction boxes, etc.
No current flow is needed for correct operation.
Rugged and reliable for utility, industrial and mine safety
applications, the TIC 300 PRO warns against dangerous
voltages in low and medium voltage applications up to
122 KV without contacting the energized conductor.
Features
• Utility tool for checking transmission lines, power
distribution equipment, down power lines, fuses,
and load break connectors
• Lower voltage setting for checking voltage
presence in breaker panels, breakers, power
outlets and wiring
• Verifies presence of voltage from 30 VAC to
122,000 VAC (122 kV)
• Non-contact AC voltage detection
• Visual and audible voltage indication
Self-test for verifying that the tester is working properly
•
• Ergonomic design with a convenient handle
• Drop proof up to 6 ft (1.83 m)
Use with the Hot Stick 410A when voltage exceeds 1500 V
4
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
OPERATION
ON/OFF Button
When the TIC 300 PRO is activated, the blue LEDs and
beeper will pulse at a slow rate about twice a second.
The red LED of the range (HIGH) will turn ON.
TEST Button
The TEST button should be used prior to testing actual
power circuits. The TEST function will cause the blue
LEDs and beeper of the range selected (LOW or HIGH) to
pulse at a fast rate.
OSHA listed clearance distances for working with
voltage. National or local requirements may be
different.
Line voltage (kV) Phase to ground Phase to phase
phase to phase (ft-in) (m) (ft-in) (m)
0.03 to 1.0 Note1 Note1 Note1 Note1
1.1 to 15.0 2-1 0.64 2-2 0.66
15.1 to 36.0 2-4 0.72 2-7 0.77
36.1 to 46.0 2-7 0.77 2-10 0.77
46.1 to 72.5 3-0 0.90 3-6 1.05
72.6 to 121 3-2 0.95 4-3 1.29
Note1 – No contact necessary
�Caution: If a three phase circuit is being checked and
one phase is open, the voltage from another phase
maybe detected and will give a faulty indication. Always
make sure that the phase cables are separated by at least
20 in (50.8 cm).
5
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Voltage Detection
LOW Range
1. Push the ON/OFF push button to turn the unit ON.
2. The high voltage detection circuit is activated. A
beep will sound and the blue LEDs will flash twice
per second.
3. Push the LOW range push button. The unit is ready
for low voltage detection.
4. Place the probe tip of the TIC 300 PRO near, but not
touching, a low (<1000 V) voltage line (Fig. 1).
5. If voltage is present, the blue LEDs will blink and the
beeper will sound at an increased rate. Continuous
visual (blue LEDs) and audible indicators will increase
when the probe tip makes contact with or is very
close to the voltage line.
Fig. 1 Voltage detection in a line
HIGH Range (HOT STICK must be used)
(See Fig. 2)
1. Push the ON/OFF push button to turn the unit ON.
2. The high voltage detection circuit is activated. A
beep will sound and the blue LEDs will flash twice
per second.
3. Approach the probe tip near, but not touching, a
high voltage (>1500 V and <122 kV) conductor.
6
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
4. If voltage is present, the blue LEDs will blink and the
beeper will sound at an increased rate. Continuous
visual (blue LEDs) and audible indicators will increase
when the probe tip makes contact with or is very
close to the high voltage line.
TIC 300 PRO
HOT STICK
Fig. 2 Voltage detection in transmission lines
Locate breaks in insulated wire and heating
elements (See Fig. 3)
1. Push the ON/OFF push button to turn the unit on.
2. Push the LOW range push button.
3. Make sure the wire or the heating element is energized.
4. Place the tip of the probe near the wire and start
tracing along it. When the fast or continuous beeping
stops, the point of the break or “open” is indicated.
7
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Fig. 3 Finding a break/open
Check Outlets and Switches (See Figs. 4 & 5)
1. Push the ON/OFF push button to turn the unit on.
2. Push the LOW range push button.
3. Place the probe tip of the TIC 300 PRO against the
hot prong of an outlet or switch contact.
4. Increased beeping indicates higher voltage presence.
OFF
ON
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Detecting voltage in an
Fig. 4
outlet (Note: disconnect
Fig. 5
Finding a breaker
all power cords from the
outlet before testing)
8
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
MAINTENANCE AND REPAIR
If there appears to be a malfunction during the
operation of the voltage detector, the following steps
should be performed in order to isolate the cause of the
problem:
1. Check the battery.
2. Review the operating instructions for possible
mistakes in operating procedure.
Except for the replacement of the battery, repair of
the voltage detector should be performed only by a
Factory Authorized Service Center or by other qualified
instrument service personnel.
Cleaning
The front panel and case can be cleaned with a mild
solution of detergent and water. Apply sparingly with a
soft cloth and allow to dry completely before using. Do
not use aromatic hydrocarbons or chlorinated solvents
for cleaning.
Battery Replacement
Use a Phillips blade screwdriver to remove the battery
hatch screw. Lift the hatch. Remove the battery and
replace it with a 9 V alkaline battery. Make sure the seal
is in place. Close the battery hatch and replace the screw.
9
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
SPECIFICATIONS
Operating voltage
LOW Range: 30 to 1500 VAC; HIGH Range: 1500 VAC to
122 kVAC
Operating Temperature: 0°C to +52°C (32°F to +125°F);
RH < 90%
Storage Temperature: 0°C to +52°C (32°F to +125°F)
battery removed
Environment: < 2000 m (1.24 mi), outdoor operation
Power: 9 V alkaline battery
Power Consumption:
• OFF: 60 uA
• Low Detection mode: 39 mA
• High Detection mode: 39 mA
Duty Cycle: Continuous
Frequency Response: 50/60 Hz
Response Time: Instantaneous
Dimensions: 345(L) x 75(W) x 47(H) mm (13.5 x 3.0 x 1.8 in)
Weight: 243 g (0.5 lb)
Optional Accessory: TIC 410A Hot Stick
Electromagnetic Compatibility (EMC): EN 61326-1
Korea (KCC): Class A Equipment (Industrial Broadcasting
& Communication Equipment)
[1]
This product meets requirements for industrial (Class
A) electromagnetic wave equipment and the seller or
user should take notice of it. This equipment is intended
for use in business environments and is not to be used
in homes.
[1]
10
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Sensitivity: LOW Voltage
Hold the TIC 300 PRO when making the detection range
measurement for LOW voltage range.
Voltage
(Phase to neutral with
890K Ohm load)
30 V 3.8 cm (1.5 in)
75 V 16.5 cm (6.5 in)
100 V 21.6 cm (8.5 in)
120 V 25.4 cm (10 in)
220 V 33 cm (1 ft 1 in)
500 V 48.3 cm (1 ft 7 in)
1000 V 86.4 cm (2 ft 10 in)
Sensitivity: HIGH Voltage
The TIC 410A Hot Stick must be used when making
detection range measurement for HIGH voltage range.
Voltage
(Open Phase with no load)
1.5 kV 12.7 mm (0.5 in)
2.0 kV 25.4 mm (1 in)
4.0 kV 5.1 cm (2 in)
10.0 kV 20.3 cm (8 in)
15.0 kV 35.6 cm (1 ft 2 in)
20.0 kV 50.8 cm (1 ft 8 in)
25.0 kV 66 cm (2 ft 2 in)
Detection Range
(From the TIP of probe to
the target line)
Average
Detection Range
(From the TIP of probe to
the target line)
Average
11
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Loading...
