1 2 3 4 5
6
7
8 9 10 11 13
14 15
17
16
12
1. 0dB Input accepts a standard
1/4” instrument plug from your bass.
This input is suited for use with
instruments that have passive electronics.
2. -15dB Input accepts a standard
1/4” instrument plug from high output basses. This input is padded
15dB to compensate for higher output sources and is suited for use
with basses that have active electronics or high output pickups.
3. Ultra Low increases the low frequency output by 7dB at 40Hz. This
adds to the rumble and overall feel
of the low bass notes.
4. Ultra Mid decreases the mid frequency output by 6dB at 600Hz.
This removes some of the middle
frequencies for a “contoured”
sound.
5. Ultra High increases the high frequency output by 7dB at 5kHz. This
adds crispness to your sound.
6. Peak LED will illuminate when
the Gain control (#8) is set too high.
This indicates overdriving of the
preamplifier which causes clipping.
(See the Gain control, #8.)
7. Signal LED will illuminate when
the Gain control (#8) is adjusted
properly. (See the text for the Gain
control.)
8. Gain must be adjusted to match
the output of your instrument to the
amplifier. For the proper setting,
turn on the amplifier, turn the Gain
control and the Master control (#13)
all the way down and begin playing
your bass. Turn the Gain control up
until the Signal LED (#7) lights while
playing and the Peak LED (#6)
flashes occasionally.
9. Bass adjusts the output level of
the low frequencies and offers a cut
or boost of 12dB at 70Hz.
10. Low Mid adjusts the output
level of the lower midrange frequencies and offers a cut or boost of
12dB at 300Hz.
11. High Mid adjusts the output
level of the upper midrange frequencies and offers a cut or boost of
11dB at 1.5kHz.
12. Treble adjusts the output level
of the high frequencies and offers a
cut or boost of 14dB at 7kHz.
13. Master controls the overall output level of the amplifier and the
level of the signal at the
Headphones jack (#15).
14. Line Out supplies a mono signal for connecting to a mixing console, tape recorder or external
amplifier. The signal is pre-Master
and post-EQ.
15. Phones allows the connection
of a pair of stereo headphones for
private practice sessions. The internal speaker is disconnected whenever headphones are used.
16. Power light indicates the amplifier is turned on by glowing an iridescent blue color.
17. Power switch is used to turn
the amplifier on and off.
18. Power cord (rear panel, not
shown) connects the amplifier to a
suitable source of A.C. voltage. This
is a grounded, three-wire cord and
must be connected to a properly
grounded outlet. DO NOT attempt
to defeat the ground connection
of the power cord! If your amp was
purchased outside of the United
States, see the sticker next to the
A.C. connector for its power ratings.
Follow the above guidelines.
Thank you for selecting the Ampeg Rocket Bass amplifier. Inspired by the classic Ampeg
bass amps of the sixties, this easy-to-use amplifier represents Ampeg’s quest to provide you
the finest instrument amplification systems available. In order to get the most out of your
new amplifier, please read these instructions before its use.
Page 3
THIS EQUIPMENT HAS BEEN
DESIGNED AND ENGINEERED
TO PROVIDE SAFE AND RELIABLE OPERATION. IN ORDER
TO PROLONG THE LIFE OF THE
UNIT AND PREVENTACCIDENTALDAMAGES OR INJURY,
PLEASE FOLLOW THESE PRECAUTIONARY GUIDELINES:
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT OPEN CHASSIS; DO NOT
DEFEAT OR REMOVE THE
GROUND PIN OF THE POWER
CORD; CONNECT ONLYTO A
PROPERLY GROUNDED AC
POWER OUTLET.
WARNING: TO REDUCE THE
RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
CAUTION: NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION: OUR AMPLIFIERS
ARE CAPABLE OF PRODUCING
HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE
TO HIGH SOUND PRESSURE
LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT
OR LOSS. USER CAUTION IS
ADVISED AND EAR PROTECTION IS RECOMMENDED IF
UNIT IS OPERATED AT HIGH
VOLUME.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
"IT IS NECESSARY FOR THE USER TO REFER TO THE INSTRUCTION MANUAL"
“ES NECESARIO QUE EL USUARIO SE REFIERA AL MANUAL DE INSTRUCCIONES.”
"REFERREZ-VOUS AU MANUAL D'UTILISATION"
"UNBEDINGT IN DER BEDIENUNGSANLEITUNG NACHSCHLAGEN"
EXPLANATION OF GRAPHICAL SYMBOLS:
EXPLICACION DE SIMBOLOS GRAFICOS:
EXPLICATION DESSYMBÔLESGRAPHIQUES:
"DANGEROUS VOLTAGE"
“VOLTAJE PELIGROSO”
"DANGER HAUTE TENSION"
"GEFAHLICHE SPANNUNG"
=
=
PRECAUCION
RIESGO DE CORRIENTAZO
NO ABRA
PRECAUCION PARA DISMINUOIR EL RIESGO DE CORRIENTAZO
NO ABRA LA CUBIERTA
NO HAY PIEZAS ADENTRO QUE EL USARIO PUEDO REPARAR
DEJE TODO MANTENIMIENTO A LOS TECHNICOS CALIFICADOS
ATTENTION
RISQUE D'ELECTROCUTION
NE PAS OUVRIR
ATTENTION: POUR REDUIRE D'ELECTROCUTION NE PAS
ENLEVER LE COUVERCLE. AUCUNE PIECE INTERNE N'EST REPRABLE
PAR L'UTILISATEUR. POUR TOUTE REPARATION, S'ADRESSER A UN
TECHNICIEN QUALIFIE.
VORSICHT
ELEKTRISCHE SCHLAGGEFAHR
NICHT OFFENEN
VORSICHT: ZUR MINIMIERUNG ELEKTRISCHER SCHLAGGEFAHR NICHT
DEN DECKEL ABENHMEN. INTERNE TEILE KONNEN NICHT VOM
BENUTZER GEWARTET WERDEN. DIE WARTUNG IS QUALIFIZIERTEM
WARTUNGSPERSONAL ZU UBERLASSEN.
ESTE APARA T O HASIDO DISENADO Y CONSTRUIDO PARA
PROVEER ANOS DE OPERACION SEGURA Y CONFIABLE.
PARAPROLONGAR LA VIDA DE
ESTAUNIDAD E IMPEDIR
DANOS ACCIDENTALES POR
FAVOR SIGAESTAS INSTRUCCIONES PREVENTIVAS:
PRECAUCION: PARADISMINUIR
EL RIESGO DE DESCARGAS
ELECTRICAS: (1) NO ABRALA
CUBIERTA, (2) NO ES
RECOMENDABLE REMOVER O
DESACTIVAR LAPATA DEL
POLO A TIERRADELCABLE DE
CORRIENTE, CONECTE CORRECTAMENTE AUNATOMA DE
CORRIENTE A TIERRA.
ADVERTENCIA: PARAEVITAR
DESCARGAS EL ECTRICAS O
PELIGRO DE INCENDIO, NO
DEJE ESTE APARATO
EXPUESTO A LALLUVIAO
HUMEDAD.
PRECAUCION: NO HAY PIEZAS
ADENTRO QUE EL USUARIO
PUEDE REPARAR. DEJE TODO
MANTENIMIENTO A LOS TÉCNICOS CALIFICADOS.
PRECAUCION: NUESTROS
AMPLIFICADORES PUEDEN
PRODUCIR NIVELES DE PRESION DE SONIDO ALTO.
EXPOSICION CONTINUADAA
LOS NIVELES DE PRESION DE
SONIDO ALTO PUEDE CAUSA
DANO PERMANENTE ASU
OIDO. ES ACONSEJADO QUE
USE PRECAUCION ALUSUARIO
Y ES RECOMENDADO PROTECCION PARALOS OIDOS SI LA
UNIDAD ES OPERADAA VOLUMEN ALTO.
CET ÉQUIPEMENT AVAIT ÉTÉ
INVENTÉ ET ARRANGÉ POUR
POURVOIR DES ANNÉES
D'USAGE SAUF ET SÛR. POUR
PROLONGER LA VIE DE CET
APPAREILETPOUR EMPÊCHER
LES DOMMAGES ET LES TORTS
ACCIDENTELS, SUIVEZ LES
INSTRUCTIONS DE PRÉCAUTION.
AVERTISSEMENT: POUR
RÉDUIRE LES RISQUES D'ÉLECTROCUTION: (1) N’OUVREZ
PAS LE CHÂSSIS, (2) NE PAS
ESSAYER DE SUPPRIMER LA
BROCHE CORRESPONDANT À
LA TERRE.
ATTENTION: POUR RÉDUIRE
LES RISQUES D'UN FEU OU
D'ÉLECTROCUTION, N’EXPOSEZ PAS L'APPAREIL À LA
PLUIE OU À LA MOITEUR.
ATTENTION: IL N'Y A PAS
D’ÉLÉMENTS RÉPARABLES
DANS L'APPAREIL. CONSULTER
UN TECHNICIEN QUALIFIÉ
POUR LES RÉPARATIONS.
ATTENTION: NOS AMPLIFICATEURS SONT CAPABLES DE LA
PRODUCTION DES NIVEAUX DE
SON D'UNE HAUTE PRESSION.
L'EXPOSITION CONTINUE AUX
CES NIVEAUX PEUT CAUSER
LA SURDITÉ PERMANENTE. LA
PRUDENCE EST ADVISÉ À UTILISATEUR ET LAPROTECTION
DES OREILLES EST RECOMMANDÉ SI L'APPAREILEST
UTILISÉ À UN HAUT NIVEAU DE
VOLUME.
The B-100R is covered with a durable Tolex material: wipe it clean with a lint-free cloth. Never
spray cleaning agents onto the cabinet. Avoid abrasive cleansers which could damage the finish.
El B-100R esta cubierto con un material durable Tolex: limpielo con una toalla seca. Nunca rocie
el gabinete con sustancias limpiadoras. Evite usar materiales abrasivos con los cuales
pueda danar el acabado.
Le B-100R est couvert avec «Tolex» un revêtement noir et durable. Essuyez cette matière avec
une toile propre et sans charpie. Ne pulvérisez jamais les agents de nettoyage sur l'appareil.
Evitez les nettoyeurs abrasifs qui peuvent endommager le «Tolex.»
Page 4
Ampeg is proudly Made in America.
A product of SLM Electronics, 1400 Ferguson Avenue, St. Louis, MO 63133 U.S.A.
B-100R TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 100 Watts RMS, 4 ohm load, 120 VAC
SIGNAL TO NOISE RATIO 70dB Typical
POWER REQUIREMENTS Domestic: 2.5A, 100/120 VAC, 60 Hz
Export: 1.5A, 230 VAC, 50 Hz
GAIN 57dB
ULTRA LOW +7dB @ 40Hz
ULTRA MID -6dB @ 600Hz
ULTRA HIGH +7dB @ 5kHz
BASS ±12dB @70Hz
LOW MID ±12dB @300Hz
HIGH MID ±11dB @1.5kHz
TREBLE ±14dB @7kHz
SPEAKER SPECS 15”, 150 w, 4 ohm, 2.5” voice coil dia., 56 oz. magnet
SIZE AND WEIGHT 19” W x 21.25” H x 14.25” D
65 lbs.
Ampeg continually develops new products, as well as improves existing ones. For this reason,
the specifications and information in this manual are subject to change without notice.
Ampeg continuamente desarrolla nuevos productos, así como también mejora los existentes. Por esta razón,
las especifaciones é información incluidos en este manual están sujetos a cambios sin previo aviso.
Ampeg développe continuellement des nouvels produits, ainsi d'améliorer ceux qui existe. Pour cette
raison les spécifications et les informations dans ce manuel peuvent se changer sans préavis.
P/N 47-591-01 • 04/96
