M130/M131
Ethernet Option
for DLM600 and DCS Series
Programming Manual
M362797-03 Rev E www.programmablepower.com
About AMETEK
AMETEK Programmable Power, Inc., a Division of AMETEK, Inc., is a global leader in the design
and manufacture of precision, programmable power supplies for R&D, test and measurement,
process control, power bus simulation and power conditioning applications across diverse
industrial segments. From bench top supplies to rack-mounted industrial power subsystems,
AMETEK Programmable Power is the proud manufacturer of Elgar, Sorensen, California
Instruments and Power Ten brand power supplies.
AMETEK, Inc. is a leading global manufacturer of electronic instruments and electromec hanical
devices with annualized sales of $2.5 billion. The Company has over 11,000 colleagues working
at more than 80 manufacturing facilities and more than 80 sales and service centers in the United
States and around the world.
Trademarks
AMETEK is a registered trademark of AMETEK, Inc. Sorensen is a trademark owned by AMETEK, Inc.
Other trademarks, registered trademarks, and product names are the property of their respective
owners and are used herein for identification purposes only.
Notice of Copyright
M130/M131 Ethernet Option for DLM600 and DCS Series Programming Manual
Programmable Power, Inc. All rights reserved.
© 2002 AMETEK
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, AMETEK PROGRAMMABLE POWER, INC.
(“AMETEK”):
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR
EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL,
WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH
INFORMATION WILL BE ENTIRELY AT THE USER’S RISK, AND
(c) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH,
ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF TH E
TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED AMETEK CONTENT
IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION, WHICH IS POSTED AT
WWW.PROGRAMMABLEPOWER.COM.
Date and Revision
December 2008 Revision E
Part Number
M362797-03
Contact Information
Telephone: 800 733 5427 (toll free in North America)
858 450 0085 (direct)
Fax: 858 458 0267
Email: sales@programmablepower.com
service@programmablepower.com
Web: www.programmablepower.com
i
This page intentionally left blank.
ii
G
G
Important Safety Instructions
Before applying power to the system, verify that your product is configured properly for your
particular application.
WARNIN
WARNIN
Only qualified personnel who deal with attendant hazards in power supplies, are allowed to perform
installation and servicing.
Ensure that the AC power line ground is connected properly to the Power Rack input connector or
chassis. Similarly, other power ground lines including those to application and maintenance
equipment must be grounded properly for both personnel and equipment safety.
Always ensure that facility AC input power is de-energized prior to connecting or disconnecting any
cable.
In normal operation, the operator does not have access to hazardous voltages within the chassis.
However, depending on the user’s application configuration, HIGH VOLTAGES HAZARDOUS TO
HUMAN SAFETY may be normally generated on the output terminals. The customer/user must
ensure that the output power lines are labeled properly as to the safety hazards and that any
inadvertent contact with hazardous voltages is eliminated.
Guard against risks of electrical shock during open cover checks by not touching any portion of the
electrical circuits. Even when power is off, capacitors may retain an electrical charge. Use safety
glasses during open cover checks to avoid personal injury by any sudden component failure.
Neither AMETEK Programmable Power Inc., San Diego, California, USA, nor any of the subsidiary
sales organizations can accept any responsibility for personnel, material or inconsequential injury,
loss or damage that results from improper use of the equipment and accessories.
Hazardous voltages may be present when covers are removed. Qualified
personnel must use extreme caution when servicing this equipment.
Circuit boards, test points, and output voltages also may be floating above
(below) chassis ground.
The equipment used contains ESD sensitive parts. When installing
equipment, follow ESD Safety Procedures. Electrostatic discharges might
cause damage to the equipment.
SAFETY SYMBOLS
iii
This page intentionally left blank.
iv
Product Family: M130/M131 Ethernet Option
Warranty Period: Five Years
WARRANTY TERMS
AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the
Product stated above, and if the Buyer discovers and notifies AMETEK in writing of any defect in
material or workmanship within the applicable warranty period stated above, then AMETEK may,
at its option: repair or replace the Product; or issue a credit note for the defective Product; or
provide the Buyer with replacement parts for the Product.
The Buyer will, at its expense, return the defective Product or parts thereof to AMETEK in
accordance with the return procedure specified below. AMETEK will, at its expense, deliver the
repaired or replaced Product or parts to the Buyer. Any warranty of AMETEK will not apply if the
Buyer is in default under the Purchase Order Agreement or where the Product or any part
thereof:
• is damaged by misuse, accident, negligence or failure to maintain the same as
specified or required by AMETEK;
• is damaged by modifications, alterations or attachments thereto which are not
authorized by AMETEK;
• is installed or operated contrary to the instructions of AMETEK;
• is opened, modified or disassembled in any way without AMETEK’s consent; or
• is used in combination with items, articles or materials not authorized by AMETEK.
The Buyer may not assert any claim that the Products are not in conformity with any warranty
until the Buyer has made all payments to AMETEK provided for in the Purchase Order Agreement.
PRODUCT RETURN PROCEDURE
1. Request a Return Material Authorization (RMA) number from the repair facility (must be
done in the country in which it was purchased):
• In the USA, contact the AMETEK Repair Department prior to the return of the
product to AMETEK for repair:
Telephone: 800-733-5427, ext. 2295 or ext. 2463 (toll free North America)
858-450-0085, ext. 2295 or ext. 2463 (direct)
• Outside the United States, contact the nearest Authorized Service Center
(ASC). A full listing can be found either through your local distributor or our
website, www.programmablepower.com, by clicking Support and going to the
Service Centers tab.
2. When requesting an RMA, have the following information ready:
• Model number
• Serial number
• Description of the problem
NOTE: Unauthorized returns will not be accepted and will be returned at the shipper’s expense.
NOTE: A returned product found upon inspection by AMETEK, to be in specification is subject to
an evaluation fee and applicable freight charges.
v
This page intentionally left blank.
vi
CONTENTS
SECTION 1 FEATURES, FUNCTIONS, AND SPECIFICATIONS ....1-1
1.1 Introduction......................................................................................................1-1
1.2 Features and Functions...................................................................................1-2
1.2.1 Features...............................................................................................1-2
1.2.2 Programmable Functions.....................................................................1-3
1.2.3 Readback Functions............................................................................1-3
1.3 Specifications...................................................................................................1-3
1.3.1 Ethernet/LAN Configuration.................................................................1-3
1.3.2 Ethernet Configuration Factory Defaults..............................................1-4
1.3.3 Programming Resolution.....................................................................1-4
1.3.4 Programming Accuracy .......................................................................1-4
1.3.5 Readback Resolution...........................................................................1-5
1.3.6 Readback Accuracy.............................................................................1-5
SECTION 2 CONFIGURATION......................................................2-1
2.1 Setup Procedure..............................................................................................2-1
2.1.1 M130 Network Setup Using DHCP......................................................2-1
2.1.2 M130 Network Setup Using Auto-IP....................................................2-2
2.1.3 M130 Network Setup Using the Serial COM Port................................ 2-3
2.1.4 M130 Network Setup Using Web Browser ..........................................2-4
2.2 Rear Panel.......................................................................................................2-5
2.2.1 M130 (Master) Option.........................................................................2-5
2.2.2 M131 (Slave) Option............................................................................2-6
2.2.3 Configuration Switch............................................................................2-8
2.2.4 Remote/Local Selection.......................................................................2-9
2.3 External User Control Signal Connector........................................................2-10
M130/131 Programming Manual
vii
Contents Sorensen Ethernet Option
2.4 Programming Via Ethernet.............................................................................2-12
2.4.1 Communication Methods ...................................................................2-12
2.4.2 Raw Socket Interface.........................................................................2-12
2.4.3 VXI-11 Protocol..................................................................................2-12
2.4.4 Web Server........................................................................................2-12
2.4.5 Troubleshooting .................................................................................2-29
2.5 Remote Programming Via RS-232.................................................................2-30
2.6 Extended Interface Bus (EIB) with the M131 Option......................................2-31
SECTION 3 IEEE 488.2 AND SCPI COMMAND OPERATION........ 3-1
3.1 Introduction ......................................................................................................3-1
3.2 IEEE-488.2 Register Definitions.......................................................................3-1
3.2.1 SCPI Status Byte .................................................................................3-1
3.2.2 Standard Event Status Register (ESR)................................................3-2
3.2.3 Protection Condition and Protection Event Status Registers...............3-3
3.2.4 Operation Status and Questionable Status Registers..........................3-4
3.2.5 Error/Event Queue...............................................................................3-4
3.2.6 Serial Poll Operation............................................................................3-6
3.3 IEEE-488.2 and SCPI Conformance Information ...........................................3-7
3.3.1 Parameter Definitions...........................................................................3-7
3.3.2 Units.....................................................................................................3-7
3.3.3 Conventions.........................................................................................3-8
3.3.4 Queries.................................................................................................3-8
3.4 IEEE-488.2 Common Command Subsystem...................................................3-9
3.5 CALIBRATION SCPI Command Subsystem..................................................3-11
3.5.1 CALIBRATION SCPI Command Summary........................................3-11
3.5.2 CALIBRATION SCPI Command Reference.......................................3-12
3.6 MEASURE SCPI Command Subsystem........................................................3-15
3.6.1 MEASURE SCPI Command Summary.............................................. 3-15
3.6.2 MEASURE SCPI Command Reference.............................................3-15
3.7 OUTPUT SCPI Command Subsystem...........................................................3-16
3.7.1 OUTPUT SCPI Command Summary.................................................3-16
3.7.2 OUTPUT SCPI Command Reference................................................3-16
3.8 SOURCE SCPI Command Subsystem..........................................................3-17
3.8.1 SOURCE SCPI Command Summary.................................................3-17
3.8.2 SOURCE SCPI Command Reference ...............................................3-18
3.8.3 THE RAMP FUNCTION.....................................................................3-21
viii M130/131 Programming Manual
Sorensen Ethernet Option Contents
3.9 STATUS SCPI Command Subsystem...........................................................3-22
3.9.1 STATUS SCPI Command Summary ................................................. 3-22
3.9.2 STATUS SCPI Command Reference................................................3-22
3.10 SYSTEM SCPI Command Subsystem ..........................................................3-24
3.10.1 SYSTEM SCPI Command Summary...............................................3-24
3.10.2 SYSTEM SCPI Command Reference..............................................3-25
3.11 TRIGGER SCPI Command Subsystem.........................................................3-29
3.11.1 TRIGGER SCPI Command Summary.............................................3-29
3.11.2 TRIGGER SCPI Command Reference............................................ 3-29
3.12 Examples of Using the SCPI Commands......................................................3-30
SECTION 4 CALIBRATION ...........................................................4-1
4.1 Introduction......................................................................................................4-1
4.2 Setup for Calibration........................................................................................4-2
4.3 Voltage Programming Calibration....................................................................4-3
4.4 Voltage Measurement/Readback Calibration ..................................................4-5
4.5 Overvoltage Protection Programming..............................................................4-6
4.6 Current Programming Calibration....................................................................4-7
4.7 Current Measurement/Readback Calibration ..................................................4-9
4.8 Update of Non-Volatile Calibration Dates......................................................4-10
SECTION 5 OPERATION WITH M131 OPTION.............................213H5-1
82H5.1 Introduction......................................................................................................214H5-1
83H5.2 Configuration ...................................................................................................215H5-1
84H5.3 System Installation...........................................................................................216H5-3
85H5.4 RS-485 Interface..............................................................................................217H5-4
86H5.5 Programming the M131 Unit (Example) ..........................................................218H5-4
LIST OF FIGURES
87HFigure 2-1. Power Supply’s Home Page (DLM600 Series shown here).......................219H2-2
88HFigure 2-2. Typical Rear Panel of M130 Ethernet Option for DLM600.........................220H2-5
89HFigure 2-3. Typical Rear Panel of M130 Option for DCS1k and DCS1.2k...................221H2-5
90HFigure 2-4. Typical Rear Panel of M130 Option for DCS3k..........................................222H2-6
91HFigure 2-5. Typical Rear Panel of M131 Ethernet Option for DLM600.........................223H2-6
92HFigure 2-6. Typical Rear Panel of M131 Ethernet Option for DCS1k and DCS1.2k.....224H2-6
93HFigure 2-7. Typical Rear Panel of M131 Ethernet Option for DCS3k...........................225H2-7
94HFigure 2-8. DLM 600W Configuration Switch for the M130 Option ..............................226H2-8
95HFigure 2-9. DCS Configuration Switch for the M130 Option.........................................227H2-8
M130/M131 Programming Manual ix
Contents Sorensen Ethernet Option
Figure 2-10. External User Connector Designation (8-pin Molex)............................. 2-10
Figure 2-11. Example of Open Collector, TTL Input, and Relay Output Circuits....... 2-11
Figure 2-12. DLM Web Page Banner......................................................................... 2-13
Figure 2-13. DCS Web Page Banner......................................................................... 2-13
Figure 2-14. Login Window........................................................................................ 2-14
Figure 2-15. DLM Home Page...................................................................................2-14
Figure 2-16. DCS Home Page...................................................................................2-15
Figure 2-17. DLM IP Configuration Page................................................................... 2-16
Figure 2-18. DCS IP Configuration Page................................................................... 2-16
Figure 2-19. Settings Page........................................................................................2-19
Figure 2-20. Alert Message for Save Settings........................................................... 2-21
Figure 2-21. Status Page........................................................................................... 2-22
Figure 2-22. Security Page........................................................................................2-24
Figure 2-23. Add New User Window from Security Page..........................................2-25
Figure 2-24. Edit Existing User Window from Security Page..................................... 2-26
Figure 2-25. Channel Allocation Window from Security Page................................... 2-27
Figure 2-26. Slave Information Page.........................................................................2-28
Figure 2-27. RS-232 Rear Panel RJ-11 Connector Pinout........................................2-30
Figure 2-28. M130 to PC RS-232 Connection (RJ-11 to DB-9).................................2-30
Figure 2-29. EIB (RS485) Rear Panel RJ-11 Connector Pinout................................2-31
Figure 2-30. M130 to M131 EIB Connection (RJ-11 to RJ-11)..................................2-31
Figure 5-1. DLM600W Configuration for M131 set to Channel 2................................. 5-1
Figure 5-2. Switch Configuration for M6 or M131 set to Channel 8.............................5-2
Figure 5-3. RS-485 System Interconnection with Two Auxiliaries............................... 5-3
Figure 5-4. M131 Rear Panel RS-485 Connectors Pinout........................................... 5-4
LIST OF TABLES
Table 2-1 Remote/Local Switch...................................................................................2-9
Table 2-2 Remote Mode Power-on Conditions............................................................ 2-9
Table 2-3 External User Control Signal Connector Pinout......................................... 2-10
Table 3-1 SCPI Status Byte.........................................................................................3-2
Table 3-2 Standard Event Status Register .................................................................. 3-3
Table 3-3 Protection Condition and Event Status Registers........................................ 3-3
Table 3-4 SCPI Error Codes.......................................................................................3-4
Table 3-5 Parameter Definitions..................................................................................3-7
Table 3-6 M130 Units...................................................................................................3-7
Table 3-7 SOURce[n]:STATus:BLOCK? "Status Flags" Register ............................. 3-21
Table 3-8 System Fault Registers.............................................................................. 3-28
Table 5-1 Definitions of S1 Switch Settings................................................................. 5-2
x M130/131 Programming Manual
FEATURES, FUNCTIONS, AND
1.1 INTRODUCTION
This manual covers the M130 and M131 Remote Programming Ethernet Interface
Options for the DLM600 Series and the DCS Series power supplies. The M130
(master interface configuration) and M131 (slave configuration) options enable you
to operate your Sorensen power supply from a computer via Ethernet IEEE-802.3 or
RS-232 communication protocols, or with SCPI-compatible language, allowing full
remote programming control and monitoring of your power supply. The M130 can
control up to 30 auxiliary (slave) power supplies
SECTION 1
SPECIFICATIONS
In addition to controlling power supplies configured with the M131 (Ethernet) slave
option, the M130 master can control power supplies configured with the M85
(GPIB/RS232) slave option, which uses the same RS485-based Extended Interface
Bus (EIB) for master/slave control; whereas, a GPIB master (M9x) can control only
GPIB slaves (M85). This means that a single Sorensen DLM600 or DCS power
supply configured with the M130 option, can control any Sorensen power supply
(DLM600, DCS 1k, DCS 1.2k, DCS 3k), in any combination of M131 and/or M85
slave configuration options, up to as many as 30 power supplies total.
A final important point is that the M130 / M131 Ethernet options are
eXtensions for Instrumentation) class C compliant. LXI™ is an instrumentation
platform based on industry-standard Ethernet technology designed to provide ease
of integration by modularity, flexibility and performance.
1.1.1 MINIMUM SYSTEM REQUIREMENTS
The minimum software and equipment requirements to operate your Sorensen
Ethernet product depend on whether it is connected directly to your PC or connected
to the Internet or to a Local Area Network (LAN).
™ (LAN
M130/M131 Programming Manual 1-1
Features, Functions and Specifications Sorensen Ethernet Option
PC Connection
To operate your Sorensen Ethernet product connected directly to a PC (no Internet
or LAN connection) you will need:
• Pentium-based laptop or desktop computer running Microsoft Windows XP
• Ethernet based Network Interface Card (NIC) or built-in port capable of
10/100 MBit operation
• CAT 5 cable Ethernet crossover cable
• Microsoft Internet Explorer version 6.0 or later
• Sun Microsystems Java Runtime Environment
Internet or LAN Connection
To operate your Sorensen Ethernet product connected to the Internet or a LAN you
will need:
• Pentium-based laptop or desktop computer running Microsoft Windows XP
• Ethernet based Network Interface Card (NIC) or built-in port capable of
10/100 MBit operation
• Appropriate Ethernet modem for Internet connection, or
• Switch or hub (Linksys brand strongly recommended) for LAN connection
• Standard CAT 5 Ethernet interconnect cable
• Microsoft Internet Explorer version 6.0 or later
• Sun Microsystems Java Runtime Environment
1.2 FEATURES AND FUNCTIONS
1.2.1 FEATURES
• Ethernet/LAN connectivity, 10/100base-T compatible
• Fully
• Built-in Web Server for direct control using Internet Explorer 6.0 or higher
• 16-bit programming and 16-bit readback of voltage and current
• Programmable overvoltage protection with reset
• SCPI compliant command set
• User-programmable signals including Local/Remote Sense, External Polarity,
and Disconnect Relay Drive
• User selectable Constant-Voltage/Constant-Current or Foldback mode, with
reset
• Voltage Ramp and Current Ramp functions
• Field-upgradeable firmware via RS-232
• Attachment of up to 30 supplies equipped with the M131 or M85 option via
EIB interface, for a total of 31 supplies controlled through one IP address
• Full calibration through software control
™ (LAN eXtensions for Instrumentation) class C compliant
1-2 M130/131 Programming Manual
Sorensen Ethernet Option Features, Functions and Specifications
• Rear panel Ethernet/IEEE-802.3 and RS-232 control interface
• Rear panel User Control Signal interface
• Rear panel configuration switch
1.2.2 PROGRAMMABLE FUNCTIONS
• Output voltage and current
• Soft limits for voltage and current
• Overvoltage protection
• Output enable/disable
• Maskable fault interrupt
• Hold and trigger
• External relay control
• Full calibration
1.2.3 READBACK FUNCTIONS
• Measured voltage and current
• Voltage and current settings
• Soft voltage and current limits
• Overvoltage protection setting
• Status and Accumulated Status registers
• Programming error codes
• Fault codes
• Manufacturer, power supply model, and firmware version identification
1.3 SPECIFICATIONS
(SUBJECT TO CHANGE WITHOUT NOTICE)
1.3.1 ETHERNET/LAN CONFIGURATION
• Ethernet IEEE 802.3 compliant
• Medium 10/100 base-T
• Connection Monitoring Media Sense supported
• Protocol TCP/IP, IPV4
• ICMP (ping server) Enable (default)/Disable
• IP Address Assignment Automatic via DHCP (Primary default), Static, or
Automatic Private IP Addressing (Auto-IP, Secondary
default)
• VXI-11 Discovery Supported
• Security Password protected access, and selective
permissions for each user
M130/M131 Programming Manual 1-3
Features, Functions and Specifications Sorensen Ethernet Option
1.3.2 ETHERNET CONFIGURATION FACTORY DEFAULTS
PARAMETER DEFAULT
Host Name S-Dxx<base model>-<last four digits of serial number>
Description Sorensen Power Supply Dxx<base model>
IP Address
IP Addressing mode DHCP-acquired (Primary default*)
Subnet Mask
Gateway 0.0.0.0
DNS Server 0.0.0.0
Listening Port 9221
User ID admin
Password password
Ping Echo On
* The Ethernet interface provides the opportunity to set both a Primary and a
Secondary IP configuration in the IP Configuration page (Section
Primary fails, the system defaults to the Secondary configuration. However, both
setting DHCP-acquired and selecting “Auto IP Enabled” together in the Primary
configuration, prevents the power supply from trying the Secondary configuration.
Please see “IP Configuration” in Section
DHCP-acquired (Primary default*) If DHCP absent,
assigned via Auto-IP (Secondary default*)
DHCP-acquired (Primary default*) If DHCP absent,
assigned via Auto-IP (Secondary default*)
2.4.4). If the
2.4.4 for more detail.
1.3.3 PROGRAMMING RESOLUTION
DLM DCS
Voltage 0.002% of full scale 0.002% of full scale
Current 0.002% of full scale 0.002% of full scale
0.002% of full scale (full
Overvoltage Protection
scale is 110% of max
output voltage.)
1.3.4 PROGRAMMING ACCURACY
DLM600 DCS
Voltage ± (0.1% of maximum output voltage)
Current ± (0.25% of full scale output current
Overvoltage
Protection
± (0.5% of max output voltage)
0.002% of full scale (full
scale is 110% of max
output voltage.)
± (0.1% + 0.1% of full
scale)
± (0.1% + 0.4% of full
scale)
± (0.5% + 0.5% of full
scale) (full scale 110% of
max. output voltage)
1-4 M130/131 Programming Manual
Sorensen Ethernet Option Features, Functions and Specifications
1.3.5 READBACK RESOLUTION
DLM600 DCS
Voltage 0.002% of full scale 0.02% of full scale
Current 0.002% of full scale 0.02% of full scale
1.3.6 READBACK ACCURACY
DLM600 DCS
Voltage ± (0.1% of full scale output voltage)
Current*
± (0.25% of full scale output current)
± (0.1% + 0.15% of
maximum output voltage)
± (0.1% + 0.4% of
*
maximum output current)
* After 30 minutes operation with fixed line, load, and temperature.
Note: Refer to the applicable power supply manual (DLM600 or DCS) for effects of
line regulation, load regulation, and temperature on accuracy specifications.
M130/M131 Programming Manual 1-5
Features, Functions and Specifications Sorensen Ethernet Option
This page intentionally left blank.
1-6 M130/131 Programming Manual
SECTION 2
CONFIGURATION
The M130 is installed into the supply at the factory. Use the Setup Procedure described below
to configure the M130 for your system and application.
2.1 SETUP PROCEDURE
There are four methods of setting the IP address of the unit, each of which is
described in the subsections that follow:
• Set an IP address through DHCP (Primary default).
• If DHCP is not available, the unit can assign itself an IP address in the Auto-IP
(dynamic link local addressing) range (Secondary default).
• Use the serial communications port to manually assign an IP address.
• Set the IP address through the Web page interface.
NOTE: The M130 Ethernet Option has been designed and tested to be fully compatible
with Microsoft Internet Explorer 6.0. This is the only browser supported by Elgar
Electronics Corporation (EEC) in its Ethernet-based products. Earlier versions of
Explorer (or browsers by other companies) may or may not work correctly, and as
such, are not supported by EEC.
2.1.1 M130 NETWORK SETUP USING DHCP
Before beginning this procedure, get access to the DHCP server or see the network
administrator to get the IP address assigned to the power supply.
NOTE: The power supply is VXI-11 compliant, so even without access to the DHCP
server, it is still possible to discover the IP address assigned to the power supply
with programs such as Agilent’s I/O Library Suite or National Instrument’s NI-VISA.
1. Start with the power supply in the power-off state.
2. Connect a RJ-45 network cable from the power supply to the network with the
DHCP server.
3. Power on the power supply and allow the power supply to perform its
initialization.
M130/M131 Programming Manual 2-1
Configuration Sorensen Ethernet Option
4. Identify the IP address assigned to the power supply by accessing the DHCP
server, asking your network administrator, or discovering it with a VXI-11
compliant discover program.
5. The M130 Ethernet hardware is now configured. Open your Web browser and
enter the IP address of the power supply to view the Home page of the power
supply.
Figure 2-1. Power Supply’s Home Page (DLM600 Series shown here)
2.1.2 M130 (MASTER) NETWORK SETUP USING AUTO-IP
For this method, use a VXI-11 compliant discovery program such as Agilent’s I/O
Library Suite or National Instrument’s NI-VISA to discover the IP address assigned to
the power supply. The power supply will assign itself an IP address in the IP address
range from 169.254.0.1 to 169.254.255.254 with a subnet mask of 255.255.0.0.
NOTE: When connecting your Sorensen Master unit to a network, Elgar strongly
recommends using Linksys® hubs or switches, which have undergone extensive
compatibility testing with the M130 interface.
1. Start with the power supply in the power-off state.
2. Connect a crossover cable from the power supply directly to your PC.
3. If the PC is already configured to obtain an IP address automatically, skip to
Step 4. Otherwise:
2-2 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
a. In Windows click Start, Settings, Control Panel.
b. Click open Network Connections. (For XP, if in the Category View, click
Network and Internet Connections, and then Network Connections).
c. In the Network Connections window, right click the icon for the network
adapter used to connect to the power supply, and click Properties.
d. Find the TCP/IP protocol item under the Configuration tab (for XP: find
the item under the General tab), and click Properties. Select Obtain an
IP Address Automatically.
e. Click OK to save the change.
f. Click OK again to apply the settings to the network adapter.
4. In Windows, click Start, and then Run…
5. In the Run window, type “ipconfig /release” and click OK.
6. Again click Start, and then Run…
7. In the Run window, type “ipconfig /renew” and click OK. Your PC will assign itself
an IP address in the Auto-IP range.
8. Power on the power supply and allow the power supply to perform its
initialization.
9. Identify the IP address assigned to the power supply by discovering it with a
VXI-11 compliant discover program.
10. Continue by following the procedure in Section
2.1.4.
NOTE: When Auto-IP assigns an IP address, Web page connections will time out
after 5 minutes of inactivity.
2.1.3 M130 NETWORK SETUP USING THE SERIAL COM PORT
1. Connect from the PC COM1 port to the power supply’s RS232 port (see Figure
2-2,
Figure 2-3 or Figure 2-4 for port location) using a straight-through DB91 to
RJ-1 connector. (See Section
2. Have ready the IP address (e.g. 192.168.0.200) and subnet mask (e.g.,
255.255.255.0) to be assigned to the power supply.
3. Run a serial terminal program, such as HyperTerminal. Set the baud rate (bits
per second) to 19200, data bits to 8, parity to none, stop bits to 1, flow control
to none. Establish the connection.
4. Power on the power supply and allow the power supply to perform its
initialization. In HyperTerminal, tap the
input buffer (tapping the
using HyperTerminal, rather than tapping the
2.5 for the wiring diagram).
ENTER key a couple of times to clear the
ENTER key is also required to clear any errors when
BACKSPACE or DELETE keys).
5. Type SYST:NET:DHCPMODE 0 <enter> to take the Primary configuration out of
DHCP mode.
M130/M131 Programming Manual 2-3
Configuration Sorensen Ethernet Option
6. Set the IP address by typing SYST:NET:IP “xxx.xxx.xxx.xxx” <enter> (where
xxx.xxx.xxx.xxx is the new IP address). For example, to set 192.168.0.200 as the
IP address, type SYST:NET:IP “192.168.0.200” <enter> (note that the format
requires a single space after SYST:NET:IP and double quotes around the IP
address numbers).
7. Set the subnet mask with “SYST:NET:MASK xxx.xxx.xxx.xxx”
8. After configuring all settings, verify with the queries, SYST:NET:IP? <enter> and
SYST:NET:MASK? <enter>.
9. Type *RST<enter> to perform a power–on reset of the power supply.
10. The M130 Ethernet hardware is now configured. Open your Web browser and
enter the assigned IP address of the power supply to view the power supply web
page.
11. The power supply is now ready to be plugged into the network.
2.1.4 M130 NETWORK SETUP USING WEB BROWSER
Note: This requires that the PC’s IP address be in the same network as the IP
address assigned to the power supply. It also requires your Web browser to open the
power supply’s Home page.
Note: For proper functionality on the Web browser, ensure that Sun Microsystems’
Java Runtime Environment is installed on the PC. Visit www.java.com to download,
after setting the Web browser’s Security to enable scripting of Java applets:
<enter>.
1. In the Tools menu, select Internet Options… and click the Security tab.
2. At the bottom of the Security window click Custom level…
3. In the Reset custom settings drop-down, select Medium and click Reset
and then OK).
Now use your Web browser for M130 Network Setup:
In the Web browser’s Address: field, type http://xxx.xxx.x.xxx where
xxx.xxx.x.xxx is the power supply’s IP address. (See Section
description and operation information).
2.4.4 for
2-4 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
2.2 REAR PANEL
2.2.1 M130 (MASTER) OPTION
Figure 2-2 through Figure 2-4 display the pertinent rear panel components of a
typical M130 Ethernet option for the DLM600 and the DCS masters.
Figure 2-2. Typical Rear Panel of M130 Ethernet Option for DLM600
1 – Configuration Switch (for correct settings see Section
2 – External User Control Signal Connector (see Section
3 – Reset switch and green dual-purpose NET LED.
Reset switch (must be depressed until NET LED begins blinking, which could take
five or more seconds) returns configuration parameters to factory default settings
(see Section
NET LED: when solid-lit, indicates Network Connectivity; blinking indicates
Instrument ID (See “Instrument ID” under Settings, Section
there is no Ethernet connection found by the power supply.
4 – Connections for Ethernet (RJ-45) with built-in 10/100 indicator (on right top of the
RJ45 connector) and an Activity indicator (on the left top). Also RJ-11 connectors
for RS232 and RS485.
Figure 2-3. Typical Rear Panel of M130 Option for DCS1k and DCS1.2k
1.3.2).
2.2.3)
2.3)
2.4.4). If the LED is off,
M130/M131 Programming Manual 2-5
Configuration Sorensen Ethernet Option
Figure 2-4. Typical Rear Panel of M130 Option for DCS3k
2.2.2 M131 (SLAVE) OPTION
Figure 2-5 through Figure 2-7 display the pertinent rear panel components of a
typical M131 Ethernet option for the DLM600 and the DCS slaves.
Figure 2-5. Typical Rear Panel of M131 Ethernet Option for DLM600
1 – Configuration Switch (for correct settings see Section
2 – External User Control Signal Connector (see Section
4 – Connections (RJ-11) for RS485
Figure 2-6. Typical Rear Panel of M131 Ethernet Option for DCS1k and DCS1.2k
2-6 M130/M131 Programming Manual
5.2)
2.3)
Sorensen Ethernet Option Configuration
Figure 2-7. Typical Rear Panel of M131 Ethernet Option for DCS3k
M130/M131 Programming Manual 2-7
Configuration Sorensen Ethernet Option
2.2.3 CONFIGURATION SWITCH
Use the DIP switch, accessible from the rear panel, to configure the power supply
with the installed M130/M131 for the particular system and application in use. The
following figures show the DIP switch configuration for the M130, as set up in
Section
Note: On the Ethernet master, the rear panel switch gets set to Remote On, and all
Note: Two types of DIP switches are utilized; toggle and rocker. For toggle
2.1 (see Section 5.2 for the M131).
remaining switches are disregarded.
switches, the shading indicates the position of the toggle switch. For rocker
switches, the shading indicates the depressed side.
Figure 2-8. DLM 600W Configuration Switch for the M130 Option
Figure 2-9. DCS Configuration Switch for the M130 Option
2-8 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
2.2.4 REMOTE/LOCAL SELECTION
Set the rear panel Remote/Local switch to select remote or local operation.
Table 2-1 Remote/Local Switch
Switch Position
ON Remote operation selected.*
OFF
* In the ON position, the power hardware and Ethernet card initialize to the remote state
at power-on. In addition, front panel control remains disabled regardless of the state of
the REN line, or the GTL command. The special SCPI command SYST[n]:LOCAL
<on/off> is now permitted as a means to revert to front panel control if desired.
Powering up in remote mode will result in the following operating conditions.
Table 2-2 Remote Mode Power-on Conditions
Condition Default
Voltage
Current
Soft Voltage Limit Model maximum voltage
Description
Local operation selected.
Front panel control is enabled. Unit will switch to remote
operation upon the first Ethernet, or RS-232 command.
0 Volts (initial from factory power–on voltage); otherwise,
last value saved by SCPI command or by the SAVE
SETTINGS button in the Web Settings page.
See CAL:INIT:VOLT to change.
0 Amps (initial from factory power–on current);
otherwise, last value saved by SCPI command or by the
SAVE SETTINGS button in the Web Settings page.
See CAL:INIT:CURR to change.
Soft Current Limit Model maximum current
Model maximum voltage +10% (initial from factory
power–on OVP); otherwise, last value saved by SCPI
OVP Trip Voltage
Delay 0.5 seconds
Foldback Protection OFF
Output ON
Hold OFF
Unmask NONE
Service Request Capability OFF
M130/M131 Programming Manual 2-9
command or by the SAVE SETTINGS button in the Web
Settings page.
See CAL:INIT:VOLT:PROT to change.
Configuration Sorensen Ethernet Option
2.3 EXTERNAL USER CONTROL SIGNAL CONNECTOR
An 8-pin Molex connector located at the rear panel provides external auxiliary control
signals to increase the user’s operating control of the supply. The mating receptacle is
Molex 43025-0800 with 8 female terminals 43030-0003. The Molex terminals
accommodate wire sizes from #20 - #24.
The relay outputs, when active, connect the POLARITY, SENSE, and ISOLATION pins
of the connector to the relay COMMON pin. The relays are rated at 120VAC/125VDC
@ 1A; for DLM600 Series 600W, maximum ratings are 60V(PK), 30VA, and 1A. For
DCS 1k, 1.2k, and 3k, the maximum ratings are 250V @ 8A. Any change in output
(voltage, current, etc.) initiated by the user from the RS-232, GPIB, or Ethernet
interface will generate a 10ms synchronization pulse at the rear panel User Control
Signal Connector of the master unit (Sync Signal).
Table 2-3 External User Control Signal Connector Pinout
Molex Pin Description
For RS-232/GPIB: FOLDBACK output signal, open collector,
1
3
6
7
8
2
5 COMMON for all signals and relay contacts.
4
active-low. Asserted when in foldback mode.
Reserved function for Ethernet interface.
FAULT output signal, open collector, active-low.
Asserted when a fault is recorded in the fault register.
POLARITY output signal, relay contacts. Asserted (contacts close
to COMMON) when a negative voltage is programmed.
(e.g., SOURce:VOLTage -5.0)
ISOLATION output signal, relay contacts. Asserted (contacts close
to COMMON) when the output relay is programmed OFF.
(e.g., OUTPut:ISOlation OFF)
SENSE output signal, relay contacts. Asserted (contacts close to
COMMON) when the sense relay is programmed OFF.
(e.g., OUTput:SENse OFF)
SHUTDOWN TTL input signal, active-high. Allows the user to
immediately shutdown the unit by a TTL input signal.
For RS-232/GPIB: SYNC output signal, open collector, active-low.
Pulsed for 10 ms when a change in the output occurs. Reserved
function for Ethernet interface.
Figure 2-10. External User Connector Designation (8-pin Molex)
2-10 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
Figure 2-11. Example of Open Collector, TTL Input, and Relay Output Circuits
CAUTION
The relays must not be hot-switched; ensure that the voltage across the relay
contacts and the current through them is zero prior to changing the relay states.
M130/M131 Programming Manual 2-11
Configuration Sorensen Ethernet Option
2.4 PROGRAMMING VIA ETHERNET
2.4.1 COMMUNICATION METHODS
With the M130 option, there are four basic methods to communicate with the power
supply from a PC:
• raw socket interface, sending delimited strings (default delimiter is
<LineFeed>)
• application program that utilizes VXI-11 Discovery protocol
• Web browser and the internal Web server, with scripting of Java applets
enabled
• RS232C serial interface
2.4.2 RAW SOCKET INTERFACE
The essential components of communicating via a raw socket interface are the
socket number, IP address and command delimiter. The default values are: socket =
9221, IP address = 192.168.0.200 (when static IP is enabled), and delimiter = line
feed <LF>. All of these items may be changed either via the Web browser (see
CONFIGURATION, p.
2-16) or RS232C interfaces (see SCPI command section).
IP
For convenience and to comply with the proposed LXI™ standard, the VISA
resource name is available on the home page of the power supply’s Web server.
2.4.3 VXI-11 PROTOCOL
With programs such as Agilent’s I/O Library Suite, or National Instrument’s NI-VISA,
the VXI-11 protocol allows the power supply to be easily configured in a test system.
2.4.4 WEB SERVER
To communicate with the power supply via the built-in Web server, open a supported
Web browser (Internet Explorer 6.0 or higher) and type the IP address of the power
supply in the “Address” field. Tap the
Ethernet Web page interface.
Note: To ensure proper functionality on your Web browser, Sun Microsystems’ Java
Runtime Environment must be installed on your PC. Visit www.java.com to
download. Also, set your Web browser’s Security to enable scripting of Java
applets. (In the Tools menu, select Internet Options… and click the Security
tab. At the bottom of the Security window click Custom level…; in the Reset
custom settings drop-down, select Medium and click Reset and then OK).
ENTER key to launch the power supply’s
2-12 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
Ethernet Web Pages, Overview
The layout of each of the Web pages includes the banner with the heading,
“Sorensen DLM (or DCS) Power Supply Interface” along with the device name
below and a LOGIN button to the right. Below the banner are six tabs, each linked
to its corresponding page. On each page is a title line (title matches tab name). In
the title line is an area that frequently displays informational messages as you use
the Web interface.
When navigating to the Ethernet Web pages by clicking their tabs, you will find
that only two of the pages may be accessed without logging in: HOME (default)
and SLAVE INFO; you must log in (click LOGIN) before tabbing to the other
pages, which allow access by permission only: FULL (Administrator), RW
(Read\Write), or R (Read).
• FULL permissions users have access to all pages and all channels and
may configure the interface, set and change security settings, allocate
channels, control the output of the power supply, send commands, etc.
• RW permissions users may access all pages except SECURITY, and may
read and control the output of the power supply for only the channels
allocated to them. They are not authorized to make changes on the IP
CONFIGURATION page.
• R permission users may read information related only to the channels
allocated them, and cannot make any changes or control the output.
Once you have logged in, the LOGIN button becomes a LOGOUT button.
Note: There are few differences between the DCS interface and the DLM
interface: their titles and device names in the banner (see
Figure 2-13), their specifics in the Home page (see Figure 2-15 and Figure
2-16), and the front panel lockout button in the Settings page (see
is grayed out for the DCS products. Unless DCS and DLM interfaces are both
shown, the following illustrations use only the DLM interface.
Figure 2-12. DLM Web Page Banner
Figure 2-12 and
Figure 2-19)
Figure 2-13. DCS Web Page Banner
M130/M131 Programming Manual 2-13
Configuration Sorensen Ethernet Option
Figure 2-14. Login Window
HOME
This is the default, information-only page. It displays all of the current information
about the master supply that you are connected to (if any slaves are connected,
their information is on the
SLAVE INFO page):
Figure 2-15. DLM Home Page
2-14 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
Figure 2-16. DCS Home Page
• The Model number, the Manufacturer, and the Serial Number of your
Ethernet power supply
• Firmware Revision: the version of the Ethernet firmware that is currently
installed for the Master. (See SLAVE INFO page for slave firmware
version.
• VISA Resource identifies the specific resource name used to
communicate via VISA (Virtual Instrument Software Architecture)
• LXI™ Compliance: the version and instrument class of the LXI™
standard with which your power supply is compliant
• Host Name: either the default or user-defined, network-unique identity
• Description: either the default or user-defined description of the power
supply in use (you can change the description to suit your needs, in the
CONFIGURATION page)
• MAC Address: the power supply Ethernet’s unique hardware address
• IP Address: your power supply’s address actually in use at start-up; can
be statically configured, DHCP acquired (default), or Auto-IP assigned
(see description for
CONFIGURATION page)
• Subnet Mask: network segment your power supply is on
• Gateway: IP address through which the instrument communicates with
systems that are not on the local subnet
• DNS Server: IP address of the Domain Name System (DNS) server
• Listening Port: port number for the embedded Web server
M130/M131 Programming Manual 2-15
Configuration Sorensen Ethernet Option
IP CONFIGURATION
Only users with FULL permissions shall have access to this Web page and be
allowed to configure the interface. You are only required to complete the
information for the parameters that you wish to change; all previously entered
and saved information remains the by default.
Figure 2-17. DLM IP Configuration Page
Figure 2-18. DCS IP Configuration Page
2-16 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
• Host Name: the default name includes the base model number of your
power supply, with the last four digits of the serial number. You may
change this name as long as it is unique so that VXI-11 Discovery and any
other IP Discovery program can identify your specific device on your
network.
To change: Type the new name (15 characters maximum) in
the blank field provided and click Apply to update
(or make all desired changes before clicking
Apply).
• Description: you may change the default factory setting to something
more meaningful to your current setup.
To change: Type your customized description, up to 64
characters, in the blank field provided, and click
Apply to update (or make all desired changes
before clicking Apply).
TCP/IP Configuration: the power supply has two TCP/IP
configurations that can be set, Primary and Secondary. If the Primary
Configuration is not valid on your network, the power supply will
attempt to try the Secondary Configuration.
NOTE: The power supply will NOT try the Secondary Configuration if
you have selected the Primary Configuration options, Obtain an IP
Address Automatically and Auto IP Enabled.
You may statically assign an IP address as well as configure other
Ethernet/LAN parameters, or you may keep/return to its default
setting for automatic assignment of an IP address.
To assign: Click the radio button next to Use a Static IP
Address to manually configure some or all of the
following the Ethernet/LAN parameters:
IP Address – input any standard IP address.
(Factory setting is 192.168.0.200). After clicking
Apply, you also must reset the power supply and
then exit and restart the Web browser to effect this
change. If you have changed the network portion of
the IP address, it may be necessary to alter the
network settings of your attached computer to
reconnect to the power supply.
Subnet Mask – input a value that identifies which
network segment your power supply is on, consisting
of 4 whole numbers, each ranging from 0 through
255, separated by periods. (Factory setting is
255.255.255.0, a class-C network subnet mask).
Click Apply to update (or make all desired changes
before clicking Apply).
Gateway – input the IP Address of any gateway that
stands between the instrument and any other
network entities that communicate with the power
M130/M131 Programming Manual 2-17
Configuration Sorensen Ethernet Option
supply. (No factory setting). Click Apply to update (or
make all desired changes before clicking Apply).
DNS Server – input an IP address for the Domain
Name System (DNS) server. Click Apply to update
(or make all desired changes before clicking Apply).
This field has no factory setting.
Listening Port – input a port number for the
embedded Web server, ranging in value from 1025 –
65535. Click Apply to update (or make all desired
changes before clicking Apply). The factory default
port number is 9221.
To automate: (To return to the default setting): Click the radio
button next to Obtain an IP Address
Automatically for dynamic address acquisition
from the DHCP server.
Auto IP Enabled: allows the power supply to assign itself an IP
address in the range from 169.254.0.1 to
169.254.255.254 with a subnet mask of 255.255.0.0.
If it is enabled, when there is no DHCP server
available, the power supply will assign itself an IP
address. However, please keep in mind that when
you select Obtain an IP Address Automatically and
you check Auto IP Enabled in TCP/IP Primary
Configuration, the system will not try the Secondary
Configuration.
To enable: Click in the box to check; click again to uncheck so
that it is no longer enabled.
Example TCP/IP Configurations:
Primary: Use a Static IP Address
Secondary: Obtain an IP Address Automatically (DHCP)
At power-up the power supply will assign itself the configured static IP address. If
no other device is using the IP address, the power supply continues with that
static IP address. If some other device is using that address, the power supply
will move to Secondary and attempt to acquire an IP address from a DHCP
server repeatedly until it gets an address.
Primary: Use a Static IP Address
Secondary: Obtain an IP Address Automatically (DHCP) and AutoIP
Enabled
At power-up the power supply will assign itself the static IP address. If no other
device is using the IP address, the power supply continues with that static IP
address. If some other device is using that address, the power supply will move
to secondary and attempt to acquire an IP address from a DHCP server. If it
cannot find a DHCP server to assign an address, it will assign itself a link-local
address. If no other device is using that link-local address it will use it for 5
minutes minimum. At that time, if it is already in communication with some other
device, it will hold onto that link-local address until the communication is finished
and then retry DHCP. Then, if DHCP is not available, the power supply will revert
to the last successful link-local address for another 5 minutes minimum.
2-18 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
Primary: Obtain an IP Address Automatically (DHCP) and AutoIP Enabled
Secondary: no matter the setting, will never be attempted
At power-up the power supply will attempt to acquire an IP address from a DHCP
server. If it cannot find a DHCP server to assign an address, it will assign itself a
link-local address. If no other device is using that link-local address, it will use it
for 5 minutes minimum. At that time, if it is already in communication with some
other device, it will hold onto the link-local address until the communication is
finished and then retry DHCP. If DHCP is not available, the power supply will
revert to the last successful link-local address for another 5 minutes minimum.
Primary: Obtain an IP Address Automatically (DHCP)
Secondary: Use a Static IP Address
At power-up the power supply will attempt to acquire an IP address from a DHCP
server. If it cannot find a DHCP server to assign an address, the power
supply will move to Secondary and assign itself the static IP address. If no other
device is using the IP address, the power supply continues with that static IP
address. If some other device is using the static IP address, the power supply will
move back to Primary and start the entire operation again
SETTINGS
The Settings page is available to users who have FULL, Read/Write or Read
Only access to at least one power supply (Read Only users can make no
changes to the settings). If you have a system with a single master and many
slaves, you could have access to one or more individual power supplies in the
system (see SECURITY pages).
Figure 2-19. Settings Page
M130/M131 Programming Manual 2-19
Configuration Sorensen Ethernet Option
• Selected Channel: selected power supply channel whose Settings are
presently displayed/updated (1= Master channel, and 2 – 31 = slave
channels); you can select a different channel to which you have access:
To select: Click and hold the drop-down button; you will see
only the channel numbers that you have rights to
access; click the desired channel number.
NOTE: If no channels are displayed, an
Administrator or a user with FULL permission (see
SECURITY, p. 2-24) must assign channel access
to the particular User ID, through the Security page
(
Figure 2-22), using the ALLOCATE CHANNELS
capability.
Below Selected Channel you will see continuous updates (2-5
times per second) of the actual voltage output (value displayed on
the left) and the actual live current output (value displayed to the
right).
• Voltage: value above is updated with actual voltage output of the power
supply
• Current: value above is updated with actual live current output
• Set V: the programmed voltage setting
• Set I: the programmed current setting
• Set OVP: the programmed over voltage protection setting
• APPLY: puts into effect the newly input settings
• CC and CV indicators: presently operating output mode of the power
supply, either constant voltage or constant current.
• OVP indicator: highlighted red if over voltage protection is activated
• FAULT indicator: highlighted red if fault has occurred
• OUTPUT indicator: solid-lit shows power output status is On
If you have Read/Write access, you can change the following settings (after
inputting desired settings, click APPLY):
• Set V – click in the Set V field and input a new value for voltage.
• Set I: click in the Set I field and input a new value for current.
• Set OVP: click in the Set OVP field and input a new value for over voltage
protection.
Output – click the applicable button(s) as follows:
• CLEAR OVP: to clear the OVP indication/condition after clearing the
cause of the event. The power supply will revert to the last saved values
for Voltage, Current, and OVP. Be sure to reset these values, if desired,
before clearing an OVP condition.
• CLEAR FAULT: to clear the hardware fault indication/condition after
clearing the cause of the event.
2-20 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
• OUTPUT: to turn on or off the power output (see Output indicator)
• FRONT PANEL LOCKOUT: to prevent or enable changes being made
via the front panel (LED to the left is lit when Lockout is in effect).
• INSTRUMENT ID: click to identify which power supply (instrument) in a
rack of equipment corresponds to the Channel selected. The LED to the
left of this button indicates whether or not this function is turned on (ON
causes the instrument’s rear panel NET LED to flash; the flashing
continues until you click INSTRUMENT ID again).
Power-on Default: click the applicable button(s) as follows:
• RECALL SETTINGS: click to restore the programmed Power-on defaults
into the Set V, Set I and Set OVP settings, and to the power supply output
(these defaults are those that were last saved prior to this Power-on).
• SAVE SETTINGS: after clicking APPLY, click to save the presently set
values displayed in the Set V, Set I and Set OVP fields into non-volatile
flash. (If only one new setting had been input, the other previously saved
values remain the same). Please be aware that these then become the
new power-on settings that will be applied at power-up time and
after OVP reset as described in “Clear OVP” above.
NOTE: When you click SAVE SETTINGS, you will get a pop-up alert
Figure 2-20) telling you that saving a non-zero voltage may cause the power
(
supply to power-on with a voltage on its output terminals after a restart or
power cycle.
Figure 2-20. Alert Message for Save Settings
SCPI command section:
• SEND COMMAND: (not to be used with any command that provides a
response) input a properly formatted SCPI command in the upper of the
two windows and click this button to send the command.
• SEND AND READ: for queries, input a properly formatted SCPI query
command in the upper of the two windows, and click this button to send
the command and read the response in the lower of the two windows.
• SCPI Command History: a history of the last few commands sent to the
power supply are remembered by the system and listed in this area. You
can click on a command to have it be pasted in the command window.
• CLEAR RESPONSES: click this button to clear the response window of
previous responses.
M130/M131 Programming Manual 2-21
Configuration Sorensen Ethernet Option
STATUS
This page displays updated information for the following parameters:
Figure 2-21. Status Page
• Selected Channel: as in the Settings page, this is the selected power
supply channel whose information is presently displayed/updated
(1= Master channel, and 2 – 31 = Slave channels); you can select a
different channel to which you have access:
To select: Click and hold the drop-down button; you will see
only the channel numbers that you have rights to
access; highlight the desired channel number and
release the mouse button.
NOTE: If no channels are displayed, an
Administrator or a user with FULL permission (see
SECURITY, p. 2-24) must assign channel access
to the particular User ID, through the Security page
(
Figure 2-22), using the ALLOCATE CHANNELS
capability.
• Output: displays the power output status, ON or OFF
2-22 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
• Trigger: set up by SCPI commands, displays whether the Trigger state is
OFF, ARMED, or TRIGGERED.
• OVP: displays Read Only status of over voltage protection, either OK
(normal) or TRIPPED.
• OTP: displays Read Only status of over temperature condition, either OK
(normal) or TRIPPED.
• Command Error: displays command and syntax errors that are queued
in the supply.
• Read Next Error: each click brings the next error into the Command
Error display, until no other errors are in the queue.
• CLEAR MESSAGES: click this button to clear the Command Error
message window of past messages.
• Last Calibration Date: displays the date that the power supply
(instrument) was last calibrated; configurable with SCPI commands,
normally at the time of calibration.
• Next Calibration Date: displays the date that the power supply should be
calibrated next; also configurable with SCPI commands, normally
calculated at time of calibration.
• Ping Echo: except for Read Only users, allows turning echo ability On or
Off, depending on whether or not you want the supply to respond to a
Ping command from another device on the network. The default setting
for Ping Echo is response enabled. Click the OFF radio button if you do
not want the supply to respond to a ping.
• Ping Remote IP Address: allows you to input an IP address of another
device in the system
• Ping: click this button to ping the device at the address that you entered
in the Ping Remote IP Address field.
• Response: displays the result of your ping. For Example, if the Ping
Address were 69.36.230.190, the Response window would display:
Pinging :69.36.230.190 Response Took 0 ticks
Or
Ping Failed (if the host specified is not in the network)
• CLEAR RESPONSES: click this button to clear the Response window of
past ping responses.
M130/M131 Programming Manual 2-23
Configuration Sorensen Ethernet Option
SECURITY
Accessible only if you have Administrative (Full) rights, this page allows you to
set up new user accounts for access to the power supply(s). It displays all of the
currently set up users and respective permission levels.
• FULL = full rights/Administrator
• RW = read and write to power supply(s)
• R = Read Only
• -L = identifies user currently logged onto a power supply session.
Figure 2-22. Security Page
• ADD: Click to pull up a separate page in which to input new users with
passwords and permission levels. (See
• REMOVE: Click to delete selected user after first highlighting their User
Name row. The Admin user cannot be removed.
• EDIT: Click to change settings (name/permissions) for selected user after
first highlighting their User Name row. This brings up the Edit Existing
User window (
• Allocate Channels: click to pull up the Channel Allocation page, which
presents a matrix of all users and all possible power supply channels,
whether they are in the system or not. (See
Figure 2-24).
Figure 2-23).
Figure 2-25).
2-24 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
ADD NEW USER
Accessible from the Security Page by clicking the ADD button, this page is
allows you (a Full permissions user) to add new users with their passwords
and permission levels.
Figure 2-23. Add New User Window from Security Page
To add: 1. Input appropriate information in User ID (case-sensitive, limited
to 14 characters), in Password (case sensitive, limited to 9
characters), and in Re-enter Password fields.
2. Select permission level from the Permission dropdown.
3. To accept into the system, click SUBMIT or tap the
ENTER key.
In the ADD NEW USER: line, you will see a message that the [new user name]
was added successfully, or a message that it was unsuccessful and the reason.
NOTE: In order to complete the addition of a new user, you must also allocate
channels to that user. (See
CHANNEL ALLOCATION, p. 2-27).
RESET clears the fields in which you input information.
CANCEL returns you to the Security page. This button does NOT “undo”
previous successful submit operations.
M130/M131 Programming Manual 2-25
Configuration Sorensen Ethernet Option
EDIT EXISTING USER
Accessible from the Security Page by clicking the EDIT button after first selecting
the user’s name, this page allows you (a Full permissions user) to edit the
parameters for an existing user.
Figure 2-24. Edit Existing User Window from Security Page
When this page appears, the fields are populated with the selected user’s
existing parameters.
To edit: 1. Input appropriate information, as desired, in User ID (case-
sensitive, limited to 14 characters), in Password (case
sensitive, limited to 9 characters), and/or in Re-enter Password
fields.
2. Select permission level from the Permission dropdown.
3. To accept into the system, click SUBMIT or tap the
ENTER key.
If your edit was successful, you will return to the Security page with a message to
that effect.
If there is an error in the editing process, you will stay in the Edit Existing User
page, and you will see a message in the EDIT EXISTING USER: line, describing
the reason for the error.
RESET clears the fields in which you input information.
CANCEL returns you to the Security page with a message verifying that the User
Edit was cancelled.
2-26 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
CHANNEL ALLOCATION
Accessible from the Security Page by clicking the ALLOCATE CHANNELS
button, this page is allows you (a Full permissions user) to select a user and
select the power supply(s) to which that user shall have access.
Figure 2-25. Channel Allocation Window from Security Page
X indicates which power supply (channel) each user has access to.
Because an Administrator has full rights to all functions of the
power supply(s), a user with FULL permissions has access to all
channels regardless of whether the Channel Allocation page
indicates he has permissions or not.
To change: 1. Select a user from the Selected User drop-down,
and check or uncheck the boxes above the
desired channel numbers.
2. Click Accept. Repeat for each user for whom you
are changing/allocating channels.
3. When finished, click Done to return to the initial
Security page.
M130/M131 Programming Manual 2-27
Configuration Sorensen Ethernet Option
SLAVE INFO
This page displays information only for the power supplies configured in this
system (one master power supply with a single IP address and up to 30 slave
power supplies – M131 and/or M85). The information for each power supply
displayed includes the Channel number (1 is the Master; 2 through 31 are
Slaves), the model number, the serial number, and the firmware revision.
Figure 2-26. Slave Information Page
Upon first entering this page, you will see information only for the slaves with
which the master established communication during the present session. Click
REFRESH SLAVE DATA to see the information on the remaining slaves present
in this system. (This refresh operation could take up to 60 seconds).
2-28 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
2.4.5 TROUBLESHOOTING
Resetting IP Configuration
Either press and hold in the IP reset switch (S2) on the rear panel until the green
NET LED flashes (this could take 5 or more seconds), which resets the Primary
configuration to DHCP and AutoIP Enabled (and ignores Secondary
configuration), or send the SCPI command, SYST:NET:IP xxx.xxx.xxx.xxx
through one of the following: the RS-232, the Server, or VXI-11. This sets the
primary configuration to Static IP, and the secondary configuration is left where it
presently is.
Cannot Establish Communication
Use RS232 port. Note 19.2k baud rate at J6.
Query IP address with the SCPI command, SYST:NET:IP?
Query the MAC address with the SCPI command, SYST:NET:MAC?
For Slave (M131) communication issues, check the slave unit address switch
setting.
Communication Established, but No Power Supply Response
Check SCPI string for errors (use the command SYST:ERR? to check response
from unit)
Web Page Does Not Come Up
Check IP address; validate your SUBNET Mask.
Verify that both your computer and the power supply are on the same network.
If using a direct connection with a crossover cable, verify the PC is set to static IP
address on the same network.
Observe the indicator LED on Ethernet port (J11) for activity. The NET LED (at
rear panel center, near IP reset switch) will be lit when communication is
established.
Lost/Forgot Password
If you are a user, contact the Administrator of the power supply network to modify
your password.
If you are the administrator, the only way to recover is to press and hold the IP
reset switch on the rear panel until the Green NET LED blinks (this could take
five or more seconds). The administrator User Name and password will be
restored to factory defaults, as will the IP Address, the IP Addressing Mode, Ping
Enable, SUBNET Mask, Host name, and Description String. All other defined
user names and passwords are not affected by the reset operation.
M130/M131 Programming Manual 2-29
Configuration Sorensen Ethernet Option
2.5 REMOTE PROGRAMMING VIA RS-232
The M130’s RS-232 interface operates at 19.2K baud with 8 data bits, no parity, and 1
stop bit. All M130 commands are supported at the RS-232 interface. The RS-232
interface is accessible through the power supply’s rear panel 6-pin RJ-11 connector,
labeled RS232(485).
Figure 2-27. RS-232 Rear Panel RJ-11 Connector Pinout
Figure 2-28. M130 to PC RS-232 Connection (RJ-11 to DB-9)
2-30 M130/M131 Programming Manual
Sorensen Ethernet Option Configuration
2.6 EXTENDED INTERFACE BUS (EIB) WITH THE M131
PTION
O
The M130 Master unit communicates with up to thirty M131 Slave units via a RS-485 serial
interface port on rear panel. To connect a M130 Master to a M131 Slave, insert a 6-conductor
serial cable (with male RJ11 connectors at both ends) between the RS-485 ports on the Master
and Slave units. Additional Slave units can be "daisy chained" together via their respective
RS-485 ports. Please refer to the applicable power supply manual (DCS or DLM600) for more
detail.
Figure 2-29. EIB (RS485) Rear Panel RJ-11 Connector Pinout
Figure 2-30. M130 to M131 EIB Connection (RJ-11 to RJ-11)
M130/M131 Programming Manual 2-31
Configuration Sorensen Ethernet Option
This page intentionally left blank.
2-32 M130/M131 Programming Manual
3.1 INTRODUCTION
The following sections describe the operation of the M130 by remote
programming using the M130 IEEE-488.2 and SCPI command sets. The supply
IEEE488.2 and SCPI command sets provide programming, query, and status
commands that facilitate remote control of the power supply.
SECTION 3
IEEE 488.2 AND SCPI
COMMAND OPERATION
3.2 IEEE-488.2 REGISTER DEFINITIONS
The M130 supports the IEEE-488.2 and SCPI 1995.0 status reporting data
structures. These structures are comprised of status registers and status register
enable mask pairs. The following sections describe these pairs.
3.2.1 SCPI STATUS BYTE
• To read the SCPI Status Byte status register, either send the *STB?
command or issue a GPIB or Ethernet serial poll. To clear the Status
Byte status register, send the *CLS command.
• To configure the supply to request service from the Ethernet controller,
set the appropriate bits in the Service Request Enable (SRE) register.
The SRE register has the same bit pattern as the SCPI Status Byte.
• To modify the SRE register, use the *SRE <mask> command; to read it,
use the *SRE? command. For example, if the SRE register is set to 0x10
(MAV), then when the supply has a message available, the Status Byte
register will contain 0x50 (RQS and MAV). See
Table 3-1.
M130/M131 Programming Manual 3-1
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
Table 3-1 SCPI Status Byte
Bit Hex Value Description
0 0x01
1 0x02
2 0x04
3 0x08
4 0x10
5 0x20
6 0x40
7 0x80
Not used.
Protection Event Status flag. Indicates the selected protection
event occurred.
Error/event queue message available. Set when any error/event is
entered in the System Error Queue. It is read using the
SYSTem:ERRor? query.
Questionable Status flag. Indicates the quality of the current data
being acquired. This bit is not used.
Message available (MAV). Indicates a message is available in the
GPIB or Ethernet output queue. Cleared after the GPIB or Ethernet
output buffer is read.
Standard Event Status Register (ESR). Summary bit for the ESR.
Set when any of the ESR bits are set and cleared when the ESR is
read.
Request Service flag (RQS) for serial polling or Master Summary
Status (MSS) in response to *STB? If service requests are enabled
(with the *SRE command), this bit represents the RQS and will be
sent in response to a serial poll, then cleared. If RQS is not
enabled, the bit represents the MSS bit and indicates the device
has at least one reason to request service. Even though the device
sends the MSS bit in response to a status query (*STB?), it is not
sent in response to a serial poll. It is not considered part of the
IEEE-488.1 Status Byte.
Operation Status flag. Indicates the current operational state of the
unit. This bit is not used.
3.2.2 STANDARD EVENT STATUS REGISTER (ESR)
• To read the Standard Event Status Register (ESR), use the *ESR?
command.
• To clear the ESR, either read this register or issue the *CLS command.
• To enable corresponding ESR bits to be summarized in the summary bit
of the SCPI Status byte, issue the *ESE (Standard Event Status Enable
Register) command.
3-2 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
Table 3-2 Standard Event Status Register
Bit Hex Value Description
0 0x01 Operation Complete
1 0x02 Request Control - not used
2 0x04 Query Error
3 0x08 Device Dependent Error
4 0x10 Execution Error (e.g., range error)
5 0x20 Command Error (e.g., syntax error)
6 0x40 User Request - not used
7 0x80 Power On
3.2.3 PROTECTION CONDITION AND PROTECTION EVENT STATUS REGISTERS
These two registers have the same bit meanings, but they differ in function.
• To read the Protection Condition, use the STAT:PROT:COND?
command. This command gives the present status condition of the
power hardware, so the data is not latched. It is a polling register.
• To read the Protection Event Status, use the
STATus:PROTection:EVENt? command. To clear the Protection Event
Status Register, either read this register with the *RST command, or
issue the *CLS command.
• To set bits in the Protection Event Status Register, you must first set the
corresponding bit in the Protection Event Status Enable Register and the
corresponding event must occur.
• To set the Enable Register, issue the STATus:PROTection:ENABle
<mask> command. The status is then latched and will remain in that
state until it is read or cleared due to some command action. Then use
the STATus:PROTection:ENABle? query to read the Enable Register.
Table 3-3 Protection Condition and Event Status Registers
Bit Hex Value Description
0 0x01 Constant voltage operation
1 0x02 Constant current operation
2 0x04 Not used
3 0x08 Overvoltage protection tripped
4 0x10 Overtemperature protection tripped
5 0x20 Supply external shutdown active
6 0x40 Foldback mode operation
7 0x80 Remote programming error
M130/M131 Programming Manual 3-3
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3.2.4 OPERATION STATUS AND QUESTIONABLE STATUS REGISTERS
The Operation Status and Questionable Status Registers will always return 0
when queried. The Operation Status Enable and Questionable Status Enable
Registers can be programmed and queried to allow SCPI compatibility but have
no effect on the Operation Status and Questionable Status Registers.
3.2.5 ERROR/EVENT QUEUE
The supply maintains an Error/Event Queue as defined by SCPI. The queue
holds up to 10 error events.
To view the error events, use the SYSTem:ERRor? Query command, which
reads in a First In/First Out (FIFO) manner. The read operation removes the
entry from the queue. The *CLS command clears all entries from the queue.
The following error codes are defined in the SCPI 1995.0 specification and are
supported by the M130. Error codes are in the range of [-32768, 32767]. SCPI
reserves the negative error codes and 0, while error codes greater than 0 are
device-specific errors.
Table 3-4 SCPI Error Codes
Error Code Description
208
207
206
205
Isolation relay must open first
An attempt to change the state of the polarity relay was made while the
isolation relay was closed. First open the isolation relay; then change the
state of the polarity relay.
Voltage sign mismatched polarity relay state
The algebraic sign on the voltage of a voltage programming command,
such as SOUR:VOLT <volt>, did not match the state of the polarity relay,
so the voltage command was ignored. For example, if the polarity relay is
in the positive voltage position (normal output voltage position), the
command SOUR:VOLT –5 will cause this error. Conversely, if the polarity
relay is in the negative voltage position (inverted output voltage position),
the command SOUR:VOLT 5 will cause this error.
Note that programming Over Voltage Protection with a mismatched
algebraic sign also can cause this error.
No channels setup to trigger
An attempt was made to trigger the M130 using the TRIG:TYPE <1|2|3>
command when there are no armed trigger settings. This error is not
generated when the GET is received, even when there are no armed
trigger settings.
GPIB or Ethernet GET not allowed during message
The GPIB or Ethernet G(roup) E(xecute) T(rigger) multiline command was
errantly generated by the system computer while or very shortly after a
message is or was sent. Give a few milliseconds after a message is sent
before attempting a GET; and never send a GET during a message
transfer over the GPIB or Ethernet.
3-4 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
Error Code Description
204
203
202
201
102
101
100
0
-102
-108
-151
-161
-200
-203
GPIB or Ethernet IFC caused warm boot
This error relates to the GPIB or Ethernet IFC signal, and is available only
in association with a proprietary command.
Hardware watchdog warm boot
Caused by a hardware fault either in the power supply proper, or on the
M130. One possible explanation might be that the mains power to the
supply was interrupted for a short but sufficient time to cause the M130
processor to reset and re-boot. Also, it might be possible to generate this
error by a very momentary power-off through the front panel power switch.
Foreground watchdog warm boot
The internal firmware on the M130 found an internal error condition that
halted processing; to force resumption of processing, a warm boot is
required.
Unexpected warm boot
The M130 GPIB or Ethernet-side processor experienced a warm boot that
was unexpected, and it may indicate an internal crash of the M130
processor.
Incompatible unit type
This error is not used. It cannot occur.
Incompatible unit version
This slave does not support user defined initialization values nor ramping;
its firmware is too old a version to do so. Slave #n provides its firmware
version number as the last number on the response from the *IDN[n]?
query command.
Incompatibility error
This error is not used. It cannot occur.
No error
The error queue is empty.
Syntax error
An unrecognized command or data type was encountered.
Parameter not allowed
More arguments than expected were received.
Invalid string data
Incorrect password. Manufacturer, model, or serial number string was
more than 16 characters. Invalid mnemonic.
Invalid block data
The expected number of data values was not received.
Execution error
An error/event number in the range [-299,-200] indicates that an error has
been detected by the instruments execution control block. The occurrence
of any error in this class shall cause the execution error bit (bit 4) in the
Event Status Register to be set. An execution error can be the result of:
• A <program data> element out of range, such as programming 35 volts
in a 33 volt device.
• A command could not be executed due to the current condition of the
device.
Command protected
Attempted to store calibration values to EEPROM without unlocking.
M130/M131 Programming Manual 3-5
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
Error Code Description
-221
-222
-225
-241
-284
-292
-293
-316
-330
-340
-350
-360
Settings conflict
Attempted to set output greater than soft limits or to set soft limits less than
output.
Data out of range
Parameter exceeded range of valid values.
Out of memory
There is not enough memory to perform the requested operation.
Hardware missing
A legal command or query could not be executed because the option is not
installed.
Program currently running
A legal command or query could not be executed because a function is
currently running.
Referenced name does not exist
Referenced name already exists
Checksum error
Self-test failed
A self-test failure has occurred.
Calibration failed
Error during calculation of calibration values occurred.
Queue overflow
The error queue can contain up to 10 entries. If more than 10 error/event
conditions are logged before the SYSTem:ERRor? query, an overflow will
occur; the last queue entry will be overwritten with error -350. When the
queue overflows, the least recent error/events remain in the queue and the
most recent error/events are discarded.
Communication error
Communication to a channel was disrupted.
3.2.6 SERIAL POLL OPERATION
Performing a serial poll will not modify the Status Byte other than to clear the
RQS (bit 6) for a supply requesting service. Queries affecting the Status
Registers and subsequent serial poll are described below:
• *STB? clears the Status Byte
• *ESR? clears the ESR and bit 5 of the Status Register
• SYSTem:ERRor? clears bit 2 of the Status Register if the queue is empty
3-6 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
3.3 IEEE-488.2 AND SCPI CONFORMANCE INFORMATION
The supply conforms to most of the specifications for devices as defined in IEEE-
488.2 and SCPI Version 1995.0. Confirmed Commands are those that are
approved commands in the SCPI 1995 Specification, Volume 2: Command
Reference. Confirmed Commands are denoted by a “C” in the “SCPI” column.
Any commands that are not Confirmed Commands are labeled as Not Approved
denoted by an “N” (e.g., Section
3.3.1 PARAMETER DEFINITIONS
Table 3-5 Parameter Definitions
PARAMETER DEFINITIONS
Type Valid Arguments
<boolean> “ON” or 1. “OFF” or 0.
<NR1>
<0+NR1> Zero and positive integer numeric values.
The data format <NR1> is defined in IEEE-488.2 for integers.
Zero, positive and negative integer numeric values are valid data.
3.5.2).
<-NR1> Negative integer numeric values.
<NRf>
<0+NRf> Zero and positive floating point numeric values.
<-NRf> Negative floating point numeric values.
<string> Characters enclosed by single or double quotes.
The data format <NRf> is defined in IEEE-488.2 for flexible Numeric
Representation. Zero, positive and negative floating point numeric
values are some examples of valid data.
3.3.2 UNITS
The Series M130 will accept the following units as suffixes to numeric values:
Table 3-6 M130 Units
UNITS
Type of Unit Valid Suffix
Voltage “VOLTS” or “volts”, “V” or “v”, “MV” or “mv” or “mV”
Current “AMPS” or “amps”, “A” or “a”, “MA” or “ma” or “mA”
Time “SEC” or “sec”, “S” or “s”, “MS” or “ms”, “MIN” or “min”
Frequency “HZ” or “hz”
The default units are VOLTS, AMPS, SEC, and HZ. For example, “SOUR:VOLT
1” programs 1 volt. To program in units of millivolts, type “SOUR:VOLT 1mV”.
M130/M131 Programming Manual 3-7
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3.3.3 CONVENTIONS
SCPI uses the conventions where optional commands and parameters are
enclosed by “[ ]”. Additionally the shorthand version of a command is indicated
by capital letters. The optional parameter “[n]” selects the auxiliary channel
number (power supply) being commanded. If “[n]” is not specified, the default
master channel 1 is automatically selected. Channel 1 selects the master unit
and channels 2-31 select an auxiliary unit attached with the M131 option.
Selecting the global channel 0 is allowed only for the TRIGgerred[n] commands.
For example,
SOURce[n]:VOLTage[:LEVel][:IMMediate][:AMPLitude] 120.0
can be written as
SOURce[n]:VOLTage 120.0 // for any channel
or
SOUR:VOLT 120.0 // for default master channel 1
3.3.4 QUERIES
The query syntax is identical to the command syntax with a “?” appended and
no additional parameters/arguments following. For example, to query the
programmed voltage, send the string: SOURce:VOLTage?. A subsequent
device read will return a value such as “33.000”. For Ethernet, all queries are
terminated with a carriage return. For GPIB controllers that require termination
characters, all queries are terminated with a carriage return and line feed (0x0D
0x0A). When the supply has nothing to report, its output buffer will contain two
ASCII characters: a carriage return and linefeed (in decimal the values are:
<13><10>).
3-8 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
3.4 IEEE-488.2 COMMON COMMAND SUBSYSTEM
The following commands are common to all SCPI instruments and declared
mandatory by IEEE-488.2. In the following table, the M130 is defined as the
“device” on the GPIB or Ethernet bus.
Command Description
*CLS[n] Clears all status reporting data structures including the
Status Byte, Standard Event Status Register, and Error
Queue. The STAT:PROT:ENAB (protection event enable
register) is cleared by this command; other enable registers
are not cleared by this command.
*ESE[n] <0+NR1> Sets the value of the Standard Event Status Enable Register
that determines which bits can be set in the Standard Event
Status Register. See section
*ESE[n]? Returns the integer value of the Standard Event Status
Enable Register. See section
Response: <0+NR1>
*ESR[n]? Returns the integer value of the Standard Event Status
Register. The ESR and the Status Byte ESR bit are cleared.
See section
3.2.2 for valid values.
3.2.2 for valid values.
3.2.2 for valid values.
Response: <0+NR1>
*IDN[n]? Returns the device identification as an ASCII string.
Response: <Manufacturer>, <model>, <serial number>,
<DCI firmware version> <AI firmware version>
Example: Sorensen, DCS33-33, B90000-0,
1.00,1.00
*OPC[n] Enables the Operation Complete bit of the Standard Event
Status Register to be set when all pending operations are
complete. See section
*OPC[n]? Returns the integer value “1” when all pending operations
are complete. See section
Response: <0+NR1>
*RST[n] Resets the supply to its Power ON (PON) state.
Clears all status reporting data structures including the
Status Byte, Standard Event Status Register, and Error
Queue. The STAT:PROT:ENAB (protection event enable
register) is cleared by this command; other enable registers
are not cleared by this command.
*SRE[n] <0+NR1> Sets the value of the Service Request Enable Register,
which determines which bits in the Status Byte will cause a
service request from the device. See section on Status Byte
for valid values.
*SRE[n]? Returns the integer value of the Service Request Enable
Register. See section on Status Byte for valid values. Values
range from 0-63 or 128-191.
3.2.2.
3.2.2.
Response: <0+NR1>
M130/M131 Programming Manual 3-9
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
Command Description
*STB[n]? Returns the integer value of the Status Byte with bit 6
representing the Master Summary Status (MSS) instead of
RQS. The MSS bit acts as a summary bit for the Status Byte
and indicates whether the device has at least one reason to
request service based on the MAV and the ESR bits. The
Status Byte is cleared. See section on Status Byte for valid
values. Values range from 0-255.
Response: <0+NR1>
*TST[n]? Sets the device to execute an internal self-test and return
the integer value of the results. Value of “0” indicates no
errors.
Response: <0+NR1>
*WAI[n] Sets the device to wait until all previous commands and
queries are complete before executing commands following
the *WAI command.
3-10 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
3.5 CALIBRATION SCPI COMMAND SUBSYSTEM
See Section 4 for calibration procedures.
Please refer to the power supply manual for further information before
performing calibration procedures. Calibration must be performed by
qualified personnel who appropriately deal with attendant hazards. If
WARNING
3.5.1 CALIBRATION SCPI COMMAND SUMMARY
CALibrate[n]
:DATA <NRf><NRf><NRf><NRf><NRf><NRf><NRf><NRf><NRf><NRf>
:INITial
:CURRent <0+NRf>
:VOLTage
[:AMPLitude] <NRf>
:PROTection <NRf>
:LOCK
:MEASure
:CURRent
:ADC?
:CALCulate
:GAIN <NRf>
:OFFSet <NRf>
:POINt <1|2> <0+NRf>
:VOLTage
:ADC?
:CALCulate
:GAIN <NRf>
:OFFSet <NRf>
:POINt <1|2> <NRf>
:MODel
:LASTCALDATE?
:NEXTCALDATE <NRf> <NRf> <NRf>
:NEXTCALDATE?
:OUTPut
:CURRent
:DAC <0+NR1>
:FIVEPOINT <1|2|3|4|5> <0+NRf>
:FIVEPOINT?
:GAIN <NRf>
:OFFSet <NRf>
calibration is not performed properly, functional problems could arise,
requiring that the supply be returned to the factory.
:LASTCALDATE <NRf> <NRf> <NRf>
M130/M131 Programming Manual 3-11
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
:VOLTage
:DAC <0+NR1>
:FIVEPOINT <1|2|3|4|5> <0+NRf>
:FIVEPOINT?
:GAIN <NRf>
:OFFSet <NRf>
:PROTection
:CALCulate
:DAC <0+NR1>
:GAIN <NRf>
:OFFSet <NRf>
:STORe
:UNLock <string>
3.5.2 CALIBRATION SCPI COMMAND REFERENCE
Command Description SCPI
CALibrate[n] Calibration subsystem. n = 1-31. The
default channel is 1.
:DATA <NRf><NRf><NRf>
<NRf><NRf><NRf>
<NRf><NRf><NRf>
<NRf>
:INITial N
:CURRent Sets the power-on default value of current. N
:VOLTage N
[:AMPLitude] <NRf> Sets the power-on default voltage. N
:PROTection <NRf> Sets the power-on default value of the
:LOCK Disables access to the non-volatile memory.
:MEASure N
:CURRent
:ADC? Returns the integer value of the A/D for the
:CALCulate Calculates the value of the gain and offset
Sets the values of the ten floating point
calibration constants:
1) output voltage DAC gain
2) output voltage DAC offset
3) output current DAC gain
4) output current DAC offset
5) output voltage protection DAC gain
6) output voltage protection DAC offset
7) voltage measurement ADC gain
8) voltage measurement ADC offset
9) current measurement ADC gain
10) current measurement ADC offset
Values are separated by space or comma.
overvoltage protection.
Prevents attempts to store calibration
values.
current measurement.
for current measurements.
C
N
N
N
N
N
3-12 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
Command Description SCPI
:GAIN <NRf> Sets the value of the gain for current
measurements.
:OFFSet <NRf> Sets the value of the offset for current
measurements.
:POINt <1|2> <0+NRf> Sets the current measurement calibration
point (1 or 2). The actual output current is
measured with an external meter.
:VOLTage N
:ADC? Returns the integer value of the A/D for the
voltage measurement.
:CALCulate Calculates the value of the gain and offset
for voltage measurements.
:GAIN <NRf> Sets the value of the gain for voltage
measurements.
:OFFSet <NRf> Sets the value of the offset for voltage
measurements.
:POINt <1|2> <NRf> Sets the voltage measurement calibration
point (1 or 2). The actual output voltage is
measured with an external meter.
:MODEL
:LASTCALDATE <NRf>
<NRf> <NRf>
:LASTCALDATE? Returns the date last calibrated.
:NEXTCALDATE <NRf>
<NRf> <NRf>
:NEXTCALDATE? Returns the due date for next calibration.
:OUTPut N
:CURRent N
:DAC <0+NR1> Sets the output of the output current D/A
:FIVEPOINT <1|2|3|4|5>
<0+NRf>
:FIVEPOINT? Displays the set of five entered calibration
:GAIN <NRf> Sets the value of the gain for the output
:OFFSet <NRf> Sets the value of the offset for the output
:VOLTage N
:DAC <0+NR1> Sets the output of the output voltage D/A
:FIVEPOINT <1|2|3|4|5>
<0+NRf>
:FIVEPOINT? Displays the set of five entered calibration
:GAIN <NRf> Sets the value of the gain for the output
Sets the date last calibrated.
Order: Month Day Year.
Sets the due date for next calibration.
Order: Month Day Year
converter. The value range is 0 – 4095 for
12-bit operations; 0-65535 for 16-bit.
Sets the five current calibration values. N
current values.
current.
current.
converter. The value range is 0 - 4095 for
12-bit operations; 0-65535 for 16-bit.
Sets the five voltage calibration values. N
voltage values.
voltage.
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
M130/M131 Programming Manual 3-13
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
Command Description SCPI
:OFFSet <NRf> Sets the value of the offset for the output
voltage.
:PROTection N
:CALCulate Calculates the value of the gain and offset
for output overvoltage protection. This takes
more than 30 seconds to complete. Use
*ESE 1 and a serial poll to detect the
completed operation.
:DAC <0+NR1> Sets the output of the output overvoltage
protection D/A converter. The value range is
0 – 4095 for 12-bit operations; 0-65535 for
16-bit.
:GAIN <NRf> Sets the value of the gain for the output
overvoltage protection.
:OFFSet <NRf> Sets the value of the offset for the output
overvoltage protection.
:STORe Stores the calibration constants in non-
volatile memory.
:UNLock <string> Sets the non-volatile memory available to
store calibration constants. The access
string is “6867”.
N
N
N
N
N
N
N
3-14 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
3.6 MEASURE SCPI COMMAND SUBSYSTEM
3.6.1 MEASURE SCPI COMMAND SUMMARY
MEASure[n]
:CURRent?
:CURRent
:AVErage <value>
:AVErage?
:VOLTage?
: VOLTage
:AVErage <value>
:AVErage?
3.6.2 MEASURE SCPI COMMAND REFERENCE
Command Description SCPI
MEASure[n] Measure subsystem. n = 1-31. The default channel
is 1.
:CURRent? Returns the floating point value of the DC output
current in amps.
:CURRent
:AVErage <value> Enter a value of 1 to 5 to set the number of readings
to average together when returning the current
value from the MEAS:CURR? command. This
function reduces noise in the readback readings.
The (default) value of 1 provides the fastest
response time, but the noisiest readings. Available
for DLM600 Series firmware versions 1.08 and later.
:AVErage? Returns the number 1 to 5 to indicate the last set
number of readings to average together when taking
a current reading. Available for DLM600 Series
firmware versions 1.08 and later.
:VOLTage? Returns the floating point value of the DC output
voltage in volts.
: VOLTage
:AVErage <value> Enter a value of 1 to 5 to set the number of readings
to average together when returning the voltage
value from the MEAS:VOLT? command. This
function reduces noise in the readback readings.
The (default) value of 1 provides the fastest
response time, but the noisiest readings. Available
for DLM600 Series firmware versions 1.08 and later.
:AVErage? Returns the number 1 to 5 to indicate the last set
number of readings to average together when taking
a voltage reading. Available for DLM600 Series
firmware versions 1.08 and later.
C
C
—
—
C
—
—
M130/M131 Programming Manual 3-15
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3.7 OUTPUT SCPI COMMAND SUBSYSTEM
3.7.1 OUTPUT SCPI COMMAND SUMMARY
OUTPut[n]
:ISOLation <boolean>
:POLarity <NORM/0/OFF|INV/1/ON>
:PROTection
:DELay <0+NRf>
:FOLD <0|1|2>
:SENSe <boolean>
:STATe <boolean>
:TRIPped?
3.7.2 OUTPUT SCPI COMMAND REFERENCE
Command Description SCPI
OUTPut[n] Output subsystem. n = 1-31. The default
channel is 1.
:ISOLation <boolean> Sets the rear panel isolation relay control
signal ON or OFF. Valid arguments are 1/ON
or 0/OFF.
:POLarity <NORM/0/OFF|INV/1/ON> Changes the state of the polarity relay. This
command requires that the isolation relay be
open beforehand. If the isolation relay is
closed when this command is attempted, the
state of the polarity relay will not change,
and an error message will be generated.
:PROTection N
:DELay <0+NRf> Sets the programmable time delay executed
by the supply before reporting output
protection conditions after a new output
voltage or current is specified.
:FOLD <0|1|2> Sets the foldback (program down) mode of
the supply. Valid arguments are 0 (OFF or
do nothing, do not program down to zero), 1
(program down to zero upon entering
constant-voltage mode), or 2 (program down
to zero upon entering constant-current
mode).
:SENSe <boolean> Sets the sense relay signal open or close.
Valid arguments are 1/ON or 0/OFF.
:STATe <boolean> Sets the output to zero or the programmed
value; opens or closes the isolation relay.
Valid arguments are 1/ON or 0/OFF. *RST
state value is ON. CAUTION: Ensure that
suitable delays are incorporated to preclude
hot switching of the isolation relay.
:TRIPped? Returns the integer value 1 (TRIPPED) or 0
(UNTRIPPED) state of the output.
C
N
N
N
N
C
N
3-16 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
3.8 SOURCE SCPI COMMAND SUBSYSTEM
3.8.1 SOURCE SCPI COMMAND SUMMARY
SOURce[n]
:CURRent
[:LEVel]
[:IMMediate]
[:AMPLitude] <0+NRf>
:TRIGgered
:CLEar
[:AMPLitude] <0+NRf>
:LIMit
[:AMPLitude] <0+NRf>
:RAMP <0+NRf> <0+NRf>
:ABORt
:ALL?
:TRIGgered <0+NRf> <0+NRf>
:ONLine?
:STATus
:BLOCk?
:REGister?
:TIMeout?
:VOLTage
[:LEVel]
[:IMMediate]
[:AMPLitude] <NRf>
:TRIGgered
:CLEar
[:AMPLitude] <NRf>
:LIMit
[:AMPLitude] <NRf>
:PROTection
[:LEVel] <NRf>
:TRIPped?
:STATe?
:RAMP <NRf> <0+NRf>
:ABORt
:ALL?
:TRIGgered <NRf> <0+NRf>
M130/M131 Programming Manual 3-17
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3.8.2 SOURCE SCPI COMMAND REFERENCE
Command Description SCPI
SOURce[n] Source subsystem. n = 1-31. The default channel
is 1.
:CURRent Sets the output current in amps (default) or in
milliamps.
[:LEVel] Sets the output current in amps (default) or in
milliamps.
[:IMMediate] Sets the output current in amps (default) or in
milliamps.
[:AMPLitude] <0+NRf> Sets the output current in amps (default) or in
milliamps.
:TRIGgered Sets the value of the output current to be
implemented by the trigger.
:CLEar Clears the trigger mode.
[:AMPLitude] <0+NRf> Sets the value of the output current to be
implemented by the trigger.
:LIMit Sets an upper soft limit on the programmed
output current for the supply.
[:AMPLitude] <0+NRf> Sets an upper soft limit on the programmed
output current for the supply.
:RAMP <0+NRf> <0+NRf> Sets the output current to ramp from the present
value to the specified value (first argument) in the
specified time (second argument). See Ramp
Function description below.
:ABORt Aborts ramping and clears trigger mode.
:ALL? Returns the ramping status of all channels.
:TRIGgered <0+NRf>
<0+NRf>
:ONLine? Returns the integer value 1(ONLINE) or 0
:STATus
:BLOCk? Returns the block of data critical to the status of
Sets the output current to ramp from the present
value to the specified value (first argument) in the
specified time (second argument) upon the
trigger command. See Ramp description below.
(OFFLINE) of the channel online status.
the channel:
C
C
C
C
C
C
C
C
C
N
N
N
N
1) channel number
2) online status
3) status flags register (see table below)
4) status register (see sect. 5.2.2)
5) accumulated status (see sect. 5.2.2)
6) fault mask register (see sect. 5.2.2)
7) fault register (see sect. 5.2.2)
8) error register (see sect. 5.2.3)
9) model serial number
10) model voltage
11) model current
12) model over-voltage
3-18 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
Command Description SCPI
13) output voltage DAC gain
14) output voltage DAC offset
15) output current DAC gain
16) output current DAC offset
17) output voltage protection DAC gain
18) output voltage protection DAC offset
19) voltage measurement ADC gain
20) voltage measurement ADC offset
21) current measurement ADC gain
22) current measurement ADC offset
23) model string
24) OVP calibrated
Each value is separated by commas.
:REGister? Returns the integer value of the status register. N
:TIMeout? Returns the integer value 1 (timeout since last
N
query) or 0 (no timeout) of the timeout status of
the channel.
:VOLTage Sets the output voltage of the supply in volts
(default) or in millivolts. *See note on page
3-20.
[:LEVel] Sets the output voltage of the supply in volts
(default) or in millivolts. *See note on page
3-20.
[:IMMediate] Sets the output voltage of the supply in volts
(default) or in millivolts. *See note on page
3-20.
[:AMPLitude] <NRf> Sets the output voltage of the supply in volts
(default) or in millivolts. *See note on page
3-20.
:TRIGgered Sets the value of the output voltage to be
C
C
C
C
C
implemented by the trigger. For DLM600 Series
firmware versions 1.07 and later, the polarity
relay must be in the correct position per the
algebraic sign of the voltage to be triggered. The
state of the polarity relay may be set using the
OUTP:POL <
NORM | INV> command if it is not
already in the correct position. Do this before the
trigger command is issued.
For DLM600 Series firmware versions 1.06 and
earlier, the algebraic sign of the trigger voltage
determines the state of the polarity relay before
the voltage is triggered. Therefore, the user load
could be exposed to an unintended reverse
polarity voltage if the pre-trigger voltage had an
opposite algebraic sign from the trigger voltage.
For a pre-trigger voltage of zero, the above
consideration is not an issue.
:CLEar Clears the trigger mode.
M130/M131 Programming Manual 3-19
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
Command Description SCPI
[:AMPLitude] <NRf> Sets the value of the output voltage to be
C
implemented by the trigger. For DLM600 Series
firmware versions 1.07 and later, the polarity
relay must be in the correct position per the
algebraic sign of the voltage to be triggered. The
state of the polarity relay may be set using the
OUTP:POL <
NORM | INV> command if it is not
already in the correct position. Do this before the
trigger command is issued.
For DLM600 Series firmware versions 1.06 and
earlier, the algebraic sign of the trigger voltage
determines the state of the polarity relay before
the voltage is triggered. Therefore, the user load
could be exposed to an unintended reverse
polarity voltage if the pre-trigger voltage had an
opposite algebraic sign from the trigger voltage.
For a pre-trigger voltage of zero, the above
consideration is not an issue.
:LIMit Sets the upper soft limit on the programmed
C
output voltage.
[:AMPLitude] <NRf> Sets the upper soft limit on the programmed
C
output voltage.
:PROTection Sets the overvoltage protection trip point in volts
C
(default) or in millivolts.
[:LEVel] <NRf> Sets the overvoltage protection trip point in volts
C
(default) or in millivolts.
:TRIPped? Returns the integer value 1(TRIPPED) or 0
C
(UNTRIPPED) state of the overvoltage
protection.
:STATe? Returns the integer value 1 (ON) or 0 (OFF) state
C
of the overvoltage protection.
:RAMP <NRf> <0+NRf> Sets the output voltage to ramp from the present
N
value to the specified value (first argument) in the
specified time (second argument). See Ramp
Function description below.
:ABORt Aborts ramping and clears trigger mode.
:ALL? Returns the ramping status of all channels.
:TRIGgered <NRf>
<0+NRf>
Sets the output voltage to ramp from the present
value to the specified value (first argument) in the
N
specified time (second argument) upon the
trigger command. See description of the Ramp
Function below.
*Note: For DLM600 Series firmware versions 1.07 and later, the algebraic sign of the
voltage value must match the state of the polarity relay, otherwise an error message
will be generated, and the voltage command will be ignored. If the voltage value
entered is positive, then the polarity relay must be in the NORM state (query the
state of the polarity relay using the OUTP:POL? query command). If the voltage
value entered is negative, then the polarity relay must be in the INV state. For
DLM600 Series firmware versions 1.06 and earlier, the algebraic sign caused the
3-20 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
polarity relay to change automatically to the matching state. This automatic change
in the polarity relay state is no longer supported in firmware versions 1.07 and later.
To change the state of the polarity relay, use the OUTP:POL <INV | norm>
command (when the isolation relay is open). For DCS Series supplies, the polarity
relay still automatically follows the algebraic sign.
3.8.3 THE RAMP FUNCTION
The ramp function allows the user to transition from one voltage or current to
another linearly in a specified time period (100 ms - 99 sec with 100 ms
programming resolution). The ramp-upon-trigger function may be used to
program different ramping parameters for several units then trigger them all to
begin their ramps at the same time. A unit may ramp only voltage or current, not
both at a given time. For example, SOUR:VOLT:RAMP:TRIG 1 1 followed by
SOUR:CURR:RAMP:TRIG 2 2 will cause the unit to ramp only the output
current to 2 amps in 2 seconds upon the TRIG0:RAMP command.
Voltage ramping to a higher voltage requires a programmed current of at least
20% of the full scale value. Settings less than 20% will significantly lengthen the
ramp time due to charging of the large capacitance in the output section of the
power supply.
Voltage ramping to a lower voltage requires an appropriate resistive load. The
discharge rate of the large capacitance in the output section of the power
supply, plus other user capacitance, significantly lengthens the ramp time.
Current ramping requires an appropriate resistive load.
Note: On DCS and PRO-T models, the Reading of Voltage or Current during Ramping will
extend Ramp Time.
Table 3-7 SOURce[n]:STATus:BLOCK? "Status Flags" Register
Bit Hex Value Name Description
0 0x001 remote mode Remote mode was selected.
1 0x002 polarity signal
2 0x004 Not Used
3 0x008 Not Used
4 0x010 EEPROM The EEPROM is locked.
5 0x020 trip occurred Either an OV or OT trip occurred.
6 0x040 sense signal Sense relay signal is on.
Negative voltage programmed.
Polarity relay signal is on.
7 0x080 isolation signal Isolation relay signal is on.
8 0x100 hold Voltage and current output waiting for trigger.
9 0x200 fold Foldback protection is enabled.
10 0x400 Not Used
11 0x800 output Output is on.
M130/M131 Programming Manual 3-21
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3.9 STATUS SCPI COMMAND SUBSYSTEM
3.9.1 STATUS SCPI COMMAND SUMMARY
STATus[n]
:OPERation
:CONDition?
:ENABle <0+NR1>
:EVENt?
:PRESet
:PROTection
:CONDition?
:ENABle <0+NR1>
:EVENt?
:SELEct <0+NR1>
:QUEStionable
:CONDition?
:ENABle <0+NR1>
:EVENt?
3.9.2 STATUS SCPI COMMAND REFERENCE
Command Description SCPI
STATus[n] Status subsystem. n = 1-31. The default
channel is 1.
:OPERation C
:CONDition? Returns the integer value of the Operation
Condition Register. The query is supported
but will always return “0” indicating
operational condition.
:ENABle <0+NR1> Sets the enable mask of the Operation Event
Register allowing true conditions to be
reported in the summary bit of the Operation
Condition Register. Values are written and
queried but have no effect on the Operation
Condition Register.
:EVENt? Returns the integer value of the Operation
Event Register. This query is supported but
always returns a value of “0” indicating
operational condition.
:PRESet Sets the enable mask of the Operation Event
Register and the Questionable Event
Register to all 1’s.
C
C
C
C
C
3-22 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
Command Description SCPI
:PROTection C
:CONDition? Returns the integer value of the Protection
Condition Register. Used to read the status
of the power hardware. See section
a detailed table of the various bits that make
up this register.
:ENABle <0+NR1> Sets the enable mask of the Protection
Event Register, which allows true conditions
to be reported in the summary bit of the
Protection Condition Register.
:EVENt? Returns the integer value of the Protection
Event Register.
:SELEct <0+NR1> This command provides a means for
selecting which fault bits from the protection
event register (also called the fault register
and readable using the STAT:PROT:EVEN?
command) are able to set the protection
event flag bit in the SCPI status byte
(readable using the *STB? command). It
defaults to value 255 at power-on time, and
never changes unless intentionally
programmed to a new value. Available in the
DLM600 version of the M130 GPIB or
Ethernet option with firmware version 1.05 or
later. Not available in the DCS.
:SELEct? Queries the last selection value
programmed.
:QUEStionable C
:CONDition? Returns the integer value of the
Questionable Condition Register. The query
is supported but will always return “0”
indicating operational condition.
:ENABle <0+NR1> Sets the enable mask of the Questionable
Event Register allowing true conditions to be
reported in the summary bit of the
Questionable Condition Register. Values are
written and queried but have no effect on the
Questionable Condition Register.
:EVENt? Returns the integer value of the
Questionable Event Register. This query is
supported but always returns a value of “0”,
indicating operational condition.
3.2.3 for
C
C
C
N
N
C
C
C
M130/M131 Programming Manual 3-23
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3.10 SYSTEM SCPI COMMAND SUBSYSTEM
3.10.1 SYSTEM SCPI COMMAND SUMMARY
SYSTem
:ERRor?
:FAULt?
:VERsion?
SYSTem[n]
:LOCAL <boolean>
:LOCLOUT <boolean>
:SLAVEBAUD <NRf>
:SLAVEBAUD?
:UPGRADE
:NET
:AUTOIP <boolean>
:AUTOIP?
:DESC <string>
:DESC?
:DHCPMODE <boolean>
:DHCPMODE?
:DNS <string>
:DNS?
:GATE <string>
:GATE?
:HOST <string>
:HOST?
:IP <string>
:IP?
:LANLED BLINKON
:LANLED BLINKOFF
:LANLED?
:MAC?
:MASK <string>
:MASK?
:NETBUTTON <string>
:PINGRESP <boolean>
:PINGRESP?
:PORT <NRf>
:PORT?
:PRICONF <integer>
:PRICONF?
:SECCONF <integer>
:SECCONF?
:TERM <NRf>
:TERM?
3-24 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
3.10.2 SYSTEM SCPI COMMAND REFERENCE
Command
SYSTem
:ERRor?
:FAULt?
:VERsion?
SYSTem[n] System [channel number]
:LOCAL
System subsystem.
Queries Error Queue for next error/event entry
(first in, first out). Entries contain an error
number and descriptive text. A 0 return value
indicates no error occurred; negative numbers
are reserved by SCPI. The maximum return
string length is 255 characters. The queue holds
up to 10 error/entries. All entries are cleared by
the *CLS command.
Returns four numeric values separated by
commas for the four system fault registers. See
System Fault Registers below (e.g., 1, 1, 2, 4
indicates ch 1, 9, 18, and 27 each have at least
one fault).
Response: <Fault1–8>, <Fault9–16>,
<Fault17–24>, <Fault25–31>
Returns a numeric value corresponding to the
SCPI version number for which the instrument
complies. The response is in the format YYYY.V
where the Y’s represent the year and V
represents the approved version number for that
year (e.g., 1995.0)
SYST[N]:LOCAL <ON|OFF> is a special
purpose programming command that may be
used to cause source [N] to be set to the local
state or to the remote state. This command has
two noteworthy circumstances under which it
may prove necessary. The first case involves
using RS232 to communicate with the supply,
since the normal GPIB or Ethernet mechanisms
for transition between local and remote and
back again do not exist when using RS232. The
other case is when the REMOTE/LOCAL switch
S1-1 is placed in the ON position—thereby
disabling the GPIB or Ethernet mechanism for
transition from remote to local. The
SYST[N]:LOCAL ON command provides a
means for the system computer to force source
[N] to the local state. Also, the
SYST[N]:LOCAL? query command is available
to examine the local-remote state of the supply.
And the command SYST[N]:LOCAL OFF may
be used to force supply [N] to the remote state.
Description
SCPI
C
C
N
C
N
M130/M131 Programming Manual 3-25
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
Command
:LOCLOUT
:SLAVEBAUD?
:UPGRADE
:NET
:AUTOIP <boolean>
:AUTOIP?
:DESC <string>
:DESC?
:DHCPMODE <boolean>
:DHCPMODE?
:DNS <string>
:DNS?
Description
The SYST[N]:LOCLOUT <0|1|OFF|ON>
command provides a means of controlling the
local lockout functionality that is an alternative to
the low level GPIB or Ethernet LLO command. A
source number may be specified with this
command, thereby allowing selective disabling
of the front panel of a selected source.
In contrast, using the GPIB or Ethernet LLO low
level command causes the master supply, and
all attached online M131 slaves, to be placed
into the local lockout state. To place the master
and all online M131 slaves into the local lockout
state using the SYST[n]:LOCAL:LOCKOUT
command, specify the source number of 0.
To place only one slave into the local lockout
state, specify that slave in the command. For
example, if the slave is source 3, use the
command: SYST3:LOCAL:LOCKOUT 1.
Returns the baud rate for the slave.
Forces slave to jump to its boot loader.
Network device
Sets the network Auto IP mode in the Primary
configuration without affecting the Secondary
configuration..
0 = disable AutoIP; 1 = enable AutoIP
Returns 1 if AutoIP is enabled in the Primary
configuration.
Returns 0 if AutoIP is disabled in the Primary
configuration.
Set the network Description, a 64 character
alphanumeric string
Returns the network Description.
Sets the network DHCP Mode in the Primary
configuration without affecting the Secondary
configuration.
0 = disable DHCP; 1 = enable DHCP
Returns 1 if DHCP Mode is enabled in the
Primary configuration.
Returns 0 if DHCP mode is disabled in the
Primary configuration.
Sets the network DNS IP address for the device.
String is in the format “NNN.NNN.NNN.NNN”
where “NNN” = 0 through 255, inclusive.
Returns the network DNS address for the
device.
SCPI
3-26 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
Command
:GATE <string>
:GATE?
:HOST <string>
:HOST?
:IP <string>
:IP?
:LANLED BLINKON
:LANLED BLINKOFF
:LANLED?
:MAC?
:MASK <string>
:MASK?
:NETBUTTON <string>
:PINGRESP <boolean>
:PINGRESP?
Description
Sets the network gateway IP address for the
device. String is in the format
“NNN.NNN.NNN.NNN” where “NNN” = 0
through 255, inclusive.
Returns the network gateway address for the
device.
Set the network Host Name, a 15-character
alphanumeric string.
Returns the network Host Name, a 15 character
alphanumeric string.
Sets the Primary configuration to STATICIP
mode and sets the network IP address for the
device.
String is in the format “NNN.NNN.NNN.NNN”
where “NNN” = 0 through 255, inclusive.
Returns two IP addresses: the first is the IP
address set to be used when the system boots
up; the second is the IP address presently in
use by the power supply. (The first address will
either be 0.0.0.0. if the Primary configuration is
DHCP or DHCP+AUTOIP, or it will be the static
IP last specified).
Causes LANLED to blink.
Causes LANLED to stop blinking.
Returns blink state of the LAN LED:
0 – not blinking; 1 – blinking.
Returns the network MAC address.
xx:xx:xx:xx:xx:xx (Hexadecimal digit pairs)
Set the network Subnet Mask for the device.
String is in the format “NNN.NNN.NNN.NNN”
where “NNN” = 0 through 255, inclusive.
Returns the network Subnet Mask for the
device.
Returns configuration parameters to factory
default. (Software equivalent of pressing the
Reset switch on the rear panel of the power
supply). You must cycle the power to effect the
change.
The access string is “6867.”
Set ping response:
1 = unit responds to ping (response enabled).
0 = ping response is not enabled.
Returns 1 if ping response is enabled.
Returns 0 if ping response is not enabled.
SCPI
M130/M131 Programming Manual 3-27
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
Command
:PORT <NRf>
:PORT?
:PRICONF <integer>
:PRICONF?
:SECCONF <integer>
:SECCONF?
:TERM <NRf>
:TERM?
Description
Set the network TCP/IP socket listening port.
Valid values are 1025 to 65535.
Returns the network TCP/IP socket listening
port.
Sets Primary IP configuration.
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
Returns currently set Primary IP configuration
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
Sets Secondary IP configuration.
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
Returns
currently set Secondary IP configuration.
0 = DHCP; 1 = DHCPAUTOIP; 2 = STATICIP
Set the return string terminators to be used by
the device. The valid range is 1-4. Values
indicate the following terminator(s):
1 = 0x0d only (CR), 2 = 0x0a only (LF), 3 =
0x0d 0x0a (CR LF), 4 = 0x0a 0x0d (LF CR)
Returns the string terminators to be used by the
device.
SCPI
Table 3-8 System Fault Registers
Bit Position Bit Weight Fault1–8 Fault9–16 Fault17–24 Fault25–31
7 128 Channel 8 Channel 16 Channel 24 not used
6 64 Channel 7 Channel 15 Channel 23 Channel 31
5 32 Channel 6 Channel 14 Channel 22 Channel 30
4 16 Channel 5 Channel 13 Channel 21 Channel 29
3 8 Channel 4 Channel 12 Channel 20 Channel 28
2 4 Channel 3 Channel 11 Channel 19 Channel 27
1 2 Channel 2 Channel 10 Channel 18 Channel 26
0 1 Channel 1 Channel 9 Channel 17 Channel 25
The M130 provides four System Fault Registers to allow the user to monitor the fault status
of a multiple-channel system. For example, the user may poll these registers to quickly
determine which channel generated an enabled GPIB or Ethernet service request.
The SYStem:FAULt? query returns 4 numeric values separated by commas. Each value is
the decimal equivalent of the total bit weights for that System Fault Register as described
in the table above.
3-28 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
3.11 TRIGGER SCPI COMMAND SUBSYSTEM
3.11.1 TRIGGER SCPI COMMAND SUMMARY
TRIGger[n]
:ABORt
:RAMP
:TYPE <1|2|3>
3.11.2 TRIGGER SCPI COMMAND REFERENCE
Command Description SCPI
TRIGger[n] Trigger subsystem. N = 0, 1-31. The default
channel is 1. A value of n = 0 will program all
channels.
:ABORt Clears all settings of voltage and current
upon trigger.
:RAMP Implements current or voltage ramping
function previously programmed by the
SOURce:CURRent:RAMP or
SOURce:VOLTage:RAMP commands.
:TYPe<1|2|3> Implements voltage and current values
previously programmed by the
SOURce:CURRent:LEVel:TRIGger and
SOURce:VOLTage:LEVel:TRIGger
commands.
Valid arguments are 1 (Voltage),
2 (Current), or 3 (Both).
C
N
N
N
M130/M131 Programming Manual 3-29
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3.12 EXAMPLES OF USING THE SCPI COMMANDS
The following examples demonstrate programming a power supply to control and to
readback the output using the SCPI commands. The maximum voltage and current output
is dependent on the particular model. The examples list only the SCPI commands; the
code required to send the commands is dependent on the type of language you are using
(e.g., C or BASIC) and GPIB or Ethernet hardware (e.g., National Instruments).
EXAMPLE
output.
// Use SYST:ERR? after each command to verify no programming errors.
// turn on the unit.
*CLS // clear the unit to its power-on default settings.
*RST // reset the unit.
SOUR:CURR 1.0 // program output current to 1.0 A.
SOUR:CURR? // confirm the output current setting (response: 1.0).
SOUR:VOLT 5.0 // program output voltage to 5.0 VDC.
SOUR:VOLT? // confirm the output voltage setting (response: 5.0).
MEAS:CURR? // measure the actual output current (response: ~ 0.0 with no load
MEAS:VOLT? // measure the actual output voltage (response: ~ 5.0).
EXAMPLE
or Ethernet OVP Fault upon an overvoltage protection trip condition (must use GPIB or
Ethernet, not RS-232).
// Use SYST:ERR? after each command to verify no programming errors.
// Turn on the unit.
*CLS // clear the unit to its power-on default settings.
*RST // reset the unit.
SOUR:VOLT:PROT 4.0 // program the OVP trip point to 4.0 VDC.
SOUR:VOLT:PROT? // confirm the OVP trip point setting (response: 4.0).
SOUR:CURR 1.0 // program output current to 1.0 A.
SOUR:VOLT 3.0 // program output voltage to 3.0 VDC.
STAT:PROT:ENABLE 8 // program the unit to report OVP trip.
STAT:PROT:ENABLE? // confirm that OVP fault is enabled (response: 8).
STAT:PROT:EVENT? // confirm no faults occurred (response: 0).
// confirm that the OVP LED is not active.
SOUR:VOLT 7.0 // program output voltage to 7.0 VDC - cause OVP trip!
// confirm that OVP LED is active.
: Program a unit with no load at the output to 5 VDC @ 1A, and verify the
on output).
: Program a unit with no load at the output to generate a GPIB service request
3-30 M130/131 Programming Manual
Sorensen Ethernet Option IEEE 488.2 and SCPI Command Operation
EXAMPLE: Program a unit with no load at the output to change its output voltage and
current to 5 VDC @ 1A at the same time.
// Use SYST:ERR? after each command to verify no programming errors.
// turn on the unit.
*CLS // clear the unit to its power-on default settings.
*RST // reset the unit.
SOUR:CURR:TRIG1.0 // program output current to 1.0 A upon trigger.
SOUR:CURR:TRIG? // confirm output current set to 1.0 A upon trigger.
SOUR:VOLT:TRIG5.0 // program output voltage to 5.0 VDC upon trigger
SOUR:VOLT:TRIG? // confirm output current set to 5.0 VDC upon trigger.
MEAS:CURR? // measure the actual output current (response: 0.0).
MEAS:VOLT? // measure the actual output voltage (response: 0.0).
TRIG:TYPE 3 // trigger the unit to implement curr and volt programming.
MEAS:CURR? // measure the actual output current (response: ~ 0. 0 with no
load on output).
MEAS:VOLT? // measure the actual output voltage (response: ~ 5.0).
TRIG:ABORT // turn off trigger mode.
EXAMPLE
VDC to 25 VDC in 30 seconds.
Note: The maximum output voltage is dependent upon the power supply rating.
// Use SYST:ERR? after each command to verify no programming errors.
// turn on the unit.
*CLS // clear the unit to its power-on default settings.
*RST // reset the unit.
SOUR:CURR 33.0 // program output current to 33.0 A.
SOUR:VOLT 5.0 // program output voltage to 5.0 VDC.
SOUR:VOLT:RAMP 25.0 30.0 // program voltage to ramp from the present
// value (5.0 VDC) to 25.0 VDC in 30 seconds.
EXAMPLE
25A in 30 seconds.
// Use SYST:ERR? after each command to verify no programming errors.
// turn on with no load at the output.
*CLS // clear the unit to its power-on default settings.
*RST // reset the unit.
// short the output.
SOUR:VOLT 33.0 // program output voltage to 33.0 VDC.
SOUR:CURR 5.0 // program output current to 5.0 A.
SOUR:CURR:RAMP 25.0 30.0 // program current to ramp from the present
// value (5.0 A) to 25.0 A in 30 seconds.
: Program a unit with no load at the output to ramp its output voltage from 5
: Program a unit with the output shorted to ramp its output current from 5A to
M130/M131 Programming Manual 3-31
IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
EXAMPLE: Program a unit with no load at the output to ramp its output voltage from
5 VDC to 25 VDC in 30 seconds upon the trigger command.
// Use SYST:ERR? after each command to verify no programming errors.
// turn on the unit.
*CLS // clear the unit to its power-on default settings.
*RST // reset the unit.
SOUR:CURR 33.0 // program output current to 33.0 A.
SOUR:VOLT 5.0 // program output voltage to 5.0 VDC.
SOUR:VOLT:RAMP:TRIG 25.0 30.0 // program voltage to ramp from the present
// value (5.0 VDC) to 25.0 VDC in 30 secs.
// upon the trigger command.
TRIG:RAMP // start ramp execution.
TRIG:ABORT // turn off trigger mode.
EXAMPLE
protection level of 3 VDC. Verify proper power-on initialization.
// Use SYST:ERR? after each command to verify no programming errors.
// turn on the unit.
*CLS // clear the unit to its power on default settings.
*RST // reset the unit.
CAL:INIT:CURR 1.0 // set power-on initial current to 1.0 A.
CAL:INIT:CURR? // confirm power-on initial current setting.
CAL:INIT:VOLT 2.0 // set power-on initial voltage to 2.0 VDC.
CAL:INIT:VOLT? // confirm power-on initial voltage setting.
CAL:INIT:VOLT:PROT 3.0 // set power-on initial overvoltage protection to 3.0 VDC.
CAL:INIT:VOLT:PROT? // confirm power-on initial overvoltage protection setting.
CAL:UNLOCK “6867” // unlock nonvolatile memory for calibration value storage.
CAL:STORE // store the calibration values in nonvolatile memory.
CAL:LOCK // lock nonvolatile memory for calibration value protection.
// cycle power to the unit.
// note voltage is initialized to 2.0 VDC via front panel.
SOUR:CURR? // confirm power-on initial current setting.
SOUR:VOLT? // confirm power-on initial voltage setting.
SOUR:VOLT:PROT? // confirm power-on initial overvoltage protection setting.
: Program a unit to power-on and initialize to 2 VDC @ 1A with an overvoltage
3-32 M130/131 Programming Manual
SECTION 4
CALIBRATION
WARNING
Please refer to the power supply manual for further information before performing
calibration procedures. Qualified personnel who appropriately deal with attendant
hazards must perform calibration. If calibration is not performed properly,
functional problems could arise, requiring that the supply be returned to the
factory.
4.1 INTRODUCTION
The supply is calibrated to adjust internal signal levels to correspond to the expected
supply output signal levels. You must perform the calibration procedures if the power
supply’s programming or readback performance falls out of specification due to
component aging drifts. Refer to your power supply manual to find the required
calibration interval. The supply also is calibrated for output voltage programming,
output current programming, output overvoltage protection programming, voltage
readback, and current readback. There are 10 calibration factors (four measurement
and six output).
The calibration procedures in the following sections are designed to be performed at
ambient temperature of 25°C +
load for at least 30 minutes.
The following test equipment is required in addition to the computer system to
complete the following calibration:
• 6-digit digital voltmeter (DVM)
• current shunt rated for 110% of full output current
5°C, after the unit has had a stable output and a stable
M130/M131 Programming Manual 4-1
Calibration Sorensen Ethernet Option
4.2 SETUP FOR CALIBRATION
STEP DESCRIPTION
1. Disconnect the power supply’s AC input power.
2. Disconnect the load from the power supply you want to calibrate.
3. Connect the power supply for sensing at the required load point. Refer to the
power supply manual for further information.
4. Connect the DVM to the output for voltage or overvoltage calibration, or
connect a current shunt rated for the full output current of the supply and the
DVM for current calibration.
5. Assure the correct primary address has been set by the rear panel switch.
6. Set the power supply to REMOTE mode by the rear panel switch.
7. Connect the GPIB or Ethernet controller to the power supply at the rear panel
connector.
8. Reconnect the AC input power. Turn the unit on and allow the unit to warm
up for at least 30 minutes.
9. The unit is ready for all calibration procedures, to be followed in the order
presented.
10. Once calibration is completed, new values for Last Calibration Date and Next
Calibration Date may be entered. See Section
WARNING
Exercise caution when using and servicing power supplies. High energy levels
can be stored at the output voltage terminals on all power supplies in normal
operation. In addition, potentially lethal voltages exist in the power circuit and the
output connector on power supplies that are rated at 60V and over. Filter
capacitors store potentially dangerous energy for some time after power is
removed.
4.8.
4-2 M130/M131 Programming Manual
Sorensen Ethernet Option Calibration
4.3 VOLTAGE PROGRAMMING CALIBRATION
The following procedures are for five-point calibration:
STEP
DESCRIPTION
1. Issue a *CLS[n] command.
2. Issue a *RST[n] command.
3. Program the overvoltage protection to maximum to prevent nuisance trips:
CAL[n]:OUTP:VOLT:PROT:DAC 65535
4. Program the output current to full scale to prevent Constant-Current
operation:
CAL[n]:OUTP:CURR:DAC 65535
5. Program the output of the first calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:VOLT:DAC 3275
6. Let the output settle and measure the voltage with a high precision voltmeter;
this is value 1.
7. Enter the actual output voltage value of the first calibration point:
CAL[n]:OUTP:VOLT:FIVEPOINT 1 <value 1>
8. Program the output of the second calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:VOLT:DAC 19000
9. Let the output settle and measure the voltage with a high precision voltmeter;
this is value 2.
10. Enter the actual output voltage value of the second calibration point:
CAL[n]:OUTP:VOLT:FIVEPOINT 2 <value 2>
11. Program the output of the third calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:VOLT:DAC 32000
12. Let the output settle and measure the voltage with a high precision voltmeter;
this is value 3.
M130/M131 Programming Manual 4-3
Calibration Sorensen Ethernet Option
13. Enter the actual output voltage value of the third calibration point:
CAL[n]:OUTP:VOLT:FIVEPOINT 3 <value 3>
14. Program the output of the fourth calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:VOLT:DAC 45000
15. Let the output settle and measure the voltage with a high precision voltmeter;
this is value 4.
16. Enter the actual output voltage value of the fourth calibration point:
CAL[n]:OUTP:VOLT:FIVEPOINT 4 <value 4>
17. Program the output of the fifth calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:VOLT:DAC 62250
18. Let the output settle and measure the voltage with a high precision voltmeter;
this is value 5.
19. Enter the actual output voltage value of the fifth calibration point:
CAL[n]:OUTP:VOLT:FIVEPOINT 5 <value 5>
20. To review entered data for five–point voltage calibration, issue the following
query:
CAL[n]:OUTP:VOLT:FIVEPOINT?
21. Program the supply to unlock the non-volatile memory for calibration value
storage:
CAL[n]:UNLOCK “6867”
22. Program the supply to store the calibration values in non-volatile memory:
CAL[n]:STORE
Allow 10 seconds for the non-volatile memory to be updated with the
new calibration values.
23. Program the supply to lock the non-volatile memory for calibration value
protection.
CAL[n]:LOCK
24. The output voltage calibration is complete. The unit may be turned off or
other calibration procedures may be performed.
4-4 M130/M131 Programming Manual
Sorensen Ethernet Option Calibration
4.4 VOLTAGE MEASUREMENT/READBACK CALIBRATION
STEP DESCRIPTION
1. Program the overvoltage protection to maximum to prevent nuisance trips:
CAL[n]:OUTP:VOLT:PROT:DAC 65535
2. Program the output current to full scale to prevent Constant-Current
operation:
CAL[n]:OUTP:CURR:DAC 65535
3. Program the output of the first calibration point to approximately 15% of full
scale voltage by sending the following command string from the computer:
CAL[n]:OUTP:VOLT:DAC 6500
4. Let the output settle and measure the voltage with the meter.
5. Enter the actual voltage readback corresponding to the DAC value 6500 of
the first calibration point:
CAL[n]:MEAS:VOLT:POINT 1 <voltage>
6. Program the output of the second calibration point to approximately 85% of
full scale voltage by sending the following command string from the
computer:
CAL[n]:OUTP:VOLT:DAC 57500
7. Let the output settle and measure the voltage with the meter.
8. Enter the actual voltage readback corresponding to the DAC value 57500 of
the second calibration point:
CAL[n]:MEAS:VOLT:POINT 2 <voltage>
9. Reset the output voltage to 0 volts.
CAL[n]:OUTP:VOLT:DAC 0
10. Program the M130 to calculate the voltage readback calibration gain and
offset values:
CAL[n]:MEAS:VOLT:CALC
11. Program the supply to unlock the non-volatile memory for calibration value
storage:
CAL[n]:UNLOCK “6867”
M130/M131 Programming Manual 4-5
Calibration Sorensen Ethernet Option
12. Program the supply to store the calibration values in non-volatile memory:
CAL[n]:STORE
Allow 10 seconds for the non-volatile memory to be updated with the
new calibration values.
13. Program the supply to lock the non-volatile memory for calibration value
protection
CAL[n]:LOCK
14. The voltage readback calibration is complete. The unit may be turned off or
other calibration procedures may be performed.
4.5 OVERVOLTAGE PROTECTION PROGRAMMING
The overvoltage protection calibration procedure requires calibrated output voltage
programming and voltage readback.
STEP
DESCRIPTION
1. Program the supply to self-calibrate the overvoltage protection:
CAL[n]:OUTP:VOLT:PROT:CALC
The overvoltage protection calibration function requires over 30 seconds.
2. Program the supply to unlock the non-volatile memory for calibration value
storage:
CAL[n]:UNLOCK “6867”
3. Program the supply to store the calibration values in non-volatile memory:
CAL[n]:STORE
Allow 10 seconds for the non-volatile memory to be updated with the
new calibration values.
4. Program the supply to lock the non-volatile memory for calibration value
protection
CAL[n]:LOCK
5. The output overvoltage protection calibration is complete. The unit may be
turned OFF or other calibration procedures may be performed.
4-6 M130/M131 Programming Manual
Sorensen Ethernet Option Calibration
4.6 CURRENT PROGRAMMING CALIBRATION
Attach a high precision shunt between the power supply’s output terminals and attach
a high precision voltmeter across the shunt.
STEP
DESCRIPTION
1. Issue a *CLS[n] command.
2. Issue a *RST[n] command
3. Program the overvoltage protection to maximum to prevent nuisance trips:
CAL[n]:OUTP:VOLT:PROT:DAC 65535
4. Program the output voltage to full scale to prevent Constant-Voltage
operation:
CAL[n]:OUTP:VOLT:DAC 65535
5. Program the output of the first calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:CURR:DAC 3275
6. Let the output settle and measure the output current with the current shunt
and the high precision voltmeter; this is value 1.
7. Enter the actual output current of the first calibration point:
CAL[n]:OUTP:CURR:FIVEPOINT 1 <value 1>
8. Program the output of the second calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:CURR:DAC 19000
9. Let the output settle and measure the output current with the current shunt
and the high precision voltmeter; this is value 2.
10. Enter the actual output current of the second calibration point:
CAL[n]:OUTP:CURR:FIVEPOINT 2 <value 2>
11. Program the output of the third calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:CURR:DAC 32000
12. Let the output settle and measure the output current with the current shunt
and the high precision voltmeter; this is value 3.
M130/M131 Programming Manual 4-7
Calibration Sorensen Ethernet Option
13. Enter the actual output current of the third calibration point:
CAL[n]:OUTP:CURR:FIVEPOINT 3 <value 3>
14. Program the output of the fourth calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:CURR:DAC 45000
15. Let the output settle and measure the output current with the current shunt
and the high precision voltmeter; this is value 4.
16. Enter the actual output current of the fourth calibration point:
CAL[n]:OUTP:CURR:FIVEPOINT 4 <value 4>
17. Program the output of the fifth calibration point by sending the following
command string from the computer:
CAL[n]:OUTP:CURR:DAC 62250
18. Let the output settle and measure the output current with the current shunt
and the high precision voltmeter; this is value 5.
19. Enter the actual output current of the fifth calibration point:
CAL[n]:OUTP:CURR:FIVEPOINT 5 <value 5>
20. To review entered data for five–point current calibration, issue the following
query:
CAL[n]:OUTP:CURR:FIVEPOINT?
21. Program the supply to unlock the non-volatile memory for calibration value
storage:
CAL[n]:UNLOCK “6867”
22. Program the supply to store the calibration values in non-volatile memory:
CAL[n]:STORE
Allow 10 seconds for the non-volatile memory to be updated with the
new calibration values.
23. Program the supply to lock the non-volatile memory for calibration value
protection:
CAL[n]:LOCK
24. The output current calibration is complete. The unit may be turned off or other
calibration procedures may be performed.
4-8 M130/M131 Programming Manual
Sorensen Ethernet Option Calibration
4.7 CURRENT MEASUREMENT/READBACK CALIBRATION
STEP DESCRIPTION
1. Program the overvoltage protection to maximum to prevent nuisance trips:
CAL[n]:OUTP:VOLT:PROT:DAC 65535
2. Program the output voltage to full scale to prevent Constant-Voltage
operation:
CAL[n]:OUTP:VOLT:DAC 65535
3. Program the output of the first calibration point to approximately 15% of full
scale current by sending the following command string from the computer:
CAL[n]:OUTP:CURR:DAC 6500
4. Let the output settle and measure the current with the current shunt and the
meter.
5. Enter the actual current readback corresponding to the DAC value 6500 of
the first calibration point:
CAL[n]:MEAS:CURR:POINT 1 <current>
6. Program the output of the second calibration point to approximately 85% of
full scale current by sending the following command string from the computer:
CAL[n]:OUTP:CURR:DAC 57500
7. Let the output settle and measure the current with the current shunt and the
meter.
8. Enter the actual current readback corresponding to the DAC value 57500 of
the second calibration point:
CAL[n]:MEAS:CURR:POINT 2 <current>
9. Reset the output current to 0 amps.
CAL:OUTP:CURR:DAC 0
10. Program the supply to calculate the current readback calibration gain and
offset values:
CAL[n]:MEAS:CURR:CALC
11. Program the supply to unlock the non-volatile memory for calibration value
storage:
CAL[n]:UNLOCK “6867”
M130/M131 Programming Manual 4-9
Calibration Sorensen Ethernet Option
12. Program the supply to store the calibration values in non-volatile memory:
CAL[n]:STORE
Allow 10 seconds for the non-volatile memory to be updated with the
new calibration values.
13. Program the supply to lock the non-volatile memory for calibration value
protection
CAL[n]:LOCK
14. The current readback calibration is complete. The unit may be turned OFF or
other calibration procedures may be performed.
4.8 UPDATE OF NON-VOLATILE CALIBRATION DATES
This procedure allows the user to store, in non-volatile memory, the date of the last
calibration (LASTCALDATE) and the date for the next due calibration
(NEXTCALDATE).
1. Program the supply with the date of the most recent calibration:
CAL[n]:MOD:LASTCALDATE <MM> <DD> <YYYY>
(e.g. CAL1:MOD:LASTCALDATE 07 31 2005)
2. Program the supply with the date of the next calibration (normally 1 year from last
calibration):
CAL[n]:MOD:NEXTCALDATE <MM> <DD> <YYYY>
3. Program the supply to unlock the non-volatile memory for calibration value
storage:
CAL[n]:UNLOCK “6867”
4. Program the supply to store the calibration values in non-volatile memory:
CAL[n]:STORE
Allow 10 seconds for the non-volatile memory to be updated with the
new calibration values.
5. Program the supply to lock the non-volatile memory for calibration value
protection
CAL[n]:LOCK
6. The unit may be turned OFF or other calibration procedures may be
performed.
4-10 M130/M131 Programming Manual
OPERATION WITH M131 OPTION
5.1 INTRODUCTION
The following sections describe the operation of the power supply with the M131
option and how to configure the option for your application.
The M131 option enables you to use your power supply as an auxiliary unit. The
master unit would be a power supply with the M130 interface option. The auxiliary unit
or units share the Ethernet address or RS-232 interface with the master unit. Up to 30
auxiliary units can be controlled by the master unit.
This option can be used with the DLM600 and DCS 1kW and 3kW supplies and
supports the SCPI language.
SECTION 5
5.2 CONFIGURATION
The S1 DIP switch is accessible from the rear panel. It allows configuration of the
M131 for auxiliary operation.
DLM600 and the DCS 3k power supplies with the M131 option, configured as an
auxiliary at channel 2, in remote mode.
Note: Only the Remote/Local switch is used for Ethernet.
Figure 5-1. DLM600W Configuration for M131 set to Channel 2
M130/M131 Programming Manual 5-1
Figure 5-1 shows an example of switch settings for the
Operation with M131 Option Sorensen Ethernet Option
Figure 5-2 shows an example of switch settings for the DLM600 with the M6 option
and the DCS 1k and 1.2k power supplies with the M131 option, configured as an
auxiliary at channel 8, in remote mode.
Note: Only the Remote/Local switch is used for Ethernet.
Figure 5-2. Switch Configuration for M6 or M131 set to Channel 8
Table 5-1 Definitions of S1 Switch Settings
Switch ON OFF
S1-1 Remote control Local control
S1-2 Not used. Not used.
S1-3 Not applicable. Must be OFF. Unit operates as an auxiliary unit.
S1-4–8
S1-4
S1-5
S1-6
S1-7
S1-8
Note: Channel numbers 0 and 1 are invalid for any auxiliary device, because the M130
implementation of the SCPI language reserves channel 0 for the “global” address to
address all channels, and it reserves channel number 1 as the default number for the
master channel.
Set channel number for unit in binary:
Binary 1 ON
Binary 2 ON
Binary 4 ON
Binary 8 ON
Binary 16 ON
(Channels 0 and 1 see note below.)
Binary 1 OFF
Binary 2 OFF
Binary 4 OFF
Binary 8 OFF
Binary 16 OFF
5-2 M130/M131 Programming Manual
Sorensen Ethernet Option SCPI Status Implementation
5.3 SYSTEM INSTALLATION
Follow the steps below, illustrated in Figure 5-3, to install the configured M131 into
your system:
1. Configure the M131 as described in the Configuration section above.
2. Connect the master unit’s RS-485 output connector, J2, to the auxiliary unit’s RS485 input connector, J1, using the modular cable.
3. If there are additional auxiliary units, connect the installed auxiliary unit’s RS-485
output connector, J2, to the additional auxiliary unit’s RS-485 input connector, J1,
using the modular cable.
4. Connect the 120 ohm resistive termination assembly to the last auxiliary unit’s J2
connector.
5. Connect power to the system, power it up, and verify that the green REMOTE
LED on the front panel is ON.
6. Test the link by communicating with the auxiliary unit from the master unit, using
the *IDN[n]? command. Note that [n] is the channel number—for example,
*IDN2? calls channel 2. (In response to this string, the system returns the power
supply model number and the firmware version.)
NOTE: The slave baud rate is 9600.
Figure 5-3. RS-485 System Interconnection with Two Auxiliaries
M130/M131 Programming Manual 5-3
Operation with M131 Option Sorensen Ethernet Option
5.4 RS-485 INTERFACE
The RS-485 interface is accessible through the two rear-panel, 6-pin, RJ-11
connectors, J1 and J2, depicted in
Figure 5-4. M131 Rear Panel RS-485 Connectors Pinout
Figure 5-4.
5.5 PROGRAMMING THE M131 UNIT (EXAMPLE)
The following example programs the M131 unit to:
• Turn on
• Initialize to 2 VDC, at 1A
• Set overvoltage protection level at 3 VDC
• Verify proper power-on initialization
• Save and store changes.
// Use SYST:ERR? after each command to verify no programming errors.
// turn on the unit.
*CLS // clear the unit to its power on default settings.
*RST // reset the unit.
CAL[n]:INIT:CURR 1.0 // set power-on initial current to 1.0A.
CAL[n]:INIT:CURR? // confirm power-on initial current setting.
CAL[n]:INIT:VOLT 2.0 // set power-on initial voltage to 2.0V.
CAL[n]:INIT:VOLT? // confirm power-on initial voltage setting.
CAL[n]:INIT:VOLT:PROT 3.0 // set power-on initial overvoltage protection to 3.0V.
CAL[n]:INIT:VOLT:PROT? // confirm power-on initial overvoltage protection setting.
CAL[n]:UNLOCK “6867” // unlock nonvolatile memory for calibration value storage.
CAL[n]:STORE // store the calibration values in nonvolatile memory.
CAL[n]:LOCK // lock nonvolatile memory for calibration value protection.
// cycle power to unit.
// note voltage is initialized to 2.0 VDC via front panel.
SOUR[n]:CURR? // confirm power-on initial current setting.
SOUR[n]:VOLT? // confirm power-on initial voltage setting.
SOUR[n]:VOLT:PROT? // confirm power-on initial overvoltage protection setting.
5-4 M130/M131 Programming Manual
A
Accuracy
programming, 4
readback, 4
C
CALibrate[n], 3-12
Calibration, 4-1
Current Measurement/Readback
Calibration, 4-9
Current Programming, 4-7
Current Programming Calibration, 4-7
Overvoltage Protection Programming
Calibration, 4-6
Setup for Calibration, 4-2
Voltage Measurement/Readback
Calibration, 4-5
Voltage Programming, 4-3
Voltage Programming Calibration, 4-3
Warning, 4-1, 4-2
Calibration Dates,
Non-Volatile Update, 4-10
Calibration SCPI Command
Reference, 3-13
Summary, 3-12
Calibration SCPI Command Subsystem, 3-
12
Communication Methods, 2-13
Configuration
Ethernet/Lan, 3
Conventions, 3-9
[ ], 3-9
E
Error/Event Queue, 3-4
INDEX
SCPI Error Codes, 3-4
Examples of Using SCPI Commands, 3-34
External User Control Signal Connector
FAULT output signal, 2-10
FOLDBACK output signal, 2-10
ISOLATION output signal, 2-10
POLARITY output signal, 2-10
SENSE output signal, 2-10
SHUTDOWN TTL input signal, 2-10
SYNC output signal, 2-10
External User Control Signal Connector, 2-
10
Illustration of Open Collector, TTL Input,
and Relay Output Circuits, 2-13
Warning, 2-13
F
Features, 1
Function
Ramp, 3-24
Functions
Programmable, 2
Readback, 2
I
IEEE-488.2 and SCPI Conformance
Information, 3-8
IEEE-488.2 Common Command
Subsystem, 3-10
*CLS, 3-10
*ESE, 3-10
*ESR?, 3-10
*IDN?, 3-10
*OPC, 3-10
*RST, 3-10
*SRE, 3-10
M130/M131 Programming Manual Index-1
Operation with M131 Option Sorensen Ethernet Option
*STB?, 3-11
*TST?, 3-11
*WAI, 3-11
IEEE-488.2 Register Definitions, 3-1
L
Local Operation, 2-9
M
Measure SCPI Command
Reference, 3-16
Summary, 3-16
Measure SCPI Command Subsystem, 3-16
MEASure[n], 3-16
Multiple Source Control with the M131
Option, 2-32
RS-485 Rear Panel RJ-11 Connector
Pinout, 2-32
O
Operation Status and Questionable Status
Registers, 3-4
Operation, M131, 5-1
Output SCPI Command
Reference, 3-18
Summary, 3-18
Output SCPI Command Subsystem, 3-18
OUTPut[n], 3-18
P
Parameter Definitions, 3-8
0+NR1, 3-8
0+NRf, 3-8
boolean, 3-8
NR1, 3-8
NRf, 3-8
string, 3-8
Power-On Conditions, 2-9
Default, 2-9
Programming
accuracy, 4
resolution, 4
Protection Event Status Register, 3-3
Q
Queries, 3-9
R
Ramp Function, 3-24
Ramping
Description, 3-24
Raw Socket Interface, 2-13
Readback
accuracy, 4
resolution, 4
Rear Panel Configuration Switch
Remote/Local Selection, 2-9
Rear Panel Configuration Switch S1, 2-8
Register Definitions
IEEE-488.2, 3-1
Remote Operation, 2-9
Remote Programming via RS-232, 2-31
Resolution
programming, 4
readback, 4
RS-485 Interface, 5-4
S
SCPI
Conformance Information, 3-8
Error Codes, 3-4
Operation Status, 3-4
Parameter Definitions, 3-8
Protection Condition/Event Status
Registers, 3-3
Questionable Status Registers, 3-4
Standard Event Status Register (ESR), 3-
2
Status Byte, 3-1
SCPI Command Operation, 3-1
CALibrate[n], 3-12
MEASure[n], 3-16
OUTPut[n], 3-18
Warning, 3-19
SOURce[n], 3-19
STATus[n], 3-25
TRIGgered[n], 3-32
SCPI Commands
examples of using, 3-34
Serial Poll Operation, 3-6
Setup Procedure, 2-1
Source SCPI Command
Reference, 3-21
Summary, 3-19
Source SCPI Command Subsystem, 3-19
SOURce[n], 3-19
Specifications, 3
Standard Event Status Register (ESR), 3-2
Index-2 M130/M131 Programming Manual
Sorensen Ethernet Option Index
Status Byte, 3-1
Status Flags Register, 3-24
Status SCPI Command
Reference, 3-25
Summary, 3-25
Status SCPI Command Subsystem, 3-25
STATus[n], 3-25
Switch Settings, M131, 5-2
Synchronization Pulse, 2-10
System Installation, M131, 5-3
System SCPI Command
Reference, 3-29
Summary, 3-28
System SCPI Command Subsystem, 3-28
T
Trigger SCPI Command
Reference, 3-32
Summary, 3-32
Trigger SCPI Command Subsystem, 3-32
TRIGgered[n], 3-32
U
Units, 3-9
W
Web Server, 2-13
Configuration page, 2-17
Home page, 2-15
Login window, 2-15
Security page, 2-24
Settings page, 2-20
Slave Info page, 2-29
Status page, 2-22
Troubleshooting, 2-29
