Page 1
FEATURES:
• Touchless operation limits the spread of germs for a safer
restroom.
• CR-P2 lithium battery Included
• Battery Life: 7 years @ 150 uses per day
• Includes 4" C-C deck plate and pop-up drain
• Above-Deck Mixing: Allows user to manually adjust
temperature. Adjustable hot limit stop. Red & blue indicators.
• Dual Inlets: For hot and cold water. Check valves included
to prevent cross ow. Filter assemblies protect the solenoid
valve from debris.
• Clean, Integrated Design: All electronics contained in
faucet spout. No control box below deck.
• Easy Installation & Maintenance: Faucet installs from the
top. All serviceable parts are easily accessible.
• Flexible Selectronic® Platform with programmable sensor.
• Adjustable Range: Detection zone can be adjusted
manually or with optional remote control.
• Fail-Safe: Faucet automatically shuts off upon loss of power
or dead battery. No reset required.
• Optional Remote Control Allows for Customization
- Metering Function
- Safety Timer
- Cleaning Mode
- Thermal Disinfection
- Comfort Timer
• Lead-Free: Faucet contains ≤ 0.25% total lead content by
weighted average.
Clean-IR
™
INTEGRATED TOUCHLESS LAVATORY FAUCET
WITH ABOVE-DECK MIXING, BATTERY POWERED
MODEL NUMBER:
■ DC POWERED
❑ 7020255.002 0.5 gpm pressure compensating,
vandal-resistant multi-laminar spray.
❑ 7020255.295 0.5 gpm pressure compensating,
vandal-resistant multi-laminar spray.
■ OPTIONAL Remote Control
❑ 605XRCW Remote control adjusts setup
parameters and allows for customization
of functions.
DESCRIPTION:
Deck-mount electronic faucet with proximity operation.
Integrated design with sensor, solenoid valve and
electronics enclosed in the spout. Above-deck mixing
with hot limit safety stop and red / blue indicators.
Water pressure range from 20 - 120 psi. Vandal-resistant
single-post mounting. Dual inlets for hot and cold water.
Pre-installed 24" exible inlet hoses with lter assembly
and 3/8" compression tting.
RECOMMENDED SPECIFICATION:
Electronic, sensor-operated lavatory faucet shall feature a programmable sensor and an electronically operated solenoid valve. Integrated
design with all electronics enclosed in the spout. Features above deck mixing with hot limit safety stop and red / blue indicators. Shall
also feature a vandal resistant metal body with single-post mounting. Shall meet ANSI A112.18.1 and ANSI 117.1 codes. Model shall be
American Standard # 7020255.002, 7020255.295.
© 2022 AS America Inc.
1/22
Page 2
Clean-IR
™
INTEGRATED TOUCHLESS LAVATORY FAUCET
WITH ABOVE-DECK MIXING, BATTERY POWERED
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112 .18 .1
CSA B 125
NSF 372
NSF 61
MEETS THE AMERICAN DISABILITIES ACT GUIDELINES AND
ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND
USABLE BUILDING FACILITIES-CHECK LOCAL CODES
FINISHES:
Polished Chrome .002
Brushed Nickel .295
175 mm
(6-15/16")
2.0
1.5
1.0
0.5
GALLONS PER MINUTE
0.0
20
INLET PRESSURE (PSI)
72 mm
(2-13/16")
FLOW RATE*
0.5 gpm
100806040
597 mm
(23-1/2")
116 mm
(4-9/16")
35 mm
(1-3/8")
148 mm
121 mm
(4-13/16")
3/8" COMPRESSION
(5-13/16")
CONNECTOR
60 mm
(2-3/8")
© 2022 AS America Inc.
1/22
