American Dynamics IPS05D3ICWIY, IPS05D2OCWTY, IPS03D3ICBTT, IPS03D2OCWIT, IPS03D2ICWTT Specsheet

PRO

Mini-Domes

Features That Make a Difference:

• Superior low light performance

• Face detection and blur detection

• 3 and 5 megapixel resolutions

• Quick and easy installation and
configuration

• One-touch focus and motorized zoom

• Multiple motorized lens options

• Reduced storage cost with H.264
and integrated region of interest (ROI)
bandwidth management analytics

• Up to five individual programmable
regions of interest

• True WDR in 3MP Mini-Dome options

• IP66 and IK10 ratings

The Illustra Pro IP Mini-Domes provide crisp
and clear high-definition video, at full frame
rates. Whether in bright sun, near darkness
or blackout conditions, you can clearly see
important details, such as license plates,
merchandise labels, and faces.

Installation is simple and easy with no
additional cost or hardware. The cameras
include various integrated mounting options
including hard surface and electric box. On
indoor cameras, a plenum cap is included
as well as mounting clips for recessed flush
installation. Configuration is simplified using
the most common web browsers to access
the browser-based camera interface for
feature control including one-touch focus and

motorized zoom. Illustra Connect, a powerful
remote management and configuration
software tool, makes set up and installation
even easier.

Using onboard motion-detection, and
advanced, integrated analytics, the Illustra
Pro Mini-Domes reduce your ongoing cost of
operation by minimizing the cost of storage
while ensuring image quality. The IP66 and
IK10 rated outdoor Mini-Domes are rugged
and durable providing a vandal resistant
enclosure, water ingress protection, and dust
ingress protection. The Mini-Domes can be
powered using PoE or 24Vac. The outdoor
Mini-Dome can operate in temperatures as
low as -40°C when powered using 24Vac.

www.illustracameras.com

Specifications

Spec Indoor Outdoor

Operational

Video Compression H.264, MJPEG H.264, MJPEG
Max Frame Rate
(primary stream)

H.264

MJPEG
ONVIF-Compliant Yes Yes
Analogue Video Output 1.0 Vp-p, BNC pigtail included 1.0 Vp-p, BNC pigtail included
Resolution 3MP and 5MP

Imager 1/3.2˝ CMOS progressive scan 1/3.2˝ CMOS progressive scan
Day/Night Yes Yes
IR Illumination Optional Yes Yes
Motion Detection Yes Yes
Face Detection Yes Yes
Privacy Zones Yes Yes
Alarms I/O 2/1 2/1
Video Streams 3 streams plus analog out 3 streams plus analog out
Minimum Illumination

Color

B/W

With IR
Dynamic Range 3MP: TWDR 96dB

Field of View (H/V)

Wide Angle

Telephoto
Lens Type Motorized varifocal Motorized varifocal

Network

Interface Ethernet 10/100Base-TX Ethernet 10/100Base-TX
Ethernet Port RJ-45 RJ-45
Supported Protocols TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery,

Configuration Management

Web Browser IE 10, 11. Firefox, Chrome IE 10, 11. Firefox, Chrome
Security Multi-level, IP address filtering, HTTPS, User access log, IEEE 802.1x Multi-level, IP address filtering, HTTPS, User access log, IEEE 802.1x

Onboard Storage

Card Support Standard SD format up to 4GB, SDHC format up to

Pre-alarm Recording Yes Yes
Recording Format AVI AVI
Playback Via browser using FTP Via browser using FTP
Recording Trigger Dry contact alarms, motion detection, face detection Dry contact alarms, motion detection, face detection

Simultaneous Users

Electrical

Power Input 24VAC, PoE IEEE 802.3af Class 3 24VAC, PoE IEEE 802.3af Class 3
Power Draw 12.95W 12.95W

Physical

Dimensions (WxH) 130 x 138 mm (5.12 x 5.43 in) 135 x 160 mm (5.31 x 6.30 in)
Weight 1 kg (2.20 lbs) 1.8 kg (3.97 lbs)
Housing Color White or black White or black
Operating Temperature -10° to 40°C (14° to 104°F) PoE: -30° to 50°C (-22° to 122°F)

Vandal Resistant IK10 IK10
Outdoor Rating N/A IP66
Plenum-Rated Ye s N/A

Regulatory

Emissions EN 55022 Class A; FCC Part 15 Class A;

Immunity EN 50130-4; EN55024 EN 50130-4; EN55024
Safety EN 60950-1; UL 60950-1

3MP 3-9mm

0.05 lux

0.003 lux

DNS, DDNS, RTP, TLS, Unicast, Multicast, NTP, SMTP, WS-Security

3MP

2048x1536@30fps
1920x1440@30fps

(2048x1536) QXGA 4:3

(1920x1440) 4:3

(1600x1200) UXGA 4:3

(1280x960) SXGA 4:3

3MP 9-22mm

0.06 lux

-

ICES-003/NMB-003 Class A; AS/NZS CISPR 22 Class A

0.004 lux

-

5MP: WDR 90dB

3-9mm

88°/64°
30°/22°

32GBytes and SDXC up to 128GBytes

CSA 22.2 No. 60950-1; IEC 60950-1

(1024x768) 1024 XGA 4:3

5MP 3-9mm

0.3 lux

0.02 lux

Ten Te n

5MP

2592x1944@15fps
1920x1440@15fps

(1920x1080) 1080p 16:9

(1280x720) 720p 16:9

(1024x576) PAL+ 16:9

-

9-22mm

28°/21°

12°/9°

2048x1536@30fps
1920x1440@30fps

(768x576) 4:3

(640x480) 640 VGA 4:3

(640x360) nHD 16:9

(480x360) 480 4:3

5MP (and all resolutions listed above)

(2592x1944) 4:3

5MP 9-22mm

0.4 lux

0.03 lux

-

TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS,

RTP, TLS, Unicast, Multicast, NTP, SMTP, WS-Security

Standard SD format up to 4GB, SDHC format up to

ICES-003/NMB-003 Class A; AS/NZS CISPR 22 Class A

3MP

2592x1944@15fps
1920x1440@15fps

(384x288) 4:3
(384x216) 16:9

3-9mm

0.3 lux

0.02 lux

0.0 lux

3MP: TWDR 96dB

5MP: WDR 90dB

3-9mm

88°/64°
30°/23°

32GBytes and SDXC up to 128GBytes

24VAC: -40° to 50°C (-40° to 122°F)

EN 55022 Class A; FCC Part 15 Class A;

EN 60950-1; UL 60950-1

CSA 22.2 No. 60950-1; IEC 60950-1

5MP

Mounts and Accessories

Pendant / Gooseneck Mounts

Integrated recessed mount

Accessories

Adapter Image Model Number Description

Mounting Options

Mount Image Model Number Description

Flush

Mount

Pendant

Cap

Wall

Mount

ADCiM6FLUSHOW

ADCiM6FLUSHOB

ADCi6DPCAPIW

ADCi6DPCAPIB

ADCi6DPCAPOW
ADCi6DPCAPOB

ADCiM6WALLWK
ADCiM6WALLBK

Flush Mount Kit:

Outdoor Dome,

White/Black

Pendant Cap:

Indoor,

White/Black

Pendant Cap:

Outdoor,

White/Black

Wall Mount Kit:

Indoor/Outdoor,

White/Black

Gooseneck

Arm

Outside

Corner

Mount

Adapter

Electrical

Box

Adapter

Pole Mount

Adapter

ADLOMARM - White
ADCBMARM - Black

ADCDMCRNRO

ADCPWMELEC

ADCDMPOLE

For use with

Pendant Cap

For use with Pendant

Cap and Gooseneck

Arm, or directly to the

camera back plate.

Use with additional

mounting options

such as the UK

single- and double-

gang boxes. This

provides a threaded
connection directly to
the rear of the Illustra

600/610 back plate

and versatile screw

options.

For use with Pendant

Cap and Gooseneck

Arm, or directly to the

camera back plate.

ILLUSTRA SERIES MODEL RESOLUTION FORM FACTOR LENS ENVIRONMENT

I E = Essentials L = Lite 01 = 1MP B = Bullet N = None N = None N = None B = Black C = Color Only N = No A = Hardware Update

F = Flex P = Plus 02 = 2MP C = Compact

P = Pro S = Standard 03 = 3MP D = Dome 0 = 1.8—3mm B = Outdoor NonVandal S = Smoked S = Silver S = Soft Day/Night Y = Yes
Q = Edge 05 = 5MP F = Fisheye 1 = 2.8—12mm I = Indoor Vandal W = White T = TDN

Dome

M = Mini-Bullet 2 = 3—9mm O = Outdoor Vandal
P = PTZ 3 = 9—22mm
W = Wireless Cube 4 = 9—40mm
X = Box 5 = 20x

F = Fixed A = Indoor NonVandal C = Clear G = Gray I = TDN w/IR T = Multi-

6 = 30x

HOUSING

BUBBLE COLOR DAY/NIGHT/IR WDR OTHER

Exposure
(>60 Frames)

ILLUSTRA CAMERA MODEL KEY

3 MP Mini-Domes

IPS03D2ICWTT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, clear, white, TDN, TWDR
IPS03D2ICWIT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, clear, white, TDN w/IR, TWDR
IPS03D2OCWTT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, clear, white, TDN, TWDR
IPS03D2OCWIT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, clear, white, TDN w/IR, TWDR
IPS03D2ISWTT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, smoked, white, TDN, TWDR
IPS03D2ISWIT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, smoked, white, TDN w/IR, TWDR
IPS03D2OSWTT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, smoked, white, TDN, TWDR
IPS03D2OSWIT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, smoked, white, TDN w/IR, TWDR
IPS03D2ICBTT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, clear, black, TDN, TWDR
IPS03D2ICBIT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, clear, black, TDN w/IR, TWDR
IPS03D2OCBTT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, clear, black, TDN, TWDR
IPS03D2OCBIT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, clear, black, TDN w/IR, TWDR
IPS03D2ISBTT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, smoked, black, TDN, TWDR
IPS03D2ISBIT Illustra Pro 3MP Mini-dome, 3-9mm, indoor, vandal, smoked, black, TDN w/IR, TWDR
IPS03D2OSBTT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, smoked, black, TDN, TWDR
IPS03D2OSBIT Illustra Pro 3MP Mini-dome, 3-9mm, outdoor, vandal, smoked, black, TDN w/IR, TWDR
IPS03D3ICWTT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, clear, white, TDN, TWDR
IPS03D3ICWIT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, clear, white, TDN w/IR, TWDR
IPS03D3ISWTT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, smoked, white, TDN, TWDR
IPS03D3ISWIT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, smoked, white, TDN w/IR, TWDR
IPS03D3ICBTT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, clear, black, TDN, TWDR
IPS03D3ICBIT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, clear, black, TDN w/IR, TWDR
IPS03D3ISBTT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, smoked, black, TDN, TWDR
IPS03D3ISBIT Illustra Pro 3MP Mini-dome, 9-22mm, indoor, vandal, smoked, black, TDN w/IR, TWDR

5 MP Mini-Domes

IPS05D2ICWTY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, clear, white, TDN, WDR
IPS05D2ICWIY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, clear, white, TDN w/IR, WDR
IPS05D2OCWTY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, clear, white, TDN, WDR
IPS05D2OCWIY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, clear, white, TDN w/IR, WDR
IPS05D2ISWTY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, smoked, white, TDN, WDR
IPS05D2ISWIY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, smoked, white, TDN w/IR, WDR
IPS05D2OSWTY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, smoked, white, TDN, WDR
IPS05D2OSWIY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, smoked, white, TDN w/IR, WDR
IPS05D2ICBTY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, clear, black, TDN, WDR
IPS05D2ICBIY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, clear, black, TDN w/IR, WDR
IPS05D2OCBTY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, clear, black, TDN, WDR
IPS05D2OCBIY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, clear, black, TDN w/IR, WDR
IPS05D2ISBTY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, smoked, black, TDN, WDR
IPS05D2ISBIY Illustra Pro 5MP Mini-dome, 3-9mm, indoor, vandal, smoked, black, TDN w/IR, WDR
IPS05D2OSBTY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, smoked, black, TDN, WDR
IPS05D2OSBIY Illustra Pro 5MP Mini-dome, 3-9mm, outdoor, vandal, smoked, black, TDN w/IR, WDR
IPS05D3ICWTY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, clear, white, TDN, WDR
IPS05D3ICWIY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, clear, white, TDN w/IR, WDR
IPS05D3ISWTY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, smoked, white, TDN, WDR
IPS05D3ISWIY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, smoked, white, TDN w/IR, WDR
IPS05D3ICBTY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, clear, black, TDN, WDR
IPS05D3ICBIY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, clear, black, TDN w/IR, WDR
IPS05D3ISBTY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, smoked, black, TDN, WDR
IPS05D3ISBIY Illustra Pro 5MP Mini-dome, 9-22mm, indoor, vandal, smoked, black, TDN w/IR, WDR
