American Dynamics IES01CFACWSY Specsheet

Essentials

IP Indoor Mini-Dome Camera

Features That Make a Difference:

• 1 and 2 megapixels

• H.264 and MJPEG dual-stream encoding

• Maximum 30 ips

• Multiple network monitoring

• 3.6mm ﬁxed lens

• PoE

• Soft Day/Night

• Wide Dynamic Range

The Illustra Essentials Indoor Mini-Domes are available in 1 and 2 megapixel options. With features such as Soft Day/Night and Wide Dynamic Range, these indoor mini-domes can capture video in various lighting conditions. These cameras are easy to install and fit a variety of indoor applications.

Low Light Clarity

The Illustra Essentials Indoor Mini-Dome cameras master low-light clarity. The sensitivity of the sensor and processor combination is enabled through the latest technology, such as Soft Day/Night. In low light, these cameras deliver clear video surveillance.

Poor low-light performance by megapixel cameras hampers some of the most important tasks security professionals need to perform. When cameras lack clarity in low light, they also tend to increase bandwidth usage and storage costs. Cameras that fail in low-light clarity negatively impact both the necessary functions of security and cost of ownership.

Wide Dynamic Range

For applications where the glare of direct sunlight may affect surveillance, WDR is a must-have feature. Only the best performing cameras can manage the contrast created by the backlighting that direct sunlight can produce.

The Illustra Essentials Indoor Mini-Domes take advantage of the latest pixel-by-pixel dynamic range offered today. Avoid loss of detail in strongly backlit scenes with the power of WDR. Maintain the details in faces with whole scene clarity. WDR works with the megapixel lens to enhance the precision of the image for a high-resolution HD solution that excels in a wide range of challenging lighting conditions.

www.illustracameras.com

Speciﬁcations

1MP 2MP

Camera

Imager 1/4˝ 1/3˝ Resolution 1280 x 720 1920 x 1080 Shutter Speed Auto/manual, 1/3(4) – 1/10000s Auto/manual, 1/3(4) – 1/10000s Minimum Illumination Color: 0.1Lux/F1.2 Color: 0.1Lux/F1.6 S/N Ratio More than 50dB More than 50dB Analog Video Output N/A N/A

Camera Features

IR Illuminator N/A N/A Day/Night Auto(Electronic)/Color/B/W Auto(Electronic)/Color/B/W Backlight Compensation Yes Yes Wide Dynamic Range WDR WDR White Balance Auto/Manual Auto/Manual Gain Control Auto/Manual Auto/Manual Digital Noise Reduction 3D 2D Privacy Zones Up to 4 areas Up to 4 areas

Lens

Focal Length 3.6mm Fixed 3.6mm Fixed Max Aperture F1.8 F1.6 Focus Control Manual Manual Angle of View H: 70° H: 71.9°

Video

Video Compression H.264/MJPEG H.264/MJPEG Resolutions 720p (1280 x 720); D1 (704 x 576/704 x 480);

CIF (352 x 288/352 x 240)

Max Frame Rate Main Stream: 720p (30ips);

Sub Stream: D1/CIF (30ips)

Audio N/A N/A

Network

Ethernet RJ-45 (10/100Base-T) RJ-45 (10/100Base-T) Wi-Fi N/A N/A Supported Protocols IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP,

RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour

ONVIF-compliant ONVIF Proﬁle S ONVIF Proﬁle S

Auxiliary Interface

Onboard Storage N/A N/A Alarm Input/Output N/A N/A

General

Power Supply DC12V, PoE (802.3af) DC12V, PoE (802.3af) Power Consumption <1.5W Max 3W Operating Temperature -30°C to +60°C (-22°F to +140°F) -30°C to +60°C (-22°F to +140°F) IP Rating N/A N/A Vandal Resistant N/A N/A Dimensions 110mm x 54mm (4.33in x 2.13in) 110mm x 54mm (4.33in x 2.13in) Menu Languages Chinese (simpliﬁed), English (default), French, German, Portuguese, Spanish English (default), French, German, Portuguese, Spanish Weight 0.2kg (0.44lb) 0.39kg (0.86lb)

1080p (1920 x 1080); 720p (1280 x 720); D1 (704 x 576/704 x 480)

CIF (352 x 288/352 x 240)

Main Stream: 1080p/720p (30ips);

Sub Stream: D1/CIF (30ips)

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP,

RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
