Page 1
VideoEdge
DESKTOP NETWORK VIDEO RECORDER
Manage a Comprehensive Environment from the
Convenience of a Desktop
The VideoEdge Desktop Network Video Recorder (NVR) offers a powerful recording
solution in a convenient form factor. By connecting a monitor to the Desktop NVR, security
operators can instantly view a real-time camera feed for ongoing surveillance. The
hardware offers a video recording solution targeted for deployments with less than 32 IP
cameras, providing up to 6TB of storage and 100 Mbps of video recording throughput.
VideoEdge NVRs also feature an advanced open architecture and can add and reassign
camera and analytic licenses at any time.
The victor client and VideoEdge hardware platforms improve the efficiency of security
personnel and daily business operations by creating a powerful video management
solution that allows users to leverage high-performance video streaming, analytics, video
intelligence and a leading-edge feature set for streamlined command and management.
FEATURES THAT MAKE A DIFFERENCE
• NEW! RESTRICT CAMERA ACCESS
PERMISSIONS BASED ON USER ROLES
FOR ENHANCED SYSTEM SECURITY
• NEW! IP I/O MODULE INCREASES
FLEXIBILITY WHEN CRAFTING
SOLUTIONS THAT REQUIRE INPUT AND
OUTPUT DEVICES
• MAXIMIZE STREAMING RESOURCES BY
ACCEPTING TRIPLE VIDEO STREAMS
FROM THE CAMERA TO THE NVR
• END TO END MULTICAST ADDS THE
ABILITY TO VIEW CAMERAS DIRECTLY
FROM A VICTOR CLIENT WHEN AN NVR
IS UNDERGOING SYSTEM UPDATES
* See victor Professional and Enterprise data sheets for more information on centralized licensing
• H.264+ AND H.265 SUPPORT HIGHER
RESOLUTIONS WHILE REDUCING
NECESSARY STORAGE SPACE
• TRICKLESTOR PROVIDES COST-
EFFECTIVE REDUNDANCY BY STORING
VIDEO ON SELECT ILLUSTRA CAMERAS
WHEN NETWORK CONNECTION IS LOST
• LICENSE PLATE RECOGNITION ANALYTIC
OFFERS REAL-TIME OR FORENSIC
ALARMS OF KNOWN VEHICLE PLATES
TO DETECT UNWANTED INTRUDERS
• NVR LICENSES CAN BE CENTRALLY
LOCATED ON THE VICTOR SERVER FOR
EASE OF ACCESS AND DOWNLOAD*
www.americandynamics.net
• SMARTSTREAM MANAGES SUPERIOR
VIDEO QUALITY IN CONSTRAINED
ENVIRONMENTS
• IP CAMERA AUTO DISCOVERY ALLOWS
FOR QUICK SYSTEM SETUP
• ONVIF PROFILE S CONFORMANT
FOR SIMPLIFIED VIDEO STREAMING
INTEGRATIONS
• COMPLIES WITH THE CYBER
PROTECTION PRODUCT SECURITY
PROGRAM
Page 2
Hardware Specifications
Specification Description
Camera Type
Max # of Cameras
Operating System
OS Drive
Network Interface
RAID Controller
Video Storage
Power Supply
Redundant Power Supply
Max BTU
Monitor Interface
Max. Digital Monitors
VideoEdge Client
Video Recording
Throughput
Dimensions (W x H x D)
Regulatory
1
50 Mbps if VideoEdge Client is used
FCC Part 15, Class A; CE: EN55022, Class A; CE: EN6100-3-2; 3-3; ICES-003/NMB-003,Class A; AS/NZS CISPR22,
Class A Immunity CE: EN50130-4 CE: EN55024 Safety UL 60950-1 (2nd Ed); IEC/EN 60950-1; CSA C22.2 60950-1,
VideoEdge OS built on openSUSE Linux
IP
32
Single 500 GB
2 x 1 GigE NiCs
None
0, 2, 4, 6 TB
300W, 100~240VAC
No
700
1 DVI, 1 VGA, 1 HDMI
1
Yes
100 Mbps
39.7 x 10.9 x 34.9 cm
(15.6 x 4.3 x 13.75 in)
UL 2900-2-3 Level 3
1
Page 3
VideoEdge
DESKTOP NETWORK VIDEO RECORDER SPECIFICATIONS
Ordering Information
Model Numbers Description
VideoEdge Desktop NVR
ADVED00N0N4G VideoEdge Desktop NVR, 0 TB storage, 2 NIC
ADVED02N0N4G VideoEdge Desktop NVR, 2 TB JBOD, 2 NIC
ADVED04N0N4G VideoEdge Desktop NVR, 4 TB JBOD, 2 NIC
ADVED06N0N4G VideoEdge Desktop NVR, 6 TB JBOD, 2 NIC
VideoEdge NVR Accessories
ADVEDRACKKIT1 VideoEdge Desktop Rack Mount Kit Brackets
www.americandynamics.net
Camera Connection Licenses*
Model Numbers Description
ADVEC01 VideoEdge NVR Add-on 1 IP Cam license
*Not required with premium Illustra Pro cameras
**For analytic ordering information, see Video Intelligence, Facial Biometric and License Plate Recognition data sheets
Related Products Approvals
Client
© 2018 Tyco Security Products. All Rights Reserved. AD1127-DS-201809-R05-HS-EN
Tyco and the product names listed above are marks and/or registered marks. Unauthorized use is strictly prohibited. Product offerings and specifications are subject to change
without notice. Actual products may vary from photos. Not all products include all features. Availability varies by region; contact your sales representative.
RAID Storage
Illustra IP Camerasvictor Unified
Software House
C•CURE 9000
