Stacked Multi-Chip Package (MCP) Flash Memory and SRAM

Am29DL323D Top Boot 32 Megabit (4 M x 8-Bit/2 M x 16-Bit) CMOS 3.0 Volt-only,
Simultaneous Operation Flash Memory and 4 Mbit (512 K x 8-Bit/ 256 K x 16-Bit) Static RAM

DISTINCTIVE CHARACTERISTICS
MCP Features

■ Power supply voltage of 2.7 to 3.3 volt

■ High performance

— 90 ns maximum access time

■ Package

— 73-Ball FBGA

■ Operating Temperature

— –25°C to +85°C

Flash Memory Features

ARCHITECTURAL ADVANTAGES

■ Simultaneous Read/Write oper at io ns

— Data can be continuously read from one bank while

executing erase/program functions in other bank

— Zero latency between read and write operations

■ Secured Silicon (SecSi) Sector: Extra 64 KByte sector

— Factory locked and identifiable: 16 bytes available for

secure, random factory Electronic Serial Number; verifiable
as factory locked through autoselect function.

— Customer lockable: Can be read, programmed, or erased

just like other sectors. Once locked, data cannot be changed

■ Zero Power Operation

— Sophisticated power management circuits reduce power

consumed during inactive periods to nearly zero

■ Top boot block

■ Manufactured on 0.23 µm process technology

■ Compatible with JEDEC standards

— Pinout and software compatible with single-power-supply

flash standard

PERFORMANCE CHARACTERISTICS

■ High performance

— Access time as fast 70 ns
— Program time: 7 µs/word typical utilizing Accelerate function

■ Ultra low power consump tion (typical values)

— 2 mA active read current at 1 MHz
— 10 mA active read current at 5 MHz
— 200 nA in standby or automatic sleep mode

■ Minimum 1 mill i on write cycl es guaranteed per sector

■ 20 Year data retention at 125°C

— Reliable operation for the life of the system

SOFTWARE FEATURES

■ Data Management Software (DMS)

— AMD-supplied software manages data programming and

erasing, enabling EEPROM emulation

— Eases sector erase limitations

■ Supports Common Flash Memory Interface (CFI)

■ Erase Suspend/Erase Resume

— Suspends erase operations to allow programming in same

bank

■ Data# Polling and Toggle Bits

— Provides a software method of detecting the status of

program or erase cycles

■ Unlock Bypass Program command

— Reduces overall programming time when issuing multiple

program command sequences

HARDWARE FEATURES

■ Any combination of sectors can be erased

■ Ready/Busy# output (RY/BY#)

— Hardware method for detecting program or erase cycle

completion

■ Hardware reset pin (RESET#)

— Hardware method of resetting the internal state machine to

reading array data

■ WP#/ACC input pin

— Write protect (WP#) function allows protection of two outermost

boot sectors, regardless of sector protect status

— Acceleration (ACC) function accelerates program timing

■ Sector protection

— Hardware method of locking a sector, either in-system or

using programming equipment, to prevent any program or
erase operation within that sector

— Temporary Sector Unprotect allows changing data in

protected sectors in-system

SRAM Features

■ Power dissipation

— Operating: 50 mA maximum
— Standby: 7 µA maximum

■ CE1s# and CE2s Chip Select

■ Power down features us in g C E 1s # and CE2s

■ Data retention supply voltage: 1.5 to 3.3 volt

■ Byte data control: LB#s (DQ0–DQ7), UB#s (DQ8–DQ15)

This document contains information on a product under development at Advanced Micro Devices. The information
is intended to help you evaluate thi s product. AMD reserves t he right to chan ge or discontinue work o n this proposed
product without notice.

Refer to AMD’s Website (www.amd.com) for the latest information.

Publication# 24218 Rev: B Amendment/1
Issue Date: March 15, 2001

GENERAL DESCRIPTION
Am29DL323 Features

The Am29DL323 is a 32 megabit, 3.0 volt-only flash
memory devices, organiz ed as 2,097, 152 words of 16
bits each or 4,194,304 bytes of 8 bits each. Word
mode data appears on DQ0–DQ15; byte mode data
appears on DQ0–DQ7. The device is designed to be
programmed in-system with the standard 3.0 volt V
supply, and can also be programm ed in standard
EPROM programmers.

The device is available with an access time of 90 ns.
The device is offered in a 73-ball FBGA package.
Standard con trol pins—chip enable (CE#f), write en­able (WE#), and out put enab le (OE #)—c ontro l nor mal
read and write operations, and avoid bus contention
issues.

The device requires only a single 3.0 volt power sup-
ply for both read and write functions. Internally
generated and regulated voltag es are pr ovided for the
program and erase operations.

CC

Simultaneous Read/Write Ope rations with
Zero Latency

The Simultaneous Read/Write architecture provides
simultaneous operation by dividing the memory
space into two banks. The device can improve overall
system performance b y a llowi ng a hos t sy ste m to pr o­gram or erase in one bank, then immediately and
simultaneously read from the othe r bank, with zero la­tency. This releases the system from waiting for the
completion of program or erase operations.

The Am29DL323D has 8 M b in Bank 1 and 24 Mb in
Bank 2.

The Secured Silicon (SecSi) Sector is an extra 64
Kbit sector capable of being permanently lo cked by
AMD or customers. The SecSi Sector Indicator Bit
(DQ7) is permane ntly set to a 1 if the part is factory
locked, and set to a 0 if c ustomer lockable. This
way, customer lockable parts ca n nev er be us ed to re ­place a factory locked part.

Factory locked parts provide several options. The
SecSi Sector may store a secu re, random 16 by te
ESN (Electronic Serial Number). Customer Lockable
parts may utilize the Sec Si Sector as bonus space ,
reading and writing like any other flash sector, or may
permanently lock their own code there.

DMS (Data Management Software) allows systems
to easily take ad vantag e of the adva nced ar chitec ture

of the simultaneous read/write product line by allowing
removal of EEPROM devices. DMS will also allow the
system software to be simplified, as it will p erform all
functions necessary to modify data in file structures,
as opposed to single-byte modi fications. To write or
update a particular piece of data (a phone number or
configuration data, for example), the user only needs
to state which piece of data is to be updated, and
where the updated data is located in the system. This
is an advantage compared to systems where
user-written software must keep tr ack of the old da ta
location, status, logical to physical translation of the
data onto the Flash memory device (or m emory de­vices), and more. Using DMS, user-written software
does not need to interface with the Flash memory di­rectly. Instead, the user's software accesses t he Fl ash
memory by calling one of onl y six func tions . AMD pro­vides this software to simplify system design and
software integration efforts.

The device offers complete compatibility with the

JEDEC single-power-supply Flash command set
standard. Commands ar e written to the comman d

register using standard microprocessor write timings.
Reading data out of the device is similar to reading
from other Flash or EPROM devices.

The host system can detect whether a program or
erase operation is complete by using the device sta-
tus bits: RY/BY# pin, DQ7 (D ata# Polling) and
DQ6/DQ2 (toggle bits). After a program or erase cycle
has been completed, the device automatically returns
to reading array data.

The sector erase architecture allows memory sec­tors to be erased and reprogra mmed withou t affecting
the data contents of other sectors. The device is fully
erased when shipped from the factory.

Hardware data protection measures include a low

detector that automatically inhibits write opera-

V

CC

tions during power transitions. The hardware secto r
protection feature disables both program and erase
operations in any combination of the sectors of mem­ory. This can be achieved in-system or via
programming equipment.

The device offers two power-saving features. Whe n
addresses have been sta ble f or a spe cified am ount o f
time, the device enters the automatic sleep mode.
The system can also place the device into the
standby mode. Power consumption is greatly re­duced in both modes.

2 DS42553
