AMD 7ZMMC User Manual

Download

7ZMMC

AMD AthlonTM/Duron

USER'S MANUAL

AMD AthlonTM/DuronTM Socket A Processor Motherboard

Socket A Processor Motherboard

REV. 2.01 First Edition

R-201-01-010205

FCC Compliance Statement:

DECLARATION OF CONFOR M I TY

Per FCC Part 2 Section 2. 1077(a)

This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to

Responsible Party Name: G.B. T. I NC.

Phone/Fax No: (818) 854-9338/ (818) 854-9339

hereby declares that the product

Product Name:

Model Number:

Conforms to the following specificatio ns:

FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), Class B Digital Device

Supplementary Information:

This device complies with part 15 o f the FCC Rules. Operation is subject to the following two conditions: ( 1 ) This device may not cause harmful and (2) this device must accept any inference received, including that may cause undesired operation.

Representative Person's Name: ERIC LU

Signature:

Address: 18305 Valley Blvd., Suite#A

Mother Board

Date: Jan. 15, 2001

LA Puent, CA 91744

GA-7ZMMC

Eric Lu

provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television equipment reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna

-Move the equipment away from the receiver

-Plug the equipment into an outlet on a circuit different from that to which the receiver is connected

-Consult the dealer or an experienced radio/television technician for additional suggestions

You are cautioned that any change or modifications to the equipment not expressly approve by the party responsible for compliance could void Your authority to operate such equipment.

This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions 1) this device may not cause harmful interference and 2) this device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity

We, Manufacturer/Importer

(full address)

G.B. T. Technology Träding GMbH

Ausschlager Weg 41, 1F, 20537 Hamburg, Germany

( description of the apparatus, system, installation to which it refers)

(reference to the specification under which conformity is declared)

in accordance with 89/336 EEC-EMC Directive

EN 55011 Limits and methods of measurement EN 61000-3-2* Disturbances in supply systems caused

EN55013 Limits and methods of measurement EN61000-3-3* Disturbances in supply systems caused

EN 55014 Limits and methods of measurement EN 50081-1 Generic emission standard Part 1:

EN 55015 Limits and methods of measurement EN 55081-2 Generic emission standard Part 2:

EN 55020 Immunity from radio interference of EN 55082-2 Generic immunity standard Part 2:

EN 55022 Limits and methods of measurement ENV 55104 Immunity requirements for household

DIN VDE 0855 Cabled distribution systems; Equi pm ent EN 50091- 2 EMC requirements for uninterruptible part 10 for receiving and/or distribution from power systems (UPS) part 12 sound and television signals

of radio disturbance characteristics of industrial, scientific and medical (ISM electrical equipment “Harmonic s” high frequency equipment

of radio disturbance characteristics of broadcast receivers and associated electrical equipment “Voltage fluctuations” equipment

of radio disturbance characteristics of Residual, commercial and light industry household electrical applianc es, portable tools and similar electrical apparatus Residual, commercial and light industry

of radio disturbance characteristics of Industrial environment fluorescent lamps and luminaries

broadcast receivers and associated Industrial environment equipment

of radio disturbance characteristics of appliances tools and similar apparatus information technology equipment

EN60555-2 by household appliances and similar

EN60555-3 by household appliances and similar

EN 50082-1 Generic immunity standard Part 1:

declare that the product

Mother Board

GA-7ZMMC

is in conformity with

CE marking (EC conformity marking)

The manufacturer also declares the conformity of abo ve mentioned product with the actual required safety standards in accordan ce wi th LVD 73/23 EEC

EN 60065 Safety requirements for mains operated EN 60950 Safety for information technology equipment

EN 60335 Safety of household and similar EN 50091-1 General and Safety requirements for

electronic and related apparatus for including electrical business equipment household and similar general use

electrical appliances uninterruptible power systems (UPS)

Manufacturer/Importer

Date : Jan. 15, 2001 Name : Rex Lin

(Stamp)

Signature

Rex Lin

7ZMMC Motherboard

Table Of Content

FEATURE SUMMARY........................................................................................................................................1

7ZMMC MOTHERBOARD LAYOUT............................................................................................................... 2

CPU SPEED SETUP.............................................................................................................................................3

SW1: CPU S

PEED SETUP............................................................................................................................... ..... 3

CONNECTORS..................................................................................................................................................... 4

ATX P

OWER........................................................................................................................................................ 4

COM A / V GA / LPT P F

LOPPY CONNECTOR ...........................................................................................................................................4

AME & AUDIO PORT ......................................................................................................................................... 4

G IDE1 (P J2: S J3: CPU F

RIMARY), IDE2 (SECONDARY) CONNECTOR ..........................................................................................5

YSEM FAN....................................................................................................................................................5

AN.......................................................................................................................................................5

ORT.................................................................................................................................4

J7: AUX_IN........................................................................................................................................................5

J8 TEL: T J9: CD A J12: W J13: R JP6: P JP8 / LED1: STR LED C PS/2 K USB 1: R USB 2: F

HE CONNECTOR IS FOR MODEM WITH INTERNAL VOICE CONNECTOR ...................................................6

UDIO LINE IN ........................................................................................................................................6

AKE ON LAN ...........................................................................................................................................6

ING POWER ON (INTERNAL MODEM CARD WAKE UP)..............................................................................6

OWER FAN .................................................................................................................................................7

ONNECTOR & DIMM LED.......................................................................................... 7

EYBOARD & PS/2 MOUSE PORT...............................................................................................................7

EAR USB PORT ....................................................................................................................................7

RONT USB CONNECTOR....................................................................................................................... 8

PANEL AND JUMPER DEFINITION................................................................................................................ 9

BAT1: B J11: 2 J16 /J17/J18: CNR (P

ATTERY..................................................................................................................................................9

X11 PINS FRONT PANEL .............................................................................................................................9

RIMARY OR SECONDARY) SELECT [OPTIONAL] (CNR

 COMMUNICATION A ND



NETWORKING RISER) ........................................................................................................................................ 10

MEMORY INSTALLATION.............................................................................................................................12

BIOS SETUP........................................................................................................................................................13

HE MAIN MENU...............................................................................................................................................14

TANDARD CMOS SETUP .................................................................................................................................15

BIOS F C P PNP/PCI C L L I H S IDE HDD AUTO D S E

EATURES SETUP.....................................................................................................................................17

HIPSET FEATURES SETUP.................................................................................................................................18

OWER MANAGEMENT SETUP...........................................................................................................................20

ONFIGURATIONS .............................................................................................................................. 22

OAD BIOS DEFAULTS......................................................................................................................................23

OAD SETUP DEFAULTS.....................................................................................................................................24

NTEGRATED PERIPHERALS................................................................................................................................25

ARDWARE MONITOR .......................................................................................................................................27

ET SUPERVISOR / USER PASSWORD..................................................................................................................28

ETECTION...........................................................................................................................29

AVE & EXIT SETUP ..........................................................................................................................................30

XIT WITHOUT SAV ING .....................................................................................................................................31

APPENDIX: ACRONYMS.................................................................................................................................32

7ZMMC Motherboard

Feature Summary

Form Factor  24.4 cm x 22.2 cm Micro ATX size form factor, 4 layers CPU

Chipset Pro Savage KM133, consisting of:

Clock Generator

Memory  2 168-pin DIMM sockets

I/O Control  VT82C686B Slots  1 AGP slot supports 4X mode & AGP 2.0 compliant

On-Board IDE  2 IDE bus master (UDMA 33/ATA 66/ATA 100) IDE ports

On-Board Peripherals

Hardware Monitor

PS/2 Connector On-Board VGA On-Board Sound

BIOS  Licensed AMI BIOS, 2M bit flash ROM Additional Features

PCB.

 AMD Athlon

/DuronTM (K7) Socket A Processor

 256K/64K L2 cache on die

 Supports 600MHz ~ 1,2 GHz

 VT8365 Memory/AGP/PCI Controller (PAC)  VT82C686B PCI Super-I/O Integrated Peripheral

Controller (PSIPC)

 ICS 9248BF-141 

100/102/104/106/108/110/112/133 MHz system bus speeds

 Supports PC-100/133 and VCM SDRAM  Supports up to 1.0GB DRAM  Supports only 3.3V SDRAM DIMM

 3 PCI slots supports 33MHz & PCI 2.2 compliant  1 CNR (Communication and Networking Riser) slot

(Not support LAN)

for up to 4 ATAPI devices

 Supports PIO mode 3, 4 (UDMA 33/ATA 66/ATA 100)

IDE & ATAPI CD-ROM

 1 floppy port supports 2 FDD with 360K, 720K, 1.2M,

1.44M and 2.88M bytes

 1 parallel port supports Normal/EPP/ECP mode  1 serial port (COM A)  2 USB ports / 2 USB ports (optional)  CPU/System fan revolution detection  CPU/Power/System fan control  System voltage detection  CPU/System temperature detection

 PS/2 Keyboard interface and PS/2 Mouse interface  Build S3 Savage4 (86C370) in VT 8365

 Support shared memory architecture  Creative CT5880 sound (Optional)  AC’97 CODEC  Line In / Line Out / Mic In / AUX In / CD In / TEL / SPDIF

(Optional) / Game Port / Four Speaker (Optional)

 Support Wake-On-LAN (WOL)  Support Internal / External Modem Ring On  Support USB KB/MS Wake up from S3-S5  Includes 3 fan power connectors  Poly fuse for keyboard over-current protection  Support STR (Suspend-To-RAM) function

7ZMMC Motherboard

7ZMMC Motherboard Layout

JP4

PS/2

USB1

Socket A CPU

COM A

LPT

VGA

VT8365

7ZMMC

DIMM1

GAME & AUDIO

Creative CT5880

AGP 1

J17

PCI1

PCI2

VT82C

686B

PCI3

CNR

J18

USB2

CODEC

J16

DIMM2

J11

TX POWER

JP7

BIOS

JP8

LED1

IDE2

BAT1

JP6

FLOPPY

IDE1

SW1

JP9

JP3

J13

J12

7ZMMC Motherboard

CPU Speed Setup

The system bus speed is selectable at 100MHz. The user can select the system bus speed by DIP switch SW1 .

SW1: CPU Speed Setup

SW1: O: ON, X: OFF

FSB 1 2 3 4

95 O O X O 100XOXX 102 0 0 X X 103 X O X O 107 O X O 0 110 0 X 0 X 113 X X O O 115 X X X 0 133 X X X X

AMD CPU Heat Sink Installation:

Beware: Please check that the heat sink is in good contact with the CPU before you turn on your system.

The poor contact will cause over heat, and might cause damage to your processor.

Connectors

ATX Power

COM A / VGA / LPT Port

Connectors

Pin No. Definition

3,5,7,13,

20 10

15-17

1,2,11 3.3V

4,6,19,20 VCC

10 +12V 12 -12V 18 -5V

8 Power Good 9 5V SB stand by+5V

14 PS-ON(Soft On/Off)

GND

LPT Port

Floppy Connector

Game & Audio Port

COM A

FDD1

VGA

Red Line

Game

Port

Line Out 1

Line In/Line Out 2

MIC In

7ZMMC Motherboard

IDE1 (Primary), IDE2 (Secondary) Connector

IDE 2 IDE 1

J2: Sysem Fan

Red Line

J3: CPU Fan

J7: AUX_IN

Pin No. Definition

1 Control 2 +12V 3 SENSE

Pin No. Definition

1 Control 2 +12V 3 SENSE

Pin No. Definition

1 AUX-L 2 GND 3 GND 4 AUX-R

J8 TEL: The connector is for Modem with internal voice connector

Pin No . Definition

1 Signal-In 2 GND 3 GND 4 Signal-Out

J9: CD Audio Line In

Connectors

Pin No. Definition

1 CD-L 2 GND 3 GND 4 CD-R

J12: Wake On LAN

Pin No. Definitio n

1 +5V SB 2 GND 3 Signal

J13: Ring Power On (Internal Modem Card Wake Up)

Pin N o . Definition

1 Signal 2 GND

7ZMMC Motherboard

JP6: Power Fan

Pin No. Definition

1 Control 2 +12V 3 NC

JP8 / LED1: STR LED Connector & DIMM LED

STR LED Connector External.

PS/2 Keyboard & PS/2 Mouse Port

PS/2 Mous e

PS/2 Keyboard

USB 1: Rear USB Port

DIMM LED

PS/2

Mouse/Keyboard

Pin No. Definition

1 Data 2 NC 3 GND 4 VCC(+5V) 5 Clock 6 NC

6 5

1 2

Pin No. Definition

1 USB V0 2 USB D03 USB D0+ 4 GND 5 USB V1

6 USB D17 USB D1+ 8 GND

USB 2: Front USB Connector

Pin No. Definition

1 +5V

2 GND 3 USB D24 NC

5 USB D2+ 6 USB D3+ 7 NC 8 USB D39 GND

10 +5V

Connectors

7ZMMC Motherboard

Panel And Jumper Definition

BAT1: Battery

☞

is incorrectly replaced.

Replace only with the same or

☞

equivalent type recommended by the manufacturer.

Dispose of used ba tter ie s

☞

according to the manufacturer’s instructions.

J11: 2x11 Pins Front Panel

CAUTION

Danger of explosion if ba ttery

S P K

P−P−P+

GN (Green Switch) Open: Normal Operation

Close: Entering Green Mode

GD (Green LED) Pin 1: LED anode(+)

Pin 2: LED cathode(−)

HD (IDE Hard Disk Active LED) Pin 1: LED anode(+)

Pin 2: LED cathode(−)

SPK (Speaker Connector) Pin 1: VCC(+)

Pin 2- Pin 3: NC Pin 4: Data(−)

RE (Reset Switch) Open: Normal Operation

Close: Reset Hardware System

P+P−P−(Power LED)

Pin 1: LED anode(+) Pin 2: LED cathode(−) Pin 3: LED cathode(−)

PW (Soft Power Connector) Open: Normal Operation

Close: Power On/Off

J16 /J17/J18: CNR (Primary or Secondary) Select [Optional]

(CNR Communication and Networ king Riser)

J16

Panel and Jumper Definition

Onboard AC97 1-2 1-2 1-2 CNR (Primary) 2-3 3-4 3-4 Onboard AC97 CNR (Secondary) [Optional]

JP3: Clear CMOS Function (Optional)

Pin No. Definition 1-2 close Normal (Default) 2-3 close Clear CMOS

J17

J16 J17 J18

1-2 1-2

3-4

J18

1-2

JP4: USB Device Wake up Selection

Pin No. Definition 1-2 close Normal (Default) 2-3 close USB Device Wake up

(If you want to use “USB Dev Wakeup from S3~S5” function, you have to set the BIOS setting “USB Dev Wakeup from S3~S5” enabled, and the jumper “JP4” enabled) *(Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “USB Dev Wakeup from S3~S5”. Remember to save the setting by pressing "ESC" and choose the “SAVE & EXIT SETUP” option.)

7ZMMC Motherboard

JP7: STR Function Enable

1-2 close STR Enable 2-3 close Normal (Default)

JP9: BIOS Write Protect Function

Pin No. Definition

Pin No. Definition 1-2 close Write Protect Enable 2-3 close Write Protect Disable

(Default)

Please set Jumper JP9 to “2-3 close” to enabled BIOS write function when you update new BIOS or new device.

7ZMMC Motherboard

Memory Installation

The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.

Install memory in any combination table:

DIMM 168-pin SDRAM DIMM Modules DIMM 1 Supports 16 / 32 / 64 / 128 / 256 / 512 MB X 1 pcs DIMM 2 Supports 16 / 32 / 64 / 128 / 256 / 512 MB X 1 pcs

Total System Memory (Max 1.0GB)

7ZMMC Motherboard

BIOS Setup

BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.

ENTERING SETUP

Power ON the computer and press <Del> immediately will allow you to enter Setup. If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" bottom on the system case. You may also restart by simultaneously press <Ctrl> − <Alt>− <Del> keys.

CONTROL KEYS

<↑> Move to previous item

<↓> Move to next item <←> Move to the item in the left hand <→> Move to the item in the right hand

<Esc> Main Menu - Quit and not save changes into CMOS Status Page Setup Menu

and Option Page Setup Menu - Exit current page and return to Main Menu

<+/PgUp> Increase the numeric value or make changes

<-/PgDn> Decrease the numeric value or make changes

<F1> General help, only for Status Page Setup Menu and Option Page Setup Menu <F2> Reserved <F3> Reserved <F4> Reserved <F5> Restore the previous CMOS value from CMOS, only for Option Page Setup

<F6> Load the default CMOS value from BIOS default table, only for Option Page

Setup Menu <F7> <F8> Reserved <F9> Reserved

<F10> Save all the CMOS changes, only for Main Menu

Load the Setup Defaults

GETTING HELP

Main Menu

The on-line description of the highlighted setup function is displayed at the bottom of the screen.

Status Page Setup Menu / Option Page Setup Menu

Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press <Esc>.

BIOS Setup

The Main Menu

Once you enter AMI BIOS CMOS Setup Utility, the Main Menu (Figure 1) will appear on the screen. The Main Menu allows you to select from nine setup functions and two exit choices. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.

AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a

STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR SETUP CHIPSET FEA TURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION LOAD BIOS DEFAULTS SAVE & EXIT SETUP LOAD SETUP DEF AULTS EXIT WITHOUT SAVING

ESC : Quit ↑↓←→ : Select Item (Shift) F2 : Change Color F5 : Old Values F6 : Load BIOS Defaults F7: Load Setup Defaults F10: Save & Exit

Time, Date, Hard Disk Type, …

Figure 1: Main Menu

•••• Standard CMOS Setup

This setup page includes all the items in standard co mpatible BIOS.

•••• BIOS Features Setup

This setup page includes all the items of AMI special enhanced features.

•••• Chipset Features Setup

This setup page includes all the items of chipset sp eci al f eatur es.

•••• Power Management Setup

This setup page includes all the items of Green function features.

•••• PnP/PCI Configurations

This setup page includes all the configurations of PCI & PnP ISA resources.

•••• Load BIOS Defaults

Bios Defaults indicates the value of the system parameter which the system would be in the safe configuration.

•••• Load Setup Defaults

Setup Defaults indicates the value of the system parameter which the system would be in the most appropriate configuration.

•••• Integrated Peripherals

This setup page includes all onboard peripherals.

•••• Hardware Monitor Setup

This setup page is auto detect fan and temperature status.

•••• Supervisor password

Change, set, or disable password. It allows you to limit access to the system and Setup, or just to Setup.

7ZMMC Motherboard

•••• User password

Change, set, or disable password. It allows you to limit access to the system.

•••• IDE HDD auto detection

Automatically configure hard disk parameters.

•••• Save & Exit Setup

Save CMOS value settings to CMOS and exit setup.

•••• Exit Without Saving

Abandon all CMOS value changes and exit setup.

Standard CMOS Setup

The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.

AMIBIOS SETUP – STANDARD CMOS SETUP

Date (mm/dd/yyyy) : Tue Jan 25, 2000 Time (hh/mm/ss) : 10:36:24

Pri Master : Auto Pri Slave : Auto Sec Master : Auto Sec Slave : Auto

Floppy Drive A: 1.44 MB 3 ½ Floppy Drive B: Not Installed

Boot Sector Virus Protection : Disabled

Month: Jan – Dec ESC : Exit Day: 01 – 31 ↑↓ : Select Item Year : 1990– 2099 PU/PD/+/– : Modify (Shift)F2 : Color

TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE

Base Memory : 640 Kb Other Memory: 384 Kb Extended Memory: 30Mb Total Memory: 31Mb

Figure 2: Standard CMOS Setup

•••• Date

The date format is <Week> <Month> <Day>, <Year>.

Week The week, from Sun to Sat, determined by the BIOS and is

display-only

Month The month, Jan. Through Dec. Day The day, from 1 to 31 (or the maximum allowed in the month) Year The year, from 1990 through 2099

•••• Time

The times format in <hour> <minute> <sec ond>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00.

•••• Primary Master, Slave / Secondary Master, Slave

The category identifies the types of hard disk from drive C to F that has been installed in the computer. There are two types: auto type, and user definable type. User type is user-definable; Auto type which will automatically detect HDD type.

Note that the specifications of your drive must match with the drive table. The hard disk will not work properly if you enter improper information for this category.

If you select User Type, related information will be asked to enter to the following items. Enter the information directly from the keyboard and press <Enter>. Such information should be provided in the documentation form your hard disk vendor or the system manufacturer.

CYLS. Number of cylind ers HEADS number of heads PRECOMP write precomp LANDZONE Landing zone SECTORS number of sectors

If a hard disk has not been installed select NONE and press <Enter>.

•••• Floppy Drive A / Drive B

The category identifies the types of floppy disk drive A or drive B that has been installed in the computer.

None No floppy drive installed 360K, 5.25 in. 5.25 inch PC-type standard drive; 360K byte capacity.

1.2M, 5.25 in. 5.25 inch AT-type high-density drive; 1.2M byte capacity (3.5 inch when 3 Mode is Enabled).

720K, 3.5 in. 3.5 inch double-sided drive; 720K byte capacity

1.44M, 3.5 in. 3.5 inch double-sided drive; 1.44M byte capacity.

2.88M, 3.5 in. 3.5 inch double-sided drive; 2.88M byte capacity.

BIOS Setup

•••• Boot Sector Virus Protection

If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time. You can run anti-virus program to locate the problem.

Enabled Activate automatically when the system boots up causing a

warning message to appear when anything attempts to access the boot sector or hard disk partition table

Disabled No warning message to appear when anything attempts to

access the boot sector or hard disk partition table. (Default

Value)

•••• Memory

The category is display-only which is determined by POST (Power On Self Test) of the BIOS.

Base Memory

The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system.

The value of the base memory is typically 512 K for systems with 512 K memory installed on the motherboard, or 640 K for systems with 640 K or more memory installed on the motherboard.

Extended Memory

The BIOS determines how much extended memory is present during the POST. This is the amount of memory located above 1 MB in the CPU's memory

address map.

Other Memory

This refers to the memory located in the 640 K to 1024 K address space. This is memory that can be used for different applications.

DOS uses this area to load device drivers to keep as much base memory free for application programs. Most use for this area is Shadow RAM

7ZMMC Motherboard

BIOS Features Setup

AMIBIOS SETUP – BIOS FEATURES SETUP

1st Boot Device Floppy 2nd Boot Device CDROM

3rd Boot Device IDE-0 S.M.A.R.T. for Hard Disks Disabled BootUp Num-Lock On Floppy Drive Seek Dis abled

Password Check Set up

F1 : Help PU/PD+/-/ : Modify

F6 : Load BIOS Defaults F7 : Load SETUP Defaults

ESC : Quit F5 :Old Values (Shift)F2:Color

↑↓→ ←

: Select Item

Figure 3: BIOS Features Setup

•••• 1st / 2nd / 3rd Boot Device

Floppy Boot Device by Floppy. ZIP A: / LS120 Boot Device by ZIP A: / LS120. CDROM Boot Device by CDROM. SCSI Boot Device by SCSI. NETWORK Boot Device by NETWORK. USB FDD Boot Device by USB FDD. IDE-0~IDE-3 Boot Device by IDE-0~IDE-3. Disabled Boot Device by Disabled. ATAPI ZIP C: Boot Device by ATAPI ZIP C:.

•••• S.M.A.R.T. for Hard Disks

Enabled Enable S.M.A.R.T. Hard for Disks. Disabled Disable S.M.A.R.T. Hard for Disks. (Default Value)

•••• Boot Up Num-Lock

On Keypad is number keys. (Default Value) Off Keypad is arrow keys.

•••• Floppy Drive Seek

During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks.

Enabled BIOS searches for floppy disk drive to determine if it is 40

or 80 tracks. Note that BIOS can not tell from 720, 1.2 or

1.44 drive type as they are all 80 tracks.

Disabled BIOS will not search for the type of floppy disk drive by

track number. Note that there will not be any warning message if the drive installed is 360. (Default Value)

•••• Password Check

Setup Set Password Check to Setup. (Default Value) Always Set Password Check to Always.

Chipset Features Setup

AMIBIOS SETUP – CHIPSET FEATURES SETUP

Configure Timing by SPD Enabled

DRAM Frequency Auto SDRAM CAS# Latency Auto

AGP Mode 4X AGP Comp. Driving Auto Manual AGP Comp. Driving CB AGP Fast Write Disabled AGP Aperture Size 64MB ClkGen Spread Spectrum Enabled USB Controller USB Port 0&1

USB Legacy Support Disabled

F1 : Help PU/PD+/-/ : Modify F5 :Old Values (Shift)F2:Color F6 : Load BIOS Defaults F7 : Load SETUP Defaults

ESC : Quit

↑↓→ ←

Figure 4: Chipset Features Setup

: Select Item

BIOS Setup

•••• Configure Time by SPD

Disabled Disable Configure Time by SPD function. Enabled Enable Configure Time by SPD function. (Default Value)

•••• DRAM Frequency

Auto Set DRAM Frequency to Auto. (Default Value) 100MHz Set DRAM Frequency to 100MHz. 133MHz Set DRAM Frequency to 133MHz.

•••• SDRAM CAS# Latency

Auto Detect SDRAM CAS# Latency by SPD. (Default Value) 2 For Fastest SDRAM DIMM module. 3 For Slower SDRAM DIMM module.

•••• AGP Mode

4X Set AGP Mode to 4X. (Default Value) 1X Set AGP Mode to 1X. 2X Set AGP Mode to 2X.

•••• AGP Comp. Driving

Auto Set AGP Comp. Driving to Auto. (Default Value) Manual Set AGP Comp. Driving to Manual.

If AGP Comp. Driving is Manual.

Manual AGP Comp. Driving:

00~FF

•••• AGP Fast Write

Enabled Enable AGP Fast Write function. Disabled Disable this function. (Default Value)

7ZMMC Motherboard

•••• AGP A perture Size

4MB Set AGP Aperture Size to 4MB. 8MB Set AGP Aperture Size to 8 MB. 16MB Set AGP Aperture Size to 16 MB. 32MB Set AGP Aperture Size to 32 MB. 64MB Set AGP Aperture Size to 64 MB. (Default Value) 128MB Set AGP Aperture Size to 128 MB. 256MB Set AGP Aperture Size to 256 MB.

• ClkGen Spread Spectrum

Disabled Disable ClkGen Spread Spectrum. Enabled Enable ClkGen Spread Spectrum. (Default Value)

•••• USB Controller

All USB Port Set USB Controller to All USB Port. Disabled Disable USB Controller. USB Port 0&1 Set USB Controller to USB Port 0&1. (Default Value) USB Port 2&3 Set USB Controller to USB Port 2&3.

•••• USB Legacy Support

Keyboard/FDD Set USB Legacy Support Keyboard / Floppy. KB/Mouse/FDD Set USB Legacy Support Keyboard / Mouse / Floppy. Disabled Disable USB Legacy Support Function. (Default Value)

Power Management Setup

AMIBIOS SETUP – POWER MANAGEMENT SETUP

ACPI Standby State S1/POS RTC Alarm Hour 12 USB Dev Wakeup From S3~S5 Disabled RTC Alarm Minute 30

Suspend Time Out (Minute) Disabled RTC Alarm Second 30 Display Activity Ignore IRQ3 Monitor IRQ4 Monitor IRQ5 Ignore IRQ7 Monitor IRQ9 Ignore IRQ10 Ignore IRQ11 Ignore IRQ13 Ignore IRQ14 IRQ15 Ignore

Soft-Off by Power Button

System after AC Back Last State Resume On Ring/LAN Enabled F1 : Help PU/PD+/-/ : Modify Resume On PME# Enabled F5 :Old Values (Shift)F2:Color Resume On RTC Alarm Disabled F6 : Load BIOS Defaults

RTC Alarm Date 15 F7 : Load SETUP Defaults

Monitor

Instant-Off

ESC : Quit

↑↓→ ←

: Select Item

Figure 5: Power Management Setup

•••• ACPI Standby State

BIOS Setup

S1/POS Set ACPI Standby State to S1. (Default Value) S3/STR Set ACPI Standby State to S3.

• USB Dev Wakeup From S3~S5

Enabled Enable USB Dev Wakeup from ACPI S3, S4 and S5 mode. Disabled Disable USB Dev Wakeup from ACPI S3, S4 and S5 mode.

(Default Value)

•••• Suspend Time Out (Minute.)

Disabled Disable Suspend Time Out Function. (Default Value) 1 Enable Suspend Time Out after 1min. 2 Enable Suspend Time Out after 2min. 4 Enable Suspend Time Out after 4min. 8 Enable Suspend Time Out after 8min. 10 Enable Suspend Time Out after 10min. 20 Enable Suspend Time Out after 20min. 30 Enable Suspend Time Out after 30min. 40 Enable Suspend Time Out after 40min. 50 Enable Suspend Time Out after 50min. 60 Enable Suspend Time Out after 60min.

•••• Display Activity

Ignore Ignore Display Activity. (Default Value) Monitor Monitor Display Activity.

•••• IRQ 3~IRQ15

Ignore Ignore IRQ3 ~IRQ15. Monitor Monitor IRQ3~IRQ15.

• Soft-off by Power Button

Instant-off Soft switch ON/OFF for POWER ON/OFF. (Default

value)

Suspend Soft switch to enter Suspend Mode.

7ZMMC Motherboard

• System after AC Back

Last State System power on depends on the status before AC lost.

(Default Value)

Off Always in Off state when AC back. On Always power on the system when AC back.

• Resume On Ring / LAN

Disabled Disable Resume On Ring / LAN. Enabled Enable Resume On Ring / LAN. (Default Value)

• Resume On PME#

Disabled Disable Resume On PME#. Enabled Enable Resume On PME#. (Default Value)

•••• Resume On RTC Alarm

You can set “Resume On RTC Alarm” item to enabled and key in Data/time to power on system.

Disabled Disable this function. (Default Value) Enabled Enable alarm function to POWER ON system.

If the default value is Enabled.

RTC Alarm Date: Every Day, 1~31 RTC Alarm Hour: 0~23 RTC Alarm Minute: 0~59 RTC Alarm Second: 0~59

PNP/PCI Configurations

AMIBIOS SETUP – PNP / PCI CONFIGURATION

VGA Frame Buffer Size VGA Boot from PCI IRQ 3 PCI/PnP

IRQ 4 PCI/PnP

IRQ 5 PCI/PnP

IRQ 7 PCI/PnP

IRQ 9 PCI/PnP

IRQ 10 PCI/PnP

IRQ 11 PCI/PnP

IRQ 14 PCI/PnP

IRQ 15

F1 : Help PU/PD+/-/ : Modify

F5 :Old Values (Shift)F2:Color

F6 : Load BIOS Defaults

F7 : Load SETUP Defaults

16MB

PCI/PnP

ESC: Quit

↑↓→ ←

: Select Item

Figure 6: PNP/PCI Configuration

BIOS Setup

•••• VGA Frame Buffer Size

8MB Set VGA Frame Buffer Size to 8MB. 16MB Set VGA Frame Buffer Size to 16MB. (Default Value) 32MB Set VGA Frame Buffer Size to 32MB.

• VGA Boot From

AGP Primary Graphics Adapter From AGP. PCI Primary Graphics Adapter From PCI. (Default Value)

•••• IRQ (3, 4, 5, 7, 9, 10, 11, 14, 15)

ISA/ EISA The resource is used by Legacy ISA device. PCI / PnP The resource is used by PCI/ PnP device. (Default

Value)

7ZMMC Motherboard

Load BIOS Defaults

AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a

ESC : Quit ↑↓→← : Select Item (Shift) F2 : Change Color F5 : Old Values F6 : Load BIOS Defaults F7: Load Setup Defaults F10: Save & Exit

Load BIOS Defaults (Y/N)? N

Load BIOS Default except Standard CMOS Setup

Figure 7: Load BIOS Defaults

•••• Load BIOS Defaults

BIOS defaults contain the most appropriate values of the system parameters that allow minimum system performance.

Load Setup Defaults

AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a

ESC : Quit ↑↓→← : Select Item (Shift) F2 : Change Color F5 : Old Values F6 : Load BIOS Defaults F7: Load Setup Defaults F10: Save & Exit

Load SETUP Defaults (Y/N)? N

Load Setup Default except Standard CMOS Setup

Figure 8: Load Setup Defaults

•••• Load Setup Defaults

BIOS Setup

Selecting this field loads the factory defaults for BIOS and Chipset Features which the system automatically detects.

7ZMMC Motherboard

Integrated Peripherals

AMIBIOS SETUP – INTEGRATED PERIPHERALS

OnBoard FDC OnBoard Serial Port 1

OnBoard Parallel Port

Parallel Port Mode EPP Parallel Port DMA N/A Parallel Port IRQ Auto OnBoard IDE Both OnBoard AC’97 Audio Auto OnBoard MC’97 Modem Auto

MPU-401 Disabled

MPU-401 I/O Address 330h-333h

F1 : He l p PU/PD+/-/ : Modify F5 :Old Values (Shift)F2:Color F6 : Load BIOS Defaults F7 : Load SETUP Defaults

Auto Auto Auto

ESC: Quit

↑↓→ ←

Figure 9: Integrated Peripherals

•••• Onboard FDC

: Select Item

Auto Auto detect OnBoard Floppy disk controller. (Default

value)

Enabled Enable OnBoard Floppy disk controller. Disabled Disable OnBoard Floppy disk controller.

• On Board Serial Port 1

Auto BIOS will automatically setup the port 1 address.

(Default Value)

3F8/COM1 Enable on Board Serial port 1 and address is 3F8. 2F8/COM2 Enable on Board Serial port 1 and address is 2F8. 3E8/COM3 Enable on Board Serial port 1 and address is 3E8. 2E8/COM4 Enable on Board Serial port 1 and address is 2E8. Disabled Disable on Board Serial port 1.

• OnBoard Parallel port

378 Enable On Board LPT port and address to 378. 278 Enable On Board LPT port and address to 278. 3BC Enable On Board LPT port and address to 3BC. Auto Set On Board LPT port to Auto. (Default Value) Disabled Disable On Board LPT port.

• Parallel Port Mode

EPP Using Parallel port as Enhanced Parallel Port. (Default

Value)

ECP Using Parallel port as Extended Capabilities Port. Normal Normal Operation. EPP+ECPUsing Parallel port as Enhanced Parallel Port & Extended

Capabilities Port.

•••• Parallel Port DMA

N/A Disable this function. (Default Value) Auto Set Auto to parallel port mode DMA Channel. 3 Set Parallel Port DMA to 3. 1 Set Parallel Port DMA to 1. 0 Set Parallel Port DMA to 0.

•••• Parallel Port IRQ

7 Set Parallel Port IRQ to 7. Auto Set Auto to parallel Port IRQ DMA Channel. (Default

Value)

5 Set Parallel Port IRQ to 5.

• OnBoard IDE

Disabled Disable OnBoard IDE. Both Set OnBoard IDE to Both. (Default Value) Primary Set OnBoard IDE to Primary. Secondary Set OnBoard IDE to Secondary.

•••• OnBoard AC’97 Audio

Auto Auto detect OnBoard AC’97 Audio. (Default Value) Disabled Disable OnBoard AC’97 Audio.

•••• OnBoard MC’97 Modem

Auto Auto detect OnBoard MC’97 Modem. (Default Value) Disabled Disable OnBoard MC’97 Modem.

•••• MPU-401

BIOS Setup

Enabled Enable MPU-401. Disabled Disable MPU-401. (Default Value)

Ps. When Force Feedback joystick is used, MPU-401 needs to be Enable.

•••• MPU-401 I/O Address

330h-333h Set MPU-401 I/O Address to 330h-333h. (Default

Value)

300h-303h Set MPU-401 I/O Address to 300h-303h. 310h-313h Set MPU-401 I/O Address to 310h-313h. 320h-323h Set MPU-401 I/O Address to 320h-323h.

7ZMMC Motherboard

Hardware Monitor

AMIBIOS SETUP – HARDWARE MONITOR SETUP

CPU Fan Speed 7123 RPM System Fan Speed 0 RPM Vcore 1.750 V Vdd 3.050 V Vcc3 3.340 V +5.000V 4.996 V +12.000V 12.166 V

F1 : Help PU/PD+/-/ : Modify F5 :Old Values (Shift)F2:Color F6 : Load BIOS Defaults

F7 : Load Setup Defaults

47°C/116°F 32°C/89°F

ESC: Quit

↑↓→ ←

: Select Item

Figure 10: Hardware Monitor

•••• CPU Temperature. (°

°C / °°°°F)

°°

Detect CPU Temperature automatically.

•••• System Temperature. (°

°C / °°°°F)

°°

Detect System Temperature automatically.

•••• CPU Fan Speed

Detect CPU Fan speed status automatically.

•••• System Fan Speed

Detect System Fan speed status automat ica lly.

•••• Voltage (V) Vcore / Vdd / Vcc3 / +5V / +12V

Detect system’s voltage status automatically.

BIOS Setup

Set Supervisor / User Password

When you select this function, the following message will appear at the center of the screen to assist you in creating a password.

AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a

ESC : Quit ↑↓→← : Select Item (Shift) F2 : Change Color F5 : Old Values F6 : Load BIOS Defaults F7: Load Setup Defaults F10: Save & Exit

Type the password, up to six characters, and pres s <Enter>. You will be asked to confirm the password. Type the password again and press <Enter>. You may also press <Esc> to abort the selection and not enter a password.

To disable password, just press <Enter> when you are prompted to enter password. A message “PASSWORD DISABLED” will appear to confirm the password being disabled. Once the password is disabled, the system will boot and you can enter Setup freely.

The BIOS Setup program allows you to specify two separate passwords: a SUPERVISOR PASSWORD and a USER PASSWORD. When disabled, anyone may access all BIOS Setup program function. When enabled, the Supervisor password is required for entering the BIOS Setup program and having full configuration fields, the User password is required to access only basic items.

If you select “Always” at “Password Check” in BIOS Features Setup Menu, you will be prompted for the password every time the system is rebooted or any time you try to enter Setup Menu.

If you select “Setup” at “Password Check” in BIOS Features Setup Menu, you will be prompted only when you try to enter Setup.

Enter new supervisor password:

Chang /Set /Disabled Password

Figure 11: Password Setting

7ZMMC Motherboard

IDE HDD AUTO Detection

AMIBIOS SETUP – STANDARD CMOS SETUP

Date (mm/dd/yyyy) : Tue Jan 25, 2000 Time (hh/mm/ss) : 10:36:24

Pri Master : Not Installed Pri Slave : Not Installed Sec Master : Not Installed Sec Slave : Not Installed

Floppy Drive A: 1.44 MB 3 ½ Floppy Drive B: Not Installed

Boot Sector Virus Protection : Disabled Month: Jan – Dec ESC : Exit

Day: 01 – 31 ↑↓ : Select Item Year : 1990– 2099 PU/PD/+/– : Modify (Shift)F2 : Color

Type "Y" will accept the H.D.D. parameter reported by BIOS.

Type "N" will keep the old H.D.D. parameter setup. If the hard disk cylinder number is over 1024, then the user can select LBA mode or LARGER mode for DOS partition larger than 528 MB.

TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE

Base Memory : 640 Kb Other Memory: 384 Kb Extended Memory: 31Mb Total Memory: 32Mb

Figure 12: IDE HDD Auto Detection

Save & Exit Setup

AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a

ESC : Quit ↑↓→← : Select Item (Shift) F2 : Change Color F5 : Old Values F6 : Load BIOS Defaults F7: Load Setup Defaults F10: Save & Exit

Type "Y" will quit the Setup Utility and save the user setup value to RTC CMOS.

SAVE to CMOS and EXIT(Y/N)? Y

Save Data to CMOS & Exit Setup

Figure 13: Save & Exit Setup

BIOS Setup

Type "N" will return to Setup Utility.

7ZMMC Motherboard

Exit Without Saving

AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a

ESC : Quit ↑↓→← : Select Item (Shift) F2 : Change Color F5 : Old Values F6 : Load BIOS Defaults F7: Load Setup Defaults F10: Save & Exit

Type "Y" will quit the Setup Utility without saving to RTC CMOS.

Quit without saving (Y/N) ? N

Abandon all Datas & Exit Setup

Figure 14: Exit Without Saving

Type "N" will return to Setup Utility.

7ZMMC Motherboard

Appendix: Acronyms

Acronyms Meaning

ACPI Advanced Configuration and Power Interface

APM Advanced Power Management AGP Accelerated Graphics Port AMR Audio Modem Riser ACR Advanced Communications Riser

BIOS Basic Input / Output System

CPU Central Processing Unit

CMOS Complementary Metal Oxide Semiconductor

CRIMM Continuity RIMM

CNR Communication and Networking Riser DMA Direct Memory Access

DMI Desktop Management Interface

DIMM Dual Inline Memory Module

DRM Dual Retention Mechanism

DRAM Dynamic Random Access Memory

DDR Double Data Rate

ECP Extended Capabilities Port

ESCD Extended System Configuration Data

ECC Error Checking and Correcting EMC Electromagnetic Compatibility

EPP Enhanced Parallel Port ESD Electrostatic Discharge FDD Floppy Disk Device FSB Front Side Bus

HDD Hard Disk Device

IDE Integrated Dual Channel Enhanced IRQ Interrupt Request

I/O Input / Output

IOAPIC Input Output Advanced Programmable Input Controller

ISA Industry Standard Architecture LAN Local Area Network LBA Logical Block Addressing LED Light Emitting Diode MHz Megahertz

MIDI Musical Interface Digital Interface MTH Memory Translator Hub MPT Memory Protocol Translator

NIC Network Interface Card

OS Operating System

OEM Original Equipment Manufacturer

P AC PCI A.G .P. Controller

POST Power-On Self Test

PCI Peripheral Component Interconnect

RIMM Rambus in-line Memory Module

SCI Special Circumstance Instructions

SECC Single Edge Contact Cartridge

SRAM Static Random Access Memory

SMP Symmetric Multi-Processing

SMI System Management Interrupt

USB Universal Serial Bus

VID Voltage ID

AMD 7ZMMC User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table Of Content

Feature Summary

CPU Speed Setup

SW1: CPU Speed Setup

Connectors

ATX Power

COM A / VGA / LPT Port

Floppy Connector

Game & Audio Port

IDE1 (Primary), IDE2 (Secondary) Connector

J2: Sysem Fan

J3: CPU Fan

J7: AUX_IN

J8 TEL: The connector is for Modem with internal voice connector

J9: CD Audio Line In

J12: Wake On LAN

J13: Ring Power On (Internal Modem Card Wake Up)

JP6: Power Fan

JP8 / LED1: STR LED Connector & DIMM LED

PS/2 Keyboard & PS/2 Mouse Port

USB 1: Rear USB Port

USB 2: Front USB Connector

Panel And Jumper Definition

BAT1: Battery

J11: 2x11 Pins Front Panel

Memory Installation

BIOS Setup

The Main Menu

Standard CMOS Setup

BIOS Features Setup

Chipset Features Setup

Power Management Setup

PNP/PCI Configurations

Load BIOS Defaults

Load Setup Defaults

Integrated Peripherals

Hardware Monitor

Set Supervisor / User Password

IDE HDD AUTO Detection

Save & Exit Setup

Exit Without Saving

Appendix: Acronyms
