Chapter 1 AMD Athlon™ 64 Processor Key
Architectural Features
The key architectural features of an AMD Athlon™ 64 processor-based system include AMD64
architecture, integrated DDR DRAM memory controller, HyperTransport™ technology, and many
other features.
Figure 1
shows a block diagram of the AMD Athlon 64 processor architecture.
Figure 1. AMD Athlon™ 64 Processor Architecture
1.1 The AMD64 Architecture
AMD64 architecture allows end users to run existing, installed 32-bit applications and operating
systems at peak performance, while providing a migration path that is 64-bit capable. It is
designed to enable 64-bit computing while remaining compatible with the vast x86 software
infrastructure. AMD64 architecture represents a new class of computing, enabling a single
architecture across 32- and 64-bit environments.
Chapter 1
AMD Athlon™ 64 Processor Key Architectural Features 9
Builder’s Guide for AMD Athlon™ 64 Processor-Based
Desktops and Workstations
31684 Rev. 3.00 September 2004
1.2 Integrated DDR DRAM Memory Controller
The 64-/128-bit wide integrated DDR DRAM memory controller:
• changes the way the processor accesses main memory, resulting in increased bandwidth,
reduced memory latencies, and increased processor performance.
• allows available memory bandwidth to scale with the number of processors and
− can support up to eight registered DDR DIMMs with an AMD Athlon 64 FX processor.
− can support up to four unbuffered DDR DIMMs with an AMD Athlon 64 939-pin
processor.
• has available memory bandwidth of up to 6.4 Gbytes/s (with PC3200).
1.3 HyperTransport™ Technology
The HyperTransport technology of the AMD64 architecture offers the following features.
• A scalable bandwidth interconnection between I/O subsystems and other chipsets
• Up to 8.0 Gbytes/s bandwidth providing sufficient bandwidth for supporting new interconnects
including PCI-X
• Low power consumption (1.2 W) to help reduce the system thermal budget
®
, DDR, InfiniBand, and 10G Ethernet
1.4 Other Features of the AMD Athlon™ 64 Processor
Other features of the AMD Athlon 64 processor include:
• 64-bit wide key data and address paths that incorporate a 48-bit virtual address space and a
40-bit physical address space.
• ECC (error correcting code) protection for L1 cache data, L2 cache data and tags, and DRAM
with hardware scrubbing of all ECC-protected arrays.
• Support for all instructions necessary to be fully compatible with SSE2 technology.
• Two additional pipeline stages (compared to AMD’s 32-bit architecture) for increased
performance and frequency scalability.
• Higher IPC (instructions-per-clock) achieved through additional key features, such as larger
TLBs (translation lookaside buffer), flush filters, and enhanced branch prediction algorithms.
10 AMD Athlon™ 64 Processor Key Architectural Features
Chapter 1
31684 Rev. 3.00 September 2004
Builder’s Guide for AMD Athlon™ 64 Processor-
Based Desktops and Workstations
Chapter 2 AMD Athlon™ 64
Processor-in-a-Box
The best solution for System Builders and Resellers manufacturing pedestal platforms is the
processor-in-a-box (PIB) from AMD. The PIB is available now in a new retail box. The AMD PIB
is covered by a three-year limited warranty.
Figure 2
Figure 2. AMD Athlon™ 64 Processor-in-a-Box
shows the new AMD Athlon™ 64 processor PIB retail box.
Chapter 2
AMD Athlon™ 64 Processor-in-a-Box 11
Builder’s Guide for AMD Athlon™ 64 Processor-Based
Desktops and Workstations
Figure 3
shows the new AMD Athlon 64 FX processor PIB retail box.
31684 Rev. 3.00 September 2004
Figure 3. AMD Athlon™ 64 FX Processor-in-a-Box
The PIB includes the following items:
• The AMD64 processor of choice
• Heatsink and fan, properly sized for the thermal requirements of the processor
• Assembly and installation instructions
• AMD64 processor case sticker
• Double processor packaging allows higher impact resistance adding more protection
• A three-year limited warranty
• Certificate of Authenticity
Please check with your preferred distribution partner for AMD Athlon™ 64 processor-in-a-box.
12 AMD Athlon™ 64 Processor-in-a-Box
Chapter 2
31684 Rev. 3.00 September 2004
Builder’s Guide for AMD Athlon™ 64 Processor-
Based Desktops and Workstations
Chapter 3 Heatsink Installation
This chapter contains instructions for the installation of the AMD Athlon™ 64 processor heatsink.
The AMD Athlon 64 processor heatsink requires the retention frame and the backplate to be
attached to the motherboard. If the retention frame and backplate are already attached to the
motherboard, proceed to step 10. shows the backplate and retention frame for the
AMD Athlon 64 processor heatsink. The hardware shown in Figure 4 may not exactly match the
one provided in a PIB.
Figure 4
Figure 4. Retention Frame and Backplate for the AMD Athlon™ 64 Processor Heatsink
3.1 Heatsink Installation Procedure
Follow these instructions to install the AMD Athlon 64 processor heatsink.
CAUTION: As with all computer equipment, the processor and motherboard components may be
damaged by electrostatic discharge (ESD). Please take proper ESD precautions
when handling any board or processor.
Warning: Do not apply voltage until the heatsink is fully installed. If voltage is applied before
the heatsink is fully installed, the processor will overheat and failure will result.
Read through the entire installation instructions completely to make sure you
understand them before you begin.
1. Place the backplate on a flat surface.
2. Peel the release liner off the backplate. (See Figure 5 on page 14.)
Chapter 3
Heatsink Installation 13
Builder’s Guide for AMD Athlon™ 64 Processor-Based
31684 Rev. 3.00 September 2004
Desktops and Workstations
Figure 5. Backplate Release Liner
3. Gently lift the motherboard by the edges over the backplate.
4. Align the two threaded standoffs on the backplate with the two mounting holes near the socket
on the motherboard. (See Figure 6.)
Figure 6. Motherboard Placed Over Backplate
5. Gently lower the motherboard until the standoffs fit through the holes near the socket and the
backplate makes complete contact with the motherboard.
6. Press firmly on the processor socket to ensure proper contact between the backplate and
motherboard. (See Figure 7 on page 15.)
14 Heatsink Installation
Chapter 3
Loading...
